LawnMaster M2EB1637M User manual

LawnMaster 37cm 1600W Electric Mower M2EB1637M
Tondeuse à gazon électrique 37 cm 1600 W LawnMaster M2EB1637M
LawnMaster 37cm 1600W Electric Mower M2EB1637M
Tosaerba elettrico LawnMaster 37 cm 1600 W M2EB1637M
Cortacésped Eléctrico LawnMaster 37 cm 1600 W M2EB1637M
Original Instructions / Consignes initiales
Original-Bedienungsanleitung / Istruzioni originali
Instrucciones originales
Instruction Manual / Manuel d’utilisation /
Bedienungsanleitung / Manuale di istruzioni
Manual de instrucciones

Read all safety instructions carefully before assembling and operating
this machine. Ensure the machine has been assembled correctly and safely. Keep the
instructions safe and pass them on to any subsequent user so that the information is always
available.
WARNING:
Veuillez lire attentivement l’intégralité des consignes de sécurité avant de
monter et d'utiliser cette machine. Assurez-vous que la machine a été montée correctement
et en toute sécurité. Conservez les consignes en lieu sûr et transmettez-les à tout utilisateur
ultérieur an que celles-ci soient toujours disponibles.
AVERTISSEMENT:
Lesen Sie alle Sicherheitshinweise sorgfältig durch, bevor Sie dieses Gerät
zusammenbauen und bedienen. Stellen Sie sicher, dass das Gerät korrekt und sicher
zusammengebaut wurde. Bewahren Sie die Anweisungen an einem sicheren Ort auf und
geben Sie diese an alle nachfolgenden Benutzer weiter, damit die Informationen jederzeit
verfügbar sind.
WARNUNG:
leggere attentamente tutte le istruzioni di sicurezza prima di montare e
mettere in funzione la macchina. Vericare che la macchina sia stata montata correttamente
e in sicurezza. Conservare le istruzioni al sicuro e cederle a qualsiasi utente successivo in
modo che le informazioni in esse contenute siano sempre disponibili.
AVVERTENZA:
Lea detenidamente todas las instrucciones de seguridad antes de
ensamblar y utilizar esta máquina. Asegúrese de que la máquina se ha ensamblado de
forma correcta y segura. Mantenga estas instrucciones a salvo y entréguelas a cualquier
usuario posterior, de forma que la información siempre esté disponible.
ADVERTENCIA:

1
2
3
4
5
7
6
8
9
10
11
12
13
14
15
16
17
18
19

4
TABLE OF CONTENTS
Section Page
Symbols
Safety Information
In the Box
Assembly
Operation
Maintenance
Troubleshooting
Technical Data
Recycling and Disposal
5
6-13
13
14-16
17-19
20-21
22-23
24
24

5
SYMBOL DESIGNATION/EXPLANATION
Caution! Take extra care, beware of hazards.
Read instruction manual.
Do not expose the equipment to rain or leave outdoors. Do not work in the rain
and do not cut wet grass.
Risk of injury by objects thrown out of from the machine.
Keep bystanders and pets at a safe distance while operating the mower.
Caution! The lawnmower blade continues to run after switching off.
Caution-sharp cutting blade! Keep feet and hands away. Risk of injury!
Switch off the motor and disconnect the plug before carrying out maintenance or
repair work, or if the power cable is caught or damaged.
Wear eye and ear protection.
Warning! Beware of electric shocks.
Keep the power cable away from the cutting blade!
Protection class II
Noise level specication LWA in dB.
Do not dispose of electrical equipment in domestic waste.
Cutting diameter
SYMBOLS
The following warning symbols appear throughout this manual and indicate the appropriate
safety measures you should take when operating and maintaining the appliance.
To avoid serious personal injury, do not attempt to use this product until you read thoroughly and
understand completely the instruction manual.
If you do not understand the warnings and instructions in the instruction manual, do not use this
product.
WARNING

6
SAFETY INFORMATION
Read all safety regulations and instructions and keep in
a safe place for future use.
Important! When using equipment, the following safety
precautions must be followed to avoid injuries and damage:
IMPORTANT
■ Read all operating instructions carefully and comply with
them. It is important to understand these instructions and to
acquaint yourself with the machine, its correct usage and
all safety requirements.
■ Keep this manual in a safe place so that the information is
available to the operator at all times.
■ If you give the equipment to any other person, give them
these operating instructions as well.
■ We accept no liability for damage or accidents which result
from non-compliance with these instructions.
■ The device must not be used by people (including children)
with limited physical, sensory or mental faculties or who
lack the necessary experience and/or knowledge - other
than they are supervised by a person responsible for safety
or are being instructed to operate the appliance by such a
person.
■ Never allow children or people who are unfamiliar with
these operating instructions to use the machine. Local
regulations can restrict the age of the operator.
■ Never operate the machine while people, especially
children, or pets are nearby.
■ Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their
property.

7
SAFETY INFORMATION
■ While operating the machine always wear substantial
footwear and long trousers. Do not operate the machine
when barefoot or wearing open toed sandals. Avoid
wearing clothing that is loose tting or that has hanging
cords or ties.
■ Thoroughly inspect the area where the machine is to be
used and remove all objects which can be thrown by the
machine.
■ Before using, always visually inspect to see that the
blade, blade bolt and the blade assembly are not worn or
damaged. Replace worn or damaged components in sets
to preserve balance. Replace damaged or unreadable
labels.
■ Before use check the power supply and extension
cord for signs of damage or aging. If the cord becomes
damaged during use, disconnect the cord from the supply
immediately. DO NOT TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY. Do not use the machine
if the cord is damaged or worn.
■ Operate the machine only in daylight or in good articial
light.
■ Avoid operating the machine in wet grass.
■ Always be sure of your footing on slopes.
■ Walk, never run.
■ Mow across the face of slopes, never up and down.
■ Exercise extreme caution when changing direction on
slopes.
■ Do not mow excessively steep slopes.
■ Use extreme caution when reversing or pulling the machine
towards you.

8
SAFETY INFORMATION
■ Stop the blade(s) if the machine has to be tilted for
transportation when crossing surfaces other than grass,
and when transporting the machine to and from the area to
be used.
■ Never operate the machine with defective guards or
shields, or without safety devices, for example deectors
and/or grass collector, in place.
■ Switch on the motor carefully according to instructions and
with feet well away from the blade(s).
■ Do not tilt the machine when switching on the motor, except
if the machine has to be tilted for starting. In this case, do
not tilt it more than absolutely necessary and lift only the
part, which is away from the operator.
■ Do not start the machine when standing in front of the
discharge opening.
■ Do not put hands or feet near or under rotating parts. Keep
clear of the discharge opening at all times.
■ Do not transport the machine while the power source is
running.
■ Stop the machine and remove plug from the socket. Make
sure that all moving parts have come to a complete stop.
− Whenever you leave the mower,
− Before clearing blockages or unclogging chute,
− Before checking, cleaning or working on the machine,
− After striking a foreign object. Inspect the machine
for damage and make repairs before restarting and
operating the machine.
■ If the machine starts to vibrate abnormally (check
immediately)
− Inspect for damage,

9
SAFETY INFORMATION
− Replace or repair any damaged parts,
− Check for and tighten any loose parts.
■ Keep all nuts, bolts and screws tight to be sure the machine
is in safe working condition.
■ Check the grass collector frequently for wear or
deterioration.
■ Be careful during adjustment of the machine to prevent
entrapment of the ngers between moving blades and xed
parts of the machine.
■ Always allow the machine to cool down before storing.
■ When servicing the blades be aware that, even though the
power source is switched off, the blades can still be moved.
■ Replace worn or damaged parts for safety. Use only
genuine replacement parts and accessories.
■ The machine should be supplied via a residual current
device (RCD) with a tripping current of not more than 30
mA.
■ Ensure that the mains voltage matches the specications
on the rating plate.
■ Use only authorised power cables of type H05VV-F, which
are no more than 75 m long and suitable for outdoor use.
The power cable wire cross section must be at least 2.5
mm2. Always completely unroll cable drums before use.
Check the cable for damage.
■ Keep the power cable away from the cutting tool when
working. The cutting blades may damage the power cable
and result in contact with live parts. Always run the power
cable behind the operator. The extension cable can be
accidentally cut. Risk of electric shock!
■ Do not use the power cable to pull the plug from the socket.
Protect the power cable from heat, oil and sharp edges.

10
SAFETY INFORMATION
■ Switch off the equipment and disconnect the plug from the
socket if the power cable is damaged. If the power cable
is damaged, it must be replaced by the manufacturer, the
customer services of the same, or a qualied person, in
order to avoid hazards.
■ Do not connect a damaged power cable to the mains. Do
not touch a damaged power cable when it is connected to
the mains. A damaged power cable may result in contact
with live parts.
■ Do not attempt to repair the equipment yourself unless you
have been trained to do so. Any work not specied in these
instructions is to be carried out only by a qualied person.
■ Use only spare parts and accessories supplied and
recommended by the manufacturer. The use of non-original
parts will immediately invalidate the guarantee.
■ Before each use, carry out a visual inspection of the
equipment. Do not use the equipment if protective devices
(e.g. grass collection bag), parts of the cutting device or
bolts are missing, worn or damaged. To avoid imbalance,
damaged tools and bolts are to be replaced only in sets.
■ Do not work with the equipment when tired, lacking
concentration or under the inuence of alcohol or drugs.
Always take breaks in good time. Take a sensible approach
to the work. A moment of carelessness when using the
equipment can result in serious injury.
■ Do not overload the equipment. Work only within the
specied power range and do not change the regulator
settings on the motor. Do not use low-powered machines
for heavy work. Do not use your equipment for purposes
other than those for which it is designed.

11
SAFETY INFORMATION
■ Do not work with equipment that is damaged, incomplete,
or has been modied without the authorisation of the
manufacturer. Do not use the equipment with damaged
safety devices or screens or with missing safety equipment
such as deection and/or grass collection devices.
■ Do not lift or carry the equipment when the motor is
running. Risk of injury from cuts.
■ Do not use the equipment near inammable liquids or
gases. Non-observance will result in a risk of re or
explosion.
■ Keep the equipment in a dry location and out of reach of
children.
■ Always keep the grass ejection hole clean and clear.
Remove cut material only when the equipment is stopped
and disconnected from power supply.
■ Do not leave the equipment unattended in the workplace.
■ When servicing the blades, remember that they can move
even if the power source is off.
■ Handle the equipment with care. Keep tools sharp and
clean, in order to facilitate better and safer work. Follow the
maintenance instructions.
Double Insulation
Double insulation is a concept in safety in electric power tools,
which eliminates the need for the usual three-wire grounded
power cord.
All exposed metal parts are isolated from the internal metal
motor components with protecting insulation. Double insulated
tools do not need to be grounded.

12
NOTE: Servicing of a product with double insulation requires
extreme care and knowledge of the system and should be
performed only by a qualied technician.
Electrical Connection
This product has a precision-built electric motor. It should be
connected to a power supply that is 220-240V~50 Hz, AC
only (normal household current). Do not operate this product
on direct current (DC). A substantial voltage drop will cause a
loss of power and the motor will overheat. If the product does
not operate when plugged into an outlet, double-check the
power supply.
Extension Cords
When using a power tool at a considerable distance from
a power source, be sure to use an extension cord that has
the capacity to handle the current the product will draw. An
undersized cord will cause a drop in line voltage, resulting in
overheating and loss of power.
Before you connect the mower to the mains supply make
sure that data on the rating plate are identical to the mains
data. Before using any extension cord, inspect it for loose or
exposed wires and cut or worn insulation.
SAFETY INFORMATION
The double insulated system is intended to protect the user from shock resulting from a break in
the tool’s internal insulation. Observe all normal safety precautions to avoid electrical shock.
WARNING

13
SAFETY INFORMATION
Intended Use
This lawnmower is designed for domestic use only:
■ This electric lawnmower is intended for mowing lawns in
domestic and hobby gardens.
■ This product is not to be used in wet weather conditions
and may not be used to mow wet or unusually high grass.
■ This product is intended for private domestic use only,
not for any commercial trade use. It must not be used for
any purposes other than those described. Any use of the
machine that deviates from its intended use will invalidate
the warranty.
Keep the extension cord clear of the working area. Position the cord so that it will not get caught
on other obstructions while you are working. Failure to do so can result in serious personal injury.
WARNING
IN THE BOX
1. Foam Grip
2. Upper Handle
3. Wing Knob (x4)
4. Lower Handle
5. Grass Collection Bag
6. Cutting Height Adjustment Lever
7. Rear Wheel
8. Deck
9. Front Wheel
10. Motor Housing
11. Carry Handle
12. Deector Guard
13. Grass Collection Bag Handle
14. Cord Retainer
15. Cable Clip (x2)
16. Safety Button
17. Start/Stop Switch Lever
18. Mulching Plug
19. Instruction Manual

14
ASSEMBLY
Assembly Preparation
■ Carefully remove all contents from the product packaging.
■ Ensure you have all the accessories and tool(s) needed for assembly and operation. This also
includes suitable personal protective equipment.
Assembling the Lower Handle (See Fig. 1)
■ Unfold the lower handle and adjust to the desired operating position. There are three possible
positions (Fig. 1).
■ Rotate the wing knobs clockwise to tighten (Fig. 1).
Assembling the Upper Handle (See Fig. 2)
■ Align the upper handle and lower handle and secure with the wing knobs and bolts (Fig. 2).
■ There are two possible height positions. Choose the one most suitable to the operator’s height.
■ Secure the control cable against the handle frame with the supplied cable clips.
If any parts are damaged or missing do not operate this product until the parts are replaced.
Failure to pay attention to this warning could result in serious personal injury.
Do not connect to power supply until assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
Do not attempt to modify this product or create accessories not recommended for use with this
product. Any such alteration or modication is misuse and could result in a hazardous condition
leading to possible serious personal injury.
Never operate the mower without the proper safety devices in place and in correct working order.
Never operate the mower with damaged safety devices. Failure to pay attention to this warning
can result in serious personal injury. Make sure all packing is removed from product parts before
starting assembly.
WARNING
WARNING
WARNING
WARNING

15
ASSEMBLY
Do not at any time make any adjustment to the lawnmower without rst stopping the motor and
disconnecting from power supply. Failure to comply could result in accidental starting and possible
serious personal injury.
WARNING
Assembling the Grass Collection Bag (See Fig. 3)
■ Fully insert the rods of the metal frame into the slots on either side of the plastic base of the
grass collection bag. Secure the metal support rods into the xing position on either side of
the grass collection base. Ensure the side clamping sleeves are properly xed onto the metal
support frame (Fig. 3).
■ There is a hole in the bottom of the grass collection bag to hang it up if required.
Attaching/Removing the Grass Collection Bag (See Fig. 4)
NOTE: When using the grass collection bag, do not install the mulching plug. The mulching plug
MUST be removed prior to installing the collection bag. The mulching plug is supplied tted in the
collection chute of the mower.
■ Lift the deector guard all the way up with one hand (Fig. 4).
■ Attach the grass collection bag onto the mounting brackets provided at the back of the lawn
mower. Align the bottom of the grass collection bag rst ensuring the collection tongue is located
fully within the discharge chute of the lawnmower (Fig. 4).
■ Lower the deector guard onto the grass collection bag - it will keep it in place.
■ To remove the grass collection bag, lift the deector guard and unhook the grass collection bag
from the mounting brackets. Carefully release the deector guard back down.
Grass Collection Full Indicator (See Figs. 5-6)
The grass collection full indicator is a small ap located on the side of the grass collection bag.
■ If the grass collection bag is empty or partially full, the grass full indicator ap will remain open
(Fig. 5).
■ When this ap remains closed it means that the grass collection bag is full and needs to be
emptied (Fig. 6).
Attaching/Removing the Mulching Plug (See Fig. 7)
NOTE: The mulching plug MUST be removed if collection bag is used during mowing operation.
This mulching plug prevents grass from being collected by blocking the collection chute. This allows
the grass clippings to be deposited back on the lawn during cutting. This nely cut grass acts as a
nutrient for the lawn.

16
ASSEMBLY
To install the mulching plug:
■ Lift the deector guard and detach the grass collection bag.
■ Lift and hold the deector guard up with one hand.
■ With other hand grasp the mulching plug by its upright handle and insert the plug into the rear
discharge chute. Ensure that the locking latch snaps into place (Fig. 7).
■ Release the deector guard back into position during operation.
To remove the mulching plug:
■ Lift and hold the deector guard up with one hand.
■ With other hand squeeze the mulching plug’s upright handle to release the locking latch. Pull
the mulching plug up and out of the discharge chute.

17
OPERATION
Setting the Cutting Height (See Fig. 8)
Do not allow familiarity with this type of product to make you careless. Always pay attention when
operating this product, not doing so can result in serious injury.
WARNING
Before using the mower for the rst time, adjust the cutting position to the height best suited for
your lawn. The mower can be set to 6 cutting heights between 20mm and 70mm. Choose the
appropriate cutting height according to the types and conditions of the grass. For the rst cut each
season, a higher cutting setting should be selected.
Always wear safety goggles or safety glasses with side shields when operating this product.
Failure to do so could result in objects being thrown into your eyes, resulting in possible serious
injury.
WARNING
Do not use any attachments or accessories not recommended by the manufacturer of this product.
The use of attachments or accessories not recommended can result in serious personal injury.
WARNING
Switch off the equipment, disconnect the plug from the power supply and wait for the blade to
come to a complete stop before adjusting the cutting height. A rotating blade can cause injury.
Keep your feet away from the deck when adjusting its height.
WARNING
Position Cutting Height
1 20mm
2 30mm
3 40mm
4 50mm
5 60mm
6 70mm

18
OPERATION
To set the cutting height:
■ To raise the cutting height, grasp the cutting height adjustment lever, disengage the lever from
its current setting, and then move it towards the back of the mower and engage the lever in the
desired cutting height position (Fig. 8).
■ To lower the cutting height, grasp the cutting height adjustment lever, disengage the lever from
its current setting, and then move it towards the front of the mower and engage the lever in the
desired cutting height position (Fig. 8).
Starting/Stopping the Mower (See Figs. 9-10)
NOTE: Use only an approved outdoor extension cord as described previously in this manual.
■ Attach the outlet end of an extension cord to the mower’s power inlet. Make a loop in the
extension cord and hang the loop onto the cord retainer(Fig. 9).
■ Connect the machine to a suitable power supply.
■ Before switching the mower on, make sure that the working area is free from debris and foreign
objects.
■ Press and hold the safety button. Pull the switch lever towards the mower handle and hold in
position (Fig. 10).
■ Once started, release the safety button. Continue to hold the switch lever against the mower
handle as you mow.
■ To switch the mower off, release the switch lever.
NOTE: A high-pitched noise and sparking may occur as the electric motor decelerates. This is
normal.
The blade may keep rotating for a few seconds after the device has been switched off. Do not
touch the rotating blade. A rotating blade can cause injury.
WARNING
General Operation
Check the product, its power cord and accessories for damage before each use. Before use,
ensure all power connections are in good working order prior to operation. If damage is present or
observed, stop and have mower serviced before use. Do not use the product if it is damaged.
■ Double check that the blade is properly installed.
■ Always hold the product by its handles. Keep the handle dry to ensure safe support.
■ Ensure that the air vents are always unobstructed and clear. Clean them if necessary with a soft
brush. Blocked air vents may lead to overheating and damage the product.
■ Switch the product off immediately if you are disturbed while working by other people entering
the working area.

19
OPERATION
■ Always let the product come to complete stop before removing the grass collection bag/
mulching plug.
■ Always keep the power cord behind you and when you turn, move it to the side that has already
been mowed.
■ Do not overwork yourself. Take regular breaks to ensure you can concentrate on the work and
have full control over the product.
Mowing (See Fig. 11)
■ Avoid cutting the power cord. It is advised to mow away from the plug socket and avoid twisting
the power cord (Fig. 11). Mow at a normal walking pace and always overlap tracks by a few
centimetres for a gap-free nish.
■ Make sure the lawn is clear of stones, sticks, wires, and other objects that could damage the
lawn mower blades or motor. Such objects could be accidentally thrown by the mower in any
direction and cause serious personal injury to the operator and others.
■ To reduce the likelihood of disconnecting the lawn mower from the power cord, be sure to use
the cord retainer provided.
■ When cutting thick grass, reduce walking speed in order to allow for a more effective cut and a
proper discharge of the clippings.
■ Never cut off more than one-third of the total length of the grass for a healthy lawn. If it is
roughly 6cm long, the grass should not be shorter than 4cm once mowed. If the grass is higher,
you should gradually cut it down to the desired length so as not to damage the grass. Cutting
grass that is too long will result in poor collection performance and may overload the motor.
■ Do not cut wet grass because it tends to stick to the underbody of the lawn mower, preventing
the proper discharge of grass clippings resulting in poor collection performance.
■ Slopes are a major factor related to slip and fall accidents that can result in severe injury.
Mowing on slopes requires extra caution. If you feel uneasy on a slope, do not mow it. For your
safety, do not attempt to mow slopes greater than 15 degrees.
■ Mow across the face of slopes, not up and down. Exercise extreme caution when changing
direction on slopes.
■ Watch for holes, ruts, rocks, hidden objects, or bumps which can cause you to slip or trip. Tall
grass can hide obstacles. Remove all objects such as rocks, tree limbs, etc., which could be
tripped over or thrown by the blade.
■ Always be sure of your footing. A slip and fall can cause serious personal injury. If you feel you
are losing your balance, release the switch lever immediately.
■ Do not mow near drop-offs, ditches, or embankments; you could lose your footing or balance.

20
MAINTENANCE
General Maintenance
■ Keep all safety devices, air vents and the motor housing free of dirt and dust. Avoid using
solvents when cleaning plastic parts. Most plastics are susceptible to damage from various
types of commercial solvents and may be damaged by their use. Use clean, dry cloths to
remove dirt, dust, oil, grease, etc.
■ Periodically check all nuts and bolts for proper tightness to ensure safe operation of the mower.
■ Remove any buildup of grass and leaves on or around the motor cover. Wipe the mower clean
with a dry cloth occasionally. Do not use water as this may damage any electrical components.
Replacing the Mower Blade (See Fig. 12)
Always wear protective, heavy gloves and/or wrap the cutting edges of the blade with rags when
performing blade maintenance. Failure to pay attention to this warning could result in serious
personal injury.
WARNING
If a part becomes worn or damaged, use recommended manufacturers replacement parts. Use of
any other parts may create a hazard or cause product damage.
Do not use any attachments or accessories not recommended by the manufacturer of this product.
The use of attachments or accessories not recommended can result in serious personal injury.
Switch off the equipment before all maintenance and cleaning work, disconnect the plug and wait
until the blade stops.
WARNING
WARNING
WARNING
■ Stop the motor and disconnect the power supply. Allow the blade to come to a complete stop.
■ Turn the mower on its side.
■ Wear sturdy gloves and hold the blade rmly. Turn the blade screw anticlockwise off the motor
spindle using a suitable wrench and remove it together with the blade (Fig. 12).
■ Replace the blade with a new one of the same type.
■ Reattach the blade onto the spindle, ensuring the blade's wings are angled upwards towards
the mower deck. Ensure that the blade is positioned correctly and the screw tightened rmly.
■ Using a torque wrench, tighten the blade nuts to 20Nm max. to ensure the bolt is properly
tightened.
