Note: the maximum input level for a TV set is 75dBμV
OUTPUT
RF OUTUP
CH:36-594.0
>LEV:90dBuV
Press ⏎to enter the OUTPUT menu.
E5÷E12 / E21÷E69
Default E36
OUPUT
>CH:36-594.0
OUTPUT CHANNEL
70÷ 100dBμV (1dB step)
Position the function selector > on CH and press ⏎
to activate the pointer --- and set the ouput channel.
To confirm your selection press ⏎.
OUTPUT LEVEL
On the right of the selected channel is
displayed the center frequency in MHz.
Position the function selector > on LEV and press
⏎to activate the pointer --- and set the RF ouput
level. To confirm your selection press ⏎.
LEV:90dBuV
>LCN: 00101
00001 ÷ 65535
OUTPUT LCN
Position the function selector > on LCN and press
⏎to activate the pointer --- and set LCN number
required.To confirm your selection press ⏎.
OUTPUT
LCN: 00101
>CNTRY:ITA
See Table below
Country preset parameters
AUSTRIA AUT GERMANY DEU NETHERLANDS NLD SLOVENIA SVN
AUSTRALIA AUS GREECE GRC NORWAY NOR SPAIN ESP
CROATIA HRV HUNGARY HUN NEW ZEALAND NZL SWEDEN SWE
CZECH REP CZE ISRAEL ISR POLAND POL SWITZERLAND CHE
DENMARK DNK IRELAND IRL PORTUGAL PRT UNITED KINGDOM GBR
ESTONIA EST ITALY ITA RUSSIA RUS
FINLAND FIN LATVIA LVA SINGAPORE SGP
FRANCE FRA MALAYSIA MYS SLOVAKIA SVK
If in the network there are more than
one DM200HD to avoid TSID conflict
when the LCN number is changed also
the TSID is automatically reassigned.
