Instruction Manual
This manual contains important information. Please keep it
for future reference. Ce guide contient des informations importantes.
Veuillez le conserver pour toute référence future.

INTRODUCTION
Thank you for purchasing the LeapPods Max™ headphones!
Dance to party songs, experience immersive adventures, unwind
with instrumental music or use with your own Bluetooth
®
wireless
technology enabled devices!
1
On/Off Switch
Indicator
Light
Back Button
Pairing Button
3.5mm Audio Port
Mode Select Dial
Play/Pause
Button
USB Charging Port
Volume Button
Next Button
Adjustable Headband

INCLUDED IN THE PACKAGE
• LeapPods Max™ • Adventure Passport booklet
• Micro-USB cable • 3.5mm audio cable
• Quick Start Guide
WARNING
All packing materials, including tape, plastic sheets, packaging
locks, removable tags, cable ties, cords and packaging screws
are not part of this toy, and should be discarded for your child’s
safety.
NOTE
Please save this Instruction Manual as it contains important
information.
ATTENTION
Pour la sécurité de votre enfant, débarrassez-vous de tous
les produits d’emballage tels que rubans adhésifs, feuilles de
plastique, attaches, étiquettes, cordons et vis d’emballage. Ils
ne font pas partie du jouet.
NOTE
Il est conseillé de conserver ce guide des parents car il comporte
des informations importantes.
2

GETTING STARTED
When you use the LeapPods Max™ for the first time, move the
On/Off Switch to the On position( ). When powered on,
the Indicator Light will turn green.
Battery Charging
Note: Adult operation required.
The LeapPods Max™ cannot be used while charging, even if
power is turned on.
When the battery is low, the Indicator Light will turn red.
To charge the LeapPods Max™, connect it to a computer using
the included Micro-USB Cable. To do so correctly, please follow
these steps:
• Please charge the LeapPods Max™ before first use.
• The LeapPods Max™ can be charged either in On or Off mode.
•Open the rubber cover of the USB Charging Port on the
bottom of the LeapPods Max™.
• Insert the small end of the included Micro-USB Cable into the
USB Charging Port on the LeapPods Max™.
• Insert the large end of the included Micro-USB Cable into a
USB port on your computer.
•The Indicator Light will turn orange while the LeapPods Max™
is charging. After the battery is fully charged, the Indicator
Light will turn green. You may then disconnect your fully
charged LeapPods Max™ headphones from the computer.
•
This toy contains a rechargeable battery that is non-replaceable.
USB port for battery charging:
The current output of USB DC 5V, with a minimum of 0.5A
3

Guidelines for Charging With the Micro-USB Cable
Charge this device using the included Micro-USB Cable connected
to a computer. Do not charge using a third party adapter. Before
use, inspect the cord to confirm that it is in good condition and
that there are no breaks or exposed wires. Ensure there are no
particles or liquid (water, juice, etc.) in either of the connectors
before plugging in either end of the cable. The device should
be completely dry with no debris in the cable connectors when
charging. Securely plug in the cable in the correct orientation.
Never leave the device unattended while charging. Do not charge
your device on soft surfaces, as they can trap heat around the
device.
Typical charging time is approximately 2-4 hours if the battery
is fully depleted. Disconnect the device when it is fully charged.
The actual charging time depends on the charging current, the
remaining charge in the battery prior to recharging and the
ambient temperature. The optimum ambient temperature is
32°F - 104°F (0°C - 40°C).
Battery Life
The time the battery lasts between charges depends on usage.
Like other electronic devices, more frequent usage will drain the
battery more quickly. When the battery level is low as shown by
the red Indicator Light, it is recommended to charge the battery
before further use. When the battery level is too low, the LeapPods
Max™ will not turn on until it is sufficiently recharged.
Battery Maintenance
Charge the battery regularly for optimal performance, even
when the LeapPods Max™ is not regularly in use. For example,
charge the LeapPods Max™ at least once every six months.
4

BATTERIES CANNOT BE REPLACED
The batteries in this toy are permanently encased. Before giving
this toy to a child make sure there are no signs of damage.
Regularly check the toy and dispose of it immediately if there
are any signs of damage. Do not dispose of the toy in a fire, as
the batteries may leak and explode. Keep batteries safely out
of children’s reach before disposing of them via a safe disposal
system.
PRODUCT FEATURES
1. On/Off Switch
Slide the On/Off Switch to the On position.
When powered on, the Indicator Light will
turn green.
2. Pairing Button
Press the Pairing Button to connect
with other Bluetooth®devices.
Note: See the Pairing Mode section
below for instructions.
3. Mode Select Dial
Rotate the Mode Select Dial to choose
a category: Dance Party, Adventures,
Learning Songs, Challenges, Quiet Time
and Instrumentals.
4. Play/Pause Button
Press the Play/Pause Button to play or
pause the track.
5

5. Next Button
Press the Next Button to skip to the
next track in the category.
6. Back Button
Press the Back Button once to go back
to the beginning of the current track.
Press the Back Button again to skip to
the previous track in the category.
7. Volume Button
Press the + on the Volume Button to
increase the volume and press the - on
the Volume Button to decrease the
volume.
8. Adjustable Headband
The headband can be adjusted by gently
pulling the headphones down from the
headband.
9. USB Charging Port
Connect the unit to your computer using
the included Micro-USB Cable to charge
the headphones.
10. Audio Port
Connect to other devices using the
included 3.5mm Audio Cable.
6

11. Automatic Shut-Off
To preserve battery life, the unit will automatically go to
sleep after 5 minutes of inactivity. The unit can be woken
up by pressing the Play Button.
PLAY MODES
1. Pairing Mode
• Press the Pairing Button to turn the Bluetooth
®
connection on
or off. Press and hold the Pairing Button for 3 seconds to go
into Pairing Mode.
• The Indicator Light will flash blue when waiting for a
connection.
• Choose the LeapPods Max™ from your peer device to send
the connection request. Press and hold the Play Button for
3 seconds to confirm.
Bluetooth
®
will be disconnected after
60 seconds if the connection is not confirmed.
• When the connection is confirmed, the Indicator Light will
turn solid blue.
•The LeapPods Max™ will automatically connect to confirmed
devices.
2. Line-In Mode
Make sure the headphones are powered on. Plug in the
included 3.5mm Audio Cable to the 3.5mm Audio Port on
the headphones and connect the other end to an external
device.
7

ACTIVITIES
Content Categories
There are six categories of content:
Dance Party
1. Silly Willy Was a Walrus
2. Dance-O-Rama Llama
3. Stinky Bean
4. Dance Together
5. Don’t Stop Dancing
6. Dance It Out
7. Nature’s Music
8. Through the Seasons
9. Dancing Robots
10. Just Bounce
Adventures
Explore with the Adventure Passport booklet to enhance the fun.
1. Amazon Rainforest
2. African Savanna
3. Under the Sea
4. Australian Animal Sanctuary
5. The Countryside
6. Deciduous Forest
8

Learning Songs
1. Dew Drops
2. Brush My Teeth
3. Pick It Up
4. Wash My Hands
5. Super Hero Helper
6. I Am Me
7. Mistakes Are Okay
8. Grow Little Seed
9. Counting Dandelions
10. Healthy Snacks
Challenges
1. Wiggle Freeze
2. Bird’s the Word
3. Pop and Flop
4. Bunny Hop Hopscotch
5. Twinkle Toes
6. Ocean Motions
7. Creepy Crawlies
8. Jumpin’ Jellybeans
Quiet Time
1. I Am Still
2. My Actions Matter
3. I Am Patient
4. Kindness
5. Having Gratitude
6. My Body is Strong
7. Relax and Reset
8. Breathe With Me
9. Trying New Things
10. Practice Makes Progress
9

Instrumentals
1. Gentle Storm
2. Dancing Trees
3. Summer Nights
4. Buzzing Energy
5. Simple Beats
6. Hidden Journey
7. Playful Winds
8. Magenta Wings
9. Exciting Adventure
10. Desert Sunset
CARE & MAINTENANCE
• Keep the rubber cover over the Micro-USB Port closed tightly
when not in use in order to prevent dust or water from getting in.
• Keep the LeapPods Max™ and accessories clean by wiping
them with a slightly damp cloth. Never use solvents or
abrasives.
• Always keep the LeapPods Max™ headphones away from
water.
• Keep the LeapPods Max™ out of direct sunlight and away
from any direct heat sources.
• Turn off the LeapPods Max™ if not being used for an extended
period of time.
• Avoid dropping the LeapPods Max™. NEVER try to dismantle it.
• Do not leave the LeapPods Max™ plugged in for extended
periods of time.
• Use the Micro-USB Cable that came with this device to charge
it.
• Examine the Micro-USB Cable regularly, checking for damage
to the cable, plug and other parts. Do not use the Micro-USB
Cable if there is any damage.
10

Important Safety Instructions
• As with all electrical products, precautions should be observed
during handling to prevent electric shock.
• The Micro-USB Cable and 3.5mm Audio Cable could be a
strangulation hazard. Keep out of reach of children under 3
years of age. The Micro-USB Cable should be used only by an
adult when connecting to a computer and is to be removed
by an adult prior to the use of the product by a child.
•
Routinely check the LeapPods Max™ for proper and safe condition.
If there is any damage or broken parts, remove from use.
•The LeapPods Max™ should only to be connected to equipment
bearing either of the following symbols: or .
• Adult supervision required at all times while children are
playing with this product.
• Always turn the volume level of your headphones down to
a low level before placing the headphones on your (or your
child’s) head. Gradually turn up the volume until you achieve
a comfortable level.
• It is not recommended to use this product while sleeping.
• The battery is recyclable, please follow your local recycling
regulations.
• The LeapPods Max™ headphones include a built-in volume
limiter to limit the sound output to 85dBA which is
recommended by the World Health Organization. This safety
level has been tested for the built-in content and streaming
via
Bluetooth
®
wireless technology connection.
• When using the 3.5mm Audio Cable, some devices may
deliver a sound level that exceeds 85dBA. Make sure to
always turn the device volume to a low level before placing
the headphones on your child’s head.
Warning! Continued exposure to loud noise may cause
gradual but permanent damage to hearing.
Avertissement ! L’exposition continue à un bruit fort peut
causer des dommages auditifs progressifs permanents. 11

Environmental Phenomena
Static electricity may cause the unit to malfunction. In cases
where unit is malfunctioning due to static electricity, reset the
unit by turning the power Off and back On again.
Disclaimer and Limitation of Liability
LeapFrog and its suppliers assume no responsibility for any
damage or loss resulting from the use of this handbook. LeapFrog
and its suppliers assume no responsibility for any loss or claims
by third parties that may arise through the use of this product.
TROUBLESHOOTING
If for some reason the heaphones do not work, please follow
these steps:
Problem Correction
The LeapPods
Max™ has
stopped working
1. Slide the On/Off Switch to the Off
position for 30 seconds.
2. Slide the On/Off Switch to the On
position again. It should now work
properly.
3. If the headphones don’t work,
recharge the battery and repeat steps
1 and 2.
(Refer to the Getting Started section
for details.)
Cannot connect
with 3.5mm
Audio Cable
1. Make sure the headphones are
powered on.
2. Check that the 3.5mm Audio Cable is
connected to your headphones and
the external device correctly.
3. Inspect the 3.5mm Audio Cable for
damage.
12

Charging
Indicator flashes
rapidly while
charging
1. Disconnect from power by unplugging
the Micro-USB Cable.
2. Inspect the Micro-USB Cable for
damage.
3. Reconnect the cable.
Cannot connect
with
Bluetooth
®
1. On your Bluetooth
®
device, please
go to Bluetooth
®
settings. If the
LeapPods Max™ is found in your list of
connected, paired or saved devices,
please “forget” or “unpair” it.
2. Then, disable and enable
Bluetooth
®
or
restart your device.
3. Turn the LeapPods Max™ off and on
and repeat the
Bluetooth
®
wireless
technology pairing process.
Cannot control
the volume level
LeapPods Max™ cannot control the
volume on some external devices. If you
do not hear audio, be sure to check the
volume setting on both LeapPods Max™
and the external device to be sure they
are not set to the lowest volume level.
IMPORTANT NOTE:
If the problem persists, please call our Consumer Services
Department at 1-800-701-5327 in the U.S. and Canada, or email
[e-mail]. Creating and developing LeapFrog
products is accompanied by a responsibility that we take very
seriously. We make every effort to ensure the accuracy of the
information, which forms the value of our products. However,
errors sometimes can occur. It is important for you to know
that we stand behind our products and encourage you to
contact us with any problems and/or suggestions you might
have. A service representative will be happy to help you.
13

NOTE
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Caution: Changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
Supplier’s Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Trade Name: LeapFrog®
Model: 6162
Product Name: LeapPods Max™
Responsible Party: LeapFrog Enterprises, Inc.
Address: 2200 Powell Street, Suite 500,
Emeryville, CA 94608
Website: leapfrog.com
14

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
USB Cable: Use only the Micro-USB Cable provided by LeapFrog.
Using any other cable may exceed FCC and other regulatory
emissions limits. The Micro-USB Cable is not a toy. Disconnect
the toy from the USB connection before cleaning.
RF Warning Statement
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure
condition without restriction.
This device contains licence-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :
1) L’appareil ne doit pas produire de brouillage;
2) L’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le
fonctionnement.
15

Visit our website for more
information about our products,
downloads, resources and more.
leapfrog.com
leapfrog.ca
Read our complete warranty and
legal policies online at
leapfrog.com/legal
LeapFrog Enterprises, Inc.,
A subsidiary of VTech Holdings Limited.
TM & © 2022 LeapFrog Enterprises, Inc.
All rights reserved.
The Bluetooth®word mark and logos are registered trademarks
owned by the Bluetooth SIG, Inc. and any use of such marks by
LeapFrog is under license. Other trademarks and trade names
are those of their respective owners.
IM-616200-000
Version:1 US CAN AUS
