Lectrosonics Venue User manual

VR Field Wideband Receiver
Modular Receiver System with 230 MHz Bandwidth
INSTRUCTION MANUAL
Rio Rancho, NM, USA
www.lectrosonics.com
Fill in for your records:
Serial Number:
Purchase Date:
Hardware/Software Installation and Configuration
Includes three versions:
• Wideband (blocks 21 through 29)
• Wideband Low (blocks 470 through 26)
• Wideband High (blocks 25 through 29)

VR Field Wideband Receiver
LECTROSONICS, INC.
2

Digital Hybrid Wireless™ Modular Receiver System
Rio Rancho, NM, USA 3
Windows is a registered trademark of Microsoft Corp.
Vista is a trademark of Microsoft Corp.
Table of Contents
Introduction.............................................................................................................................................................................................5
Unpacking the unit ................................................................................................................................................................................5
Controls and Functions .........................................................................................................................................................................6
Front Panel............................................................................................................................................................................................6
Rear Panel ............................................................................................................................................................................................7
Hardware Installation .............................................................................................................................................................................8
Installing/Removing Receiver Modules .................................................................................................................................................8
Installing the VR Field System ..............................................................................................................................................................8
Initial Startup ........................................................................................................................................................................................10
Navigating the LCD Menus and Screens............................................................................................................................................11
Resetting to Factory Defaults..............................................................................................................................................................12
System Setup with the LCD.................................................................................................................................................................12
Selecting Compatibility Modes............................................................................................................................................................12
Selecting the Noise Reduction Mode..................................................................................................................................................12
Selecting Diversity Modes...................................................................................................................................................................13
Selecting the Tuning Mode..................................................................................................................................................................14
Finding Clear Frequencies with SmartTune ........................................................................................................................................15
Finding Clear ChannelsUsing Full Spectrum Scan.............................................................................................................................15
Adjusting Audio Output Levels ............................................................................................................................................................16
Selecting Audio Phase........................................................................................................................................................................17
Selecting Transmitter Battery Status Monitoring Mode .......................................................................................................................17
Locking Out the Front Panel Controls .................................................................................................................................................18
Installing LecNet2™Software and USB Driver ...................................................................................................................................19
Setting Up the Venue Receiver Using VRpanel..................................................................................................................................22
Opening VRpanel with USB Port ........................................................................................................................................................22
Opening VRpanel with a COM Port ....................................................................................................................................................22
VRpanel Main Window........................................................................................................................................................................22
Main Window Top Menu Items ............................................................................................................................................................23
Popup Menu Items ..............................................................................................................................................................................23
Antenna Use and Placement ...............................................................................................................................................................25
Powering Remote RF Amplifiers .........................................................................................................................................................25
Pre-coordinated Frequencies..............................................................................................................................................................26
Compatible Frequency Table...............................................................................................................................................................26
Compatibility Diagram.........................................................................................................................................................................27
Diagnostics ...........................................................................................................................................................................................28
Multi-channel System Checkout..........................................................................................................................................................28
Pilot Tone Bypass................................................................................................................................................................................28
Accessories and Common Replacement Parts .................................................................................................................................29
Remote Antennas ...............................................................................................................................................................................29
Coaxial Cable......................................................................................................................................................................................29
Coaxial RF Amplifier ...........................................................................................................................................................................29
Common Replacement Parts..............................................................................................................................................................29
Service and Repair ...............................................................................................................................................................................30
Returning Units for Repair ..................................................................................................................................................................30

VR Field Wideband Receiver
LECTROSONICS, INC.
4
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. The equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorientorrelocatethereceivingantenna
• Increasetheseparationbetweentheequipmentandreceiver
• Connecttheequipmentintoanoutletonacircuitdifferentfromthatwhichthereceiv-
er is connected
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp
Changes or modifications to this equipment not expressly approved by Lectrosonics, Inc.
could void the user’s authority to operate it.

Digital Hybrid Wireless™ Modular Receiver System
Rio Rancho, NM, USA 5
Introduction
A basic VR Field System package includes:
1 DCR15/1A6U Power Supply w/21499 Power Cord
1 MC65 1/4” TRS (stereo) plug to 3.5mm TRS
(stereo) plug; 10 ft. long
1 P1214 Battery Slot Cover
1 P1215 Battery Rain Shroud
1 21529-1 DB9-TRS stereo mini cable (BLACK) for
Windows®computer system
1 21710-1 DB9-TRS stereo mini cable (RED) for
AMX or Crestron control system
1 21713 USB cable
6 35908 Stick-on Battery Handles
1 VRFIELD Instruction Manual
1 CD-ROM with LecNet2™software and
documentation in Adobe Acrobat PDF files
NOTE: Receiver modules sold separately. NP type
battery sold by other manufacturers.
Introduction
The Venue Wideband receiver is a modular rack mount
design for use with a wide variety of transmitters from
Lectrosonics and other manufacturers. Designed for
maximum versatility and performance, the wideband
design offers the flexibility needed in today’s changing
and increasingly congested RF environments.
A Venue receiver is a “system” that consists of a master
unit and up to six receiver modules. Two different types
of receiver modules are available. The standard module
(VRS) is an excellent choice for fixed installations where
fairly clear RF spectrum is available. The tracking mod-
ule (VRT) is a more costly alternative, but its tracking
front-end makes it the better choice for use in congest-
ed RF environments. VRpanel software is included to
simplify setup and monitoring.
This guide covers the essential steps and settings
needed to get a Venue system up and running. It covers
the hardware installation, configuration using the LCD
on the master unit, setting up a USB port on the com-
puter and installing the VRpanel software.
LecNet2 software runs under Microsoft Windows®XP,
VistaTM and Windows 7 operating systems.* An online
Help in the software includes a listing of commands
used to control the Venue through the serial ports.

VR Field Wideband Receiver
LECTROSONICS, INC.
6
POWER Switch
Headphone
LEVEL Control
PHONES Jack
Receiver Select
Buttons
Function Button
(labeled by the LCD)
BACK Button
PUSH FOR
MENU/SELECT
Rotary Control
The Venue receiver master unit (VRM) serves as a
“host assembly” for up to six receiver modules. The
standard module (VRS) and tracking module (VRT) can
be mixed and matched in the assembly in any combina-
tion to suit the needs of various applications.
The VRM front panel provides an LCD for system setup,
monitoring and troubleshooting. During normal opera-
tion, the LCD shows RF and audio levels, diversity
status, pilot tone status (where applicable) and transmit-
ter battery status (in certain modes) for all six receivers
at the same time. Individual screens for each receiver
provide additional information and adjustments.
A built-in analyzer scans the tunable spectrum of the
receiver to assist in finding clear operating frequencies.
The spectrum scan data is presented in a graphical
format on the LCD.
POWER Button
Turns the power on and off. A brief press also clears the
spectrum scan data after the spectrum analyzer has
been used. Press and hold the button for a few seconds
to turn the unit off.
Function Button
Used for various functions in selected Setup Screens as
labeled on the LCD.
BACK Button
The Back Button is used to return to the previous menu
or setup screen.
LCD Screen
The LCD is a backlit, graphics-type Liquid Crystal Dis-
play used to set up and monitor system operation.
Controls and Functions
Receiver Select Buttons
The six Receiver Select Buttons are used to select indi-
vidual installed receiver modules, for monitoring via the
PHONES jack and for setup and adjustment.
PUSH FOR MENU/SELECT Rotary Control
This control, called the MENU/SELECT control for
short, is a pushbutton switch and rotary knob used for
navigating and selecting setup menus and screens, and
for selecting parameters within the setup screens.
PHONES Jack and LEVEL Control
The LEVEL control is used to adjust the output level
of the front panel PHONES jack for individual chan-
nel monitoring. It does not affect the output levels at
the rear panel XLR jacks. Only the audio from a single
receiver (or a diversity pair) selected via the Receiver
Select Buttons will be present at this jack.
The PHONES jack can also used as an audio output for
recording when using the Walk Test Recorder.
NOTE: An explanation of the Walk Test Recorder
is presented in the section entitled Setting Up the
Venue Receiver Using VRpanel.
Front Panel
Battery
Compartment

Digital Hybrid Wireless™ Modular Receiver System
Rio Rancho, NM, USA 7
The rear panel provides six balanced XLR audio out-
puts, antenna inputs, “loop thru” antenna outputs from
an internal multicoupler, a power jack with a locking
connector, plus USB and RS-232 serial ports for setup
and control.
Receiver Modules
Up to six receiver modules can be installed in each
Venue receiver rack mount chassis. Spring tensioned
clips retain the receiver modules to maintain secure
connections with the host assembly.
XLR Audio Output Jacks
Six balanced XLR audio output jacks connect the Venue
receiver to external equipment. By default, pin 2 is au-
dio pos (+). The polarity of each output can be reversed
in the LCD setup menus or with the software.
Power Input Jack
The receiver is powered from +10 VDC to +18 VDC,
with the center pin of the connector positive (+). The
input is diode protected to prevent damage if the power
is accidentally applied with reversed polarity.
RS-232 Port
A serial RS-232 interface is provided for setup and
control of the Venue System from computers or other
devices using industry standard RS-232 communication
links.
Antenna Input Jacks
The two outermost BNC connectors are provided for
use with right-angle whip antennas, cables from remote
antennas, or cables from another Venue receiver. DC
voltage can be supplied on these connectors from an
internal source to power remote RF amplifiers. The
power is enabled with jumpers on the circuit board. See
the section on Antenna Use and Placement for details.
Multicoupler Output Jacks
The built-in antenna multicoupler provides RF distribu-
tion for the six receiver modules and a “loop thru” output
at the same level to deliver the RF signal to another
Venue receiver. The second receiver can then feed a
third receiver and so on, to create a “stack” that oper-
ates with a single pair of antennas. The result is very
efficient use of rack space and a cost savings by not
having to purchase a separate antenna multicoupler.
Note: Venue receivers with a 50 MHz bandwidth
must be on the same frequency block to use the
antenna loop through.
USB Port
Standard USB Version 1.1 port for setup and control of
the receiver from computer systems using Windows®
2000, XP or VistaTM operating systems.
Rear Panel
Multicoupler Outputs
Receiver Modules 4-6
(under lower cover)
Receiver Modules 1-3
(under lower cover)
USB PortRS-232
Port
Antenna Inputs
Balanced Audio
Outputs 1-3
Balanced Audio
Outputs 4-6
Power Input

VR Field Wideband Receiver
LECTROSONICS, INC.
8
Hardware Installation
Installing/Removing Receiver Modules
Up to six Receiver Modules can be installed in a VRF
chassis. These modules may be installed at the factory
or added later.
Although the VR Field System is quite flexible, any com-
bination of Receiver Modules installed must be within
the frequency block range of the VRF chassis. The
frequency block range of the VRF chassis is displayed
during the PowerUp Sequence.
Frequency Block Range
Installing Receiver Modules
1. Ensure the VR Field System is turned off and the
power source has been disconnected. Slide the
Receiver Module Connector firmly onto the Receiv-
er Module Tab.
Caution: Do not force the Receiver Module
onto the Receiver Module Tab. If the module
does not seat properly, look to see if its
position is a little off. Excessive force may
damage the module’s connector or the
Receiver Module Tab.
2. Install a Receiver Module Retaining Clip between
the rear of the Receiver Module and the Module
Tab. Ensure this clip is firmly snapped into place.
Removing Receiver Modules
1. Ensure the VR Field System is turned off and the
power source has been disconnected.
2. Remove the Retaining Clip and slide the module
outward off the connecting tab and remove it from
the chassis.
Installing the VR Field System
The VR Field Receiver is designed for portable use, as
in a bag system.
1. Position the unit for easy access to the panel con-
trols and connections. There are no special ventila-
tion requirements.
2. Connect the antennas (or antenna cables if remote
antennas are being used) to the antenna input con-
nectors on the rear panel of the VRF.
3. For multiple unit installations, connect coaxial patch
cables from the Antenna A and B OUT jacks on the
rear panel of the first unit to the Antenna A and B IN
jacks on the second unit. An additional unit can be
connected to the second unit in the same manner.
Note: All units connected in this manner must be on the same
frequency block.
Receiver Module
Retaining Clips
Receiver Modules
Receiver Module Tabs
Receiver Module
Connectors
Bottom View of the Chassis
VRF Rear Panel
VRF Front Panel
Coaxial Cables
Antenna
Inputs

Digital Hybrid Wireless™ Modular Receiver System
Rio Rancho, NM, USA 9
ALP Series
A500RA SNA600
USB Port on
Computer System
Typical USB Hookup for Single VR Field System
NOTE: Frequencies of the receiver modules
must be within the range of whip antennas and
the SNA600 dipole. The ALP Series antennas are
wideband designs that cover the entire range.
4. Insert a charged battery into the front panel, or plug
the VR Field power supply into a suitable outlet
and plug the power connector into the Power Input
Jack (unscrew the power connector that goes to the
battery). Repeat for each VR Field System being
installed.
5. Turn down the audio inputs on all the externally
connected equipment, then connect them to the ap-
propriate Audio Output XLR Jacks.
6. If the VR Field System is to be set up using a com-
puter system using a USB interface, connect a USB
cable between the USB connector on the rear panel
of the VRF and the computer system or a USB hub
connected to the computer system.
7. Refer to “Setting Up the VR Field System via the
USB Port”.
USB Port on
Computer
System
Typical USB Hookup for Multiple VR Field Systems
USB Port
on VR FIeld
System Rear
Panel
Typical Lectrosonics
Antenna Combinations
Coaxial
Patch Cables
(Not Supplied)
Antenna Inputs
10-18VDC
RS-232
654LINK 2 321
IN USB IN OUT OUT
ANTENNA A ANTENNA B
LINK 1
LINK 3
12
3
12
3
12
3
12
3
12
3
12
3
10-18VDC
RS-232
654LINK 2 321
IN USB IN OUT OUT
ANTENNA A ANTENNA B
LINK 1
LINK 3
12
3
12
3
12
3
12
3
12
3
12
3
USB Hub
RS-232 Port USB Port on VR Field
System Rear Panel
Audio Output XLR Jacks
Audio Output Wiring Diagrams

VR Field Wideband Receiver
LECTROSONICS, INC.
10
Initial Startup
When the Venue receiver is first powered up the LCD
will show the firmware revision and the tuning range of
the host assembly. The wideband version of the VRM
covers the entire 230 MHz bandwidth of frequency
blocks 21 through 29.
As the boot sequence continues, the display will switch
to an overview of all six receiver channels. In this ex-
ample, six receiver modules are installed but no trans-
mitters are turned on. In this case the “P” will be blinking
since no pilot tone is detected.
The wideband Venue receiver is different than the 50
MHz version in that the receiver modules are detected
through a manual process rather than automatically at
boot up. Press the MENU/SELECT control and rotate it
to select “Detect” on the menu.
Press the MENU/SELECT control to launch the detec-
tion process.
It takes about 45 seconds to detect all the modules and
update the memory in the host assembly. Once com-
pleted, the LCD will briefly display the results showing
the frequencies of the installed modules.
If a slot is not occupied by a module, the display will
place an “X” in that position.
The display then switches to the overview of all six
channels.
Any slot that is not occupied by a module will leave a
blank space in the overview display.
If a module in any position has been removed, changed
or added since the last use, the LCD will flash a mes-
sage advising that the Detect process needs to be run
again.
In normal operation with all six channels running, the
overview display will include:
 • Audiolevel
 • RFlevel
 • Diversityantennaphaseactivity
 • Pilottonestatus
 • Transmitterbatterystatus
Audio level
RF level Transmitter
battery status
Pilot tone status
Diversity activity
(in Switched mode)
Once the initial startup is complete, go to the next
section of this manual for details on setup and
configuration options.
To power off the unit, press and hold the red power
switch for several seconds. The LCD will display a mes-
sage briefly then power down.

Digital Hybrid Wireless™ Modular Receiver System
Rio Rancho, NM, USA 11
Navigating the LCD Menus
and Screens
Front panel controls provide access to screens and
menus for setup. The Function Button, Back Button, Re-
ceiver Select buttons and the MENU/SELECT control
are used to make selections and adjust parameters.
Function Button (labeled by the LCD)
Back Button Receiver Select
Buttons 1-6
MENU/SELECT
Control
The overview screen displays a summary of all six
channels, as shown above. This is a good starting point
for navigating to any menu or setup screen. Pressing
the BACK button repeatedly from any menu or screen
will eventually return to this overview screen.
From the overview screen, pressing one of the six
Receiver Select Buttons will switch to the detail screen
for the associated receiver module to display all current
settings, levels and status.
Receiver Module
Location
Pilot Tone
Monitoring Status
Operating
Frequency
RF Signal
Strength
Antenna Phase
Transmitter
Battery Gauge TV Channel
Audio Level Meter
Tuning Mode
Transmitter Frequency
Select Switch Settings
Pressing the Receiver Select Button again will switch
to the receiver module information screen to show the
basic setup.
Press the BACK button twice to return to the overview
screen.
From the overview screen, press the MENU/SELECT
control to open the TopMenu, rotate the control to
select an item, then press the control to enter the setup
screen for that item.
In a setup screen such as the LockSet example shown
here, up/down arrows prompt you to change the setting
by rotating the MENU/SELECT control.
Up/Down
Arrows
When the desired setting or value is displayed, press
the MENU/SELECT control or BACK button to return to
the previous menu.
Selecting SetUpRx (set up receiver) in the TopMenu
will take you to another menu where all settings for the
receiver modules can be made.
Select an item with the MENU/SELECT control and
press the control to open the setup screen (“Level” in
this example).
Setup screens for the receiver modules display the
settings for the selected module and allow immediate
access to all modules by pressing the Receiver Select
Buttons. Receiver module 1 (Rx1) is selected in this
example with its output level set at -3 dBu.
Function
Button
If another option is available, it will appear in the left
hand section of the LCD (“TONE” in this example).
Press the Function Button to select and deselect this
option with repeated presses. The display will highlight
the option when it is selected.
NOTE: Settings take effect immediately and are
stored until changed again. Pilot Tone Bypass is
different in that it resets to the default value when
the power is cycled.

VR Field Wideband Receiver
LECTROSONICS, INC.
12
Resetting to Factory
Defaults
Resetting to Factory Defaults can be a time saver for
setting up the system. Start with the power turned off,
then hold Receiver Select Buttons 5 and 6 while power-
ing up the system.
POWER Switch
Receiver Select
Buttons 5 and 6
The Factory Default Settings are:
Level +00 dBu
Level +00 dBu
Phase NORMAL
TxBatt 9V ALK
SmartNR NORMAL
Compat Dig. Hybrid
Tuning NORMAL MODE
DivMode Switched
LockSet NOT LOCKED
RxCh 8, 0
System Setup with the LCD
It is generally best to complete these steps in the se-
quence shown.
 • Selectcompatibilitymodes
• SelectSmartNoiseReductionmode
(for Digital Hybrid Compat Mode only)
• Selectdiversitymodes
• Findclearchannelsandsettransmittersto
match the receivers
• Adjustaudiooutputlevel
• Selectaudiosignalphase
• Selecttransmitterbatterymonitoringmode
• Controlpanellockout
Selecting Compatibility Modes
Navigate to the Compat setup screen.
Six compatibility modes are available to match various
transmitter types. In this example, the Digital Hybrid
compatibility mode is selected for receiver module 1.
Press the Receiver Select button for each module and
rotate the MENU/SELECT control to select the mode.
The following modes are available:
Compat
Setup Mode Description
Dig. Hybrid Lectrosonics Digital Hybrid (HYB)
Mode 3 Mode 3 (M.3) (call for details)
200 Series Lectrosonics 200 Series (200)
100 Series Lectrosonics 100 Series (100)
IFB Lectrosonics IFB Series (IFB)
Mode 6 Mode 6 (M.6) (call for details)
Mode 7 Mode 7 (M.7) (call for details)
Shortcut: Press and hold the Receiver Select
button under the selected module (module 1 in
the example above) then press the buttons under
the other modules that are to be set to the same
mode.
If you are using Digital Hybrid transmitters, set them
and the matching receiver modules to the Dig. Hybrid
mode for best performance.
Selecting the Noise Reduction Mode
When the Compat Mode is set to Digital Hybrid, three
settings are available that affect the high frequency
audio content and noise:
• NORMAL(factory default) applies a moderate
amount of noise reduction, dramatically reducing
hiss with virtually no discernible side effects.
• FULL applies more aggressive noise reduction with
transparency superior to the noise reduction system
used for many years in the earlier Lectrosonics
wide deviation analog systems.
• OFF applies no noise reduction for complete trans-
parency.
Navigate to the SmartNR setup screen.

Digital Hybrid Wireless™ Modular Receiver System
Rio Rancho, NM, USA 13
Select the receiver module with Receiver Select Button
and rotate the MENU/SELECT control to the desired
mode. Listen to the audio signal as you rotate the knob
and select the mode that best fits the situation.
Note: If the selected Receiver Module is part of
a ratio or frequency diversity pair, the mode will
automatically be set for both receiver modules in
the pair.
When any Compat Mode other than Dig. Hybrid is se-
lected, FIXED will automatically be selected.
In this example, receiver modules 4, 5 and 6 are set to
the FIXED mode with no adjustment available.
Selecting Diversity Modes
Navigate to the DivMode setup screen.
Three diversity reception modes are available:
• Switched Diversity uses one receiver module per
audio channel.
• Ratio Diversity (OptiBlendTM)uses two receiver
modules per audio channel.
• Frequency Diversity uses two receiver modules
and two transmitters per audio channel.
Press the Receiver Select Buttons to enter the setup
screens for the receiver modules.
Switched Diversity
In this mode the signals from both antennas are com-
bined into a single receiver module, with the phase of
one of them inverted back and forth so that they always
add to one another. The process reduces dropouts and
provides a stronger signal than a single antenna.
Ratio Diversity (OptiBlendTM)
Ratio diversity uses two adjacent receiver modules to
pick up a single transmitter. The audio outputs of the
modules are blended (mixed) together, using more or
less audio from each module based upon which module
has the stronger RF signal.
Ratio diversity anticipates dropouts before they occur,
rather than waiting until the RF signal level is very weak
and on the verge of noise or dropout. The comparison
of the RF signal levels in the modules begins when the
RF level is still high, so the circuit can blend in more
audio from the module with the stronger signal before
the signal decays enough to cause noise.
The blending action is smooth and seamless to avoid
any audible artifacts that can occur with abrupt switch-
ing. Most of the time both receiver modules have good
signals, so the audio is blended equally, which improves
the signal to noise ratio by 3 dB.
The blended audio appears at the rear panel XLR out-
puts of both modules.
Frequency Diversity
Frequency Diversity differs from the other two diversity
modes in that it uses two receiver modules and two
transmitters operating on different frequencies. The pur-
pose of this mode is to have redundancy in the system
for critical productions, such as live television, to guard
against failures caused by dead batteries and multipath
dropouts. The blending process to combine the audio
from the receiver modules is the same as that used for
OptiBlend ratio diversity.
Frequency Diversity requires that the levels of the two
audio channels to be closely matched to avoid au-
dible level changes as the blending action takes place.
In order for this blending to work properly, a special
test mode helps to get the transmitter levels exactly
matched. The test mode is automatically activated when
the DivMode Setup Screen is active and Frequency
Diversity is selected, as shown in the LCD photo above.

VR Field Wideband Receiver
LECTROSONICS, INC.
14
Note: In Frequency Diversity mode, both
transmitters must be the same type (usually the
same model). The microphones must also be
placed very close together to minimize comb
filtering.
To prepare for operation in the Frequency Diversity
mode, make the following adjustments:
1.Set up the transmitters according to their instruc-
tions. Plug a set of headphones into the front panel
PHONES jack to monitor the blended output. You
can also monitor the output from the rear panel
XLR jack for either module in the pair.
2. While listening to the blended output, adjust the
gain control on one of the transmitters so that the
audio loudness drops way down (nulls) as the two
channels cancel each other. If the output does not
null, then reset the transmitter input gain control
back to where it was and press the Function button
on the front panel next to the word INVT on the
LCD. This will invert the phase of the audio on the
second module so it will null properly.
INVT shown in Off Position
Depending on how microphones are wired and
other vagaries, either position of the INVT toggle
switch might achieve the null. Keep toggling the
switch until the null is found, adjust the level for the
deepest null. Be sure to press INVT one more
time to put the audio from the two channels
back in phase for normal operation.
Selecting the Tuning Mode
Pre-coordinated tuning groups are stored in memory to
simplify frequency coordination. The groups are labeled
GROUP a, b, c and d on the LCD, with eight frequen-
cies stored in each one. Refer to the section near the
back of this manual entitled Pre-coordinated Frequen-
cies for details on compatibility and using these groups.
Select a
through d
Three additional modes are also available to enable
compatibility with non-standard transmitters and storing
custom frequency sets. Navigate to the Tuning menu
and press the MENU/SELECT control.
NORMAL MODE is the standard Lectrosonics mode
with 256 frequencies in 100 kHz steps. A unique pilot
tone is present for each frequency.
FINE MODE allows tuning to 1024 frequencies in
25 kHz steps for compatibility with older and non-
Lectrosonics transmitters. Pilot tone frequency is set to
the next lower even 100kHz frequency. For example,
650.000, 650.025, 650.050 and 650.075 all use the
same pilot tone frequency.
CUSTOM MODE is a special mode used to store up to
50 frequencies per block in 25 kHz steps. Frequencies
are stored in memory in a “table” with positions num-
bered 0 through 49. The pilot tone frequency is defined
by the position of each frequency in the table.
The Receiver Detail window will indicate the selected
mode and frequency information. In the FINE mode
transmitter switch settings will be shown when the
frequency is on an even 100 kHz step. In the CUSTOM
mode the position of the frequency in the table of 50
stored in memory will be shown.
FINE mode on
100kHz step;
Tx switch
settings shown
FINE mode NOT
100kHz step;
Tx switch
settings not
shown
CUSTOM mode;
memory
position shown

Digital Hybrid Wireless™ Modular Receiver System
Rio Rancho, NM, USA 15
Finding Clear Frequencies with SmartTune
SmartTune simplifies setup by scanning the tuning
range of the receiver and automatically setting a re-
ceiver module to a clear frequency. A receiver module
is selected, a scan is completed and the frequency is
set for that module. A prompt appears, reminding you to
turn on a transmitter on the newly selected frequency,
and the procedure continues until all modules have
been tuned to clear frequencies.
NOTE: SmartTune is only available using the LCD
and front panel controls. It is not implemented in
the software.
1. Navigate to the SmrtTun setup screen and press
the MENU/SELECT control.
2. Press the Receiver Select Button for the module
you wish to tune and scanning will begin.
When the full spectrum has been scanned, the cur-
sor will stop moving and blink briefly on the newly
selected frequency briefly.
3. The display will then switch back to the receiver se-
lection screen and ask if you want to tune another
module.
4. If you select Yes the display will remind you to turn
on the transmitter for the receiver you just tuned.
When the transmitter is turned on and detected, the
display will return to receiver selection (Step 2) and
prompt you to select the next receiver.
5, Repeat steps 2 through 4 for all receiver modules
that will be used.
In most cases the system will be ready to use after
SmartTune has been run on all modules, however, it’s
a good idea to perform a system checkout to verify
the compatibility of the frequencies selected. Refer to
the section entitled Diagnostics near the back of this
manual for details.
Finding Clear Channels with Tuning
Groups a through d
Groups “a” though “d” contain 8 frequencies each that
can be used together in certain combinations. In brief,
“a” and “b” are compatible with each and “c” and “d”
are compatible with each. Other combinations require
testing. Refer to the section entitled Pre-coordinated
Frequencies for details on using these groups.
To use groups a through d, complete the following
steps:
1. Navigate to the Tuning setup screen.
2. Select each module in turn with the Receiver Select
Buttons and select the desired tuning group. Then
return to the overview screen.
3. Turn transmitters off. From the overview screen,
open the receiver detail screen for each module
and rotate the MENU/SELECT control to select a
frequency where no RF signal is indicated.
Finding Clear Channels
Using Full Spectrum Scan
In crowded RF environments, it may not be possible to
find enough clear channels using a Tuning Group. The
internal spectrum scanner can then be used to find
clear channels manually across the entire tuning range
of the receiver in 100 kHz steps.
1. Turn off all transmitters and set all receiver modules
to the NORMAL tuning mode (not a tuning group).
2. Select Scan from the TopMenu and press the
MENU/SELECT control.

VR Field Wideband Receiver
LECTROSONICS, INC.
16
Select the receiver module to use for scanning and
press MENU/SELECT. The scanning begins auto-
matically.
3. Allow the scanner to continue sweeping through the
tuning range several times, then press the Function
button to enter “Stop Mode.”
Function
Button
4. With the scanning stopped, rotate the MENU/
SELECT control to adjust the frequency to clear
spectrum. Press the Function Button to ZOOM to a
close up view of the scan results.
Function
Button
Cursor blinks
Strong InterferenceClear Spectrum
5. Press the BACK button to return to the “Stop Mode.”
NOTE: At any point in the Stop or Zoom screens,
you can select any module on the same block to
tune.
6. Press the BACK button to return the previous menu
to select the next receiver to use for scanning.
7 . Continue from step 2 to scan all blocks that are
installed.
8. Conduct a system checkout with the procedure
explained in the section entitled Diagnostics.
Adjusting Audio Output Levels
The audio output levels at the rear panel XLR jacks are
software controlled. (The front panel LEVEL knob af-
fects the PHONES output only.)
The optimum output level will provide the highest level
signal possible without overloading the input to external
equipment or driving a subsequent stage in the signal
chain into limiting or compression. Ideally, the gain
needed to drive the rest of the signal chain should be
present at the receiver outputs, with each successive
stage in other equipment set to unity (no gain or loss).
NOTE: In Ratio Diversity and Frequency Diversity
modes, the receiver modules are paired 1-2, 3-4,
5-6. Setting the audio level output on either module
in the pair, sets the audio output to the same level
on both of them.
1. Navigate to the Level setup screen.
2. Select each receiver one at a time with the buttons
under the LCD and rotate the knob to adjust the
output to the desired level.
Selected Receiver Output Level
Tone On/Off Indicator
(Shown in Off position.)
Function
Button
3. Use the Tone Generator to adjust other equipment
to match the output level from the receiver with full
modulation of the transmitter. Press the Function
Button to start the tone.
The indicator will reverse to a dark background
with light letters when the tone is delivered to the
selected output. Rotate the MENU/SELECT control
to set the desired level.
WARNING: The 1 kHz reference tone is
equivalent to full modulation at the transmitter.
It is LOUD.
The test tone level is always at the 0dB reference level
(full modulation of the wireless system), which is the
level at which the first red “limit” light comes on at the
transmitter.
The highest level that the equipment downstream will
ever see before the receiver clips is 4.5 dB higher than
the test tone. Note that this is output headroom. Over
the entire 30+ dB range of the limiter in a Lectrosonics
transmitter, the output at the receiver goes up only 4.5
dB or less.
NOTE: The tone is a sine wave with about 1%
distortion

Digital Hybrid Wireless™ Modular Receiver System
Rio Rancho, NM, USA 17
Selecting Audio Phase
Microphone wiring and other vagaries can alter the
phase of an audio signal. To compensate for this, the
phase of the audio output of each receiver module can
be inverted.
1. Navigate to the Phase setup screen.
2. Select each receiver module with the Receiver
Select Button and adjust the phase with the MENU/SE-
LECT control.
Selecting Transmitter Battery Status
Monitoring Mode
The receiver will monitor the status of the batteries in
the transmitters and display it when used with certain
transmitters, such as Lectrosonics 200 Series and Digi-
tal Hybrid models. The type of battery being used in the
transmitter must be defined in the TxBatt setup screen.
NOTE: The Compat Mode (compatibility mode)
set for each receiver module will determine which
battery monitoring methods are available
The TxBatt setup screen allows you to select the exact
battery being used in the transmitter to provide more
accurate battery level monitoring. Alkaline, lithium and
rechargeable AA and 9V types are commonly used.
The voltage declines gradually over the life of alkaline
and lithium types, so the voltage can be estimated and
displayed by the receiver. Rechargeable types, on the
other hand, maintain almost constant voltage as they
discharge, so a timer is provided in the receiver to
track operating time and anticipate the need for battery
changes.
1. Navigate to the TxBatt setup screen.
Selected Receiver
Battery Types for Each
Receiver Module
Current
Transmitter
Battery Voltage
(when available)
2. Select each receiver module with the Receiver
Select Button and set the battery type being used in
the corresponding transmitter.
9V ALK Transmitter uses a 9V alkaline battery.
Monitor voltage with battery icon in main
window.
9V LTH Transmitter uses a 9V lithium battery. Moni-
tor voltage with battery icon in main window.
9V TIM Transmitter uses a 9V battery. Display its
voltage normally in the battery level window
but monitor its status with the battery timer
in the main window.
AA ALK Transmitter uses a AA alkaline battery.
Monitor voltage with battery icon in main
window.
AA LTH Transmitter uses a AA lithium battery. Moni-
tor voltage with battery icon in main window.
AA TIM Transmitter uses an AA battery. Display its
voltage normally in the battery level window
but monitor its status with the battery timer
in the main window.
The 9V TIM and AA TIM settings are most useful for re-
chargeable batteries, all or most of which do not exhibit
reliably identifiable voltage drops as they discharge.
In compatibility modes other than 400 Series and 200
Series, no battery telemetry information is available so
the TXBAT setup screen offers only two choices:
NOTIMER Display no transmitter battery status in the
main window.
TIMER Monitor the transmitter battery status with
the battery timer in the main window.
If the selected receiver module is part of a ratio
diversity pair, the battery type will be automatically
set for both units in the pair. If the selected receiver
module is part of a frequency diversity pair, the
battery type is set independently for each receiver
in the pair since there are two transmitters in use.
3. When either the AA TIM or 9V TIM (timer) mode
is selected, press the Function Button to reset
(“ZERO”) the timer.
Elapsed Time
Press the Function Button
to Reset (ZERO) the Timer
Selected Receiver
is Highlighted

VR Field Wideband Receiver
LECTROSONICS, INC.
18
Battery status is displayed on the receiver detail screen,
the overview screen and the info screen.
Battery Gauges
The display
changes to a
numerical readout
when a timer mode
is selected.
Locking Out the Front Panel Controls
Navigate to the LockSet setup screen.
Rotate the MENU/SELECT control to the LOCKED or
NOT LOCKED setting and press the control.
When LOCKED is selected, no changes can be made
to the configuration with the front panel controls. If an
attempt is made to change a setting, the LCD will flash
a reminder that the controls are locked.

Digital Hybrid Wireless™ Modular Receiver System
Rio Rancho, NM, USA 19
Installing USB Drivers
This sequence and the screens are typical of installing
the drivers on a computer running 64-bit Windows 7.
Insert the disk into your local drive. When the first
screen appears, select Install USB Drivers for either
the 32-bit or 64-bit version to match your computer
operating system. The driver only needs to be installed
one time on each computer that will be connected to
the processors.
Select 32-bit or 64-bit to match
your operating system
When the Welcome Screen appears, click on Next to
continue the installation.
Select Next to continue
The EULA (End User License Agreement) must be ac-
cepted in order to continue the installation. Click on the
radio button labeled I accept the EULA and then on
Next to continue.
A progress screen will appear briefly as the installation
proceeds, followed by the confirmation screen that veri-
fies that the drivers were successfully installed. Click on
Finish to exit the confirmation screen.

VR Field Wideband Receiver
LECTROSONICS, INC.
20
Installing LecNet2
Software
IMPORTANT: Install the USB driver BEFORE
installing the software to simplify the process. See
the steps on the previous page.
This sequence and the screens are typical of installing
the drivers on a computer running 64-bit Windows 7.
Insert the disk and when the main screen appears,
select Install LecNet2 Software.
Select Install
LecNet2 Software
The welcome screen will appear. Click on Next to pro-
ceed to the installation.
The next screen presents the EULA (end user license
agreement) which must be approved to continue. Click
on the button labeled I Agree, then on Next to continue
with the installation.
The next screen will prompt you to select a folder for
the program. The default location appears automatically.
It is generally best to accept the default. You can also
choose to allow the software to run for anyone using
the computer, or just for the administrator installing the
software (you). Click Next to continue.
