S E R V I C E M A N U A L

SIMPLE MANUAL

• Replace this Service Manual with ”Revision Publishing” when it is issued.

CT-X4019

CT-X4059

• TYPE:

S/M Code No. 09–997–334–8T1

STEREO CAR CASSETTE

RECEIVER

HJB,HJW(207)HJB,HJW(207)

• BASIC TAPE MECHANISM:CDS-36SCH-94

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

*409YUST ...............XX..................................A...................

4019YLST ...............XX...................................B..................

4059YLST ...............XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 706 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 703 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

C 702 87-010-263-010 0E CAP, ELECT 100-10V ABC.................

C 705 87-010-314-080 0E C-CAP,S 22P-50V ABC.................

C 707 87-010-314-080 0E C-CAP,S 22P-50V ABC.................

C 708 87-010-314-080 0E C-CAP,S 22P-50V ABC.................

C 701 87-010-380-010 0E CAP,E 47-16 SME ABC.................

C 709 87-012-358-080 0E C-CAP,S 0.47-10 F Z ABC.................

C 710 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 711 87-010-404-010 0E CONDENSER 4.7-50 ABC.................

C 712 87-012-349-080 0E C-CAP,S 1000P-50 CH ABC.................

D 702 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 701 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

IC 701 8Z-KTG-621-010 2A C-IC,TC9323F-007 ABC.................

L 702 87-003-097-080 0E COIL,1UH ABC.................

L 701 87-003-149-080 0E COIL,47UH ABC.................

Q 702 87-A30-282-040 C-TR,DTA114TKA ABC.................

Q 701 87-A30-287-040 0E C-TR,DTC114TKA ABC.................

S 751 87-A91-152-010 1A SW,SL 1-1-2 SSSS212-11-A ABC.................

X 701 87-A70-175-010 1B VIB,XTAL 4.5MHZ AT-49 ABC.................

C 307 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

C 308 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

C 305 87-010-263-010 0E CAP, ELECT 100-10V ABC.................

C 306 87-010-263-010 0E CAP, ELECT 100-10V ABC.................

C 304 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 303 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 309 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 301 87-012-349-080 0E C-CAP,S 1000P-50 CH ABC.................

C 302 87-012-349-080 0E C-CAP,S 1000P-50 CH ABC.................

C 311 87-010-263-010 0E CAP, ELECT 100-10V ABC.................

C 310 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

CN 301 87-009-031-010 0E CONNECTOR, 3P ABC.................

CN 302 87-099-408-010 0E CONN,8P EH V WHT ABC.................

CNA 301 8Z-KTG-651-010 CONN ASSY,3P HEAD ABC.................

CNA 302 8Z-KTG-652-010 CONN ASSY,8P MOTOR ABC.................

IC 301 87-A21-191-010 IC,KIA6225S ABC.................

ANT 101 8Z-KT1-614-010 1A ANT,AW-002 ABC.................

C 102 87-010-186-080 0E CAP,CHIP 4700P ABC.................

C 106 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 109 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 101 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

C 105 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

C 104 87-010-380-010 0E CAP,E 47-16 SME ABC.................

C 103 87-010-380-010 0E CAP,E 47-16 SME ABC.................

C 117 87-010-180-080 0E C-CER 1500P .BC.................

C 118 87-010-180-080 0E C-CER 1500P .BC.................

C 110 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 112 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

C 115 87-010-220-080 0E C-CAP,S 0.018-25 B .BC.................

C 116 87-010-220-080 0E C-CAP,S 0.018-25 B .BC.................

C 114 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 113 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 111 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 119 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 116 87-012-365-080 0E C-CAP,S 0.027-25VBK A...................

C 115 87-012-365-080 0E C-CAP,S 0.027-25VBK A...................

ELECTRICAL MAIN PARTS LIST - 2

C 121 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 122 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 123 87-010-380-010 0E CAP,E 47-16 SME ABC.................

C 120 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 124 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

D 101 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

D 102 87-020-465-080 0E DIODE,1SS133 (110MA) ABC.................

L 101 87-003-143-080 0E COIL 4.7 UH ABC.................

L 102 8Z-KT1-619-010 1A COIL,68MH K7-D ABC.................

Q 101 87-A30-287-040 0E C-TR,DTC114TKA ABC.................

Q 104 87-A30-287-040 0E C-TR,DTC114TKA ABC.................

Q 109 87-A30-289-040 0E C-TR,2SA1037AK(R) ABC.................

Q 103 87-A30-289-040 0E C-TR,2SA1037AK(R) ABC.................

Q 107 89-324-122-080 0E TR,2SC2412K ABC.................

Q 108 89-324-122-080 0E TR,2SC2412K ABC.................

Q 102 89-324-122-080 0E TR,2SC2412K ABC.................

Q 110 87-A30-287-040 0E C-TR,DTC114TKA ABC.................

TU 101 8Z-KT1-631-010 2D TU UNIT, FAE347-A02 ABC.................

TU 101 8Z-KT1-632-010 2D TU UNIT, FAE347-P01 ....................

C 408 87-010-184-080 0E CHIP CAPACITOR 3300P(K) ABC.................

C 407 87-010-184-080 0E CHIP CAPACITOR 3300P(K) ABC.................

C 409 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

C 404 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 403 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 401 87-010-380-010 0E CAP,E 47-16 SME ABC.................

C 405 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 406 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 402 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 410 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

C 412 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 418 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 417 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 411 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 419 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 416 87-A11-177-080 0E C-CAP,S 0.15-16 K B ABC.................

C 414 87-A11-177-080 0E C-CAP,S 0.15-16 K B ABC.................

C 415 87-A11-177-080 0E C-CAP,S 0.15-16 K B ABC.................

C 413 87-A11-177-080 0E C-CAP,S 0.15-16 K B ABC.................

C 424 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 421 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 422 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 420 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 423 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

IC 401 8Z-KT1-622-010 2A C-IC,LC75374E ABC.................

C 609 87-012-157-080 0E C-CAP,S 330P-50 CH ABC.................

C 601 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 604 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 602 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 606 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 603 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 605 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 607 87-A11-179-010 CAP,E 10-16-105 D5*L11 KMF ABC.................

C 608 8Z-KT1-633-000 1B CAP,E 3300U-16 105 PW ....................

C 608 8Z-KT1-633-090 1B CAP,E 3300U-16 PW ABC.................

C 611 87-012-157-080 0E C-CAP,S 330P-50 CH ABC.................

C 612 87-012-157-080 0E C-CAP,S 330P-50 CH ABC.................

C 610 87-012-157-080 0E C-CAP,S 330P-50 CH ABC.................

C 622 87-010-182-080 0E C-CAP,S 2200P-50 B ABC.................

C 621 87-010-182-080 0E C-CAP,S 2200P-50 B ABC.................

C 623 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

D 602 87-A40-529-080 1A DIODE,1GWJ42 ABC.................

D 607 87-A40-529-080 1A DIODE,1GWJ42 ABC.................

D 606 87-A40-529-080 1A DIODE,1GWJ42 ABC.................

D 604 87-A40-529-080 1A DIODE,1GWJ42 ABC.................

ELECTRICAL MAIN PARTS LIST - 3

D 605 87-A40-529-080 1A DIODE,1GWJ42 ABC.................

D 608 87-A40-529-080 1A DIODE,1GWJ42 ABC.................

D 603 87-A40-529-080 1A DIODE,1GWJ42 ABC.................

D 601 87-A40-529-080 1A DIODE,1GWJ42 ABC.................

IC 601 8Z-KTG-622-010 2A IC,TA8259H ABC.................

C 207 87-010-112-010 0E CAP,ELECT 100-16V ABC.................

C 203 87-010-182-080 0E C-CAP,S 2200P-50 B ABC.................

C 204 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

C 208 87-010-235-010 0E ELECTROLYTIC, 470-16 ABC.................

C 209 87-010-248-010 0E CAP, ELECT 220-10V ABC.................

C 205 87-010-263-010 0E CAP, ELECT 100-10V ABC.................

C 206 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

C 201 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 212 87-010-112-010 0E CAP,ELECT 100-16V ABC.................

C 213 87-010-380-010 0E CAP,E 47-16 SME ABC.................

C 210 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 211 87-016-669-080 0E C-CAP,S 0.1-25 K B ABC.................

C 251 87-010-198-080 0E CAP, CHIP 0.022 ABC.................

CN 201 8Z-KT1-611-010 1B CONN,16P CAM-B51 ABC.................

CNA 201 8Z-KT1-620-110 CONN ASSY,8P ISO-BLACK ....................

CNA 202 8Z-KT1-621-110 CONN ASSY,8P ISO-WHITE ....................

D 204 87-001-783-080 0E DIODE,1N4002 ABC.................

D 203 87-001-783-080 0E DIODE,1N4002 ABC.................

D 205 87-017-932-080 0E ZENER,MTJ6.2B ABC.................

D 206 87-070-334-080 0E ZENER,MTZJ10B ABC.................

D 202 87-A40-654-010 0E DIODE,DSA17C ABC.................

D 201 87-A40-654-010 0E DIODE,DSA17C ABC.................

D 251 87-070-136-080 0E ZENER,MTZJ5.1B ABC.................

F 201 8Z-KC1-621-010 1B FUSE,15A 32V ABC.................

IC 201 88-KTD-604-010 IC,BA09T ABC.................

IC 251 88-KT1-606-080 1A IC,PST994D ABC.................

L 201 8Z-KT1-615-010 1C FLTR,AMORPHOUS -CHOKE ABC.................

Q 203 87-A30-168-010 TR,2SB1566F ABC.................

Q 202 87-A30-168-010 TR,2SB1566F ABC.................

Q 204 87-A30-287-040 0E C-TR,DTC114TKA ABC.................

Q 207 87-A30-287-040 0E C-TR,DTC114TKA ABC.................

Q 205 87-A30-287-040 0E C-TR,DTC114TKA ABC.................

Q 208 87-A30-294-040 C-TR,DTB123YK ABC.................

Q 206 89-423-953-010 TR,2SD2395F ABC.................

Q 201 8Z-KTH-626-080 TR,KTC3203Y ABC.................

C 801 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 802 87-010-316-080 0E C-CAP,S 33P-50 CH A...................

CN 801 88-KTA-603-010 1C CONN,15P CAM-B68 ABC.................

D 802 87-017-932-080 0E ZENER,MTJ6.2B ABC.................

D 804 87-017-932-080 0E ZENER,MTJ6.2B ABC.................

D 805 87-017-932-080 0E ZENER,MTJ6.2B ABC.................

D 801 87-017-932-080 0E ZENER,MTJ6.2B ABC.................

D 803 87-017-932-080 0E ZENER,MTJ6.2B ABC.................

D 806 87-027-262-010 0E LEDE,TLR-124(RED) ABC.................

L 801 87-003-149-080 0E COIL,47UH ABC.................

Q 801 87-A30-287-040 0E C-TR,DTC114TKA ABC.................

C 453 87-010-318-080 0E C-CAP,S 47P-50 CH A...................

C 452 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 451 87-010-401-010 0E CAP, ELECT 1-50V ABC.................

C 505 87-010-175-080 0E CAP 560P .BC.................

C 508 87-010-175-080 0E CAP 560P ABC.................

C 507 87-010-175-080 0E CAP 560P ABC.................

C 506 87-010-175-080 0E CAP 560P .BC.................

C 509 87-010-322-080 0E C-CAP,S 100P-50 CH ABC.................

C 504 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 503 87-010-378-010 0E CAP, ELECT 10-16SME ABC.................

C 502 87-010-378-010 0E CAP, ELECT 10-16SME .BC.................

C 501 87-010-378-010 0E CAP, ELECT 10-16SME .BC.................

D 451 87-017-932-080 0E ZENER,MTJ6.2B A...................

ELECTRICAL MAIN PARTS LIST - 4

J 501 88-KTA-604-010 1C JACK,PIN 4P V-TYPE .BC.................

J 501 88-KTA-605-010 1C JACK,PIN 2P V-TYPE A...................

L 451 87-005-902-080 C-COIL,S4.7UH K LK2125 A...................

Q 501 87-A30-281-040 0E C-TR,DTC363TK ABC.................

Q 504 87-A30-281-040 0E C-TR,DTC363TK ABC.................

Q 503 87-A30-281-040 0E C-TR,DTC363TK ABC.................

Q 502 87-A30-281-040 0E C-TR,DTC363TK ABC.................

C 904 87-010-189-080 0E C-CAP,S 8200P-50 B ABC.................

C 903 87-010-189-080 0E C-CAP,S 8200P-50 B ABC.................

C 902 87-010-197-080 0E CAP, CHIP 0.01 DM ABC.................

C 905 87-010-805-080 0E CAP, S 1-16 ABC.................

C 901 87-012-358-080 0E C-CAP,S 0.47-10 F Z ABC.................

CN 901 88-KTA-602-010 1A CONN,15P CAM-B67 ABC.................

D 901 87-020-585-080 0E CHIP-ZENER,02CZ6.2Y ABC.................

D 904 87-020-585-080 0E CHIP-ZENER,02CZ6.2Y ABC.................

D 905 87-020-585-080 0E CHIP-ZENER,02CZ6.2Y ABC.................

D 903 87-020-585-080 0E CHIP-ZENER,02CZ6.2Y ABC.................

D 902 87-020-585-080 0E CHIP-ZENER,02CZ6.2Y ABC.................

IC 902 87-A90-951-010 1C RCR UNIT,SBX1971-52 ABC.................

IC 901 88-KTD-602-010 1H C-IC,TC9297F ABC.................

J 901 87-A60-249-010 1B JACK,MOJ-B32 ABC.................

LCD 901 8Z-KTG-606-010 LCD,ZKT-16 ABC.................

PL 903 8Z-KTA-610-010 LAMP,T-3-9V-50MA ABC.................

PL 902 8Z-KTA-610-010 LAMP,T-3-9V-50MA ABC.................

PL 901 8Z-KTA-610-010 LAMP,T-3-9V-50MA ABC.................

PL 906 8Z-KTA-610-010 LAMP,T-3-9V-50MA ABC.................

PL 904 8Z-KTA-610-010 LAMP,T-3-9V-50MA ABC.................

PL 905 8Z-KTA-610-010 LAMP,T-3-9V-50MA ABC.................

PL 907 8Z-KTA-610-010 LAMP,T-3-9V-50MA ABC.................

S 904 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 903 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 906 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 905 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 907 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 902 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 901 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 908 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 909 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 917 87-A90-001-010 1A C-SW,TACT SKQMAL ABC.................

S 919 87-A90-001-010 1A C-SW,TACT SKQMAL ABC.................

S 918 87-A90-001-010 1A C-SW,TACT SKQMAL ABC.................

S 916 87-A90-001-010 1A C-SW,TACT SKQMAL ABC.................

S 915 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 914 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 913 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 912 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 911 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 910 87-A91-159-010 0E SW,TACT SKHLAD ABC.................

S 920 87-A90-001-010 1A C-SW,TACT SKQMAL ABC.................

S 921 87-A90-001-010 1A C-SW,TACT SKQMAL ABC.................

MECHANICAL PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

*409YUST................XX..................................A...................

4019YLST ...............XX...................................B..................

4059YLST ...............XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-KT1-023-010 DOOR,CASS ABC.................

8Z-KTA-002-010 CABI,REAR -T10 ABC.................

8Z-KTA-011-010 CABI,BASE -T10 ABC.................

8Z-KTA-012-010 CABI,TRIM -T10 ABC.................

8Z-KTB-002-010 RING,OVAL T -T ABC.................

8Z-KTG-001-010 WINDOW,LCD X419 IR ....................

8Z-KTG-002-010 CABI,FRONT -T16 ABC.................

8Z-KTG-003-010 WINDOW,LCD X409 IR A...................

8Z-KTG-004-010 WINDOW,LCD X4059 IR ..C.................

8Z-KTG-005-010 WINDOW,LCD X459 ....................

8Z-KTG-009-010 WINDOW,LCD X4019 IR .B..................

8Z-KTG-010-010 WINDOW,LCD X419 ....................

8Z-KTG-017-010 WINDOW,LCD X309 ....................

8Z-KTG-021-010 WINDOW,LCD X319 ....................

8Z-KT1-007-010 BTN,+/- -T ABC.................

8Z-KT1-008-010 BTN,SEL -T ABC.................

8Z-KT1-010-010 BTN,H-BASS -T ABC.................

8Z-KT1-011-010 BTN,U/D -T ABC.................

8Z-KT3-002-010 BTN,P.SET -T3 ABC.................

8Z-KT5-019-010 BTN,M.INF -T ABC.................

8Z-KTA-005-010 BTN,EJ -T10 ABC.................

8Z-KTA-006-010 BTN,FF -T10 ABC.................

8Z-KTA-007-010 BTN,REW -T10 ABC.................

8Z-KTA-008-010 BTN,DETACH -T10 ABC.................

8Z-KTF-003-010 BTN,TETRA BALD -T ABC.................

8Z-KTG-006-010 BTN,PWR -T ABC.................

8Z-KTG-007-010 BTN,TWIN T/M -T ABC.................

8Z-KTG-008-010 BTN,CD/MD IN -T ABC.................

87-KTE-205-010 SPR-C,EJ/FF/REW ABC.................

8Z-KT1-211-010 COVER, TOP -T ABC.................

8Z-KT1-212-010 COVER, BOTTOM -T ABC.................

8Z-KT1-220-010 HLDR,JACK F -T .BC.................

8Z-KT1-235-010 COVER, CONN.BLIND -T ....................

8Z-KT1-244-010 SPR-T,DOOR Z ABC.................

8Z-KT1-257-010 HLDR,ISO-WIRE -T ....................

8Z-KT1-265-010 HLDR,TR2 ABC.................

8Z-KT4-201-010 COVER, CD BLIND -T ABC.................

8Z-KT5-020-010 HLDR,M.INF -T ABC.................

8Z-KT5-201-010 COVER, ISO BLIND -T ABC.................

8Z-KTA-202-010 HLDR,DECK CDS36 ABC.................

8Z-KTA-203-010 LEVER,DFP LOCK -T10 ABC.................

8Z-KTA-204-010 LEVER,DEF HOOK -T10 ABC.................

8Z-KTA-205-010 HLDR,JACK -T10 A...................

8Z-KTA-210-010 HLDR,LCD -T10 ABC.................

8Z-KTA-213-010 LENS,L -T10 ABC.................

8Z-KTA-214-010 LENS,R -T10 ABC.................

8Z-KTA-221-010 SPR-C,DETACH LOCK-T10 ABC.................

8Z-KTA-222-010 SPR-T,DETACH LOCK-T10 ABC.................

8Z-KTA-223-010 SPR-C,RELEASE -T10 ABC.................

8Z-KTA-226-010 SPR-C,EJECT ABC.................

8Z-KTG-202-010 HLDR,P-IC -T16 ABC.................

8Z-KTG-207-010 CAP,LAMP BLU B2*4 ALC ABC.................

8Z-KTG-208-010 CAP,LAMP GRN G50 ALC ABC.................

8Z-KTG-209-010 CAP,LAMP ORN ....................

8Z-KTG-211-010 CASE,LCD LENS -T16 ABC.................

8Z-KTG-212-010 LENS,LCD -T16 ABC.................

87-251-073-410 0E SCREW,U+2.6-6 ABC.................

87-251-075-410 0E U+2.6-10 ABC.................

87-251-096-410 0E U+3-10 ABC.................

87-432-903-010 0E WASHER,WTE 2.6 ABC.................

87-B10-210-010 0E UT2+3.0-6.0 W/0 SLOT (BH TAP) ABC.................

88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK ABC.................

8Z-KT1-253-010 S-SCREW,PT 2*8 BH+ BLK ABC.................

8Z-KT1-254-010 S-SCREW,PT 2*5 BH+ BLK ABC.................

MECHANICAL PARTS LIST - 2

ACCESSORIES LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

*409YUST ...............XX..................................A...................

4019YLST ...............XX...................................B..................

4059YLST ...............XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-KTG-901-010 IB,YU(3L) 419 ....................

8Z-KTG-902-010 IB,INST,YU (3L)419 ....................

8Z-KTG-903-010 IB,YU(3L) 409 A...................

8Z-KTG-904-010 IB,INST,YU (3L)409 A...................

8Z-KTG-905-010 IB,YL(3L) 4019/4059 .BC.................

8Z-KTG-906-010 IB,INST,YL (3L)4019/4059 .BC.................

8Z-KTG-907-010 IB,YZ(9L) 409/419 ....................

8Z-KTG-908-010 IB,INST,YZ (6L)409/419 ....................

8Z-KTG-909-010 IB,INST,YZ (CZ-PO-H)409/419 ....................

8Z-KTG-910-010 IB,YV(ER) 419 ....................

8Z-KTG-911-010 IB,INST,YV (ER) 419 ....................

8Z-KTG-912-010 IB,Y(E CH A) 459 ....................

8Z-KTG-913-010 IB,Y,INST (E CH A)459 ....................

86-KT1-237-010 HLDR,REAR MTG ABC.................

87-B10-141-010 0E NUT,5 TYPE-2 ABC.................

87-B10-144-010 0E W,5.2-10-0.5 ABC.................

87-B10-145-010 0E W-SPR,5.3-8.5-1.5 ABC.................

88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK ABC.................

8Z-KT1-030-010 CASE,DFP -T ABC.................

8Z-KT1-231-010 HLDR,HALF -T ABC.................

8Z-KT1-232-010 KEY,REMOVE -T ABC.................

8Z-KT1-616-010 1F CONN ASSY,16P B52 ABC.................

8Z-KTG-951-010 SPKR,16CM ASSY ..C.................

* 87-B10-143-010 0E UT1+5-15 W/O SLOT ABC.................

* 88-KT1-247-010 S-SCREW,HEXAGON ABC.................

* 8Z-KT1-251-010 S-SCREW,5*6 TH+ TAPPING ST ABC.................

Printed in Singapore

Tokyo Japan

737004

Other manuals for CT-X4019

This manual suits for next models

Table of contents

Popular Car Receiver manuals by other brands

Linear Series

Linear Series LS5050 Operation and installation manual

Kenwood

Kenwood KRC-160 instruction manual

Sony

Sony XR-CA430X Service manual

T+A Elektroakustik

T+A Elektroakustik K1 CD-RECEIVER operating instructions

SoundMax

SoundMax SM-CDM1052 instruction manual

Xtrons

Xtrons HD107HD user manual

Mopar

Mopar RB3 manual

Clarion

Clarion ADDZEST DMZ615 owner's manual

Sony

Sony XAV-601BT Specifications

PIE

PIE GM12-POD/S Operation manual

Hyundai

Hyundai H-910H instruction manual

Sony

Sony XR-C6100 Service manual

Sony

Sony CDX-L600X - Fm/am Compact Disc Player Installation/connections

Motorola

Motorola VWA63 Service manual

Sound Storm

Sound Storm STM93R user manual

Nextar

Nextar D3201 instruction manual

Alpine

Alpine CDE-163BT owner's manual

Kenwood

Kenwood KDC-X303 quick start guide

Aiwa CT-X4019 User manual

Popular Car Receiver manuals by other brands
