LD ROADMAN 102 User manual

LD ROADMAN 102
PORTABLE SOUND SYSTEM 150 W
1
Y
USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D‘ USO

Thank you for choosing LD-Systems!
We have designed this product to operate reliably over many years. Therefore LD-Systems guarantees for high
quality products with its name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new LD-Systems
products quickly and to the fullest.
For information about LD-Systems check out our website WWW.LD-SYSTEMS.COM
2
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
02

3
ITALIANO
POLSKI
ESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAIS
DEUTSCHENGLISH
03
LD ROADMAN 102
PORTABLE PA SPEAKER 150 W
1
Y

1. Please read the attached safety instructions as well as the following instructions carefully.
2. Please keep all the instructions.
3. Please use the device only as intended.
4. Please respect the valid waste management rules. Please deliver the packaging divided into plastic and paper/
cardboard to the recycling management.
5. Please refer all servicing to qualified personel only if the device is damaged, exposed to liquid/rain or if it does
not operate normally.
6. Please, do not expose to any kind of heat such as ovens, radiators, or any other devices (incl. amplifiers).
Please check for enough distance between amplifiers and walls, racks, etc. to prevent overheating.
7. After connection please check the wiring to prevent any kind of accident or damage.
Please never use any kind of damaged cable and wiring.
8. Only use authorized and stable stands, brackets, shelfs, tables etc.. for installations. Please check for adequate
stability against collapse.
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product´s enclosure that may be
of sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION! HIGH VOLUME!
You will operate this system for professional use. Therefore the commercial use of this equipment is liable to the
rules and regulations of the Accident Prevention & Insurance Association of your industry sector. Adam Hall as a
manufacturer is bound to inform you formally about the existence of eventual sanitary risks.
These speakers are able to induce high acoustic sound pressure levels. 85 db is by law the maximum audio
pressure level which your ear can be exposed to during a work day. It was set according to the technical exper-
tise of the occupational medicine as a basis for the noise rating level. Higher sound levels or longer exposition
times could damage your ear. The time of exposition by higher sound pressure levels should be shortened in
order to prevent from ear damages. Here are a few reliable warning signals which show that you have exposed
yourself for a too long period to excessive sound pressure levels:
- You hear bell- or whistling sounds!
- You have the impression that you can’t hear high tones anymore!
CAUTION
RISK O F E L EC T RI C SH O CK
DO NO T O PE N
4
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
04
PREVENTIVE MEASURES:

1
2
3
4
5
6
7
8
1
Y
5
ITALIANO
POLSKI
ESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAIS
DEUTSCHENGLISH
05
BACK PANEL:
1WIRELESS RECEIVER MODULE
The roadman 102 is equipped of one wireless receiver
module.You can install a second receiver module if you
wish to use a second wireless microphone simultaneously.
2CD PLAYER
Digital Slot-In CD Player with USB memory stick input
and SD card slot. CD Player with anti-shock function.
Supported files (CD Player, USB Player, SD card reader):
Audio CD, MP3, WMA.
3TAPEDECK (OPTIONAL)
Cassette player/recorder, with tape reverse function
4CONTROL PANEL
Volume Control: Master, Wired Mic 1 & 2, Line-In, Tape
EQ: Bass, Treble
Audio Link: XLR In & XLR Out (Master or Slave), RCA In
& Out
Speaker Out: Switched & Unswitched
LED Indicator: Low Battery power (red), battery char-
ging (green blinking), battery fully charged (green).
5TROLLEY
6CARRY HANDLE
7WIRELESS ANTENNAS THREAD
8WHEELS

6
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
06
SYSTEM COMPONENTS:
Roadman
Handheld Microphone Antenna
Mic Case
Remote Control
Power Cord

7
ITALIANO
POLSKI
ESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAIS
DEUTSCHENGLISH
07
OPTIONAL ACCESSORIES:
Transport Bag (LDRM102BAG)
Belt Pack Transmitter (LDWS1616BP)
Headset Mic (WS100MH3)
Additional Receiver (LDRM102R)
Tapedeck (LDRM102TD)

12
13
14
1
2345
6
7
8
9
10
11
8
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
CD PLAYER:
08
1POWER/VOL
On / Off, Volume control
2PLAY / PAUSE
3STOP
Stop, return to the main menu
4FOLDER
Available in USB, MP3 CD and SD Card Mode
In Stop Mode: Use the FOLDER (LEFT/RIGHT)
buttons to go to the previous/next folder.
In Play Mode: Use the FOLDER (LEFT/RIGHT) but-
tons to go to the first file of the previous/next folder.
5SKIP (LEFT/RIGHT) BUTTONS
In Play and Stop Mode, press SKIP (LEFT/RIGHT)
to go to the previous /next track.
In Play Mode keep the SKIP button pressed to fast
forward (SKIP RIGHT) or fast reverse (SKIP LEFT)
a track.
6PROG
Function not available
7MODE
Press this button to switch between SD / USB /
CD mode
8REPEAT
Press once to repeat the current track.
Press twice to repeat all tracks.
9SHUF
Random play
10 EJECT
Remove disc
11 MUTE
Mutes the volume of the SD / USB / CD Player.
12 SD CARD SLOT
13 USB 2.0
Memory stick input
14 IR
Remote control receiver module
Since all our products are constantly controlled and improved, technical changes
are possible without prior notice.

8
4
3
2
1
7 10 12 13 16 19 20 23 17 25
5 6 9 11 14 15 18 21 22 24
9
ITALIANO
POLSKI
ESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAIS
DEUTSCHENGLISH
09
CD REMOTE CONTROL:
1POWER BUTTON: Power switch
2MODE BUTTON: Mode switch
3BUTTON: Pause / play button
4BUTTON: Repeated short press to clear and
restore the sound.
5BND/SYS
Function not available
6BUTTON:
Function not available
7TITLE BUTTON:
Function not available
8SUB-T BUTTON:
Function not available
9ENTER BUTTON:
Function not available
10 SETUP BUTTON:
Function not available
11 BUTTON:
Stop button
12 ANGLE BUTTON:
Function not available
13 SLOW BUTTON:
Function not available
14 AMS / RPT BUTTON:
Press once to repeat the current track.
Press twice to repeat all tracks.
15 ST / PROG BUTTON:
Function not available
The Roadman 102 is equipped with two remote control infrared receiver modules. One on the front and one on the rear
panel of the unit. You can therefore use the remote control in front of or behind the speaker.
Since all our products are constantly controlled and improved, technical changes
are possible without prior notice.

10
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
10
CD REMOTE CONTROL:
16 ZOOM BUTTON:
Function not available
17 VOL+VOL-BUTTON:
Increase or decrease the volume.
18 „LOC / RDM“ BUTTON
LOC / RDM“ button, random play.
19 SEL BUTTON:
Press this button to switch between SD / USB / CD
mode
20 BUTTON:
In Play and Stop Mode, press SKIP (LEFT/RIGHT) to
go to the previous /next track.
In Play Mode keep the SKIP button pressed to fast
forward (SKIP RIGHT) or fast reverse (SKIP LEFT)
a track..
21 PBC BUTTON:
Function not available
22 OSD BUTTON:
Available in Audio CD Mode.
Without pressing: Display shows track running time
Press once:
Display shows remaining time for the current track
Press twice:
Display shows the CD running time
Press three times:
Display shows remaining CD time
23 AUDIO LEFT / RIGHT STEREO ADJUSTMENT:
Function not available
24 1-10+BUTTON:
Function not available
25 GOTO BUTTON:
Function not available
Since all our products are constantly controlled and improved, technical changes
are possible without prior notice.

1
2
3
4
5
6
7
89101112
11
ITALIANO
POLSKI
ESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAIS
DEUTSCHENGLISH
CASSETTE RECORDER / PLAYER:
11
1EJECT
Opens the Cassette slot.
2COUNTER
3SPEED ADJ
With this button you can regulate the play speed of
the cassette player.
4CONTINUOUS LOOP
The player will play continuously (A and B Side
repeated) until you press stop.
5SINGLE LOOP
The player will play the A and the B Side and then
stop from itself
6SINGLE SIDE PLAYING
The player will read only one side of the cassette
and then stop from itself.
7MODE
Allows you to select between Continuous Loop,
Single Loop or Single Side playing Mode.
8STOP
9FAST FORWARD
The cassette player features an auto search func-
tion, pressing this button during play will take you
to the next song on the cassette.
10 PLAY
The cassette player features the Auto-Reverse
Function. You do not need to turn the cassette when
one side is over. The Play button disposes of 2
directions representing both sides of the cassette.
11 FAST REVERSE
The cassette player features an auto search func-
tion, pressing this button during play will take you
to the previous song on the cassette.
12 RECORD
Push the record button to activate the Recording
Mode, then push the play button to start recording.
Since all our products are constantly controlled and improved, technical changes
are possible without prior notice.

1
8 9
2 3
4
5
5
6
7
16
15
14
1320
21
22
23
24
10
11 12
25
26
181719
200-250V 50/60 Hz
12
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
12
BACK PANEL:
1AC 200-250 V POWER INPUT PLUG
2DC 24-32V POWER INPUT PLUG
3FUSE 5A
4VOICE PRIORITY
When Music is playing, turning on the Voice Priority
function will automatically decrease the volume of
the music when you speak in the microphone.
5As soon as you stop talking the music volume
increases again. It is the so called “Talk Over”
function.
5POWER SWITCH
This is the general power switch (ON/OFF for the
whole system)

13
ITALIANO
POLSKI
ESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAIS
DEUTSCHENGLISH
13
SYSTEM SETTINGS AND OPERATIONS:
6SWITCHED OUT
Use this Output to plug a further passive speaker.
When using this output the speaker of the Roadman
102 is automatically muted and the sound only
comes out of the passive speaker. (min 4 Ω)
7UNSWITCHED OUT
Use this Output to plug a further passive speaker.
When using this output the sound comes out of both
the Roadman and the passive speaker. (min 8 Ω)
8LINK OUTPUT
This output allows you to connect the Roadman to
another Roadman.
9LINK SET
MASTER / SLAVE: When connecting several Road-
man together (from 2 to max. 7) the Master / Slave
Order hast to be respected. First Roadman of the
“Chain” should be set on Master, the following ones
should be set on Slave. The Roadman that is set on
Master takes the control over all other Roadman
(Volume control, switch ON/OFF etc.)
10 VOLUME
Control of Slave Speakers
11 RCA OUTPUT
Allows line level output for recording or any other
use
12 RCA INPUT
Allows the connection of any line level device
13 MASTER
General volume control of the system
14 TREBLE
TREBLE / HIGH TONE Equalizer
15 BASS
BASS / LOW TONE Equalizer
16 LINE
Line Input (12) volume controller
17 MIC 1
Microphone 1 (20) volume controller
18 MIC2
Microphone 2 (22) volume controller
19 TAPE
Tape volume controller
20 MIC/LINE
Microphone or Line Input 1. Accepts Jack or XLR
connectors.
21 SPEECH/MUSIC
SPEECH: Microphone Input Level
Music: Line Input Level
22 MIC/LINE
Microphone or Line Input 2. Accepts Jack or XLR
connectors.
23 SPEECH/MUSIC
SPEECH = MIC: Microphone Input Level
Music = LINE: Line Input Level
24 LINK INPUT
This Input allows you to connect a Roadman to
another Roadman. The Link Input of the Slave Road-
man should be connected to the Link Output of the
Master Roadman.
25 CHARGING / LOW BATT
LED Indicator: Low Battery power (red), battery
charging (green blinking), battery fully charged
(green).
26 LED INDICATOR
When red, the system is in operation. Turned ON.

8769 5 4 321
14
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
14
WIRELESS RECEIVER MODULE:
1IR WINDOW
Sends infrared signals to the transmitter (handheld
mic) in order to synchronize the frequencies
2POWER
Power switch and Volume controller
3ASC
After selecting a transmitting frequency in the
receiver, press ASC to sync the transmitter. Hold the
IR port of the microphone in front of the IR port of
the receiver. (Sync with beltpack: Press ASC on the
beltpack and on the receiver to activate sync.
4MUTE LEVEL
Adjusting the receiver squelch setting:
This function suppresses noise when the trans-
mitter is off or when the receiver is no longer able
to receive a sufficiently strong signal from the
transmitter.
The squelch setting of the receiver is adjusted at
the factory so that the system functions optimally.
Normally, no further adjustment is required.
If readjustment does become necessary, the
squelch level should be set so that no noise is
detected in the receiver when the transmitter is off.
This makes it possible to suppress interference,
but it may also reduce system range under some
circumstances. If the squelch level is reduced,
interference can increasingly affect transmission
quality. However, this may increase system range
under some circumstances.
5AF
Shows if the module receives an audio signal
6RF
Shows if the module receives a radio signal
7UP
Channel Up
8DIGITAL DISPLAY
Digital channel display
9DOWN
Channel Down
5

1
4
5
6
7
2
3
15
ITALIANO
POLSKI
ESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAIS
DEUTSCHENGLISH
15
HANDHELD TRANSMITTER
1MICROPHONE HEADGRILLE
2GAIN
Use this controller to adjust the microphone sensitivity
Left decrease, Right increase.
Factory settings should give you complete satisfaction.
3RF POWER SWITCH
H stands for High power signal, L for Low power
signal.
4IR PORT
Receives the infrared frequencies sent by the recei-
ver in order to synchronize transmitter and receiver.
5BATTERIES RACK
Please Insert 2 AA Alkaline batteries (LR 6 1,5 V)
6POWER/ASC
Green light: Power On
Green flash: IR transmission in progress
Red flash: battery low
7ON/OFF SWITCH
CHANGING BATTERIES
Battery life is about 8 hours. If the Low Battery indica-
tor glows then change the batteries immediately.

5
6
234
1
7
16
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
16
1ANTENNA
2GAIN SETTINGS
Mic: Microphone
0: Guitar with passive pickup
-10 dB: Guitar with active pickups
3POWER LED
Green: operating
Red: Battery low
Blinking red: IR transmission is in progress
4MINI XLR MIC INPUT
5POWER ON / OFF BUTTON
6ASC BUTTON (ACTIVATE SYNC)
Press this button to activate the infrared connection
between transmitter and receiver
7IR PORT
Receives the infrared frequencies sent by the recei-
ver in order to synchronize transmitter and receiver.
WEARING THE BELTPACK TRANSMITTER
Clip the receiver to a belt. For ultimate results, clip the
receiver onto a belt by pushing the receiver down onto
the belt as far as it goes.
For guitarists, attach the guitar strap ”through” the
receiver clip.
CHANGING THE BATTERIES
Expected life for two alkaline batteries is approxima-
tively 8 hours. When the battery status indicator flashes
red the batteries should be changed immediately
as show on the left side. Please Insert 2 AA Alkaline
batteries (LR 6 1,5 V)
BELT PACK TRANSMITTER:

17
ITALIANO
POLSKI
ESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAIS
DEUTSCHENGLISH
17
HANDLING OF THE BATTERY:
Before you use your device for the first time the battery should be charged for 12 hours.
When the battery is low, the LED will glow red, when the battery is charging it will flash green.
To charge the battery simply connect the device with the power voltage cable to the AC Current.
This device is equipped with two 12 V4.5AH batteries. They can be used and recharged around 500 times, depen-
ding on the use and care.
The batteries should be charged 8 hours long. If the device stays for a long time unused make sure that you char-
ge the battery once every 3 month or at least before the next use.
HOW TO REPLACE THE BATTERIES
1. Make sure that the device is turned off and not connected to the power voltage
2. Unscrew the bottom panel to access the battery storage
3. Disconnect old batteries and connect the new ones. Make sure to respect the +/- order (Red + // Black -).
4. Place the new batteries in the battery storage and screw the bottom panel back.
5. Charge the new batteries at least 12 hours.
AT THE BOTTOM YOU CAN FIND THE BATTERY
STORAGE

TECHNICAL SPECIFICATIONS:
BASIC SPECIFICATIONS MAIN UNIT
Output power (max.): 100 W RMS / 4 Ω
Frequency response: 70 Hz - 16 kHz
Maximum sound pressure: 115 dB
THD: <0,5%
Speaker: 10“ Woofer / 1“ Tweeter
Power: 100 V - 240 V switching power supply
Charge battery 12 V / 5 Ah (2 pieces)
Size (W x H x D): 355 x 610 x 315 mm
Weight: 19 kg
Receiver module: UHF Module (863 MHz - 865 MHz)
(art. LDRM102R)
Battery life: 4 to 6 hours
CD PLAYER
Product type:
Compact disc digital audio system with mechanic &
electronic anti-shock CD, CD-R, CD-R/W, MP3, WMA,
USB MP3 WMA, SD MP3, WMA.
Disc loading: Slot-in Type
Power consumption: ≤ 5 W
Dimensions (W x H x D): 160 x 147.4 x 68,5 mm
Weight: 1,2 kg
WIRELESS MIC TRANSMITTER
Max Audio input level: 0 dBV
Dimensions (L x Ø): 250 x 54mm
Weight: 270 g (without batteries)
Power Requirements: 2 “AA” size alkaline or recharge-
able batteries
Battery Life: >12 hours (with alkaline batteries)
BELTPACK TRANSMITTER
Max Audio input level: 0 dBV to +10 dBV
Gain Adjustment Range: 30 dB
Input Impedance: 470 kΩ
Dimensions (W x H x D): 85 x 65 x 23 mm
Weight: 80 g (without batteries)
Power Requirements: 2 “AA” size alkaline or recharge-
able batteries
Battery Life: > 10 hours (with alkaline batteries)
Since all our products are constantly controlled and
improved, technical changes are possible without prior
notice.
18
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
18

Nr.
1 863,100 X
2 863,900
3 864,500
4 864,900
5 863,200
6 863,300
7 863,400
8 863,500
9 863,600
10 863,700 X
11 863,800
12 864,000
13 864,100 X
14 864,200
15 864,300
16 864,400
TECHNICAL SPECIFICATIONS:
LDWS1616 / Roadman / Roadboy
Frequency list for intermodulation free use of up to three wireless microphones simultaneously.
Frequency MHz Simultaneous
19
ITALIANO
POLSKI
ESPAÑOL
FRANCAISFRANCAIS FRANCAISFRANCAIS FRANCAIS
DEUTSCHENGLISH
19

LIMITED WARRANTY
This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer and Eminence branded products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional
independent warranty claims towards Adam Hall.
Adam Hall warrants that the Adam Hall product you have purchased from Adam Hall or from an Adam Hall autho-
rized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 5 years from
the date of purchase.
The Limited Warranty Period starts on the date of purchase. In order to receive warranty services you are required
to provide proof of the purchase date. Your dated sales or delivery receipt, showing the date of purchase, is your
proof of the purchase date. Should products of the brands named above be in need of repair within the limited war-
ranty period, you are entitled to warranty services according to the terms and conditions stated in this document.
This Limited Warranty extends only to the original purchaser of this Adam Hall branded product and is not trans-
ferable to anyone who obtains ownership of the Adam Hall branded product from the original purchaser. During
the Limited Warranty Period, Adam Hall will repair or replace the defective component parts or the product. All
component parts or hardware products removed under this Limited Warranty become the property of Adam Hall.
In the unlikely event that your Adam Hall product has a recurring failure, Adam Hall, at its discretion, may elect to
provide you with a replacement unit of Adam Hall´s choice that is at least equivalent to your Adam Hall branded
product in hardware performance.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not
responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam
Hall branded product.
This Limited Warranty does not apply,
- to wear parts (e.g. accumulator)
- to any product from which the serial number has been removed or that has been damaged or rendered defec
tive as the result of an accident
- in case of, misuse, abuse, or other external causes
- by operation outside the usage parameters stated in the user´s documentation shipped with the
product
- by use of spare parts not manufactured or sold by Adam Hall
- by modification or service by anyone other than Adam Hall
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.
MANUFACTURER´S DECLARATIONS:
20
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
20
