Lemco HDMOD 5F User manual

HDMOD 5F
"Home" modulator
1 x HD (in/out) + A/V in to DVB-T (COFDM) + IR TX
Quick Start Quide
(/ ) / ( )
1. INTRO
Congratulations on purchasing the HDMOD-5F. You now own a high quality, “Home” DVB-T HD modulator with
Bluetooth interface. To get the most out of your purchase, please take the time to carefully read through this
manual.
2. INSTRUCTIONS
2.1 - Description
The HDMOD-5F is a high-quality DVB-T "Home" modulator with HDMI loop-through circuit. It receives one HDMI
or one CVBS signal as input and converts it into one RF DVB-T channel output as well as in HDMI out. The ex-
cellent picture (Full HD 1920*1080-30p) and modulation quality (MER~35dB) renders the HDMOD-5F an ideal
solution for distributing SD/HD digital signals received from any device (e.g. a DVD player, STB or camera) in a
CATV network using the DVB-T technology.
The user has the ability to control the device remotely using a Bluetooth interface by downloading and using
the appropriate application from Google play or IOS App Store for free.
Finally, the HDMOD-5F’s small size and metal case provides excellent electromagnetic shielding as well as great
temperature dissipation and rigidness.
2.2 - Features
zx w High quality and performance
zx w Very clean RF spectrum
zx w CVBS & HDMI input
zx w RF & HDMI loop-through circuit
zx w MER value ~ 35dB
zx w RF output frequencies 174…230 MHz & 470...862 MHz
zx w H.264 HD encoder bitrate 1-19Mbps
zx w HDCP support
zx w IR support
zx w Bluetooth interface
zx w Very small size
zx w External power supply

HDMOD 5F
Quick start guide | 1 x HD (in/out) + A/V in to DVB-T (COFDM) + IR TX |
3. App INSTALLATION
The HDMOD-5F can be programmed on the field using the following simple steps:
Step 1
Power up the HDMOD-5F, connecting the external power supply. The HDMOD-5F will need 20-30 seconds to
initialize and the status indicator will blink between red and green until the procedure is finished. After the status
indicator remains constantly green, you will be able to connect to the HDMOD-5F.
Step 2
Download the “Lemco” app from Google play or App Store:
This step is not necessary, if you already have installed the app on your phone / tablet.
Step 3
The app has the following icon:
Upon execution, the app will ask you to turn on Bluetooth. Depending on your phone / tablet OS version, you
may be prompted also to turn on GPS / Location / Position. The app does NOT record or use your location. Lo-
cation services are necessary on specific Android OS versions for Bluetooth Low Energy (BLE) access.
The HDMOD-5F utilizes BLE (Bluetooth Low Energy) and does NOT need to be “paired” with your phone / tablet.
If you have paired the device with your phone / tablet, please unpair it.
More information
zx w You can download full manual at www.lemco.tv
