Launch Creader VII+ Quick start guide

Follow the steps described as below to proceed
registration and update:
1. Go to http://mycar.x431.com/pad/landingPageIndexCrv.
action and click the“Updating Tool Download” icon. See
Figure 1-a or Figure 1-b.
Figure 1-a (For Creader VII+)
Figure 1-b (For Creader VIII)
2. Download and install the Creader VII+ / Creader VIII
update tool and launch the program when installed, a
screen similar to Figure 2 will appear:
Figure 2
3. In Figure 2, type in the serial number, which is located on
the back of the Creader VII+ / Creader VIII.
4. After the serial number is entered, click “Update” to jump
to the registration page. Enter the following information
and click “Submit” (refer to Figure 3).
Figure 3
(If you need the Register Code, please refer to Steps 5~8.)
(If you have the Register Code, directly proceed to step 9.)
5. The register code can be found in your Creader VII+ /
Creader VIII. Connect one end of the supplied USB cord
to Creader VII+ / Creader VIII, and the other end to the
computer.
6. After Creader VII+ / Creader VIII has powered up and
entered the main menu screen, move the highlight bar on
the “Help” icon (See Figure 4) and press the button.
Figure 4
7. Select “Tool Information” (refer to Figure 5) and press the
button to enter.
Figure 5
8. The register code shown in Figure 6 is the register code
for inputting in step 4.
LAUNCH
Guide to Register & Upgrade

Figure 6
(Return to step 4 and input the code and then proceed)
9. Install the TF card from the tool into the supplied USB TF
card adaptor and insert into the USB port of the computer.
10. Reopen the Creader VII+ / Creader VIII update tool, select
the updates you would like to perform or click “Select
All”, and then click “Download” to start downloading. See
Figure 7.
Figure 7
11. Once all steps are complete, reinsert the TF card into the
tool and power the tool via USB cable (one end to Creader
VII+ / Creader VIII and the other end to the computer) or
via OBD II cable (one end to OBD II connector of Creader
VII+ / Creader VIII and the other end to the vehicle’s DLC).
A dialog box prompting you to upgrade will pop up on the
screen (See Figure 8), select OK button to proceed.
Figure 8
12.The registration process is now complete!
