Long Ranger 4
LECTROSONICS, INC.2
Contents
General Technical Description ..............................................................................................................................................................3
Rechargable Batteries and External Power Sources ..........................................................................................................................3
Controls and Functions .........................................................................................................................................................................4
Control Panel ........................................................................................................................................................................................4
Front Panel............................................................................................................................................................................................5
System Setup..........................................................................................................................................................................................6
Initial Equipment Adjustments..............................................................................................................................................................6
M175 Controls and Functions ...............................................................................................................................................................8
MIC JACK .............................................................................................................................................................................................8
POWER ON/OFF..................................................................................................................................................................................8
BATTERY INDICATOR LAMP ...............................................................................................................................................................8
MIC LEVEL ADJUST ............................................................................................................................................................................8
AUDIO SWITCH....................................................................................................................................................................................8
M175 Battery Replacement....................................................................................................................................................................8
H187 Controls and Functions................................................................................................................................................................8
POWER ON/OFF..................................................................................................................................................................................9
BATTERY POWER LED .......................................................................................................................................................................9
LEVEL CONTROL ................................................................................................................................................................................9
H187 Battery Replacement ..................................................................................................................................................................10
Using Additional Speakers..................................................................................................................................................................10
Adding a Second Wireless Channel to your Long Ranger ...............................................................................................................11
Initial Adjustments to the Add-On Receiver System.........................................................................................................................12
Special Note to Dual Channel Users...................................................................................................................................................12
Multiple Long Ranger Systems ...........................................................................................................................................................13
Microphone Choices ............................................................................................................................................................................14
Accessories and Replacement Parts..................................................................................................................................................15
Troubleshooting....................................................................................................................................................................................16
Symptom Possible Cause.......................................................................................................................................................................16
Service and Repair ...............................................................................................................................................................................17
Returning Units for Repair......................................................................................................................................................................17

Portable Wireless Sound System
Rio Rancho, NM 3
The built-in battery pack in the Long Ranger is charged
by plugging the DCR15/2AU charger into the jack
labeled DCR15/2AU CHARGER on the control panel.
Connect the charger into a standard 110 or 220 Volt AC
outlet. (The DCR15/2AU charger can be operated from
110/220V, 50/60Hz.) The green lamp beneath the jack
will light as long as the batteries are charging. When
the batteries are almost completely charged the green
charging light will go out. You may leave the charger
plugged in after the green light has gone out with no
danger of damage to the system. In fact, we recom-
mend charging the system whenever it is not in use,
then the system will always be “ready to go.”
The DCR15/2AU charger can charge the batteries in as
little as 2 1/2 hours. If the unit is completely run down, it
may require as much as 6 hours to fully charge the bat-
teries. Leave the charger plugged in at least until the
green lamp below the CHARGER jack goes out.
(NOTE: In the case of severely discharged batteries
(this can happen if the Long Ranger has been left on
constantly for several months), it may be necessary to
charge the unit for a much longer time. Up to 10 days
charge time is not uncommon in these circumstances.)
Rechargable Batteries and External Power Sources
The standard Long Ranger Portable Wireless Sound
System consists of a combination wireless receiver/am-
plifier/speaker with a rechargeable battery pack, a belt-
pack or plug-on transmitter and a microphone. Optional
microphones, extension speakers and add-on equip-
ment for a second wireless channel are available.
The Long Ranger features a VHF wireless microphone
system with a transmitter-to-receiver operating range of
up to 750 feet. The receiver is designed for high selec-
tivity to prevent interference from other transmitted radio
signals. The system is designed and constructed for
rigorous portable use with the antenna integrated into
the horn speaker to eliminate damage.
General Technical Description
The Long Ranger will operate from 8 to 12 hours
from the “on-board” rechargeable battery pack before
recharging is necessary. The actual operating time is
dependent upon the type of usage....intermittent or con-
tinuous. The unit can also be operated from an external
12 Volt DC source or an AC wall outlet.
The amplifier produces 33 Watts, RMS, into the 8 Ohm
horn speaker. The sound output will cover an area the
size of a football field under average outdoor conditions.
Several Long Rangers can be easily connected togeth-
er to provide even greater area coverage.
The DCR15/2A charger is capable of charging the bat-
teries and running the Long Ranger in normal operation
at the same time. The time required to fully recharge
that batteries will be longer if the unit is being used
while charging the battery pack.
CAUTION : USE ONLY THE SUPPLIED DCR15/
2A CHARGER. DO NOT USE THE OLDER CH40
CHARGER IN THE NEW LONG RANGER 4. THE
CH40 WILL NOT CHARGE THE BATTERIES IN
THE LONG RANGER 4 AND WILL BE DAMAGED
IF USED.
The Long Ranger can be operated from an external 12
Volt DC source such as an automobile battery or, most
commonly, from the cigarette lighter receptacle in your
vehicle. To use an external power source it must be
connected into the 12V DC POWER INPUT jack on the
Long Ranger front panel.
CAUTION: Make sure you comply with the polarity
markings on the jack. The correct plug for making
the co nnection is a Radio Shack 274-1567 size K
coaxial DC power plug. Radio Shack also stocks
cigarette lighter plugs (with built-in fuse) and cords
to construct a suitable assembly

Long Ranger 4
LECTROSONICS, INC.4
Controls and Functions
Control Panel
Wireless Microphone Volume
Turns unit power on and off and also functions as the
volume control for the internal wireless receiver.
POWER A red LED that lights when unit power is on.
RF
A green LED that lights when the companion transmit-
ter is turned on and there is sufficient signal for good
system operation. Internal circuits monitor both signal
level and interference levels and decide if the transmit-
ted signal is strong and “clean” enough for satisfactory
operation. If not, the green RF LED will go out and the
receiver will mute the audio (“squelch”), turning off the
sound output. This action is automatic and requires no
user adjustment.
Mod Level
The red and green MOD LEVEL LEDs continuously in-
dicate the modulation level (audio level) of the received
signal from the transmitter and are used when making
initial adjustments to the transmitter.
MIC
This connector is a standard 1/4” phone jack and is
used for plugging in the cord from a low impedance
dynamic microphone.
Line
This mini jack is used for connecting high level, high im-
pedance outputs from tape decks or other amplifiers. It
also may be used for connecting the “earphone” output
from portable cassette players.
Auxiliary Input Volume
Adjusts the volume of the MIC and LINE inputs.
Aux In/Out
An RCA phono jack that functions both as a line level
input and line level output. This “omnibus” jack is
primarily used for interconnecting several Long Rang-
ers together for simultaneous operation. This jack can
also be used with a tape deck to either record from or
play back into the Long Ranger. When used with a tape
deck or other audio source, the sound output level must
be controlled by the volume control on the tape deck
since there is no volume control on the Long Ranger for
the AUX IN/OUT jack. When an external device is con-
nected to this jack, the loudness of the Long Ranger will
usually be reduced.
DCR15/2AU Charger
A special jack used for connecting the charger when
charging the battery pack. The green LED located
under the jack lights when the batteries are charging.
This LED automatically goes out when the batteries are
almost fully charged.
12V DC Output
A special jack used to supply power to the Add-On
receiver when that option is installed.

Portable Wireless Sound System
Rio Rancho, NM 5
OFF
RF
12V DC
OUTPUT
CHARGE UNTIL
LAMP GOES OUT
POWER
AUX IN/OUT
MIC LINE
WIRELESS
MICROPHONE
VOLUME
AUXILIARY
INPUT
VOLUME
MOD
LEVEL
L o n g
R a n g e r
DCR15/2AU
CHARGER
USE
ONLY
FAST CHARGE
CIRCUITRY
12V DC
EXT POWER
Figure 1 - Long Ranger 4 Control Panel
Figure 2 - Long Ranger 4 Front Panel
12V DC Ext Power
A special jack used to connect an external 12 Volt DC
source to the unit to substitute for the “on-board” bat-
tery pack. It is most commonly used for connecting the
Long Ranger to a vehicle cigarette lighter or 12V DC
auxiliary receptacle. When an external power source
is connected to this jack, the on-board battery pack is
automatically disconnected.
CAUTION: Make sure you comply with the polarity
markings on the jack. The correct plug for making
the connection is a Radio Shack 274-1567 size K
coaxial DC power plug. Radio Shack also stocks
cigarette lighter plugs (with built-in fuse) and cords
to construct a suitable assembly
External 8 Ohm Speakers
Two jacks which are used to connect external 8 ohm
loudspeakers such as the Lectrosonics H300 re-entrant
horn. This jack can also be used to power other brands
of loudspeakers, but be sure that the speaker has a
rated impedance of 8 ohms. The left-hand jack discon-
nects the built-in horn when the plug is inserted. The
right-hand jack will operate the internal horn along with
the external speaker. The efficiency of different makes
and models of speakers varies significantly. Even
though two different speakers are both rated at 8 ohms,
their loudness could be quite a bit different. The other
specification to compare when considering the use of
another speaker is the efficiency rating. The horn built
into the Long Ranger is rated at 107 dB SPL (sound
pressure level) at one meter with a one watt input.
Check this specification on the speaker you are consid-
ering. A speaker with a lower “dB’ number will not be as
loud as the horn built into the Long Ranger.
Front Panel

Long Ranger 4
LECTROSONICS, INC.6
This section covers the initial adjustments to the
transmitter and Long Ranger that must be made before
the system is placed into operation. The step-by-step
procedures are listed in the order in which they should
be performed:
1) Turn Long Ranger power on - The POWER lamp
lights.
2) Rotate both volume controls counter-clockwise to
their minimum settings.
3) Position yourself behind the Long Ranger so that
the sound from the speaker will be directed away
from the microphone.
4) Plug your microphone into the transmitter. Make
sure the connector is screwed in snugly.
5) Turn the transmitter power on and verify that the red
lamp on it lights. If the lamp is very dim or does not
light, replace the battery.
6) Observe that the green RF lamp on the Long Rang-
er control panel is lighted. This verifies that the unit
is receiving a usable signal from the transmitter.
Initial Equipment Adjustments
This section includes some basic rules that will ensure
trouble-free operation of your Long Ranger system:
1) Make sure the transmitter battery is good or new.
2) Charge up the battery pack in the Long Ranger fully
before you use the system. Charge until the green
charging lamp underneath the CHARGER jack on
the Long Ranger control panel goes out.
3) Set up the system so that the Long Ranger is as far
from large metal surfaces as possible. Metal sur-
faces under the unit (such as pickup truck cabs or
a car top) are generally no problem but large metal
surfaces alongside the Long Ranger may interfere
with wireless reception.
4) If you have more than one transmitter on the same
frequency, turn on only one transmitter at a time.
You cannot use two transmitters at the same time
with a single Long Ranger. You will need to “al-
ternate” back and forth between the transmitters.
Failure to do so will result in an obnoxious whining
sound from the system, and the audio will probably
not be understandable. “Add-on” wireless mic sys-
tems are available separately to permit operation
of two transmitters simultaneously through a single
Long Ranger.
System Setup
5) Use the minimum volume that will enable everyone
to hear. It doesn’t have to be loud to be heard.
6) Always turn the power off before connecting or
disconnecting external speakers.
7) The Long Ranger should be elevated for best
coverage. The unit should ideally be at least 2
feet higher than the audience. For example, with
an audience standing on flat ground, the number
of people that can hear clearly will double if you
raise the unit from 5 feet above the ground to 7 feet
above the ground.
8) During actual operation the Long Ranger should
be located at least 20 feet away from the person
using the microphone and aimed so that the sound
from the speaker is directed toward the audience
and away from the microphone. This will reduce
feedback problems. Feedback is a squealing sound
coming from the speaker when the volume is too
high or the microphone is too close to the Long
Ranger. Feedback is generally much more of a
problem when using lavalier (lapel) type micro-
phones. The headset models are recommended
for use with the Long Ranger system since they
place the microphone pickup much closer to
your mouth, which increases the volume of the
Long Ranger before feedback occurs.
7) Position the microphone on yourself (or other user)
in the location it will be during actual operation.
If you are using the single-band or dual-band
headset microphone, turn the white knob on the
headset fully clockwise (maximum). The HM162
over-ear microphone should be positioned so that
the pickup element is just to the left of the mouth,
so that breath pops do not strike the capsule. Lava-
lier microphones should be positioned high on the
chest or collar, as close to the mouth as possible
to minimize the possibility of feedback. A handheld
microphone with the H175DC plug-on transmitter
should be kept at a consistent distance from the
mouth during setup and use.
8) A small screwdriver is supplied with belt-back trans-
mitters to adjust the audio gain of the transmitter to
match your microphone and your voice. The plug-
on transmitter has a small knob for adjusting gain.
The adjustment is made while observing the MOD
LEVEL lamps on the Long Ranger control panel:
a) Speak at the voice level you will be using during
actual operation.

Portable Wireless Sound System
Rio Rancho, NM 7
b) While speaking, adjust the transmitter gain until
the green MOD LEVEL lamp on the Long Ranger
control panel is lighted or flickers and the red MOD
LEVEL lamp blinks on the loudest words. Raise
and lower your voice while observing the lamps.
The red lamp should blink occasionally.
9) Now adjust the WIRELESS MICROPHONE VOL-
UME control on the control panel to a level where
everyone can hear. You will probably have to do
this in several steps. If you attempt to adjust the
volume yourself while standing and just behind the
unit, you will likely have a “feedback” problem. It
is convenient to have another person adjust the
volume while you transmit from a position 20 feet or
more behind the unit.
Figure 3 - Transmitter Gain Adjustment Green Red
REMEMBER--the transmitter gain control is used only
to adjust for proper MOD LEVEL lamp indications. DO
NOT use it to adjust the output volume of the Long
Ranger speaker. Different voices and different micro-
phones will usually require readjustment of the transmit-
ter gain control, so check the adjustment frequently. If
several different people will be using the system and
there is not time to make the adjustment for each indi-
vidual, adjust it for the loudest voice.
While speaking, adjust the transmitter as you observe
the LEDs on the receiver.

Long Ranger 4
LECTROSONICS, INC.8
H187 Controls and Functions
The H187 may be used with a wide variety of micro-
phones. The 3-pin XLR type connector on the H175DC
allows the transmitter to be used with any dynamic
microphone, as well as many two wire positive bias
lavalier systems (such as those systems supplied by
Lectrosonics.)
MIC JACK
The MIC JACK is a locking micro jack that supplies
“phantom power” for electret microphones such as the
Lectrosonics M119, M140 Lavalier and the HM142V,
HM152V and HM162 headset models. Insert the micro-
phone cord plug into the jack and rotate it clockwise to
lock it. It is important that the plug be securely locked,
since the microphone cord serves as the antenna for
the transmitter.
POWER ON/OFF
The POWER ON/OFF switch turns the power on and
off. The switch should be left in the OFF position when
the transmitter is not in use. When the switch is in the
ON position, the battery will be drained even though the
transmitter is not being used.
BATTERY INDICATOR LAMP
The BATTERY INDICATOR LAMP will light when the
transmitter is turned on and will stay lit as long as the
battery is good. As the battery voltage drops, the lamp
will grow dim and finally go out.
MIC LEVEL ADJUST
The MIC LEVEL adjust is a recessed screwdriver
adjustment used to match the gain of the transmitter to
different microphones, individual voices or other audio
inputs such as tape deck outputs.
The battery you use in the M175 Series transmitter
should be a 9 Volt lithium or alkaline, available almost
everywhere. A lithium 9 Volt battery will provide the
best performance with over 30 hours of operation. An
alkaline battery will provide up to 15 hours of operation,
and carbon zinc batteries, even if marked “heavy duty”
AUDIO SWITCH
The AUDIO SWITCH (M175-LS only) is a toggle type
on-off switch used to shut off the audio signal without
shutting off the RF carrier of the transmitter.
(Note: The M175DC, Digital Code Squelch version
is operationally identical to the standard M175.)
M175 Controls and Functions
will only provide about 4 hours of operation. Recharge-
able batteries made to look like 9 Volt batteries typically
only produce 7.2 Volts at full charge, which will only
operate the transmitter for an hour or less. Make sure
your batteries are marked “alkaline.” Short battery life is
almost always caused by weak batteries or batteries of
the wrong type.
The BATTERY LAMP will light when the transmitter is
turned on and will stay lit as long as the battery is good.
As the battery voltage drops, the lamp will grow dim and
finally go out. Even after the lamp goes out, there may
still be up to an hour or more of operating time remain-
ing. When the battery voltage is too low for proper
transmitter operation, the sound from the wireless
system may be distorted, intermittent or totally absent.
When the transmitter is first turned on, the lamp may
light for a short while even with a bad battery. It is good
practice to check the brightness of the lamp after the
transmitter has been on for several minutes and to note
the brightness occasionally during use.
To replace the battery, open the bottom battery door
cover with your thumb, rotate the door until it is perpen-
dicular with the case and allow the battery to fall out of
the compartment into your hand. It is difficult to install
the battery backwards. Observe the large and small
holes in the battery contact pad before inserting a new
battery. Insert the contact end of the battery first, mak-
ing sure the contacts are aligned with the holes in the
contact pad, and then swing the door closed. You will
feel it snap into place when it is fully closed.
M175 Battery Replacement

Portable Wireless Sound System
Rio Rancho, NM 9
(Note: The H187, Digital Code Squelch version is
operationally identical to the standard H175.)
1) Turn on the receiver and adjust the Long Ranger
volume to minimum.
2) Turn on the transmitter. The RF LED on the receiv-
er should come on.
3) Hold the microphone as you will when you will be
using it.
4) While speaking, adjust the transmitter gain until
the green MOD LEVEL lamp on the Long Ranger
control panel is lighted or flickers and the red MOD
LEVEL lamp blinks on the loudest words. Raise
and lower your voice while observing the lamps.
The red lamp should blink occasionally.
Occasional lighting of the LIMIT LED (about 10-15% of the
time) indicates proper operation and optimum signal-to-
noise ratio.
Even when the transmitter is limiting, little distortion is
produced because of the high linearity of the gain con-
trol circuit in the H187.
5) Adjust the Long Ranger volume level as necessary.
NOTES: The LEVEL control on the transmitter
should not be used to control the volume of your
sound system. This should be done using the level
control on the Long Ranger.
If the mic level is too high - the Red LED on the Long
Ranger will light frequently or stay on. This condition
may cause distortion.
If the mic level is too low — neither LED will light, or
the Red LED will light dimly. This condition will cause
hiss and noise. You may experience severe reduction
in apparent range if the transmitter gain is too low. It
may sound as if you are getting dropouts. What is actu-
ally happening is that you are hitting your noise floor
because the S/N ratio has been reduced by the low
modulation.
The input limiter operates over a full 30dB range regard-
less of the gain control setting. The Red LED should
flicker occasionally during operation
1. Install the Microphone
onto the transmitter.
2. Press the mic onto the
XLR connector until
you hear a “click.” The
click indicates the mic
has locked into place.
3. Pull on mic to ensure
that it is secure.
4. Tighten the collar by
turning it counter-clock
wise.
TO ATTACH
TO REMOVE
Hold the
transmitter
case with the
microphone
pointed
upward.
Rotate the
collar in the
direction
shown.
Pull on mic to ensure it is locked.
Press firmly, listen for click.
Depress collar fully.
Click!
TO ATTACH
TO REMOVE
Hold the
transmitter
case with the
microphone
pointed
upward.
Rotate the
collar in the
direction
shown.
Pull on mic to ensure it is locked.
Press firmly, listen for click.
Depress collar fully.
Click!
POWER ON/OFF
Turns the battery power on and off.
BATTERY POWER LED
Glows brightly when battery is good. A weak or dim
power LED means that the battery is weak, and has
about an hour of operation left. If the LED fails to light,
the battery should be replaced. The POWER LED is
connected to a precision battery test circuit that continu-
ously monitors battery voltage. The LED is at full bright-
ness with a new 9 Volt alkaline. As the battery voltage
drops during use, the LED brightness will also de-
crease. After 12 to 15 hours the battery voltage will be
about 7 Volts. The LED will be completely extinguished.
Since the internal circuits are all tightly regulated and
the RF output stage has a separate discrete regulator,
the transmitter will continue to operate to a battery volt-
age of 6.5 Volts. From 6.5 Volts to 6 Volts, the transmit-
ter will still operate, but with degraded performance.
Please note that a weak battery will sometimes light the
POWER LED immediately after turn on, but soon will
discharge to the point where the LED will extinguish.
The combination of an accurate battery condition indi-
cator and regulation of all internal circuits guarantees
much longer battery life, as well as consistent perfor-
mance over the life of the battery.
LEVEL CONTROL
Used to adjust the audio input volume for the proper
modulation level. Rotate knob until the LEVEL LED on
the receiver flickers when there is an input signal. The
LIMIT LED on the receiver should light occasionally. Gain adjustment knob

Long Ranger 4
LECTROSONICS, INC.10
CAUTION! ALWAYS TURN THE LONG RANGER
POWER OFF BEFORE PLUGGING IN OR
UNPLUGGING EXTERNAL SPEAKERS
In some cases, the proper coverage of an audience re-
quires a second speaker. The optional H300 is identical
to the Long Ranger speaker and can be used to spread
the sound over a broader area.
The output jacks for external speakers are located on
the Long Ranger front panel. The left and right jacks
operate differently. The right jack does not discon-
nect the built-in speaker when a plug is inserted into it.
This means that the built-in speaker and the external
speaker will both operate together. The left output jack
disconnects the built-in speaker and powers only the
external speaker. Internal circuits and switching net-
works keep track of the number of speakers hooked
up and select the amplifier impedance so that the full
power of the amplifier is always available. It is impor-
tant that you use only an 8 Ohm speaker in these jacks.
If you are not using Lectrosonics extension speakers,
check the speaker for the proper rating before connect-
ing to the Long Ranger.
The efficiency of different makes and models of speak-
ers varies significantly. Even though two different
Using Additional Speakers
The battery you use in the H187 Series transmitter
should be a 9 Volt lithium or alkaline, available almost
everywhere. A lithium 9 Volt battery will provide the
best performance with over 30 hours of operation. An
alkaline battery will provide up to 15 hours of operation,
and carbon zinc batteries, even if marked “heavy duty”
will only provide about 4 hours of operation. Recharge-
able batteries made to look like 9 Volt batteries typically
only produce 7.2 Volts at full charge, which will only
operate the transmitter for an hour or less. Make sure
your batteries are marked “alkaline.” Short battery life is
almost always caused by weak batteries or batteries of
the wrong type.
To open the battery compartment, press outward on the
cover door in the direction of the arrow as shown in the
drawing. Only slight, sliding pressure is needed to open
and close the battery door.
H187 Battery Replacement
Swing the door open and take note of the polarity
marked inside showing the location of the positive
(+) and negative (-) terminals. Insert the battery and
close the cover by pressing in and across, reversing
the opening procedure. Note that the battery door will
speakers are both rated at 8 ohms, their loudness
could be quite a bit different. The other specification to
compare when considering the use of another speaker
is the efficiency rating. The horn built into the Long
Ranger is rated at 107 dB SPL (sound pressure level)
at one meter with a one watt input. Check this specifi-
cation on the speaker you are considering. A speaker
with a lower “dB’ number will not be as loud as the horn
built into the Long Ranger.
The H300 speaker is typically used in conjunction with
the built-in speaker to increase the sound coverage
area. This is done by plugging the H300 into the right
speaker jack, so that both speakers will work together.
In a large area, such as a football field, try to arrange
the speakers so that the listeners are not in the direct
sound field of both speakers. If a listener can hear two
speakers located at different distances, a distracting
“echo effect” occurs. Put the speakers close to one
another in a central location and aim them in opposite
directions to broaden the coverage pattern.
When using two external speakers simultaneously, the
built-in speaker will be automatically disconnected to
prevent overload of the amplifier since a plug has been
inserted into the left-hand jack.

Portable Wireless Sound System
Rio Rancho, NM 11
ANTENNA
BLACK
LEAD
WHITE
LEAD
BLACK
LEAD
SPEAKER
MOUNTING
BLOCK
Add-On
Receiver
BATTERY
Figure 4 - Add-on Receiver Antenna Connections
Adding a Second Wireless Channel to your Long Ranger
A very popular feature of the Long Ranger is the ability
to add a second wireless channel to an existing system
in the field. The Lectrosonics Add-On Receiver system
was expressly designed for that purpose. The standard
system consists of an Add-On receiver, a transmitter
and a microphone.
The Add-On receiver is supplied with velcro attach-
ing strips and is equipped with the necessary cabling
for making the connections to the Long Ranger. The
receiver is installed on the Long Ranger by performing
the following steps as shown in Figure 4:
1) The antenna cable for the Add-On is packed
together with screws, lock washers and the velcro
strips. The antenna cable is terminated with two
ring lugs. Feed the lug end of this cable through the
hole in the Long Ranger rear panel upright. Dress
the cable along the top of the battery pack along
with the speaker wires as shown in Figure 4.
2) Remove and discard the two black Phillips head
screws from the bottom of the antenna strip on the
right-hand side of the speaker and from the speaker
mounting block. Using the supplied bright screws
and lockwashers, connect the shield ring lug (the
black wire) to the speaker mounting block. Connect
the center conductor ring lug (the clear/white wire)
to the antenna. Tighten both screws securely.
3) The Add-On receiver is to be mounted on the Long
Ranger upright with velcro. The receiver should
be positioned, control panel up, between the horn
mounting screw and the screw which secures the
battery pack to the upright. Remove the paper
backing from one side of the velcro and affix it to
the back of the receiver. Remove the remaining
paper backing and affix the receiver to the upright.
4) Route the antenna cable through the hole in the
rear upright panel, above the battery pack so that
the black and white wires reach the speaker mount-
ing block. Connect the remaining two cables to the
12V DC OUTPUT jack and the LINE input jack on
the control panel.

Long Ranger 4
LECTROSONICS, INC.12
If you are only using one of the two wireless systems,
it is best to use the wireless system built into the Long
Ranger and leave the Add-On receiver turned off. This
will prevent unwanted noise, hiss or static that could
occur in the unused receiver from entering the Long
Ranger.
Special Note to Dual Channel Users
1) Set up the Long Ranger system according to the
Initial Equipment Adjustments on page 6.
2) Leave the Long Ranger power turned on. Set both
volume controls on the Long Ranger control panel
to minimum.
3) Turn the Add-On receiver power switch to “ON.”
Check to see that the power lamp comes on.
4) Plug the microphone into the transmitter that is on
the same frequency as the Add-On receiver. The
plug on the microphone is a twist-lock connector.
Make sure there is a good connection. If you are
using the head set microphone, turn the white level
control knob on the headset fully clockwise (maxi-
mum).
5) Install the 9 Volt battery into the transmitter, turn the
transmitter on and make sure the red LED on the
transmitter glows brightly.
6) Check to see that the green “RF” LED on the Add-
On receiver glows steadily. This verifies that the
receiver is picking up a good radio signal from the
transmitter.
Initial Adjustments to the Add-On Receiver System
7) This is the most important step in the set up
procedure. Place the microphone in the exact po-
sition where you will be using it. Speak at the same
voice level that you will use during actual operation.
While you speak, use the supplied screwdriver to
adjust the gain control on the transmitter side panel
(see pages 5 & 7) while you observe the MODULA-
TION LEDs on the Add-On receiver front panel.
The green LEVEL lamp should flicker or stay lit as
you speak. The red LIMIT lamp should blink only
on louder words.
8) Adjust the AUXILIARY INPUT VOLUME control on
the Long Ranger control panel for the necessary
loudness. If the transmitter gain controls have been
correctly set on both the Longer Ranger 4 and the
Add-On system, both volume control knobs on the
Longer Ranger 4 panel will be in about the same
position for equal loudness on both systems. It
is not unusual, however, that one of the volume
controls may need to be set higher or lower than
the other one in normal use. Adjust the controls
separately for adequate sound levels for each mi-
crophone.
If it is necessary to use the Add-On receiver by itself,
turn the WIRELESS MICROPHONE VOLUME control
knob on the Long Ranger control panel to minimum.
Then set the AUXILIARY INPUT VOLUME for the nec-
essary loudness of the Add-On system.

Portable Wireless Sound System
Rio Rancho, NM 13
Connect two
Long Rangers
together using
the AUX IN/OUT
jacks.
AUX IN/OUT AUX IN/OUT
Figure 5 - Connecting Two Long Ranger Systems
Multiple Long Ranger Systems
A unique use of the AUX IN/OUT jack is for connecting
two Long Ranger systems together for simultaneous
use. When connected in this manner, they will operate
like a single system. It is best to use two different Long
Ranger units that operate on different frequencies. Any
input on either Long Ranger will appear at both speak-
ers. If the Long Ranger systems are on the same fre-
quency, only one transmitter can be used at any given
moment.
Second channel (add-on) wireless systems on either
(or both) Long Ranger systems will work fine, as long
as they are all on different frequencies. Each wireless
microphone will have its own volume control. The built-
in wireless in each Long Ranger will be controlled by
the left-hand knob on the matching unit. The volume of
each add-on wireless system will be controlled by the
right-hand knob on the matching unit. All sound from all
wireless microphones will appear on all loudspeakers,
both built-in or external.
Connect the Long Ranger systems together with a stan-
dard RCA (phono) patch cord, male plug to male plug.
It is best to use cords 10 to 12 ft. in length (or less) to
minimize noise that can occur with long cables.
If any of the Long Rangers or add-on wireless system
are on the same frequency, only one transmitter can be
used at a time on that frequency. REMEMBER that if
two transmitters on the same frequency are turned on
at the same time, the receiver will not receive either of
them properly. You will need to “alternate” the use of the
transmitters.
The INITIAL EQUIPMENT ADJUSTMENTS (see page
6) should be performed on each system individually
before the AUX IN/OUT interconnection is made. After
the units are connected together, adjust the volume on
each Long Ranger for the loudness level needed.

Long Ranger 4
LECTROSONICS, INC.14
Specifications
Operating frequency: 169 to 186 MHz
Audio power output: 33 Watts, RMS, into 8 Ohms
Distortion: less than 1%
Amplifier freq. response: 100 Hz to 15 kHz; +0, -3 dB
(Omnibus jack input to external
speaker jack output.)
Overall freq. response: 200 Hz to 3 kHz; +0/-3dB (Wireless
input tohorn output.)
Max. audio output (SPL): Over 120 dB at 3 feet
M119 - This is a very small, omni-directional mic used
only as a lavalier (“lapel”) microphone. It may be prone
to feedback since it is usually placed so far away from
the users mouth; however it has a very flat response
and excellent tone quality. The M119 generally works
best with the Long Ranger and an ES300 column
speaker indoors at a lower volume setting. As is true of
most omni-directional type microphones, the M119 is
very free from wind noise and clothing “rattle”.
M140 - A cardioid (directional) microphone for lavalier
(“lapel”) use. Due to the directional pickup pattern,
this model will generally provide more gain (loudness)
before feedback than the M119 omni-directional model.
The M140 has a “brighter” sound than the M119 (the
treble is boosted). This crisper sound normally im-
proves the clarity that is sometimes lost with lavalier
type microphones. The M140 is subject to wind noise
and generally works best indoors, however it is supplied
with a foam windscreen which helps to prevent noise
caused by wind.
HM142V - This single-band headset microphone is nor-
mally worn on the head, but can also be worn around
the neck for hands-free operation. It provides maximum
gain before feedback since the microphone is very
close to the user’s mouth. The built-in volume control
helps control feedback in difficult environments, such as
when the user must be close to the Long Ranger. Worn
on the head, the microphone will remain at a constant
distance from the user’s mouth, which keeps the vol-
ume of the sound system constant as your head moves.
HM152V - A double-band headset microphone intended
to be worn on the head. The pickup element and
tonal characteristics are the same as the single-band
Microphone Choices
HM142V, but it is more securely mounted and in most
cases, more comfortable, due to the fully adjustable
dual headband. The same volume control is provided to
help control feedback.
HM162 - A “over the ears” noise cancelling microphone
that uses a dual-element design to minimize feedback
when the microphone is close to the speaker.
Other brands of microphones may be used, provided
they are the correct type, with an appropriate connec-
tor. Consult the factory or your dealer if you are not
sure. A mis-matched microphone will generally cause
background noise (hiss) or feedback problems, or may
not work at all.
FM deviation: ±15kHz
Wireless operating range: Up to 750 feet
RF signal-to-noise ratio: 96dB, A weighted
Speaker: 6” x 12” re-entrant horn
Weight: 16 lbs.
Dimensions: 15” high, 6 3/4” wide, 9 3/4” deep
Specifications subject to change without notice.

Portable Wireless Sound System
Rio Rancho, NM 15
Accessories and Replacement Parts
DCR15/2AU Battery Charger Replacement
HM142V Single headband with locking micro plug
for M175 series transmitters.
HM152V Double Headband, adjustable, with micro
plug Headset Microphone for M175
series transmitters.
HM162 “Over ears” Headset. A comfortable
headworn design that places
the microphone pickup
element close to the mouth, using
a dual-element, noise cancelling
technique to minimize feedback.
H300 Extension Speaker with detachable cable.
H300CA 50’ cable for extension speaker
MM-36 Patch Cord. 36” RCA (male to male) For
interconnecting AUX IN/OUT jacks.
RK-119 Wind Screen for M119 and M140
microphones
RK-142 Wind Screen for HM142V and HM152V
headset microphones
CCPRO Carrying Case. Molded, pre-cut foam
lined
SS-5 Tripod Stand. 2-section legs, riser col
umn; 59” max. height
HM162
H300
H300CA
SS-5
CCPRO

Long Ranger 4
LECTROSONICS, INC.16
Symptom Possible Cause
Long Ranger red POWER lamp not on or dim
1) WIRELESS MICROPHONE VOLUME control in OFF position
2) Batteries completely discharged
3) Battery terminals disconnected or loose
Long Ranger green RF lamp not on
1) Transmitter not on
2) Dead battery in transmitter
3) Transmitter and receiver not on same frequency
Long Ranger red POWER lamp andgreen RF lamp on, but no sound
A) MOD LEVEL lamps dark 1) Transmitter is not getting an audio signal. Defective mic or
cable.
2) Transmitter gain control set much too low
B) MOD LEVEL lamps indicating 1) WIRELESS MICROPHONE VOLUME control normal turned
completely down
2) Defective horn or speaker
System operation normal except for high hiss or hum level
A) Green MOD LEVEL lamp 1) Transmitter gain control set too low dark or barely flickers
2) Headset volume (white knob) turned down
B) MOD LEVEL lamps appear normal 1) Noisy microphone or mic cable? To verify, replace with
known good microphone.
2) Hiss in device connected to Long Ranger? Turn off the device.
If hiss stops, problem is in the device. If hiss remains, the prob
lem is in the Long Ranger.
3) Hiss in the Long Ranger can be caused by poorly shielded
computers, phone systems, older electronic organs, etc. Try
turning off nearby suspect equipment.
System operation normal except for “feedback” and/or red MOD LEVEL lamp on or blinking frequently
1) Transmitter gain set too high.
2) Output level of device connected is too high
Weak, distorted sound. Power lamp flickers. “Motorboating” (rapid popping sound.)
Batteries very low. Recharge.
Troubleshooting

Portable Wireless Sound System
Rio Rancho, NM 17
Service and Repair
If your system malfunctions, you should attempt to correct or isolate the trouble before concluding that the equipment
needs repair. Make sure you have followed the setup procedure and operating instructions. Check the interconnect-
ing cables and then go through the TROUBLESHOOTING section in this manual.
We strongly recommend that you do not try to repair the equipment yourself and do not have the local repair shop
attempt anything other than the simplest repair. If the repair is more complicated than a broken wire or loose connec-
tion, send the unit to the factory for repair and service. Don’t attempt to adjust any controls inside the units. Once
set at the factory, the various controls and trimmers do not drift with age or vibration and never require readjustment.
There are no adjustments inside that will make a malfunctioning unit start working.
LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In warranty repairs
are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a modest
flat rate plus parts and shipping. Since it takes almost as much time and effort to determine what is wrong as it does
to make the repair, there is a charge for an exact quotation. We will be happy to quote approximate charges by phone
for out-of-warranty repairs.
Returning Units for Repair
For timely service, please follow the steps below:
A. DO NOT return equipment to the factory for repair without first contacting us by letter or by phone. We need to
know the nature of the problem, the model number and the serial number of the equipment. We also need a
phone number where you can be reached 8 A.M. to 4 P.M. (U.S. Mountain Standard Time).
B. After receiving your request, we will issue you a return authorization number (R.A.). This number will help speed
your repair through our receiving and repair departments. The return authorization number must be clearly shown
on the outside of the shipping container.
C. Pack the equipment carefully and ship to us, shipping costs prepaid. If necessary, we can provide you with the
proper packing materials. UPS is usually the best way to ship the units. Heavy units should be “double-boxed” for
safe transport.
D. We also strongly recommend that you insure the equipment, since we cannot be responsible for loss of or dam-
age to equipment that you ship. Of course, we insure the equipment when we ship it back to you.
Mailing address: Shipping address: Telephone:
Lectrosonics, Inc. Lectrosonics, Inc. [phone]
PO Box 15900 581 Laser Rd. [phone] Toll-free
Rio Rancho, NM 87174 Rio Rancho, NM 87124 [phone] Fax
USA USA
Web: E-mail:
www.lectrosonics.com [email protected]

Long Ranger 4
LECTROSONICS, INC.18

Portable Wireless Sound System
Rio Rancho, NM 19

August 15, 2007
581 Laser Road NE • Rio Rancho, NM 87124 USA • www.lectrosonics.com
[phone] • [phone] • fax [phone] • [email protected]
LIMITED ONE YEAR WARRANTY
The equipment is warranted for one year from date of purchase against defects in
materials or workmanship provided it was purchased from an authorized dealer. This
warranty does not cover equipment which has been abused or damaged by careless
handling or shipping. This warranty does not apply to used or demonstrator equipment.
Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any
defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot
correct the defect in your equipment, it will be replaced at no charge with a similar new
item. Lectrosonics, Inc. will pay for the cost of returning your equipment to you.
This warranty applies only to items returned to Lectrosonics, Inc. or an authorized
dealer, shipping costs prepaid, within one year from the date of purchase.
This Limited Warranty is governed by the laws of the State of New Mexico. It states the
entire liablility of Lectrosonics Inc. and the entire remedy of the purchaser for any
breach of warranty as outlined above. NEITHER LECTROSONICS, INC. NOR
ANYONE INVOLVED IN THE PRODUCTION OR DELIVERY OF THE EQUIPMENT
SHALL BE LIABLE FOR ANY INDIRECT, SPECIAL, PUNITIVE, CONSEQUENTIAL,
OR INCIDENTAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE
THIS EQUIPMENT EVEN IF LECTROSONICS, INC. HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL THE LIABILITY OF
LECTROSONICS, INC. EXCEED THE PURCHASE PRICE OF ANY DEFECTIVE
EQUIPMENT.
This warranty gives you specific legal rights. You may have additional legal rights which
vary from state to state.
