Lawmate C1176 User manual

Operation Manual
Law Enforcement Products Manufacturer
LawMate
C1176 Ear Phone
Type Camera

DVR
DC 9-12V Input
Video Output(yellow)
Audio Output(White)
2.Connections Illustration
1.Names and Parts
Camera
Microphone
Video/Audio Ouput
PV-500EVO DVR
PV-500ECO DVR
PV-500LITE DVR
PV-900HD DVR
PV-1000 DVR

3.How correct to use Camera
Wrong
Correct

Yes
CM-EP10
NTSC & PAL
640 x 480
Audio Output
1.0V p-p Composite at 75 ohm
2Vp-p(MAX) 10KHz ohms Impedance
3.59 mm
66.5 Degree
CMOS 1/4 inch
DC 5V
23(W)x26(H)x18(T) mm
50 dB
130 mA
25 g
MIN Illumination 3 Lux / 30 IRE @ F2.0
Video Output
MIC Sensitivity
Item Number
Video System
Picture Element
S/N Ratio
Resolution (H)
Image Sensor
Lens
Angle of View
Power Supply Voltage
Power Supply Current
-10~50
-10~50
Operation Tempareture
Storage Temperature
Dimension (Incld Lens)
Weight
480 TV Lines
