User's Manual
LEICKE Portable Power Station
(LEICKE external battery 4400 mAh
Product number: AK69197

Thank you for purchasing the LE CKE Portable Power Station.
We hold several brands to produce and distribute our products: LE CKE (power adapters, batteries),
KanaaN (adapters/converters, charging cables etc.), Sharon (iPad cases with keyboard, fans etc.),
Hebron (protective cases, docking stations, screen protectors etc.), Manna (notebook cases).
We continuously work on the further development of our products, our customer support and
innovations. ur products have a long service life, are eco-friendly and high performing. Furthermore,
every day we do our very best to satisfy you as our customer. That is why you, no matter if private or
business customer, are in the focus of our company‘s efforts. We take your reviews and proposals
seriously and evaluate them continuously. That way, we get to know you and your demands on our
products and services better and thus allow for positive enhancements.
To discover more about LEICKE products, or if you have any questions about this product, visit our
website www.leicke.com (production & wholesale) or www.leicke-distributor.de (distribution) and feel
free to contact us.
2

Dear customer,
The LEICKE Portable Power Station enables you to charge your mobile up to 2 or 3 times
where er you are. The included adapters and the USB port allow you to use your LEICKE
Portable Power Station with different mobile and smartphones, e.g. iPhone, Samsung, HTC,
Sony Ericsson or Nokia. The external LEICKE battery has a practical charging indicator LED.
This external LEICKE battery fits in e ery pocket and is ideal for usage on the mo e thanks
to its small size. For optimal protection of the Power Station a protection case is included in
deli ery. This case holds place for all necessary cables and adapters.
For optimum performance, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for further reference.
Your LEICKE Team!
PACKAGE CONTENTS
Before attempting to use this device, please check the packaging and make sure the
following items are contained in the package:
Name Number of Pieces Note
LEICKE Portable Power Station 1 -
USB adapter cable 1 USB to 3.5mm pin port
Micro USB port 1 -
Mini USB port 1 -
Mobile phone adapter 6 For different producers
Protection case 1 -
User's Manual 1 -
3

TECHNICAL DETAILS
Signal nput/Output
Input 5,0 – 6,0 V (±0,25V) / 1000 mA
utput 5,0 V (±0,25 V) / 1 A (max.)
Connectors
Input connector USB Typ B mini
utput connector USB Typ A
Battery
Capacity 4400 mAh (sufficient for up to 2 or 3 mobile phone
charging processes), 3.7 V cell voltage
Battery cells Li-Polymer
Charging time 4 h @ 5 V,1000 mA, 7 h @ 5 V,500 mA
Life cycle 500 charge cycles
Dimensions
(L x W x H) 100 x 62 x 14 mm
Weight 187 g
Environmental Specifications
perating Temperature 0°C~40°C
perating Humidity 10% to 60% RH
Power Requirements
External Power Supply 5 V, 1 A
Power Consumption Max. 5 W
Compatibility
USB Mini type B Mobile phones, MP3 player, digital cameras, navigation
systems, PSP
USB Micro Mobile phones, HTC, LEICKE accessories
Apple charging adapter iPad, iPhone 4, iPad 2, iPhone 4s
Mobile phone charging adapter Different mobile phones from the producers Nokia,
Motorola, Dell, Sony Ericsson, Samsung
4

CONNECTORS
Please study the panel drawings below and become familiar with the signal input(s), output(s)
and power connector.
CONNECTION DIAGRAM
Please use the Mini / Micro USB cable to charge your LEICKE Portable Power Station.
5

CHARGING AND CAPACITY STATE
ATTENT ON: The Portable Power Station cannot be used for charging other devices
during its own charging process.
Step 1: Please check, if the power supply is compatible with the LEICKE Portable Power
Station.
Step 2: Connect the Power Station with help of the Mini USB Cable to your PC or Laptop
or with the USB charging cable to a wall socket. The charging process will start
automatically and the LED indicator light will glow red.
Step 3: When fully charged, the LED indicator light of the LEICKE Portable Power
Station will glow green. Now you may charge other devices with your Power
Station.
Notes:
•The LED indicator light glows green as long as the LEICKE Portable Power
Station's capacity is between 30% and 00%.
•A red light indicates that the capacity is below 30%. In this case, please charge your
LEICKE Portable Power Station.
•In case the LEICKE Portable Power Station does not charge your device or itself
properly, please make sure, that the charging cable is properly connected at the
device and the power supply.
•You may use your Portable Power Station also as pocket light. Just hold the
"On/Off" button for about two seconds. Now the white LED next to the charging port
will glow and you can thus use your portable battery to find your keys etc. To switch
the pocket light off, just press the "On/Off" button again.
6

CHARGING MOBILES/SMARTPHONES AND OTHER DEVICES
ATTENT ON: The Portable Power Station cannot be used for charging other devices
during its own charging process. Please use the LE CKE Portable Power Station to
charge digital devices with a DC 5 V input interface.
Step 1: Choose the right USB plug connector and connect the device you wish to be
charged with the LEICKE Portable Power Station. To start the charging process,
please press the " n/ ff" button shortly. Now the Power Station's LED indicator
light will glow green or red depending on the charging status and the charging
process starts. If the LED glows red, please charge the Portable Power Station
as soon as possible.
Notes:
•Included in deli ery are: a 30 cm USB charging cable, charging adapters with mini
and micro USB connectors and other adapters, which are compatible with common
digital communication de ices. If the charging cables are not compatible with your
mobile phone or other de ices, please use the original charging cables of these
de ices.
7

FAQ
In general, in case of technical troubles check the electrical signal connections and the power
supply (LED glows) first. If this turns out to be not helpful, we arranged the following
questions and answers for you to find the cause and solve the problem.
Problem Description Possible Cause/Possible Solution
Battery does not load
or loads too long
•Does the red charging LED glow? Maybe the charging
power of you power adapter or the USB port is not strong
enough. In this case, please use another compatible power
adapter or another USB port.
•The LED does not glow - Please check, if all interfaces are
properly connected and the DC input was used to charge.
If the Power Station is charged via PC, it may be necessary
to switch the PC on to have power at the USB port.
Battery cannot load
device
•Is the Portable Power Station switched on? (Press " n/ ff"
button)
•Is the Portable Power Station sufficiently charged? If the
LED glows red, the capacity of the battery is below 30 %.
Please charge the battery as soon as possible.
•Please check, if the included adapters are compatible with
your mobile phone or devices. If necessary, check the
charging function with the original accessories of your
device.
Battery loads device
just partly
•Maybe the capacity of the device's battery is higher than the
capacity of the Power Station, especially possible with
Tablets, where batteries of high capacity are built in.
f the problems cannot be solved, please don't hesitate to contact us. Our customer's
support will be glad to help you under [e-mail].
8

SAFETY NOTES
For your own safety and for long enjoyment of our product, please follow the following safety
instructions:
•Please use device as described in the manual.
•Any modifications to the LEICKE Portable Power Station may result in fire, electric
shock, damage or injury.
•Avoid contact with spiky or sharp items.
•Do not open or puncture the LEICKE Portable Power Station.
•Keep away from fire, high temperatures or water.
•Avoid short circuits.
•Keep safe from being hit or falling down.
•If you discover a bulge on your Portable Power Station, please stop using it and
contact us.
•The pocket light LED is very bright and strong. Never turn it into your or somebody
