LEGEND FORCE 1006273116 User manual

THANK YOU
USE AND CARE GUIDE
FRONT TINE TILLER
Questions, problems, missing parts?
Before returning to the store, call
Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday
9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
Item #LF22150
We appreciate the trust and confidence you have placed in Legend Force through the purchase of this tiller. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Legend Force!
Model #1006273116

2
Table of Contents
Safety Information ............................. . . . . . 2
Pre-Assembly ......................................8
Warranty ...........................................6
Planning Assembly ................................8
Tools Required ....................................8
Hardware Included............................ . . . . . 8
Package Contents .................................8
Assembly .......................... . . . . . . ..... . . . . 9
Operation .................................. . . . . . . 11
Maintenance ......................................16
Care, Cleaning and Storage ...................... . . . . 19
Troubleshooting ...................................20
Service Parts ......................................21
Safety Information
GENERAL SAFETY
Read this operator’s manual carefully in its entirety before
attempting to assemble this machine. Read, understand,
and follow all instructions on the machine and in the
manual(s) before operation. Keep this manual in a safe
place for future and regular reference and for ordering
replacement parts.
□
□
□
□
□
□
□
□
□
□
□
□
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate injury.
IMPORTANT: Indicates operation or maintenance
information which is important but not hazard-related.
NOTICE: Indicates a practice not related to personal injury which,
if not avoided, may result in property damage.
Be completely familiar with the controls and the proper use
of this machine before operating it.
This machine is a precision piece of power equipment.
Therefore, exercise extreme caution at all times.
Regularly inspect the tiller. Make sure parts are not bent,
damaged, or loose.
Use this equipment for its intended purpose only.
Operate the unit only with guards, shields, and other safety
items in place and working correctly.
Service the unit only with authorized or approved replacement
parts.
Complete all unit maintenance and adjustments according to
the instructions in this manual.
To prevent accidental starting when setting up, transporting,
adjusting or making repairs, always disconnect spark plug
wire.
Be thoroughly familiar with the controls and the proper use
of the tiller before starting. Know how to stop the engine
quickly.
To help avoid tiller tines contact or a thrown object
injury, stay in operator zone behind handles and keep
children, bystanders, helpers and pets at least 75 feet from
tiller while it is in operation. Stop machine if anyone enters
area.
Always wear safety glasses or safety goggles during
operation and while performing an adjustment or repair
to protect your eyes. Thrown objects which ricochet can
cause serious injury to the eyes.
Wear sturdy, rough-soled work shoes and close-fitting
pants and shirts. Shirts and pants that cover the arms
and legs and steel-toed shoes are recommended. Never
operate this machine while barefoot, in sandals, or in
slippery or lightweight (e.g. canvas) shoes.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

3
Safety Information (continued)
GENERAL SAFETY
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
Do not put hands or feet near or under rotating parts. Keep
clear of discharge area at all times as the rotating tines
can cause injury.
Never operate the tiller without proper shields,
guards, control lever or other safety protective devices in
place and working.
Never operate the tiller with damaged safety devices.
Failure to do so can result in personal injury.
Familiarize yourself with all the safety and operating decals
on this equipment.
Thoroughly inspect the area where the tiller is to be used
and remove all foreign objects. Your equipment can propel
small objects at high speed causing personal injury or
property damage.
Check that all nuts and bolts are tight and equipment is in
good condition before each use.
Never allow children or young teenagers to operate the tiller.
Only allow responsible individuals, who are familiar with the
instructions, to operate the tiller.
Do not operate the tiller while under the influence of alcohol
or drugs.
The control lever is a safety device. Never attempt to
bypass its operation. Doing so makes the safety device
inoperative and may result in personal injury through
contact with the rotating tines. The control lever
must operate easily in both directions and automatically
return to the disengaged position when released.
Do not put hands or feet near or under rotating parts.
Operate only in daylight or in good artificial light. Walk, never
run.
Exercise extreme caution when operating on or crossing
gravel drives, walks, or roads. Stay alert for hidden hazards
or traffic.
Exercise caution to avoid slipping or falling. Always be sure
of your footing; keep a firm hold on the handle and walk;
never run. Never operate the tiller at high transport speeds
on slippery surfaces.
If the equipment should start to vibrate abnormally, stop
the engine and check immediately for the cause. Vibration
is generally a warning of trouble.
Never leave the tiller unattended when the engine is running.
Stop the engine and make sure all moving parts have
stopped. Remove the wire from the spark plug.
Muffler and engine become hot and can cause a burn. Do
not touch.
Do not run the engine indoors or inside a closed area. The
exhaust fumes are dangerous, containing CARBON
MONOXIDE, an ODORLESS AND DEADLY GAS.
Watch for holes, roots, bumps, or other rough ground. Tall
grass can hide obstacles.
Always look behind and down and use caution when using
reverse or pulling the tiller towards you.
Never attempt to start the tiller unless both wheels are in the
locked position. This acts as a brake for the tiller.
Always start the tiller on the level surface.
Only use parts and accessories made for this machine by
the manufacturer. Failure to do so can result in personal
injury.
When starting engine, pull cord slowly until resistance
is felt, then pull rapidly. Rapid retraction of starter cord
(kickback) will pull hand and arm toward engine faster than
you can let go. Broken bones, fractures, bruises or sprains
could result.
Disengage clutch lever and stop engine before leaving the
tiller in operating position. Wait until the tines come to a
complete stop before removing debris or making any
adjustments to the tiller.
Do not attempt to till hard soil, till too deep or till at too fast
a rate that can overload the tiller.
Gasoline is extremely flammable, and gasoline vapors can
explode if ignited. Handle with care.
Gasoline must be stored in an approved fuel container – usually
5 gallons or less.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

4
Safety Information (continued)
GENERAL SAFETY
□
□
Tragic accidents can occur if the operator is not alert to the
presence of children. Children are often attracted to the tiller.
They do not understand the dangers. Never assume that children
will remain where you last saw them.
□
□
□
□
□
□
□
□
□
Always be sure of your footing. A slip and fall can cause
serious personal injury. If you feel you are losing your
balance, release the control lever immediately and the
tine will stop rotating.
Do not till near drop-offs, ditches or embankments, you
could lose your footing or balance.
Keep children out of the tilling area and under watchful
care of a responsible adult other than the operator.
Be alert and turn tiller off if a child enters the area.
Before and while moving backwards, look behind and
down for small children.
Use extreme care when approaching blind corners,
doorways, shrubs, trees, or other objects that may obscure
your vision of a child who may run into the tiller.
Keep children away from hot or running engines. They can
suffer burns from a hot muffler.
Never allow children to operate this machine.
To avoid personal injury or property damage, use extreme
care in handling gasoline. Gasoline is extremely flammable
and the vapors are explosive. Serious personal injury can
occur when gasoline is spilled on yourself or your clothes,
which can ignite. Wash your skin and change clothes
immediately.
Use only an approved gasoline container.
Never fill containers inside a vehicle or on a truck or trailer
bed with a plastic liner. Always place containers on the
ground away from your vehicle before filling.
CHILDREN SAFETY
□
□
□
□
□
□
□
□
□
□
□
□
□
Remove gas-powered equipment from the truck or
trailer and refuel it on the ground. If this is not possible,
then refuel such equipment on a trailer with a portable
container, rather than from a gasoline dispenser nozzle.
Keep the nozzle in contact with the rim of the fuel tank or
container opening at all times until fueling is complete. Do
not use a nozzle lock-open device.
Extinguish all cigarettes, cigars, pipes and other sources
of ignition.
Never fuel machine indoors because flammable vapors will
accumulate in the area.
Never remove gas cap or add fuel while engine is hot or
running. Allow engine to cool at least two minutes before
refueling.
Never over fill fuel tank. Fill tank to no more than 1 inch
below bottom of filler neck to provide for fuel expansion.
Replace gasoline cap and tighten securely.
If gasoline is spilled, wipe it off the engine and equipment.
Move machine to another area. Wait 5 minutes before
starting engine.
Never store the machine or fuel container near an open
flame, spark or pilot light as on a water heater, space
heater, furnace, clothes dryer or other gas appliances.
To reduce fire hazard, keep machine free of grass, leaves,
or other debris build-up. Clean up oil or fuel spillage and
remove any fuel soaked debris.
Allow machine to cool at least 5 minutes before storing.
Never run an engine indoors or in a poorly ventilated area.
Engine exhaust contains carbon monoxide, an odorless
and deadly gas.
If situations occur which are not covered in this manual,
use care and good judgement. Contact Customer Support
for assistance or the name of the nearest service dealer.
SAFETY WHILE SERVICING
Safe Handling Of Gasoline:
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

5
Safety Information (continued)
GENERAL SAFETY
□
□
□
□
□
□
□
□
□
□
□
Before cleaning, repairing, or inspecting, make certain the
tines and all moving parts have stopped. Disconnect the
spark plug wire and ground against the engine to prevent
unintended starting.
Check the tines and engine mounting bolts at frequent
intervals for proper tightness. Also, visually inspect tines
for damage. Replace with the original equipment
manufacturer's (O.E.M.) parts only, listed in this manual.
Use of parts which do not meet the original equipment
specifications may lead to improper performance and
compromise safety!
Keep all nuts, bolts, and screws tight to be sure the
equipment is in safe working condition.
Never tamper with safety devices. Check their proper
operation regularly.
After striking a foreign object, stop the engine, disconnect
the spark plug wire and ground against the engine.
Thoroughly inspect the tiller for any damage.
Repair the damage before starting and operating the tiller.
The tiller components, guards and shields are subject
to wear and damage which could expose moving parts
or allow objects to be thrown. For safety protection,
frequently check components and replace immediately
with original equipment manufacturer’s (O.E.M.) parts only,
listed in this manual. Use of parts which do not meet the
original equipment specifications may lead to improper
performance and compromise safety!
Do not change the engine’s governor setting or over-speed
the engine. The governor controls the maximum safe
operating speed of the engine.
Check fuel line, tank, cap, and fittings frequently for cracks
or leaks. Replace if necessary.
Do not crank engine with spark plug removed.
Maintain or replace safety and instruction labels, as
necessary.
Observe proper disposal laws and regulations. Improper
disposal of fluids and materials can harm the environment.
Do not modify engine.
□To avoid serious injury or death, do not modify engine in any
way. Tampering with the governor setting can lead to a
runaway engine and cause it to operate at unsafe speeds.
Never tamper with the factory setting of the engine governor.
WARNING: This machine is equipped with an internal
combustion engine and should not be used on or near any
unimproved forest-covered, brush covered or grass-covered
land unless the engine’s exhaust system is equipped with a
spark arrestor meeting applicable local or state laws (if any).
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

6
Warranty
2-YEAR LIMITED WARRANTY
WHAT IS COVERED
From the date of original purchase, Legend Force warrants to the original purchaser that each lawn and garden product sold, shall be free
from defect in material and workmanship for the items and time period set forth below. Legend Force, at its discretion, agrees to repair or
replace any defective part that upon examination, inspection, and testing by a Legend Force authorized service dealer, is found to be
defective within the original warranty period. Legend Force will also decide upon the use of new or rebuilt parts or comparable product. Any
part or product that is replaced will be retained by Legend Force. This warranty period shall not be extended and any repaired product shall
be warranted for the remaining period of the original warranty. The consumer is responsible, and shall prepay all transportation costs,
including returning items to Legend Force. This warranty is non-transferable and proof of purchase and serial number must be presented
when requesting warranty service. If a proof of purchase receipt is not provided, the product’s shipping date by the manufacturer will be
used to determine the warranty period.
LENGTH OF WARRANTY: Personal use applications of this lawn and garden product are warranted for two (2) years. Proof of
purchase and of maintenance must be provided.
YEAR 1 - Limited coverage on lawn and garden product components, parts and labor.
YEAR 2 - Limited coverage on lawn and garden product components, parts only.
“Personal use” means personal residential household use or recreational use by the retail consumer. “Commercial use” means all other
uses including commercial, construction, or other income producing purposes. Once a lawn and garden product has been used for
commercial purposes, it shall thereafter be considered as a “commercial use” product for the purposes of this warranty. Any commercial
product used as rental equipment will not be covered under this warranty.
CONSUMER RESPONSIBILITIES:
• Consumer is responsible for carefully reading and following all instructions in the operator manual. Any product that is damaged due to
misuse or abuse will not be covered by this warranty.
• Customer MUST present their concerns to Legend Force Support – FIRST by calling 1-877-527-0313. Only when we authorize the
work may the customer deliver the product to a repair center. Warranted repairs will be completed in a reasonable period of time, not to
exceed 30 days.
• Consumer is responsible for all transportation costs to an authorized Legend Force Service Center. Unless otherwise requested,
ground shipping will apply for part orders. Customer may request expedited service, but will be responsible to pay any additional charge(s).
• Consumer is responsible for labor costs associated with warranted repairs twelve (12) months after the purchase date. Consumer is
responsible for maintaining the lawn and garden product as specified in the operator’s manual. Warranty coverage for labor will be based
on normal working hours for the repair center.
• Maintenance may be required to fulfill a warranty claim; consumer is responsible for all costs for routine maintenance.
WHAT THIS WARRANTY DOES NOT COVER:
• Normal wear: This warranty excludes normal wear items such as filters, spark plugs, gaskets, o-rings, adapter cord sets, wheels,
and batteries.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

7
Warranty (continued)
2-YEAR LIMITED WARRANTY
•Maintenance: This warranty does not apply to tune-ups or routine maintenance and does not cover any adjustments or repairs not
performed by an authorized repair facility.
•Misuse: This warranty does not apply if your product has failed due to abuse, misuse, neglect, using incorrect fuels or lubricants,
overloading, overspeeding, improper maintenance, improper storage, unapproved modifications, or has been operated in any way contrary
to the instructions found in the product operator manual.
•Adverse conditions: This warranty does not apply if your product has failed due to freezing, accident or natural disasters.
•Product shipment: This warranty does not apply to damage resulting from shipping, handling, or warehousing. Any damage claims to this
product caused by shipment must be filed with the freight company.
•Other exclusions: This warranty does not apply if your product has been sold “as is” or where the factory applied serial number has been
removed. Refurbished, used, demonstration or floor models are not covered by this warranty.
WHERE WARRANTY IS VALID:
For warranty coverage, this product must be purchased from an authorized Legend Force dealer and the warranty only extends to
the original purchaser in the United States, Canada, or Mexico. Refurbished, used, demonstration, or floor models are not covered by this
warranty. Products purchased from auction websites are not covered by this warranty. Products used for commercial use are not covered
by this warranty.
HOW TO OBTAIN WARRANTY SERVICE:
You can locate your nearest Legend Force dealer for service or warranty questions by calling 1-877-527-0313. Legend Force recommends
you retain all of your receipts covering the purchase and maintenance of your lawn and garden product.
Legend Force obligation under this warranty is exclusively limited to product repair or replacement and shall not be liable for any incidental or
consequential damages including, but not limited to, the expense of delivering product to and from repair center, loss or damage to personal
property, loss of revenue, telephone charges, loss of time, or inconvenience. Some states, provinces or jurisdictions do not allow the
exclusion or limitation of incidental damages, so the above limitation may not apply to you. The warranty gives you specific legal rights, and
you may also have other rights which vary from state to state or province to province.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

8
Pre-Assembly
PLANNING ASSEMBLY
Place box on a level surface. Remove all items from box. Make sure all items listed on the package contents list are included and not
damaged.
TOOLS REQUIRED
PACKAGE CONTENTS
HARDWARE INCLUDED
NOTE: Hardware is not shown to actual size.
Part Description Quantity
A
B
Tiller Body/Upper Handle 1
B Dust Cover 2
Part Description Quantity
E Tines
DTiller Protective Shield
End Caps
2
2
C Face Plate 1
FSecondary Tine 2
GDepth Regulator 1
HUse And Care Guide 1
Part Description Quantity
AA Bolt M6x16
Bolt M8x38
6
BB
CC
Nut M6
2
6
Flat WasherDD 2
Bolt M8x35EE 2
Nut MBFF 2
Part Description Quantity
D Pin
GG
HH
8.4 x 20 Washer
4
2
Cable ClipII 1
Wing NutJJ 2
Clevis PinKK 1
Cotter PinLL 1
H
Safety goggles Adjustable Funnel
wrench
AA DD FFBB CC
E
DC
F
HH II JJ
EE
GG
A
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
KK LL
G

9
Assembly
Assembling the Rear Wheels
□Pull the rear wheel downward so that the rear wheel can
rotate freely, then lift the rear wheel bracket to the
proper position. The rear wheel bracket will
automatically attach with the spring. See Figure 1-1.
□
□
Attach the upper handle to the lower bracket on the main
body of the tiller. Properly align the holes and then secure
with the M8x35 bolt (EE), the flat washer (DD), and the
wing nut (JJ).
Align the face plate (C) holes on the upper part of the
handle. Insert the M8x38 bolt (CC) and nut (FF) to secure.
See Figure 1-2.
Figure 1-2.
3
1
Assembling the Upper Handle
2
Assembling the Depth Regulator
4Assembling the Tines
□Attach the depth regulator to the drag bar holder, choose the
proper height, and then lock the depth regulator (G) with a
clevis pin (KK) and cotter pin (LL). See Figure 1-3.
□Insert the dust covers (B), the tines (E), and the secondary tines (F),
onto the drive shaft in sequence and lock tines with the D Pins (HH).
Make sure the tines and the secondary tines are facing the correct
direction as per the illustration below. See Figure 1-4.
NOTICE: This tiller is shipped without gasoline or oil in the engine.
Fill up the gasoline and oil BEFORE operating your machine.
Figure 1-1
Rear Wheel
EE
JJ
DD
C
CC
FF
G
Figure 1-3
HH
F
B
E
Figure 1-4
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
KK
LL

10
Assembly (continued)
Assembling the Front Protective
Shield
□Align holes on the protective shield end caps (D) to the
main protective shield, and secure with M6x16 bolts (AA)
and M6 nuts (BB). See Figure 1-5
5
WARNING: Make sure the tiller protective shield is
installed in place before starting the machine.
Protective Shield
BB
Figure 1-5
D
AA
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

11
Operation
Adding Gas and Oil
□
□
Remove gas cap. Place funnel securely into the gas tank
opening and add fuel. Do not top off the gas tank.
Secure the gas cap and wipe off any excess fuel.
See Figure 1-6.
□
□
□
Place the tiller on a level surface.
Remove the filler cap. Place the funnel securely into the
crankcase opening and add oil. Do not top off the oil. Check
dipstick to confirm there is an adequate amount of oil.
Secure the oil cap and wipe off any excess oil.
See Figure 1-7.
□
□
□
We recommend the use of 10W-30 oil. Other high-quality
detergent oils are acceptable if classified for service SF, SG,
SH. SJ or higher.
Do not use special additives.
Outdoor temperatures determine the proper oil viscosity for
the engine. Use the chart to select the best viscosity for the
outdoor temperature range expected.
1
WARNING: Use extreme care when handling gasoline.
Gasoline is extremely flammable and the vapors are
explosive. Never fuel the machine indoors or while the
engine is hot or running. Extinguish cigarettes, cigars,
pipes and any other sources of ignition.
IMPORTANT: Use only Regular Octane Fuel. IMPORTANT: We recommend using 10W-30 Oil.
Figure 1-6
Figure 1-7
104
86
68
50
32
14
-4
-22
40
30
20
10
0
-10
-20
-30
°C°F
SAE 30
10W-30
SYNTHETIC 5W-30
5W-30
GAS
OIL
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

Operation (continued)
Controls and Features
RECOIL STARTER
TILLER PROTECTIVE SHIELD
FORWARD LEVER
□
□
The recoil starter is attached to the right side of the upper
handle. Stand behind the unit and pull the recoil starter
rope to start the unit.
The tiller protective shield is located in the rear of the tiller
and it is used to shield you from debris being thrown.
□The forward lever located on the upper handle controls the
tiller's action to start the tine rotation.
ON/OFF SWITCH
□The On/Off switch is needed to start and stop the tiller.
2DEPTH REGULATOR
TINES
□
□
In hard compacted soil, the depth regulator helps restrain the
tiller's forward motion. In looser soil, it controls how deeply the
tines can dig into the ground.
The tines and secondary tines are the are rotating metal blades
that dig into the soil.
OIL DIPSTICK
□Located on the engine, the opening for the oil dipstick is used
to add oil. The oil dipstick is used to measure the amount of oil
in the crankcase. This tiller does not come with oil. Oil must be
added before operating the tiller.
Recoil Starter
Oil Dipstick
12
Forward
Lever
Depth Regulator
Tiller Protective Shield
On/Off
Switch
Tines
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

Operation (continued)
Pre-Start Inspection
□
□
□
□
□
□
□
□
□
□
□
Make sure all safety guards are in place and all nuts
and bolts are secure.
Check oil level in engine crankcase. Add oil if necessary.
Check the fuel supply. Fill the fuel tank no closer
than 1 inch from the top of the tank to provide space for
expansion.
Be sure the spark plug wire is attached and the spark
plug is tightened securely.
Check the depth regulator lever position.
Examine underneath and around engine for signs of
oil or fuel leaks.
Inspect the fuel hoses for tightness and fuel seepage.
Look for signs of engine damage.
Remove excessive debris from muffler area and
recoil starter.
Always set the wheels in tilling position before starting
engine.
Always put depth regulator lever in the transport position
before starting engine. The tines should clear ground.
□
□
□
□
□
COLD STARTS
Put the On/Off switch located on the back of the engine
in the On position.
Press the primer bulb 3 times.
Pull the recoil starter grip lightly until resistance is felt, and
then pull rapidly.
RESTARTING A WARM ENGINE
Put the On/Off switch located on the back of the engine
in the On position.
Pull the recoil starter lightly until resistance is felt, and then
pull rapidly.
3
WARNING: Gasoline is highly flammable and must be
handled with care. Never fill the tank when the engine is hot
or running. Always move outdoors to fill tank.
Starting the Tiller
4
13
CAUTION: Please do not start your tiller until you have
read the manual that comes with your tiller, including the
tiller controls and safety sections. If you have read the
manual, follow the steps below to start your tiller. Always
perform this pre-start checklist before starting the engine.
CAUTION: Be sure the forward lever is disengaged
to prevent sudden uncontrolled movement when the engine
starts. The forward lever is engaged by pulling in the
lever and disengaged by releasing the lever.
DANGER: Always keep hands and feet clear of rotating
machine parts.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
I
On/Off
Primer Bulb

Operation (continued)
Shutting Down the Tiller
□To stop the engine at any time, turn the engine On/Off
switch to the Off position. □
□
Engages wheels and tines into forward.
Pushing down the drive safety control lever (FORWARD)
toward the handlebar engages the tines.
Releasing the lever stops the tines and brings the tiller
to a complete stop.
5
Tilling
□
□
Adjust the depth regulator lever to desired tilling depth.
Insert the clevis and cotter pin to secure depth
regulator to desired depth. See Figure 1-8.
Place the tiller in forward position by pushing down on the
forward control lever (FORWARD)--this will engage the tines.
6
WARNING: Raise depth regulator up one hole at a time,
testing tiller operation after each raise. Raising depth
regulator too high can result in loss of control of tiller!
WARNING: Temperature of muffler and nearby areas
may exceed 150˚F. Avoid these areas. Do not move choke
control to stop engine, as backfire or engine damage may
occur. To stop wheels and tines at any time, release drive
safety control levers to neutral position. Always release
drive safety control levers to neutral position AND STOP
THE ENGINE before adjusting the depth of the regulator lever.
Drive Safety Control Levers
7
14
NOTICE: You can slow the tiller’s forward advance at any time
by putting slight downward pressure on the handlebars. You can stop
the tiller by releasing the drive safety control levers to the neutral
position.
Figure 1-8
FORWARD LEVER
IMPORTANT: Practice operating the controls and
tiller with tines out of ground before beginning to till.
It is important that you know how to use the tiller
properly, keep control at all times, stop the tines and
wheels from turning, and stop the engine if necessary.
If you do not know how to do these things, read the
controls, adjustments and safety sections before
proceeding.
123
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

Operation (continued)
Adjusting the Handle Height
□To adjust the tiller height, loosen the wing nut (JJ),
select the appropriate hole for height and tighten.
See Figure 1-9.
8
15
JJ
Figure 1-9.
Tilling Tips
□
□
□
□
□
□
□
□
9
The key to successful tilling is to begin with a shallow cut
on the first pass, and then work an inch or two deeper on
each successive pass.
Tilling depth will vary with ground conditions.
When beginning to till in unbroken ground or in extremely
hard soil, set the clevis and cotter pin in the highest hole of the
depth regulator. This will allow for shallow tilling. With the depth
regulator in this position, make several light passes over
the area to be tilled. Reset for deeper depths with successive
passes.
If tiller jumps or skids uncontrollably, lower the depth
regulator by placing the clevis and cotter pin in a higher hole.
This will allow for shallower tilling. Hold firmly to the handlebars
to control sudden lurches.
If weeds, tall grasses, vines, or other materials clog or jam
the tines, reverse the tiller to unwind vegetation.
Immediately release the forward lever if the tines jam
or you strike a foreign object. Turn the tiller off and
disengage the spark plug wire. When tines have stopped,
remove foreign objects and check for damage.
CULTIVATING
Plant rows on 20 - 22 in. centers for ease of turning.
Set the depth regulator lever with the detent pin in one
of the higher holes. This will allow for shallow cultivation
necessary to turn over weeds, and break up and aerate
the soil.
CAUTION: Before adjusting the handle bar, place the tiller
on firm level ground to prevent the handle from collapsing
accidentally.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
□If operating equipment with engines regularly at altitudes over
5,000 feet, the carburetor’s air-fuel mixture will be too rich and
emmissions may increase. On engines not built for the United
States the carburetor can be adjusted to operate under this
condition. The carburetor should be returned to its normal setting
if regular operation is less than 5,000 feet. Contact your service
center to modify the carburetor.
HIGH ALTITUDE OPERATION

Maintenance
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
□
The warranty on this tiller does not cover items
that have been subjected to operator abuse or negligence.
To receive full value from warranty, operator must
maintain the tiller as instructed here.
Changing of engine-governed speed will void engine
warranty.
All adjustments should be checked at least once each
season.
Periodically check all fasteners and make sure these are
tight.
Good maintenance is your responsibility.
Follow good shop practices.
Keep service area clean and dry.
Use adequate light for the job at hand.
Make sure the engine is off before you begin any
maintenance or repairs. This will eliminate several potential
hazards.
Be sure there is adequate ventilation whenever you operate
the engine to avoid carbon monoxide poisoning.
Never operate the engine in a closed building.
Let the engine and exhaust system cool before touching.
Do not run the engine unless instructed to do so.
Read the instructions before you begin, and make sure you
have the tools and skills required.
To reduce the possibility of fire or explosion, be careful when
working around gasoline.
Use only a nonflammable solvent, not gasoline, to clean
parts. Keep cigarettes, sparks and flames away from all fuel
related parts.
Lubricate the wheels at least once a season with light oil (or
motor oil). If the wheels are removed for any reason, lubricate
the surface of the axle bolt and inner surface of the wheel with
light oil.
Always use personal protection devices such as eye, hand and
hearing protectors when performing any service or
maintenance.
Frequently check tiller tines. They should be free of nicks and
cracks and securely fastened in place.
Periodically tighten all bolts, nuts, screws, and check that all
pins are properly installed to make certain the tiller is safe to
operate.
When completing maintenance or service, make sure all safety
guards and devices are installed before using the tiller.
Where replacement parts are necessary for periodic maintenance
and servicing, use only OEM replacement parts for repair and
replacement to restore your equipment to original specifications.
The manufacturer and/or distributor will not be responsible for
injuries or damages caused by use of unapproved parts and/or
accessories.
A first aid kit should be kept readily accessible while performing
maintenance on this equipment.
Always observe safety rules when performing any
maintenance.
16 HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

Maintenance (continued)
□
□
Your tiller has been designed and produced by the industry’s leading manufacturer of outdoor power equipment to provide you with
years of reliable operation. Keeping your tiller in top running condition will prolong its life, and help you obtain optimum performance.
Please read this normal care schedule, and note the recommended care operating intervals to extend the life of your tiller.
*Service more frequently when used in dusty areas.
MAINTENANCE SCHEDULE
17
Before Each UseMaintenance Operation
Engine Oil
Air Filter
Tine Shaft
Wheel Axle Shaft
First
Month or
20 Hours
Every
3 Months
or
50 Hours
Every
6 Months
or
100 Hours
Every
Year or
300 Hours
Check Level
Change
Check
Clean
Replace
Clean
Lubricate
Spark Plug Clean Adjust
Fuel Strainer Clean
Fuel Line Check Every 2 Years (Replace if necessary)
√
√
√
√
√
√
√
√* √*
√ √
WARNING: Use only genuine replacement parts. Other
parts may damage the tiller or result in injury.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.

Maintenance (continued)
□
□
□
CHECK OR FILL ENGINE CRANKCASE
Add oil. Do not overfill. Use a clean, high quality detergent
oil. Do not mix oil with gasoline. Oil level must be full.
Check the engine oil level. With the engine off and cool,
place the machine on a flat, level surface, twist the oil
cap ¼ turn left and remove. Wipe the dipstick clean,
reinsert then remove and see if oil is within the hash
marks; add as necessary but do not overfill.
Always check oil level before starting engine.
18
IMPORTANT: Engine is shipped from factory without oil. You
must add engine oil before starting engine.
.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
L
Oil
Level
Oil Dipstick

Care, Cleaning and Storage
□
□
□
□
□
□
□
□
□
□
Coat the axles lightly with axle grease.
Drain fuel system completely or add fuel stabilizer to prevent
fuel from gumming up during extended storage period.
While engine is still warm, drain the oil from the engine.
Refill with fresh oil of the recommended grade.
Clean external surfaces, engine and cooling fan.
Remove spark plug, pour one ounce of SAE 30 oil into spark
plug hole.
Plug hole and pull the recoil starter slowly to distribute oil
evenly in cylinder head area.
Reinstall spark plug.
Transport unit to a suitable storage location. If you have
chosen to use a fuel stabilizer and have not drained the fuel
system, follow all safety instructions storage precautions in
this manual to prevent the possibility of fire from the ignition
of gasoline fumes. Remember, gasoline fumes can travel to
distant sources of ignition and ignite, causing risk of
explosion and fire.
If there is any possibility of unauthorized use or tampering,
remove the spark plug and store it in a safe place before
storing the tiller.
Be sure to plug the spark plug hole to prevent foreign
material from entering.
19
Follow the steps below to prepare your tiller for storage.
WARNING: Do not store tiller in an unvetilated area where
fuel fumes may reach flame, sparks, pilot lights or an ignited
object. Drain fuel outdoors away from any ignition sources.
Use only approved fuel containers.
HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
□
□
□
□
□
□
CLEAN TINE AXLE SHAFT
Turn off engine. Wait until engine is cool.
Remove spark plug wire and secure away from spark plug.
Tip the tiller forward. Block the tiller in position so that
it rests on the engine mount and the tines are exposed.
Remove all debris, string, wire, and other material that
may have accumulated on the axle between the inside
set of tines and the seal on the transmission housing.
Place the tiller back to an upright position.
Replace spark plug wire.

Troubleshooting
Problem SolutionCause
The engine is difficult
to start.
□Add fresh fuel.
Turn the engine switch On.
Move the choke lever to the On position.
Attach spark plug wire to the spark plug.
Remove spark plug and inspect. Replace if necessary.
Take the tiller to an authorized service center to clean
the carburetor.
Remove and clean the air filter.
Drain and clean the fuel tank. Fill with fresh fuel.
The engine is out of fuel.
The engine switch is Off.
The engine is not primed.
The spark plug wire is disconnected.
The spark plug is fouled.
The carburetor is dirty.
The air filter is clogged.
The fuel is contaminated.
□
The engine is
experiencing problems.
Problems may include
smoking excessively,
running very "rough,"
running erratically, or
not maintaining full
speed.
□Add engine oil.
Check engine oil, and add or drain engine oil if necessary.
Remove spark plug, inspect or replace if necessary.
Remove and clean air filter.
Drain and clean the fuel tank. Fill with fresh fuel.
Take the tiller to an authorized service center to clean
the carburetor.
There is no engine oil in the crankcase.
The engine oil is not at proper level.
The spark plug is fouled.
The air filter is clogged.
The fuel is contaminated.
The carburetor is out of adjustment.
□
The tiller produces
excessive vibration
and noise.
□Tighten all fasteners.
Refer to The Engine is Experiencing Problems section
(above).
There are loose parts.
Refer to The Engine is Experiencing Problems
section (above).
□
The tines will not
rotate.
□
□
Remove debris from around tines.
Replace tine bolts and nuts.
There is debris interfering with the tines.
Tines are loose.
□
□
The engine will not stop.
□Replace the On/Off switch.The On/Off switch is not working properly. □
The tines do not cut
properly.
□Refer to the “Install the Tines” section.The tines are assembled incorrectly. □
The engine stalls
frequently.
□
□
Till at a moderate pace. Make multiple passes.
Refer to The Engine is Experiencing Problems section
(above).
The tilling speed / depth is too fast for conditions.
Refer to The Engine is Experiencing Problems
section (above).
□
□
□□
□
□
□
□
□
□
□
□
□
□
□□
□□
□□
□□
□□
□
□
□
□
20 HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
