Lemco HDMOD 5L User manual

1 x HD (in/out) to DVB-T (COFDM)
HDMOD 5L
"Home" modulator
Operation
Manual
v1.0

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
2
1. IMPORTANT SAFETY PRECAUTIONS INFORMATION
READ THE FOLLOWING WARNINGS BEFORE YOU USE YOUR DEVICE
Παρακαλούμε φυλάξτε αυτό το εγχειρίδιο σε ασφαλές μέρος για μελλοντική αναφορά.
Power supply / Mains cord
zx w Operate the unit only within the voltage range defined as appropriate by the man-
ufacturer.
zx w Occasionally check the power connector and remove dirt or dust that may have
accumulated.
zx w Use only the mains cord that comes with your unit.
zx w Do not operate the unit or plug in the mains cord if it is broken, split, or damaged
in any way.
zx w Do not place the mains cord next to heating devices. Do not pull it, place heavy
objects on it or damage it in any way. Keep it out of reach of children.
zx w Ensure that the device is plugged in a properly grounded socket. Insufficient
grounding may cause electrocution.
zx w Always carefully disconnect all plugs by pulling on the plug and not on the cord.
Make sure the unit's power switch is turned off before removing the cord from an
outlet.
zx w Disconnect the mains cord when the unit is not in use for long periods of time or
during storms.
zx w Do not connect the unit to a multiple-outlet to avoid plug overheating.
Disassembling
zx w This unit contains parts that cannot be repaired by the user. Do not disassemble
or try to repair it as this will void all warranties. Please contact the manufacturer if
you experience any problems with your unit.
Water/humidity
zx w Do not keep the unit in a humid place or near water.
zx w Do not plug/unplug the unit with wet hands.
WARNING
The following safety precautions must be observed to prevent fire
or electric shock hazard. Safety precautions include but are not re-
stricted to the following:

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
3
Fire
zx w Never place a candle or another source of fire on the unit as it may fall and start
a fire.
zx w If the mains cord or the power connector is damaged or destroyed, or if there is a
sudden loss of picture during operation, or if you notice a strange smell or there is
smoke, immediately switch the unit off, disconnect the mains cord and contact the
manufacturer’s technical support department.
Installation / Storage
zx w This unit contains high precision pieces of electronics. To ensure optimal perform-
ance and avoid damage, do not store it in any location where it may collect dirt,
duct, lint, etc. Do not expose it to extreme heat or cold (e.g. in direct sunlight, near
a heater or in the car during the day). Place the unit in a secure place to avoid falls.
zx w Before moving the unit, always unplug all cords first.
zx w When installing the unit, make sure that an outlet is within easy reach. In case of
malfunction, switch the unit off and unplug the power cord. When the unit is not in
use for a long period of time, make sure that the mains cord is disconnected.
Connectivity
zx w Before connecting the unit to other electronic devices, always switch off and unplug
all devices.
Maintenance
zx w Do not spill liquids on the unit. Do not use any diluents or volatile liquid to clean
the unit. Instead, use a soft slightly damp cloth and allow the unit to dry completely
before using again.
Handling
zx w Do not poke your finger into the openings on your unit.
zx w Never put paper, metal parts or other objects into the openings of your unit. If you
suspect that there are foreign parts in your unit, switch it off and unplug the mains
cord. Contact the manufacturer’s technical support department.
zx w Do not step on or place heavy objects on top of the unit. To avoid hardware dam-
age, handle all buttons, connectors and switches gently.

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
4
2. INTRODUCTION
Congratulations on purchasing the HDMOD-5L. You now own a high quality, “Home”
DVB-T HD modulator with Bluetooth interface. To get the most out of your purchase,
please take the time to carefully read through this manual.
3. DESCRIPTION
The HDMOD-5L is a high-quality DVB-T "Home" modulator with HDMI loop-through
circuit. It receives one HDMI as input and converts it into one RF DVB-T channel output
as well as in HDMI out. The excellent picture (Full HD 1920*1080-30p) and modulation
quality (MER~35dB) renders the HDMOD-5L an ideal solution for distributing SD/HD
digital signals received from any device (e.g. a DVD player, STB or camera) in a CATV
network using the DVB-T technology.
The user has the ability to control the device remotely using a Bluetooth interface by
downloading and using the appropriate application from Google play or IOS App
Store for free.
Finally, the HDMOD-5L’s small size and metal case provides excellent electromagnetic
shielding as well as great temperature dissipation and rigidness.
3.1 - FEATURES
zx w High quality and performance
zx w Very clean RF spectrum
zx w HDMI input
zx w HDMI loop-through circuit
zx w MER value ~ 35dB
zx w RF output frequencies 174…230 MHz & 470...862 MHz
zx w H.264 HD encoder bitrate 1-19Mbps
zx w HDCP support
zx w Bluetooth interface
zx w Very small size
zx w External power supply

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
5
3.2 - Typical schedule diagrm
RF OUT
HD OUT
HD IN
IR OUT

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
6
4. INSTRUCTIONS
4.1 - App installation
The HDMOD-5L can be programmed on the field using the following simple steps:
Step 1
Power up the HDMOD-5L, connecting the external power supply. The HDMOD-5L will
need 20-30 seconds to initialize and the status indicator will blink between red and
green until the procedure is finished. After the status indicator remains constantly
green, you will be able to connect to the HDMOD-5L.
Step 2
Download the “Lemco” app from Google play or App Store:
This step is not necessary, if you already have installed the app on your phone / tablet.
Step 3
The app has the following icon:
Upon execution, the app will ask you to turn on Bluetooth. Depending on your phone
/ tablet OS version, you may be prompted also to turn on GPS / Location / Position.
The app does NOT record or use your location. Location services are necessary on
specific Android OS versions for Bluetooth Low Energy (BLE) access.
The HDMOD-5L utilizes BLE (Bluetooth Low Energy) and does NOT need to be “paired”
with your phone / tablet. If you have paired the device with your phone / tablet, please
unpair it.The factory default PIN is 1234.

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
7
4.2 - App usage
The app will scan for any available devices that
are within range (Picture No1). The list shows all
detected devices within range, with the device
closest to your phone / tablet at the top of the
list. If your phone / tablet is moved closer to
another device, that device will move at the top
of the list in a few seconds.
Choose the device that you want to connect to,
by tapping on the appropriate “box”. As soon as
the connection between the phone / tablet and
the HDMOD-5L is established, the status indi-
cator on the HDMOD-5L will become red and
you may proceed to 4.4.1.
You may also “connect” to virtual devices shown
as “OFFLINE MODE” to get acquainted with the
menus and features of the app and the devices.
4.3 - App settings
The app has its own settings and features, inde-
pendent of any device. The app features menu
shows up when tapping on the icon at
the top right corner of the screen while scanning
(Picture No2).
You may select the app language, you may read
the app information, terms & conditions, access
the app help, backup or restore all stored cus-
tom profiles (4.3.1).
To close the app settings menu, swipe the scan-
ning page to the right or tap on the icon
again.
Picture No1
Picture No2

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
8
4.3.1 - Backup & Restore
The app is capable of backing up and/or restor-
ing all the stored custom profiles (4.4.4) for all
the supported device models. This feature is use-
ful in the following cases:
zx w Reinstalling the app
zx w Lost your phone / tablet
zx w Migrating to another phone / tablet
zx w Sharing your custom profiles with another
phone / tablet.
Your phone / tablet has a hardware-embedded
unchangeable unique code. This code is used to
identify the phone / tablet. It cannot be used to
identify the phone / tablet’s owner, phone
number or extract any other personal infor-
mation.
The backup data are stored on Lemco’s servers.
You may backup your data several times. Each
backup has its own timestamp. When restoring
you may select which backup you want to re-
store by its timestamp.
You may also delete all backups. In such case,
all the backup data corresponding to your
phone / tablet’s unique code will be irrevocably
deleted from Lemco’s servers.
4.4 – Device settings
While connected to an HDMOD-5L, the app
constantly observes the Bluetooth signal level
and displays it on the appropriate on-screen in-
dicator. If the level is critically low, the app will
prompt you to move closer to the device.
If the device is powered down or the Bluetooth
connection gets severed, the app will show a
warning and return to scanning for devices.
Picture No3

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
9
4.4.1 - PIN
Before accessing the connected device’s set-
tings, you will need to enter a PIN (Picture No4).
This PIN is specific to the HDMOD-5L you have
connected and is not associated with your
phone / tablet.
The factory default PIN is 1234
You may change this PIN using the “ Security
PIN ” menu option (4.4.12). If you change this PIN,
please keep it somewhere safe, preferably
written on a piece of paper or the “9. Notes” sec-
tion on this leaflet.
4.4.2 - Menu
When the app is connected to a device and the
correct PIN is entered, the device’s main menu
will be displayed (Picture No5).
The main menu consists of the following options:
zx w Quick Settings (4.4.3)
zx w Custom profiles (4.4.4)
zx w Device name (4.4.5)
zx w DVB-T (4.4.6)
zx w Output attenuator (4.4.7)
zx w Encoder (4.4.8)
zx w Transport Stream (4.4.9)
zx w Other settings
w Factory defaults (4.4.10)
w Security PIN (4.4.11)
w Update firmware (4.4.12)
zx w System info (4.4.13)
zx w Help (4.4.14)
By tapping on the “Back” icon labeled “ Scan ”,
the app disconnects from the HDMOD-5L and
returns to scanning for all devices.
Picture No4
Picture No5

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
10
4.4.3 - Quick Settings
With this feature you are able to setup several
HDMOD-5L modulators easily and quickly, one
at a time. All you need is to enter the following
parameters, for each of your modulators:
zx w The output RF channel
zx w Set the output level by adjusting the mod-
ulator’s attenuator
zx w Set the Profile No.
The app applies a suitable predefined profile to
the connected device.
The settings are applied to the connected
HDMOD-5L by tapping on the “ Apply ” button.
This feature may be used with different mod-
ulator models.
Picture No6
How the quick settings profile works
In an installation all the modulators (or Mux in general) need to have different values
of the following settings to avoid conflict in the automated scan of the TV sets:
Program Nam Service ID TS ID
For that reason, the user must always select a unique Profile number in every mod-
ulator starting from Number #1.
E.g. If we want to install three modulators in a CATV network, in the profile option we
will select:
zx w Profile Νο 1for the 1st modulator
m meaning: Program Name = DTV 1
m meaning: Service ID = 1
m meaning: TS ID = 2240
zx w Profile Νο 2for the 2nd modulator
m meaning: Program Name = DTV 2
m meaning: Service ID = 2
m meaning: TS ID = 2241
zx w Profile Νο 3for the 3rd modulator
m meaning: Program Name = DTV 3
m meaning: Service ID = 3
m meaning: TS ID = 2242
As a result, all the above modulators have different values in the above settings.

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
11
4.4.4 - Custom Profiles
The app provides the ability to create custom
profiles under your custom name (Picture No7,
Picture No8).
By tapping on the “+” button you are able to
save the current configuration in your phone /
tablet for future use. You can create as many
customs profiles as you need.
By selecting a custom profile, you may view its
properties, apply it to the connected device,
clone it, rename it or delete it. By tapping on the
“ Apply ” button, all the selected profile’s settings
are applied to the connected HDMOD-5L.
Note: The app supports multiple device models.
Each model has its own custom profile list. You
may not apply a custom profile of a device to a
different device model.
Picture No7
Picture No8

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
12
4.4.5 – Device name
You may assign any name you want on the
HDMOD-5L (Picture No9). The names you may
have assigned to your devices are shown while
scanning. Τhe name of the connected device is
shown on all the app’s pages. In this way, you
may have multiple devices, even of different
models but still be able to select the right one
for changing its settings.
The new name is applied to the HDMOD-5L by
tapping on the “ Apply ” button.
4.4.6 – DVB-T
With the “DVB-T” option (Picture No10), you may
setup all the necessary DVB-T parameters ac-
cording to the standards, as follows:
Channel: Select the desired output RF
channel
Frequency: Select the output RF channel
frequency
Bandwidth: Select the channel bandwidth
Constellation: Select the channel constellation
Modulation: Select the channel modulation
mode
Guard interval: Select the guard interval
Code Rate: Select the desired code rate
The settings are applied to the HDMOD-5L by
tapping on the “ Apply ” button.
Picture No9
Picture No10

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
13
4.4.7 – Output attenuator
In the “Output attenuator” option (Picture No11),
you may select the attenuation applied on the
output level, between 0dB, -10dB and -20dB.
Set to 0dB: Set the output level to
90dBμV
Set to -10dB: Set the output level to
80dBμV
Set to -20dB: Set the output level to
70dBμV
The setting is applied to the HDMOD-5L by tap-
ping on the “ Apply ” button.
4.4.8 - Encoder
You may set manually all the encoder parame-
ters (Picture No12).
Video Bitrate: Select the video bitrate of the
encoder
Resolution: Select the output resolution of
the modulator
Audio Bitrate: Select the audio bitrate of the
encoder
Audio encoding: Select the audio encoding of
the encoder
HDCP: Enable or disable the HDCP
function
The settings are applied to the HDMOD-5L by
tapping on the “ Apply ” button.
Picture No11
Picture No12

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
14
4.4.9 - Transport Stream
You may set manually all the TS (Transport
Stream) parameters (Picture No13).
Network name: Set the network name
Network ID: Set the network ID
Original Network ID: Set the original network ID
Service name: Set the service name
Service ID: Set the service ID
Service provider: Set the service provider
TS ID: Set the TS ID
PMT ID: Set the PMT PID number
Video PID: Set the video PID number
LCN Enabled: Enable or disable the LCN
function
LCN No: Set the LCN number
LCN Provider: Select the LCN provider
The settings are applied to the HDMOD-5L by
tapping on the “ Apply ” button.
Picture No13

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
15
4.4.10 – Other settings / Factory de-
faults
You may revert the HDMOD-5L to factory de-
faults by tapping on the “ Apply factory defaults ”
button (Picture No14).
Note: All settings of the device will be reset, in-
cluding the PIN (4.4.1) and any custom profile
(4.4.4) you may have applied.
4.4.11 – Other settings / Security PIN
You may change the device PIN which is asked
upon connecting (Picture No15).
First you have to enter the existing PIN and then
you’ll be able to enter the new PIN.
Note which checkbox is highlighted on the left
side, to know which PIN is currently being en-
tered.
The new PIN is applied to the HDMOD-5L by
tapping on the “ Apply ” button.
Picture No14
Picture No15

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
16
Picture No16 Picture No17 Picture No18
4.4.12 – Other settings / Update firmware
The app is capable of updating the device’s firmware. The procedure is automatic and
if a newer firmware version is available, you only need to tap on the “Update firmware”
button for the procedure to start. (Picture No16, 17, 18)
Note: You need an internet connection on your phone / tablet to perform a firmware update.
Caution: Please follow the on-screen instructions when updating firmware.

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
17
4.4.13 - System Info
On this page you may see information details of
the connected HDMOD-5L (Picture No19).
4.4.14 - Help
The last menu entry is the “Help” for the device
(Picture No20). The contents are divided in
chapters that expand by tapping on each chap-
ter title.
Note: When in trouble with a device, please refer
to the “Troubleshooting” and “F.A.Q.” chapters
first.
Picture No19
Picture No20

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
18
5. TECHNICAL SPECIFICATIONS
Input
Type: 1 x HDMI in & 1 x HDMI out
HDMI loop-through: Yes
Connector: 1 x HDMI Type A
Video coding: MPEG-4 AVC/H.264
Profile: High profile 4.0
Resolution: 1920x1080-30p for HDMI
HDCP support: Yes
Audio: HDMI
Audio encoding: MPEG2, ACC, AC3
Standard: MPEG-1 Layer II
Audio Bit Rate: 64, 96, 128, 192, 256, 320, 384 kbps
Level: 0.5Vpp to 1.0Vpp adjustable
H.264 Encoder
Standard: MPEG-4 AVC/H.264
Bit Rate: 1 – 19 Mb/s adjustable
Configurable parameters: Service Name, Service ID, Video PID, Audio
PID, PMT PID
Transport Stream Processing
Automatic regeneration: NIT, PAT, CAT, SDT, PMTs, EITs tables
Configurable parameters: TS ID, Original Network ID, Network ID,
Provider Name
LCN support: Yes
LCN Providers: Nordig, ITC/UK, EICTA/Europe, New Zealand
DVB-T Output
Standard: EN 300 744
Bandwidth: 5, 6, 7, 8 MHz
Mode: 2K, 8K
Constellation: QPSK, 16QAM, 64QAM
Guard interval: 1/4, 1/8, 1/16, 1/32
Code rate: 1/2, 2/3, 3/4, 5/6, 7/8
RF Output
Type: RF DVB-T (COFDM)
Output frequencies: 174…230 MHz & 470...862 MHz
Output level: 85dbμV max.
Connector: 75Ω - F, female
Output attenuator: 0, -10, -20dBm
MER: 35dB (Typical)
Shoulder attenuation: >45dBc
Connectors: 1 x F – female

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
19
Programming interface
via Bluetooth
Requires version 4.0 and above
ETSI EN 300 328 and EN 300 440 Class 2 (Europe),
FCC CFR47 Part 15 (US) and ARIB STD-T66 (Japan)
App information:
Android version 5.1 and above
iOS version: 11 or above
General
Power supply: +12VDC
Power supply consumption: 290 mA max.
Operating temperature: 0 °C to 50 °C
Storage temperature: -10 °C to +70 °C
Humidity: Up to 90%
Dimensions: 160.0 x 89.3 x 28.4 mm
Weight: 0.25 Kg

HDMOD 5L | 1 x HD (in/out) to DVB-T (COFDM) |
OPERATION MANUAL v1.0
20
6. DIMENSIONS
100,03
26,40
88,30 55,00
198,00
198,00
184,00
4 x
O
5,00
7,00
169,80
*dimensions in mm
