LEDCity SEMI-AUTONOMOUS+ Gen2 User manual

LED TUBE
SEMI-AUTONOMOUS+ Gen2
User Guide
daylight sensor
radar movement
detection sensor
factory reset switch
(magnetic)
status LED
(green: mesh network
blue: motion sensor)
SEE
PRODUCT
ONLINE

APP COMMISSIONING
The full procedure of the commissioning with the
mobile application is explained in separate
guidelines and videos. Please contact [e-mail]
for further details.
LED INDICATORS
The function of the status LED is explained in the fol-
lowing table. There are two colors with two different
meanings –one for Bluetooth Mesh network status
and one for radar sensor status:
ENOCEAN SWITCH
The Semi
Autonomous+
Tubes can be
controlled with
EnOcean BLE
switches. A QR-
code on the back
of the switch can
be scanned and
linked to a
luminaire.
GREEN LED (BLUETOOTH MESH NETWORK STATUS)
Fast blink (each 300 ms) Unprovisioned
Slow blink (each 2000 ms) Provisioned
Blink twice (50 ms cycle) Meshpacket recieved
On / Off (500 ms cycle) Attention event
Long blink Factory reset
BLUE LED (RADAR MOVEMENT SENSOR STATUS)
Blink once Motion detected
The location of the status LED as well as the other sen-
sors (daylight / radar) is shown in the following
picture:
FACTORY RESET
The semiautonomous
plus tube can be reset to
unprovisioned mode by
placing a strong magnet
(e.g. a neodymium
magnet) near the right
side on the light sensor
position of the sensor
head for 5 seconds (as
visible in the picture on
the left). The factory
reset procedure needs
to be executed with a
powered tube .
Once the factory reset is done successfully, the tube
(lightness output) behaves as follows:
The light sequence above is executed every time du-ring
power-on of an unprovisioned tube.
WIRING DIAGRAM
L N
100 %
50%
0 %
3
6
9
[s]
sensor
factory
reset
switch
daylight
sensor
radio
transmitter /
antenna
status
LED
radar
motion
detector
LEDCITY TUBE
The products of LEDCity are constantly being further developed. The pictures, drawings and
specifications shown here represent the current status at the time of publication of this document
and cannot be used as a point of a contract. During the validity of this document we reserve the
right to make technical or formal changes to our products.
Date: 31.03.2022
head
