LEDLITE LTUSF10PIR Assembly instructions

60mm 156mm
168mm
Please read these instructions before commencing installation
and retain them for future reference.
CHOOSING A MOUNTING LOCATION
• For the best results, fix your sensor on a solid surface, 1.8~2.5M above the ground
• For outdoor installation, a location under eaves is preferable
• Avoid aiming the motion sensor at pools, heating vents, air conditioners or objects that may
change temperature rapidly
• Do not allow sunlight to fall directly on the front of unit
• Try to avoid pointing the unit at trees or shrubs or where the motion of pets may be detected
• When choosing the mounting position consider that the sensor is more sensitive to motion across
the detection field (A) and less sensitive to motion directly towards the sensor (B) (Figure1)
• Select a location for the unit based on the coverage angles shown in Figure 2
SENSOR
LESS SENSITIVE
SENSOR
MORE SENSITIVE
SENSITIVITY TO MOTION
Figure 1
COVERAGE ANGLES
Figure 2
UNIT (M)
WIRING INFORMATION
Connection Box
220-240V Input
Brown = Live
Blue= Neutral
Green/Yellow = Earth
Walking Towards
Walking across
1
2
COVERAGE RANGE
The Ultra Slim Floodlights with PIR have a Pulse Override facility to enable lighting to be switched
on for long periods using an existing switch.
For pulse override switch the power OFF then ON twice within 1 second to enable constant light.
In constant light mode turn OFF then ON after 10 seconds to enable sensor mode.
A B
20m
10m
0
140
3.5m
220-240V
Ultra Slim COB LED Floodlights
with PIR Sensor 10W/30W/50W
Important information
It is recommended that floodlights are installed by a qualified electrician ensuring the
installation complies to current IEE wiring regulations & local building control.
• These products are designed for connection to a 220-240V mains supply.
• Any broken or damaged parts should be replaced as soon as possible.
• We will not accept responsibility for any claims arising from a poor installation.
Specifications:
• Voltage Range: 220-240V
• Nom. Watts: 10W / 30W / 50W
• Beam Angle: 120°
• IP Rating: IP65 Body / IP44 PIR sensor
• Warranty: 3 Years
• Die Cast Aluminium Casing
• Shatter Resistant Tempered Glass
• Not Dimmable
• Protection against electric shock: Class I
Requires earth connection
• With Connection Box
Sensor Specifications:
• Up to 10m Detection Range
• Time adjustment: 10sec. - 10min.
• Lux adjustment: 3 ~ 2000lux
• Detection Angle: 140°
• Mounting Height Recommended:
1.8 to 2.5m (2.9m max)
• Pulse Override Facility
• Includes additional Wall Mounting bracket
• Optional Garden Spike (not included)
• Operational Temp.: -20 C ~ +40 C° °
Dimensions:
63mm 190mm
197mm
134mm
60mm 104mm
LTUSF10PIR LTUSF30PIR LTUSF50PIR
Always switch off mains supply before servicing.
The distance between two floodlights should be no less than 50cm.
PULSE OVERRIDE FACILITY
INSTALLATION INSTRUCTIONS:

Turn the wall switch on. The floodlight will turn on for about 10 seconds to warm up. It will then
turn off. Walk through the detection area. The floodlight turns on when you move and turns off
when you stop. Wait for the floodlight to turn off before moving again to test the sensor.
Adjust the motion sensor to cover the desired detection area.
2. TIME ADJUSTMENT
The TIME adjustment controls how long the floodlight will stay on after motion has been detected.
Turn the time control knob clockwise to increase how long the floodlight stays on (up to approx. 10
minutes) or anti-clockwise to decrease the time the floodlight stays on (down to about 10 seconds).
3. LUX ADJUSTMENT
The LUX adjustment determines at what light level the lighting system will
start operating when you set the sensor to automatic operation.
Provisionally turn the LUX control knob to the edge anti-clockwise to the
moon (dusk) position. In this setting the motion sensor remains inactive
during daylight. At dusk when the light level is at the LUX required adjust
the knob clockwise to when the light comes on.
ABOUT 10 SECONDS ABOUT 10 MINUTES
4. SENSOR ADJUSTMENT
The sensitivity adjustment may be adjusted to compensate for seasonal variations
in temperature and to reduce unwanted triggering. The optimum sensitivity can be
achieved by setting the SENS control knob initially to its mid-point and then
adjusting the control knob clockwise to increase the detection distance (up to 10
metres) or anti-clockwise to decrease the detection distance (down to 2 metres).
Open the connection box cover using a
screwdriver
Insert the cable through the waterproof gland
Cable
Installing the Cable:
Pass the cable through the buckle and make
sure the buckle is tightened.
Check the wiring diagram for wiring information.
Close the connection box cover by tightening
the four screws.
Installing the Bracket:
Swing Bracket
Fixing Bolt
Mark the position, drill the holes
and install the wall plugs
Mount the round bracket on the
wall using the three fixing bolts
Install the swing bracket onto
the base using the fixing bolt
WARNING: Ensure all items and screws are secure and fitted correctly.
• Turn On Power and test the luminaire
• This floodlight is not dimmable
• Floodlights should not be connected in series
1. TEST MODE
Turn the Time, Sens and Lux control anti-clockwise to the edge – the TEST position.
SETTING THE PIR SENSOR
