Lehmannaudio Black Cube II User manual

Black CubeII
Black Cube SEII
Phonoverstärker
Phono Stage/Amplificateur Phono
Amplificador Phono/Preamplificatore Phono
Bedienungsanleitung/Manual/Mode d’emploi/Manual de instrucciones/Istruzioni per l’uso
FR
ES
IT
DE
EN

Lehmannaudio Vertriebs GmbH
Waltherstr. 49 – 51
51069 Köln (Germany)
Phone: +49 221 – 29 49 33 20
Fax: +49 221 – 29 49 33 19
[email protected]
www.lehmannaudio.com
www.facebook.com/lehmannaudio
www.twitter.com/lehmannaudio
31 | Introduction
32 | Important safety notes
36 | Installation
38 | Functional description
41 | Putting into operation
42 | Common settings
44 | Expert notes
Although you may have had some experience with phono stages from other
manufacturers, please read the manual carefully before putting the Black
CubeII/Black Cube SEII to service and keep it close to the device for future
reference!
Table of content
47 | Sound optimisation tips
48 | Technical data
49 | Troubleshooting
53 | Legal notes
138 | Annex: Filter settings and
measured values
Introduction
Dear customer,
thank you very much for your trust you’ve shown us by purchasing the Black
CubeII
or the Black Cube SEII respectively . This phono preamplifier from
Lehmannaudio is a meticulously crafted device for the connection of common
turntables equipped with MM or MC systems.
All our products are developed and manufactured exclusively in Germany. Since
the company foundation in 1988 Lehmannaudio has been representative for
first-class devices, which are always committed to the original sound and built
with love for details. Owing to finest components and a sophisticated circuit
design we can guarantee a superb standard of listening enjoyment. The Black
CubeII
, and even more so the Black Cube SEII, are superior to industrial mass
products in every respect. As follow-up models of the classic Black Cube, they
will take the Black Cube series to a new level.
More information can be found in this user manual and also on our website at
www.lehmannaudio.com.
Now you can get the very best from your favourite records and experience
analogue music enjoyment full of passion again.
Your Norbert Lehmann
CEO
31
EN
Black Cube II/Black Cube SE II

Important safety notes
In this manual we use hierarchic ‘red flags’. Warning notes are printed in bold
and also marked and highlighted by a symbol (warning sign) in the text.
The warning notes are classified hierarchically according to the following
scheme:
1. WARNING!
2. CAUTION!
3. NOTE!
This symbol points to important operation and maintenance
notes in the accompanying documentation. Please refer to the
manual.
This symbol warns of the presence of a non-insulated
hazardous voltage inside the device and the risk of a potentially
life-threatening electric shock.
This symbol refers to additional information in the manual. Here
you will find supplementary information, recommendations and
tipps regarding the use of the product.
CAUTION!
Read all safety and operation notes before putting the device
to service.
Storage
Keep the safety and operation notes for future reference.
Warning notes
Observe all warning notes printed on the device or contained in the manual.
Operation notes
Follow all operation notes and advice for users.
Heat
The device must not be placed near heat sources like radiators, heat accumu-
lators, stoves or other heat-generating appliances (e.g. amplifiers).
Ventilation
Do not cover any ventilation slots on the device and when mounting it in a rack,
make sure that there is sufficient air circulation. Always heed the appropriate
manufacturer notes when installing the unit.
Water and moisture
Do not expose the unit to rain nor use it in close proximity to water (bath tub,
swimming pool etc.) or in high air humidity (condensation).
Ingress of liquids
Make sure that no dripping or spray water can enter into the interior of the unit.
Don’t place objects filled with liquids (such as vases or drinking vessels) on the
device.
3332
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Power cable
Use only power cables which are officially approved for your country. The power
cable must be designed for the product and its corresponding power consump-
tion (voltage/current) as stated on the device label and in the user manual.
CAUTION!
Use the device only on a power outlet with protective conductor
connection and correct polarity. Do not disable the function of
the protective conductor connection on the included power cord.
If the plug of the included cable won’t fit into your mains outlet,
contact your local electrician.
Mains connection
Protect the power cord from footsteps and crushing, notably on the device plug,
the extension cord and the cable outlet on the device.
Power supply
Only use the included power supply.
Thunderstorm
Disconnect the unit from mains to protect it from lightning strokes and excess
voltage.
Electric overload
Do not exceed the maximum load current for power outlets, extension cables or
integrated multi sockets. Overload may cause a fire.
Fire sources
Do not put any open fire sources (e.g. burning candles) on the device.
Accessories
Use only accessories/extensions with the device which have been approved by
the manufacturer for this purpose.
Mounting
Use the device only in a safe, level position on a table, dolly or a special
designed stand. Don’t drop the unit, since this may cause personal injuries and
damages to the device. When installing the device, make sure that the mains
plug will remain easily accessible.
Cleaning
Use only a dry cloth for cleaning the device.
Non-use
Pull the mains plug if the unit is not used over prolonged periods of time.
Service
All service and repair works must be carried out by an authorised service techni-
cian. Service is required if the device has been damaged in any way, for instance
if
≠the power cord or mains plug have been damaged,
≠liquid or some object has got into the unit,
≠the device has been exposed to rain or moisture
≠or if it does not function normally or after it has been dropped.
Spare parts
Only such spare parts must be used exclusively for repair works which have been
specified and approved by the manufacturer.
3534
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Installation
This section tells you about the connections, control elements
and application possibilities of your Lehmannaudio Black CubeII/
Black Cube SEII phono amplifier.
1 | Unpacking
After unpacking the Black CubeII/Black Cube SEII check it for possible transport
damages. If you notice visible damages, you must by no means connect the
device to mains. In this case consult your dealer immediately.
Delivery includes the following components:
≠Black CubeII device
≠Power supply (Black CubeII) or
PWX power supply (Black Cube SEII)
≠Mains cable
≠User manual
≠Allen key (2 mm)
≠2 jumpers
≠Certificate of warranty
Note
We recommend keeping the entire packaging for later shipment.
That way you will avoid transport damages. Use by no means
‘foam chips’ or similar packaging material. Otherwise the device
will jolt through to the bottom of the cardboard box during
transport and can be damaged! If the original packaging is no
longer available, it’s best to use bubble wrap in which to wrap up
the device in a generous manner. Finally the whole should be put
into a solid cardboard box.
2 | Setup
Always position the Black CubeII/Black Cube SEII on a stable surface. Thanks to
the compact dimensions and low weight, you can set up the Black CubeII/Black
Cube SEII directly next to the record player.
3 | Connecting
Check whether the included mains adapter is suitable for connection to the
mains network used in your country. On the adapter, you will find informa-
tion about the specified mains voltage for the device. Now connect the Black
CubeII/Black Cube SEII to the mains network using the external power supply
and the connection on the rear of the device.
Note the safety instructions starting on page 32!
3736
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Front panel
1
1 | Operating mode display (LED)
When the LED is lit up, the Black CubeII/Black Cube SEII is operational. The
device does not have a power switch.
Functional description
In this chapter you will learn more about the connections,
controls and also the application possibilities of your
Lehmannaudio Black CubeII/Black Cube SEII phono stage.
Rear panel
2 3
4 5 6 7
2| Ground terminal (GND)
If your record player has a separate ground cable, please connect it here. The
terminal is suitable for connecting a cable, flex, open cable ends, cable lug or
4mm banana plug.
3 | Grommet for the external power supply (Black CubeII)/PWX power
supply (Black Cube SEII)
The four-pin Neutrik XLR connector is plugged into the enclosed power supply.
Please do never pull off or plug in this connection during operation.
4 + 6 | Output jacks (OUT)
RIAA filtered high-level output. Connect the cables that either lead to the input
of a downstream high-level pre-amplifier (high-level inputs are labelled ‘Line’,
‘AUX’, ‘CD’, ‘Tuner’ etc.) or directly to a power amplifier with volume control. The
left jack (black) is for the left channel, the right jack (red) for the right channel.
Please be sure to connect the channels correctly.
3938
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

ATTENTION!
Never connect the output of the Black CubeII/Black Cube SEII
to the phono input of another device. This could damage the
phono stage or speakers.
5+7| Input jacks (IN)
Connect the cables coming from your record player to these jacks. Here too,
please be sure to connect the cables to the correct channels.
Putting into operation
To put your Black CubeII/Black Cube SEII into operation, you
need information about your pick-up system.
Two details are important: Are we talking about an MM (moving magnet) or MC
(moving coil) system? What is the required connection resistance? As a rule, you will
find both pieces of information on the product packaging of your pick-up system.
Please ask your specialist dealer for recommended values in case of doubt. Support
for correctly configuring your Black CubeII/Black Cube SEII will be gladly provided.
Once you have the required information, please proceed as follows:
1 | Set the volume on your system to minimum or turn your amplifier off
entirely.
2 | Connect the power supply.
3 | Set the gain for your pick-up system (MM/MC) on the Black CubeII/Black
Cube SEII. The settings must be made in the same way for both channels
and are done by means of the DIP switches A and B on the bottom side
of the device. Common amplifier settings for various types of pick-ups
are found on the next page. The gain switch (respectively B1) is active on
delivery.
4 |
Set the terminating resistance on the Black CubeII/Black Cube SEII. The
setting must be identical for both channels. Use the custom impedances in-
side and the DIP switches on the bottom of the device. Further information
is found on page 44.
5 | Connect the record player to the input on the Black CubeII/Black Cube SEII.
6 | Connect the output on the Black CubeII/Black Cube SEII to a line input on
the downstream amplifier. To largely exclude line losses, the signal cables
should be kept short.
4140
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Common settings
The switch configurations for some systems are listed below.
Please bear in mind that both channels must have identical
settings.
System Switch A Switch B
MM
MM High output
MC 47 kohms
MC 47 kohms Mid output
MC 1 kohm
MC 1 kohm Mid output
MC 100 ohms
MC 100 ohms Mid output
MC custom impedance
MC custom impedance Mid output
4342
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Expert notes
The Black CubeII/Black Cube SEII can be adapted to virtually
all systems available on the market. With the exception of the
DIP switches, the adjustment mechanisms are located inside
the device and should only be changed by experts. An Allen key
for opening the enclosure and jumpers for bridging the output
capacitors are supplied with the device.
DC L
CON102 CON101 CON202 CON201
DC R
ON
1234
ON
1234
ON
123
ON
123
ON
12
ON
12
R 102 R 202
R 104 R 204
1
2
3
4
5
6
Interior view
1 | DC L/DC R
The MKP output capacitors are bridged with these jumpers so they are no longer
in the signal path. These jumpers are not activated at delivery.
ATTENTION!
When output capacitors are bridged, there may be DC voltage on
the outputs. Before activating these jumpers, it is therefore neces-
sary to ensure that the downstream input stage has a DC voltage
input filter since DC voltage can damage the speakers. In case of
doubt, have your system checked by the dealer first.
2 | DIP switch C on the bottom side of the device
With switch no. 1 you can set the bass cut filter behind the output stage to 27 Hz.
Switch no. 2 sets the filter to 15 Hz.
An attenuation of the low-frequency range may be useful to protect your
loudspeakers against excessive transients, particularly from warped records. If the
speakers are placed close to a wall, a low-frequency adjustment can enhance the
sound.
The Black CubeII/Black Cube SEII offers a total of 16 different filter settings
which you can select by ear. More details on the different setting options can be
found in the annex on page 138 ff.
3 | DIP switch B on the bottom side of the device
Switch no. 1 changes the gain by +10 dB and is active on delivery.
Using switches no. 2 and 3 you can set the bass cut before the output stage to 23,
30 or 47 Hz. More details on the different filter settings can be found in the annex
on page 138 ff.
4544
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

4 | DIP switch A on the bottom side of the device
With these switches you can choose between different gain settings and also
select the input impedance for MC systems. Common setting options for various
systems are available in the chart on page 42 f.
5 | R104/R204
Available custom impedance plug connections for activation with the DIP switches
for the channels (respectively no. 3). An impedance/capacity activated here is
switched in parallel to all other impedances/capacities activated by switches and
the 47 kohms/100 pF.
6 | R102/R202
These are free hardwire plug-in slots for additional impedances/capacitors with
immediate effect and no need for activation via switches. A resistor/capacitor
plugged in here will be put in parallel with all other switch-activated impedances/
capacitors and the 47 kohms/100 pF.
1 | Adjusting the pick-up arm geometry and system should always be performed by
a specialist. In case of incorrect settings, the effects range from sound problems to
one-sided and therefore premature wear of the system. Good specialist dealers have
special measuring and adjusting equipment. It is much more accurate than what may
be included with the pick-up system.
2 | On record players with a sub-chassis, the vibration behaviour should also be
optimised by an expert. Sound improvements are possible here as well.
3 | Using a decoupling mat that contributes to better mechanical separation
between the record and turntable can further improve the sound quite significantly.
4 | Special attention should also be paid to the chosen cable materials and
assembly. This applies in particular to the system cables (headshell), the cables from
the pick-up to the Black CubeII/Black Cube SEII and the cables to the downstream
pre-amplifier.
Sound optimisation tips
The Black CubeII/Black Cube SEII can only be as good as the
signal supplied by the turntable or pick-up system. Since playing
back a record consists of mechanical sampling with many impor-
tant influencing variables, we provide some sound optimisation
tips here. For high-end record players in particular, you should
consult your dealer for the required service and adjustments.
4746
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Technical specifications
MM MC
Sensitivity for output level
775 mV/ 0 dB
(with activated high gain switch)
3.8 mV/1 kHz 0.38 mV/1 kHz
Gain 1 kHz 46 dB 66 dB
Maximum input level 45 mV 4.5 mV
Signal to noise ratio
(RMS unweighted)
71 dB 63 dB
Gain 36 dB, 46 dB, 56 dB, 66 dB
Channel separation > 85 dB at 10 kHz
Input impedance 47 kohms, 1 kohm, 100 ohms
≠1 x custom load
≠1 x Hardwire slot
Output impedance 47 ohms
Input capacitance 100 pF
Channel mismatch typ. 0.5 dB
Bass filter 16 settings between 7 Hz and app. 90 Hz
Power consumption < 3 W
Mains voltage ≠Europe: 240 V AC
≠USA/Canada/Mexico/Taiwan: 120 V AC
Fuse ≠Europe: 250 mA Slow
≠USA/Canada/Mexico/Taiwan: 500 mA Slow
Outer dimensions W x D x H ≠Audio section: 114 mm x 124 mm 50 mm
≠Power supply (Black CubeII):
70 mm x 115 mm x 55 mm
≠PWX power supply (Black Cube SEII):
92 mm x 232 mm x 45 mm
Weight ≠Audio section: 0.6 kg netto
≠Power supply (Black CubeII):
0.3 kg netto
≠PWX power supply (Black Cube SEII):
1.0 kg netto
Troubleshooting
Fault Cause Solution
LED indicator is
not lit.
The mains cable is not
plugged in at the power
outlet.
Insert the mains cable into the
power outlet.
The power supply is not
connected with the device.
Connect the power supply with
the device.
No signal. The mains cable is not
plugged in at the power
outlet.
Insert the mains cable into the
power outlet.
The power supply is not
connected with the device.
Connect the power supply with
the device.
Input and output are not
wired correctly on the
Black CubeII/Black Cube
SEII.
Check if the cables coming
from the turntable are con-
nected to the input and also if
those going out to the amp are
connected to the output of the
Black CubeII/Black Cube SEII.
Reconnect them correctly if
necessary.
A wrong input channel
has been selected on the
following amplifier.
Select the appropriate input
channel.
4948
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Signal on one
channel only.
The DIP switches are
unevenly set.
Check the positions of both
DIP switches. Make sure that
the settings are equal on both
channels.
One connection lead
has a loose contact, is
not well plugged in or
defective.
Check the connection leads
for slack joints, loose pushfits
or defects and, if necessary,
replace them. Potential causes:
system cable (headshell),
tonearm cable from turntable
to Black CubeII/Black Cube
SEII and line cable from Black
CubeII/Black Cube SEII to the
following input.
The subsequent input
stage is defective.
Check by connecting to differ-
ent line inputs.
Left and right
channels are
reversed.
The channels were re-
versed in the connection
lead.
Check the connection leads and
swap the channels here, if nec-
essary. Potential causes: system
cable (headshell), tonearm cable
from turntable to Black CubeII/
Black Cube SEII and line cable
from Black CubeII/Black Cube
SEII to the following input.
Signal level is too
low.
Non-optimal matching
between pickup cartridge
and Black CubeII/Black
Cube SEII.
Increase the gain factor ac-
cording to this user manual
by means of the DIP switches
located on the bottom side of
the Black CubeII/Black Cube
SEII.
The selected input
impedance on the Black
CubeII/Black Cube SEII is
too low.
Select a resistance value for the
input impedance which is at
least 10 times greater than the
pickup’s system impedance.
Signal is soft and
muffled.
An MC impedance has
been selected for an MM
system.
Deactivate all MC impedances
via DIP switch. Also watch out
for a custom impedance that
may be plugged in.
Signal sounds
distorted.
The gain is set too high
on the Black CubeII/Black
Cube SEII.
Lower the gain factor according
to this user manual by means
of the DIP switches located on
the bottom side of the Black
CubeII/Black Cube SEII.
The output of the Black
CubeII/Black Cube SEII is
connected to the subse-
quent phono input.
Connect the output of the
Black CubeII/Black Cube SEII
to a line input on the following
amp.
The signal sounds
hollow, without
a proper bass and
localisation.
The pickup system has
been connected phase-
reversed.
Connect the system cable
in-phase.
Audible hum.
The tonearm ground is not
connected on the Black
CubeII/Black Cube SEII.
Connect the tonearm ground
on the Black CubeII/Black Cube
SEII.
Several connected devices
create a ground loop.
Make a correct grounding con-
nection. If required, consult an
electrician.
There is an interference
caused by some other
power consumer.
One by one, disconnect all
devices connected to the same
electric circuit and listen to the
effect. Keep the interfering
device turned off during music
listening or use a mains filter to
connect it to the electric circuit.
5150
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Audible hum. The mains transformer of
a device placed nearby is
causing interference at
the input.
Make sure the distance
between your hifi chain and
interfering devices is sufficient.
Radio interference
audible in the
background.
The tonearm ground is
not connected on the
Black CubeII/Black Cube
SEII.
Connect the tonearm ground
on the Black CubeII/Black Cube
SEII.
The standard input ca-
pacitance (100 pF) is too
low for MC.
See your dealer to have the
custom impedance plug-in
slot fitted with an additional
capacitance.
If a problem cannot be remedied with the help of this summary, please contact
the specialist retailer where you purchased the device. If this is not possible, you
can easily find another competent dealer in your area with the dealer search at
www.lehmannaudio.com/service/dealers.
Legal notes
Warranty
Each device from Lehmannaudio is tested individually and subject to a compre-
hensive functional check. The use of only the very best components enables us
to grant a warranty of two years.
The receipt/proof of purchase shall serve as warranty proof. A registration form
is supplied with the product or can be downloaded at www.lehmannaudio.com/
service/register.html. Damages due to incorrect installation or inappropriate
handling are not covered by warranty and will therefore be repaired at the
owner’s expense. Claims for damage of any kind, notably for secondary failures,
are excluded. In addition we exclude any liability which exceeds the merchandise
value of the device.
The general terms and conditions apply of:
Lehmannaudio Vertriebs GmbH
Waltherstr. 49 – 51
51069 Köln (Germany)
Phone: +49 221 – 29 49 33 20
Fax: +49 221 – 29 49 33 19
www.lehmannaudio.com
State of technology
To ensure the highest audio quality, Lehmannaudio devices are constantly
updated to the current state of the art. We reserve the right to make necessary
alterations in design and circuitry without prior notice. Technical data and visual
appearance may therefore differ from the present user manual.
5352
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Service
In any event all maintenance or repair works must be carried out by quali-
fied technical staff. If you want to send back the device, please contact
Lehmannaudio directly to discuss the procedure in detail.
For service works on the Black CubeII/Black Cube SEII please contact the
retailer where you purchased the device. If this is not possible, you can easily
find another competent dealer in your area with the dealer search at
www.lehmannaudio.com/ service/dealers.
Any modifications on the device are not permissible. In case of nonobservance
the device will lose its CE conformity and warranty claims.
Trademark and copyright
All trademarks and registered brands used in this manual are property of the
respective right holders.
This user manual is protected by copyright. Any duplication or reprint, even
in excerpts, is only permitted with the written consent of the Lehmannaudio
Vertriebs GmbH. This also applies to the pictures and graphic works used.
CE conformity
When properly installed in line with this handbook, this product complies with
the following European directives:
Low-Voltage Directive 2006/95/EG: EN 60065
EMV Directive (electromagnetic compatibility) 2004/108/EG:
EN 55103-1:2009, EN 55103-2:2009
RoHS conformity
The product has been manufactured in compliance with the directive 2002/95/EG.
WEEE Disposal of waste electronic equipment
The crossed-out trash bin is the EC symbol for the separate disposal of waste
electronic equipment. The Black CubeII/Black Cube SEII contains electric and
electronic components which, after disposal of the device, will either be reused
or salvaged and recycled. According to the directive 2003/108/EG it must
therefore not be disposed of together with household waste. In case of disposal
please take the junk device back your dealer or request further information
there.
The Lehmannaudio Vertriebs GmbH is listed in the WEEE registry.
Norbert Lehmann, managing director
Cologne, May 02, 2020
5554
EN EN
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Anhang/Annex/Annexe/Anexo/Allegato
Filter/Filtre/Filtro
Schalter/
Switch/
Interrupteur/
Interruptor/
Interruttori
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
Filter/Filtre/Filtro
Schalter/
Switch/
Interrupteur/
Interruptor/
Interruttori
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
139138
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Filter/Filtre/Filtro
Schalter/
Switch/
Interrupteur/
Interruptor/
Interruttori
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
Filter/Filtre/Filtro
Schalter/
Switch/
Interrupteur/
Interruptor/
Interruttori
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
141140
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Filter/Filtre/Filtro
Schalter/
Switch/
Interrupteur/
Interruptor/
Interruttori
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
Filter/Filtre/Filtro
Schalter/
Switch/
Interrupteur/
Interruptor/
Interruttori
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
143142
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Filter/Filtre/Filtro
Schalter/
Switch/
Interrupteur/
Interruptor/
Interruttori
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
Filter/Filtre/Filtro
Schalter/
Switch/
Interrupteur/
Interruptor/
Interruttori
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
6-
0-
5-
4-
3-
2-
1-
d
B
u
02 k1 03 04 05 06 07 08 001 002 003 004 005 007
zH
B
C
145144
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Filter/
Filtre/
Filtro 28 Hz 38 Hz 20 Hz 32 Hz fg/Hz
B2 B3 C1 C2
1––––7
2– – X – 20
3X – – – 28
4– – – X 32
5X – X – 37
6– X – – 38
7– X X – 45,5
8X – – X 46
9– – X X 47
10 – X – X 55
11 X – X X 60
12 X X – – 60,5
13 X X X – 67
14 – X X X 69
15 X X – X 76
16 XXXX88
147146
Black Cube II/Black Cube SE IIBlack Cube II/Black Cube SE II

Lehmannaudio Vertriebs GmbH
Waltherstraße 49 – 51
51069 Köln
[email protected]
www.lehmannaudio.com
www.facebook.com/lehmannaudio
www.twitter.com/lehmannaudio
Made in Germany
DE–EN–FR-ES-IT/V.2005
