LaserLine 670T User manual

GB
®
CAR ALARM SYSTEMS
670T INSURANCE APPROVED CAN BUS ALARM
(ORIGINAL REMOTE CONTROL UPGRADE)
USERGUIDE
ISUT670T NEW.p6519/12/2011, 16.061

pag.2
ENGLISH
1) Index.........................................................................................................................................2
2) Introduction...............................................................................................................................3
3) 670TSystem Components.......................................................................................................4
4) Alarmsystem Operation:.........................................................................................................5
4.1 -AlarmSystemArming/Disarming....................................................................................5
4.2 -AlarmCondition...............................................................................................................5
4.3 -AlarmCycle Limitation.....................................................................................................6
4.4 -AlarmTrigger History.......................................................................................................6
5) Problem Solving........................................................................................................................7
6) PassiveArming.........................................................................................................................7
7) UltrasonicExclusions................................................................................................................8
8) EmergencyDisarm/GarageMode By The Electronic Key..........................................................8
9) Arming/Disarm By The Electronic Key.......................................................................................9
10) Programming of New Electronic Key.....................................................................................10
11) TestAproval Numbers(MIRRC).............................................................................................10
12) Homologations....................................................................................................................11
13) TechnicalData.....................................................................................................................11
14) LifetimeWarranty..................................................................................................................12
15) Service Inspection.................................................................................................................14
16) CustomerLifetime WarrantyRegistration..............................................................................15
1-INDEX
THIS PRODUCTMUSTBEINSTALLED
BYSKILLEDAND QUALIFIED PERSONNEL
WARNING
ALARMS MUSTNOTBE STEAM CLEANEDORPRESSUREWASHED.
BEFORE CARRYINGOUT ANYELECTRICAL WORK ONTHE VEHICLE ISOLATETHE SYSTEM
BYREMOVING SYSTEMFUSE/VEHICLE BATTERY OR DAMAGETOTHEALARMMAY
RESULT!
ISUT670T NEW.p6519/12/2011, 16.062

pag.3
ENGLISH
This systemismanufactured fromthe highestquality componentstoensure along trou-
blefree operating life and complywiththeBritish insuranceindustry’scriteriafor vehicle
securityforCategory2 à1(L2 à1) (AFTERMARKET SYSTEMS)[Utilising the original
equipment remote testedto Issue 2 Criteria] product, as evaluatedby Thatcham
(MIRRC).
Note: Category2 à1 (L2 à1) product –670Talarmsystemis onlyto be fittedin conjunction
with aCategory2 (L2) immobiliserto obtainCategory 1 status forthe vehicle security.
The 670T alarmis forvehicles equipped with a12vnegative earth electrical system.
This alarm system is exclusively adeterrent against possible theft.
Inno waycanitbeconsideredasanactualinsurance against theft.
The manufacturerdeclinesany liabilityforfaults or anomaliesin the alarm system, in itsaccesso-
riesorinthe vehicles’selectric equipment due to incorrect installation orunobservant ofspecified
features/standards.
Theseinstructionsareintendedto familiarise you with theirvery simpleoperation.
What is CAN BUS?
CANBUS (ControllerAreaNetwork) isa serialcommunications network that allowsmost ofthe
vehiclemodules(ECU’s)to communicate with each other using data.Onoldvehicle’sthe four
controlswitchesfor the electricwindowsinthe drivers doorwouldhaveatleast2 wiresfrom each
switch goingto each doorwindow on the vehicle. Onnew vehicleswith CAN busonlytwo wiresare
required to comefromthe driversdoor to controlall the electricwindowson the vehicle. This is
achieved byhavingsmallmodules inside each doorthat interprets the CANdataon these two
wires. These modules not onlycontrolthe electricwindowsthey alsocontrolotherequipment like,
central locking, interior/exteriorlighting, electricmirrors, electricseats, etc. The Laserline 6 series
alarmsarecapable ofreading someofthe CANbusdata to interpret when doorsare open/closed,
2-INTRODUCTION
ISUT670T NEW.p6519/12/2011, 16.063

pag.4
ENGLISH
Electronicsocket
RedLED
Receptacle
Electronickey
Ultrasonic detectors
Alarm unit
908 Siren
3-670TSYSTEMCOMPONENTS
Your alarm system consists of the following items:
KEY*Optional. ** Vehicle dependent.
andwhen doorsare lockedorunlocked.Usingthisdata means thereare less connectionsfromthe
alarmto the vehicle.
ISUT670T NEW.p6519/12/2011, 16.064

pag.5
ENGLISH
4-ALARM SYSTEM OPERATION
Toarmthealarm,pressthelockordeadlock** buttononthevehiclesoriginalremotecontrol;thealarm
maygivetwoacoustictones*andthedirectionindicatorlightsmayflashanumberoftimes**toindicate
thatthe systemis now armed.
Once armed,the alarmsystemwilloperate the comfortclosure**/window closure* ifthesefunctions
havebeenincorporated.
The redLEDinthe receptaclewill remain on for40 seconds(pre-alarm time), then beginto flashto
indicate the alarmsystemisfullyarmed.
To disarm the alarm,pressthe unlockbutton on the vehicleoriginal remote control;the alarmmay
giveoneacoustictone* andthedirectionindicatorlightsmayflashanumberoftimes** toindicatethat
the alarm system isnow disarmed.
Ø In some vehicles, when usingthe mechanical key forthe doorlocking, the alarm system will
arm.Itis possibleinsome cases,when unlockingthe vehicle bythe mechanicalkey, during
the pre-alarm time ofarming, the alarmsystemwilldisarm.For security reasonswhen the
alarmis fullyarmed the systemcanonly bedisarmedby remote controlorby the electronic
key.
Ø Comfortclosure isafeaturethat may alreadybe incorporatedinto the original remote control
of the vehicle. Checkvehicleuserguidefor operation.
Ø Ifthe alarmasbeen triggered bymanuallyopeningadoor itmaybe necessaryto close the
door,then lockandunlock with the original remote controlto disarmthe alarm.
4.2 -ALARM CONDITION
When fully armedif asensoris activated, the system will generate analarm condition:direction
indicatorsmayflashandthe sirenwillsoundfor27seconds(alarmcycle).Attheendofthealarmcycle,
ifthe samesensorisstillactivated,the alarmwill generate an alarmcycle again.
4.1-ALARMSYSTEM ARMING/DISARMIG
ISUT670T NEW.p6519/12/2011, 16.065

pag.6
ENGLISH
Itispossibleto know the lastalarm triggerthathasoccurred byturningon the ignition after dis-
arming the alarmsystem.
Each alarm causeisassociated to anidentification flashcode:
The alarmcause isdisplayedbythe LED flashing 5timesthe alarmidentification flashcode, e.g.:
4.4-ALARMTRIGGERHISTORY
Bonnet/
Boot
opening
alarm =X5
The systemwillautomaticallyexcludethe sensor,which hasgenerated8alarmcyclesin one
armed period.Allthe othersensors will continue toprotect thevehicle. The maximum
numberofalarmcyclesfor everysensoris8, exceptfor power supplyinterruption to siren
(10alarm cycles).
Note: Ifasensorcontinuesto remainactivatedwhilstinthe pre-alarmtime, the system will
generate analarmcondition. When the alarm systemis next disarmedashorterthan normal
flash** ofthe direction indicatorlights andan accoustictone willbeproduced to indicate that
asensor wasactivatedwhilstarming.Toidentifythe sensor thatwasactivated,consult the
“ALARMTRIGGER HISTORY”
4.3-ALARMCYCLELIMITATION
2FLASHES/PAUSE: the IGNITION KEY sensor generatedan alarmcondition
3FLASHES/PAUSE: the DOOR/HATCH sensorgeneratedan alarmcondition
4FLASHES/PAUSE: the BONNET/BOOTsensor generatedanalarm condition
6FLASHES/PAUSE: the ULTRASONICsensorgeneratedan alarmcondition
FLASH CODES ALARM CAUSE
ISUT670T NEW.p6519/12/2011, 16.066

pag.7
ENGLISH
5-PROBLEMSOLVING
Ifyou find you haveto get closerto the vehicleto unlock/disarmthe alarm,this is normally
aindication thatthe originalremote controlbatteriesmayneedreplacing. Referto vehicle’s
user guide for replacing the remote batteries.
If youralarmsounds for no apparent reason, pleasereferto the “ALARMTRIGGER HISTORY”
forpossiblecondition. Possiblecausesofthe alarm condition could be:
-Vehiclehasbeen tamperedwith.
-Windows/sunroofarenot fullyclosed.
-Doors/boot/bonnet arenot fullyclosed.
-Check thatthe airventshavenot been left open. Air movement withinthe vehiclemaytrigger
youralarm.
-Check the doors/boot/bonnet contact switchesoperate correctly.
-Articles inside the vehicle aremoving e.g. jacket, hangingtoysoraccessories.
6-PASSIVEARMING*
This function,ifenabled, allows thealarmtoautomaticallyarm after 60seconds after
switchingthe ignitionOFF.However,whenarmedthroughthis function it will not activate
thecomfortoutput/ultrasonicsensors. Thenext alarm disarmingcanbeactivatedbythe
EMERGENCY ELECTRONIC KEY orthe ORIGINALREMOTE -inthis caseyou may needto prompt
thesystem for locking andthen promptitagainforunlocking,inorder forthe alarm to be
synchronisedagain withthelock status.
ISUT670T NEW.p6519/12/2011, 16.067

pag.8
ENGLISH
7-ULTRASONICEXCLUSION
Ultrasonicexclusion (e.g. ifyou want to usethe alarmwhilst keeping vehiclewindowsopen);
Todisabletheultrasonicsensors foronearmingcycle:
ŒWith the alarmsystemdisarmedandthe ignition inthe offposition;
•Insertthe electronickeyinto the receptacle twice within2seconds.The statusLEDwill
illuminate brieflyforeach insertion ofthe electronic keyand maybe followedbyone
short acoustic tone*,will indicate theexclusionof ultrasonicsensors.
ŽExitthe vehicleandarm the alarmwith the vehicle'soriginalradio control or insert the
electronic keyandexitvehicle.
Disarming the alarmandrearmingwill switch the ultrasonicsensorsbackON.
Disablingthe ultrasonic sensorsalsocausesthe optional window closing*/comfortclosing**
tobedisabled.
8-EMERGENCYDISARMING/GARAGEMODEBYTHEELECTRONICKEY
Todisarmwith the electronic key,ifthe alarm wasoriginally armed with the vehicles remote
control:
Πenter thevehicleusing thevehiclekeyin the doorlock (alarm willsound);
• insert the electronic keyintothe receptaclesocket(alarm will stop sounding andLED
inthereceptaclewill switchOFFandalarm will enterintoGarage Mode).
When disarmedinthiswaythe alarm willenterGarageMode andwillnot arm when the
remote control isnext usedto lock the vehicle. With the ignition Onor Offthe LEDwill flash
briefly every 16 secondsto indicate thatthe alarmisin GarageMode.
ISUT670T NEW.p6519/12/2011, 16.068

pag.9
ENGLISH
Toarm/disarm withthe electronickey,if theoriginally vehiclesremote controlisnot
available/not working.
Toarm the alarm:
Œarm thealarm by inserting anelectronic keyonceinto thereceptacle socket,LEDin re-
ceptaclewill illuminate(pre-settime);
• Exitthe vehicleand manuallylockthe vehiclewith keywhilstthe LED is illuminated(pre-
set time).
When the alarmisarmed using the electronickeythe ultrasonic sensorsandanyoptional
windowclosing*/comfort closing**aredisabled.
Todisarm the alarm:
Πmanuallyunlockthe vehicleandenterthe vehicle;
• if the electronickey is insertedinto the receptacle within10 secondsof entering vehicle
the alarm will disarmwithout causinganalarm condition.
9-ARM/DISARMBY THEELECTRONICKEY
ToexitGarageModeand beableto arm/disarmthe alarmwith the vehiclesremote control:
Πinsert an electronickeyinto the receptaclesocket, LED inreceptacle willilluminate
(pre-set time);
• whilst the LEDisilluminated (pre-set time) insertanelectronickey forasecondtimeinto
thereceptacle socket (alarm will disarm).
Now when the vehicleislockedwith the vehicles remote control the alarmwillarm.
ISUT670T NEW.p6519/12/2011, 16.069

pag. 10
ENGLISH
ΠWith the alarmdisarmed;
• Open bonnet;
Ž Turnthe ignition keyONandOFF fourtimeswithinfourseconds,makingsurethaton
the fourth cyclethe ignition is left in the ONposition;
• The alarmwillindicate the startingofthe electronic procedureby,3acousticsignalsand
3flashesofthe statusled.;
• Insert each electronickey to belearnt to the alarminto the receptaclesocket (LEDwill
flashonceforeach key learnt);
‘ TurnOFF the ignition;procedurecompletion willbeindicatedby3acousticsignalsand
3flashesofthe receptacleLED.
’ Closebonnet.
ØYou canprogramamaximumof4electronickeys.
ØElectronickeys not programmedduringthe lastself-learningsession will beautomati-
cally cancelledfrom the alarmmemory.
KEY*Optional. ** Vehicle dependent.
10-PROGRAMMINGOFNEW ELECTRONICKEY
Theprocedureallows you toprogramnewelectronickeys.
To carry outtheprocedure, thebonnetswitch mustbe fitted. Note: Notall installations
requirethe bonnet switch to be fitted,ifthis is the casepleasecontact your originalinstaller.
Thendo thefollowing:
670T -MIRRCReference Number:Category2-1TU2-1426/1207
670T -MIRRCReference Number: Category L2-1TUL1-151/1207
11 -670T TEST APPROVAL NUMBER
ISUT670T NEW.p6519/12/2011, 16.0610

pag. 11
ENGLISH
This product complies with the requirements of applicable European directives.
You willfindalabelon the alarm unit stating the homologation number, obtained accordingto the
Europeandirective 95/56/CE. homologationmark
product
12-HOMOLOGATIONS
manufacturer e24
XXXXXXXX12V
AI-00XXXX
670 02 xxxx
244 02 0035
670T
POWERSUPPLY............................................................................................9-15V negative ground
CURRENT ABSORBEDWITH ALARM ARMED (with ultrasonic).............................................<10 mA
PRE-ALARMTIME..................................................................................................................40 sec.
DELAY ENTRY TIME (armedby passive arming or electronickey)........................................10 sec.
ALARMCYCLEPERIOD........................................................................................................27 sec.
OPERATINGTEMPERATURE......................................................................................-30°Cto 70°C
DIRECTION INDICATORLIGHTRELAYCONTACT CAPACITY.....................................................8A
908SIREN
POWERSUPPLY.......................................................................9-15V negative ground
CURRENT ABSORBEDWHEN CHARGING.........................................................................<25 mA
CURRENT ABSORBED WHENFULLYCHARGED...............................................................<2.5 mA
13-TECHNICALDATA
ISUT670T NEW.p6519/12/2011, 16.0611

pag. 12
ENGLISH
Product warranty coversunits to be free from defects inmanufacture for the lifetime
ownership oftheoriginalvehicle, inaccordancewith theterms andconditionsof this
warranty document.
Any product,whichisdeemedtobe defective,will bereplacedorrepaired.Accessories
includingelectronickeys and additional modules are guaranteed foraperiodof12 months
fromdate ofinstallation.
1.Productmust beinstalled byanauthorisedqualifiedinstaller.
2.Ifproduct is transferredby anauthorisedinstalleronto anothervehicle then inthis
casethe warranty revertsbackto 2yearsfromthe date ofthe originalinstallation.
3.Warranty isnot transferable bythe original customerto otherowners ofthe product
oraccessory.
4.The customer mustcomplete and returnthe warrantyregistration document within
21 days fromdate of purchaseinorderfor the warrantyto be valid.
5.The warranty covers productonlyandnotthe quality of theinstallation.The
warranty forinstallation is providedby the installer. Wecannot beheld responsible
for costsarisingdue to incorrectinstallation.
6.Allwarrantyclaims must be directedthroughthe originalinstaller,accompaniedby
the originalinvoice, detailingdate ofinstallation and annualservice record.Failure
to dothis will renderthe warrantyinvalid.
7.Continuance of product warrantyis subject to an annual product service inspection
forwhich asmallcharge may be leviedbyanyauthorisedinstaller.Evidence of
serviceinspectionrecord must be providedinsupport ofwarranty claims.
8.Warranty does not cover costs incurredfor breakdown assistance orvehicle
recovery, due toproductor accessory failure.Warranty doesnotextend to
reimbursementfordamage duetodefects inproducts or accessories.
TERMSAND CONDITIONS
14-LIFETIMEWARRANTY
ISUT670T NEW.p6519/12/2011, 16.0612

pag. 13
ENGLISH
Warranty will not bevalid due to the following:
1.Poorresponse to transmittersdue to abnormallyhigh electromagnetic interference.
2.Low battery voltage in transmitters.
3.Abuseormistreatmentof any productor accessory.
4.Loss ordamagedue to accident, fire, lightening, explosion, flood or water, war or
civildisturbances.
5.Damage causedby externalelectricalsource orfrom abnormalvariation or failure
ofpower supply.
6.Failure caused by installation ofaccessories not approved by the product
manufacturer.
7.Failure ofproduct occurring outside GreatBritain.
8.Replacementofdefectiveparts withintheguarantee perioddoes notinclude
consumable parts or includelabour.
9.Ifproduct is repairedby anon authorised installertheproductwill ceaseto be
coveredbythe warranty.
10.Originalmanufacturer negligence.
EXCLUSIONS FROMWARRANTY
CONSUMERSUMMARY
All warrantiesarelimitedto the durationofthis warranty.
This is the complete warranty andno otherexpress orimpliedwarrantyisvalid.Nothing
inthiswarranty shallaffectyour statutoryrights.
NOTE
Manufacturerdeclines anyresponsibilityfor damage ofthealarm/immobiliser and the
vehicle electricalsystemduetoWRONGINSTALLATION OR TAMPERING.
LASERLINE SpARESERVESTHE RIGHT TO EFFECT CHANGESOFTHE PRODUCT WITHOUT
FURTHER NOTICE.
ISUT670T NEW.p6519/12/2011, 16.0613

pag. 14
ENGLISH
15-SERVICE INSPECTION
1YRS 2YRS3YRS 4YRS
PLEASE NOTE7 YRS6 YRS5 YRS
Installer’s Stamp
Cert. No.
Reg. No.
Date.
Signature
The above Service
Inspection must be
carried out in order
to ensure the
validity of the
Customer Lifetime
Warranty
Installer’s Stamp
Cert. No.
Reg. No.
Date.
Signature
Installer’s Stamp
Cert. No.
Reg. No.
Date.
Signature
Installer’s Stamp
Cert. No.
Reg. No.
Date.
Signature
Installer’s Stamp
Cert. No.
Reg. No.
Date.
Signature
Installer’s Stamp
Cert. No.
Reg. No.
Date.
Signature
Installer’s Stamp
Cert. No.
Reg. No.
Date.
Signature
ISUT670T NEW.p6519/12/2011, 16.0614

pag. 15
ENGLISH
Alarm/Immobiliser Model No. ………...…………….............Make………………………..............…….
AccessoriesFitted………………………….............................Model………………….....................……
DateofInstallation……………………………….....................Reg.No.……….…..........……….....…….
CustomerName………………………………........................YearofManufacture………….................
Address………………………………........................………………………………...............……………..
.................................................................................................................................................................
Postcode………………………......................…...........TelNo...................……….............……………
InstallerName………………….......…………….........Account No. …...................……………....……..
Address………………………………………………………………………………….........………………...
Postcode…………………………………………….........Tel No. ……................…..................…………
Ihaveread andunderstood thetermsandconditions of theCustomerLifetimeWarranty.
CustomerSignature.......................................................................
16 -CUSTOMER LIFETIME WARRANTYREGISTRATION
IMPORTANT NOTE
FAILURE TOCOMPLETE ANDRETURNTHIS CARD WILLRESULTINYOURWARRANTY
BECOMINGVOID.
ISUT670T NEW.p6519/12/2011, 16.0615

pag. 16
ENGLISH
Return to:
Laserline S.p.A. Limited
73, Manchester Road
Woolston
Warrington
Cheshire
WA1 4AE
ISUT670T NEW.p6519/12/2011, 16.0616

pag. 17
ENGLISH
NOTES
ISUT670T NEW.p6519/12/2011, 16.0617

pag. 18
ENGLISH
NOTES
ISUT670T NEW.p6519/12/2011, 16.0618

pag. 19
ENGLISH
NOTES
ISUT670T NEW.p6519/12/2011, 16.0619

cod. ISUT670T-new FILENAME: ISUT670T.P65
OurcommissionedSales andSupport Agents intheUK are
LaserlineS.p.ALimited
73, Manchester -Road Woolston -Warrington -Cheshire WA1 4AE
DealerStamp
ISUT670T NEW.p6519/12/2011, 16.0620
