LEDS C4 71-7669-00-00 User manual

LEDS-C4 Afores s/n 25750 Torà (Lleida) Spain [phone] [email protected] Receptor RGB Controller 71-7669-00-00 V0 1 / 3
Instructions de montage
3D File
Revit
Receptor RGB
Controller 71-7669-00-00
Leds C4 Team Solution Control Receptor RGB Controller
CARACTÉRISTIQUES TECHNIQUES
Matière de la structure : PVC Tension/Fréquence : 24VDC
Garantie : 2 Ans
LOGISTIQUE
Poids net (kg): 0.11
Poids emballé (kg): 0.14
100 Un

71-7669-00-00 — RF/RGB Receiver
—Function introduction
Important: Read All Instructions Prior to Installation
LEDS C4 S.A. - Afores s/n 25750 Torà. Lleida (Spain). [phone] leds-c4.com
CH1: R
Learning Key
Paring with RF
DC Power input
CH2: G
CH3: B
CH4: W
If you use multiple receivers, you have two choises:
Option 1: Have all the receivers in the same zone, like zone 1
Option 2: Have each receiver in a different zone, like zone 1, 2, 3 or 4
—Operation
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.
—Safety & Warnings
—Wiring Diagram
Step 1: Connect and wire up the RF receiver correctly, power on.
Step 2: Click ON/OFF button of the remote/panel to turn on it.
Step 3: Click the “Learning key” button on RF receiver
Step 4: Click a zone number (ignore this step if the remote/panel has only 1 zone)
Step 5: Touch the color wheel/slider (click any button except on/off and zone
buttons if the remote has no color wheel/slider)
Step 6: LED lights connected with the receiver will blink to indicate successful
pairing to the selected zone.
Step 1: Connect and wire up the RF receiver correctly, power on.
Step 2: Press and hold the “Learning key” button on receiver for over 3 seconds until the connected led light on
receiver flickers twice, which means well deleted.
—Product Data
No. Input
Voltage
1 12-48VDC
Output
Current
4×5A
Output
Power
4×(60-240)W
Remarks
Constant voltage
Size (L×W×H)
178×46×22mm
• Radio Frequency:
869.5/916.5/434mhz
• Waterproof grade: IP20
Do wiring according to connection diagram
Pair to RF sender with learning key
Delete pairing with learning key
x1 Learning key RF/RGB
RECEIVER
x3 sec. Learning key RF/RGB
RECEIVER
5 x1
2x1
4 x1
RF/RGB
RECEIVER
Master/Slave jumper
With RGB/RGBW color LED
Power
Supply
RF/RGB
RECEIVER
RF/RGB
RECEIVER
white
1234
Learning Key
wwcwwwcw
RF/RGB
RECEIVER
white
1234
Learning Key
wwcwwwcw
RF/RGB
RECEIVER
white
1234
Learning Key
wwcwwwcw
RF/RGB
RECEIVER
white
1234
Learning Key
wwcwwwcw
RF/RGB
RECEIVER
white
1234
Learning Key
wwcwwwcw
RF/RGB
RECEIVER
Zone 1 RF remote
Zone 1 Zone 2 Zone 3 RF remote

LEDS C4 S.A. - Afores s/n 25750 Torà. Lleida (Spain). [phone] leds-c4.com
Master and Slave Setting:
1: The receiver has both master and slave functions which can be set with a jumper. Short circuit of the jumper
means master function, and open circuit means slave function. Once short circuit the jumper on a receiver, please
power off and power on the receiver to enable master function. Setting master and slave enables perfect
synchronization of color changing effects.
2: Set one receiver as master and pair it to any zone of a remote, and this zone shall only have one receiver which
works as master. Set all other receivers as slave and pair them to other zones of the remote, and multiple receivers
can be paired to each zone. Then choose all zones on the remote and play the color changing effects, the master
will send sync signal to the slaves to achieve perfect synchronization. The max. sync distance between the master
and any slave is within 30m.
Buit-in 10 color changing modes are as follows:
Mode 1: Any two colors of RGB mix fade-in & fade-out.
Mode 2: RGB three colors mix fade-in & fade-out.
Mode 3: RGB three colors mix fade-out & fade-in.
Mode 4: RGB flash.
Mode 5: RGB three colors fade-in & fade-out successively.
Mode 6: RGB three colors fade-in successively.
Mode 7: RGB three colors fade-out successively.
Mode 8: RGB three colors jump changing successively.
Mode 9: R&B two colors mix fade (R in B out), then G fade-in, then R&B mix fade (R out B in), then G fade-out.
Mode 10: B fade-out, then G&B mix fade (G out B in), the R&G mix fade (R out G in), then R fade-in.
—Product Dimension
