lassele LNRT-2B/C-1200 User manual

< SIDE TABLE >
BASIC, GN TYPE, GLASS DOOR, SALAD, SALAD HOOD, DRAWER
Operating Instruction
Lassele Refrigerated Counters
Please read this user manual before you use this product.
If you request unnecessary services, you may waste money.
Thus, fix simple troubles by yourself which you have found.
R512A-773

- 2 -
1. Comprehension and preparation
2. How to use
3. References
1) Part name 4
(2) How to ground 10
(3) Caution 11
Installation 15
Temperature control 17
(1) Proper usage 18
(2) Cautions 19
(3) Cleaning 20
(4) Troubleshooting tips 21
(5) Before you call for service 22
(6) Product dimension 23
•The temperature inside refrigerator depends on the frequency of door opening and closing, volume of
food stored and the circumstance under which the product is installed.
•Set the temperature control at Weak if food in the refrigerator is a little.
•After a power outage or after the power cord is reconnected, the temperature previously selected will
automatically be displayed.
•Don’t cool or freeze water or meat stock in the product as it may change other sorts of food in it. Use a
refrigerator for meat stock to cool or freeze it.
•In the case that the ambient temperature of the product is below 10℃(50℉), food in refrigerator may be
frozen.
•Set the temperature control according to the conditions of the ambient temperature.
•Don’t touch the vessels or food in refrigerator with a wet hand.
Your hand may be frost-bitten.
•Don’t keep drugs, academic materials, herbal tonics (liquor made from deer antler or dog) or medicinal
herbs in the product. - The company will not be responsible for spoiled drugs, academic materials,
herbal tonics or medicinal herbs.
Table of Contents

- 3 -
The merits
of the
product
Glossy Appearance
Lustrous Stainless Steel brightens a room.
Power-saving Design
The product is designed to reduce greatly electric
bills.
Powerful Cooling System
Rapid and powerful cooling system keeps your food
fresh and safe longer without the loss of nutrition.
Low Noise and High Efficiency Compressor
The product with a compressor designed for Low
Noise and High Efficiency makes quiet and
powerful operation possible.
Safe Design
Built-in self test equipment which informs a rise in
room temperature and a safe device which
perceives the disorder of compressor are adopted.
Check Local electric rating.
*Plug into exclusive power socket.
*Dont’t plug into multi-socket.
*Make sure to read and follow this manual before you use the product.

Appearance LNRT-1A/1B/C-900, LNRT-2A/2B/C-1200/1500, LNRT-3A/3B/C-1800(Refrigerator only)
LNFT-1A/1B/C-900, LNFT-2A/2B/C-1200/1500, LNFT-3A/3B/C-1800(Freezer only)
Appearance LERT-1B/C-900, LERT-2B/C-1200/1500, LERT-3B/C-1800(Refrigerator only)
LEFT-1B/C-900, LEFT-2B/C-1200/1500, LEFT-3B/C-1800(Freezer only)
- 4 -
Part name
※ The door quantity depends on the model specification.

Appearance LGRT-1B/C-900, LGRT-2B/C-1200/1500, LGRT-3B/C-1800(Refrigerator only)
Appearance LEGRT-1B/C-900, LEGRT-2B/C-1200/1500, LEGRT-3B/C-1800(Refrigerator only)
- 5 -
Part name
※ The door quantity depends on the model specification.

Appearance LNRT-1B/C-90-V, LNRT-2B/C-12VV, LNRT-2B/C-15VV, LNRT-3B/C-18-VVV
Appearance LNRT-1B/C-90-W, LNRT-2B/C-12-WW, LNRT-2B/C-15-WW, LNRT-3B/C-18-WWW
- 6 -
Part name
※ The door quantity depends on the model specification.

Appearance LHRT-1B/C-900, LHRT-2B/C-1200, LHRT-2B/C-1500,
LHRT-3B/C-1800 (Refrigerator only)
Appearance LSRT-1B/C-900, LSRT-2B/C-1200, LSRT-2B/C-1500
LSRT-3B/C-1800 (Refrigerator only)
- 7 -
Part name
※ The door quantity depends on the model specification.

Appearance LNRT-1B-1200, LNRT-2B-1800(Refrigerator only)
LNFT-1B-1200, LNFT-2B-1800(Freezer only)
Appearance LHRT-1B-1200, LHRT-2B-1800(Refrigerator only)
- 8 -
Part name
※ The door quantity depends on the model specification.

Appearance LSRT-1B-1200, LSRT-2B-1800(Refrigerator only)
- 9 -
Part name

- 10 -
How to ground
Connect a ground wire to prevent problems such as power leakage or electric shock.
* Power outlet for the product must be
grounded
* Power connection must be made using a
safety plug socket earthed according to
the regulations. Follow local regulations!
-After connecting a ground wire to a copper
ground plate, bury the wire beneath ground.
Size of cooper plate: Over 0.7mm thick
Over 900cm²wide
-Connect the wire to a properly grounded
outlet
※The places where a ground wire can’t
be connected
Never use the product for other purposes except for keeping food.
Especially, don’t let children play in the product. If the door of the product is closed,
they may choke.
A Ground Wire
Over 75 cm
A Cooper plate
properly grounded outlet
A Ground wire
a gas pipe water pipe telephone wire
Grounding
Terminal
Connect
exclusive
Outlet Only

- 11 -
Caution
•As the proper use of product can prevent danger or physical loss,
you should observe general cautions to use it safely.
The contents of warning and caution
Warning
The contents of signs
A man may die or may
be seriously injured.
The sign represents NO.
The sign represents NO DISASSEMBLING.
The sign represents NO TOUCHING.
You must observe it.
You must unplug the power
cord from outlet.
The sign represents the protective
grounding to prevent any electric shock.
Caution
A man may be
wounded or suffer
from a physical loss.
Warning
Don’t overload an electrical
outlet with several
appliances or extension
cords
•Electrical overheating and
fire may occur.
Don’t spray water directly
inside or outside of
refrigerator
•Fire or electric shock may occur.
Don’t touch an electric plug,
electrical components and
operating part located to the left
side of the refrigerator with a
wet hand
•You may be shocked electrically or
your hand may be injured.
Don’t spray flammable and
combustible materials
around the product
•A burst or fire may occur.
Don’t let children sit on or
go in the product. Don’t
detach shelves to keep
them separately
•If children enter the product,
their lives may be dangerous.
Make sure that the grounding
wire is connected
•If the grounding wire has not
been connected, a disorder or
electric shock may occur.
No No
No No Grounding
No wet hand

- 12 -
Warning
No
Observe Observe
No No
Unplug the
power cord.
No disassembling
Don’t keep volatile and flammable materials
in the product
• If benzene, thinners, alcohol, ether, LP gas and
medicines are kept in it, they may burst.
Never dissemble, fix and convert it
arbitrarily. Especially, don’t let children play,
control or operate it
• The wrong operation may cause fire, electric
shock or damage.
If gas escapes, you should not touch the
product and its plug, and you should
ventilate at once
• There is a real fire risk and burn risk once tiny
spark bursts into open flame.
Remove doors and their packing when
discarding the product
• Especially, don’t let children play in the product. If
the door of product is closed, they may choke.
• Please contact the place where you purchased the
product or a consumer service center for additional
information.
Don’t break, modify, bend with force, stretch
or twist an electric cord: If the cord is
damaged, fire or electric shock may occur.
Make sure that an electric plug is not
pressed by the rear side of the product. Put
it where it is easy to use the plug
• If the electric plug is damaged, fire caused by
overheating may occur.
Remember to unplug the power cord when thunder and lightening occur and
when you don’t use it for a long time.
• Even though you don’t use the product, it may be overheated if the power cord remains
plugged. There is also fire or electric risk.
• The appliance must be positioned so
that the plug is accessible.

- 13 -
Caution
Install the product where rodents (mouse
and so on) are not present: If they gnaw the
wire, fire may occur.
If abnormal conditions (strange sound, smell
and smoke) are founded, unplug the power
cord immediately, and then contact the
appointed customer service center.
When disconnect the power cord, pull on the
plug, not the cord itself
• Pulling on the cord can damage the cord and
may result in fire or electric shock.
As the product is heavy, several people
should move it together
• Don’t lay it while carrying.
Don’t touch food or containers in the
refrigerator with wet hands
• Your hands may be frostbitten.
Don’t put the bowls filled with water, drugs and
small metals around the machine room on the
left side of the product
• There is an electric shock, fire and burst risk or you
may be hurt. The longevity of the product may be
reduced. Its cooling function may weaken. It may
result in malfunction.
Use a door knob when closing the refrigerator
door
• If you close the door with other parts except door
knob, your fingers may be hurt
Don't pack the refrigerator with too much
food
• If the food pours down while opening the
door, you may be hurt. Cooling efficiency would
be decreased accordingly.
No
No No
No
Unplug the power cord
Observe
Observe
Observe

over
30kg
over
30kg
- 14 -
Caution
Keep drugs, reagents, academic materials,
herbal tonics (liquor made from deer antler or
dog) and medicinal herbs
• If things which require the strict temperature
control are put in the product, they may spoil or
their unexpected reaction may result in a hazard.
• The company is not responsible for drugs,
academic materials, reagents and herbal tonics
spoiled by the trouble of the product.
Don’t cling to the door or clime to the upper
part of product. It is very dangerous
• The product may fall down or you may be hurt.
Especially, let children be careful.
• The company doesn’t compensate according to
the Consumer Protection Laws for damages or
losses which have occurred owing to unstable
action.
Make sure that plug pins are not wet with water or
there is not dirt stuck around the pins. Insert the
plug fully into the outlet not to be shaken
• If dirt or foreign substances are stuck to the pins,
or the plug is connected unstably, fire may occur.
If you want to reconnect the power plug after you
have pulled it off, replug it at least in 5 minutes.
• If a cooler works too hard, it may result in a trouble.
Don’t plug the power plug if the hole of
outlet is too big. It may result in an electric
shock or fire.
Don’t put your hands in a part of the
product or its left machine room
They may be hurt.
No No
5 minutes
later
No
No
Do not leave too much food on the shelf of the
cool chamber.
* Maximum carrying capacity of the shelf is
under 30kg.
* The shelf might be bent in case of over 30kg.
Observe Observe

- 15 -
When the product is installed in a basement or
in a wet or damp place
• In the case that the product is installed in a
basement or in a wet or damp place, purchase an
earth leakage circuit breaker from an agent or
after-sales service center and then connect it to
the outlet. Electric leakage breaker.
Install the product indoors
• It is indoor use only. If it is installed outdoors, the
product may be damaged or its cooling efficiency
may be decreased.
Install the product on the firm and even floor
• The unstable installation may result in vibration
and noise of the product. If the floor where the
product is supposed to be installed is not flat, put a
strong board on it.
• Fasten the product not to be shaken by turning the
height control screws of fixing legs to the left.
Install the product under a shelf or where
there is nothing to fall down on the top.
Install it in a well-ventilated area
• As cooling efficiency gets better in the well-
ventilated area, allow adequate space around the
refrigerator for good air circulation as follows.
E.L.B
Installation
Turn the screw to the left to
increase the height of product or
turn it to the right to decrease it.
Over 50cm
over 15cm
Avoid the place where there is much corrosive gas
to install it
•If the ambient temperature is high, cooling
efficiency will be reduced and electric fee will be
increased.
•The color of its appearance may be changed or its
longevity may be reduced by briquette or corrosive gas.
over 10cm

- 16 -
Avoid places that are damp, dusty or where
water splashes
• If you install the product in a place which is damp
or subject to water, it may result in a power
leakage. If dust is piled up a lot in a machine
room, condensation may be reduced and cooling
efficiency may be decreased.
Avoid places that are exposed to direct
sunlight or excessive heat
• Avoid places that are exposed to direct sunlight
and excessive heat like electric or gas heater.
Connect a power plug into an electric outlet
when 2-3 hours have passed after installation.
If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or qualified person in order to avoid
any hazard.
Moist

- 17 -
Temperature control
●Continuous 5 second press on the button
will toggle the power On/Off.
- If you turn the power off during operation,
every power becomes shut down.
At this moment if the power is turned on,
the fan motor inside the room will be
activated immediately and the comp will
start operation after 5 minutes of delay.
●One time push of the or button will
make the set temperature changed.
●Continuous 3 second press on the button
will change the defrost fequency (5H, 8H).
●Press and at the same item for 3 sec
and "SEL" will appear on the display.
Press once and "dS" will appear on the
display.
Press once to activate Force Defrost
and "dF" will appear on the display while the
Force Defrost is activating. After 30 minutes
from the defrost activation if the temperature
sensor inside the room senses the 5 degree
C, then the forced defrost stops.
●Refrigerator : +7℃ ~ -3℃
(Other Market : 39℉ ~ 28℉)
●Freezer : -3℃ ~ -24℃
(Other Market : 5℉ ~ -9℉)

- 18 -
Don't pack the refrigerator with too much food
• As cooling circulation gets worse owing to too
much food, cooling time gets longer. Keep food
at proper intervals. (If you put food at the bottom
of product, cooling circulation becomes poor.
Thus, keep food on shelves.)
Keep food when 2 ~ 3 hours have passed
• Put food into the refrigerator when 2 ~ 3 hours
have passed since it starts working, that is, when
the inside of product gets fully cold.
Wait until hot food is cooled down and then
keep it.
• If you put hot food directly, it may make its
surrounding food spoil and electric fee will be
increased.
Put food into plastic bags or containers with a
cover before keeping them in the product.
• Put juicy or smelly food into plastic bag or
containers with a cover. They prevent food from
being dry and changed. Thus, food can be kept
longer and the smell inside the refrigerator can be
reduced.
• Take food after expiration date out of the
refrigerator.
Proper usage
Put the food when 2 ~
3 hours have passed.
Wash and then keep vegetables or fruits.
• Keep vegetables or fruits after washing and
wiping them. Clean bottled or packed food not
to soil other foods and then keep it.

- 19 -
When you don’t use the product for a long
time
• Take food out of the refrigerator and unplug the
power cord.
• Clean up and wipe the inside of product and then
dry the inside for 2~3 hours.
• If someone enters the unused refrigerator and
then its door is closed, it is very dangerous. Thus,
insert something between the door and a body of
the product not to be closed completely.
When power is off
• Don’t open the door more frequently than you
need to.
When power is supposed to be off
• Avoid keeping new food because it raises the
temperature inside the product
When tiny water droplets are formed
• Tiny water droplets may be formed when humidity
around the product is high or it rains. This
phenomenon occurs when moisture in the air
reach the cold side of refrigerator. Then, wipe the
product with a dry towel.
When you carry or move the product
• Be sure to unplug the power cord when you
carry or move the product.
• Be sure to carry the product with several people
as it is very heavy.
• See the manual when you operate again the
product after placing it.
Cautions
Don’t open the door
more frequently than
you need to.
2~3hours....
Wipe the product
with a dry towel.
Don’t open the door more frequently than you
need to.
• The frequent door opening may reduce cooling
efficiency as the cold air in the product comes
out.
Don’t open the
door more frequently
than you need to.
Don’t operate the product with the power
plug.
• If you operate the product with the power plug,
you may be shocked electrically.

- 20 -
Before you clean the product
• Clean the product once a month. If you clean it
frequently, you can keep it clean and use it for a
long time.
• Unplug the power cord.
• Especially, don’t sprinkle water directly on the
top of machine room to clean the product. It may
cause power leakage and it may have the product
tarnished.
• Don’t sprinkle water directly to clean the
product.
Washing the inside and outside of the
product
• Wash it with a soft cloth soaked in warm water.
• Wash its serious stain with a soft cloth soaked in
neutral detergent. In the case that you use neural
detergent, be sure to wash it with clean water and
to wipe completely dampness with a dry cloth.
• You can detach and wash shelves.
• Don’t use thinner, benzene, oil, boiling water, a
rough brush, abrasive and hydrochloric acid which
can change the color and form of the product.
Packing of door (Door Gasket)
• If you keep using door gasket stained with juice
or lactobacillus beverage, the gasket may be
damaged in rapid. Especially, its lower part is apt
to be dirty. Thus, wash it with a soft cloth soaked
in a neutral detergent and wipe it with a clean
cloth.
After cleaning
• After cleaning, close the door tightly as food or
other things may prevent the door packing from
being adhered to the body of the product. Make
sure that it is adhered to the body completely.
• Make sure that the power cord is not damaged.
• Make sure that electrical overheating is not
found from the power plug..
• Make sure that the power plug is connected to
the outlet completely.
• Please read the user’s manual thoroughly
before you use this product.
Cleaning
Wash it once
in a while
