Laskomex ISD-02 User manual

Installation and activation
of interface
ISD-02
MLX
LASKOMEX

Page 2
ISD-02
CONTENTS
1. Safety of use........................................................................................................................2
2. ISD-02 set assignment...........................................................................................................2
3. ISD-02 set contents...............................................................................................................3
ISD-02 interface..............................................................................................................................3
MLX module................................................................................................................................3
Additional elements of the set.........................................................................................................3
4. Use of ISD-02 set.................... .............................................................................................3
4.1 Installation of software....... ................................................................................................3
4.2 Data exchange........... .....................................................................................................6
4.2.1 Connection EC electronic cassette - ISD-02 interface ............................................................6
4.2.2 Connection EC electronic cassette - MLX module ................................................................6
Connection MLX module - ISD-02 interface ..........................................................................7
4.2.3 DIP memory ..............................................................................................................................7
5. Maintenance..........................................................................................................................7
6. Connections diagrams............................................................................................................7
Direct connection between EC electronic cassette and ISD-02 interface or MLX module.........7
Connection with MLX module........................................................................................7
Data read/write from/to DIP memory chip .......................................................................7
7. Technical data..... .................................................................................................................8
ISD-02 interface.. .....................................................................................................................8
MLX module. ......................................................................................................................................8
1. Safety of use
Prior to the installation and usage of ISD-02 set please read the following instruction.
Elements of the set should be used according to their intended purpose. The usage of components
for another purpose, connecting with devices other than those listed in the manual or connecting
in a different way than recommended by the manufacturer may result in damage, fire or electric
shock.
Both the ISD-02 interface and the MLX module should not be exposed to high temperature and
humidity. It should be protected against flooding with any liquids.
No metal objects can be put into the openings in ISD-02 and MLX casings because this can
cause the equipment damage and electric shock.
The locations of connecting sockets are shown on pictures in manual.
ISD-02 interface is supplied from USB PC socket.
Repair of the equipment by unauthorized persons is forbidden because this can result in loss of
guarantee.
2. ISD-02 set assignment
ISD-02 software is used to configure all the parameters of CD-2502 and CD-3100 entry phone
system, and database management of identifiers - electronic keys "iButton" or "RFID" (125kHz
standard).
Hardware requirements
PC equipped with minimum 400MHz processor and 256MB RAM
CD-ROM drive + 100MB free disk space on hard drive
minimum screen resolution 800x600
1 free USB 1.1 or 2.0 port to connect ISD-02 interface
mouse or other pointing device
one of the operating systems: Windows 7, Windows XP or Linux (Ubuntu 9.1 version)

Page 3
ISD-02
3. ISD-02 set contents
ISD-02 interface
Figure 1. ISD-02 interface
LED 1 flashing green indicates connection to USB port, while a flashing red - the exchange of data
with the electronic cassette, MLX module or PC.
MLX module
MLX module can be used as a portable memory device which enables data exchange between
electronic cassette of CD-2502 or CD-3100 system and ISD-02 interface.
LED 1 (green) indicates power supply.
LED 2 (red) indicates the exchange of data with ISD-02 interface.
Figure 2. MLX module
Additionally the set includes:
Cable to connect ISD-02 interface with electronic cassette EC-2502 or EC-3100
Cable mini USB-B (5pin) - USB-A
CD with ISD-02 software
4. Use of ISD-02 set
4.1 Installation of software
Installation of ISD-02 software does not require specialized installer. One should just copy the appropriate
directory to PC's hard drive.
Depending on the installed operating system in the PC, one should copy from CD to PC's hard drive
the entire contents of the ISD-02 directory:
- for Windows SOFTWARE/Windows/ISD-02/*.*
- for systemu LINUX SOFTWARE/Ubuntu/ISD-02/*.*
In Linux operating system make sure that after copying to hard drive, files isd.sh and ISD-02 have
"Allow executing file as program" option selected in tab "Permissions" in "Properties".
Using supplied USB-A/mini USB-B cable, connect ISD-02 interface to the PC.
For Linux operating system installation process has come to an end - one should just copy the
appropriate directory. The further part of the installation applies only to Windows XP, Windows7.
Windows operating system should detect connection of new device and display the window.
NOTE! For driver installation, Windows administrator rights are required.
mini USB B socket
memory socketiButton electronic touch
keys reader
LED 1RFID electronic
proximity keys reader
plug for connection
to ISD-02 interface
or electronic cassette
EC-2502 or EC-3100
LED 1
LED 2
DIP socket for memory
chip placement from electronic
cassette EC-2502 or EC-3100

Page 4
ISD-02
In displayed window one should select "Install from a list or specific location" option and press "Next"
button.
In next window one should select "Include this location in the search" option and by pressing
"Browse" button, specify the path to the DRIVER directory which is present in main ISD-02
directory. After specify the path, press "Next" button.

Page 5
ISD-02
Windows operating system should display "Hardware Installation" window where one should
press "Continue Anyway" button.
After finish driver installation a window should be displayed where one should press "Finish"
button.

Page 6
ISD-02
Driver installation was completed successfully.
The device has been installed and assigned to the first available COM port (see Device Manager)
4.2 Data exchange
Data (settings of electronic cassette) exchange from entry phone system to PC takes place through:
4.2.1. Connection EC electronic cassette  ISD-02 interface
connect ISD-02 interface to the CN1 socket in EC electronic cassette using appropriate cable
(CN1* in cassettes manufactured till August 2009 is situated on the edge of PCB circuit of EC
- cable should be insert with coding inset at the top)
electronic cassette automatically enters into data exchange mode - on the display of external
panel caption will be shown
in ISD-02 software choose the direction of data exchange
4.2.2. Connection EC electronic cassette  MLX module
connect MLX module to the CN1 socket in EC electronic cassette (CN1* in cassettes manufactured
till August 2009 is situated on the edge of PCB circuit of EC - MLX should be insert with coding
inset at the top)
on the display of external panel caption will be shown.
NOTE! Since software version 6.8 of EC-2502 electronic cassette or 7.1 of EC-3100 electronic
cassette one should enter P-8 procedure in programming mode.
Using external panel keyboard one should choose the appropriate option:
 1- data backup from electronic cassette to the internal memory of MLX module -
 2- displays the CPU serial number of configuration saved in MLX -
 3- data upload from MLX module to the electronic cassette -
after choosing the direction of data transfer (upload or backup) one have to choose:
 1- copying all the parameters of el. cassette including electronic keys database -
 3- copying only identifiers database -
the selection should be confirmed by pressing the field with a symbol of key  process of writing
or reading will begin which is signalled by flashing caption or properly
after copying data caption will be shown and short acoustic signal will appear

Page 7
ISD-02
Connection MLX module  ISD-02 interface
connect MLX module to the socket in ISD-02 interface
in ISD-02 software choose the direction of data exchange
4.2.3. DIP memory
remove U4 (24C64) memory chip from electronic cassette
insert memory chip to the socket in MLX module
connect MLX module to the socket in ISD-02 interface
in ISD-02 software choose the direction of data exchange
5. Maintenance
Elements of the set should be cleaned with a damp cloth or by using detergents intended for
cleaning elements made of plastics.
NOTE!
No benzine, solvents or abrasive materials should be used for cleaning because it can cause to
permanent damage of the casing surface!
Avoid flooding of elements with water or detergents while cleaning because it can cause the
equipment damage!
6. Connections diagrams
Figure 3. Direct connection between EC electronic cassette and ISD-02 interface or MLX module
Figure 4. Connection with MLX module
Figure 5. Data read/write from/to DIP memory chip removed from EC electronic cassette
and inserted in MLX module
To PC
CN1 - Socket for connection
to ISD-02 interface
or MLX module
CN1* - for older version
of electronic
cassette
To PC
To PC
DIP8
To PC
DIP8

V1.1 (2011-02-07)
7. Technical data
ISD-02 interface
Dimensions: 95x40x18mm
Ambient temperature: 5°C...40°C
Connectors: mini USB-B
EC / MLX
Reader: iButton
RFID
Power supply: via USB connector
MLX module
Dimensions: 52x22x9mm
Ambient temperature: 5°C...40°C
Connectors: DIP-8
EC / ISD
List of collecting units of used Laskomex equipment is available on a company website
www.laskomex.com.pl or telephone No. [phone].
Product packing should be removed according to environment protection regulations.
Remember!
Selective collection and recycling of used electronic and electric equipment
considerably contributes to the protection of human health and life as well as
protection of natural environment.
Return of packaging materials for the material recycling saves raw materials and
reduces generating of wastes.
According to European Directive 2002/96/WE on used electric and electronic
equipment, the product is marked with a symbol of crossed dustbin. Used
equipment cannot be placed with other wastes from households. Product
user is obliged to give it to the firm which collects used electronic
or electric equipment such as local collection points, shops, places
appointedby the producer or commune waste collection units.
INSTRUCTION ON ENVIRONMENT PROTECTION
