Laskomex MVC-8151 User manual

COLOR MONITOR
MVC-8151
for Laskomex digital video door entry systems

- 2 -
Color monitor MVC-8151
Table of Contents
1. Terms of use and operation ................................................................... 3
2. Purpose and functions of the monitor ........................................................ 3
3. Using the monitor .............................................................................. 4
Conversation ........................................................................................ 4
Switching to simplex mode ................................................................... 4
Control of the electric strike and drive of the entrance gate ............. 5
Connection to porter .............................................................................. 5
Adjusting the call volume ................................................................... 5
Adjusting the conversation volume, brightness and color saturation........... 5
Image preview from cameras ................................................................... 5
4. Using the door phone .............................................................................. 6
Using the code lock function ................................................................... 6
Using the lock function in the mode with building numbering ............. 6
Using electronic keys .............................................................................. 6
Using the proximity electronic keys (RFID) .............................................. 6
Using the touch electronic keys (iButton) .............................................. 6
The „quick entry” function .................................................................... 7
User menu (for CD-2502 and CD-3100 digital door phones) ............. 7
Change of tone, call volume and number of rings ................................... 8
Code change of the code lock .................................................................... 9
Registering a new electronic key ......................................................... 9
Exit from User menu ............................................................................... 9
5. Installation and activation of the monitor .............................................. 10
Execution of electrical installation ......................................................... 10
Monitor installation ............................................................................... 10
Connecting an additional camera or COMMAX panel ......................... 11
Connecting the doorbell .................................................................... 11
Connecting an additional device ......................................................... 11
6. Programming the number and activating the monitor ......................... 11
Setting the monitor number .................................................................... 12
Video line conguration ............................................................................... 12
Adjusting the monitor ............................................................................... 14
7. Operation of the „installation procedure” ..................................................... 14
8. Doorbell function .......................................................................................... 15
9. Maintenance .......................................................................................... 15
10. Technical data and wiring diagram ......................................................... 16

- 3 -
Color monitor MVC-8151
1. Terms of use and operation
• Monitor connection should be made by a specially trained installer.
• Monitor should be connected to the system with power supply cut off. Power supply sho-
uld be switched on after making sure that other connections are correct.
• Monitor should be installed in an easily accessible place in such a way that it does not
pose a threat to users.
• It is forbidden to connect the monitor to the systems other than door entry systems made
according to the requirements and recommendations of the producer.
• The location of connection receptacles and control elements is shown on a sticker placed
on the monitor rear cover.
• Monitor should not be exposed to high temperature or moisture; it should be protected
againstoodingwithanyliquids.
• Openings in monitor casing should not be covered because this can result in its impro-
per operation.
• Do not insert any metal objects into the openings in monitor casing because this can cau-
se the equipment damage.
• Connection to the monitor terminals electrical supply from sources other than the recom-
mendedpowersupplyisforbiddenbecausethiscancausemonitordamageorre.
• It is recommended to use KSAS0181500120 or SAPC15018EU power supplies.
• Self-repair of devices included in the door entry system is forbidden because this results
in loss of warranty.
• Nienależyprzykładaćuchadootworówgłośnikawmonitorze,ponieważwprzypadku
pojawieniasięgłośnejsygnalizacjiakustycznejmożenastąpićuszkodzeniesłuchu.Do
notputyoureartothespeaker’sopeningsinthemonitor,asyoumayheardamageincase
of loud sound signaling.
• Do not remove the cover on the programming connector. Removal of the cover will void
the warranty and may lead to permanent damage to the monitor (Figure 6).
2. Purpose and functions of the monitor
MVC-8151 is a color monitor dedicated to Laskomex digital video door entry systems. The
monitor is a hands-free device that allows you to talk and watch the caller on the screen. The
monitorisequippedwithilluminatedeldsthatactasbuttons.Touchinganyoftheeldsdi-
sables the highlighting of the others. The monitor has elements that allow you to adjust the
volume of the call and the brightness and color of the image. The monitor is equipped with
a gong module – after connecting the bell button it can act as a standard doorbell. The moni-
torcanbeconnectedwithaoorpanelworkingintheCommaxsystemoranyexternalca-
mera,forexampleadomecameraplacedinfrontoftheentrancetotheat.

- 4 -
Color monitor MVC-8151
• Preview–switchingonandoffthepreviewfromthecamera,endingtheconnection,
extendingtheconnectiontime,extendingthepreviewtime.
• Control–controlofthegatedrive,lighting,etc.
• Lock–controloftheelectricstrike,stepadjustmentofthecallvolume.
• Conversation–receivingandmakingcalls,switchingonthemonitor-panelaudiopath.
PREVIEW
CONTROL
CONVERSATION
PROG
BRIGHTNESS
COLOT
VOLUME
(conversation)
VOLUME
(call)
KEY(LOCK)
PROG
LED1 (green)
LED2 (red)
LED3 (yellow)
LED4 (blue)
Figure 1. Monitor MVC-8151
3. Using the monitor
Conversation
Anattempttoestablishaconnectionwiththemonitorissignaledbythebell,atthesame
time the caller’s image will appear on the screen.
Tomakeacall,presstheCONVERSATIONbuttonduringthecallorwithin30secondsafter
the call.
Thetalktimeislimitedandis120secondsbydefault.10secondsbeforetheendofthistime,
short beeps will appear in the loudspeaker indicating that the end of the call is approaching.
The conversation can be ended at any time by long pressing the PREVIEW button.
Switching to simplex mode
Ifthereisalotofnoiseintheplacewherethepanelisinstalled,itmaybedifculttocon-
ductaconversation.Thenyoucanusethesimplexmode.Todothis,usetheCONVERSA-
TIONbutton.Aslongasthebuttonispressed,thesoundistransmittedinonlyonedirec-
tion – from the monitor user to the person at the external panel.

- 5 -
Color monitor MVC-8151
Control of the electric strike and drive of the entrance gate
The LOCK and CONTROL buttons are active only during the call (conversation).
Pressing the LOCK button will release the entrance lock (electric strike or electromagnetic
lock),whichisindicatedbytheLED2blinking.
LongpresstheCONTROLbuttonwillactivatetheadditionaldevice,forexamplethedrive
of the entrance gate. Switching on the additional device is signaled by the LED4 which will
turn on for approx. 1 second.
Connection to porter
Tosendanoticationtotheportermodule,longpresstheCONVERSATIONbutton.
ReceivingthenoticationissignaledbyalongblinkofLED1andLED2.Ifthenotication
isnotreceived,LED1andLED2willbrieyashseveraltimes.Theportercanpickupthe
call immediately or call later.
Adjusting the call volume
The call volume can be adjusted in two ways:
- using the User menu (adjustment in the door entry system – Figure 3).
-usingtheKEYbuttoninthemonitor.Inthiscase,theselectedvolumeissignaledbyLED1
andLED2(LED1–loud,LED2–quiet,LED2ashing–calldisabled).
FastashingLED1orLED2meansthatthelineisbusy.
Adjusting the conversation volume, brightness and color saturation
Tochangetheconversationvolume,imagebrightnessorcolorsaturation,usetheVOLU-
ME,BRIGHTNESSandCOLORpotentiometersontherightsideofthemonitor(Figure1).
Image preview from cameras
Thisfunctioncanonlybeusedifthelineisnotbusy.AfterpressingthePREVIEWbutton,
thecameraimagewillappearinthedoorentrypanel.Inmulti-entrancessystem,images
from several cameras may appear sequentially on the screen. Repeated pressing of the PRE-
VIEW button will turn on the image from the additional camera (if connected).
Thepreviewtimeislimitedtoapprox.2minutes,theapproachingmomentofturningoffis
indicated by the LED1 blinking. Press the PREVIEW button to extend the preview for ano-
ther minute. The installer can block the possibility of preview from cameras.
Note!
The blink of the image that may appear when the preview function is activated is not a symp-
tom of incorrect operation of the device.

- 6 -
Color monitor MVC-8151
4. Using the door phone
Using the code lock function
• EntertheapartmentnumberandconrmwiththeKEYbutton.
• Whenatthedisplaythe----messageappears,enterthefour-digitlockcode.
• Iftheenteredcodeiscorrect,theentrylockwillbereleased.
• Iftheenteredcodeisincorrect,Errmessagewillbedisplayed.
• The use of a code at the subordinate entrance is signaled in the receiver. Providing cor-
rectcodesignalsthreeshortbeeps,anincorrect–twolongones.
• The code lock function can be blocked by the installer. At the main entrance we use the
same code as at the subordinate entry.
Using the lock function in the mode with building numbering
• Enter the building number from the keyboard at the main entrance.
• Wait until L--- message appears in the display.
• EntertheapartmentnumberandconrmwiththeKEYbutton.
• Whenthe----messageappears,enterthefour-digitcode.
Using electronic keys
Touseelectronickeys,theymustberegisteredinthedoorphonememoryinadvance.
The keys are registered by the installer or user. The door phone user can register the key
using the User menu function.
Using the reader can be blocked by the installer.
Afterapplyingtheregisteredkeytothereader,theentrywillbeunlockedandthedisplay
will show the digit for a moment. This is the key position in the door phone memory. This
numberisworthremembering,becauseitcanbeusefulifyouneedtodeletethekey.
The use of the key can be signaled by three short beeps in the receiver. If an unregistered key
isappliedtothereader,thedotvisibleonthedisplaywillashbriey.
Using the proximity electronic keys (RFID)
• Takethekeyclosetothedoorphonekeypad,whichactasareader.
• Keep the key in such a way that it will be turned to the keyboard with largest possible sur-
face. This position ensures reading from a greater distance.
Using the touch electronic keys (iButton)
• Apply the key to the TM reader.
• Lightly press the key to the lateral edge of the reader.

- 7 -
Color monitor MVC-8151
a) b)
Figure 2. Using electronic keys: a) iButton touch keys, b) RFID proximity keys
The „quick entry” function
The function is available in the door entry system with the main entrance and the subordi-
nate entrance (entrances).
Thevisitormustrstcallthechosenapartmentbyselectingitsnumberinthepanelatthe
mainentrance,thenhemustrepeatthisoperationattheentrancetothestaircase.Ifthe„qu-
ickentry”functionwasactivatedaftertherstconnection,thenwhenyoutrytoconnect
fromthedoorphoneattheentrancetothestaircase,thedoorlockingelectricstrikewillbe
automatically released.
The function remains active for approx. 10 minutes from the time of activation.
Activationofthe„quickentry”function:
• Answer the call.
• Unlock the entrance by pressing the LOCK button.
• Press the CONVERSATION button – in the loudspeaker will be heard short sounds with
increasing altitude signaling the activation of the function.
• End the conversation by pressing the PREVIEW button.
• AgainpressingtheCONVERSATIONbuttonbeforethecallendswilldisablethe„qu-
ick entry” function.
User menu (for CD-2502 and CD-3100 digital door phones)
The User menu is a mechanism that allows users of digital door phones to change some pa-
rameters of the door phone work. The changes concern the selected apartment number (the
premises where the menu was activated). The introduced changes are then permanently sto-
red in the door phone’s memory.
Thankstothis,eachusercanadjusttheworkofthedoorphonetohisexpectations.

- 8 -
Color monitor MVC-8151
call volume
call tone number of rings
Figure 3. User menu
User menu allows to:
• changethecalltone,
• changethecallvolume,
• setthenumberofrings,
• change the code of the code lock.
• register electronic keys.
To make changes a tenant must activate User menu. The help of the person in the apartment
isneededforthis.ToactivatetheUsermenu,performthefollowingsteps:
• Establish a connection with the apartment (only from the subordinate entry panel).
• Press the button KEY in the panel and still pressing it ask the person in the apartment to
presstheLOCKbuttoninthemonitorvetimes.
• Activation of the function is signaled by short beep in the monitor’s and the external pa-
nel’s loudspeaker as well as by message [OPC] displayed temporarily on the external pa-
nel`s display.
• Finish the conversation.
• Entertheapartmentnumber,thenpresstheKEYbuttonandenterthecodeofthecode
lock.Thedisplaywillshowthesymbolsdeningthecurrentstatusofindividualsettings.
In Figure 3 is shown the view of the display after switching on the User menu (view for the
default parameter values).
Change of tone, call volume and number of rings
• [1]Therstsignonthedisplaydenesthecalltone(0...7).Thecallsignalcanbechan-
ged by pressing the button marked with number [1].
• [2]Thesecondsignonthedisplaydenesvolumeofcallsignal(G–loud,N–incre-
asing,C–quiet,U–moderate).Theselectionofanincreasingsignalissensiblewhenthe
number of call signals is higher than 1. The volume is controlled with button [2].
• [3]Thethirdsignonthedisplaydenesthenumberofrings(1-8)–decideshow
long the door entry handset rings. Number of signals is controlled with button [3].

- 9 -
Color monitor MVC-8151
Code change of the code lock
This option can be blocked by installer.
• Activate User menu.
• Select[0]button.Therewillappearfourhorizontallines.
• Enter the current installer code. This step can be omitted if the installer decides so.
• Foramoment[NEU]and[CODE]messagesandthenfourhorizontallineswillappear.
• Enter the new code.
• Enter the new code again.
Registering a new electronic key
This option can be blocked by installer.
• Activate User menu.
• Select [8] button. The message [ADD] will appear on the display.
• Apply the electronic key to the reader.
• Message [NEU] means that the key has been stored in the memory with the assignment
totheapartment.Ifapreviouslyregisteredkeyhasbeenappliedtothereader,themessa-
ge [OLD] will appear on the display.
Exit from User menu
To exit from edition of User menu (not to exit from the whole procedure) in order to check
theoperationofsettingsandmakelaterpossiblechanges,presstheLOCKbutton.Thenthe-
re is a possibility to make a call.
Todenitivelyexitthewholeprocedurepressthe[C]button.Inthiscasere-enteringthe
menu requires repeating the entire procedure from the beginning.
After4minutesofinactivity,accesstotheUsermenuwillbeturnedoffautomatically.

- 10 -
Color monitor MVC-8151
5. Installation and activation of the monitor
Execution of electrical installation
Detailed recommendations regarding the electrical installation of the video door entry sys-
tem can be found in the operating instructions of the CD-2502 or CD-3100 digital door pho-
nes.
The installation should be done using video splitters. You need one splitter for four mo-
nitors.Thesplittercanactasacentralpowersupply,providedthatitispoweredfromthe
15VDC/4A power supply. With this connection the distance between the splitter and the mo-
nitorshouldnotexceed30m,accordingtothetableinFigure4.Themonitorcanalsobepo-
weredfromalocalpowersupply13,5V/1,2A.Thisisrecommendedifthedistancebetween
the external panel and the monitor exceeds 30m. The video signal should still be fed from
the CVR-2 splitter. For video installations it is recommended to use UTP cat.5.5.
Monitor installation
Monitorshouldbemountedinsidethebuildinginaplaceeasilyaccessibletotheresidents,
ataheightofatleast1,5minsuchawaythatitdoesnotposeathreattothemandisnot
exposed to accidental hit.
Do not install the monitor in front of a window or strong light source as this may make it dif-
culttoobservetheimageonthemonitorscreen.Itisnotrecommendedtoinstallmonitors
innarrowcorridorsorpassageways,asthismaycausesounddistortion.
Themonitorshouldbemountedatleast1,5mfromsourcesofstrongelectromagneticinter-
ference–transformerpowersupplies,magnets,metalsewerandgaspipes,asthismaycau-
seimagedistortion.Itisrecommendedtoplaceaush-mountedelectricalboxwithaxing
socket or an electric switch in the place provided for the monitor installation. Connect the
monitor connection cables in a box. Attach the monitor mounting bracket to the box so that
the holders with the holes will be directed up. Attach the mounting plugs to the cables (Fi-
gure5and6).Inserttheplugsintotheappropriatesockets,remembertoputthepowerplug
at the end.
Programthemonitornumber(seesection6„Programmingthenumber”).
Finallyattachthemonitortothemountingbracketandlightlypullitdown,overcominga
slight resistance.
Terminals Distance
<15m <30m
L+,L-,CAM1+,CAM1- 0,5mm
+VS,GS 0,5mm 2x0,5mm
Figure 4. Permissible monitor-distributor distances and required cable diameters

- 11 -
Color monitor MVC-8151
Connecting an additional camera or COMMAX panel
To the monitor can be connected an additional camera or COMMAX video door entry pa-
nel. The CN CAM2 connector is used for this purpose.
Inthecaseofanexternalpanel,connectthewiresinaccordancewiththedescriptionofthe
plug.
Thepanelallowsyoutocallthemonitor,conductaconversation,pressingtheelectricstri-
ke’sbuttoninthemonitorwillactivatetherelayinthepanel,whichcancontroltheelectric
strike. As an additional camera a standard camera with a COMPOSITE VIDEO output can
beused.Itcanbeadisccamera,adomecamera,acameraintheformofaviewnderetc.
AnadditionalcameracanbedirectlyconnectedtotheCN_CAM2plugforVC(+12V),GND
(ground) and C2 (video) terminals.
Someoorpanelsrequire5Vinrestconditionforproperoperation.
TheJP2jumperallowsyoutosetarestingvoltageof1,5Vor5Vonthemonitor’spower
line.
Connecting the doorbell
Themonitorcanreplacethestandarddoorbell(DING-DONGgongsignal).Forthispurpo-
se,astandardbellswitch(NO)shouldbeconnectedtotheterminalsoftheCN_BELLplug.
It should be noted that the switch terminals were not connected to elements of any other in-
stallation,inparticularto230Vmains.
Connecting an additional device
AlongpressoftheCONTROLbuttonactivateforapprox.1secondtheinternalrelay,which
shortstheNOterminalsintheCN_BPplug.Thesecontactscanbeused,forexample,tocon-
trol the drive of the entrance gate or automatic barrier (Figure
6. Programming the number and activating the monitor
Bydefaulttestnumber63isprogrammedineachmonitor.Ineachmonitormustbepro-
grammed target number (including 63).
In the monitor you can set numbers in the range 1...254. It is not possible to program other
numbers.ToprogramthenumbertheLOCKandCONVERSATIONbuttonsareused,as
wellasthePROGbuttonlocatedonthesideofthemonitor.Thenumberofhundreds,tens
and units of the programmed number are programmed sequentially.
Description of buttons:
PROG–enteringtheprogrammingmode(Figure1).
CONVERSATION – entering the programmed value.
LOCK–conrmationofthevalue,transitiontothenextprogrammingstage.

- 12 -
Color monitor MVC-8151
Setting the monitor number
To program a number you should do in order the following operations:
• PressthePROGbuttonthreetimes.Themonitorgoesintoprogrammingmode,whichis
signaledbyashortsimultaneousashingofLED1andLED2signalingdiodes.
• Setting the number of hundreds. Press the CONVERSATION button as many times as
hundredshas the programmednumber(0,1or 2). Eachpressissignaledby blinking
LED2.EndtheoperationwiththeLOCKbutton,whichwillbeconrmedbyalongash
ofthediode.Ifthenumberofhundredsis0(programmednumberlessthan100),imme-
diately press the LOCK button.
• Setting the number of tens. Press the CONVERSATION button as many times as tens
has the programmed number. Each press is signaled by blinking LED2. End the opera-
tionwiththeLOCKbutton,whichwillbeconrmedbyalongashofthediode.Ifthe
numberoftensis0,immediatelypresstheLOCKbutton.
• Setting the number of units. Press the CONVERSATION button as many times as the
unity has the programmed number. Each press is signaled by blinking LED2. End the
operationwiththeLOCKbutton,whichwillbeconrmedbyalongashofthediode.
Ifthenumberofunitsis0,presstheLOCKbutton.Themonitornumberhasbeenpro-
grammed.
• Restore the programmed number. The LED2 starts blinking as many times as next digits
oftheprogrammednumber(numberofhundreds,tensandunits).
Alongerpausemeansmovingtothenextdigitintheprogrammednumber,andalongera-
shingoftheLED1indicatesthezerovalueofthegivendigit.Thenthediodeswillsignalthe
current state of the device.
Iftheprogrammingprocedureisnotcompletedandtheidletimeexceeds30seconds,the
procedure will automatically exit and the monitor number will not be changed.
Checking the monitor number
TochecktheprogrammednumberofthemonitorpressthePROGbuttoninstandbymode.
The LED1 and LED2 will light for a moment. The LED2 starts blinking as many times as
nextdigitsoftheprogrammednumber(numberofhundreds,tensandunits).Alongerpau-
semeansmovingtothenextdigitintheprogrammednumber,andalongerashingofthe
LED1indicatesthezerovalueofthegivendigit.Afternishingthedemonstrateofthepro-
grammednumber,theLEDsindicatingthecurrentstatusofthemonitorwilllightup.
Video line conguration
Dependingonthetopologyofthevideotransmissionsystem,threesettingsareavailableto
congurethevideoline.Thesesettingsaremadeusingappropriatejumperslocatedonthe
back of the monitor (Figure 6 or a sticker on the back of the monitor).
• BNC–setthejumperinthispositionifthevideosignalissentviacoaxialcable.Theline
can be loaded with a terminator (JP3 jumper).
• UTP – set the jumper in this position if the video signal is sent symmetrically twisted pair.

- 13 -
Color monitor MVC-8151
CN-CAM2
CN-CD
CN-BP
CN-PWR
CN-BELL
red
black
white
blue
red
black
white
blue
red
black
white
blue
red
black
red
black
VC GND
PORT
NO
NO
+VS
GS
BELL
GND
GND
C2
AUD
CAM1+
CAM1-
L-
L+
P1 (MIC1)
CN_BELL
CN_PWR PROG connector*
CN_BP
CN_CAM2
JP2
JP1 JP3
CN_CD
P2 (BAL1)
P4 (BAL2)
P3 (MIC2)
CN_PWR
1 - +VS - monitor power supply
2 - GS - monitor power supply (ground)
JP1 – C+, C- line conguration (CAM1+, CAM1-)
JP2 – VC line conguration of connector CN_CAM
BNC – coaxial cable
TERM OFF
C2 TERM 75R
C1 TERM 75R
UTP – UTP twisted pair
UTP+TERM – UTP twisted pair with 100R terminator
1,5V in standby mode
5V in standby mode
JP3 – C1 and C2 line conguration for coaxial cable
1 2
CN_BELL
CN_BP
1 - BELL - doorbell
2 - GND - doorbell (ground)
1 – GND – ground
2 – PORT – porter line
3 – NO – gate drive control
4 – NO – gate drive control
1 2
1 4
CN_CAM 1 – VC – power supply for additional camera
/ oor panel
2 – GND – ground
3 – C2 – video signal from the additional camera
4 – AUD – audio line of the oor panel
1 4
CN_CD 1- CAM1+ video signal from the door entry system
2 – CAM1- video signal from the door entry system
3 – L- line of handsets
4 – L+ line of handsets
1 4
* The programming connector is used in the production
process and for service purposes
NOTE!
Removing the plastic cover from the programming
connector will void the manufacturer's warranty!
C1 TERM 75R, C2 TERM 75R
Figure 5. Description of the monitor connection plugs
Figure 6. Description of the monitor connection sockets. Control elements and congura-
tion jumpers

- 14 -
Color monitor MVC-8151
• UTP+TERMINATOR – set the jumper in this position if the video signal is sent symme-
trically with the UTP cable and the monitor is located at the end of the video bus or is the
only line load. In this position the line is loaded with a 100R resistor.
Adjusting the monitor
The regulations available to the user are described in point 3 of this instruction.
In special cases you can adjust the audio signal using the following potentiometers available
on the back of the monitor:
• BAL1–correctionofthelevel(volume)ofthesignalcomingfromtheexternalpanel
• MIC1 – correction of the level (volume) of the signal coming out to the external panel
• BAL2–correctionofthelevel(volume)ofthesignalcomingfromtheoorpanel
• MIC2–correctionofthelevel(volume)ofthesignalcomingouttotheoorpanel
7. Operation of the „installation procedure” (requires activation in the CD-
2502/3100 system)
The procedure makes it easier to activate the door entry system. After starting the installa-
tion procedure you can set in the monitor the number of rings and the tone and volume of
the call (these are individual settings for each apartment number). Then the electronic mo-
dule automatically establishes connection with the handset or monitor in which the procedu-
rewasactivated,givingtheinstallertheabilitytocheckthedevice.
Turn on the preview from the CD door phone camera (one touch of the PREVIEW key) and
press the CONVERSATION button four times. The LED1 and LED2 light up at the same
time.
• Press the LOCK button once. The electronic module will start looking for the monitor
number in which the installation procedure was activated.
• Afterndingthemonitorthemonitornumberwillbedemonstrateusingtheacousticsi-
gnals(threedigitscorrespondingtothenumberofhundreds,tensandunits,similartopo-
int6).Alongerbreakmeansmovingtothenextnumber,alongersoundmeansthatthe
numberiszero.
• Select the call tone by pressing the LOCK button sequentially.
• Set the call volume in the door entry system using the CONVERSATION button (do not
confusewiththevolumesettingdirectlyinthemonitor,seepoint3).Therearethreevo-
lumelevels(loud,moderate,quiet)andaincreasingsignal(threeshortbeeps).
• Theselectedsettingsmustbeconrmedbylong-pressingtheCONVERSATIONbutton.
• After a moment the electronic module will call the monitor in which the installation pro-
cedure was activated. Press the CONVERSATION button to get a connection. The instal-

- 15 -
Color monitor MVC-8151
lercanchecktheoperationofthevideo,soundandelectricstrike.
• End the conversation.
8. Doorbell function
In the monitor there is a generator which can function as a door bell.
The generator is activated with a bell button connected to appropriate terminals in the mo-
nitor. Pressing the bell button causes generating gong sound. If bell button is pressed during
monitorcallingthencallsignalwillbereplacedforamomentbygongsound,andthenswit-
ched on again.
All signals are automatically turned down during the conversation.
Note!
Bellterminals(BELL,GND)shouldnotbeconnectedtoanyotherelectricalsystems,espe-
cially 230V mains.
9. Maintenance
Inthecaseofcontamination,monitorshouldbecleanedwithsoft,dampcloth.
Monitorinsideshouldnotbeoodedwithwaterorotherliquidbecausethiscancausethe
equipment damage.
Do not use abrasive materials that can scratch the surface of the casing.
Donotusegasolineandanysolventsorstrongdetergentsforcleaning,astheymaydama-
ge or discolor the surface.

- 16 -
Color monitor MVC-8151
10. Technical data and wiring diagram
Power: 15V DC/1A
Recommendedpowersupply:  KSAS0181500120,SAPC15018EU
Screen diagonal: 7”
Protection degree: IP30
Operating temperature: (5 – 40) °C
Dimensions: 213x152x21 mm

- 17 -
Color monitor MVC-8151
CAM1+
CAM1-
L-
L+
GND
VC
AUD
C2
GND
PORT
NO NO
+VS
GS
BELL
GND
CN_BELLCN-PWR CN_BP CN_CAM2 CN_CD
+
-
controller*
splitter
power supply
CVR-2
audio
ground
+12V
door entry panel
COMMAX**
*
MON1...MON4
to EC-2502
or EC-3100
video
porter
switchboard
+
-
~230V
MVC-8151
button
L+
L-
AC AC
+15V
GND
C+
C-
+15V
GND
L+
L-
C+
C-
Figure 7. Monitor wiring diagram

- 18 -
Color monitor MVC-8151

- 19 -
Color monitor MVC-8151

ul. Dąbrowskiego 249, 93-231 Łódź, Poland, tel. (042) 671 88 00, fax (042) 671 88 88
e-mail: [email protected], www.laskomex.com.pl, www.elektrozaczepy.pl
V1.4 26.07.2018
This product was marked with a symbol of crossed dustbin according to Euro-
pean Directive 2002/96/WE on used electric and electronic equipment.
Used equipment cannot be placed with other wastes from households.
Productuserisobligedtogiveittothermwhichcollectsusedelectronic
orelectricequipmentsuchaslocalcollectionpoints,shops,placesappointed
by the manufacturer or commune waste collection units.
List of collecting units of used Laskomex equipment is available on www.laskomex.com.pl or tel.
42 671 88 68.
Product packing should be removed according to environment protection regulations.
Remember!
Selective collection and recycling of used electronic and electric equipment considerably con-
tributes to the protection of human health and life as well as protection of natural environ-
ment. Return of packaging materials for the material recycling saves raw materials and re-
duces generating of wastes.
INSTRUCTION ON ENVIRONMENT PROTECTION
