INSTALLATION INSTRUCTIONS
Y1-1054
MULTI-FUNCTION HAND SHOWER

2
What you need to know
Adjustable Wrench
Groove Joint Pliers
Hacksaw
Phillips Screwdriver
Pipe Tape
Spatula
Spirit Level
Your new bathroom faucet is designed for years
of trouble-free performance.
Keep it looking new by cleaning it periodically with
a soft cloth. Avoid abrasive cleaners, wire wool and
harsh chemicals as these will dull the finish and
void your warranty.
If you are soldering during faucet installation,
remove cartridges, seats, gaskets and washers
prior to applying flame, otherwise you will void
the warranty.
Cover drain openings to avoid losing small parts.
When cutting or soldering pipe, use safety glasses
to protect your eyes.
Correct installation may vary depending on previous faucet installation. All necessary supplies required for
faucet installation are not included, but may be found where plumbing supplies are sold. It is suggested that
IAPMO and/or CSA approved plumbing supplies are used during installation.
Prior to beginning installation. turn off the cold and
hot water lines and open the old faucet to release
built-up pressure.
Overtightening nuts may cause damage.
Wrap all threaded connections with pipe tape
available at your local plumbing supply store.
Always wrap in a clockwise direction. The fittings
should be installed by a state-licenced plumber.
Tools: Maintenance
SafetyTips
ThingsYouMayNeed
ImportantPoints
IAPMO/cUPC Listed
Meets A112.18.1
Standards FlowRate
Please note :
Final achievable flow rate is dependent on the outlets fitted, see relevant outlets (spouts, roses, sprays) for fully
assembled product flow rate.
0
1
2
20 40 60 80PSI

3
Step 1
InstallationProcedure
Lefroy Brooks always recommends that plumbing products be installed by a licensed professional.
Shut off main water supply before installation.
Tighten the handshower to a shower hose
(not included) by hand only.
Adaptor (S2254406-R1)
Handle grip (S2254400-R6)
Body (S2254400-R1)
Stopper (S2254400-R10)
Spring (S2254400-R9)
O-ring (S2254406-R4)
Fixing base (S2254400-R4)
O-ring (S2254406-R5)
Diverter base (S2254400-R5)
Fixing ring (S2254400-R3)
Decorative ring (S2254400-R2)
Diverter ring (S2254400-R13)
Plate (S2254400-R14)
Massage plate (S2254400-R15)
Massage impeller (S2254400-R12)
Front cover (S2254400-R11)
O-ring (S2254406-R3)
Inner pipe (S2254406-R2)
Decorative cover (S2254400-R8)
Inner pad (S2254400-R7)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
45678910111213141516
20
19
18
17
This product requires the installation of certified atmospheric vacuum breaker (AVB) installed in-between the
shut off valve and hose inlet. The AVB should be installed so its vent ports are not pointing in an upward
direction. Should you be unfamiliar with an AVB, we recommended consulting a plumbing professional.
valve AVB HOSE
1/2-14NPSM-2A
2 1/8"
Ø3 7/8"
9 15/16"
7/16"
(54mm)
(Ø99mm)
(252mm)
(10.7mm)

The use of trademarks, product design and artwork is subject to licence or agreement with Christo A. Lefroy Brooks. The design
registrations, trademark registrations and copyrights are protected by law and the use or reproduction outside the terms of an agreement is prohibited.
The right to modify designs and dimensions is reserved. Christo Lefroy Brooks is a member of ACID (Anti Copying in Design).
LEFROY BROOKS INC, 1828 TROUTMAN STREET, RIDGEWOOD, NY, 11385
TELEPHONE: [phone]. FAX: [phone]
©CHRISTO A. LEFROY BROOKS 2009
For additional assistance or service call
718-302-5292
9am to 5pm EST Monday to Friday
www.lefroybrooks.com
