Lenovo ThinkStation E32 User manual
Product Specifications Reference
Lenovo®ThinkStation®Workstations
January 2014 - Version 449
ThinkStation Family
(ThinkStation E32 SFF/E32 Tower/D30/S30/C30)
Visit www.lenovo.com/psref for the latest version
ThinkStation E32 Tower - Overview
1. External 5.25” Bay for optical
2. External 5.25” Bay for optical
or optional 3.5" hard drive bay
3. Media card reader (optional)
or optional mSATA SSD drive
4. Power Button
5. Front I/O: 2 USB 3.0 (blue)
1 Headphone
1 Microphone
Front view
6. 280 watts Power Supply, 80 PLUS Bronze
7. Rear I/O: 2 USB 2.0
4 USB 3.0(blue)
1 serial (9-pin)
1 RJ-45 (GbE)
1 line-in
1 line-out
1 microphone-in
2 DisplayPort (for Intel HD Graphics)
1 VGA (for Intel HD Graphics)
8. 1 PCIe 3.0 x16
1 PCIe 2.0 x1
1 PCIe 2.0 x16 (x4 elec)
1 PCI
Rear view
Internal
• One LGA1150 socket, supports one processor from Intel Xeon E3-1200 v3, Core i7-4000, and Core-i5 4000 families
• 4 DIMM sockets, supports up to 32GB ECC or non-ECC UDIMM memory
• Up to three 3.5" hard drive bays, two 3.5" hard drive bays are standard
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
• 27.56 lb (12.5kg) max configuration
•25-liter
1
2
3
4
5
6
7
8
ThinkStation E32 SFF - Overview
1. Power Button
2. Media card reader (optional)
or optional mSATA SSD drive
3. Front I/O: 2 USB 3.0 (blue)
1 Headphone
1 Microphone
4. 1 External 5.25” Bay for optical
or optional slim optical + 3.5" hard drive bay
or optional standalone 3.5" hard drive bay
Front view
5. 240 watts Power Supply, 80 PLUS Bronze
6. Rear I/O: 2 USB 2.0
4 USB 3.0(blue)
1 serial (9-pin)
1 RJ-45 (GbE)
1 line-in
1 line-out
1 microphone-in
2 DisplayPort (for Intel HD Graphics)
1 VGA (for Intel HD Graphics)
7.* 1 PCIe 3.0 x16
1 PCIe 2.0 x1
1 PCIe 2.0 x16 (x4 elec)
1 PCI
* Discrete graphics adapter is optional
Rear view
1
2
3
4
5
6
7
Internal
• One LGA1150 socket, supports one processor from Intel Xeon E3-1200 v3, Core i7-4000, and Core-i5 4000 families
• 4 DIMM sockets, supports up to 32GB ECC or non-ECC UDIMM memory
• Up to two 3.5" hard drive bays and one 2.5" hard drive bay, one 3.5" hard drive bay is standard
Mechanical
•Raven black color; metal case
• 13.35"W x 15.0"D x 3.93"H
• 338mm W x 375mm D x 102mm H
• 17.20 lb (7.8kg) max configuration
•12.9-liter
ThinkStation E32 Platform Specifications - I of III Product Specifications Reference (PSREF)
Lenovo
(E32-SPEC-I) September 2013
From factor ThinkStation E32 Tower ThinkStation E32 SFF
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel Xeon processors
Processor One LGA1150 socket,
supports one processor from Intel Xeon E3-1200 v3, Core i7-4000, Core-i5 4000, Core-i3 4000, and Pentium G3000 families,
integrated 2-channel DDR3 memory controller, optional integrated processor graphics on selected processors.
The following processors are supported:
Processor Number # of
Cores
# of
Threads
Clock
Speed
Max Turbo
Frequency Cache Memory
speed
ECC Memory
Supported Processor Graphics
Xeon E3-1220 v3 4 4 3.1 GHz 3.5 GHz
8 MB DDR3-1600 Ye s
Xeon E3-1225 v3 4 4 3.2 GHz 3.6 GHz
8 MB DDR3-1600 Ye s Intel HD Graphics P4600
Xeon E3-1230 v3 4 8 3.3 GHz 3.7 GHz
8 MB DDR3-1600 Ye s
Xeon E3-1240 v3 4 8 3.4 GHz 3.8 GHz
8 MB DDR3-1600 Ye s
Xeon E3-1245 v3 4 8 3.4 GHz 3.8 GHz
8 MB DDR3-1600 Ye s Intel HD Graphics P4600
Xeon E3-1270 v3 4 8 3.5 GHz 3.9 GHz
8 MB DDR3-1600 Ye s
Xeon E3-1275 v3 4 8 3.5 GHz 3.9 GHz
8 MB DDR3-1600 Ye s Intel HD Graphics P4600
Xeon E3-1280 v3 4 8 3.6 GHz 4 GHz
8 MB DDR3-1600 Ye s
Core i5-4670 4 4 3.4 GHz 3.8 GHz
6 MB DDR3-1600 Intel HD Graphics 4600
Core i5-4570 4 4 3.2 GHz 3.6 GHz
6 MB DDR3-1600 Intel HD Graphics 4600
Core i7-4770 4 8 3.4 GHz 3.9 GHz
8 MB DDR3-1600 Intel HD Graphics 4600
Core i3-4340 2 4 3.6 GHz 4 MB DDR3-1600 Ye s Intel HD Graphics 4600
Core i3-4330 2 4 3.5 GHz 4 MB DDR3-1600 Ye s Intel HD Graphics 4600
Core i3-4130 2 4 3.4 GHz 3 MB DDR3-1600 Ye s Intel HD Graphics 4400
Pentium G3430 2 2 3.3 GHz 3 MB DDR3-1600 Ye s Intel HD Graphics
Pentium G3420 2 2 3.2 GHz 3 MB DDR3-1600 Ye s Intel HD Graphics
Pentium G3220 2 2 3 GHz 3 MB DDR3-1333 Ye s Intel HD Graphics
Notes:
All processors information is provided by Intel and may be changed at any time without notice. The information herein is provided “as-is”.
Intel may update this information in non-scheduled. For latest information, please see http://ark.intel.com/
Memory type 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets
Memory capacity Up to 32GB ECC/non-ECC (8GBx4)
Additional
memory disclaimers
●Actual memory operating speed depends on processor memory controller speed, installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on Pentium, Core i3, i5, i7 and Xeon E3-12x5 v3 pocessors,
uses main memory, works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports (detailed information please see Rear ports section)
Discrete Graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (40W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 40W max)
Supports the following NVIDIA Quadro, NVS graphics adapters:
Memory
Size
CUDA
Processor Cores Display Connectors Max. Displays
Power
Supported on ThinkStation
E32 Tower E32 SFF
Quadro K2000 2GB 384 1 dual-link DVI-I
2 DisplayPort
4* 51W ●
Quadro K2000D 2GB 384 1 dual-link DVI-I
1 dual-link DVI-D
1 mini DisplayPort
4* 51W ●
Quadro K600 1GB 192 1 dual-link DVI-I
1 DisplayPort
2 41W ● ●
Quadro 410 512MB 192 1 dual-link DVI-I
1 DisplayPort
2 37W ● ●
NVS 510 2GB 192 4 mini DisplayPort
(with 4 mini DP to
DP dongles)
4 35W
● ●
* Quadro K2000 and Quadro K2000D are equipped with 3 onboard display connectors, 4 Displays require a supported DisplayPort 1.2 Multi-Stream capable hub or displays.
ThinkStation E32 Platform Specifications - II of III Product Specifications Reference (PSREF)
Lenovo
(E32-SPEC-II) September 2013
From factor ThinkStation E32 Tower ThinkStation E32 SFF
Discrete Graphics
adapters
Memory
Size
CUDA
Processor Cores Display Connectors Max. Displays
Power
Supported on ThinkStation
E32 Tower E32 SFF
NVS 315 1024MB 48 DMS59 to dual
single-link DVI-I or
dual DisplayPort
2 19.5W
● ●
NVS 310 512 MB 48 2 DisplayPort 2 19.5W
● ●
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1 support,
supports Intel Smart Response Technology
Drive Bays
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Bay 1 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 2 Standard, 5.25”, 1.6” high, external, for optical,
also supports one of the following:
(1) 5.25" slim optical (access) and 3.5" 2nd hard
drive bay (internal), optional
(2) 3.5" 2nd hard drive bay (internal), optional
Bay 3 Optional, 2.5”, 0.6” high, internal, 3rd hard drive bay
Bay 4 Optional, 3.5”, 0.5” high, supports one of the following:
(1) for optional slim media card reader, external
(2) for optional mSATA drive, internal
(Bay 4 is not available on slim optical models)
Notes:
Standard optical and hard drive bays are included in models;
optional optical and hard drive bays are available on models with the
corresponding drives only
Hard drive(s)
Supports the following:
3.5" SATA: SATA 6.0Gb/s, 7200 rpm, up to 3TB (250GB/500GB/1TB/2TB/3TB)
2.5" SATA: SATA 6.0Gb/s, 10000 rpm, up to 1TB (250GB/500GB/1TB)
2.5" SSD: Solid State Drive (SSD), SATA 6.0Gb/s, OPAL-capable on selected models, up to 480GB
(128GB/180GB/240GB/256GB/480GB)
mSATA: m S ATA SSD, SATA 6.0Gb/s, 24GB or 128GB
(24GB mSATA SSD is only for Intel Smart Response Technology enabled models)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Supports DVD-ROM, DVD±RW, or Blu-ray Burner,
1.6" high or slim, SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models Optional 29-in-1 media card reader (slim) on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45), three analog audio ports (line-in, line-out, mic-in)
Expansion slots
Slot 1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
Slot 2: half-length, full-height, PCIe 2.0 x1
Slot 3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
Slot 4: half-length, full-height, PCI 2.3
Slot 1: Low Profile, PCIe
3.0
x16
(40w max, near CPU)
Slot 2: Low Profile, PCIe 2.0 x1
Slot 3: Low Profile, PCIe 2.0 x16 (x4 elec, 40W max)
Slot 4: Low Profile, PCI 2.3
IEEE 1394 adptr
(optional)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Optional Low Profile FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Keyboard Preferred Pro USB Keyboard (USB connector)
Mouse Optical Wheel Mouse, red wheel (USB connector)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
240 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers Computing Bronze, 80 PLUS Bronze qualified
Bay 1
Bay 2
Bay 3
Bay 4
Image above is for reference only. Model in this image contains optional slim optical +
3.5" 2nd hard drive bay with supplemental fan (Bay 2) and optional 2.5"
3rd hard drive bay (Bay 3)
ThinkStation E32 Platform Specifications - III of III Product Specifications Reference (PSREF)
Lenovo
(E32-SPEC-III) September 2013
From factor ThinkStation E32 Tower ThinkStation E32 SFF
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional Kensington®Microsaver®cable; prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Raven black color; metal case
• 13.35"W x 15.0"D x 3.93"H
• 338mm W x 375mm D x 102mm H
•17.20 lb (7.8kg) max configuration
•12.9-liter
Serviceability
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
•Toolless top cover removal
•Toolless disk and optical drive removal
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Environmental
certifications
•GREENGUARD®certified
•RoHS-compliant
•EPEAT™ Gold rating
•ENERGY STAR 5.2-compliant
Warranty 1 or 3-year limited warranty, parts and labor
ThinkVantage®Supports ThinkVantage technologies
Preloaded operating
systems
One the following, depending on model:
•Windows 7 Professional 64
•Windows 7 Professional 64 preinstalled through downgrade rights in Windows 8 Pro 64-bit
•Windows 8 Pro 64-bit
Preloaded
applications
(only some listed)
Preloaded OS
Note
Windows 7 Windows 8
Intel AppUp • •
PC Device Stage • •
Evernote •
Lenovo Companion •
Lenovo Solution Center • •
Lenovo Support •
Norton Internet Security
(30 days of virus definitions) • •
Norton Studio •
Skype • •
Cyberlink PowerDVD • • On models with DVD ROM, DVD±RW and BluRay
Cyberlink PowerDVD Create • • On models with DVD±RW
Cyberlink Power2Go • • On models with DVD±RW
Cyberlink Power Producer • • On models with DVD±RW
Cyberlink PowerDVD Create • • On models with Blu-Ray
Cyberlink Power2Go • • On models with Blu-Ray
Cyberlink Power Producer • • On models with Blu-Ray
Microsoft Office preloaded,
purchase product key to activate • •
AutoCAD LT • • Only on models with Xeon processor
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
ThinkStation E32 Tower (30A1) - TopSeller (August 2013) Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A1-1) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A10007US Core i5-4670
(4C/3.4GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro 410
(512MB, 1xDVI-I DL,
1xDP, 37W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A10008US Xeon E3-1230 v3
(4C/3.3GHz/8MB/1600MHz)
1600MHz
ECC 4GBx1
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A10009US Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
ECC 4GBx2 Intel HD P4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002JUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002KUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002LUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro 410
(512MB, 1xDVI-I DL,
1xDP, 37W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002MUS Core i5-4670
(4C/3.4GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
ThinkStation E32 Tower (30A1) - TopSeller (August 2013) - II Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A1-2) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A1002NUS Core i5-4670
(4C/3.4GHz/6MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002PUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002QUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro 410
(512MB, 1xDVI-I DL,
1xDP, 37W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002RUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002SUS Xeon E3-1225 v3
(4C/3.2GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD P4600 No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002TUS Xeon E3-1225 v3
(4C/3.2GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD P4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002UUS Xeon E3-1240 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
ThinkStation E32 Tower (30A1) - TopSeller (August 2013) - III Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A1-3) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A1002VUS Xeon E3-1240 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002XUS Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600 No 1x180GB SATA SSD DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002YUS Xeon E3-1275 v3
(4C/3.5GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x256GB SATA SSD DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A10030US Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A10031US Xeon E3-1240 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x128GB SATA SSD DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A10032US Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x180GB SATA SSD DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A10033US Xeon E3-1280 v3
(4C/3.6GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
ThinkStation E32 Tower (30A1) - TopSeller (August 2013) - IV Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A1-4) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A10034US Xeon E3-1280 v3
(4C/3.6GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A10035US Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600 No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A10036US Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 128GB SATA
SSD+1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1003BUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A1003CUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A1003DUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro 410
(512MB, 1xDVI-I DL,
1xDP, 37W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A1003EUS Core i5-4670
(4C/3.4GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
ThinkStation E32 Tower (30A1) - TopSeller (August 2013) - V Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A1-5) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A1003FUS Core i5-4670
(4C/3.4GHz/6MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003GUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x500GB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003HUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro 410
(512MB, 1xDVI-I DL,
1xDP, 37W)
No 1x500GB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003JUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003KUS Xeon E3-1225 v3
(4C/3.2GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD P4600 No 1x500GB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003LUS Xeon E3-1225 v3
(4C/3.2GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD P4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003MUS Xeon E3-1240 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
ThinkStation E32 Tower (30A1) - TopSeller (August 2013) - VI Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A1-6) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A1003NUS Xeon E3-1240 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003QUS Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600 No 1x180GB SATA SSD DVD±RW Media No Switch Win8 Pro64
30A1003RUS Xeon E3-1275 v3
(4C/3.5GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x256GB SATA SSD DVD±RW Media No Switch Win8 Pro64
30A1003SUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003TUS Xeon E3-1240 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x128GB SATA SSD DVD±RW Media No Switch Win8 Pro64
30A1003UUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x180GB SATA SSD DVD±RW Media No Switch Win8 Pro64
30A1003VUS Xeon E3-1280 v3
(4C/3.6GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
ThinkStation E32 Tower (30A1) - TopSeller (August 2013) - VII Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A1-7) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A1003WUS Xeon E3-1280 v3
(4C/3.6GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003XUS Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600 No 1x1TB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
30A1003YUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 128GB SATA
SSD+1TB 3.5 SATA DVD±RW Media No Switch Win8 Pro64
ThinkStation E32 Tower (30A1) - TopSeller (September 2013) Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced September 3, 2013
Lenovo
(30A1-8) September 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
Drives Bays
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A1000RUS Core i3-4130
(2C/3.4GHz/3MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4400 No 1x500GB 3.5" SATA DVD±RW Media No Switch Win7 Pro64
30A1000SUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x500GB 3.5" SATA DVD±RW Media No No
Win7 Pro64
(Downgrade
from Win8)
30A1002FUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro 410
(512MB, 1xDVI-I DL,
1xDP, 37W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002GUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002HUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A1002WUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x128GB SATA SSD DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A10037US Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
ThinkStation E32 Tower (30A1) - TopSeller (September 2013) - II Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced September 3, 2013
Lenovo
(30A1-9) September 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
Drives Bays
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A10038US Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro 410
(512MB, 1xDVI-I DL,
1xDP, 37W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A10039US Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A1003AUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A1003PUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x128GB SATA SSD DVD±RW Media No Switch Win8 Pro64
ThinkStation E32 Tower (30A0) - August 2013 Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A0-1) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A0002TUS Core i5-4670
(4C/3.4GHz/6MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A0002UUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A0002VUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A0002WUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A0002XUS Xeon E3-1225 v3
(4C/3.2GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD P4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A0002YUS Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A00030US Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
ThinkStation E32 Tower (30A0) - August 2013 - II Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A0-2) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A00031US Xeon E3-1275 v3
(4C/3.5GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A00032US Core i5-4670
(4C/3.4GHz/6MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x180GB SATA SSD DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A00033US Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x180GB SATA SSD DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A00034US Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x180GB SATA SSD DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A00035US Xeon E3-1280 v3
(4C/3.6GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A00039US Core i5-4670
(4C/3.4GHz/6MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A0003AUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
ThinkStation E32 Tower (30A0) - August 2013 - III Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A0-3) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A0003BUS Core i5-4570
(4C/3.2GHz/6MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A0003CUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A0003DUS Xeon E3-1225 v3
(4C/3.2GHz/8MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD P4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A0003EUS Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A0003FUS Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A0003GUS Xeon E3-1275 v3
(4C/3.5GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A0003HUS Core i5-4670
(4C/3.4GHz/6MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x180GB SATA SSD DVD±RW Media No Switch Win8 Pro64
ThinkStation E32 Tower (30A0) - August 2013 - IV Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced August 20, 2013
Lenovo
(30A0-4) August 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A0003JUS Core i7-4770
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x180GB SATA SSD DVD±RW Media No Switch Win8 Pro64
30A0003KUS Xeon E3-1245 v3
(4C/3.4GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1 Intel HD P4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x180GB SATA SSD DVD±RW Media No Switch Win8 Pro64
30A0003LUS Xeon E3-1280 v3
(4C/3.6GHz/8MB/1600MHz)
1600MHz
Non-ECC 8GBx1
1xQuadro K2000
(2GB, 1xDVI-I DL,
2xDP, 51W)
No 1x1TB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
ThinkStation E32 Tower (30A0) - September 2013 Product Specifications Reference (PSREF)
See footnotes for important warranty information
Model(s) announced September 3, 2013
Lenovo
(30A0-5) September 2013
Chipset Intel C226 Chipset
Intel AMT Intel Active Management Technology 9 supported on models with Intel
Xeon processors
Processor One LGA1150 socket, integrated 2-channel DDR3 memory controller,
optional integrated Intel HD Graphics on selected processors
Memory 1600MHz UDIMM, DDR3, ECC or non-ECC, 2-channel capable
Memory DIMM
sockets Four 240-pin DIMM sockets, up to 32GB ECC/non-ECC (8GBx4)
Additional
memory
disclaimers
●Actual memory operating speed depends on processor memory controller speed,
installed memory speed, and quantity of memory DIMMs
●Mixing of ECC and non-ECC is not supported
●Intel Core i5/i7 processors support non-ECC memory only
Intel HD Graphics
in processor
(optional)
Integrated Intel HD Graphics on selected processors, uses main memory,
works along with discrete graphics to support multi-display,
enables three display connectors (2 DisplayPort, 1 VGA) on rear ports
(detailed information please see Rear ports section)
Discrete graphics
adapters
Two PCI Express x16 slots for discrete graphics adapters:
● One PCI Express 3.0 x16 slot (75W max, near CPU)
● One PCI Express 2.0 x16 slot (x4 electrical, 75W max)
Onboard drive
controllers
Four SATA connectors via onboard drive controller in chipset,
SATA 6.0Gb/s, RAID 0, 1, 5 support,
supports Intel Smart Response Technology
Storage
Up to three 3.5" SATA (SATA 6.0Gb/s, 7200rpm)/2.5" SATA (SATA
6.0Gb/s, 10000rpm)/SATA SSD (SATA 6.0Gb/s) drives;
up to one mSATA SSD drive (SATA 6.0Gb/s)
Optical Supports DVD-ROM, DVD±RW, or Blu-ray Burner, 1.6" high,
SATA interface
Media reader (opt) Optional 29-in-1 media card reader on selected models
Front ports Two USB 3.0 (blue), microphone (3.5mm), headphone (3.5mm)
Rear ports One VGA and two DisplayPort for models with Intel HD Graphics,
two USB 2.0, four USB 3.0 (blue), one serial (9-pin), one ethernet (RJ-45),
three analog audio ports (line-in, line-out, mic-in)
IEEE 1394 adptr
(opt)
Optional FireWire PCIe adapter on selected models,
1394a-2000, 400Mbps, two 6-pin ports on rear
Audio High Definition (HD) Audio, Realtek®ALC662 codec
Speaker Internal speaker for business audio
Onboard Ethernet One onboard gigabit ethernet, Intel I217LM
Security
•Security chip: STMicro ST33ZP24AR28PVSP, TCG 1.2-compliant
•Security slot (in rear for optional KensingtonMicrosavercable;
prohibits side cover removal)
•Power-on/Administrator password
•Boot sequence control
•Boot without keyboard, mouse
•Serial port I/O control
• USB port disablement (front or all/individual)
• Chassis intrusion switch available on selected models
Keyboard/Mouse 104-key keyboard (USB)/Optical Wheel Mouse (USB)
Power supply 280 watts with variable speed fan, autosensing, 85% PSU,
Climate Savers®Computing Bronze, 80 PLUS®Bronze qualified
Environmental
certifications
GREENGUARD®certified/RoHS-compliant/EPEAT™ Gold rating/
ENERGY STAR 5.2 qualified
ISV certifications For the latest list of certifications, please visit www.lenovo.com/support/ISV
Limited warranty13-year parts and labor
Mechanical
•Raven black color; metal case
• 6.9"W x 17.0"D x 16.7"H (with handle)
• 175mm W x 431mm D x 425mm H
•27.56 lb (12.5kg) max configuration
•25-liter
•Removable handle on top front
•Toolless side cover removal
•Toolless disk and optical drive removal (standard bays)
•Toolless adapter retention
•Illuminated front icons
•Recessed power button
Bay 1 Standard, 5.25”, 1.6” high, external, for optical
Bay 2 Standard, 5.25”, 1.6” high, external, for optical or:
optional, 3.5”, 1” high, 3rd hard drive bay
Bay 3 Optional, 3.5”, 1” high, supports one of the following:
(1) for optional media card reader, external
(2) for optional mSATA drive, internal
Bay 4 Standard, 3.5”, 1” high, internal, primary hard drive bay
Bay 5 Standard, 3.5”, 1” high, internal, 2nd hard drive bay
Notes:
Standard optical and hard drive bays are included in models;
optional hard drive bays are available on models with the
corresponding hard drives only
Expansion Slots
1: half-length, full-height, PCIe
3.0
x16
(75w max, near CPU)
2: half-length, full-height, PCIe 2.0 x1
3: half-length, full-height, PCIe 2.0 x16 (x4 elec, 75W max)
4: half-length, full-height, PCI 2.3
● For detailed ThinkStation E32 Tower platform specifications, please see ThinkStation E32 Platform Specifications sheet
* Model in italics shows that this is a Global Model ** DL = Dual Link, SL = Single Link
Drives Bays
Type-
model*Processor
Memory
(MHz/type)
Memory
DIMMs
Intel HD
Graphics
Discrete
graphics
adapters**
Pre-
conf
RAID Storage Optical
29-in-1
Media
reader
1394
adptr
Chassis
intrusion
switch
Preloaded
OS
30A0002QUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A0002RUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A0002SUS Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro 410
(512MB, 1xDVI-I DL,
1xDP, 37W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch
Win7 Pro64
(Downgrade
from Win8)
30A00036US Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro K600
(1GB, 1xDVI-I DL,
1xDP, 41W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A00037US Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600 No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
30A00038US Core i3-4330
(2C/3.5GHz/4MB/1600MHz)
1600MHz
Non-ECC 4GBx1 Intel HD 4600
1xQuadro 410
(512MB, 1xDVI-I DL,
1xDP, 37W)
No 1x500GB 3.5" SATA DVD±RW Media No Switch Win8 Pro64
Other manuals for ThinkStation E32
2
This manual suits for next models
5
Table of contents
Other Lenovo Desktop manuals
Lenovo
Lenovo 10KW User manual
Lenovo
Lenovo ThinkCentre Edge 72z Quick start guide
Lenovo
Lenovo ThinkCentre Edge 72z Troubleshooting guide
Lenovo
Lenovo ThinkCentre M93z Owner's manual
Lenovo
Lenovo ThinkCentre A50p User manual
Lenovo
Lenovo ThinkCentre M90a User manual
Lenovo
Lenovo IdeaCentre Q700 User manual
Lenovo
Lenovo ThinkCentre Edge 91 Owner's manual
Lenovo
Lenovo V130-20IGM AIO Owner's manual
Lenovo
Lenovo ThinkCentre M76 User manual
Lenovo
Lenovo ThinkCentre A57e User manual
Lenovo
Lenovo ThinkCentre Edge 72 Owner's manual
Lenovo
Lenovo ThinkStation S30 User manual
Lenovo
Lenovo ThinkCentre Edge 91z User manual
Lenovo
Lenovo IdeaCentre Q700 User manual
Lenovo
Lenovo ThinkCentre A61e User manual
Lenovo
Lenovo 12LMA00RGE Owner's manual
Lenovo
Lenovo ThinkCentre M600 User manual
Lenovo
Lenovo ThinkCentre A58e User manual
Lenovo
Lenovo ThinkCentre Edge 71 Guide
