LD DAVE G³ SERIES
ACTIVE 2.1 DSP BASED PA SYSTEM
LDDAVE18G3

2
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
You‘ve made the right choice!
We have designed this product to operate reliably over many years. LD Systems stands for this with its name and
many years of experience as a manufacturer of high-quality audio products.
Please read this User‘s Manual carefully, so that you can begin making optimum use of your LD Systems product
quickly.
You can find more information about LD SYSTEMS at our Internet site WWW.LD-SYSTEMS.COM
Introduction
Dave 18 G3 is a powerful and, at the same time handy, mobile compact PA system with two satellites and a subwoofer
that is characterised by a crystal clear, dynamic sound with a strong midrange. With its frequency response of 32 Hz
to 20 kHz and a maximum sound pressure level (SPL) of 135 dB peak, this system is an excellent choice for the most
diverse applications - mobile or fixed installations.

3
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
LD DAVE G³ SERIES
ACTIVE 2.1 DSP-CONTROLLED PA SYSTEM LDDAVE18G3

4
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
Avoid direct sunlight!
PREVENTIVE MEASURES:
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations). Make certain that wall
mounts are properly installed and secured. Make certain that the equipment is installed securely and cannot fall down.
7. During installation, observ e the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other sources of heat. Make certain
that the equipment is always installed so that is cooled sufficiently and cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. Do not use this equipment in the immediate vicinity of water (does not apply to special outdoor equipment -
in this case, observe the special instructions noted below. Do not expose this equipment to flammable materials,
fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not place containers filled with
liquids, such as vases or drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the manufacturer.
15. Do not open or modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to
tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly cause property damage and
personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the equipment or
if it has been damaged in anot her way, switch it off immediately and unplug it from the mains outlet (if it is a
powered device). This equipment may only be repaired by authorized, qualified personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate
plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
FOR EQUIPMENT THAT CONNECTS TO THE POWER MAINS:
22. CAUTION: If the power cord of the device is equipped with an earthing contact, then it must be connected to
an outlet with a protective ground. Never deactivate the protective ground of a power cord.
23. If the equipment has been exposed to strong fluctuations in temperature (for example, after transport), do
not switch it on immediately. Moisture and condensation could damage the equipment. Do not switch on the
equipment until it has reached room temperature.
24. Before connecting the equipment to the power outlet, first verify that the mains voltage and frequency match
the values specified on the equipment. If the equipment has a voltage selection switch, connect the equipment to
the power outlet only if the equipment values and the mains power values match. If the included power cord or
power adapter does not fit in your wall outlet, contact your electrician.
25. Do not step on the power cord. Make certain that the power cable does not become kinked, especially at the
mains outlet and/or power adapter and the equipment connector.
26. When connecting the equipment, make certain that the power cord or power adapter is always freely
accessible. Always disconnect the equipment from the power supply if the equipment is not in use or if you want

5
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
To prevent possible hearing damage, avoid listening at high volume levels over long periods of time.
Even exposure to short bursts of loud noise can result in hearing loss. Please keep the volume
constantly at a comfortable level.
SAFETY:
to clean the equipment. Always unplug the power cord and power adapter from the power outlet at the plug or
adapter and not by pulling on the cord. Never touch the power cord and power adapter with wet hands.
27. Whenever possible, avoid switching the equipment on and off in quick succession because otherwise this
can shorten the useful life of the equipment.
28. IMPORTANT INFORMATION: Replace fuses only with fuses of the same type and rating. If a fuse blows repea-
tedly, please contact an authorised service centre.
29. To disconnect the equipment from the power mains completely, unplug the power cord or power adapter
from the power outlet.
30. If your device is equipped with a Volex power connector, the mating Volex equipment connector must be
unlocked before it can be removed. However, this also means that the equipment can slide and fall down if
the power cable is pulled, which can lead to personal injuries and/or other damage. For this reason, always be
careful when laying cables.
31. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike or
before extended periods of disuse.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
Never remove the cover, because otherwise there may be a risk of electric shock. There are no user serviceable
parts inside. Have repairs carried out only by qualified service personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electrical shock.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance instructions.
CAUTION – HIGH VOLUME LEVELS WITH AUDIO PRODUCTS!
This equipment is intended for professional use. Therefore, commercial use of this equipment is subject to the
respectively applicable national accident prevention rules and regulations. As a manufacturer, Adam Hall is
obligated to notify you formally about the existence of potential health risks.
Hearing damage due to high volume and prolonged exposure: When in use, this product is capable of producing
high sound-pressure levels (SPL) that can lead to irreversible hearing damage in performers, employees, and
audience members. For this reason, avoid prolonged exposure to volumes in excess of 90 dB.

6
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
3 3
5
6
2 2
1 1
4
7
CONNECTIONS, CONTROLS, AND INDICATORS:
1LINE INPUT LEFT / RIGHT
Unbalanced line input (left / right) with 2 RCA jacks.
2LINE INPUT LEFT / RIGHT
Balanced line input with 2 XLR / 6.3 mm jack (combo jack).
3LINE OUTPUT LEFT / RIGHT
Balanced line output with 2 male XLR connectors. The output signal corresponds to the input signal.
4SUB PHASE 0° / 180°
The phase reverse switch for the subwoofer (0°, 180°) is factory set to 0°. This setting is suitable for the
majority of applications. In unfavourable acoustic conditions, the setting of 180° may have a positive effect
on the overall sound.
5INDICATOR LEDS
ON: Lights up once the system is properly connected to the power mains and switched on.
SIGNAL: Lights up as soon as an audio signal is present.
LIMIT: Lights up if the loudspeaker system is operating in the clipping range. A short flash of the LED is not
critical. To protect the system, an excessive signal level is gently turned down by the built-in limiter. If the
limiter LED lights up permanently or for longer periods, reduce the volume level. Failure to do so may result
in a distorted sound and damage to the speaker system.
PROTECT: Lights up if the system is overloaded/overheated. The amplifiers are muted automatically. Upon
reaching normal operating conditions, the device reverts to normal operating mode, after a few minutes.

7
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
108 8 9
6SUB LEVEL
Adjusting the volume ratio of the subwoofer to the satellite speakers.
7MAIN LEVEL
Overall volume adjustment. The subwoofer volume is also adjusted in accordance with the preset level on
the SUB LEVEL controller.
8SAT POWER OUT LEFT / RIGHT
Speakon compatible outputs (left / right) for the satellite speakers of the LD DAVE18G3 system.
9IEC VOLEX POWER SOCKET WITH INTEGRAL FUSE HOLDER
Used to power the device. An appropriate power cord is included in the delivery. To unlock, please press the
spring-loaded button on the connector.
IMPORTANT INFORMATION: The speaker is intended for 2 operating voltage ranges (100 V - 120 V AC and
200 V - 240 V AC). The conversion is done automatically.
Replace the fuse only with a fuse of the same type and rating (see label on the rear panel)! If the fuse blows
repeatedly, please contact an authorised service centre.
10 POWER
Illuminated On / Off switch for the power supply of the device. Before switching the active speaker on or off,
always adjust the volume to zero (MAIN LEVEL all the way to the left).
CONNECTIONS, CONTROLS, AND INDICATORS:

8
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
CONNECTING THE SATELLITE SPEAKERS:
The satellite speakers of the LD DAVE18G3 system each have a Speakon compatible speaker connection. Establish
the connection between the subwoofer (SAT POWER OUT LEFT / RIGHT) and the satellites using a suitable cable
(2-wire speaker cable, min. 2 x 1.5 mm², with Speakon compatible connectors.) Allocation: 1+ / 1-).

9
ITALIANOPOLSKIESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAISDEUTSCHENGLISH
SPEAKER FLANGE WITH VARIABLE TILT ANGLE:
The satellites of the LD DAVE18G3 system are equipped with the patented SM707 speaker flange with variable
tilt angle (0°, +/- 4.5°, +/- 9°, +/- 13.5°). To change the tilt angle, please follow these steps: Mount the speaker
on a suitable speaker stand, as usual. Now lift the speaker carefully (by approximately 0.5 cm), in order to unlock
the locking mechanism. Tilt the speakers to the desired position and lower it again.
The different tilt angles allow for an optimal positioning of the loudspeakers for different sound situations.
At events with a standing audience and
places where a greater range is required,
it is advisable to use the 0° angle of the
speaker flange.
At events with a seated audience and
rooms with smaller dimensions, it is
advisable to select a downward angle. This
way, in addition to a short-range acoustic
cover, adverse reflections on low ceilings
and rear walls are minimised.
To obtain an optimal dispersion in a pedestal
sound situation, choose an upward angle.

10
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
LD SYSTEMS LECC DSP:
WHAT DOES LD SYSTEMS LECC DSP STAND FOR?
DSP stands for Digital Signal Processing (Digital Signal Processing), LECC for limiter, EQ, Compressor and
Crossover. The digital signal processing ensures maximum audio performance with maximum clarity and
protects the PA system from overload.
WHAT EXACTLY DOES THE LECC DSP DO?
The Limiter function protects the speakers and prevents distortions caused by overload. Separate limiters
for the bass, midrange and high range attenuate the signal when the level exceeds a value which could have a
negative effect. Each limiter is optimised for one of the three seamlessly contiguous frequency ranges (multi-band
limiter). The system can be operated in this manner with a higher overall sound pressure as extreme peaks are
automatically lowered, so that the total volume does not need to be reduced.
The Multiband EQ works over the entire frequency range and optimises the overall sound of the system.
The Compressor is switched on automatically to raise the bass response and create a punchier sound. When
the volume is increased, the bass boost is automatically reduced. The automatically controlled bass blends
perfectly into the overall sound.
The Crossovers divide the audio signal according to the frequency range of the respective speakers, namely
the subwoofer or the mids and tweeters of the array column. The amplitude and running-time optimisation of the
crossover ensures that all frequencies are output evenly and reach the listener at the same time.
