Lennox Xp17 User manual

SEER up to 17.70

2 to 5 Tons

Cooling Capacity - 22,000 to 56,500 Btuh

Heating Capacity - 21,200 to 55,000 Btuh

MODEL NUMBER IDENTIFICATION

x P 17 - 036 - 230 - 2

Series

Unit Type

P = Heat Pump Outdoor Unit

Refrigerant Type

X = R-410A

Nominal Cooling Capacity

024 = 2 tons

030 = 2.5 tons

036 = 3 tons

042 = 3.5 tons

048 = 4 tons

060 = 5 tons

Minor Revision Number

Voltage

230 = 208/230V-1ph-60hz

HEAT PUMP OUTDOOR UNITS

XP17

DAVE LENNOX SIGNATURE®COLLECTION

R-410A - SilentComfort™ Technology

Bulletin No. 210584

August 2012

Supersedes July 2012

PRODUCT SPECIFICATIONS

XP17 - 2 to 5 Ton Heat Pump / Page 2

FEATURES

Equipment Warranty

Compressor - limited warranty for ten years in

residential installations and ve years in non-residential

installations.

All other covered components - limited warranty for

ten years in residential installations and one year in

non-residential installations.

Refer to Lennox Equipment Limited Warranty certicate

included with unit for specic details.

Approvals

AHRI Certied to AHRI Standard 210/240-2008.

Tested in the Lennox Research Laboratory

environmental test room.

Rated according to U.S. Department of Energy (DOE)

test procedures.

Heat Pump units and components within bonded

for grounding to meet safety standards for servicing

required by ETL, NEC and CEC.

Units are ETL certied for the U.S. and Canada.

ISO 9001 Registered Manufacturing Quality System.

EnErgy Star® certied units are designed to use less

energy, help save money on utility bills, and help protect

the environment. Many Lennox home comfort systems

meet EnErgy Star requirements when used with

matching components.

APPLICATIONS

SEER up to 17.70.

HSPF (Region IV) up to 9.50.

2 through 5 ton.

Single phase power supply.

Sound levels as low as 63 dB.

Vertical air discharge allows concealment behind shrubs

at grade level or out of sight on a roof.

Designed for applications with remotely located indoor

air handler units or gas furnaces with indoor add-on

coils.

When heat pumps are used with gas furnaces, a

dual-fuel control or a control system with dual-fuel

capabilities (i.e. Harmony III or LZP-4) must be used

(order separately).

See Indoor Coils and Air Handlers sections for indoor

unit data.

Units shipped completely factory assembled, piped, and

wired. Each unit is test operated at the factory insuring

proper operation.

Installer must set outdoor unit, connect refrigerant lines,

and make electrical connections to complete job.

Contents

AHRI System Matches................................................16

Controls ......................................................................12

Dimensions.................................................................14

Electrical Data ............................................................12

Features........................................................................2

Field Wiring.................................................................13

Installation Clearances ...............................................13

Model Number Identication.........................................1

Optional Accessories ..................................................12

Sound Data ................................................................13

Specications .............................................................12

Sunsource®Home Energy System - Components .......8

XP17 - 2 to 5 Ton Heat Pump / Page 3

FEATURES

REFRIGERATION SYSTEM

R-410A Refrigerant

Non-chlorine, ozone friendly, R-410A.

Unit is factory pre-charged with

refrigerant. Total system refrigerant

charge is dependant on outdoor unit size, indoor unit

size and refrigerant line length.

Refer to Installation Instructions for “Indoor Unit Match-

Up and Sub-Cooling Charge Levels” to determine

correct amount of charge required.

See Specication table.

Outdoor Coil Fan with SilentComfort™ Technology

Specially-designed, SilentComfort fan guard uses

Passive Vortex Suppression to reduce air noise.

Corrosion-resistant PVC (polyvinyl chloride) coated

steel wire.

Specially designed fan blades reduce operating

sound levels. Direct drive fan moves large air volumes

uniformly through entire condenser coil for high

refrigerant cooling capacity.

Vertical air discharge minimizes operating sounds and

eliminates damage to lawn and shrubs.

Fan motor is inherently protected.

Motor totally enclosed for maximum protection from

weather, dust and corrosion.

Fan service access accomplished by removal of fan

guard.

Copper Tube/Enhanced Fin Coil

Lennox designed and fabricated coil.

Ripple-edged aluminum ns.

Copper tube construction.

Lanced ns provide maximum exposure of n surface to

air stream resulting in excellent heat transfer.

Fin collars grip tubing for maximum contact area.

Flared shoulder tubing connections/silver soldering

construction.

Coil is factory tested under high pressure to insure

leakproof construction.

Entire coil is accessible for cleaning.

High Pressure Switch

Shuts off unit if abnormal operating conditions cause the

discharge pressure to rise above setting.

Protects compressor from excessive condensing

pressure.

Manual reset.

Low Pressure Switch

Shuts off unit if suction pressure falls below setting.

Provides loss of charge and freeze-up protection.

Automatic reset.

Expansion Valve - Outdoor Unit

Designed and sized specically for use in heat pump

system.

Sensing bulb is located on the suction line between the

coil and the reversing valve thus sensing evaporator out

temperature in the heat cycle.

Factory installed and piped.

Reversing Valve

4-way interchange reversing valve effects a rapid

change in direction of refrigerant ow resulting in quick

changeover from cooling to heating and vice versa.

Valve operates on pressure differential between outdoor

unit and indoor unit of the system. Factory installed.

Hi-Capacity Liquid Line Drier

Factory installed in the liquid line, the drier traps

moisture or dirt that could contaminate the refrigerant

system.

100% molecular-sieve bead type drier.

OPTIONS

Check/Expansion Valve Kits

Must be ordered extra and eld installed on certain

evaporator units. See TXV Usage table.

Chatleff style tting.

Freezestat

Installs on or near the discharge line of the evaporator

or on the suction line.

Senses suction line temperature and cycles the

compressor off when suction line temperature falls

below it’s setpoint.

Opens at 29°F and closes at 58°F.

Refrigerant Line Kits

Refrigerant lines (suction & liquid) are shipped

refrigeration clean. Lines are cleaned, dried,

pressurized, and sealed at factory.

Suction line fully insulated.

L15 lines are stubbed at both ends.

See Specications table for selection.

Not available for -060 model and must be eld

fabricated.

XP17 - 2 to 5 Ton Heat Pump / Page 4

COMPRESSOR

Scroll Compressor

Compressor features high

efciency with uniform suction

ow, constant discharge ow, high

volumetric efciency and quiet

operation.

Compressor consists of two

involute spiral scrolls matched

together to generate a series

of crescent shaped gas

pockets between them. During

compression, one scroll remains

stationary while the other scroll

orbits around it. Gas is drawn

into the outer pocket, the pocket is sealed as the scroll

rotates. As the spiral movement continues, gas pockets

are pushed to the center of the scrolls. Volume between

the pockets is simultaneously reduced.

When the pocket reaches the center, gas is now at high

pressure and is forced out of a port located in the center

of the xed scrolls.

During compression, several pockets are compressed

simultaneously resulting in a smooth continuous

compression cycle.

Continuous ank contact, maintained by centrifugal

force, minimizes gas leakage and maximizes efciency.

Scroll compressor is tolerant to the effects of slugging

and contaminants. If this occurs, scrolls separate,

allowing liquid or contaminants to be worked toward the

center and discharged.

Low gas pulses during compression reduces

operational sound levels.

Compressor motor is internally protected from

excessive current and temperature.

Compressor is installed in the unit on resilient rubber

mounts for vibration free operation.

Factory installed crankcase heater.

Crankcase Heater

Crankcase heater prevents migration of liquid

refrigerant into compressor and ensures proper

compressor lubrication.

Compressor Sound Dampening System

A polyethylene compressor cover containing a 2 inch

thick batt of berglass insulation for better sound

dampening.

All open edges are sealed with a one-inch wide hook

and loop fastening tape.

CONTROLS

icomfort®Control

Advanced icomfort®control

communicates information about

various operating parameters

in the heat pump outdoor unit

to the optional icomfort Wi-

Fi™ Thermostat to constantly

maintain the highest level of comfort, performance and

efciency available.

Connections for connecting a conventional heat pump

thermostat are also provided.

Auto Conguration - On start-up the control

automatically sends a description of the unit to the

optional icomfort™ Thermostat to automatically

congure the number of stages and features available.

Seven-Segment Display

Seven-segment display shows information about

outdoor unit type and capacity and also displays alerts

for common fault conditions (electrical and mechanical).

Control also features:

• Compressor anti-short cycle delay (5 minutes).

• Compressor defrost shift delay - Adjustable 0 (factory)

or 30 seconds.

• Demand defrost using outdoor ambient air

temperature, coil temperature and compressor run-

time inputs. 14 minute maximum defrost time.

• Selectable defrost termination temperature - 50, 70,

90 or 100ºF. Default setting is 50°F.

• High and low pressure switch monitoring with

provisions for lockout.

• Five-Strike lockout protection protects compressor.

• Outdoor air temperature and sensor monitoring.

• Fan cycling operates outdoor fan for 5 minutes when

outdoor ambient air temperature is between 15°F and

35°F and the compressor has been off for 25 to 30

minutes. Reduces the potential for ice buildup on the

fan orice ring. User selectable 5 minutes on or off

(default setting).

• Lennox Humiditrol® Whole Home Dehumidication

System (EDA) compatible.

• EEPROM storage of all local congurations.

FEATURES

XP17 - 2 to 5 Ton Heat Pump / Page 5

CONTROLS (CONTINUED)

OPTIONS

Compressor Low Ambient Cut-Off

Non-adjustable switch (low ambient cut-out) prevents

compressor operation when outdoor temperature is

below 35°F.

Compressor Hard Start Kit

Single-phase units are equipped with a PSC

compressor motor.

This type of motor normally does not need a potential

relay and start capacitor.

In conditions such as low voltage, kit may be required to

increase the compressor starting torque.

Indoor Blower Off Delay Relay

Delays the indoor blower-off time during the cooling

cycle.

Indoor Blower Speed Relay Kit

Relay kit provides optimum humidity control conditions

by automatically reducing indoor blower speed during

continuous fan operation.

Low Ambient Kit

Outdoor units will operate in the cooling mode

satisfactorily down to 45°F outdoor air temperature

without any additional controls.

Kit can be added in the eld enabling unit to operate

properly down to 30°F.

A Freezestat should be installed on compressors

equipped with a low ambient kit.

A Compressor Low Ambient Cut-Off should be added to

terminate compressor operation below recommended

operation conditions.

Monitor Kit - Service Light

Contains ambient compensating thermistor and service

light thermostat.

For use with thermostats requiring input for indicator

lights.

Outdoor Thermostat Kit

An outdoor thermostat can be used to lock out some of

the electric heating elements on indoor units where two-

stage control is applicable.

Outdoor thermostat maintains the heating load on the

low power input as long as possible before allowing the

full power load to come on the line.

Thermostat kit and mounting box must be ordered

separately.

FEATURES

XP17 - 2 to 5 Ton Heat Pump / Page 6

FEATURES

CONTROLS (CONTINUED)

icomfort Wi-Fi™ Thermostat (part of the icomfort™

Residential Communicating Control System)

The icomfort Wi-Fi™ Thermostat recognizes

and connects to

all icomfort™-

enabled products

to automatically

congure and control

the heating/cooling

system (based

on user-specied

settings) for the

highest level of comfort, performance and efciency.

Also recognizes model and serial number information

for icomfort™-enabled products to simplify system

installation.

Wi-Fi remote temperature monitoring and adjustment

through a home wireless network for desktop PCs,

laptops and apps for smartphones or tablets. Service

alerts and reminders sent via text message or e-mail.

Dealer Dashboard features online real-time monitoring

of installed icomfort systems.

A simple easy-to-use touchscreen allows complete

system conguration. Scheduled maintenance alerts,

system warnings and troubleshooting are also displayed

on thermostat screen.

Easy to read 7 inch color screen (measured diagonally).

Conventional outdoor units (not icomfort™-enabled) can

easily be added and controlled by the icomfort Wi-Fi™

Thermostat.

Installer setup screens allow quick and simple system

conguration without a manual, Installer can also run

tests on complete system or individual components for

easy maintenance and troubleshooting.

Serial communications bus (RSBus), with less wiring

than a conventional heating/cooling system, allows

system communication. Uses 4-wire, 18-gauge

standard thermostat wiring.

See the icomfort Wi-Fi™ Thermostat Product

Specications bulletin in the Controls section for more

information.

ComfortSense®7000 Touchscreen Thermostat

Electronic 7-day, universal, multi-stage, programmable,

touchscreen thermostat.

4 Heat/2 Cool.

Auto-changeover.

Controls humidity during

cooling mode.

Offers enhanced capabilities

including humidication /

dehumidication / dewpoint

measurement and control,

Humiditrol®control, and

equipment maintenance

reminders.

Easy-to-use, menu driven thermostat with a back-lit,

LCD touchscreen.

Remote outdoor temperature sensor (optional) allows

the thermostat to display outdoor temperature. Required

in dual-fuel and Humiditrol®applications.

See the ComfortSense® 7000 Product Specications

bulletin in the Controls section for more information.

Outdoor Temperature Sensor

Used with icomfort™ thermostats

and ComfortSense®7000 thermostat.

When installed outdoors, sensor

allows thermostat to display outdoor

temperature. Sensor is auto-detected

when connected to thermostat.

NOTE - Sensor is required for dual

fuel and Humiditrol®applications.

Thermostat

Thermostat (icomfort™ thermostat or programmable/

non-programmable) is not furnished with unit.

See Thermostat bulletins in Controls Section and

Lennox Price Book for selection.

INDOOR RH 26%

WED AN 21 12:35AM

MODE

AUTO

HOME SCHEDULE OPTIONS

SET AT

HEAT

COOL

SCHED

XP17 - 2 to 5 Ton Heat Pump / Page 7

FEATURES

Cabinet

Heavy-gauge steel construction

Pre-painted cabinet nish.

Durable zinc-coated base section.

Control box is conveniently located with all controls

factory wired.

Large removable panel provides service access.

Drainage holes are provided in base section for

moisture removal.

High density polyethylene unit support feet raise the

unit off of the mounting surface, away from damaging

moisture.

SmartHinge™ Louvered Coil Protection

Steel louvered panels

provides complete coil

protection.

Panels are hinged to

allow easy cleaning and

servicing of coils.

Panels may be completely

removed.

Interlocking tabs and slots

assure tight t on cabinet.

Refrigerant Line

Connections, Electrical Inlets and Service Valves

Suction and liquid lines are located on corner of unit

cabinet and are made with sweat connections. See

dimension drawing.

Fully serviceable brass service valves prevent corrosion

and provide access to refrigerant system. Suction valve

can be fully shut off, while liquid valve may be front

seated to manage refrigerant charge while servicing

system.

Suction and liquid line service valves and gauge ports

are located inside the cabinet.

Refrigerant line connections and eld wiring inlets

are located in one central area of the cabinet. See

dimension drawing.

OPTIONS

Snow Guards

For use in locations where the possibility of heavy snow

or freezing rain accumulation may occur.

Heavy gauge powder coated steel guard deects snow

and ice away from the outdoor fan and prevents build-

up on the fan guard.

XP17 - 2 to 5 Ton Heat Pump / Page 8

Solar Modules

Future

Modules

Air Conditioner

or Heat Pump

Standard

Outlet

Communication

Gateway

Performance

Monitoring

Website

Broadband

Internet

Connection

Electrical

Panel

Unit

SUNSOURCE®HOME ENERGY SYSTEM - COMPONENTS

SYSTEM OVERVIEW

All Dave Lennox Signature®

Collection air conditioners and

heat pumps are equipped at the

factory for upgrading to the

SunSource®Home Energy System.

Units can be upgraded at the time of installation or in

the future.

Solar energy is rst used to meet cooling/heating

demands. When the cooling/heating system is not

operating, the system powers lighting, appliances and

other electronic devices in the home. And in some

locations, any surplus power is sent back to the utility

company for a possible credit (check with your local

utility company for availability).

The SolarSync™ Package consists of the following

components:

• Lennox Solar Subpanel eld installed in a Dave

Lennox Signature®Collection air conditioner or heat

pump unit.

• Solar Modules (1 to 15 may be used to vary the

amount of electricity generated).

• Envoy Communications Gateway that monitors home

energy usage.

All components must be ordered separately.

Wiring from the roof mounted solar modules is routed to

the outdoor unit. From there power travels to the home

electrical service panel using the existing outdoor unit

power wiring.

NOTE - Refer to separate Product Specications

Bulletin for the SunSource®Home Energy System

for more detailed information. See section Solar - Kits/

Accessories.

Also refer to SunSource®Home Energy System

Applications and Design Guidelines Manual (Corp.

1021-L3) for complete information on designing, sizing

and installing a complete system.

APPROVALS

The SunSource®Home Energy System meets the

requirements for federal tax credits listed under the

U.S. Emergency Economic Stabilization Act of 2008,

covering 30% of the cost of the solar modules, including

installation.

LENNOX® SOLAR SUBPANEL

The Lennox®Solar Subpanel replaces the

factory piping panel on the outdoor unit and

provides circuit breaker protection and power

entry for both HVAC (line) and solar power

wiring.

Subpanel is equipped with separate circuit

breakers for both HVAC (line) voltage and

solar power.

Equipped with pigtail connections for easy

eld wiring.

Subpanel is an ETL listed accessory.

Split design (upper/lower panel) allows installation on

different size outdoor units. Subpanel is furnished with

three separate lower panels. See Outdoor Unit Usage

table for correct lower panel size.

Note - Subpanel is not backwards compatible with older

Dave Lennox Signature®Collection outdoor units.

Disconnects for HVAC (line) and solar power wiring are

not furnished and must be eld provided.

SOLAR MODULES

Converts solar energy

into electricity.

Built-in racking

hardware, wiring,

grounding and

microinverters.

Microinverters produce

AC power synchronized to the utility grid.

Modules operate independently from each other

allowing modules that are not shaded or dirty to operate

with optimum performance.

Racking system is built-in to the module frame.

Painted at black frame.

Solar modules are available in packages of four or fteen.

Solar modules are CSA listed for the US and Canada

to UL Standard 1703 and meet National and Canadian

Electrical Code requirements.

XP17 - 2 to 5 Ton Heat Pump / Page 9

SOLAR MODULES (CONTINUED)

Roof Mounting Kits

Several roof mounting kits for mounting Solar Modules

are available for a variety of different roof styles. All

kits contain sufcient hardware for mounting four solar

modules.

NOTE - All kits contain sufcient hardware for mounting

four solar modules.

1Composition (Asphalt) Shingle Roof

Mounting Kit

Qty.

Composition Flashing Mounts 10

Serrated L-Brackets 10

East-West Solar Module Splices 6

North-South Solar Module Brackets 4

Lag Bolts 10

Flange Nuts 20

Hex Bolts 20

Fender Washers 10

Wire Spring Clips 10

Ground Lug w/Screw 2

Installation Wrenches 2

S or Barrel Tile Roof Mounting Kit Qty.

S/Barrel Tile Mounts 10

Serrated L-Brackets 10

East-West Solar Module Splices 6

North-South Solar Module Brackets 4

FastJack®Roof Stanchion 6 in. 10

Lag Bolts 10

Hex Bolts 20

Flange Nuts 20

Fender Washers 6

Wire Spring Clips 10

Ground Lug w/Screw 2

Wrenches 2

1 15-Pack also available.

Flat (Cement) Tile Roof Mounting Kit Qty.

Flat Tile Brackets 10

Universal Tile Brackets 10

East-West Solar Module Splices 6

North-South Solar Module Brackets 4

Lag Bolts 40

Flange Nuts 40

Fender Washers 20

Hex Bolts 10

Flat Washers 20

Wire Spring Clips 10

Ground Lug w/Screw 2

Wrenches 2

Standing Seam Roof Mounting Kit Qty.

S-5!™standing seam clamps 10

Serrated L-Brackets 10

East-West Solar Module Splices 6

North-South Solar Module Brackets 4

Hex Bolts 10

Wire Spring Clips 10

Ground Lug w/Screw 2

Wenches 2

Trapezoidal Sheet Metal Roof Mounting Kit Qty.

S-5! VB-47 mounting brackets 10

East-West Solar Module Splices 6

North-South Solar Module Brackets 4

Serrated L-Brackets 10

Hex Bolts 30

Flange Nuts 30

Washers 30

Wire Spring Clips 10

Ground Lug w/Screw 2

Wrenches 2

SUNSOURCE®HOME ENERGY SYSTEM - COMPONENTS

XP17 - 2 to 5 Ton Heat Pump / Page 10

SUNSOURCE®HOME ENERGY SYSTEM - COMPONENTS

SOLAR MODULES (CONTINUED)

Installation Kits and Tools

AC System Kit (Required - One per each outdoor unit)

Kit includes interconnection cable required to connect

the eld installed wiring from the solar modules to the

outdoor unit. Also includes the end cap to place on

the last microinverter connection in the row. One kit

required per outdoor unit.

Kit contains 6 ft. AC interconnection cable and end cap.

AC 6 Foot Extension Cable

Six foot extension cable for connecting one row of

modules to the next if they are further than the standard

interconnection cable can reach (second row above or

below, etc.). Only required for multiple rows.

Rooftop Junction Box

Flash mounted rooftop junction box is used to transition

from interconnection cable to wiring/conduit to the

outside HVAC unit. Use one for each outdoor unit.

Professional Installer Tool Kit

Installer tools to aid in installation. Includes driver to

tighten splices with ratchet from opposite side of module

(in place of wrench) and step block to support module

while until splices and mounting points are installed.

Includes (2) Splice Drivers and (2) Step Blocks.

Solar Module Splices

Required if installing a second row of solar modules

above or below an existing row or adding additional 4

packs of modules end to end.

Splices used in top and bottom applications are not a

grounding component and only act as a rigid attachment

to support the upper or lower module frame of the

second row to the module frame of the existing row.

Allows for fewer roof penetrations by supporting the

upper and lower solar modules in a two-row application

with a common roof mount in-between.

Kit contains 10 splices.

SYSTEM MONITORING

Envoy Communications Gateway

(Communications Booster Furnished)

The Envoy Communications

Gateway monitors

microinverter (on solar

modules) performance

and can be connected

to a broadband internet

connection to send data to the Enphase Enlighten™

web site for online monitoring by the homeowner. The

Envoy Communications Gateway is not required, but

must be used if system performance monitoring is

desired.

System monitoring is also available locally with the

Envoy Communications Gateway and a personal

computer if no internet connection is available.

Various Event Messages are also available when

monitoring the system via a personal computer locally.

Contents - (1) Envoy Communications Gateway, (1) 6 ft.

power cord, (1) 10 ft. Ethernet cable, communications

booster.

CSA (US/C) listed.

Communications Booster

Ethernet bridge signal booster for the Envoy

Communications Gateway. Booster is only needed if the

communications gateway is installed and signal is not

strong enough in the installed location. Allows the unit to

be plugged into an outlet closer to the distribution panel,

yet still plug into the broadband router.

Enphase Enlighten™ Performance Monitoring

Website

Communications Gateway,

the Enphase Enlighten™

Performance Monitoring

website allows the

homeowner to keep track

of home energy usage and

see environmental benets

in real time.

See demos, view reference

installations and other additional information at:

http://enlighten.enphaseenergy.com/

XP17 - 2 to 5 Ton Heat Pump / Page 11

LENNOX®SOLAR SUBPANEL - OUTDOOR UNIT USAGE

Outdoor Unit Model No. Lower Subpanel Height - in. (mm)

17 (432) 27 (686)

XP17-024-030-036-042 X

XP17-048-060 X

SUNSOURCE®HOME ENERGY SYSTEM - COMPONENTS

Description Catalog Number

OUTDOOR UNIT COMPONENTS

Lennox®Solar Subpanel

(see table below for lower subpanel usage)

67W83

SOLAR COMPONENTS

Solar Module

190 W, single-phase 240 VAC. Weight - 42 lbs. (each module)

Y4675 (4-pack)

Y4674 (15-pack)

Dimensions (L x W x D)

62-1/2 x 32 x 2 in. (1588 x 813 x 51 mm)

ROOF MOUNTING KITS FOR SOLAR MODULES

Composition (Asphalt) Shingle Y4583 (4-pack)

Y4582 (15-pack)

Flat (Cement) Tile Y4584 (4-pack)

S or Barrel Tile Y4585 (4-pack)

Standing Seam Y4586 (4-pack)

Trapezoidal Sheet Metal Y4587 (4-pack)

INSTALLATION KITS AND TOOLS

AC System Kit (Required - One per each outdoor unit) Y3310

AC 6 Foot Extension Cable Y3313

Rooftop Junction Box Y3312

Professional Installer Tool Kit Y4588

East-West Solar Module Splices (10-Pack) Y4589

MONITORING CONTROLS

Envoy Communications Gateway

(Communications Booster Furnished)

Y4263

XP17 - 2 to 5 Ton Heat Pump / Page 12

SPECIFICATIONS

General

Data

Model No. XP17-024 XP17-030 XP17-036 XP17-042 XP17-048 XP17-060

Nominal Tonnage 2 2.5 3 3.5 4 5

Connections

(sweat)

Liquid line (o.d.) - in. 3/8 3/8 3/8 3/8 3/8 3/8

Vapor (Suction) line (o.d.) - in. 3/4 3/4 7/8 7/8 7/8 1-1/8

Refrigerant 1 R-410A charge furnished 10 lbs. 0 oz. 10 lbs. 2 oz. 10 lbs. 2 oz. 11 lbs. 0 oz. 14 lbs. 0 oz. 14 lbs. 8 oz.

Outdoor

Coil

Net face area

- sq. ft.

Outer coil 20.73 20.73 20.73 20.73 27.21 27.21

Inner coil 20.08 20.08 20.08 20.08 26.36 26.36

Tube diameter - in. 5/16 5/16 5/16 5/16 5/16 5/16

No. of rows 2 2 2 2 2 2

Fins per inch 22 22 22 22 22 22

Outdoor

Fan

Diameter - in. 26.2 26.2 26.2 26.2 26.2 26.2

No. of blades 5 5 5 5 5 5

Motor hp 1/3 1/3 1/3 1/3 1/3 1/3

Cfm 2300 2600 3500 3500 4230 4230

Rpm 400 450 600 600 675 675

Watts 40 57 130 130 185 185

Shipping Data - lbs. 1 pkg. 287 287 288 312 349 356

ELECTRICAL DATA

Line voltage data - 60hz - 1 ph 208/230V 208/230V 208/230V 208/230V 208/230V 208/230V

2 Maximum overcurrent protection (amps) 30 30 35 40 50 60

3 Minimum circuit ampacity 18.9 19.6 22.9 24.4 29.3 35.0

Compressor Rated load amps 13.5 14.1 16.7 17.9 21.8 26.4

Locked rotor amps 58.3 73.0 79.0 107.0 117.0 134

Power factor 0.99 0.99 0.97 0.92 0.96 0.96

Outdoor Fan Motor Full load amps 2 2 2 2 2 2

CONTROLS

icomfort Wi-Fi™ Thermostat 88W58 

4Remote Outdoor Temperature

Sensor (for dual fuel and Humiditrol®)

X2658 

5Discharge Temperature Sensor 88K38 

ComfortSense®7000 Thermostat Y0349 

Outdoor Temperature Sensor - for

ComfortSense 7000 Thermostat

X2658 

OPTIONAL ACCESSORIES - ORDER SEPARATELY

Compressor Hard Start Kit 88M91 

Compressor Low Ambient Cut-Off 45F08 

Freezestat 3/8 in. tubing 93G35 

5/8 in. tubing 50A93 

Low Ambient Kit 68M04 

Indoor Blower Off Delay Relay 58M81 

Mild Weather Kit 33M07 

Monitor Kit - Service Light 76F53 

Outdoor

Thermostat Kit

Thermostat 56A87 

Mounting Box 31461 

Refrigerant

Line Sets

L15-41-20 L15-41-40

L15-41-30 L15-41-50

 

L15-65-30 L15-65-40

L15-65-50



Field Fabricate 

6Snow Guards X8782 

NOTE - Extremes of operating range are plus 10% and minus 5% of line voltage.

1 Refrigerant charge sufcient for 15 ft. length of refrigerant lines.

2 HACR type breaker or fuse.

3 Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.

4 Remote Outdoor Sensor may be used with an icomfort™-enabled outdoor unit for a secondary (alternate) sensor reading. Sensor may also be used with a conventional

outdoor unit.

5 Optional for service diagnostics.

6 Adds 11-1/2 inches (292 mm) to unit height.

XP17 - 2 to 5 Ton Heat Pump / Page 13

See

Notes

See

Notes

See

Notes

See

Notes

Service

INSTALLATION CLEARANCES

DISCONNECT

SWITCH

(By Others)

OPTIONAL

OUTDOOR

THERMOSTAT LENNOX

INDOOR UNIT

OPTIONAL

ELECTRIC

HEAT

THERMOSTAT

(Optional)

LENNOX

OUTDOOR

UNIT

DISCONNECT

SWITCH

(By Others)

A - Two Wire Power (see Electrical Data)

B - Two or Three Wire Power (size to heater capacity)

C - Twelve Wire Low Voltage 18 ga. minimum

Fourteen Wire Low Voltage with Optional Outdoor Thermostat

D - Eight Wire Low Voltage 18 ga. minimum

Ten Wire Low Voltage with Optional Outdoor Thermostat

NOTE - Field Wiring Not Furnished

All wiring must conform to NEC or CEC and local electrical codes.

NOTES:

One of these three sides must be 36 in. (914 mm).

One of the two remaining sides may be 12 in. (305 mm).

The remaining side may be 6 in. (152 mm).

Service Clearance − 30 in. (762 mm)

48 in. (1219 mm)clearance required on top of unit

24 in. (610 mm) required between two units

FIELD WIRING

SOUND DATA

1Unit

Model No.

Octave Band Sound Power Levels dBA, re 10-12 Watts

Center Frequency - HZ 1Sound Rating

Number (dB)

125 250 500 1000 2000 4000 8000

XP17-024 49.4 53.8 58.6 57.8 51.3 46.0 39.7 63

XP17-030 53.5 55.0 61.5 63.0 51.0 45.5 42.5 67

XP17-036 50.4 56.9 63.8 60.5 55.7 50.5 37.9 71

XP17-042 53.4 56.9 62.8 60.0 63.7 50.0 39.4 72

XP17-048 60.5 63.0 67.0 65.5 60.5 54.5 48.0 73

XP17-060 57.0 64.0 69.0 67.0 63.0 57.5 52.0 73

NOTE - the octave sound power data does not include tonal correction.

1Tested according to AHRI Standard 270-2008 test conditions.

XP17 - 2 to 5 Ton Heat Pump / Page 14

39-1/2 (1003) 35-1/2 (902)

37 (940) -024-30-036-042

47 (1140) - 048-060

18-1/2

(470)

8 (203)

1 (25)

4-1/2

(114)

LIQUID LINE

INLET

SUCTION LINE

INLET

ELECTRICAL

INLET

TOP VIEW

WEIVSSECCAWEIVEDIS

DISCHARGE AIR

UNIT SUPPORT

FEET

TOP VIEW BASE SECTION

(Large Base)

16-7/8

(429)

4-5/

17)

26-7/8

(683)

8-3/4

(222)

30-3/4

(781)

3-3/4

(95)

3-1/8

(79)

DIMENSIONS - INCHES (MM)

XP17 - 2 to 5 Ton Heat Pump / Page 15

*TXV SUBSTITUTIONS

Indoor Coils/Air Handlers with factory installed expansion

valves that require eld replacement

Model No. Indoor Coil or Air

Handler

Order No.

XP17-030 CX34-43 49L24

XP17-030 CX34-44/48 49L24

XP17-030 CX34-49 49L24

XP17-030 CX34-50/60 49L24

XP17-036 CBX32MV-048 49L25

XP17-036 CBX32M-048 49L25

XP17-036 CBX40UHV-036 49L25

XP17-036 CBX40UHV-042 49L25

XP17-036 CBX40UHV-048 49L25

XP17-036 CX34-49 49L25

XP17-042 CX34-38 91M02

XP17-042 CX34-44/48B 91M02

XP17-042 CX34-43 91M02

* Factory installed expansion valve on the indoor coil or air handler shown must

be replaced with the expansion valve listed (ordered separately).

TXV USAGE

Model No. Order No.

XP17-024 49L24

XP17-030 49L24

XP17-036 49L25

XP17-042 91M02

XP17-048 91M02

XP17-060 91M02

CX34 upow coils and all Lennox air handlers (except CB26UH “R”) are

shipped with a factory installed TXV. In most cases, no change out of the valve

is needed.

If a change out is required it will be listed in the “TXV SUBSTITUTIONS” table.

The correct TXV must be ordered and eld installed. C33 coils and all horizon-

tal and downow coils are shipped without a TXV. The TXV must be ordered

and eld installed.

MOST POPULAR MATCHES

Outdoor Unit

Model No.

Indoor Unit

Model No

XP17-024 CBX32MV-024/030

XP17-030 CBX32MV-024/030

XP17-036 CBX32MV-048

XP17-042 CBX32MV-048

XP17-048 CBX32MV-060

XP17-060 CBX32MV-060

AHRI STANDARD 210/240

Cooling or heating capacities are net values, including

the effects of blower motor heat, and do not include

supplementary heat. Power input is the total power input

to the compressor(s) and fan(s), plus any controls and

other items required as part of the system for normal

operation.

Units which do not have an indoor air-circulating blower

furnished as part of the model, i.e., split system with

indoor coil only, is established by subtracting from the

total cooling capacity 1250 Btu/h per 1,000 cfm, and by

adding the same amount to the heating capacity. Total

power input for both heating and cooling is increased by

365 W per 1,000 cfm of indoor air circulated.

XP17 - 2 to 5 Ton Heat Pump / Page 16

AHRI SYSTEM MATCHES

Model No. Cooling

Capacity SEER EER Heat Capacity Heat COP HSPF

(IV)

Coil or

Air Handler Furnace AHRI

Reference

High Low High Low

XP17-024-230 24,800 17.20 14.20 21,200 14,100 3.54 2.50 8.70 C33-31 EL195UH045XE36B 4693555

XP17-024-230 24,600 17.20 14.20 21,200 14,100 3.62 2.54 9.00 C33-31 EL195UH070XE36B 4693556

XP17-024-230 24,600 17.20 14.20 21,200 14,000 3.60 2.54 9.00 C33-31 EL296UH070XV36B 5054700

XP17-024-230 24,400 16.70 14.00 21,400 14,200 3.58 2.52 8.70 C33-31 ML180UH045E36A 4669889

XP17-024-230 24,400 16.70 14.00 21,400 14,200 3.58 2.52 8.70 C33-31 ML180UH045XE36A 4671800

XP17-024-230 24,800 17.20 14.20 21,200 14,100 3.64 2.56 8.70 C33-31 ML180UH070E36B 4669890

XP17-024-230 24,800 17.20 14.20 21,200 14,100 3.64 2.56 8.70 C33-31 ML180UH070XE36B 4671917

XP17-024-230 24,600 16.50 13.70 21,400 14,300 3.46 2.46 8.70 C33-31 O23V2/3-70/90 3843905

XP17-024-230 24,600 16.70 13.70 21,400 14,200 3.48 2.46 8.70 C33-31 O23V3/4-105/120 3843906

XP17-024-230 25,000 17.50 14.50 21,400 14,100 3.64 2.56 9.00 C33-31 SL280UH070V36A 3894581

XP17-024-230 25,000 17.50 14.50 21,400 14,100 3.64 2.56 9.00 C33-31 SL280UH070XV36A 4041563

XP17-024-230 24,800 17.70 14.50 21,200 14,000 3.60 2.54 8.70 C33-31 SL280UH090V36B 3894582

XP17-024-230 24,600 16.70 13.70 21,400 14,200 3.48 2.46 8.70 C33-31 SLO183UF101/114V42 5505652

XP17-024-230 24,600 16.50 13.70 21,400 14,300 3.46 2.46 8.70 C33-31 SLO183UF68/86V36 5505651

XP17-024-230 24,600 17.20 14.20 21,200 14,000 3.60 2.54 9.00 C33-31 SLP98UH070XV36B 5137369

XP17-024-230 24,200 15.00 12.70 22,000 14,700 3.36 2.36 8.20 C33-31 3839730

XP17-024-230 24,200 17.00 14.00 21,200 14,100 3.56 2.52 8.70 C33-38 EL195UH045XE36B 4693557

XP17-024-230 24,600 17.00 14.20 21,400 14,100 3.66 2.56 9.00 C33-38 EL195UH070XE36B 4693558

XP17-024-230 24,400 16.70 14.00 21,400 14,200 3.60 2.54 9.00 C33-38 ML180UH045E36A 4669891

XP17-024-230 24,400 16.70 14.00 21,400 14,200 3.60 2.54 9.00 C33-38 ML180UH045XE36A 4671801

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.68 2.58 9.00 C33-38 ML180UH070E36B 4669892

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.68 2.58 9.00 C33-38 ML180UH070XE36B 4671918

XP17-024-230 24,200 16.20 13.50 21,400 14,300 3.48 2.46 8.70 C33-38 O23V2/3-70/90 3843907

XP17-024-230 24,200 16.20 13.70 21,400 14,300 3.50 2.50 8.70 C33-38 O23V3/4-105/120 3843908

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.70 2.58 9.00 C33-38 SL280UH070V36A 3894583

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.70 2.58 9.00 C33-38 SL280UH070XV36A 4041564

XP17-024-230 24,200 17.20 14.20 21,200 14,000 3.62 2.56 9.00 C33-38 SL280UH090V36B 3894584

XP17-024-230 24,200 16.20 13.70 21,400 14,300 3.50 2.50 8.70 C33-38 SLO183UF101/114V42 5505654

XP17-024-230 24,200 16.20 13.50 21,400 14,300 3.48 2.46 8.70 C33-38 SLO183UF68/86V36 5505653

XP17-024-230 24,000 15.00 12.50 22,000 14,700 3.40 2.38 8.50 C33-38 3839737

XP17-024-230 24,600 17.20 14.20 22,000 14,300 3.74 2.66 9.20 CBX27UH-024 3839712

XP17-024-230 24,800 17.70 14.70 22,000 14,200 3.84 2.70 9.50 CBX27UH-030 3839713

XP17-024-230 24,200 15.70 13.20 22,400 14,600 3.58 2.54 9.00 CBX32M-030 3839714

XP17-024-230 24,200 15.70 13.20 22,600 14,700 3.62 2.56 8.70 CBX32M-036 3839715

XP17-024-230 25,000 17.50 14.50 22,200 14,400 3.82 2.68 9.50 CBX32MV-024/030 3839707

XP17-024-230 25,000 17.20 14.20 22,400 14,500 3.86 2.70 9.50 CBX32MV-036 3839708

XP17-024-230 24,800 17.20 14.20 22,200 14,400 3.80 2.68 9.50 CBX40UHV-024 3839709

XP17-024-230 24,600 17.00 14.20 22,200 14,400 3.78 2.68 9.20 CBX40UHV-030 3839710

XP17-024-230 25,200 17.20 14.20 22,400 14,500 3.88 2.72 9.50 CBX40UHV-036 3839711

XP17-024-230 24,200 16.70 14.00 21,400 14,100 3.60 2.52 8.70 CH33-31 SL280UH090V48B 4249309

XP17-024-230 24,400 16.70 14.00 21,600 14,200 3.70 2.58 9.00 CH33-31A ML180UH045E36A 4666835

XP17-024-230 24,400 16.70 14.00 21,600 14,200 3.70 2.58 9.00 CH33-31A ML180UH045XE36A 4671793

XP17-024-230 24,400 17.00 14.00 21,600 14,200 3.76 2.60 9.20 CH33-31A SL280UH070V36A 3894585

XP17-024-230 24,400 17.00 14.00 21,600 14,200 3.76 2.60 9.20 CH33-31A SL280UH070XV36A 4041565

XP17-024-230 23,800 15.00 12.50 22,000 14,700 3.42 2.40 8.50 CH33-31A 3839744

XP17-024-230 24,200 17.00 14.00 21,400 14,100 3.60 2.52 8.70 CH33-31B EL195UH045XE36B 4693549

XP17-024-230 24,600 17.00 14.20 21,400 14,100 3.68 2.56 9.00 CH33-31B EL195UH070XE36B 4693550

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.70 2.58 9.00 CH33-31B EL296UH070XV36B 5054698

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.70 2.58 9.00 CH33-31B ML180UH070E36B 4666836

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.70 2.58 9.00 CH33-31B ML180UH070XE36B 4671903

NOTES:

Ratings are AHRI certied to AHRI Standard 210/240 (with 25 ft. of connecting refrigerant lines);

• Cooling Ratings - 95°F outdoor air temperature and 80 °F db/67° F wb entering indoor coil air.

• High Temperature Heating Ratings - 47° F db/43° F wb outdoor air temperature and 70 °F db entering indoor coil air.

• Low Temperature Heating Ratings - 17 °F db/15° F wb outdoor air temperature and 70 °F db entering indoor coil air.

All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed Furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air

Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.

Also see TXV Substitution Table at the beginning of the Heat Pump AHRI System Matches section.

When used with gas furnaces, a dual-fuel control, a control system with dual-fuel capabilities (LZP-2 or LZP-4), or a thermostat with dual-fuel capabilities must be used

(order separately).

To convert HSPF from Region IV to Region V - Divide by 1.15.

XP17 - 2 to 5 Ton Heat Pump / Page 17

AHRI SYSTEM MATCHES

Model No. Cooling

Capacity SEER EER Heat Capacity Heat COP HSPF

(IV)

Coil or

Air Handler Furnace AHRI

Reference

High Low High Low

XP17-024-230 24,200 17.20 14.20 21,200 14,000 3.64 2.56 9.00 CH33-31B SL280UH090V36B 3894586

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.70 2.58 9.00 CH33-31B SLP98UH070XV36B 5137321

XP17-024-230 23,800 15.00 12.50 21,800 14,600 3.34 2.36 8.20 CH33-31B 3839746

XP17-024-230 24,000 16.70 13.70 21,200 14,100 3.54 2.50 8.70 CH33-42 EL195UH045XE36B 4693551

XP17-024-230 24,400 17.00 14.00 21,400 14,100 3.62 2.54 9.00 CH33-42 EL195UH070XE36B 4693552

XP17-024-230 24,400 17.20 14.20 21,400 14,100 3.66 2.56 9.00 CH33-42 EL296UH070XV36B 5054699

XP17-024-230 24,400 17.00 14.20 21,400 14,100 3.64 2.56 9.00 CH33-42 ML180UH070E36B 4669549

XP17-024-230 24,400 17.00 14.20 21,400 14,100 3.64 2.56 9.00 CH33-42 ML180UH070XE36B 4671915

XP17-024-230 24,200 17.20 14.20 21,200 14,000 3.60 2.54 8.70 CH33-42 SL280UH090V36B 3894587

XP17-024-230 24,000 16.70 13.70 21,400 14,100 3.56 2.50 8.70 CH33-42 SL280UH090V48B 4249310

XP17-024-230 24,400 17.20 14.20 21,400 14,100 3.66 2.56 9.00 CH33-42 SLP98UH070XV36B 5137322

XP17-024-230 23,600 14.70 12.50 21,800 14,600 3.30 2.34 8.20 CH33-42 3839752

XP17-024-230 22,400 15.50 13.00 21,600 14,300 3.66 2.58 9.00 CR33-48 EL195DF045XE36B 4693553

XP17-024-230 22,600 15.70 13.00 21,800 14,300 3.76 2.62 9.20 CR33-48 EL195DF070XE48B 4693554

XP17-024-230 29,200 15.50 12.70 21,800 14,400 3.68 2.58 9.20 CR33-48 EL296DF045V36B 5066117

XP17-024-230 22,400 15.00 12.50 21,600 14,300 3.78 2.64 9.00 CR33-48 ML180DF070E36B 4669551

XP17-024-230 22,400 15.00 12.50 21,800 14,400 3.68 2.58 9.00 CR33-48 SL280DF070V36A 3894588

XP17-024-230 22,400 15.00 12.50 21,600 14,300 3.64 2.58 9.00 CR33-48 SL280DF090V48B 3894589

XP17-024-230 22,600 15.70 13.00 21,800 14,400 3.72 2.62 9.20 CR33-48 SLP98DF070XV36B 5136883

XP17-024-230 22,000 13.70 11.50 22,200 14,800 3.42 2.42 8.50 CR33-48 3839757

XP17-024-230 24,800 17.20 14.20 21,200 14,100 3.54 2.50 8.70 CX34-31 EL195UH045XE36B 4693545

XP17-024-230 24,600 17.20 14.20 21,200 14,100 3.62 2.54 9.00 CX34-31 EL195UH070XE36B 4693546

XP17-024-230 24,600 17.20 14.20 21,200 14,000 3.60 2.54 9.00 CX34-31 EL296UH070XV36B 5054697

XP17-024-230 24,400 16.70 14.00 21,400 14,200 3.58 2.52 8.70 CX34-31 ML180UH045E36A 4666831

XP17-024-230 24,400 16.70 14.00 21,400 14,200 3.58 2.52 8.70 CX34-31 ML180UH045XE36A 4671791

XP17-024-230 24,800 17.20 14.20 21,200 14,100 3.64 2.56 8.70 CX34-31 ML180UH070E36B 4666832

XP17-024-230 24,800 17.20 14.20 21,200 14,100 3.64 2.56 8.70 CX34-31 ML180UH070XE36B 4671901

XP17-024-230 24,600 16.50 13.70 21,400 14,300 3.46 2.46 8.70 CX34-31 O23V2/3-70/90 3843901

XP17-024-230 24,600 16.70 13.70 21,400 14,200 3.48 2.46 8.70 CX34-31 O23V3/4-105/120 3843902

XP17-024-230 25,000 17.50 14.50 21,400 14,100 3.64 2.56 9.00 CX34-31 SL280UH070V36A 3894577

XP17-024-230 25,000 17.50 14.50 21,400 14,100 3.64 2.56 9.00 CX34-31 SL280UH070XV36A 4041561

XP17-024-230 24,800 17.70 14.50 21,200 14,000 3.60 2.54 8.70 CX34-31 SL280UH090V36B 3894578

XP17-024-230 24,800 17.20 14.20 21,200 14,100 3.52 2.50 8.70 CX34-31 SL280UH090V48B 4249307

XP17-024-230 24,600 16.70 13.70 21,400 14,200 3.48 2.46 8.70 CX34-31 SLO183UF101/114V42 5505648

XP17-024-230 24,600 16.50 13.70 21,400 14,300 3.46 2.46 8.70 CX34-31 SLO183UF68/86V36 5505647

XP17-024-230 24,600 17.20 14.20 21,200 14,000 3.60 2.54 9.00 CX34-31 SLP98UH070XV36B 5136882

XP17-024-230 24,200 15.00 12.70 22,000 14,700 3.36 2.36 8.20 CX34-31 3839716

XP17-024-230 24,200 17.00 14.00 21,200 14,100 3.56 2.52 8.70 CX34-38 EL195UH045XE36B 4693547

XP17-024-230 24,600 17.00 14.20 21,400 14,100 3.66 2.56 9.00 CX34-38 EL195UH070XE36B 4693548

XP17-024-230 24,400 16.70 14.00 21,400 14,200 3.60 2.54 9.00 CX34-38 ML180UH045E36A 4666833

XP17-024-230 24,400 16.70 14.00 21,400 14,200 3.60 2.54 9.00 CX34-38 ML180UH045XE36A 4671792

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.68 2.58 9.00 CX34-38 ML180UH070E36B 4666834

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.68 2.58 9.00 CX34-38 ML180UH070XE36B 4671902

XP17-024-230 24,200 16.20 13.50 21,400 14,300 3.48 2.46 8.70 CX34-38 O23V2/3-70/90 3843903

XP17-024-230 24,200 16.20 13.70 21,400 14,300 3.50 2.50 8.70 CX34-38 O23V3/4-105/120 3843904

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.70 2.58 9.00 CX34-38 SL280UH070V36A 3894579

XP17-024-230 24,600 17.20 14.20 21,400 14,100 3.70 2.58 9.00 CX34-38 SL280UH070XV36A 4041562

XP17-024-230 24,200 17.20 14.20 21,200 14,000 3.62 2.56 9.00 CX34-38 SL280UH090V36B 3894580

XP17-024-230 24,200 16.70 14.00 21,400 14,100 3.58 2.52 8.70 CX34-38 SL280UH090V48B 4249308

XP17-024-230 24,200 16.20 13.70 21,400 14,300 3.50 2.50 8.70 CX34-38 SLO183UF101/114V42 5505650
