leahua LH-A026 User manual

Add：A1 Building The Sixth Industrial Zone Zhu Gang Road Hongxing Shijing Town Baiyun
District Guangzhou China.
Tel：[phone] Fax：[phone]
LH-A026 17R Beam Spot Wash moving
head light
User Manual
This manual contains important information.
Please read before operating fixture.

www.leahualight.com 1
1 SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
non-professionals, not to disassemble the light arbitrarily and
lighting accessories inside.
rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
(to be selected).
not beam irradiate the flammable materials, flammable materials
and the lamp should be maintained at least 1M over the distance.
lamps used in ambient temperature: -15 ℃-40 ℃, the highest
temperature of the surface of the lamp: 60 ℃.
to keep away from the liquid substance and humid environment.
before using the lights must ensure the good grounding, can not
install charging and remove any parts.
the installation of lamps, must be fixed screw fasteners with
additional security cable and regular inspection.
lamps consecutive working hours is not recommended more than
10 hours.
should stop using the lights in time when happens unusual
conditions during the process
lamp parts of the rotation, external accessories and paste parts
should be regular inspected, such as the emergence of loose and
rock, should be reinforced in a timely manner to prevent the
accident.
lamps adopt strong winds to refrigerate, it is easy to accumulate the
dust, so you have to clean it weekly especially the cooling air
opening, otherwise the dust will plug leading to poor light

www.leahualight.com 2
2 TECHNOLOGY REFERENCE
Input: AC100v-240V 50/60HZ
Power Consumption:460w
Lamp source: YODN MSD 350w 17R
Lamp life:2000Hrs
Zoom angel:30-100(beam mode)50-400(Spot mode)
Electronic Focus:30-400
Color temperature:8000K
Control mode:DMX512/auto/master-slave
Channel:16/24ch
Net weight:20kg
Flight case size: 940*500*830mm(Double/CTN)
G.W.: 75kg
Specifiction：
Colors:1color wheel with 13 fixed colors+blank,with rainbow
effect
Rotating gobos:1 gobo wheel with 9 gobos+blank, indexable and
replaceable "SLOT&LOCK" glass gobos + open
Static gobos:1 gobo wheel with 14 gobos+blank
Prism:6 linear prism rotating+8 prisms rotating
Dimmer:0-100% linear dimmer
Strobe:Independent strobe channel, 1-13times/s, speed
adjustable
Pan=5400Tilt=2500movement
Pan/Tilt Resolution:16bit
LCD display
3pin DMX in/out
Power input:Power con

www.leahualight.com 3
3 Board Instruction
MENU:
DMX
001-512
Sys Set
DMX mode
Channel mode:16
Channel mode:24
Pan Inverse
OFF/ON
Tilt Inverse
OFF/ON
XY Blackout
OFF/ON
Run Mode
DMX/Auto
Backlight
60S/Always
Save
Exit
Adjust
Pan
001-255
Pan Fine
001-255
Tilt
001-255
Tilt Fine
001-255
Pan Tilt Speed
001-255
function
001-255
color
001-255
color Fine
001-255
Effect Speed
001-255
Static Gobo
001-255
Rotating Gobo
001-255
Rot Gobo
001-255
Rot Gobo Fine
001-255
Prism
001-255
Prism Rot
001-255
Frost
001-255
Zoom
001-255

www.leahualight.com 4
Zoom Fine
001-255
Focus
001-255
Focus Fine
001-255
Auto Focus
001-255
Shutter
001-255
Dimmer
001-255
Dimmer Fine
001-255
Exit
Infor
Factory
Lamp
Lamp Status
On/Off
Lamp on power
On/off
Exit
Reset
Reset Pan&Tilt
Reset Effect
Reset All
Exit
Display
Language
Chinese
English
Display Flip
Yes/No
Touch calibration
Exit

www.leahualight.com 5
4 DMX CHANNEL SHEET
24CH
16CH
DMX Value
Function
1
1
0-255
Pan
2
*
0-255
Pan fine
3
2
0-255
Tilt
4
*
0-255
Tilt fine
5
3
0-255
Pan, Tilt speed
6
4
Macro function
0-19
Reserve
20-24
230W power
25-29
350W power
30-49
Reserve
50-59
Reserve
60-69
Reserve
70-79
P/T Rotate Off Light
80-89
P/T Rotate On Light
90-99
Reserve
100-109
Reserve
110-119
Reserve
120-129
Reserve
130－139
Lamp
140－149
P/T Reset
150－189
Effect Reset
190－199
Reserve
200－209
whole Reset
210－229
Reserve
230－239
Lamp Off
240－255
Reserve
7
5
Color wheel
0-127
Linear Color

www.leahualight.com 6
128-129
white
130-134
Color 1
135-138
Color 2
139-143
Color 3
144-147
Color 4
148-152
Color 5
153-157
Color 6
158-161
Color 7
162-166
Color 8
167-171
Color 9
172-176
Color 10
177-180
Color 11
181-185
Color 12
186-189
Color 13
190-220
Forward from fast to slow
221-224
STOP
225-255
Backward from slow to fast
8
*
Reserve
9
6
Static gobo wheel
0-3
White
4-9
Gobo 1
10-15
Gobo 2
16-21
Gobo 3
22-27
Gobo 4
28-33
Gobo 5
34-39
Gobo 6
40-45
Gobo 7
46-51
Gobo 8
52-57
Gobo 9
58-63
Gobo 10
64-69
Gobo 11
70-75
Gobo 12

www.leahualight.com 7
76-81
Gobo 13
82-87
Gobo 14
88-95
Gobo 1 Shake
96-103
Gobo 2 Shake
104-111
Gobo 3 Shake
112-119
Gobo 4 Shake
120-127
Gobo 5 Shake
128-135
Gobo 6 Shake
136-143
Gobo 7 Shake
144-151
Gobo 8 Shake
152-159
Gobo 9 Shake
160-167
Gobo 10 Shake
168-175
Gobo 11 Shake
176-183
Gobo 12 Shake
184-191
Gobo 13 Shake
192-199
Gobo 14 Shake
200-201
White
202-227
Backward flow fast to slow
228-229
STOP
230-255
Forward from slow to fast
10
7
Rotated gobo wheel
0
Small white
1-4
Large white
5-8
Gobo 1
9-12
Gobo 2
13-16
Gobo 3
17-20
Gobo 4
21-24
Gobo 5
25-28
Gobo 6
29-32
Gobo 7
33-36
Gobo 8
37-40
Gobo 9

www.leahualight.com 8
41-48
Gobo 1 Shake
49-56
Gobo 2 Shake
57-64
Gobo 3 Shake
65-72
Gobo 4 Shake
73-80
Gobo 5 Shake
81-88
Gobo 6 Shake
89-96
Gobo 7 Shake
97-104
Gobo 8 Shake
105-112
Gobo 9 Shake
113-119
Large white
120-185
Forward from fast to slow
186-189
STOP
190-255
Backward from fast to slow
11
8
Rot. gobo
0-127
Rotation indexing
128-190
Backwards gobo rotation
from fast to slow
191-192
STOP
193-255
Forwards gobo rotation from
slow to fast
12
*
Reserve
13
9
Prism
0-63
Empty
64-127
Prism1:6 linear prism
128-191
Prism2: 8 circular prism
192-255
Prism1/Prism2
14
10
Prism1 Rotation
0－127
Rotation indexing
128－189
Backward rotating flow fast
to slow
190－192
STOP

www.leahualight.com 9
178-255
Forward rotating from slow
to fast
15
11
Prism2 Rotation
0－127
Rotation indexing
128－189
Forward rotating from fast to
slow
190－192
STOP
178-255
Backward rotating from slow
to fast
16
12
Frost
0-64
Reserve
65-255
Linear Frost
17
13
0-255
Zoom
18
*
0-255
Zoom fine
19
14
0-255
Focus
20
*
0-255
Focus fine
21
*
Reserve
22
15
Strobe
0-31
Closed
32-63
Open
64-95
Slow to Fast
96-127
Open
128-143
Fast close slow open, speed
from fast to slow
144-159
Fast open slow close, speed
from slow to fast
160-191
Open
192-223
Random strobe
224-255
Open
23
16
0-255
Linear Dimmer
24
*
Reserve

www.leahualight.com 10
5 DIFFICULTY RESOLUTION
The following is a list of problems and resolution, and other
malfunction preparing work should be professionally qualified staff to
deal with.
1. Bulb not working
a) Check whether approaching the service life of light bulbs, then
change it
b) Check whether bulbs circuitry leak, loss or connect poorly
2. Beam appears bleak
a) The bulbs maybe approach the service life, then change it, or
the optical components are unclean.
b) Bulbs have accumulation of dust, so the bulbs and other parts
inside the lamp should be cleaned and maintained in regular
period.
3. Computer lamp work intermittently
a) Check whether the fan process naturally and become dirty
b) Check inner temperature-response control plug is off
c) Check whether the circuitry is good
4. The computer lamp not controlled by controller during lighting
a) Check numeral starting address and the connection of
communication control circuit
b) The corresponding channel button of controller is open or not
c) Check whether the fuse on power supply input jack is broken
off

www.leahualight.com 11
6 AFTER SERVICE
1. Our company offer technical consultation to customers for ever.
2. If the machine is wrong and need repairmen, please truthfully fill in
the related content and feedback us the problems timely, as well as
we have to improve the product.
3. In addition to the lamp, also matching accessories are as follows：
accessories：Power line 1 piece Optional parts：(customers）

Warranty Card
Name Model Production Purchase
Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the
warranty will not work (warranty period and terms, see the following)
warranty period：one year since purchase warranty terms：1、If fail when using the product
in normal state, you can made under the provisions of the warranty, show the warranty card
and purchase bills(copy), and enjoy free maintenance service in a specific service center or
the manufacturer.
2. The following will be the implementation of paid service:
(1)Without the effective warranty card
(2)There’s blank, alter and no point-of-sale name
(3)Fail caused by unresistance
(4)Fail caused by transportation or unloading
(5)Fail caused by not operate by manual
End User
Company Name:
Add:
Sale Store
Link man:
Tel: Stamp

www.leahualight.com 12
(6)Fail caused by disassemble without unauthorized
(7)Fail caused by using the unauthorized control system
Note:
Based on our company continue to improve the product, the statement
containing data may have changed, and will not notice the change any
more. Company retains its right to change specifications related when
product is improved. Thanks for your understanding.
