USE AND CARE GUIDE
Sears Madeline 3pc Bistro Set
* Swivel Rocker
Product Code: D71 M20918
UPC Code: 7 22938 11294 4
Date of Purchase: __ / __ / __
La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
© 2015 La-Z-Boy Incorporated.

2
Thank you for your purchase
THANK YOU FOR YOUR PURCHASE!
We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you
enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously
considered all the way down to the smallest details, exclusively for you, by our world class design
team. We know you have a choice when it comes to your patio furniture needs, so from our team to
yours, thank you for letting us be a part of your outdoors.
Table of Contents
Table of Contents.......................................... 2
Safety Information ........................................ 3
Warranty ........................................................ 3
What is Covered ......................................... 3
What is Not Covered................................... 3
Care and Maintenance.................................. 4
Pre-Assembly................................................ 5
Planning Assembly ..................................... 5
Observe weight limits.................................. 5
Tools required ............................................. 5
Hardware Included...................................... 5
Package Contents....................................... 6
Assembly Instruction ................................... 7
Customer Service ....................................... 12

3
SET UP YOUR FURNITURE
PROPERLY
□Ensure that all parts are assembled
properly and fully tightened as per the
instructions.
□When placing in the desired location,
ensure that all legs are resting on the same
surface. You may adjust the legs levelers
as required to ensure that the item stands
in a rigid position.
EXAMINE YOUR FURNITURE
□Examine occasionally to ensure that there
are no loose parts. If loose parts are found,
they must be retightened fully before
additional use.
Warranty
THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR
COMMERCIAL USE.
2 YEARS WARRANTY FOR FRAME, 1 YEAR WARRANTY FOR RESIN WICKER
AND CUSHIONS
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for 2 years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service
center.
This warranty does not cover commercial use, hardware, acts of nature, fire, freezing and abusive
use.
Discoloration or fading of the finish or fabrics as a result of chemicals or spills is not covered.
Glass table top breakage and corrosion or rusting of hardware are not covered.
In addition, purchase parts are not covered under this warranty.
Proof of purchase (dated register receipt) is required for warranty claims.
Safety Information
CAUTION: Read all of the instructions in
this manual before you begin assembly.
Failure to do so may result in faulty
assembly and potential injury!

4
We reserve the right to make substitutions with similar merchandise, if the model in question is no
longer in production.
For a copy of our full limited warranty, please contact our customer service team below.
Contact the Customer Service Team at 1-866-391-4868 or visit www.Bjifurniture.com.
Care and Maintenance
□Do not allow water to build up in frames. This will cause corrosion and possible freezing damage
in cold climates.
□Use a mild soap and water for normal cleaning. DO NOT use janitorial or alcohol based cleaners.
Some cleaners may be marked as natural, but some ingredients can cause discoloration or have
adverse reaction to your finish.
□Rinse with clean water and dry with a soft, absorbent cloth towel.
□Cushions, slings, and/or an umbrella may be cleaned by hand with a solution of soap and water
with a clean water rinse. Never machine wash as this will result in shrinking or damage. After
cleaning, tip on end and allow to drip dry. Never use a commercial or home dryer to tumble dry
fabric goods.
□Treat frames with liquid wax for maximum protection against UV rays and /or salty, damp air.
□Umbrella should be closed when not in use. Umbrella should be removed and stored in the event
of wind, rain, hail, sleet, snow, or any other inclement weather. To prevent damage to your table,
always use an umbrella base with your umbrella. Store indoors during winter months.
□Use and operation: To prolong the life of your outdoor furniture, cover when not in use. Store
indoors during winter months.
Warranty (continued)

5
Pre-Assembly
PLANNING ASSEMBLY
PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY!
Identify all parts packed in the carton against the parts list. Remove all protective materials and place
the parts on a nonabrasive surface to avoid scratching. It takes about 25 minutes for three persons to
complete all the assembly.
OBSERVE WEIGHT LIMITS
The recommended weight limit for each item is listed below:
□Swivel Rocker: 300lbs
TOOLS REQUIRED
Socket
Wrench
[included]
Hex
Wrench
[included]
HARDWARE INCLUDED
NOTE: Hardware not shown to actual
size.
Part Description Quantity
AA M6*40mm Hex Bolt 12
BB M6*30mm Hex Bolt 8
CC M6*20mm Hex Bolt 4
C1C1 M8*20mm Hex Bolt 4
EE M6 Washer 24
E1E1 M8 Washer 4
FF M6 Hex Bolt Cap 24
F1F1 M8 Hex Bolt Cap 4
NOTE: More than one person may be
required to complete the assembly of this
product.

Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
D Left Arm 2
E Right Arm 2
F Chair Seat 2
G Chair Back 2
H Chair Swivel Base 2
I Stem Bracket 2
J Seat Cushion 2
K Back Cushion 2
□EVERY BOLT NEEDS TO BE USED WITH A WASHER.
□DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 3.
Safety Information

7
Assembly Instruction
1 Attaching the stem bracket
NOTE: Do not fully tighten the bolts.
□Attach the stem bracket (I) to the chair seat (F) using washers (EE) & (E1E1) and hex bolts
(CC) & (C1C1).

8
Assembly Instruction
(continued)
2 Attaching the chair back
NOTE: Do not fully tighten the bolts.
□Attach the chair back (G) to the chair seat (F) using washers (EE) and hex bolts (AA).

9
Assembly Instruction
(continued)
3 Attaching the chair arms
□Attach the arms (D) & (E) to the chair seat (F) using washers (EE) and hex bolts (BB).
□Attach the arms (D) & (E) to the chair back (G) using washer (EE) and hex bolts (AA).
□Tighten all hex bolts (AA), (BB), (CC) & (C1C1) with the socket wrench and hex wrench.
□Attach the hex bolt caps (FF) & (F1F1).
NOTE: Once all the bolts are in place tighten
completely.

A
s
(c
4
s
sem
b
ontin
u
4
Inse
r
□Place
t
on the
b
ly In
s
u
ed)
r
ting th
e
t
he chair b
base. Ma
k
s
tructi
e
chair
ase (H) o
n
k
e sure th
e
on
bucket
n
a flat sur
f
e
seat bott
o
10
f
ace and a
o
ms out in
lign the st
e
the base
f
e
m under
t
f
or safety.
t
he seat fr
a
a
me with t
h
h
e hole

A
s
(c
5
s
sem
b
ontin
u
5
Addi
□Place
t
b
ly In
s
u
ed)
ng the
c
t
he seat c
u
s
tructi
c
ushio
n
u
shion (J)
a
on
n
s
a
nd back
c
11
c
ushion (K ) onto the chair.

12
Please refer to part number when reordering
Questions, problems, missing parts? Before returning to the store,
call our Customer Service
8 a.m. - 5 p.m., EST, Monday-Thursday
8 a.m. – 4 p.m., EST, Friday
1-866-391-4868
Made in/ Hecho en CHINA
Distributed by Sears, Roebuck and Co., Hoffman Estates, IL60179
See our extensive assortment of outdoor living products on-line
at www.sears.com and www.kmart.com
Retain this manual for future use.

13
USE AND CARE GUIDE
Sears Madeline 3pc Bistro Set
* Bistro Table
Product Code: D71 M20918
UPC Code: 7 22938 11294 4
Date of Purchase: __ / __ / __
La-Z-Boy® is a registered trademark of La-Z-Boy Incorporated and is used under license to BJI, Inc.
© 2015 La-Z-Boy Incorporated.

14
Thank you for your purchase
THANK YOU FOR YOUR PURCHASE!
We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you
enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously
considered all the way down to the smallest details, exclusively for you, by our world class design
team, We know you have a choice when it comes to your patio furniture needs, so from our team to
yours, thank you for letting us be a part of your outdoors.
Table of Contents
Table of Contents........................................ 14
Safety Information ........................................ 3
Set up your furniture properly...................... 3
Examine your furniture.............................. 15
Warranty ...................................................... 15
What is covered ........................................ 15
What is Not covered.................................. 15
Care and Maintenance................................ 16
Pre-Assembly.............................................. 17
Planning assembly.................................... 17
Observe weight limits................................ 17
Tools required ........................................... 17
Hardware included .................................... 17
Package contents ..................................... 18
Assembly Instruction ................................. 19
Customer Service ....................................... 10

15
Safety Information
SET UP YOUR FURNITURE
PROPERLY
□Ensure that all parts are assembled
properly and fully tightened as per the
instructions.
□When placing in the desired location,
ensure that all legs are resting on the same
surface. You may adjust the legs levelers
as required to ensure that the item stands
in a rigid position.
EXAMINE YOUR FURNITURE
□Examine occasionally to ensure that there
are no loose parts. If loose parts are found,
they must be retightened fully before
additional use.
WARNING: Do not sit or stand on the table.
WARNING: Do not place heavy items on the
table top.
Warranty
THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR
COMMERCIAL USE.
2 YEARS WARRANTY FOR FRAME, 1 YEAR WARRANTY FOR RESIN WICKER
AND CUSHIONS
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for 2 years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service
center.
This warranty does not cover commercial use, hardware, acts of nature, fire, freezing and abusive
use.
Discoloration or fading of the finish or fabrics as a result of chemicals or spills is not covered.

16
Glass table top breakage and corrosion or rusting of hardware are not covered.
In addition, purchase parts are not covered under this warranty.
Proof of purchase (dated register receipt) is required for warranty claims.
We reserve the right to make substitutions with similar merchandise, if the model in question is no
longer in production.
For a copy of our full limited warranty, please contact our customer service team below.
Contact the Customer Service Team at 1-866-391-4868 or visit www.Bjifurniture.com.
Care and Maintenance
□Do not allow water to build up in frames. This will cause corrosion and possible freezing damage
in cold climates.
□Use a mild soap and water for normal cleaning. DO NOT use janitorial or alcohol based cleaners.
Some cleaners may be marked as natural, but some ingredients can cause discoloration or have
adverse reaction to your finish.
□Rinse with clean water and dry with a soft, absorbent cloth towel.
□Cushions, slings, and/or an umbrella may be cleaned by hand with a solution of soap and water
with a clean water rinse. Never machine wash as this will result in shrink or damage. After
cleaning, tip on end and allow to drip dry. Never use a commercial or home dryer to tumble dry
fabric goods.
□Treat frames with liquid wax for maximum protection against UV rays and /or salty, damp air.
□Umbrella should be closed when not in use. Umbrella should be removed and stored in the event
of wind, rain, hail, sleet, snow, or any other inclement weather. To prevent damage to your table,
always use an umbrella base with your umbrella. Store indoors during winter months.
□Use and operation: To prolong the life of your outdoor furniture, cover when not in use. Store
indoors during winter months.
Warranty (continued)

17
Pre-Assembly
PLANNING ASSEMBLY
PLEASE READ COMPLETE USE AND CARE GUIDE PRIOR TO ASSEMBLY!
Identify all parts packed in the carton against the parts list. Remove all protective materials and place
the parts on a nonabrasive surface to avoid scratching. It takes about 25 minutes for three persons to
complete all the assembly.
OBSERVE WEIGHT LIMITS
The recommended weight limit for each item is listed below:
□Swivel Rocker: 300lbs
TOOLS REQUIRED
Socket
Wrench
[included]
HARDWARE INCLUDED
NOTE: Hardware not shown to actual
size.
NOTE: More than one person may be
required to complete the assembly of this
product.
Part Description Quantity
DD M6*15mm Hex Bolt 12
EE M6 Washer 12
FF M6 Hex Bolt Cap 12

18
Pre-Assembly (continued)
PACKAGE CONTENTS
-------------------------------- A
-------------------------------- B
-------------------------------- C
Part Description Quantity
A Table Top 1
B Table Leg 4
C Fixed Connector 1
□EVERY BOLT NEEDS TO BE USED WITH A WASHER.
□DO NOT FULLY TIGHTEN BOLT UNTIL INDICATED IN STEP 2.
Safety Information

19
Assembly Instruction
6 Attaching the fixed connector
NOTE: Do not fully tighten the bolts.
□Place the fixed connector (C) on a soft, flat non-abrasive surface.
□Attach the table legs (B) to the fixed connector (C) using washers (EE) and hex bolts (DD).

20
Assembly Instruction
(continued)
7 Attaching the table top
□Place the table top (A) on a soft, flat non-abrasive surface.
□Attach the table legs (B) to the table top (A) using washers (EE) and hex bolts (DD).
□Tighten all hex bolts (DD) with the socket wrench.
□Attach the hex bolt caps (FF).
NOTE: Once all the bolts are in place tighten
completely.
