Lennox Hearth Products CI1500DVF Series User manual

FREESTANDING VENTED
GAS FIRED
ROOM HEATERS
HOMEOWNER'S CARE AND
OPERATION INSTRUCTIONS
Report No. 116-S-08-5
Model
CI1500DVF
Series
Model
CI2500DVF
Series
Serefina Series Direct Vent Gas Stoves
P/N 775,148M Rev. C, 11/2006
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser
d’essencenid’autrevapeursouliquidesinflammablesdans
le voisinage de cet appareil ou de tout autre appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d’allumer d’appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où vous
vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L’installation et service doit être exécuté par un qualifié
installeur, agence de service ou le fournisseur de gaz.
WARNINGS
• Hot! Do not touch! The glass and surfaces of this appliance
will be hot during operation and will retain heat for a while
after shutting off the appliance. Severe burns may result.
• Carefully supervise children in the same room as appliance.
• If small children are present in the home, it is recommended
that this appliance be fitted with a screen door or screen panel
kit. See Page 10 for ordering information.
WARNING:IF THEINFORMATIONINTHIS MANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SIONMAYRESULTCAUSINGPROPERTYDAMAGE,
PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow your gas supplier's
instructions.
• If your gas supplier cannot be reached, call
the fire department.
Installationandservicemustbeperformedbyaquali-
fied installer, service agency or the gas supplier.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE
POUR RÉDUIRE AU MINIMUM LE RISQUE D’INCENDIE
OU POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
RETAIN THIS MANUAL FOR
FUTURE REFERENCE
A French manual is available upon
request. Order P/N 775,148CF
Ce manuel d’installation est disponible en
francais, simplement en faire la demande.
Numéro de la pièce 775,148CF.

2NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
WARNING
If the information in this
manual is not followed
exactly, a fire or explo-
sion may result caus-
ing property damage,
personal injury or loss
of life.
SAFETY & WARNIING
INFORMATION
IMPORTANT: PLEASE READ THIS
MANUAL IN ITS ENTIRETY AND
UNDERSTAND THESE RULES TO
FOLLOW FOR SAFETY.
WARNING
Improper installation, adjust-
ment, alteration, service or
maintenance can cause injury
or property damage. Refer to
this manual. For assistance or
additional information consult
a qualified installer, service
agency or the gas supplier.
WARNING
Failuretocomplywiththeinstal-
lationandoperatinginstructions
provided in this document will
result in an improperly installed
andoperatingappliance,voiding
its warranty. Any change to this
appliance and/or its operating
controlsisdangerous. Improper
installation or use of this appli-
ance can cause serious injury or
deathfromfire,burns,explosion
or carbon monoxide poisoning.
IMPORTANT
These appliances must not be
connected to a chimney or flue
serving a separate Solid-Fuel
burning appliance.
WARNING
Children and adults should be
alerted to the hazards of high
surface temperatures. Use
caution around the appliance
to avoid burns or clothing igni-
tion. Young children should be
carefully supervised when they
are in the same room as the
appliance.
Note: An Optional Screen Panel
for the glass is available (see
Page 10 for ordering informa-
tion).
WARNING
Do not place clothing or other
flammable materials on or near
this appliance.
AVERTISSEMENT
Surveiller les enfants. Garder les
vêtements,lesmeubles,l'essence
ouautresliquidesà vapeurinflam-
mables à cote de l'appareil.
WARNING
Carbon monoxide poisoning:
early signs of carbon monoxide
poisoning are similar to the flu
withheadaches,dizzinessand/or
nausea. If you have these signs,
obtain fresh air immediately.
Turn off the gas supply to the
appliance and have it serviced
by a qualified professional, as it
may not be operating correctly.
WARNING
Any safety guard or screen
removedforservicingtheappli-
ance must be replaced prior to
operating the appliance.
WARNING
Do not use these appliances if
any part has been under water.
Immediately call a qualified,
professional service technician
to inspect the appliances and to
replace any parts of the control
system and any gas controls
which have been under water.
AVERTISSEMENT
Ne pas se servir de cet appareil
s'il a été plongé dans l'eau,
complètement ou en partie.
Appeler un technicien qualifié
pourinspecterl'appareiletrem-
placertoutepartiedusystèmede
contrôle et toute commande qui
ont été plongés dans l'eau.
WARNING
Do not attempt to alter or modify
theconstructionoftheappliance
or its components. Any modi-
fication or alteration may void
the warranty, certification and
listings of this unit.
WARNING
This appliance is only for use with
the type of gas indicated on rating
plate. This appliance is not con-
vertible for use with other gases,
unless a certified kit is used.
AVERTISSEMENT
Cet appareil doit être utilisé
uniquement avec les types de
gaz indiqués sur la plaque sig-
nalétique. Nepas l'utiliser avec
d'autres gaz sauf si un kit de
conversion certifié est installé.
WARNING
Thesestovesareventedheaters.
Do not burn wood or other mate-
rial in these appliances.

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE. 3
Due to high temperatures the appliance should
belocated out of traffic and away fromfurniture
and draperies. Locate furniture and window
coverings accordingly. The recommended
clearance zone from the front of the appli-
ance to combustibles is 36 inches (914 mm).
Maintain all other clearances as outlined in the
installation manual.
These appliances are designed as supplemen-
tal heaters. Therefore, it is advisable to have
an alternate heat source when installed in a
dwelling.
These appliances are designed to operate on
natural or propane gas only.
Inputofmillivoltmodelsisvariable.Theserates
are shown in the following table:
These millivolt appliances are designed to
operate on either natural or propane gas. A
millivolt gas control valve with piezo ignition
system provides safe, efficient operation.
External electrical power is required to operate
the optional electrically powered components
if installed.
These appliances comply with National
Safety Standards and are tested and listed
by OMNI-Test Laboratories Inc.; Beaverton,
Oregon (Report No. 116-S-08-05) to ANSI
Z21.88-2002 (in Canada, CSA-2.33-2002),
and CAN/CGA-2.17-M91 in both USA and
Canada, as vented gas heaters.
Installation must conform to local codes. In
the absence of local codes, installation must
complywiththecurrentNationalFuelGasCode,
ANSIZ223.1 (NFPA54).(InCanada,the current
CAN/CGA B149 installation code.) Electrical
wiring must comply with local codes. In the
absence of local codes, installation must be in
accordance with the National Electrical Code,
NFPA70-(latestedition).(InCanada,thecurrent
CSA C22.1 Canadian Electric Code.).
GENERAL INFORMATION
Note:Installationand repairshouldbe performed
by a qualified service person. The appliance
should be inspected annually by a qualified
professional service technician. More frequent
inspectionsandcleanings maybe required dueto
excessive lint from carpeting, bedding material,
etc.It is imperativethat thecontrol compartment,
burners and circulating air passage ways of the
appliance be kept clean.
S'assurer que le brùleur et le compartiment des
commandes sont propres. Voir les instructions
d'installation et d'utilisation qui accompagnent
l'appareil.
Provideadequateclearancesaroundairopenings
and adequate accessibility clearance for service
and proper operation.
Never obstruct the front openings of the
appliance.
TABLE OF CONTENTS
Safety and Warning Information .......Page 2
Introduction ......................................Page 3
General Information..........................Page 3
Variable Flame Adjustment................Page 4
Burn-In Period ..................................Page 4
Maintenance......................................Page 4
Operation/Care of Your Appliance .....Page 5
Gas Controls & Compartment Access.Page 5
Front Glass Enclosure Panel,
Removal and Installation.................Page 5
Burner Adjustments..........................Page 6
Flame Appearance and Sooting.........Page 6
Adjustment Rod................................Page 6
Log and Ember Placement................Page 7
Millivolt Appliance Checkout.............Page 8
Small Area Paint Touch-up................Page 8
Wiring Diagrams...............................Page 9
Warranty Information........................Page 9
Accessory Components ....................Page 10
Lighting Instructions – Millivolt ........Page 12
Maintenance Schedule......................Page 14
Troubleshooting Guide – Millivolt .....Page 15
Replacement Parts List.....................Page 16
Optional Warming Shelves ...............Page 20
INTRODUCTION
The stove models covered in this manual are
Direct-Vent sealed combustion vented gas
stove heaters designed for residential applica-
tion. Direct-Vent appliances operate with the
combustion chamber isolated from the inside
atmosphere. Allairforcombustionisbrought in
from the outside and exhaust gases are vented
through the same direct vent, vent system.
Table 2 shows the units' gas orifice size for
the elevations indicated.
CONGRATULATIONS ON THE PURCHASE OF YOUR NEW GAS APPLIANCE MANU-
FACTURED BY LENNOX HEARTH PRODUCTS.
When you purchased your new gas fired heater, you joined the ranks of thousands of con-
cerned individuals whose answer to their home heating needs reflects their concern for
aesthetics, efficiency and our environment. We extend our continued support to help you
achieve the maximum benefit and enjoyment available from your new gas fired heater. It
is our goal at Lennox Hearth Products to provide you, our valued customer, with an appli-
ance that will ensure you years of trouble free warmth and pleasure.
Thank you for selecting a Lennox Hearth Products gas fired heater as the answer to your
home heating needs.
Sincerely,
All of us at Lennox Hearth Products
Input (BTU/HR) Manually-Modulated Gas
Valves (millivolt models)
Models Nat. Gas Propane
CI1500DVF 17,500 to
28,000
20,500 to
27,000
CI2500DVF 25,500 to
38,500
26,500 to
34,500
Table 1
Lighting Millivolt Appliances
To light millivolt appliances refer to the detailed
lighting instructions found on Page 12 (Eng-
lish) and Page 13 (French). Millivolt appliance
lighting instructions may also be found on the
pull-out lighting instruction labels attached to
therear stove shield. Refer to Figure 3 on Page
5for the location of the piezo igniter.
MillivoltappliancesarefittedwithaburnerON/OFF
RockerSwitch,locatedattheright therearstove
shield as shown in Figure 1. Oncethepilot is lit,
theON/OFFrockerswitchwillcontroltheappliance
ON/OFFoperation.Tooperate: Toggle the switch
between its ON and OFF positions.
Burner Orifice Sizes
Elevation 0-4500 feet ( 0-1372 meters)
Model
Series
Natural
Gas
drill size (inches)
Propane
Gas
drill size (inches)
CI1500DVF #37 (.104") *
24M10 •
1.5 mm (.061") *
42M79 •
CI2500DVF # (.121") *
H1073 •
#51 (.068")*
H1074 •
* Standard size installed at factory
• Part /Cat. Number
Table 2

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
4
Tables 3 and 4 show the units' gas pressure
requirements
Inlet Gas Supply Pressure
(all models)
Fuel # Minimum Maximum
Natural Gas 4.5" WC
(1.12 kPa)
10.5" WC
(2.61 kPa)
Propane 11.0" WC
(2.73 kPa)
13.0" WC
(3.23 kPa)
Table 3
Manifold Gas Supply Pressure
(millivolt models)
Fuel # Low High
Natural
Gas
(Lo) 1.6" WC
(.40 kPa)
(Hi) 3.5" WC
(.87 kPa)
Propane (Lo) 6.3" WC
(1.57 kPa)
(Hi) 10.0" WC
(2.49 kPa)
Table 4
Always turn off gas to the pilot (millivolt appli-
ances) before cleaning. Before re-lighting,
refer to the lighting instructions in this manual.
Instructions are also found on a pull-out panel
located on the rear stove shield.
Keep lower control compartment clean by
vacuuming or brushing at least twice a year.
More frequent cleaning may be required due to
excessivelintfromcarpeting,beddingmaterials,
etc. It is important that control compartments,
burners and circulating air passageways of the
appliance be kept clean.
Glass Cleaning
Note: Clean glass after first two weeks of opera-
tion (after Burn-In period is over).
The viewing glass should be cleaned periodi-
cally to remove any build-up caused from the
following:
• During start-up, it is normal for condensa-
tion to form on the inside of the glass (this
condensation and fog will usually disappear
in a few minutes). This can cause lint, dust
and other airborne particles to cling to the
glass surface.
• Initial curing of the high temperature paint
and burning off of lubricants used in the
manufacturing process may result in a film
on the glass.
• A white coating may form on the glass as a
result of impurities and minerals in the fuel.
It is recommended that the glass be cleaned
two or three times during each heating season,
depending on the circumstances present.
Exterior glass may be cleaned with an non-
ammonia based household cleaner and warm
water as desired (a gas stove glass cleaner is
recommended).
Models with Porcelain Enamel Finish
CrazingofPorcelainEnamel: Porcelainenamel,
when heated to high temperatures, is subject
to crazing (a very fine and random network of
hairlinecracks onthe surface of the porcelain).
Crazing is a normal occurrence when enamel
is exposed to high temperatures. Your enamel
finish will not be harmed nor will the function
of the stove be impaired.
Repairing Chips: If the enamel finish on your
stove becomes chipped, it can be touched up
using enamel touch-up paint. For ordering
information, see Page 16.
CleaningEnamelSurfaces:Toremovebuild-up
of dust, dirt or crud from the enamel surfaces,
combinebakingsodaandalittlewatertomakea
cleaningpaste.Useasoftragtorubthesurface
with the mix until the stains are removed.
IMPORTANT
Turn off gas and any electri-
cal power before servicing the
appliance.
Verify proper operation after
servicing.
WARNING
Do not use abrasive cleaners.
Never clean the glass when it
is hot.
WARNING
Do not attempt to touch the front
enclosure glass with your hands
while the stove is in use.
IMPORTANT
Ensure stove is completely cold
priortocleaningorusingenamel
touch up paint.
VARIABLE FLAME HEIGHT
ADJUSTMENT
All Millivolt appliances are equipped with a
variable gas control valve. Flame height for
these models may be adjusted through a range
between fixed low and high settings by rotating
the HI/LO knob on the valve (see Figure 3),
alternately, while the appliance is in opera-
tion. Adjust the flame height as desired after
lighting the appliance by rotating the variable
adjustmentcontrol (HI/LO)knob located on the
front of the valve.
BURN-IN PERIOD:
Duringthe firstfewburnsofthis appliancethere
will be some odor due to the “burn-in” of paints
and lubricants (curing of the high temperature
paint and burning off of lubricants used in the
manufacturing process).
Depending on your use, the burn-in period may
take a few hours or a few days. The dwelling
should be well ventilated during these initial
burns.
If the optional Blower Kit (see Page 10 for
ordering information) is installed, do not turn
on a blower during the Burn-In period. Do not
place anything on the stove surface until the
paint is completely cured.
(Serefina Models with Black Paint) Do not
attempt to repaint the stove until the paint is
completely cured. If the surface later becomes
stained or marred, it may be lightly sanded and
touched up with spray paint (See Small Area
Paint Touch-Up, Page 8). Paint is available at
your local authorized Lennox Hearth Products
dealer. Never attempt to paint a hot stove.
MAINTENANCE
The appliance and venting system should be
thoroughly inspected before initial use and at
least annually by a qualified service technician.
However, more frequent periodic inspections
and cleanings should be performed by the
homeowner. Homeowner must contact a quali-
fied service technician at once if any abnormal
condition is observed.
Refer to the maintenance schedule on Page 14
for maintenance tasks, procedures, periodic-
ity and by whom they should be performed.
Always verify proper operation of the appliance
after servicing.
IMPORTANT
Keep your house well ventilated
during the curing process. The
odor and haze emitted by the
curing process can be quite
noticeable and may set off a
smoke detector.

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE. 5
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
O
F
F
HI / LO Knob
Variable Flame Height Adjustment
Manifold Pressure Port
Inlet
Pressure
Port
Main Gas
Control Knob
Piezo Igniter
IN OUT
Test gage connections are provided on the front
ofthe millivolt gascontrol valve(identified IN for
the inlet and OUT for the manifold side).
These appliances must be isolated from the
gas supply piping system (by closing their
individual manual shut-off valve) during any
pressure testing of the gas supply piping
system at test pressures equal to or less
than 1/2 psig (3.5 kPa).
Theseappliancesandtheirindividualshut-off
valves must be disconnected from the gas
supply piping system during any pressure
testing of that system at pressures in excess
of 1/2 psig (3.5 kPa).
OPERATION AND CARE OF YOUR
APPLIANCE
Appliance operation may be controlled through
a remotely located optional wall thermostat or
remote control.
In lieu of remote or remote wall thermostat
operation, the appliance must be operated
directly through the on/off rocker switch located
on the upper right side of the rear shield. See
Figure 1.
If your millivolt appliance is equipped with an
optional wall thermostat kit or remote control
kit and the pilot is lit, the appliance main burner
maybeturnedonandoffwiththewallthermostat
or remote control.
Always keep the appliance area clear and free
from combustible materials, gasoline and other
flammable liquids.
Remember, Millivolt appliances have a continu-
ous burning pilot flame. Exercise caution when
using products with combustible vapors.
Control Compartment Access
The gas controls can be found behind the lower
access door. To access, pull the door open
(see Figure 2).
Millivolt appliances will be fitted with the gas
control valve shown in Figure 3. Familiarize
yourself with the gas control valve that your
appliance uses.
Figure 3
SIT Millivolt Gas Valve Controls
Burner
On /Off
Switch
Top View
Front
Figure 1
Burner On/Off Switch
GAS CONTROLS
Lower Access Door
Pull open lower door to access Valve Contols
Lower Access
Door
Figure 2
FRONT GLASS ENCLOSURE PANEL,
REMOVAL AND INSTALLATION.
These are direct-vent appliances. They are
designed to operate only with the front glass
enclosurepanelproperlyinstalled.Generally,the
glass enclosure panel should not be removed
except to gain access to the components within
thefirebox,andtheappliancemayonlybeoper-
ated without the front glass enclosure panel in
place for very brief periods of time during initial
appliance checkout and adjustment.
During this appliance checkout and adjust-
ment period, a potential safety hazard exists
- EXERCISE EXTREME CAUTION to prevent
the occurrence of any burn injuries from the
exposed flames or hot surfaces. Also note,
that while the front glass enclosure panel is
removed, the flame will appear to be smaller
than normal.
WARNING
Never operate the appliance
without the glass enclosure
panel in place and secure. Do
not operate appliance with the
FRONT glass panel cracked,
brokenormissing.Replacement
panels are available through
your local Lennox Hearth Prod-
uctsdealerandmustbeinstalled
byalicensedorqualifiedservice
technician.
1. Remove the trivet, then the cast iron stove
top by carefully lifting them up and off
and setting them aside (READ CAUTION
BELOW).
CAUTION
The cast iron stove top is very
heavy and may require a mini-
mum of two people to lift; one
person on each side (the CI1500
series cast top weighs ~20
pounds and the CI2500 series
cast top weighs ~40 pounds).
WARNING
Do not attempt to substitute the
materials used on this door, or
replace cracked or broken glass
with any materials other than
those provided by the appliance
manufacturer. The glass door
of this appliance must only be
replaced as a complete unit as
provided by the manufacturer.
Donotattempttoreplacebroken,
cracked or chipped glass sepa-
rately.
2. Locate and open the 2 latches as shown in
Figure 4 (locate below the stove body).

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
6
BURNER ADJUSTMENTS
The following paragraphs address burner
adjustment concerns and procedures.
Flame Appearance and Sooting:
Generally most people prefer the warm glow of
a yellow to orange flame. Appliances operated
with air shutter openings that are too large will
exhibit flames that are blue and transparent.
These weak, blue and transparent flames are
termed anemic. If the air shutter opening is too
small sooting may develop.
Open both Latches as shown.
Figure 4
3. Reach under the bottom front of the front
glass enclosure and pull it forward as
shown in Figure 5.
Figure 5
4.Liftglassassemblyupandoutandcarefully
set aside in a safe place (see Figure 6).
Figure 6
Sooting is indicated by black puffs developing
at the tips of very long orange flames. Sooting
may result in black deposits forming on the
logs, appliance inside surfaces and on exterior
surfaces adjacent to the vent termination.
Sootingiscaused by incompletecombustionin
the flames and a lack of combustion air enter-
ing the air shutter opening. To achieve a warm
yellow to orange flame with an orange body
that does not soot, the shutter opening must
be adjusted between these two extremes. No
smokeorsootshouldbepresent. Repositionthe
logstoensuretheyareintheproperpinlocations
if the flames impinge on any of them.
If the logs are properly positioned and soot-
ing conditions exist, the air shutter opening
on the main burner tube should be adjusted.
Normally, the more offsets in the vent system,
the greater the need for the air shutter to be
opened further.
Burner Flame Appearance
Figure 7
WARNING
Air shutter adjustment should
only be performed by a qualified
professional service techni-
cian.
Initially, always position the air shutter to
the factory setting as shown in Table 5
and Figure 8 (adjustment rod is located in
the lower control area). This can be done
by moving the adjustment rod up or down
accordingly. Allow the burner to operate
for at least 15 minutes. Observe the flame
continuously. If it appears weak or sooty as
previouslydescribed,adjusttheairshutterto
a more open position until the desired flame
appearance is achieved.
The adjustment rod and associated adjustable
airshutterispatentedtechnology.Flameadjust-
ments can be made quickly and accurately to
taste without the need of disassembling the
appliance and waiting for 30 minutes after
each adjustment.
Propane models may exhibit a flame pattern
that may candle or appear stringy. If this is
problematic or persists as the appliance is
continually operated, adjust the air shutter
open as described in the previous paragraphs.
Operatethe appliance for a period of time as the
effect diminishes, ensuring that the appliance
does not develop sooty flames.
Adjustment Rod Up
(1/8" Open Position)
Air Shutter
Burner Tube
Adjusting Set Screw
Adjustment Rod Down
(full open position)
Burner Air Shutter Adjustment
Figure 8
Ref. Air shutter Patent:
U.S. Pat. 5,553,603
WARNING
Ensure that the front glass panel
is in place and sealed during
adjustment.
ADJUSTMENT
WARNING
The adjustment rod and nearby
appliancesurfacesarehot. Exer-
cisecautiontoavoidinjurywhile
adjusting flame appearance.
Refer to Table 5
To install the front glass enclosure panel,
proceed as follows:
1. Retrieve the glass door frame. Visually
inspect the gasket on the backside of the
panel. The gasket surface must be clean,
free of irregularities and seated firmly.
2. With the stove top off, position the glass
front enclosure panel into the front open-
ing with the gasket facing the relief door
(see Figure 6). Let the bottom of the door
frame gently slide down, then hook the top
flange of the glass frame over the top of the
firebox frame.
3. Fasten the two latches located beneath the
fireboxbottomtotheglassframevee-flange.
Close both the latches securely.
4. Reinstall the cast iron stove top (read "Cau-
tion," on Page 5).
5. Reinstall Trivet.

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE. 7
Air Shutter Adjustment Guidelines:
Ifthe burnerflame appearance differsgreatly
from what is shown on Page 6 (see Burner
Flame Appearance), some adjustment from
the factory setting for the air shutter gap may
be necessary (to compensate for variables in
the installation and fuel such as, BTU value /
composition, gas pressure, specific gravity
of gas, altitude, etc.).
Table 6 is provided to aid you in achieving
the correct air shutter adjustment for your
installation.
When satisfied that the appliance operates
properly, proceed to finish the installation.
Leave the control knob in the ON position
and the ON/OFF switch in the OFF position.
Close the lower access door.
LOG AND EMBER PLACEMENT
Carefully install this seven-piece log set into
the firebox as shown in these instructions.
All logs should fit onto corresponding pins
and/orlogstoppers.Thiswillensureaproper
flame and safe combustion.
Main Burner Factory Air Shutter
Opening Setting - Inches (millimeter)
Model Natural
Gas
Propane
Gas
CI1500DVF 5/16"
(7.93 mm)
5/8"
(15.9 mm)
CI2500DVF 1/2"
(12.7 mm)
5/8"
(15.9 mm)
Table 5
Air Shutter Adjustment Guidelines:
Amount of
Primary Air
Flame
Color
Air Shutter
Adjustment
If air shutter is
closed too far Flame will be yellow Air shutter gap should be
increased
If air shutter is
open too far Flame will be blue Air shutter gap should be
decreased
Table 6
Refer to Figure 8
Figure 9
Ember
Strip
Rear Log Stoppers
1. Place the ember strip in front of the burner
asshowninFigure 9.Itshouldbepositioned
all the way back (toward the sub-floor front
flange).
WARNING
Logsgetveryhotandwillremain
hot up to one hour after gas
supply is turned off. Handle
only when logs are cool. Turn
offallelectricitytotheappliance
before you install logs.
WARNING
This appliance is not meant to
burn wood. Any attempt to do so
couldcauseirreparabledamage
to your appliance and prove
hazardous to your safety.
WARNING
The size and position on the
log set was engineered to give
your appliance a safe, reliable
and attractive flame pattern.
Any attempt to use a different
log set in the stove will void
the Warranty and will result in
incomplete combustion, soot-
ing, and poor flame quality.
WARNING
If logs are not installed accord-
ing to the directions shown
here, flame impingement and
improper combustion could
occur and result in soot and/or
excessive production of carbon
monoxide (CO), a colorless,
odorless, toxic gas.
Rear
Log
Figure 10
2. Place the largest log onto the rear log
stoppers (see Figure 9). Ensure that the
grooves on the bottom of the log aligns
onto the corresponding places on the rear
log stoppers. Push the log back so that it
isagainst the backof therear log stoppers
(see Figure 10).
Left Front Log
Figure 11
Center
Log
Piece
Figure 12
4.Placethecenterlogoverthecorresponding
pins next to the front left log as shown
in Figure 12.
3. Placetheleftfrontlogontothecorrespond-
ing burner pin and sub-floor left tab as
shown in Figure 11.
5. Install the right front log onto the corre-
sponding burner pin and sub-floor right
tab as shown in Figure 13.
Right Front Log
Figure 13

8NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
Figure 14
Left Top
Twig
6. Install the left top twig onto the corre-
sponding pin on the rear log and align it
with the indentation on the front left log
as shown in Figure 14.
Center
Top Twig
Right
Front Twig
7. Install the center top twig onto the cor-
responding pin on the rear log and align
it with the indentation on front left log as
shown in Figure 15.
8. Install the front right twig onto the cor-
respondingpinontherightfrontlog. Align
the twig with the indentation on the front
right log as shown in Figure 16.
Figure 15
Figure 16
Withpropercareand maintenance, yourappli-
ance will provide many years of enjoyment. If
you should experience any problem, first refer
to the troubleshooting guide in this manual.
If problem persists, contact your Lennox
distributor.
SMALL AREA PAINT TOUCH-UP
Models with Black Painted Finish
The stove body is painted with a quality high-
temperature stove paint. Only use factory sup-
plied Stove Paint for touch-ups (70K99).
Using one small piece of 320 grit sand paper
and lightly sand the blemish so that the edges
are“feathered” or smoothto the touchbetween
the painted and bare sur-faces. Do not let the
sandpaper gumup with paint, as this will cause
scratches on the metal surface. If there are any
scratches,use600gritsandpaperinstead.Mask
off surfaces you do not want painted. Paint
lightly over the bare surface first as this will
act as an under-coat. Then paint over a larger
area in smooth even strokes to blend.
See Burn-In Period on Page 4 for information
on curing the paint.
SMALL AREA TOUCH-UP PAINT
Models with Enamel Finish
If the enamel finish on your stove becomes
chipped, it can be touched up using the
enamel touch-up paint. Follow instructions on
tube for applying. See Page 16 for ordering
information.
Note: When enamel is heated to high tempera-
tures it is subject to crazing (a very fine and
random network ofhairline cracks onthe surface
of the porcelain). Crazing is a normal occurrence
when enamel is exposed to high temperatures.
Your enamel finish will not be harmed nor will
the function of the stove be impaired.
Embers
Figure 17
a. Unpackage and divide the fine ember mate-
rial (mineral wool) into dime-sized fluffy
pieces.
b.Distributetheemberpiecesoverthetopofthe
front burner ports. Avoid covering the slots
and filling the area in front of the forward
logs (see Figures 17 and 18).
DONOTPLACE EMBERSONTOP
OF THE BURNER SLOTS.
Figure 18
Proper Pilot Flame Appearance
SIT MILLIVOLT APPLIANCE CHECKOUT
The pilot flame should be steady, not lifting
orfloating.Flameshould beblueincolorwith
tracesoforangeattheouteredge.Thetop3/8"
(10 mm) at the pilot generator (thermopile)
and the top 1/8" minimum (tip) of the quick
drop out thermocouple should be engulfed
in the pilot flame. The flame should project 1"
(25 mm) beyond the hood at all three ports
(Figure 19).
Replace logs if removed for pilot inspec-
tion.
Tolighttheburner,rotatethegasvalvecontrol
knob counterclockwise to the “ON” position
then turn “ON” the on/off rocker switch.
MILLIVOLT
Thermocouple
Hood Igniter Rod
3/8" Min.
(9 mm)
Thermopile
Pilot
Nozzels
Figure 19
9. Place the glowing embers on the burner
as shown in Figures 17 and 18.
One package of ember material has been
includedwiththislogset Youwillnotneed
to use the entire bag.
IMPORTANT: The quantity and place-
ment of the ember material can affect
stove performance therefore it is very
important that it be placed as shown in
Figures 17 and 18.

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE. 9
WIRING DIAGRAMS
Wiring diagrams are provided here for reference purposes only. This information is also provided on schematics attached directly to the appliance
on a pullout panel located within the control compartment.
CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND DAN-
GEROUS APPLIANCE OPERATION.
WARRANTY INFORMATION
Yourgasapplianceiscoveredbyalimitedtwenty
year warranty. You will find a copy of the war-
ranty accompanying this manual. Please read
the warranty to be familiar with its coverage.
Retain this manual. File it with your other docu-
ments for future reference.
REPLACEMENT PARTS
A complete parts list is found at the end of
this manual. Use only parts supplied from the
manufacturer.
Normally, all parts should be ordered through
your Lennox Hearth Products Distributor or
Dealer. Parts willbeshippedatprevailingprices
at time of order.
Product Reference Information
We recommend that you record the following important information about your stove. Please
contact your Lennox Hearth Products Dealer for any questions or concerns. For the number of
your nearest Lennox Hearth Products Dealer, please call 1-800-9-Lennox
Your Stove's Model Number __________________________________________
Your Stove's Serial Number___________________________________________
The Date On Which Your Stove Was Installed _____________________________
The Type of Gas Your Stove Uses ______________________________________
Your Dealer's Name ________________________________________________
Ifyouencounteranyproblemsorhaveanyques-
tions concerning the installation or application
of this system, please contact your distributor,
or Lennox directly:
Lennox Hearth Products
1110 West Taft Avenue
Orange, CA 92865
Visit us at www.LennoxHearthProducts.com
When ordering repair parts, always give the
following information:
1. The model number of the appliance.
2. The serial number of the appliance.
3. The part number.
4. The description of the part.
5. The quantity required.
6. The installation date of the appliance.
If any of the original wire as supplied must be replaced,
it must be replaced with Type AWM105°C – 18 GA. wire.
Thermopile
TH
TP TH
TP
* ON/OFF Switch, Optional
Thermostat Remote
Control Receiver
* SWITCH
Figure 20
Blower
Mounting
Bracket
Black
Black
White
White
Fan Disc Rheostat
Blower
Assembly
(Shown
Rotated 90
Degrees CCW)
Black
Power Cord
Blower Wiring Diagram
Optional Room Air Blower
SIT Millivolt Wiring Diagram
Figure 22
IMPORTANT: Ground supply wire must
beconnectedtothegreenwireattached
to the green ground screw. Failure to
do so will result in a potential safety
hazard. The appliance must be electri-
callygroundedinaccordance with local
codes or, in the absence of local codes,
theNationalElectricalCode,ANSI/NFPA
70 - latest edition. (In Canada, the cur-
rentCSAC22-1CanadianElectricalCode
- latest edition.
WARNING: The power cord must
be plugged directly into a properly
grounded three-prong 120 Volt, 60 Hz
wall receptacle. Do not cut or remove
the grounding prong from this plug. Do
not route power cord under or in front
of appliance.

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
10
Firescreen Kits
These firescreens can be installed on the glass
enclosurepanel toprovidedprotectionfromthe
hot glass surface.
ACCESSORY COMPONENTS
H0249 RCL Remote Control System (Standard)
Standard Remote Control System
The Model RCL (Standard) Remote Control
System, features a simple On/Off control
function for the stove. This model includes a
hand-held transmitter, a remote receiver with
wall-mountcoverplateandallhardwarerequired
to install the unit. The remote receiver can be
wall or hearth mounted.
Deluxe Remote Control System
The Model RCL-T (Deluxe) Remote Control
System has all of the features of the standard
system along with an added easy to read LCD
screenwhichpresentsaccesstomanyenhance-
ments, including; battery power level indicator,
timer, mode of operation, thermostatic display
including room temperature in either metric
or English units, flame indicator and clock.
Fully programmable, the Model RCL-T allows
for command over nearly all operational and
temperature variables, using the hand held
remote control transmitter.
H0251 RCL-T Remote Control System (Deluxe)
Touch-Up Paint Kit (painted models
only)
Repair of minor scratches and discoloration
of the appliance's painted surfaces may be
accomplished with the use of these touch-up
paint kits.
70K99, Touch-Up Paint (Black) Kit
Room Air Blower Kit
The BK-CI blower provides constant velocity forced air circulation. It includes a variable speed
control rheostat and a thermally activated fan disc.
Variable Speed Control Rheostat
Thermally Activated Switch
H0767 BK-CI Blower Kit CI1500 and CI2500
Flat Firescreen
Bubble Firescreen
Flame Modulating Remote Control
System
The Model RCL-MN and RCL-ML remote con-
trolshaveonandoffburnercontrol,flameheight
adjustment, thermostat operation and a timer
to shut unit down automatically. This system
also provides blower on/off and speed control
(if optional BK-CI Blower Kit is installed).
Flame Modulating Remote Control
H0301 RCL-MN Natural Gas
H0302 RCL-ML LP/Propane Gas
89L36 WTK Wall Thermostat KiT
Wall Thermostat
The wall thermostat kit provides temperature
control for optimum comfort.
Blower
    

  

P
A
I
N
T
Firescreen Kits
Cat. No. Model Description Where Used
H0768 FSF-CI15 Flat Screen CI1500DVF
H0770 FSF-CI25 Flat Screen CI2500DVF
H0769 FSB-CI15 Bubble Screen CI1500DVF
H0771 FSB-CI25 Bubble Screen CI2500DVF

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE. 11
Side View of Warming Shelf
ACCESSORY COMPONENTS CONTINUED
Brickaded Liner Kits
The brickade liner kits include panels for the rear and side walls of the
firebox. The panels have brick-like features in relief. These kits can be
retrofitted into previously installed appliances.
Warming Shelves
These attactive warming shelves are designed to be functional for
placing food to stay warm. The shelves extend on both sides of the
stove top and add an attractive accent. See Page 20 for installation
instructions.
Top View of Warming Shelf
Full View Showing Warming Shelves Installed
Cat. No. Model Description
H0757 WS-CI150 Warming Shelves, CI1500 Black
H0758 WS-CI152 Warming Shelves, CI1502 Mid Blu
H0759 WS-CI154 Warming Shelves, CI1504 Maj Bwn
H0760 WS-CI156 Warming Shelves, CI1506 Hu Grn
H2159 WS-CI158-2 Warming Shelves, CI1508-2 Ivory White
H0762 WS-CI250 Warming Shelves, CI2500 Black
H0763 WS-CI252 Warming Shelves, CI2502 Mid Blu
H0764 WS-CI254 Warming Shelves, CI2504 Maj Bwn
H0765 WS-CI256 Warming Shelves, CI2506 Hu Grn
H2158 WS-CI258-2 Warming Shelves, CI2508-2 Ivory White
Cat. No. Model Description
H0773 BLK-CI15 Brick Liner Kit CI1500DVF Series
H0774 BLK-CI25 Brick Liner Kit CI2500DVF Series

12
4. Depress gas control knob slightly and turn clockwise
to “OFF.” Do not force.
5. Close lower control compartment.
6. Wait five (5) minutes to clear out any gas. If you then smell gas,
STOP! Follow “B” in the safety information above on this page. If you
do not smell gas, go to the next step.
7. Push in gas control knob slightly and turn counterclockwise
to “PILOT.”
8. Push in control knob all the way and hold in. Immediately light the
pilot by triggering the spark igniter (pushing the button) until pilot
lights. Continue to hold the control knob in for about 1 1/2 minutes
after the pilot is lit. Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 5 through 8.
•If knob does not pop up when released,
stop and immediately call your service
technician or gas supplier.
•If pilot will not stay lit after several
tries, turn the control knob to “OFF”
and call your service technician or gas
supplier.
9. Turn gas control knob counterclockwise
to “ON.”
10. Close lower control compartment.
LIGHTING INSTRUCTIONS – SIT MILLIVOLT GAS VALVE
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY READ BEFORE LIGHTING
A. This appliance has a pilot which must be lighted with a
piezo igniter. When lighting the pilot, follow these instructions
exactly.
B. BEFORE OPERATING smell all around the appliance area for
gas. Be sure to smell next to the floor because some gas is
heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
•Extinguish any open flame.
•Open windows.
•Do not light any appliance.
•Do not touch any electrical switches.
TO TURN OFF GAS TO APPLIANCE
1. Turn remote wall switch “OFF.” The pilot will remain lit for
normal service.
2. For complete shutdown, turn remote wall switch to “OFF.”
3. Access the lower control compartment.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above on this page.
2. Access the lower control compartment.
3. Turn remote wall switch to “OFF.”
4. Verify main line shut-off valve is open.
5. Push in gas control knob slightly and turn clockwise
to “OFF.”
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s
phone.
•If your gas supplier cannot be reached, call the fire depart-
ment.
C. Use only your hand to push in or turn the gas control knob.
Never use tools. If the knob will not push in or turn by hand,
do not try to repair it, call a qualified service technician. Force
or attempted repair may result in a fire or an explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
Note: Knob cannot be turned from “PILOT” to “OFF”
unless the knob is pushed in slightly. Do not force.
SIT
MILLIVOLT PILOT
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
it
O
F
F
OUT
OUT
IN
IN
SIT Millivolt Gas Valve
- LO / HI + GAS CONTROL
KNOB
TP/TH
TH
TP
PIEZO
IGNITER
BURNER
ON/OFF SWITCH
OFF
ON

13
INSTRUCTIONS D'ALLUMAGE
8. Enfoncez le bouton de réglage jusqu’au fond et gardez-le enfoncé.
Allumez immédiatement la veilleuse en déclenchant l’allume-gaz
à étincelle (en poussant le bouton) jusqu’à ce que la veilleuse
s’enflamme. Continuez de tenir le bouton de réglage enfoncé
pendant environ 90 secondes après l’allumage de la veilleuse.
Relâchez le bouton et il sortira subitement. La veilleuse devrait
rester allumée. Si elle s’éteint, répétez les étapes 5 à 8 inclusive-
ment.
• Si le bouton ne sort pas automatiquement après avoir été relâché,
arrêtez immédiatement et téléphonez à votre technicien de service
ou à votre fournisseur de gaz.
• Si la veilleuse refuse de rester allumée après plusieurs tentatives,
tournez le bouton de réglage jusqu’à sa position d’arrêt “OFF” et
téléphonez à votre technicien de service
ou à votre fournisseur de gaz.
9. Tournez le bouton de réglage du gaz
en sens inverse des aiguilles d’une
montre jusqu’à sa
position de marche “ON”.
10. Fermez le compartiment de contrôle
du bas.
11. Au besoin, rebrancher l’appareil
au courant électrique et remettre
l’interrupteur du brûleur principal à la
position “ON” ou régler le thermostat à
la température désirée.
12. Si l’appareil ne fonctionne pas, suivre les instructions intitulées
“Pour fermer le gaz qui alimente l’appareil” et appeler un tech-
nicien ou le fournisseur de gaz.
AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU
UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE.
POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE
A. Cet appareil est muni d’une veilleuse qui doit être allumée avec un
allumeur piézo-électrique. Lorsque vous allumez la veilleuse, suivre
exactement ces instructions.
B. AVANTL’ALLUMAGE:Assurez-vousque vousnedétectez aucuneodeur
de gaz autour de l’apareil ainsi que près du sol; certains gaz, étant plus
lourds que l’air, descendent au niveau du sol.
VOICI CE QUE VOUS DEVEZ FAIRE SI VOUS DÉCELEZ UNE ODEUR
DE GAZ:
•Éteignez toute flamme visible.
•Ouvrez les fenêtres.
•N’allumez aucun appareil.
•Ne touchez à aucun commutateur électrique.
•Ne vous servez d’aucun téléphone dans votre édifice.
•Appelez immédiatement votre compagnie de gaz en utilisant le télé-
phone du voisin.
•S’il vous est impossible de contacter votre compagnie de gaz, appelez
le service des incendies.
C. N’utilisez que votre main pour manipuler le bouton de réglage du gaz.
N’utilisez jamais d’outils. Si le bouton refuse de tourner ou de bouger,
n’essayez pas de le réparer. Communiquez immédiatement avec un
technicien de service qualifié. Toute tentative pour le forcer ou le
réparer, risquerait de provoquer un incendie ou une explosion.
D. Ne vous servez pas de cet appareil si l’un de ses éléments a été
immergé dans l’eau. Appelez immédiatement un technicien compétent
pour faire inspecter l’appareil et remplacer toute pièce du système de
réglage ou commande du gaz qui a été sous l’eau.
1. ARRÊTEZ! Lisez les consignes de sécurité au verso de cette plaque.
2. Ouvrez le compartiment de contrôle du bas.
3. Tournez l’interrupteur mural à la position d’arrêt “OFF”.
4. Assurez-vous que la soupape d’arrêt de la canalisation principale
est ouverte.
5. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la
position d’arrêt “OFF”.
Remarque: Il est impossible de tourner le bouton de “PILOT” à “OFF” à
moins qu’il ne soit légèrement enfoncé. Ne le forcez pas.
6. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous décelez
une odeur de gaz, ARRÊTEZ ! Retournez au point “B” des consignes
de sécurité au verso de cette plaque. Si vous ne remarquez aucune
odeur de gaz, passez à l’étape suivante.
7. Enfoncez légèrement le bouton de réglage du gaz et tournez-le
en sens inverse des aiguilles d’une montre jusqu’à la position de
veilleuse “PILOT”.
1. Tournez l’interrupteur mural à la position d’arrêt “OFF”. La veilleuse
restera allumée jusqu’au retour du service normal.
2. Pour une fermeture complète, tournez l’interrupteur mural à la posi-
tion d’arrêt “OFF”.
3. Ouvrez le compartiment de contrôle du bas.
POUR FERMER LE GAZ QUI ALIMENTE L’APPAREIL
4. Enfoncez légèrement le bouton de réglage du gaz et tournez-le dans
le sens des aiguilles d’une montre jusqu’à la position
d’arrêt “OFF”. Ne forcez pas le bouton.
5. Fermez le compartiment de contrôle du bas.
SIT
MILLIVOLT PILOT
VANNE GAZ MILLIVOLT SIT
H
I
L
O
W
TPTH TP TH
P
I
L
O
T
P
I
L
O
T
O
N
it
it
O
F
F
OUT
OUT
IN
IN
TP/TH
TH
TP
ON/OFF
OFF
ON
BOUTON DE RÉGLAGE DU GAZ
- LO / HI + (COMMANDE
DE TAILLE DE FLAMME)
ALLUMEUR
INSTRUCTIONS D’ALLUMAGE - VANNE GAZ MILLIVOLT SIT

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
14
Maintenance Task Accomplishing Person Procedure
Inspecting/Cleaning Burner, Logs
and Controls
Qualified Service Technician Inspect valve and ensure it is properly operating. Check piping
for leaks. Vacuum the control compartment, fireplace logs and
burner area.
Check Flame Patterns and Flame
Height
Qualified Service Technician Refer to Figure 7 on Page 6 and verify the flame pattern and height
displayed by the appliance conforms to the picture. Flames must
not impinge on the logs. Ensure flames are steady (not lifting or
floating).
Inspecting/Cleaning Pilot Qualified Service Technician Refer to Figure 19 (Page 8). Remove any surface build-up on
pilot and burner assembly. Wipe the pilot nozzles, igniter/flame
rod and hood. Ensure the pilot flame engulfs the flame sensor
as shown.
Checking Vent System Qualified Service Technician Inspect the vent system at the top and at the base (within the
firebox) for signs of blockage or obstruction. Look for any signs
of dislocation or deterioration of the vent components. Note:
Excessive condensation can cause corrosion of caps, pipe and
fittings (excessive condensation can be caused by long lateral
runs,too manyelbowsand/orexteriorportions ofthesystembeing
exposed to cold weather). Also inspect wall straps or plumbers's
tabe to ensure it is secure and in place.
Appliance Checkout Qualified Service Technician Perform the appropriate appliance checkout procedure detailed
in this manual.
Replacing Rockwool Ember Materials Homeowner/Qualified Service
Technician
Remove old ember materials and vacuum the rockwool placement
area. Place new rockwool as described on Page 8 (see Figures
17 and 18).
Periodically (After the Burning Season)
Maintenance Task Accomplishing Person Procedure
Cleaning Firebox Interior Homeowner Carefully remove logs, rockwool, volcanic stone and volcanic
stone. Vacuum out interior of the firebox. Clean firebox walls
and log grate. Replace logs, Rockwool and volcanic stone as
detailed in this manual.
Check Flame Patterns and Flame
Height
Homeowner Refer to Figure 7 on Page 6 and verify the flame pattern and height
displayed by the appliance conforms to the picture. Flames must
not impinge on the logs.
Checking Vent System Homeowner Inspect the vent system at the top and at the base (within the
firebox) for signs of blockage or obstruction. Look for any signs
of dislocation of the vent components.
Cleaning Front Glass Enclosure Panel Homeowner Cleanasnecessaryfollowingthedirectionsprovidedinthismanual.
DO NOT TOUCH OR ATTEMPT TO CLEAN GLASS WHILE HOT.
Anually (Before the onset of the Burning Season)
MAINTENANCE SCHEDULE

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE. 15
TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM
Note: Before troubleshooting the gas control system, be sure external gas shut off valve (located at gas supply inlet) is in the “ON”
position.
Important: Valve system troubleshooting should only be accomplished by a qualified service technician.
SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION
1. Spark igniter will not light pilot after
repeated triggering of igniter button. A. Defective igniter (no spark at electrode). Checkthegapbetweentheelectrodeandpilot.Itshould
be between 1/8” and 3/16." If the gap is out of this
range, adjust the gap or replace the pilot.
B. Defective or misaligned electrode at pilot
(spark at electrode). Using a match, light pilot. If pilot lights, turn off pilot
and trigger the igniter button again. If pilot lights, an
improper gas mixture caused the bad lighting and a
longer purge period is recommended. If pilot will not
light – check gap at electrode and pilot – It should
be between 1/8” and 3/16". If the gap is out of this
range, adjust the gap or replace the pilot. (Figure 19
on Page 8).
C. Gas supply pressure errant. Check inlet gas pressure. It should be within the limits
as marked on the rating plate.
D. Pilot orifice plugged. Clean or replace pilot orifice.
2. Pilot will not stay lit after
carefully following the lighting
instructions.
A. Defective pilot generator
(thermocouple). Check pilot flame, it must impinge on thermocouple
(Figure 19 on Page 8). Clean and/or adjust pilot for
maximum flame impingement on thermocouple.
Ensure that the connection between the valve and
thermocouple are tight and secure.
3. Pilot burning, no gas to burner, Valve
knob “ON,” Wall Switch “ON.” A. Wall switch or wires defective. Check wall switch and wires for proper connections.
Jumper wire across terminals at wall switch, if burner
comeson,replacedefectivewallswitch.Ifokay,jumper
wiresacrosswallswitchwiresatvalve,ifburnercomes
on, wires are faulty or connections are bad.
B. Thermopile may not be generating suf-
ficient millivoltage. Check thermopile with millivolt meter. Take reading
at thermopile terminals of gas valve. Should read
325 millivolts minimum with optional wall switch
“OFF.” Replace faulty thermopile if reading is below
specified minimum.
C. Plugged burner orifice. Check burner orifice for stoppage and remove.
4. Frequent pilot/burner outage prob-
lem. A. Pilot flame may be too low or blowing (high) causing the pilot/valve safety to drop out. Clean and/or adjust pilot flame for maximum flame
impingement on thermocouple (Figure 19 on Page
8).

16
REPLACEMENT PARTS LIST
Gas Controls
Item # Part/Cat. No. Description Where Used
1 H1657 Valve Assembly – Natural Gas, SIT All
30 H2211 Gas Train Assembly, MV, Natural Gas (LP units will also require LB-102158A) CI1500DVF Series
30 H2212 Gas Train Assembly, MV, Natural Gas (LP units will also require LB-102158B) CI2500DVF Series
2 10K86 Piezo Igniter, Push Button (wire not included) All
3 69L17 Pilot Assembly, Natural Gas All
5 H3737 Pilot Shield All
6 74L56 Pilot Tube All
H3697 RB Regulator (Hi/Lo)- Natural Gas, SIT (H1656) – Converts LP Valve to NG All
H3698 RB Regulator (Hi/Lo)- Propane Gas, SIT – Converts NG Valve to LP All
7 74L57 Thermocouple All
8 60J79 Thermopile (pilot generator) All
H3364 Tube, Gas Valve All
H1061 Wire Harness, Valve All
15 74L58 Electrode and Cable All
Miscellaneous Parts
4 55M91 Bracket, Corner, Black Painted, 1 ea. CI1500DVF Series
4 66M03 Bracket, Corner, Black Painted, 1 ea. CI2500DVF Series
9 42M72 Burner Assembly CI1500DVF Series
10 42M73 Burner Assembly CI2500DVF Series
H3705 Conversion Kit, NG to LP (RB Reg., Pilot Orifice, Burner Orifice & Label) CI1500DVF Series
H3706 Conversion Kit, NG to LP (RB Reg., Pilot Orifice, Burner Orifice & Label) CI2500DVF Series
35M50 Gasket, Relief Door, CI1500 CI1500DVF Series
35M51 Gasket, Relief Door, CI2500 CI2500DVF Series
11 93L32 Gas Line Connector, Flexible, With Shut-Off Valve, 1 ea. All
12 H3703 Glass Panel Enclosure Assembly, Complete CI1500DVF Series
12 H3704 Glass Panel Enclosure Assembly, Complete CI2500DVF Series
29b 527 Knob, Rheostat, 1 ea. All
69L21 Latch, 1 ea. All
13 24M10 Orifice, Main Burner, #37, Natural Gas, 1 ea. CI1500DVF Series
13 H1073 Orifice, Main Burner, .121”, Natural Gas, 1 ea. CI2500DVF Series
55M62 Paint, Touch-up for enamel, 1/2 oz Bottle - Hunter Green, 1 ea. CI1506DVF & CI2506DVF
55M63 Paint, Touch-up for enamel, 1/2 oz Bottle - Ivory White, 1 ea. CI1508DVF-2 & CI2508DVF-2
55M61 Paint, Touch-up for enamel, 1/2 oz Bottle - Maj. Brown, 1 ea. CI1504DVF & CI2504DVF
55M60 Paint, Touch-up for enamel, 1/2 oz Bottle - Mid. Blue, 1 ea. CI1502DVF & CI2502DVF
14 27K30 Switch, ON/OFF (Rocker Switch), 1 ea. All
74L58 Wire, Igniter Electrode (includes electrode), 1 ea. All

REPLACEMENT PARTS LIST
17
Cast Body Components
Item # Part/Cat. No. Description Where Used
19 66M53 Ash Lip, Enamel Hunter Green, 1 ea. CI1506DVF
19 66M93 Ash Lip, Enamel Hunter Green, 1 ea. CI2506DVF
19 H2163 Ash Lip, Enamel Ivory White, 1 ea. CI1508DVF-2
19 H2164 Ash Lip, Enamel Ivory White, 1 ea. CI2508DVF-2
19 66M52 Ash Lip, Enamel Maj. Brown, 1 ea. CI1504DVF
19 66M92 Ash Lip, Enamel Maj. Brown, 1 ea. CI2504DVF
19 66M51 Ash Lip, Enamel Mid. Blue, 1 ea. CI1502DVF
19 66M91 Ash Lip, Enamel Mid. Blue, 1 ea. CI2502DVF
19 55M89 Ash Lip, Painted Black, 1 ea. CI1500DVF
19 66M01 Ash Lip, Painted Black, 1 ea. CI2500DVF
22 66M57 Door Casting, Lower Access - Enamel Hunter Green, 1 ea. CI1506DVF
22 66M97 Door Casting, Lower Access - Enamel Hunter Green, 1 ea. CI2506DVF
22 H2169 Door Casting, Lower Access - Enamel Ivory White, 1 ea. CI1508DVF-2
22 H2170 Door Casting, Lower Access - Enamel Ivory White, 1 ea. CI2508DVF-2
22 66M56 Door Casting, Lower Access - Enamel Maj. Brown, 1 ea. CI1504DVF
22 66M96 Door Casting, Lower Access - Enamel Maj. Brown, 1 ea. CI2504DVF
22 66M55 Door Casting, Lower Access - Enamel Mid. Blue, 1 ea. CI1502DVF
22 66M95 Door Casting, Lower Access - Enamel Mid. Blue, 1 ea. CI2502DVF
22 55M90 Door Casting, Lower Access - Painted Black, 1 ea. CI1500DVF
22 66M02 Door Casting, Lower Access - Painted Black, 1 ea. CI2500DVF
23 H5324 Front Face and Door Set Assembly, Hunter Green, 1 ea. CI1506DVF
23 H5322 Front Face and Door Set Assembly,Hunter Green, 1 ea. CI2506DVF
23 H5325 Front Face and Door Set Assembly, Ivory White, 1 ea. CI1508DVF-2
23 H5323 Front Face and Door Set Assembly, Ivory White, 1 ea. CI2508DVF-2
23 H5327 Front Face and Door Set Assembly, Majolica Brown, 1 ea. CI1504DVF
23 H5321 Front Face and Door Set Assembly, Majolica Brown, 1 ea. CI2504DVF
23 H5326 Front Face and Door Set Assembly, Midnight Blue, 1 ea. CI1502DVF
23 H5320 Front Face and Door Set Assembly, Midnight Blue, 1 ea. CI2502DVF
23 H5318 Front Face and Door Set Assembly, Flat Black, 1 ea. CI1500DVF
23 H5319 Front Face and Door Set Assembly, Flat Black, 1 ea CI2500DVF
24 H1023 Leg Casting, Enamel Hunter Green, 1 ea. CI1506DVF & CI2506DVF
24 H2173 Leg Casting, Enamel Ivory White, 1 ea. CI1508DVF-2 & CI2508DVF-2
24 H1022 Leg Casting, Enamel Maj. Brown, 1 ea. CI1504DVF & CI2504DVF
24 H1021 Leg Casting, Enamel Mid. Blue, 1 ea. CI1502DVF & CI2502DVF
24 66M08 Leg Casting, Painted Black, 1 ea. CI1500DVF & CI2500DVF
25 H1007 Side Casting, Left - Enamel Hunter Green, 1 ea. CI1506DVF
25 H1031 Side Casting, Left - Enamel Hunter Green, 1 ea. CI2506DVF
25 H2174 Side Casting, Left - Enamel Ivory White, 1 ea. CI1508DVF-2
25 H2175 Side Casting, Left - Enamel Ivory White, 1 ea. CI2508DVF-2
25 H1006 Side Casting, Left - Enamel Maj. Brown, 1 ea. CI1504DVF
25 H1030 Side Casting, Left - Enamel Maj. Brown, 1 ea. CI2504DVF
25 H1005 Side Casting, Left - Enamel Mid. Blue, 1 ea. CI1502DVF
25 H1029 Side Casting, Left - Enamel Mid. Blue, 1 ea. CI2502DVF
25 66M04 Side Casting, Left - Painted Black, 1 ea. CI1500DVF
25 66M14 Side Casting, Left - Painted Black, 1 ea. CI2500DVF

18
REPLACEMENT PARTS
Cast Body Components (continued)
26 H1011 Side Casting, Right, Enamel Hunter Green, 1 ea. CI1506DVF
26 H1035 Side Casting, Right, Enamel Hunter Green, 1 ea. CI2506DVF
26 H2176 Side Casting, Right, Enamel Ivory White, 1 ea. CI1508DVF-2
26 H2177 Side Casting, Right, Enamel Ivory White, 1 ea. CI2508DVF-2
26 H1010 Side Casting, Right, Enamel Maj. Brown, 1 ea. CI1504DVF
26 H1034 Side Casting, Right, Enamel Maj. Brown, 1 ea. CI2504DVF
26 H1009 Side Casting, Right, Enamel Mid. Blue, 1 ea. CI1502DVF
26 H1033 Side Casting, Right, Enamel Mid. Blue, 1 ea. CI2502DVF
26 66M05 Side Casting, Right, Painted Black, 1 ea. CI1500DVF
26 66M15 Side Casting, Right, Painted Black, 1 ea. CI2500DVF
27 66M81 Top Casting, Stove, Enamel Hunter Green, 1 ea. CI1506DVF
27 H1043 Top Casting, Stove, Enamel Hunter Green, 1 ea. CI2506DVF
27 H2178 Top Casting, Stove, Enamel Ivory White, 1 ea. CI1508DVF-2
27 H2179 Top Casting, Stove, Enamel Ivory White, 1 ea. CI2508DVF-2
27 66M80 Top Casting, Stove, Enamel Maj. Brown, 1 ea. CI1504DVF
27 H1042 Top Casting, Stove, Enamel Maj. Brown, 1 ea. CI2504DVF
27 66M79 Top Casting, Stove, Enamel Mid. Blue, 1 ea. CI1502DVF
27 H1041 Top Casting, Stove, Enamel Mid. Blue, 1 ea. CI2502DVF
27 55M97 Top Casting, Stove, Painted Black, 1 ea. CI1500DVF
27 66M18 Top Casting, Stove, Painted Black, 1 ea. CI2500DVF
28 66M85 Trivet, Enamel Hunter Green, 1 ea. CI1506DVF
28 H1047 Trivet, Enamel Hunter Green, 1 ea. CI2506DVF
28 H2180 Trivet, Enamel Ivory White, 1 ea. CI1508DVF-2
28 H2183 Trivet, Enamel Ivory White, 1 ea. CI2508DVF-2
28 66M84 Trivet, Enamel Maj. Brown, 1 ea. CI1504DVF
28 H1046 Trivet, Enamel Maj. Brown, 1 ea. CI2504DVF
28 66M83 Trivet, Enamel Mid. Blue, 1 ea. CI1502DVF
28 H1045 Trivet, Enamel Mid. Blue, 1 ea. CI2502DVF
28 55M98 Trivet, Painted Black, 1 ea. CI1500DVF
28 66M19 Trivet, Painted Black, 1 ea. CI2500DVF
Room Air Blower System (Optional Kit)
H0767 Blower Kit (BK-CI), Complete All
29 528 Rheostat, Blower Speed Control (knob not included) All
42M60 Switch, Temperature Control (thermally activated fan disc) All
Log Sets
16 35M66 Ember Strip (bottom front refractory), 1 ea. CI1500DVF Series
16 42M61 Ember Strip (bottom front refractory), 1 ea. CI2500DVF Series
17 88L53 Embers, Bag of (1 oz. rockwool), 1 ea. All
18 H1065 Log Set, 7 pc. CI1500DVF Series
18 H1075 Log Set, 7 pc. CI2500DVF Series

NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE. 19
2
REPLACEMENT PARTS
18
L E N N O X
7
5
8
3
6
9
11
12
13 14
17
1
19
25
L E N N O X
26
24
22
27
28
29
23
*
* *
Front View
******
10
Front View
4
16 Log Set Does Not Include Ember Strip (purchased
separately)
15
30
29b

20
Printed in U.S.A. © 2003 Lennox Hearth Products
P/N 775,148M REV. C 11/2006
Reference Information
If Optional Warming Shelves are purchased, install as follows:
OPTIONAL WARMING SHELVES KIT
Kit Contents:
2 ea. Warming Shelves 6 ea. Insets (CI2500 Series)
4 ea. Decorative Brackets 4 ea. Screws, 6mm x 20mm
4 ea. Insets (CI1500 Series) 1 ea. Instruction Sheet
Tools Required:
Phillips Screwdriver
Installation Instructions:
1. Lift off trivet, then stove top and set aside.
3. Using the existing screws on the stove body, install both warming
shelve assemblies as shown in Figure 23. Tighten screws just enough
to level shelves.
Install Screws Provided
Install, using
the existing
screws.
Figure 22
Figure 23
4. Place the insets (4 ea. for the CI1500 series or 6 ea. for the CI2500
series) into the recessed areas on both warming shelves as shown in
Figures 24 and 25. Note: Common ceramic tiles (4-1/4” square) can
be used in place of insets on the warming shelves (available at most
home improvement stores).
Install Insets
Place insets as
shown here.
Top View of Warming Shelves Installed
5. Reinstall stove top into position (see Figure 25).
Figure 24
Figure 25
Proper Use Instructions:
These attractive shelves are designed to be functional for placing food
to stay warm. For cleaning instructions see Cleaning Enamel Surfaces
on Page 4.
IMPORTANT NOTES:
• NEVER PLACE ANYTHING ON THE SHELVES WHICH EXCEEDS 80
POUNDS (36 KILOGRAMS).
• NEVER PLACE FOOD CONTAINERS OR OTHER MATERIALS ON THE
SHELVES THAT MAY BE SUBJECT TO MELTING.
1110 West Taft Avenue • Orange, CA 92865
NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
Lennox reserves the right to make changes at any time, without notice, in design,
materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
Installing onto Stove Body
Assemble Shelves to Brackets
2. Install decorative brackets to both warming shelves using the screws
provided (see Figure 22).
CAUTION
The cast iron stove top is very heavy and may
require a minimum of two people to lift; one person
on each side (the CI1500 series cast top weighs
~20 pounds and the CI2500 series cast top weighs
~40 pounds).
