Leding moviSpark Strobe User manual

1
USER MANUAL

2
INTRODUCTION
Thank you for having chosen our LED lighting
Unpack the device, inside the box you should find:
The fixture device
One power cable
One XLR connection cable
This manual
Please check carefully that there is no damage caused by
transportation. Should there be any problems, consult your dealer
and don’t install this device.
DESCRIPTION
Features
600pcs 1W RGB LED, 600pcs 1.2W White LED，no ultraviolet
radiation.
More than 20,000 hours for the LED light source
200,000 lm for white version/ 70,000 lm for RGB version
120 degrees
3/6/9/13/14/25/50/57/72 DMX channels
16 Bit Dimmer
DMX Mode/Master-Slave mode/Pixel mode( can be used as a
wash with the output of 300W)
AC200-240V 50/60Hz 1500W
Diecasting heatsink with fans Control
With temperature sensor to extend the lamp's life
7000 Hz LED scan rate
⚫L: 557 W: 146mm H:326.5 mm
⚫IP65
SAFETY INSTRUCTIONS
This device has left the factory in perfect condition. In order to
maintain this condition and to ensure a safe operation, it is
absolutely necessary for the user to follow the safety
instructions and warning notes written in this user manual.
This device falls under protection-class I. Therefore it is essential that
the device should be earthed.
The electric connection must carry out by qualified person.

3
If the external flexible cable or cord of this luminaire is damaged, it
shall be exclusively replaced by the manufacturer or his service agent
or a similar qualified person in order to avoid a hazard.
Make sure that the available voltage is not higher than stated at the
end of this manual.
Make sure the power cord is never crimped or damaged by sharp
edges.
If this would be the case, replacement of the cable must be done by
an authorized dealer.
Always disconnect from the mains, when the device is not in use or
before cleaning it. Only handle the power cord by the plug. Never
pull out the plug by tugging the power cord.
Never look directly into the light source, as
sensitive persons may suffer an epileptic shock.
Important:
Damages caused by the disregard of this user manual are not
subject to warranty. The dealer will not accept liability for any
resulting defects or problems.
DMX-512 control connection
The product has a DMX 512 input fitted with 3-pin XLR connectors.
Screened cables in compliance with EIA RS-485 specifications and
the following characteristics must be used for connections:
- 2 conductors plus screen
- 120Ohm impedance
- low capacitance
- max. transmission rate 250kBaud.
DMX-512 connection with DMX terminator
For installations where the DMX cable has to run a long distance or
is in an electrically noisy environment, such as in a discotheque, it is
recommended to use a DMX terminator. This helps in preventing
corruption of the digital control signal by electrical noise. The DMX
terminator is simply an XLR plug with a 120 OHM resistor connected

4
between pins 2 and 3, which is then plugged into the output XLR
socket of the last fixture in the chain.
Display Menu
Menu
Sub-menu
Config
Mode
Channel Mode
XXch，XXch，
XXch
Keep Screen On
Enable/Disable
Output Inverse
Normal/Inverse
Keep DMX Data
Enable/Disable
White Balance
Led Red
0 - 255
Led Green
0 - 255
Led Blue
0 - 255
Led White
0 - 255
Fan speed
low/standard/high
Fast Dimmer
Enable/Disable
System Info
Temperature
Head XX ℃
Body XX ℃
RDM
RDM_Status
Enable/Disable
RDM_UID
XXX
RDM_ID
XXX
RDM_Label
XXX
Led All On
Led All On
Auto Test
Auto Mode 1
Auto Mode 2
Auto Mode 3
Led Test
Led Red
0 - 255
Led Green
0 - 255
Led Blue
0 - 255
Led White
0 - 255
Fan Test
On/Off

5
Led Load
Defaul
False/True
Main functions
1. Address: Current DMX address
A. Setting DMX address by button
press ENTER button when show the address menu, then adjust
the DMX address by pressing [UP] or [DOWN] button
Press [ENTER] to confirm or press [ESC] to return to main
menu.
B. Setting DMX address by controller
1.Set the DMX value of channel 5 to 10-15,channel 17 to 20-26,
channel 7 to 30-36,channel 8 to 40-46,then the devices
connected to the controller will enter to the setting address
mode
2. Set the DMX value of channel 1 from 0-59,then you will see
the first number of the Address change to (channel 1 value)/10.
For example, when set the value of channel 1 to 20,the first
DMX address number will be 2(20/10=2),
3. Set the DMX value of channel 2 from 0-99,then you will see
the second number of the Address change to (channel 2
value)/10.
For example, when set the value of channel 2 to 30,the first
DMX address number will be 2(30/10=3),
4.Set the DMX value of channel 3 from 0-99,then you will see
the third number of the Address change to (channel 3
value)/10.
For example, when set the value of channel 1 to 40,the first
DMX address number will be 3(40/10=4),
And the DMX address you set by controller will be 234.
5. Set the DMX value of channel 4 to 255,then you will save the
DMX address settled by the controller.
Caution: It won’t save the address if the address number
is over 512
6. set the value of channel 5-8 out of the value range show on
the step 1,and the device will exit the setting address mode

6
2. Config.
Setting DMX mode
press ENTER button when show the channel menu, then
select the DMX mode by pressing [UP] or [DOWN] button.
Keep Screen On
press ENTER button when show the Keep Screen On menu,
then select Enable or Disable to keep the screen on by
pressing [UP] or [DOWN] button.
Output Inverse
press ENTER button when show the Output Inverse menu,
then select Normal or Inverse by pressing [UP] or [DOWN]
button.
Keep DMX Data
press ENTER button when show the Keep DMX Data menu,
then select Enable or Disable to keep DMX Data by pressing
[UP] or [DOWN] button.
White Balance
press ENTER button when show the White Balance menu,
then setting the values of LED Red/Green/Blue/White by
pressing [UP] or [DOWN] button.
Fan speed
press ENTER button when show the Fan speed menu, select
the speed of Fan in low, standard or high by pressing [UP] or
[DOWN] button.
Fast Dimmer
press ENTER button when show the Fast Dimmer menu, then
setting the dimmer speed effort by selecting Enable or Disable by
pressing [UP] or [DOWN] button.
Curve Mode
press ENTER button when show the Curve Mode menu, then

7
setting the Gamma Curve effort by selecting Enable or Disable by
pressing [UP] or [DOWN] button.
Dimmer Speed
press ENTER button when show the Dimmer Speed menu, then
setting Dimmer Speed as Normal or Smooth by pressing [UP] or
[DOWN] button.
3. System info
Temperature
press ENTER button when show the Temperature menu, then
it will show the temperatures of the fixture.
4. RDM
press ENTER button when show the RDM menu, press Enter
button to select RDM_Status as Enable or Disable, and select
the value of RDM_UID, RDM_ID and RDM_Label by
pressing [UP] or [DOWN] button.
5. Static Color
press ENTER button when show the Color menu, press Enter
button to select the color mode, then adjust the color by
pressing [UP] or [DOWN] button
6. Led All On
press ENTER button when show the Led All On menu, to keep
all LED on by pressing [UP] or [DOWN] button.
7. Auto test
press ENTER button when show the auto test menu, select
test mode by pressing [UP] or [DOWN] button.
8. Led Test
press ENTER button when show the Led Test menu, select test
mode of different color by pressing [UP] or [DOWN] button.
9. Fan Test
press ENTER button when show the Fan Test menu, select
test mode as on or off by pressing [UP] or [DOWN] button.

8
10. Led Load Default
press ENTER button when show the Led Load Defaul menu,
select Default mode as False or True by pressing [UP] or
[DOWN] button.
DMX functions and values
3 Channel Mode
1
Coarse Tilt
000 - 255
0-180°
2
Fine Tilt
000 - 255
0-2°
3
Strobe
000 - 010
No function
011 - 255
From slow to fast
6 Channel Mode
1
Coarse Tilt
000 - 255
0-180°
2
Fine Tilt
000 - 255
0-2°
3
All Red LED
000 - 255
0 - 100%
4
All Green LED
000 - 255
0 - 100%
5
All Blue LED
000 - 255
0 - 100%
6
All White LED
000 - 255
0 - 100%
9 Channel Mode
1
Coarse Tilt
000 - 255
0-180°
2
Fine Tilt
000 - 255
0-2°
3
Master Dimmer
000 - 255
0 - 100%
4
All Red LED
000 - 255
0 - 100%
5
All Green LED
000 - 255
0 - 100%
6
All Blue LED
000 - 255
0 - 100%
7
All White LED
000 - 255
0 - 100%
8
Duration
000 - 255
0 - 100%
9
Strobe
000 - 010
No function

9
011 - 255
From slow to fast
13 Channel Mode
1
Coarse Tilt
000 - 255
0-180°
2
Fine Tilt
000 - 255
0-2°
3
Master Dimmer
000 - 255
0 - 100%
4
Master Dimmer
fine
000 - 255
0 - 100%
5
All Red LED
000 - 255
0 - 100%
6
All Green LED
000 - 255
0 - 100%
7
All Blue LED
000 - 255
0 - 100%
8
All White LED
000 - 255
0 - 100%
9
Duration
000 - 255
0 - 100%
10
Strobe
000 - 010
No function
011 - 255
From slow to fast
11
Macro
000 - 035
No function
036 - 071
Effect 1
072 - 107
Effect 2
108 - 143
Effect 3
144 - 215
Effect 4
216 - 255
Effect 5
12
Flow Effect
0 - 50
No function
51 - 101
Effect 1
102 - 152
Effect 2
153 - 203
Effect 3
204 - 254
Effect 4
255
Effect 5
13
speed
000 - 254
Fast to slow
255
Tungsten Effect

10
14 Channel Mode
1
Coarse Tilt
000 - 255
0-180°
2
Fine Tilt
000 - 255
0-2°
3
Red Block1
000 - 255
0 - 100%
4
Green Block1
000 - 255
0 - 100%
5
Blue Block1
000 - 255
0 - 100%
6
White Block1
000 - 255
0 - 100%
7
Red Block2
000 - 255
0 - 100%
8
Green Block2
000 - 255
0 - 100%
9
Blue Block2
000 - 255
0 - 100%
10
White Block2
000 - 255
0 - 100%
11
Red Block3
000 - 255
0 - 100%
12
Green Block3
000 - 255
0 - 100%
13
Blue Block3
000 - 255
0 - 100%
14
White Block3
000 - 255
0 - 100%
25 Channel Mode
1
Coarse Tilt
000 - 255
0-180°
2
Fine Tilt
000 - 255
0-2°
3
Master Dimmer
000 - 255
0 - 100%
4
Master Dimmer
fine
000 - 255
0 - 100%
5
All Red LED
000 - 255
0 - 100%
6
All Green LED
000 - 255
0 - 100%
7
All Blue LED
000 - 255
0 - 100%
8
All White LED
000 - 255
0 - 100%
9
Duration
000 - 255
0 - 100%
10
Strobe
000 - 010
No function

11
011 - 255
From slow to fast
11
Macro
000 - 035
No function
036 - 071
Effect 1
072 - 107
Effect 2
108 - 143
Effect 3
144 - 215
Effect 4
216 - 255
Effect 5
12
Flow Effect
0 - 50
No function
51 - 101
Effect 1
102 - 152
Effect 2
153 - 203
Effect 3
204 - 254
Effect 4
255
Effect 5
13
speed
000 - 254
Fast to slow
255
Tungsten Effect
14
Red Block1
000 - 255
0 - 100%
15
Green Block1
000 - 255
0 - 100%
16
Blue Block1
000 - 255
0 - 100%
17
White Block1
000 - 255
0 - 100%
18
Red Block2
000 - 255
0 - 100%
19
Green Block2
000 - 255
0 - 100%
20
Blue Block2
000 - 255
0 - 100%
21
White Block2
000 - 255
0 - 100%
22
Red Block3
000 - 255
0 - 100%
23
Green Block3
000 - 255
0 - 100%
24
Blue Block3
000 - 255
0 - 100%
25
White Block3
000 - 255
0 - 100%
50 Channel Mode
1
Coarse Tilt
000 - 255
0-180°

12
2
Fine Tilt
000 - 255
0-2°
3
Red 1
000 - 255
0 - 100%
4
Green 1
000 - 255
0 - 100%
5
Blue 1
000 - 255
0 - 100%
6
White 1
000 - 255
0 - 100%
7
Red 2
000 - 255
0 - 100%
8
Green 2
000 - 255
0 - 100%
9
Blue 2
000 - 255
0 - 100%
10
White 2
000 - 255
0 - 100%
11
Red 3
000 - 255
0 - 100%
12
Green 3
000 - 255
0 - 100%
13
Blue 3
000 - 255
0 - 100%
14
White 3
000 - 255
0 - 100%
15
Red 4
000 - 255
0 - 100%
16
Green 4
000 - 255
0 - 100%
17
Blue 4
000 - 255
0 - 100%
18
White 4
000 - 255
0 - 100%
19
Red 5
000 - 255
0 - 100%
20
Green 5
000 - 255
0 - 100%
21
Blue 5
000 - 255
0 - 100%
22
White 5
000 - 255
0 - 100%
23
Red 6
000 - 255
0 - 100%
24
Green 6
000 - 255
0 - 100%
25
Blue 6
000 - 255
0 - 100%
26
White 6
000 - 255
0 - 100%
27
Red 7
000 - 255
0 - 100%
28
Green 7
000 - 255
0 - 100%
29
Blue 7
000 - 255
0 - 100%
30
White 7
000 - 255
0 - 100%
31
Red 8
000 - 255
0 - 100%

13
32
Green 8
000 - 255
0 - 100%
33
Blue 8
000 - 255
0 - 100%
34
White 8
000 - 255
0 - 100%
35
Red 9
000 - 255
0 - 100%
36
Green 9
000 - 255
0 - 100%
37
Blue 9
000 - 255
0 - 100%
38
White 9
000 - 255
0 - 100%
39
Red 10
000 - 255
0 - 100%
40
Green 10
000 - 255
0 - 100%
41
Blue 10
000 - 255
0 - 100%
42
White 10
000 - 255
0 - 100%
43
Red 11
000 - 255
0 - 100%
44
Green 11
000 - 255
0 - 100%
45
Blue 11
000 - 255
0 - 100%
46
White 11
000 - 255
0 - 100%
47
Red 12
000 - 255
0 - 100%
48
Green 12
000 - 255
0 - 100%
49
Blue 12
000 - 255
0 - 100%
50
White 12
000 - 255
0 - 100%
57 Channel Mode
1
Coarse Tilt
000 - 255
0-180°
2
Fine Tilt
000 - 255
0-2°
3
Master Dimmer
000 - 255
0 - 100%
4
Master Dimmer
fine
000 - 255
0 - 100%
5
Duration
000 - 255
0 - 100%
6
Strobe
000 - 010
No function
011 - 255
From slow to fast

14
7
Macro
000 - 035
No function
036 - 071
Effect 1
072 - 107
Effect 2
108 - 143
Effect 3
144 - 215
Effect 4
216 - 255
Effect 5
8
Flow Effect
0 - 50
No function
51 - 101
Effect 1
102 - 152
Effect 2
153 - 203
Effect 3
204 - 254
Effect 4
255
Effect 5
9
speed
000 - 254
Fast to slow
255
Tungsten Effect
10
Red 1
000 - 255
0 - 100%
11
Green 1
000 - 255
0 - 100%
12
Blue 1
000 - 255
0 - 100%
13
White 1
000 - 255
0 - 100%
14
Red 2
000 - 255
0 - 100%
15
Green 2
000 - 255
0 - 100%
16
Blue 2
000 - 255
0 - 100%
17
White 2
000 - 255
0 - 100%
18
Red 3
000 - 255
0 - 100%
19
Green 3
000 - 255
0 - 100%
20
Blue 3
000 - 255
0 - 100%
21
White 3
000 - 255
0 - 100%
22
Red 4
000 - 255
0 - 100%
23
Green 4
000 - 255
0 - 100%
24
Blue 4
000 - 255
0 - 100%
25
White 4
000 - 255
0 - 100%

15
26
Red 5
000 - 255
0 - 100%
27
Green 5
000 - 255
0 - 100%
28
Blue 5
000 - 255
0 - 100%
29
White 5
000 - 255
0 - 100%
30
Red 6
000 - 255
0 - 100%
31
Green 6
000 - 255
0 - 100%
32
Blue 6
000 - 255
0 - 100%
33
White 6
000 - 255
0 - 100%
34
Red 7
000 - 255
0 - 100%
35
Green 7
000 - 255
0 - 100%
36
Blue 7
000 - 255
0 - 100%
37
White 7
000 - 255
0 - 100%
38
Red 8
000 - 255
0 - 100%
39
Green 8
000 - 255
0 - 100%
40
Blue 8
000 - 255
0 - 100%
41
White 8
000 - 255
0 - 100%
42
Red 9
000 - 255
0 - 100%
43
Green 9
000 - 255
0 - 100%
44
Blue 9
000 - 255
0 - 100%
45
White 9
000 - 255
0 - 100%
46
Red 10
000 - 255
0 - 100%
47
Green 10
000 - 255
0 - 100%
48
Blue 10
000 - 255
0 - 100%
49
White 10
000 - 255
0 - 100%
50
Red 11
000 - 255
0 - 100%
51
Green 11
000 - 255
0 - 100%
52
Blue 11
000 - 255
0 - 100%
53
White 11
000 - 255
0 - 100%
54
Red 12
000 - 255
0 - 100%
55
Green 12
000 - 255
0 - 100%

16
56
Blue 12
000 - 255
0 - 100%
57
White 12
000 - 255
0 - 100%
72 Channel Mode
1
Coarse Tilt
000 - 255
0-180°
2
Fine Tilt
000 - 255
0-2°
3
Master Dimmer
000 - 255
0 - 100%
4
Master Dimmer
fine
000 - 255
0 - 100%
5
All Red LED
000 - 255
0 - 100%
6
All Green LED
000 - 255
0 - 100%
7
All Blue LED
000 - 255
0 - 100%
8
All White LED
000 - 255
0 - 100%
9
Duration
000 - 255
0 - 100%
10
Strobe
000 - 010
No function
011 - 255
From slow to fast
11
Flow Effect
0 - 50
No function
51 - 101
Effect 1
102 - 152
Effect 2
153 - 203
Effect 3
204 - 254
Effect 4
255
Effect 5
12
speed
000 - 254
Fast to slow
255
Tungsten Effect
13
Red Block1
000 - 255
0 - 100%
14
Green Block1
000 - 255
0 - 100%
15
Blue Block1
000 - 255
0 - 100%
16
White Block1
000 - 255
0 - 100%
17
Red Block2
000 - 255
0 - 100%

17
18
Green Block2
000 - 255
0 - 100%
19
Blue Block2
000 - 255
0 - 100%
20
White Block2
000 - 255
0 - 100%
21
Red Block3
000 - 255
0 - 100%
22
Green Block3
000 - 255
0 - 100%
23
Blue Block3
000 - 255
0 - 100%
24
White Block3
000 - 255
0 - 100%
25
Red 1
000 - 255
0 - 100%
26
Green 1
000 - 255
0 - 100%
27
Blue 1
000 - 255
0 - 100%
28
White 1
000 - 255
0 - 100%
29
Red 2
000 - 255
0 - 100%
30
Green 2
000 - 255
0 - 100%
31
Blue 2
000 - 255
0 - 100%
32
White 2
000 - 255
0 - 100%
33
Red 3
000 - 255
0 - 100%
34
Green 3
000 - 255
0 - 100%
35
Blue 3
000 - 255
0 - 100%
36
White 3
000 - 255
0 - 100%
37
Red 4
000 - 255
0 - 100%
38
Green 4
000 - 255
0 - 100%
39
Blue 4
000 - 255
0 - 100%
40
White 4
000 - 255
0 - 100%
41
Red 5
000 - 255
0 - 100%
42
Green 5
000 - 255
0 - 100%
43
Blue 5
000 - 255
0 - 100%
44
White 5
000 - 255
0 - 100%
45
Red 6
000 - 255
0 - 100%
46
Green 6
000 - 255
0 - 100%
47
Blue 6
000 - 255
0 - 100%

18
48
White 6
000 - 255
0 - 100%
49
Red 7
000 - 255
0 - 100%
50
Green 7
000 - 255
0 - 100%
51
Blue 7
000 - 255
0 - 100%
52
White 7
000 - 255
0 - 100%
53
Red 8
000 - 255
0 - 100%
54
Green 8
000 - 255
0 - 100%
55
Blue 8
000 - 255
0 - 100%
56
White 8
000 - 255
0 - 100%
57
Red 9
000 - 255
0 - 100%
58
Green 9
000 - 255
0 - 100%
59
Blue 9
000 - 255
0 - 100%
60
White 9
000 - 255
0 - 100%
61
Red 10
000 - 255
0 - 100%
62
Green 10
000 - 255
0 - 100%
63
Blue 10
000 - 255
0 - 100%
64
White 10
000 - 255
0 - 100%
65
Red 11
000 - 255
0 - 100%
66
Green 11
000 - 255
0 - 100%
67
Blue 11
000 - 255
0 - 100%
68
White 11
000 - 255
0 - 100%
69
Red 12
000 - 255
0 - 100%
70
Green 12
000 - 255
0 - 100%
71
Blue 12
000 - 255
0 - 100%
72
White 12
000 - 255
0 - 100%

19
CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft
lint-free and moistened cloth. Never use alcohol or solvents!
CAUTION!
Disconnect from mains before starting maintenance
operation.
There are no serviceable parts inside the device. Maintenance
and
service operations are only to be carried out by authorized
dealers.
If you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has
to be replaced by authorized dealers only in order to avoid
hazards.
If you have further questions, please contact your dealer.
NOTE!
Not For Permanent Out Door!
INSTALLATION
The device must only be installed at a vibration-free, oscillation-
free and fire-resistant location.
