Page 1
Corp. 0925-L11
LCH SERIES
Service Literature
3 to 6 ton
7 to 21 kW
Revised 10-2018
LCH036 through 074
LCH036H, 048H, and 060H are high efficiency packaged
units equipped with direct drive blowers. LCH036S, 048S
and 060S are standard efficiency packaged units equipped
with two speed belt drive blowers. LCH072H, 074H are high
efficiency packaged units equipped with a single and two
speed belt drive motors.
Optional electric heat is factory or field installed . Electric
heat operates in single stage depending on the kW input
size. 7.5kW through 30 kW heat sections are available for
the LCH unit.
Information contained in this manual is intended for use by
qualified service technicians only. All specifications are sub
ject to change. Procedures outlined in this manual are pre
sented as a recommendation only and do not supersede or
replace local or state codes.
If the unit must be lifted for service, rig unit by attaching four
cables to the holes located in the unit base rail (two holes at
each corner). Refer to the installation instructions for the proper
rigging technique.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, person
al injury or loss of life. Installation and service must
be performed by a licensed professional installer (or
equivalent) or service agency.
IMPORTANT
The Clean Air Act of 1990 bans the intentional vent
ing of refrigerant (CFC's and HCFC's) as of July 1,
1992. Approved methods of recovery, recycling or re
claiming must be followed. Fines and/or incarcera
tion may be levied for non-compliance.
WARNING
Electric shock hazard. Can cause injury
or death. Before attempting to perform
any service or maintenance, turn the
electrical power to unit OFF at discon
nect switch(es). Unit may have multiple
power supplies.
CAUTION
Danger of sharp metallic edges. Can cause injury.
Take care when servicing unit to avoid accidental
contact with sharp edges.
CAUTION
Electrostatic discharge can affect elec
tronic components. Take precautions to
neutralize electrostatic charge by
touching your hand and tools to metal
prior to handling the control.
Table of Contents
Options Page 2.......................
Specifications Page 5..................
Blower Data Page 7...................
Electrical /Electric Heat Data Page 19.....
Electric Heat Capacities Page 26........
Parts Arrangement Page 31.............
I Unit Components Page 32.............
II Placement and Installation Page 43.....
III Start Up Operation Page 43...........
IV Charging Page 43...................
V System Service Checks Page 53.......
VI Maintenance Page 53................
VII Accessories Page 54................
VIII Diagrams Page 63..................

Page 2
OPTIONS / ACCESSORIES
Item Model
Number
Catalog
Number
Unit Model Number
036 048 060 072 074
COOLING SYSTEM
Condensate Drain Trap PVC - C1TRAP20AD2 76W26 OX OX OX OX OX
Copper - C1TRAP10AD2 76W27 OX OX OX OX OX
Conventional Fin/Tube Condenser Coil (replaces Environ™ Coil System) Factory O O O O O
Drain Pan Overow Switch E1SNSR71AD1 68W88 OX OX OX OX OX
Efciency Standard Factory O O O
High Factory O O O O O
Service Valves (not for Environ™ Coil System or Humiditrol® Dehumidication Option) Factory O O O O O
BLOWER - SUPPLY AIR
Motors Direct Drive - 0.50 hp Factory O
Direct Drive - 0.75 hp Factory O
Direct Drive - 1 hp Factory O
Belt Drive - 0.75 hp (2 Speed) Factory O O
Belt Drive - 1 hp (2 Speed) Factory O O O
Belt Drive - 2 hp (2 Speed) Factory O O O
Belt Drive - 1 hp Standard Efciency Factory O
Belt Drive - 2 hp Standard Efciency Factory O
Drive Kits
See Blower Data Tables for
selection
Kit A01 - T1DRKT001-1 - 673-1010 rpm Factory O
Kit A02 - T1DRKT002-1 - 745-1117 rpm Factory O
Kit A03 - T1DRKT003-1 - 833-1250 rpm Factory O
Kit A05 - T1DRKT005-1 - 897-1346 rpm Factory O
Kit A06 - T1DRKT006-1 - 1071-1429 rpm Factory O
Kit A07 - T1DRKT007-1 - 1212-1548 rpm Factory O
Kit AA01 - T1DRKT001AP1 - 522-784 rpm Factory O O
Kit AA02 - T1DRKT002AP1 - 632-875 rpm Factory O O
Kit AA03 - T1DRKT003AP1 - 798-1105 rpm Factory O O
Blower Belt Auto-Tensioner Factory O O O O O
ELECTRIC HEAT
7.5 kW 208/230V-1ph - E1EH0075AN1P 46W28 OX OX OX
208/230V-3ph - E1EH0075AN1Y 46W31 OX OX OX OX OX
460V-3ph - E1EH0075AN1G 46W35 OX OX OX OX OX
575V-3ph - E1EH0075AN1J 46W39 OX OX OX OX OX
15 kW 208/230V-1ph - E1EH0150AN1P 46W29 OX OX OX
208/230V-3ph - E1EH0150AN1Y 46W32 OX OX OX OX OX
460V-3ph - E1EH0150AN1G 46W36 OX OX OX OX OX
575V-3ph - E1EH0150AN1J 46W40 OX OX OX OX OX
22.5 kW 208/230V-1ph - E1EH0225N1P 46W30 OX
208/230V-3ph -- E1EH0225N1Y 46W33 OX OX OX
460V-3ph - E1EH0225N1G 46W37 OX OX OX
575V-3ph - E1EH0225N1J 46W41 OX OX OX
30 kW 208/230V-3ph - E1EH0300N-1Y 46W34 OX OX
460V-3ph -- E1EH0300N-1G 46W38 OX OX
575V-3ph - E1EH0300N-1J 46W42 OX OX
NOTE - Catalog and model numbers shown are for ordering eld installed accessories.
OX - Congure To Order (Factory Installed) or Field Installed
O = Congure To Order (Factory Installed)
X = Field Installed

Page 3
OPTIONS / ACCESSORIES
Item Model
Number
Catalog
Number
Unit Model Number
036 048 060 072 074
CABINET
Combination Coil/Hail Guards C1GARD51A-1 13R98 X X
C1GARD51AT1 13T03 X X X
Corrosion Protection (indoor coil / outdoor coil) Factory O O O O O
CONTROLS
Blower Proving Switch C1SNSR35FF1 53W65 OX OX OX OX OX
Commercial Controls CPC Einstein Integration Factory O O O O OX
Prodigy® Control System - BACnet® Module - C0CTRL60AE1L 59W51 OX OX OX OX OX
Prodigy® Control System - LonTalk® Module - C0CTRL65FF1 54W27 OX OX OX OX OX
Novar®2051 - E0CTRL30A1 64W72 OX OX OX OX OX
Novar®LSE Factory O O O O O
L Connection®Building Automation System - - - X X X X X
Dirty Filter Switch E1SNSR55AP1 53W66 OX OX OX OX OX
General Purpose Control Kit E1GPBK30C1 13J78 XXXXX
Fresh Air Tempering C1SNSR75AD1 58W63 OX OX OX OX OX
1SmartAirow™ (Supply and Ventilation Airow Control) Factory O O O
Smoke Detector - Supply or Return (Power board and one sensor) C1SNSR44AP1 53W78 OX OX OX OX OX
Smoke Detector - Supply and Return (Power board and two sensors) C1SNSR43AP1 53W79 OX OX OX OX OX
ELECTRICAL
Voltage 208/230V - 1 phase Factory 2O 2O 2O
60 hz 208/230V - 3 phase Factory O O O O O
460V - 3 phase Factory O O O O O
575V - 3 phase Factory O O O O O
HACR Circuit Breakers Factory O O O O O
Disconnect Switch 80 amp - T1DISC080AH1 20W23 OX OX
80 amp - T1DISC080NH1 20W26 OX OX OX
GFI Service
Outlets
15 amp non-powered, eld-wired (208/230V, 460V only) - LTAGFIK10/15 74M70 OX OX OX OX OX
20 amp non-powered, eld-wired (575V only) - C1GFCI20FF1 67E01 OX OX OX OX OX
Weatherproof Cover for GFI C1GFCI99FF1 10C89 X X X X X
Phase/Voltage Detection - 3 Phase Models Only Factory O O O O O
1 Available for 3, 4 and 5 ton high efciency models equipped with direct drive blower and Economizer.
NOTE - Smart Airow®is not available on units with the High Gas Heat (4 Stage) option on LGH060H4E high efciency, direct drive, Low NOx, models.
2 208/230-1ph not available on belt drive units.
NOTE - Catalog and model numbers shown are for ordering eld installed accessories.
OX - Congure To Order (Factory Installed) or Field Installed
O = Congure To Order (Factory Installed)
X = Field Installed

Page 4
OPTIONS / ACCESSORIES
Item Model
Number
Catalog
Number
Unit Model Number
036 048 060 072 074
ECONOMIZER
Standard Economizer With Outdoor Air Hood (Sensible Control) (Not for Title 24)
Standard Economizer - Includes Barometric Relief Dampers
and Exhaust Hood
E1ECON30A-2- 90W59 OX OX OX OX OX
Standard Economizer - Includes Barometric Relief Dampers
and Exhaust Hood and Power Exhaust
Factory O O O O O
Standard Economizer - No Exhaust Option Factory O O O O O
High Performance Economizer With Outdoor Air Hood (Sensible Control)
(Approved for California Title 24 Building Standards / AMCA Class 1A Certied)
High Performance Economizer - Includes Barometric Relief
Dampers with Exhaust Hood
E1ECON17A-1 10U54 OX OX OX OX OX
High Performance Economizer - No Exhaust Option Factory O O O O O
Economizer Accessories
Horizontal Economizer Conversion Kit T1HECK00AN1 17W45 X X X X X
Economizer Controls (Not for Title 24)
Differential Enthalpy Order 2 - C1SNSR64FF1 53W64 OX OX OX OX OX
Sensible Control Sensor is Furnished Factory O O O O O
Single Enthalpy C1SNSR64FF1 53W64 OX OX OX OX OX
Global Control Sensor Field Provided Factory O O O O O
Building Pressure Control E1GPBK20C1 13J77 XXXXX
OUTDOOR AIR
Outdoor Air Dampers With Outdoor Air Hood
Motorized C1DAMP21A-1 15D17 OX OX OX OX OX
Manual C1DAMP11A-2 15D18 OX OX OX OX OX
POWER EXHAUST FAN
Standard Static
Note: Factory installed Power
Exhaust Fan includes Exhaust
Hood. Barometric Relief Dampers
without Exhaust Hood are required
(order separately).
Note: Field installed Power Exhaust
Fans do not include Exhaust Hood.
Barometric Relief Dampers with
Exhaust Hood are required (order
separately).
208/230V-1 or 3ph - C1PWRE10A-1P 79W87 OX OX OX OX OX
460V-3ph - C1PWRE10A-1G 79W88 OX OX OX OX OX
575V-3ph - C1PWRE10A-1J 79W89 OX OX OX OX OX
BAROMETRIC RELIEF
1 Barometric Relief Dampers with Exhaust Hood C1DAMP50A-1- 74W38 X X X X X
2 Barometric Relief Dampers without Exhaust Hood C1DAMP50A-2- 72W89 X X X X X
HUMIDITROL®CONDENSER REHEAT OPTION
Humiditrol Dehumidication Option Factory O O O O O
Humidity Sensor Kit, Remote mounted (required) C0SNSR31AE-1 17M50 X X X X X
1 Required when Economizer is factory installed (no exhaust option) with eld installed Power Exhaust Fan option.
2 Required when Economizer is factory installed with factory installed Power Exhaust Fan option.
NOTE - Catalog and model numbers shown are for ordering eld installed accessories.
OX - Congure To Order (Factory Installed) or Field Installed
O = Congure To Order (Factory Installed)
X = Field Installed

Page 5
OPTIONS / ACCESSORIES
Item Model
Number
Catalog
Number
Unit Model Number
036 048 060 072 074
INDOOR AIR QUALITY
Air Filters
Healthy Climate®High Efciency
Air Filters
Order 4 per unit
MERV 8 (16 x 20 x 2 in.) - C1FLTR15A-1- 54W20 OX OX
MERV 13 (16 x 20 x 2 in.) - T1FLTR40A-1- 52W37 OX OX
MERV 8 (20 x 20 x 2 in.) - C1FLTR15D-1- 54W21 OX OX OX
MERV 13 (20 x 20 x 2 in.) - C1FLTR40D-1- 52W39 OX OX OX
Replaceable Media Filter With
Metal Mesh Frame
(includes non-pleated lter media)
16 x 20 x 2 in. (Order 4) - K1FLTR30A-1 39W09 X X
20 x 20 x 2 in. (Order 4) - K1FLTR30A-2 44N60 X X X
Indoor Air Quality (CO2) Sensors
Sensor - Wall-mount, off-white plastic cover with LCD display C0SNSR50AE1L 77N39 X X X X X
Sensor - Wall-mount, off-white plastic cover, no display C0SNSR52AE1L 87N53 X X X X X
Sensor - Black plastic case with LCD display, rated for plenum
mounting
C0SNSR51AE1L 87N52 X X X X X
Sensor - Wall-mount, black plastic case, no display, rated for plenum
mounting
C0MISC19AE1 87N54 X X X X X
CO2 Sensor Duct Mounting Kit - for downow applications C0MISC19AE1- 85L43 X X X X X
Aspiration Box - for duct mounting non-plenum rated CO2
sensors (87N53 or 77N39)
C0MISC16AE1- 90N43 X X X X X
UVC Germicidal Lamps
1Healthy Climate®UVC Light Kit (208/230v-1ph) C1UVCL10AN1- 50W90 OX OX OX OX OX
ROOF CURBS
Hybrid Roof Curbs, Downow
8 in. height C1CURB70A-1 11F50 XXXXX
14 in. height C1CURB71A-1 11F51 X X X X X
18 in. height C1CURB72A-1 11F52 X X X X X
24 in. height C1CURB73A-1 11F53 X X X X X
Adjustable Pitched Curb
14 in. height C1CURB55AT1 43W27 X X X X X
Transition Curb
Matches Energence® 036-074 Units to existing L Series®Curbs E1CURB60A-1 20W06 X X X X X
CEILING DIFFUSERS
Step-Down - Order one RTD9-65S 13K60 X X X
RTD11-95S 13K61 X X
Flush - Order one FD9-65S 13K55 X X X
FD11-95S 13K56 X X
Transitions (Supply and Return) - Order one T1TRAN10AN1 17W53 X X X
T1TRAN20N-1 17W54 X X
1 Lamps operate on 110-230V single-phase power supply. Step-down transformer may be ordered separately for 460V and 575V units. Alternately, 110V power supply
may be used to directly power the UVC ballast(s).
NOTE - Catalog and model numbers shown are for ordering eld installed accessories.
OX - Congure To Order (Factory Installed) or Field Installed
O = Congure To Order (Factory Installed)
X = Field Installed

Page 6
SPECIFICATIONS - DIRECT DRIVE
General Data Nominal Tonnage 3 Ton 4 Ton 5 Ton
Model Number LCH036H4E LCH048H4E LCH060H4E
Efciency Type High High High
Blower Type Multi-Speed
Direct Drive
Multi-Speed
Direct Drive
Multi-Speed
Direct Drive
Cooling
Performance
Gross Cooling Capacity - Btuh 36,600 50,100 61,600
1 Net Cooling Capacity - Btuh 36,000 49,000 60,000
AHRI Rated Air Flow - cfm 1200 1600 1750
Total Unit Power - kW 2.8 3.8 4.7
1 SEER (Btuh/Watt) - 208/230V-1-3ph 18.0 17.6 17.1
1 SEER (Btuh/Watt) - 460V-3ph, 575V-3ph 17.0 17.0 17.0
1 EER (Btuh/Watt) - 208/230V-1-3ph 12.8 12.8 12.7
1 EER (Btuh/Watt) - 460V-3ph, 575V-3ph 12.5 12.8 12.7
AHRI Reference No. 208/230V-1 ph 3607616 3607631 3607645
208/230V-3 ph 3607617 3607633 3607646
460V-3 ph 3607618 3607634 3607647
575V-3 ph 3607619 3607659 3607648
Refrigerant
Charge
Refrigerant Type R-410A R-410A R-410A
Environ™ Coil System 4 lbs. 5 oz. 6 lbs. 4 oz. 8 lbs. 0 oz.
Conventional Fin/Tube Coil 8 lbs. 8 oz. 11 lbs. 2 oz. 14 lbs. 0 oz.
Environ™ Coil System With Humiditrol® Dehumidication Option 5 lbs. 2 oz. 6 lbs. 8 oz. 8 lbs. 0 oz.
Conventional Fin/Tube With Humiditrol® Dehumidication Option 9 lbs. 3 oz. 12 lbs. 4 oz. 16 lbs. 0 oz.
Electric Heat Available 7.5 and 15 kW 7.5 and 15 kW 7.5, 15 and 22.5 kW
Compressor Type (one per unit) Two-Stage Scroll Two-Stage Scroll Two-Stage Scroll
Outdoor Coil
Environ™
(Fin/Tube)
Net face area (total) - sq. ft. 11.70 (15.60) 14.50 (15.60) 17.80 (19.30)
Tube diameter - in. 0.71 (3/8) 0.71 (3/8) 0.71 (3/8)
Number of rows 1 (1.5) 1 (2) 1 (2)
Fins per inch 20 (20) 20 (20) 20 (20)
Outdoor Coil
Fans
Motor - (No.) horsepower (1) 1/3 (ECM) (1) 1/3 (ECM) (1) 1/3 (ECM)
Motor rpm 715-810 645-810 930-1100
Total Motor Input - watts 112-160 89-165 230-350
Diameter - (No.) in. (1) 24 (1) 24 (1) 24
Number of blades 3 3 3
Total air volume - cfm 3400-3795 2910-3675 4315-4980
Indoor
Coil
Net face area (total) - sq. ft. 7.78 7.78 9.72
Tube diameter - in. 3/8 3/8 3/8
Number of rows 344
Fins per inch 14 14 14
Drain connection (Number) and size - in. (1) 1 NPT (1) 1 NPT (1) 1 NPT
Expansion device type Balanced Port Thermostatic Expansion Valve, removable power head
3Indoor
Blower
Nominal motor HP 0.50 (ECM) 0.75 (ECM) 1 (ECM)
Blower wheel nominal diameter x width - in. (1) 10 X 10 (1) 10 X 10 (1) 11 X 10
Filters Type of lter disposable
Number and size - in. (4) 16 X 20 X 2 (4) 20 x 20 x 2
Electrical characteristics 208/230V - 60 hz - 1 phase
208/230V, 460V, or 575V - 60 hz -3 phase
NOTE - Net capacity includes evaporator blower motor heat deduction. Gross capacity does not include evaporator blower motor heat deduction.
1 AHRI Certied to AHRI Standard 210/240: 95°F outdoor air temperature and 80°F db/67°F wb entering evaporator air; minimum external duct static pressure.
2 Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable output of
motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep within the
service factor limitations outlined on the motor nameplate.

Page 7
SPECIFICATIONS - BELT DRIVE
General Data Nominal Tonnage 3 Ton 4 Ton 5 Ton 6 Ton 6 Ton
Model Number LCH036S4T LCH048S4T LCH060S4T LCH072H4B LCH074H4T
Efciency Type Standard Standard Standard High High
Blower Type Two Speed
Belt Drive
Two Speed
Belt Drive
Two Speed
Belt Drive
Single Speed
Belt Drive
Two Speed
Belt Drive
Cooling
Performance
Gross Cooling Capacity - Btuh 35,800 49,100 61,600 73,500 72,000
Net Cooling Capacity - Btuh 1 34,800 1 48,000 1 60,000 2 72,000 2 69,000
AHRI Rated Air Flow - cfm 1200 1600 1750 1920 2100
Total Unit Power - kW 3.0 3.9 4.8 6.0 5.7
SEER (Btuh/Watt) 115.0 115.0 115.5 - - - - - -
EER (Btuh/Watt) 111.6 111.6 112.3 212.0 2 12.0
IEER (Btuh/Watt) - - - - - - - - - 213.5 2 16.0
AHRI Reference No. 208/230V-3 ph 3607621 3607639 3607653 - - - - - -
460V-3 ph 3607622 3607640 3607654 - - - - - -
575V-3 ph 3607623 3607641 3607655 - - - - - -
All voltages - - - - - - - - - 202088939 202089006
Refrigerant
Charge
Refrigerant Type R-410A R-410A R-410A R-410A R-410A
Environ™ Coil System 4 lbs. 5 oz. 6 lbs. 4 oz. 8 lbs. 0 oz. 7 lbs. 8 oz. 7 lbs. 2 oz.
Conventional Fin/Tube Coil 8 lbs. 8 oz. 11 lbs. 2 oz. 14 lbs. 0 oz. 13 lbs. 12 oz. 13 lbs. 11oz
Environ™ Coil System With Humiditrol® 5 lbs. 2 oz. 6 lbs. 8 oz. 8 lbs. 0 oz. 9 lbs. 0 oz. 8 lbs. 15 oz.
Conventional Fin/Tube With Humiditrol® 9 lbs. 3 oz. 12 lbs. 4 oz. 16 lbs. 0 oz. 15 lbs. 3 oz. 15 lbs. 11oz
Electric Heat Available 7.5 and 15 kW 7.5 and 15 kW 7.5, 15 and
22.5 kW
7.5, 15, 22.5 and
30 kW
7.5, 15, 22.5
and 30 kW
Compressor Type (one per unit) Two-Stage Scroll Two-Stage Scroll Two-Stage Scroll Scroll Two-Stage Scroll
Outdoor Coil
Environ™
(Fin/Tube)
Net face area (total) - sq. ft. 11.70 (15.60) 14.5 (15.60) 17.80 (19.30) 17.80 (19.30) 17.80 (19.30)
Tube diameter - in. 0.71 (3/8) 0.71 (3/8) 0.71 (3/8) 0.71 (3/8) 0.71 (3/8)
Number of rows 1 (1.5) 1 (2) 1 (2) 1 (2) 1 (2)
Fins per inch 20 (20) 20 (20) 20 (20) 20 (20) 20 (20)
Outdoor Coil
Fans
Motor - (No.) horsepower (1) 1/6 (PSC) (1) 1/4 (PSC) (1) 1/3 (PSC) (1) 1/3 (PSC) (1) 1/3 (PSC)
Motor rpm 825 825 1075 1075 1075
Total Motor Input - watts 168 230 410 410 375
Diameter - (No.) in. (1) 24 (1) 24 (1) 24 (1) 24 (1) 24
Number of blades 3 3 3 3 3
Total air volume - cfm 3000 3300 4800 4800 4800
Indoor
Coil
Net face area (total) - sq. ft. 7.78 7.78 9.72 9.72 9.72
Tube diameter - in. 3/8 3/8 3/8 3/8 3/8
Number of rows 3 4 4 4 4
Fins per inch 14 14 14 14 14
Drain connection (Number) and size - in. (1) 1 NPT (1) 1 NPT (1) 1 NPT (1) 1 NPT (1) 1 NPT
Expansion device type Balanced Port Thermostatic Expansion Valve, removable power head
5Indoor
Blower
and Drive
Selection
No. of Speeds 2 2 2 1 2
Nominal
motor HP
Low static 0.75 0.75 1 1 1
High static 1 2 2 2 2
Maximum
usable motor
output
(US Only)
Low static 0.86 0.86 1.15 1.15 1.15
High static 1.15 2.3 2.3 2.3 2.3
Motor - Drive kit number A01
low 449-673
high 673-1010
A05
low 598-897
high 897-1346
A02
low 497-673
high 745-1117
A06
low 714-953
high 1071-1429
A03
low 555-833
high 833-1250
A07
low 808-1032
high 1212-1548
AA01
522 - 784 rpm
AA02
632 - 875 rpm
AA03
798 - 1105 rpm
AA01
522-784 rpm
AA02
632-875 rpm
AA03
798-1105 rpm
Blower wheel nominal diameter x width - in. (1) 10 X 10 (1) 10 X 10 (1) 10 X 10 (1) 15 X 9 (1) 15 X 9
Filters Type of lter disposable
Number and size - in. (4) 16 X 20 X 2 (4) 20 X 20 X 2
Electrical characteristics 208/230V, 460V, or 575V - 60 hz - 3 phase
NOTE - Net capacity includes evaporator blower motor heat deduction. Gross capacity does not include evaporator blower motor heat deduction.
1, 2 AHRI Certied to AHRI Standard 1210/240 or 2 340/360: 95°F outdoor air temperature and 80°F db/67°F wb entering evaporator air; minimum external duct static
pressure.
3 Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable output of
motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep within the
service factor limitations outlined on the motor nameplate.

Page 8
BLOWER DATA - DIRECT DRIVE - 3 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE. FOR ALL UNITS ADD: 1 - Any factory installed options air resistance (heat section, economizer, etc.). 2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.). See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data. DOWNFLOW
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 785 38 407 969 68 468 1152 98 529 1301 140 581 1449 182 634 1571 236 683 1693 290 732 1799 352 770 1904 414 809
0.1 720 44 475 919 74 522 1117 104 569 1264 150 626 1411 195 684 1539 248 724 1667 301 765 1772 366 805 1877 431 844
0.2 645 50 550 851 83 593 1056 116 637 1218 161 680 1380 205 722 1509 259 762 1638 313 802 1744 380 840 1849 446 879
0.3 570 56 620 793 90 651 1016 124 681 1175 172 730 1334 220 779 1468 274 813 1601 328 846 1708 396 883 1815 464 920
0.4 505 60 678 731 97 712 956 135 746 1130 182 781 1303 229 815 1434 286 852 1564 342 889 1676 410 920 1787 477 951
0.5 432 65 740 663 105 775 895 145 810 1076 194 839 1257 243 867 1396 298 895 1534 353 923 1647 421 952 1759 489 981
0.6 - - - - - - - - - - - - - - - - - - 855 152 852 1033 204 884 1211 256 917 1351 312 944 1490 369 971 1604 437 997 1718 505 1024
0.7 - - - - - - - - - - - - - - - - - - 792 163 916 986 213 933 1180 264 949 1320 321 975 1460 379 1002 1575 447 1026 1690 515 1050
0.8 - - - - - - - - - - - - - - - - - - 734 173 975 934 224 985 1134 275 995 1275 334 1021 1416 393 1046 1533 460 1067 1649 527 1088
0.9 - - - - - - - - - - - - - - - - - - 674 183 1034 881 234 1037 1088 286 1039 1230 346 1064 1371 406 1088 1490 471 1106 1608 537 1123
1.0 - - - - - - - - - - - - - - - - - - 613 193 1095 820 246 1094 1026 300 1093 1184 357 1104 1342 414 1115 1448 480 1140 1553 547 1165
1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 980 309 1131 1139 367 1142 1297 425 1154 1404 488 1173 1511 551 1192
1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1253 436 1190 1355 495 1207 1456 554 1225
HORIZONTAL
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 796 43 372 975 64 447 1155 85 524 1302 126 560 1448 168 597 1566 214 639 1684 260 680 1786 323 720 1888 386 761
0.1 709 50 461 909 75 512 1110 101 564 1254 143 613 1398 185 662 1523 231 695 1649 277 729 1754 344 769 1858 411 810
0.2 617 57 553 828 88 591 1040 118 629 1204 156 664 1368 194 698 1492 243 734 1616 291 771 1721 358 808 1826 424 845
0.3 503 64 662 747 97 668 992 131 676 1151 172 722 1310 212 768 1442 260 794 1574 308 820 1681 374 853 1787 440 887
0.4 419 69 747 671 107 746 924 146 747 1095 185 782 1266 225 818 1398 275 844 1530 325 870 1640 389 899 1749 454 927
0.5 323 75 843 589 117 832 857 159 821 1039 198 844 1221 237 867 1359 287 888 1496 337 909 1598 403 941 1701 470 973
0.6 - - - - - - - - - - - - - - - - - - 817 165 871 990 208 900 1162 252 929 1296 306 954 1431 360 979 1546 421 995 1662 481 1010
0.7 - - - - - - - - - - - - - - - - - - 747 176 957 933 219 966 1118 262 974 1264 314 987 1410 367 1000 1523 427 1016 1636 487 1032
0.8 - - - - - - - - - - - - - - - - - - 700 181 1026 886 226 1022 1073 271 1018 1216 327 1035 1359 383 1051 1469 442 1066 1579 501 1081
0.9 - - - - - - - - - - - - - - - - - - 643 187 1110 829 235 1091 1015 283 1073 1161 341 1087 1307 399 1101 1409 456 1118 1510 513 1136
1.0 - - - - - - - - - - - - - - - - - - 592 190 1197 781 241 1154 970 291 1113 1114 352 1130 1258 413 1147 1355 467 1161 1452 520 1176
1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 915 300 1162 1067 362 1171 1219 424 1180 1312 473 1192 1405 522 1204
1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1168 437 1223 1248 480 1235 1329 523 1246

Page 9
BLOWER DATA - DIRECT DRIVE - 4 TON BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE. FOR ALL UNITS ADD: 1 - Any factory installed options air resistance (heat section, economizer, etc.). 2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.). See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data. DOWNFLOW
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1046 77 485 1257 134 565 1468 191 646 1639 271 715 1810 351 784 1960 445 837 2109 539 890 2251 674 947 2393 810 1004
0.1 992 85 543 1211 145 619 1430 205 695 1609 285 755 1788 365 814 1937 463 870 2086 561 925 2227 691 977 2367 822 1029
0.2 926 95 612 1166 154 669 1405 214 727 1580 299 793 1755 384 859 1909 482 909 2063 581 959 2200 708 1008 2336 835 1056
0.3 883 101 657 1125 164 715 1367 227 774 1551 311 831 1734 396 888 1891 495 934 2048 593 980 2181 719 1028 2314 844 1076
0.4 818 111 724 1074 175 772 1329 240 820 1515 327 875 1701 414 930 1859 515 975 2017 617 1021 2147 737 1064 2276 857 1107
0.5 752 121 791 1022 187 828 1291 253 865 1485 339 911 1679 425 957 1837 529 1003 1994 632 1049 2120 749 1090 2245 866 1131
0.6 - - - - - - - - - - - - - - - - - - 1253 265 908 1450 354 952 1646 442 996 1809 544 1036 1972 646 1076 2094 760 1114 2215 873 1153
0.7 - - - - - - - - - - - - - - - - - - 1202 282 965 1408 370 999 1613 458 1034 1777 560 1071 1941 662 1109 2063 771 1141 2185 879 1174
0.8 - - - - - - - - - - - - - - - - - - 1164 294 1006 1372 383 1038 1580 473 1070 1745 574 1104 1910 676 1138 2025 781 1171 2139 886 1204
0.9 - - - - - - - - - - - - - - - - - - 1126 306 1046 1337 396 1075 1548 487 1105 1714 587 1135 1880 687 1165 1987 788 1198 2094 889 1230
1.0 - - - - - - - - - - - - - - - - - - 1081 320 1092 1298 410 1115 1515 500 1138 1675 599 1169 1834 699 1200 1941 794 1227 2048 889 1254
1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1476 514 1174 1632 609 1201 1788 704 1229 1896 795 1251 2003 886 1274
1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1728 702 1256 1835 790 1277 1942 878 1298
HORIZONTAL
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1023 78 452 1234 131 536 1445 183 621 1611 251 688 1776 319 754 1910 400 800 2043 480 846 2192 613 904 2340 746 963
0.1 970 82 529 1192 137 596 1414 192 664 1586 261 722 1757 330 780 1902 427 837 2048 523 893 2189 640 942 2330 758 991
0.2 909 86 590 1146 144 647 1383 201 705 1553 275 764 1723 349 824 1876 444 873 2028 540 923 2170 659 970 2312 779 1018
0.3 829 95 675 1084 154 718 1339 213 761 1520 287 807 1701 361 853 1853 459 903 2005 557 953 2138 673 1001 2271 789 1049
0.4 772 104 734 1032 165 774 1293 226 814 1477 304 859 1661 382 904 1818 480 949 1975 579 993 2098 690 1039 2222 802 1084
0.5 688 118 818 967 178 841 1247 238 864 1439 317 902 1631 396 940 1787 498 986 1943 599 1032 2066 704 1069 2189 809 1106
0.6 - - - - - - - - - - - - - - - - - - 1202 249 910 1400 330 944 1597 411 978 1758 512 1018 1920 613 1059 2035 715 1095 2150 817 1132
0.7 - - - - - - - - - - - - - - - - - - 1146 265 967 1355 345 990 1565 426 1014 1727 527 1053 1889 629 1092 1997 726 1125 2105 822 1158
0.8 - - - - - - - - - - - - - - - - - - 1085 280 1021 1302 362 1040 1520 443 1060 1685 544 1095 1849 646 1130 1950 737 1160 2051 828 1191
0.9 - - - - - - - - - - - - - - - - - - 1029 292 1064 1255 376 1085 1481 460 1106 1643 560 1137 1805 660 1167 1898 745 1194 1991 830 1222
1.0 - - - - - - - - - - - - - - - - - - 961 308 1114 1207 389 1126 1456 471 1137 1601 571 1173 1746 672 1209 1836 751 1230 1926 829 1251
1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1416 488 1185 1549 581 1213 1682 675 1241 1774 750 1258 1867 824 1276
1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1570 652 1268 1675 732 1286 1780 812 1305

Page 10
BLOWER DATA - DIRECT DRIVE - 4 TON BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE. FOR ALL UNITS ADD: 1 - Any factory installed options air resistance (heat section, economizer, etc.). 2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.). See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data. DOWNFLOW
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1046 77 485 1257 134 565 1468 191 646 1639 271 715 1810 351 784 1960 445 837 2109 539 890 2251 674 947 2393 810 1004
0.1 992 85 543 1211 145 619 1430 205 695 1609 285 755 1788 365 814 1937 463 870 2086 561 925 2227 691 977 2367 822 1029
0.2 926 95 612 1166 154 669 1405 214 727 1580 299 793 1755 384 859 1909 482 909 2063 581 959 2200 708 1008 2336 835 1056
0.3 883 101 657 1125 164 715 1367 227 774 1551 311 831 1734 396 888 1891 495 934 2048 593 980 2181 719 1028 2314 844 1076
0.4 818 111 724 1074 175 772 1329 240 820 1515 327 875 1701 414 930 1859 515 975 2017 617 1021 2147 737 1064 2276 857 1107
0.5 752 121 791 1022 187 828 1291 253 865 1485 339 911 1679 425 957 1837 529 1003 1994 632 1049 2120 749 1090 2245 866 1131
0.6 - - - - - - - - - - - - - - - - - - 1253 265 908 1450 354 952 1646 442 996 1809 544 1036 1972 646 1076 2094 760 1114 2215 873 1153
0.7 - - - - - - - - - - - - - - - - - - 1202 282 965 1408 370 999 1613 458 1034 1777 560 1071 1941 662 1109 2063 771 1141 2185 879 1174
0.8 - - - - - - - - - - - - - - - - - - 1164 294 1006 1372 383 1038 1580 473 1070 1745 574 1104 1910 676 1138 2025 781 1171 2139 886 1204
0.9 - - - - - - - - - - - - - - - - - - 1126 306 1046 1337 396 1075 1548 487 1105 1714 587 1135 1880 687 1165 1987 788 1198 2094 889 1230
1.0 - - - - - - - - - - - - - - - - - - 1081 320 1092 1298 410 1115 1515 500 1138 1675 599 1169 1834 699 1200 1941 794 1227 2048 889 1254
1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1476 514 1174 1632 609 1201 1788 704 1229 1896 795 1251 2003 886 1274
1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1728 702 1256 1835 790 1277 1942 878 1298
HORIZONTAL
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1023 78 452 1234 131 536 1445 183 621 1611 251 688 1776 319 754 1910 400 800 2043 480 846 2192 613 904 2340 746 963
0.1 970 82 529 1192 137 596 1414 192 664 1586 261 722 1757 330 780 1902 427 837 2048 523 893 2189 640 942 2330 758 991
0.2 909 86 590 1146 144 647 1383 201 705 1553 275 764 1723 349 824 1876 444 873 2028 540 923 2170 659 970 2312 779 1018
0.3 829 95 675 1084 154 718 1339 213 761 1520 287 807 1701 361 853 1853 459 903 2005 557 953 2138 673 1001 2271 789 1049
0.4 772 104 734 1032 165 774 1293 226 814 1477 304 859 1661 382 904 1818 480 949 1975 579 993 2098 690 1039 2222 802 1084
0.5 688 118 818 967 178 841 1247 238 864 1439 317 902 1631 396 940 1787 498 986 1943 599 1032 2066 704 1069 2189 809 1106
0.6 - - - - - - - - - - - - - - - - - - 1202 249 910 1400 330 944 1597 411 978 1758 512 1018 1920 613 1059 2035 715 1095 2150 817 1132
0.7 - - - - - - - - - - - - - - - - - - 1146 265 967 1355 345 990 1565 426 1014 1727 527 1053 1889 629 1092 1997 726 1125 2105 822 1158
0.8 - - - - - - - - - - - - - - - - - - 1085 280 1021 1302 362 1040 1520 443 1060 1685 544 1095 1849 646 1130 1950 737 1160 2051 828 1191
0.9 - - - - - - - - - - - - - - - - - - 1029 292 1064 1255 376 1085 1481 460 1106 1643 560 1137 1805 660 1167 1898 745 1194 1991 830 1222
1.0 - - - - - - - - - - - - - - - - - - 961 308 1114 1207 389 1126 1456 471 1137 1601 571 1173 1746 672 1209 1836 751 1230 1926 829 1251
1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1416 488 1185 1549 581 1213 1682 675 1241 1774 750 1258 1867 824 1276
1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1570 652 1268 1675 732 1286 1780 812 1305

Page 11
BLOWER DATA - DIRECT DRIVE - 5 TON BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE. FOR ALL UNITS ADD: 1 - Any factory installed options air resistance (heat section, economizer, etc.). 2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.). See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data. DOWNFLOW
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1102 76 420 1324 143 510 1545 211 601 1740 302 667 1934 393 734 2096 519 797 2258 645 860 2396 791 910 2534 938 959
0.1 1038 85 484 1284 153 559 1529 221 633 1722 315 698 1914 410 763 2078 535 823 2242 660 882 2378 810 934 2514 960 986
0.2 975 94 546 1235 165 611 1495 236 677 1692 332 737 1888 429 798 2057 553 851 2225 677 905 2363 825 954 2501 973 1003
0.3 911 104 603 1192 175 654 1473 245 706 1672 343 763 1871 441 820 2040 566 874 2208 692 928 2348 839 974 2488 987 1020
0.4 847 114 657 1143 187 702 1439 259 747 1642 359 800 1845 458 852 2015 585 904 2185 712 956 2327 858 1000 2469 1005 1044
0.5 784 124 708 1095 198 747 1406 273 785 1613 374 835 1819 475 884 1994 600 931 2168 726 977 2309 874 1022 2450 1022 1066
0.6 - - - - - - - - - - - - - - - - - - 1372 285 822 1583 388 868 1793 490 915 1969 617 959 2145 743 1004 2288 890 1046 2431 1037 1087
0.7 - - - - - - - - - - - - - - - - - - 1339 297 856 1553 401 900 1767 505 944 1945 633 987 2122 760 1029 2267 906 1068 2411 1051 1108
0.8 - - - - - - - - - - - - - - - - - - 1294 313 899 1518 416 936 1741 519 973 1920 647 1013 2099 776 1054 2246 920 1090 2392 1064 1127
0.9 - - - - - - - - - - - - - - - - - - 1249 327 937 1478 432 974 1706 537 1010 1891 663 1043 2076 790 1077 2221 934 1113 2366 1078 1150
1.0 - - - - - - - - - - - - - - - - - - 1193 343 980 1437 446 1008 1680 549 1036 1867 676 1067 2053 803 1098 2200 945 1132 2347 1087 1166
1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1649 562 1066 1834 691 1097 2019 821 1129 2164 961 1162 2308 1100 1194
1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1984 836 1157 2133 971 1184 2282 1106 1211
HORIZONTAL
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1129 85 418 1343 146 512 1556 208 606 1740 306 679 1923 405 752 2084 530 812 2245 655 872 2377 807 927 2508 959 982
0.1 1063 88 464 1295 154 550 1527 220 635 1715 318 705 1903 417 776 2070 546 835 2237 675 895 2368 823 948 2498 972 1002
0.2 984 95 534 1234 166 607 1483 237 680 1681 335 743 1878 432 807 2046 562 863 2214 691 920 2347 842 971 2479 993 1023
0.3 917 103 606 1178 179 665 1438 255 724 1645 351 780 1852 447 836 2018 580 894 2183 712 952 2321 862 997 2459 1012 1043
0.4 862 112 681 1128 192 725 1393 272 768 1604 370 823 1814 468 878 1987 598 927 2160 728 975 2298 881 1021 2435 1034 1067
0.5 818 124 760 1091 204 779 1364 283 798 1576 383 851 1788 482 905 1963 612 951 2137 742 997 2274 898 1044 2410 1055 1090
0.6 - - - - - - - - - - - - - - - - - - 1319 300 842 1541 398 886 1762 495 931 1934 628 979 2106 761 1026 2244 919 1071 2381 1076 1115
0.7 - - - - - - - - - - - - - - - - - - 1274 317 885 1499 415 926 1724 513 967 1900 646 1010 2075 779 1054 2219 934 1093 2362 1089 1131
0.8 - - - - - - - - - - - - - - - - - - 1245 328 914 1466 429 957 1686 531 1001 1865 663 1040 2044 796 1080 2188 951 1117 2332 1106 1154
0.9 - - - - - - - - - - - - - - - - - - 1200 344 957 1424 446 995 1647 547 1032 1830 679 1069 2013 812 1105 2154 968 1143 2294 1124 1181
1.0 - - - - - - - - - - - - - - - - - - 1155 360 1000 1382 461 1030 1609 563 1061 1796 695 1095 1983 826 1129 2124 980 1164 2264 1134 1200
1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1570 577 1087 1753 712 1124 1936 847 1162 2086 994 1189 2235 1141 1216
1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1905 859 1182 2041 1003 1213 2176 1146 1244

Page 12
BLOWER DATA - BELT DRIVE - 3 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data.
DOWNFLOW
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
700 447 0.09 517 0.12 589 0.15 663 0.17 739 0.19 815 0.2 883 0.23 938 0.25 988 0.27 1039 0.29
800 465 0.1 534 0.14 605 0.17 678 0.19 753 0.21 825 0.23 890 0.25 946 0.27 996 0.3 1047 0.32
900 486 0.12 554 0.16 623 0.2 695 0.22 767 0.23 836 0.25 897 0.28 953 0.3 1004 0.33 1055 0.35
1000 508 0.15 576 0.19 643 0.22 713 0.24 783 0.26 848 0.28 907 0.3 961 0.33 1011 0.36 1062 0.38
1100 533 0.18 599 0.22 665 0.25 733 0.27 800 0.28 863 0.31 919 0.34 971 0.36 1020 0.39 1070 0.41
1200 560 0.21 625 0.25 689 0.28 755 0.3 820 0.32 879 0.34 932 0.37 983 0.4 1031 0.43 1079 0.45
1300 591 0.24 654 0.28 716 0.31 779 0.33 841 0.35 897 0.38 948 0.41 996 0.44 1044 0.47 1091 0.49
1400 631 0.26 690 0.3 748 0.34 807 0.36 864 0.39 916 0.42 964 0.46 1011 0.49 1058 0.51 1105 0.54
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
700 1088 0.31 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
800 1098 0.34 1144 0.36 1185 0.39 1224 0.42 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
900 1106 0.37 1152 0.4 1193 0.43 1232 0.46 1269 0.49 1305 0.52 1340 0.55 1376 0.59 - - - - - - - - - - - -
1000 1111 0.41 1157 0.43 1199 0.47 1238 0.5 1276 0.53 1311 0.56 1347 0.6 1382 0.63 1417 0.67 1452 0.7
1100 1118 0.44 1163 0.47 1206 0.51 1245 0.54 1282 0.58 1318 0.61 1353 0.65 1388 0.68 1423 0.72 1458 0.75
1200 1127 0.48 1171 0.52 1213 0.55 1252 0.59 1289 0.62 1324 0.66 1358 0.7 1393 0.73 1428 0.77 1463 0.81
1300 1137 0.53 1181 0.56 1221 0.6 1259 0.64 1296 0.68 1330 0.71 1364 0.75 1398 0.78 1432 0.82 1467 0.86
1400 1150 0.57 1191 0.61 1231 0.65 1268 0.69 1303 0.73 1337 0.77 1371 0.8 1404 0.84 1437 0.88 1473 0.91

Page 13
BLOWER DATA - BELT DRIVE - 3 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data.
HORIZONTAL
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
700 445 0.08 516 0.11 591 0.13 670 0.15 753 0.16 820 0.19 870 0.22 918 0.24 969 0.27 1021 0.29
800 463 0.09 534 0.12 608 0.14 685 0.16 766 0.18 830 0.21 878 0.24 926 0.27 977 0.29 1030 0.32
900 485 0.11 554 0.14 627 0.16 703 0.18 780 0.21 841 0.23 888 0.27 935 0.3 986 0.32 1039 0.35
1000 509 0.13 578 0.16 649 0.19 722 0.21 796 0.23 854 0.26 900 0.29 947 0.33 997 0.35 1048 0.38
1100 537 0.16 605 0.19 674 0.21 744 0.24 813 0.26 868 0.29 913 0.33 959 0.36 1008 0.39 1059 0.41
1200 567 0.19 633 0.22 700 0.24 768 0.27 833 0.3 884 0.33 928 0.37 974 0.4 1022 0.43 1071 0.45
1300 599 0.22 664 0.25 729 0.28 793 0.3 853 0.33 902 0.37 945 0.41 990 0.44 1037 0.47 1085 0.5
1400 634 0.26 697 0.29 758 0.31 819 0.34 875 0.38 921 0.42 964 0.46 1008 0.49 1054 0.52 1100 0.54
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
700 1071 0.32 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
800 1082 0.34 1128 0.37 1169 0.4 1205 0.42 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
900 1090 0.37 1137 0.4 1177 0.43 1214 0.46 1248 0.49 1280 0.51 1310 0.54 1340 0.57 - - - - - - - - - - - -
1000 1098 0.41 1143 0.44 1184 0.47 1221 0.5 1255 0.53 1287 0.56 1318 0.59 1347 0.61 1377 0.64 1406 0.67
1100 1107 0.44 1150 0.47 1191 0.51 1228 0.54 1263 0.57 1295 0.6 1325 0.63 1355 0.66 1384 0.69 1413 0.72
1200 1117 0.48 1160 0.52 1200 0.55 1237 0.59 1271 0.62 1303 0.66 1334 0.69 1363 0.72 1392 0.75 1420 0.78
1300 1130 0.53 1171 0.57 1210 0.6 1246 0.64 1280 0.68 1312 0.71 1342 0.74 1372 0.78 1400 0.81 1429 0.84
1400 1144 0.58 1183 0.62 1221 0.66 1256 0.7 1290 0.73 1321 0.77 1352 0.8 1381 0.84 1410 0.87 1439 0.9

Page 14
BLOWER DATA - BELT DRIVE - 4 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data.
DOWNFLOW
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
900 496 0.13 568 0.16 640 0.18 711 0.2 779 0.22 844 0.25 905 0.28 960 0.3 1010 0.33 1061 0.35
1000 521 0.15 592 0.18 662 0.2 731 0.23 796 0.25 858 0.28 916 0.31 969 0.34 1019 0.36 1069 0.38
1100 548 0.18 618 0.21 686 0.23 752 0.25 814 0.28 873 0.31 929 0.34 980 0.37 1029 0.39 1078 0.42
1200 577 0.21 646 0.24 712 0.26 775 0.29 834 0.31 890 0.35 943 0.38 993 0.41 1041 0.43 1089 0.46
1300 611 0.24 677 0.27 740 0.3 800 0.32 856 0.35 909 0.39 959 0.42 1007 0.45 1055 0.47 1102 0.5
1400 654 0.26 713 0.29 771 0.33 826 0.36 878 0.39 928 0.43 976 0.47 1023 0.49 1070 0.52 1117 0.55
1500 698 0.28 751 0.32 802 0.36 852 0.4 901 0.44 948 0.48 995 0.51 1041 0.54 1088 0.57 1133 0.6
1600 738 0.32 785 0.36 831 0.41 878 0.45 923 0.49 969 0.53 1014 0.57 1061 0.59 1107 0.62 1151 0.66
1700 773 0.36 816 0.41 859 0.46 903 0.51 947 0.55 991 0.58 1036 0.62 1082 0.65 1128 0.68 1169 0.72
1800 803 0.42 844 0.47 886 0.52 929 0.57 972 0.61 1016 0.64 1060 0.68 1106 0.71 1150 0.74 1189 0.79
1900 831 0.48 872 0.54 915 0.59 957 0.63 1000 0.67 1043 0.71 1087 0.74 1131 0.78 1173 0.81 1208 0.86
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
900 1112 0.38 1157 0.4 1198 0.43 1236 0.46 1273 0.49 1309 0.52 1344 0.56 1380 0.59 - - - - - - - - - - - -
1000 1119 0.41 1164 0.44 1206 0.47 1244 0.5 1281 0.54 1317 0.57 1352 0.6 1387 0.64 1422 0.67 1458 0.71
1100 1126 0.45 1171 0.48 1213 0.51 1252 0.55 1288 0.58 1324 0.62 1359 0.65 1394 0.69 1429 0.72 1464 0.76
1200 1136 0.49 1180 0.52 1221 0.56 1259 0.6 1296 0.63 1331 0.67 1365 0.7 1400 0.74 1435 0.78 1471 0.81
1300 1148 0.53 1190 0.57 1230 0.61 1268 0.65 1304 0.68 1338 0.72 1372 0.76 1406 0.79 1440 0.83 1476 0.87
1400 1161 0.58 1202 0.62 1240 0.66 1277 0.7 1312 0.74 1346 0.78 1379 0.81 1412 0.85 1446 0.89 1482 0.92
1500 1175 0.64 1214 0.68 1252 0.72 1287 0.76 1321 0.8 1355 0.83 1387 0.87 1420 0.91 1454 0.95 1490 0.99
1600 1190 0.7 1228 0.74 1264 0.78 1298 0.82 1332 0.86 1364 0.9 1397 0.93 1430 0.97 1464 1.01 1499 1.06
1700 1206 0.76 1242 0.8 1277 0.84 1310 0.88 1343 0.92 1375 0.96 1407 1 1440 1.04 1475 1.09 1510 1.13
1800 1223 0.83 1257 0.87 1291 0.91 1324 0.95 1356 0.99 1388 1.03 1420 1.08 1453 1.12 1487 1.16 1523 1.21
1900 1240 0.91 1273 0.95 1306 0.99 1338 1.03 1369 1.07 1401 1.12 1433 1.16 1467 1.2 1501 1.25 1537 1.29

Page 15
BLOWER DATA - BELT DRIVE - 4 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data.
HORIZONTAL
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
900 493 0.12 564 0.14 637 0.17 712 0.19 788 0.21 847 0.24 894 0.27 942 0.3 993 0.33 1046 0.35
1000 520 0.14 589 0.17 660 0.19 733 0.21 805 0.24 861 0.27 907 0.3 954 0.33 1004 0.36 1056 0.38
1100 549 0.16 617 0.19 686 0.22 756 0.24 823 0.27 876 0.3 921 0.33 968 0.37 1017 0.39 1067 0.42
1200 582 0.19 648 0.22 714 0.25 781 0.27 843 0.3 893 0.34 938 0.37 984 0.41 1032 0.43 1081 0.46
1300 624 0.22 686 0.25 747 0.28 808 0.31 865 0.34 912 0.38 956 0.42 1001 0.45 1048 0.48 1096 0.5
1400 670 0.24 726 0.27 782 0.31 837 0.35 887 0.39 932 0.43 975 0.47 1020 0.5 1066 0.52 1112 0.55
1500 714 0.26 765 0.31 814 0.35 863 0.39 910 0.44 953 0.48 996 0.52 1041 0.55 1086 0.58 1130 0.61
1600 752 0.3 798 0.35 844 0.4 889 0.45 933 0.49 975 0.53 1018 0.57 1062 0.6 1107 0.63 1149 0.67
1700 785 0.35 827 0.4 871 0.46 914 0.51 957 0.55 999 0.59 1042 0.63 1085 0.66 1129 0.69 1169 0.73
1800 813 0.42 855 0.47 898 0.52 940 0.57 983 0.62 1025 0.66 1067 0.69 1110 0.72 1152 0.76 1190 0.8
1900 841 0.49 883 0.54 926 0.6 969 0.65 1011 0.69 1052 0.72 1094 0.76 1136 0.79 1176 0.83 1212 0.89
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
900 1097 0.38 1142 0.41 1182 0.43 1218 0.46 1252 0.49 1284 0.52 1314 0.55 1344 0.57 - - - - - - - - - - - -
1000 1105 0.41 1149 0.44 1190 0.47 1226 0.5 1260 0.53 1292 0.56 1322 0.59 1352 0.62 1381 0.65 1410 0.68
1100 1115 0.45 1158 0.48 1198 0.51 1235 0.55 1269 0.58 1301 0.61 1331 0.64 1360 0.67 1389 0.7 1418 0.73
1200 1126 0.49 1168 0.53 1208 0.56 1244 0.6 1278 0.63 1309 0.66 1340 0.69 1369 0.72 1398 0.75 1426 0.78
1300 1140 0.54 1180 0.57 1218 0.61 1254 0.65 1287 0.68 1319 0.72 1349 0.75 1378 0.78 1407 0.81 1436 0.84
1400 1154 0.59 1193 0.63 1230 0.67 1265 0.7 1298 0.74 1330 0.78 1360 0.81 1389 0.85 1418 0.88 1447 0.91
1500 1170 0.65 1208 0.69 1244 0.73 1278 0.77 1310 0.8 1341 0.84 1371 0.88 1401 0.91 1430 0.95 1459 0.98
1600 1187 0.71 1223 0.75 1258 0.79 1291 0.83 1323 0.87 1354 0.91 1384 0.95 1414 0.99 1443 1.02 1474 1.06
1700 1204 0.78 1240 0.82 1274 0.86 1306 0.9 1338 0.95 1369 0.99 1399 1.03 1429 1.06 1459 1.1 1490 1.14
1800 1223 0.85 1258 0.9 1291 0.94 1323 0.99 1354 1.03 1385 1.07 1415 1.11 1445 1.15 1476 1.19 1507 1.23
1900 1243 0.94 1277 0.99 1309 1.03 1341 1.08 1372 1.12 1402 1.16 1433 1.2 1464 1.24 1495 1.28 1527 1.32

Page 16
BLOWER DATA - BELT DRIVE - 5 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data.
DOWNFLOW
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1100 512 0.15 571 0.19 630 0.23 690 0.26 770 0.26 854 0.26 922 0.27 970 0.30 1006 0.35 1045 0.39
1200 535 0.18 593 0.22 651 0.26 710 0.29 788 0.30 868 0.30 933 0.31 978 0.34 1013 0.38 1053 0.42
1300 559 0.22 616 0.26 674 0.29 732 0.32 807 0.34 883 0.34 944 0.35 987 0.38 1022 0.42 1062 0.46
1400 584 0.26 641 0.29 698 0.33 755 0.36 827 0.37 899 0.38 956 0.40 997 0.43 1033 0.47 1072 0.51
1500 615 0.29 671 0.33 726 0.36 782 0.39 850 0.41 917 0.42 970 0.44 1009 0.47 1045 0.52 1085 0.56
1600 665 0.30 716 0.34 768 0.38 819 0.41 879 0.44 937 0.46 985 0.49 1022 0.52 1059 0.57 1098 0.61
1700 723 0.31 768 0.35 814 0.39 860 0.43 910 0.47 959 0.50 1001 0.54 1037 0.58 1074 0.62 1113 0.66
1800 779 0.32 818 0.37 857 0.41 897 0.46 939 0.50 980 0.55 1018 0.59 1054 0.64 1091 0.68 1129 0.72
1900 826 0.36 859 0.41 894 0.45 928 0.50 964 0.56 1000 0.61 1036 0.66 1072 0.70 1109 0.75 1146 0.79
2000 857 0.42 889 0.47 920 0.52 952 0.57 986 0.62 1020 0.68 1055 0.73 1091 0.77 1128 0.82 1164 0.86
2100 878 0.49 909 0.54 940 0.59 973 0.64 1006 0.70 1041 0.75 1076 0.80 1112 0.85 1148 0.89 1185 0.93
2200 897 0.55 929 0.61 961 0.66 994 0.72 1028 0.78 1063 0.83 1099 0.89 1134 0.93 1170 0.97 1206 1.01
2300 918 0.62 950 0.68 983 0.74 1017 0.80 1052 0.86 1087 0.92 1122 0.97 1157 1.02 1193 1.06 1228 1.09
2400 941 0.70 974 0.77 1008 0.83 1042 0.90 1077 0.96 1111 1.01 1146 1.06 1181 1.11 1216 1.15 1250 1.19
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1100 1089 0.43 1134 0.46 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1200 1095 0.46 1139 0.50 1186 0.53 1230 0.57 1266 0.60 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1300 1104 0.50 1146 0.54 1192 0.57 1234 0.60 1269 0.64 1301 0.68 1334 0.71 1367 0.75 - - - - - - - - - - - -
1400 1114 0.55 1155 0.58 1199 0.61 1240 0.65 1275 0.68 1305 0.72 1338 0.76 1372 0.80 1406 0.83 1440 0.87
1500 1125 0.60 1165 0.63 1208 0.66 1248 0.69 1281 0.73 1311 0.77 1344 0.81 1378 0.85 1412 0.89 1446 0.92
1600 1138 0.65 1177 0.68 1218 0.71 1257 0.75 1290 0.79 1319 0.83 1352 0.87 1385 0.91 1418 0.95 1452 0.98
1700 1152 0.70 1190 0.74 1231 0.77 1268 0.80 1299 0.84 1328 0.89 1360 0.93 1393 0.97 1426 1.01 1459 1.05
1800 1167 0.76 1205 0.80 1244 0.83 1280 0.87 1310 0.91 1338 0.95 1370 0.99 1402 1.04 1434 1.08 1466 1.11
1900 1183 0.82 1221 0.86 1260 0.90 1294 0.94 1323 0.98 1349 1.02 1380 1.07 1412 1.11 1443 1.15 1475 1.19
2000 1201 0.89 1239 0.93 1276 0.97 1310 1.01 1336 1.06 1362 1.10 1392 1.15 1423 1.19 1454 1.23 1485 1.27
2100 1221 0.97 1258 1.01 1294 1.05 1325 1.09 1351 1.14 1376 1.19 1406 1.23 1436 1.27 1466 1.31 1497 1.35
2200 1242 1.05 1277 1.09 1311 1.14 1341 1.18 1365 1.23 1390 1.28 1420 1.32 1450 1.36 1480 1.41 1510 1.45
2300 1262 1.14 1295 1.19 1327 1.24 1355 1.29 1380 1.33 1406 1.37 1435 1.42 1465 1.46 1494 1.50 1524 1.54
2400 1282 1.24 1313 1.30 1343 1.36 1371 1.40 1396 1.44 1423 1.48 1452 1.52 1481 1.56 1510 1.60 1540 1.64

Page 17
BLOWER DATA - BELT DRIVE - 5 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data.
HORIZONTAL
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1100 509 0.15 562 0.18 624 0.20 691 0.22 771 0.24 852 0.25 919 0.28 970 0.31 1010 0.35 1049 0.38
1200 535 0.18 589 0.21 650 0.23 715 0.25 792 0.27 869 0.29 932 0.32 980 0.35 1019 0.38 1058 0.42
1300 564 0.21 618 0.24 678 0.27 741 0.29 815 0.31 887 0.33 946 0.36 991 0.39 1030 0.43 1068 0.47
1400 604 0.24 657 0.27 715 0.30 775 0.33 842 0.35 908 0.37 962 0.40 1004 0.43 1042 0.47 1080 0.51
1500 656 0.26 706 0.30 760 0.33 814 0.36 874 0.39 931 0.41 979 0.45 1019 0.48 1056 0.53 1094 0.57
1600 712 0.29 758 0.32 807 0.36 855 0.39 906 0.43 955 0.46 997 0.50 1035 0.54 1071 0.58 1109 0.62
1700 766 0.32 808 0.36 850 0.40 892 0.44 936 0.47 978 0.51 1016 0.56 1052 0.60 1088 0.64 1126 0.68
1800 814 0.36 851 0.40 888 0.44 925 0.49 963 0.53 1000 0.57 1035 0.62 1071 0.66 1107 0.70 1143 0.74
1900 853 0.41 886 0.46 919 0.50 952 0.55 986 0.60 1021 0.64 1056 0.69 1091 0.73 1126 0.77 1163 0.81
2000 883 0.48 913 0.53 944 0.57 976 0.62 1009 0.67 1043 0.71 1078 0.76 1112 0.80 1148 0.84 1183 0.88
2100 906 0.56 936 0.60 967 0.65 999 0.70 1033 0.75 1067 0.79 1101 0.84 1135 0.88 1170 0.92 1206 0.96
2200 930 0.64 960 0.68 991 0.73 1024 0.78 1058 0.83 1092 0.88 1126 0.92 1160 0.96 1195 1.00 1230 1.04
2300 954 0.72 985 0.77 1017 0.82 1051 0.87 1085 0.92 1119 0.96 1152 1.00 1186 1.04 1220 1.08 1254 1.13
2400 981 0.81 1013 0.86 1046 0.91 1079 0.96 1113 1.00 1146 1.05 1180 1.09 1213 1.13 1245 1.18 1278 1.22
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1100 1091 0.42 1134 0.45 1176 0.48 1218 0.51 1258 0.54 1297 0.57 1335 0.59 - - - - - - - - - - - - - - - - - -
1200 1099 0.46 1141 0.49 1182 0.52 1223 0.55 1263 0.58 1302 0.61 1339 0.64 1376 0.67 1410 0.70 1444 0.72
1300 1108 0.50 1149 0.53 1190 0.56 1230 0.59 1270 0.63 1308 0.66 1345 0.70 1381 0.73 1415 0.75 1449 0.78
1400 1120 0.55 1160 0.58 1200 0.61 1240 0.65 1278 0.68 1315 0.72 1352 0.75 1387 0.78 1421 0.81 1454 0.84
1500 1133 0.60 1172 0.63 1212 0.67 1250 0.70 1288 0.74 1324 0.77 1360 0.81 1394 0.84 1428 0.87 1460 0.90
1600 1147 0.66 1186 0.69 1225 0.72 1263 0.76 1299 0.80 1334 0.83 1369 0.87 1402 0.90 1435 0.94 1467 0.96
1700 1164 0.72 1202 0.75 1240 0.78 1276 0.82 1311 0.86 1345 0.90 1379 0.93 1411 0.97 1443 1.00 1475 1.03
1800 1181 0.78 1219 0.81 1256 0.85 1291 0.89 1324 0.93 1357 0.97 1390 1.00 1421 1.04 1453 1.07 1483 1.10
1900 1200 0.85 1237 0.88 1273 0.92 1306 0.96 1339 1.00 1371 1.04 1402 1.08 1433 1.11 1463 1.15 1493 1.18
2000 1220 0.92 1257 0.96 1291 1.00 1323 1.04 1354 1.08 1385 1.12 1416 1.16 1446 1.20 1476 1.23 1505 1.26
2100 1242 1.00 1277 1.04 1310 1.08 1340 1.13 1371 1.17 1401 1.21 1431 1.25 1460 1.29 1489 1.32 1519 1.36
2200 1265 1.08 1299 1.13 1330 1.18 1359 1.23 1388 1.27 1418 1.31 1447 1.35 1476 1.39 1504 1.42 1533 1.45
2300 1288 1.17 1320 1.23 1350 1.28 1378 1.34 1406 1.38 1435 1.42 1464 1.46 1492 1.50 1521 1.53 1549 1.56
2400 1311 1.28 1341 1.33 1370 1.40 1397 1.45 1425 1.50 1454 1.54 1482 1.57 1510 1.61 1538 1.64 1567 1.67

Page 18
BLOWER DATA - BELT DRIVE - 6 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page20 for blower motors and drives and wet coil and options/accessory air resistance data.
DOWNFLOW
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1900 480 0.38 512 0.44 545 0.51 579 0.57 614 0.63 648 0.7 683 0.76 719 0.83 752 0.89 781 0.95
2000 493 0.43 525 0.49 558 0.56 592 0.62 626 0.68 659 0.75 693 0.81 728 0.88 759 0.94 788 1
2100 507 0.48 539 0.54 572 0.61 605 0.67 639 0.74 671 0.8 704 0.86 737 0.93 768 0.99 795 1.04
2200 522 0.53 554 0.6 587 0.66 619 0.73 652 0.79 684 0.86 716 0.92 747 0.98 777 1.04 803 1.1
2300 537 0.59 569 0.65 602 0.72 634 0.79 666 0.85 697 0.91 728 0.98 758 1.04 786 1.1 812 1.15
2400 553 0.65 585 0.71 617 0.78 649 0.85 680 0.91 711 0.98 740 1.04 769 1.1 796 1.15 821 1.21
2500 570 0.71 602 0.78 633 0.84 665 0.91 695 0.97 725 1.04 753 1.1 781 1.16 807 1.22 832 1.27
2600 588 0.77 619 0.84 650 0.91 680 0.97 710 1.04 739 1.1 767 1.16 793 1.22 818 1.28 842 1.33
2700 607 0.84 637 0.91 667 0.97 697 1.04 726 1.11 753 1.17 780 1.23 806 1.29 830 1.35 854 1.4
2800 626 0.91 655 0.97 684 1.04 713 1.11 741 1.18 768 1.24 794 1.3 819 1.36 842 1.42 866 1.47
2900 646 0.98 674 1.05 702 1.11 730 1.18 757 1.25 783 1.32 808 1.38 832 1.44 855 1.49 878 1.54
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1900 807 1 832 1.04 857 1.07 883 1.11 912 1.14 941 1.17 968 1.21 993 1.25 1017 1.29 1039 1.34
2000 813 1.04 838 1.08 862 1.12 889 1.15 917 1.19 945 1.22 972 1.26 997 1.3 1020 1.35 1042 1.4
2100 820 1.09 844 1.13 869 1.17 895 1.21 923 1.24 951 1.28 977 1.32 1001 1.36 1024 1.41 1046 1.46
2200 828 1.14 852 1.18 877 1.22 903 1.26 930 1.3 957 1.33 983 1.37 1006 1.42 1028 1.47 1050 1.53
2300 836 1.2 861 1.24 885 1.28 911 1.31 938 1.35 964 1.39 989 1.43 1012 1.48 1033 1.54 1054 1.6
2400 846 1.25 870 1.29 895 1.33 920 1.37 947 1.41 972 1.45 996 1.5 1018 1.55 1039 1.61 1059 1.67
2500 856 1.31 880 1.35 905 1.39 930 1.43 956 1.47 980 1.52 1003 1.57 1024 1.63 1044 1.69 1064 1.76
2600 866 1.38 891 1.42 915 1.46 940 1.5 965 1.54 988 1.59 1010 1.65 1031 1.71 1050 1.78 1069 1.84
2700 878 1.44 902 1.48 926 1.52 950 1.57 974 1.61 997 1.67 1018 1.73 1037 1.8 1056 1.87 1075 1.93
2800 889 1.51 913 1.55 937 1.59 961 1.64 984 1.69 1006 1.75 1026 1.82 1044 1.89 1063 1.96 1081 2.03
2900 902 1.58 925 1.63 949 1.67 972 1.72 994 1.78 1015 1.84 1034 1.91 1052 1.99 1069 2.06 1087 2.13

Page 19
BLOWER DATA - BELT DRIVE - 6 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page20 for blower motors and drives and wet coil and options/accessory air resistance data.
HORIZONTAL
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1900 507 0.55 538 0.58 571 0.6 604 0.63 639 0.66 673 0.7 707 0.74 740 0.78 772 0.82 802 0.86
2000 522 0.59 554 0.62 586 0.64 620 0.67 653 0.71 687 0.74 720 0.78 752 0.82 783 0.87 812 0.91
2100 539 0.63 571 0.66 603 0.69 636 0.72 669 0.75 702 0.79 734 0.83 765 0.88 795 0.92 823 0.97
2200 557 0.68 588 0.71 620 0.74 652 0.77 685 0.81 717 0.84 748 0.89 778 0.93 807 0.98 834 1.03
2300 576 0.73 607 0.76 638 0.79 670 0.83 701 0.86 733 0.9 763 0.95 792 0.99 820 1.04 846 1.09
2400 596 0.79 626 0.82 657 0.85 688 0.89 718 0.92 749 0.96 778 1.01 806 1.06 833 1.11 858 1.16
2500 616 0.85 645 0.88 676 0.91 706 0.95 736 0.99 765 1.03 794 1.08 821 1.13 847 1.18 871 1.23
2600 636 0.91 665 0.94 695 0.98 724 1.02 754 1.06 782 1.1 809 1.15 836 1.2 861 1.25 885 1.3
2700 657 0.97 685 1.01 714 1.04 743 1.08 771 1.13 799 1.17 826 1.22 851 1.27 875 1.32 899 1.37
2800 677 1.03 706 1.07 734 1.11 762 1.16 790 1.2 816 1.25 842 1.3 867 1.35 890 1.4 913 1.45
2900 698 1.1 726 1.14 754 1.19 781 1.23 808 1.28 834 1.33 859 1.38 883 1.43 906 1.48 928 1.54
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1900 830 0.91 857 0.95 883 0.99 910 1.04 937 1.09 964 1.13 991 1.18 1017 1.23 1042 1.28 1067 1.34
2000 839 0.96 865 1 891 1.05 917 1.09 944 1.14 970 1.19 996 1.24 1022 1.29 1047 1.34 1071 1.4
2100 849 1.02 874 1.06 900 1.11 926 1.15 952 1.2 978 1.25 1003 1.3 1028 1.35 1052 1.41 1075 1.46
2200 860 1.08 885 1.12 910 1.17 935 1.21 960 1.26 986 1.31 1010 1.36 1034 1.42 1058 1.48 1081 1.53
2300 871 1.14 895 1.19 920 1.23 945 1.28 969 1.33 994 1.38 1018 1.43 1042 1.49 1065 1.55 1087 1.61
2400 883 1.21 907 1.25 931 1.3 955 1.35 979 1.4 1003 1.45 1027 1.51 1050 1.57 1072 1.63 1094 1.69
2500 895 1.28 919 1.32 942 1.37 966 1.42 990 1.48 1013 1.53 1036 1.59 1059 1.65 1081 1.71 1102 1.78
2600 908 1.35 931 1.4 955 1.45 978 1.5 1001 1.56 1024 1.62 1046 1.68 1068 1.74 1089 1.8 1110 1.87
2700 922 1.43 945 1.48 967 1.53 990 1.59 1013 1.65 1035 1.71 1056 1.77 1078 1.84 1099 1.9 1119 1.96
2800 936 1.51 958 1.56 980 1.62 1003 1.68 1025 1.74 1046 1.8 1067 1.87 1088 1.93 1109 2 1129 2.06
2900 950 1.6 972 1.66 994 1.72 1016 1.78 1037 1.84 1058 1.91 1079 1.97 1099 2.04 1119 2.11 1139 2.17

Page 20
FACTORY INSTALLED OPTIONS/FIELD INSTALLED ACCESSORY AIR RESISTANCE - in. w.g.
Air
Volume
cfm
Wet Indoor Coil Humiditrol
Dehumidication
Coil
Electric Heat Economizer
Filters
036 048 060, 072,
074 MERV 8 MERV 13
036-048 MODELS
800 0.01 0.01 - - - 0.00 0.01 0.04 0.04 0.05
1000 0.02 0.02 - - - 0.00 0.03 0.04 0.04 0.07
1200 0.03 0.04 - - - 0.01 0.06 0.04 0.04 0.07
1400 0.04 0.05 - - - 0.02 0.09 0.04 0.04 0.07
1600 0.05 0.06 - - - 0.03 0.12 0.04 0.04 0.07
1800 0.06 0.07 - - - 0.04 0.15 0.05 0.04 0.07
2000 0.08 0.09 - - - 0.04 0.18 0.05 0.05 0.08
060, 072, 074 MODELS
1000 - - - - - - 0.02 0.00 0.01 0.04 0.03 0.05
1200 - - - - - - 0.04 0.00 0.03 0.04 0.03 0.07
1400 - - - - - - 0.05 0.01 0.06 0.04 0.04 0.07
1600 - - - - - - 0.07 0.02 0.09 0.04 0.04 0.07
1800 - - - - - - 0.08 0.02 0.12 0.05 0.05 0.07
2000 - - - - - - 0.10 0.03 0.15 0.05 0.05 0.07
2200 - - - - - - 0.11 0.04 0.18 0.05 0.05 0.08
2400 - - - - - - 0.13 0.04 0.20 0.05 0.05 0.08
2600 - - - - - - 0.15 0.05 0.22 0.06 0.05 0.08
2800 - - - - - - 0.16 0.05 0.24 0.06 0.05 0.08
3000 - - - - - - 0.18 0.06 0.28 0.06 0.05 0.08
BLOWER DATA
BELT DRIVE KIT SPECIFICATIONS - 036-060
Model
No.
Motor HP No. of
Speeds
Drive Kits and RPM Range
Nominal Maximum A01 A02 A03 A05 A06 A07
036 0.75 0.86 2 low 449-673
high 673-1010
- - - - - - - - - - - - - - -
1 1.15 2 - - - - - - - - - low 598-897
high 897-1346
- - - - - -
048 0.75 0.86 2 - - - low 497-673
high 745-1117
- - - - - - - - - - - -
2 2.3 2 - - - - - - - - - - - - low 714-953
high 1071-1429
- - -
060 1 1.15 2 - - - - - - low 555-833
high 833-1250
- - - - - - - - -
2 2.3 2 - - - - - - - - - - - - - - - low 808-1032
high 1212-1548
BELT DRIVE KIT SPECIFICATIONS - 072-074
Model
No.
Motor HP No. of
Speeds
Drive Kits and RPM Range
Nominal Maximum AA01 AA02 AA03
072 1 1.15 1 522-784 - - - - - -
2 2.3 1 - - - 632-875 798-1105
074 1 1.15 2 522-784 - - - - - -
2 2.3 2 - - - 632-875 798-1105
POWER EXHAUST FAN PERFORMANCE
Return Air System Static
Pressure
in. w.g.
Air Volume Exhausted
cfm
0.00 2000
0.05 1990
0.10 1924
0.15 1810
0.20 1664
0.25 1507
0.30 1350
0.35 1210
