Starting at under 2.7 lb (1.22kg),

select ThinkPad®X60 and X60s

notebooks offer up to 8.8 hours2

(X60s models) and 8.2 hours (X60

models) for the ultimate in mobility.

Intel®Core™ 2 Duo processors

(select models) and available Genuine

Windows Vista™ prepare you for

tomorrow's computing today. Add

integrated WWAN and the ThinkPad

X6 UltraBase™ for easy expandability,

and you’ll see why this small system is

big on power.

New Thinking. New ThinkPad.™

LIGHTEN UP.

THINKPAD X60 AND X60s NOTEBOOKS

Lenovo recommends Windows Vista™Business.

Take on the world.

For those with global ambitions, these next-generation ultraportables pack long battery life and

more potent performance into a sleek, exceptionally lightweight design. Plus, you can connect

in more places as you travel. Select models feature WWAN technology, which enables you to connect

wirelessly to the Internet from within the participating providers’ coverage areas, making your ThinkPad

a portable hot spot.

And although we can’t do much about the tight fit in business class or bumpy

cab rides, we do make ultraportable computing comfortable. Only ThinkPad ultraportables boast

the legendary, full-size4ThinkPad keyboard with the TrackPoint®pointing device and ThinkLight®

keyboard light. ThinkPad X60 and X60s notebooks are products of Lenovo, a global company

uniting Lenovo and the former IBM PC Division.

ThinkPad X60 notebook specifications

ThinkPad X60 Machine types: 1706, 1707, 1708, 1709, 2509, 2510

THE WEIGHT OF THE WORLD: NOW EASIER TO BEAR.

Processor6 (speed, L2 cache, FSB)

Intel®Core™ 2 Duo T7200 (2.0GHz, 4MB, 667MHz)

Intel Core 2 Duo T5600, (1.83GHz, 2MB, 667MHz)

Intel Core 2 Duo T5500 (1.66GHz, 2MB, 667MHz)

Intel®Core™ Duo T2500 (2.0GHz, 2MB, 667MHz)

Intel Core Duo T2400 (1.83GHz, 2MB, 667MHz)

Intel Core Duo T2300E (1.66GHz, 2MB, 667MHz)

Preloaded operating system7

Genuine Windows Vista™ Business 32

Genuine Windows®XP Professional

Genuine Windows XP Home

Display/resolution

12" XGA/1024x768

Hard disk drive8

40, 60, 80, 100, 120GB 5400rpm or 100GB 7200rpm

Memory

Up to 2GB PC2–5300/667MHz or up to 4GB PC2–

4200/533MHz

Optical drive

DVD-ROM, CD-RW/DVD Combo, or

Multi-Burner Plus DVD Dual Layer Recordable

(ThinkPad X6 UltraBase required)

Video graphics

Intel Graphics Media Accelerator 950 up to 128MB

Integrated communications

Modem; Gigabit Ethernet

ThinkPad 11a/b/g Il9(select models)

ThinkPad 11a/b/g/n Wireless Mini-PCI Express

Adapter (select models)

Intel PRO/Wireless 3945ABG (select models)

Bluetooth™,10 (select models)

Embedded WWAN (select models)

Li-Ion battery life2

Up to 4.1hr (4-cell cylindrical)

Up to 8.2hr (8-cell cylindrical)

With optional extended-life battery

Up to 11.1hr (standard 8-cell high capacity battery

plus ThinkPad X60 Series Extended Life battery)

Ports

3 USB 2.0, 1394; Infrared; expansion bus

(for optional ThinkPad X6 UltraBase or ThinkPad X60

Series Extended Life Battery); external display; AC

adapter; RJ-11, RJ-45; audio: headphone/

line-out, external microphone

Slots

1 Type I / II PC Card slot with 34mm ExpressCard

via adapter, 1 Secure Digital card slot

ThinkVantage Active Protection System™ and

ThinkPad Shock-Mounted Hard Drive

Standard

ThinkVantage Client Security Solution

Standard

Integrated Fingerprint Reader

Select models

Keyboard

Ergonomic keyboard with palm rest, TrackPoint

pointing device with “Press-to-Select,” Internet Scroll

Bar,

11 intuitive volume, ThinkVantage button and

Windows keys

Dimensions12

268mmx211mm x 20–35mm/10.5" x 8.3" x .80–1.39"

Travel weight1

1.43kg/3.15 lb (4-cell cylindrical)

1.65kg/3.64 lb (8-cell cylindrical)

Port replicator/dock support

Optional ThinkPad X6 UltraBase

Limited warranty13

3yr or 1yr system/1yr battery

Supported operating systems

Genuine Windows Vista Business 32

Genuine Windows XP Professional

Genuine Windows XP Home

Genuine Windows 2000 Professional

Included software14 (preloaded)

Adobe Reader; Diskeeper Lite; Google: Google

Toolbar, Google Desktop, Picasa from Google;

Multimedia Center for Think Offerings, including:

InterVideo WinDVD (DVD, DVD/CD-RW & DVD-RW

models), InterVideo WinDVD Creator (DVD-RW

models), Sonic RecordNow & DLA (DVD/CD-RW

& DVD-RW models); PC-Doctor; Symantec Client

Security (with 90 days of virus definitions); ThinkPad

Utilities (Power Manager and Presentation Director);

ThinkVantage Access Connections; ThinkVantage

Fingerprint Software, ThinkVantage Productivity

Center with Away Manager; ThinkVantage Rescue

and Recovery; ThinkVantage System Update

(downloadable)

ThinkVantage System Migration Assistant™

(license–CD not included)

IBM®Lotus®SmartSuite,

IBM Lotus Notes®stand-alone client

Certified operating systems

For a listing of completed Linux®certifications,

visit lenovo.com/linux

For important warranty information, see page 4.

THE WEIGHT OF THE WORLD: NOW EASIER TO BEAR.

ThinkPad X6 UltraBase

(40Y8116) sports a host

of useful ports to simplify

cable management. Plus, its

Ultrabay™ Slim drive bay

supports a variety of optical

drives.

ThinkPad X60 Series

Extended Life Battery

(40Y7005) combines with

your system battery for up

to 11.8 hours2of battery life for

select X60s models and 11.1

hours for select X60 models.

ThinkPad Carrying Case—

Leather Ultraportable15

(73P5186) helps you keep

it together in style.

Select models are

Microsoft Office ready

for the 2007 Microsoft

Office Business Suites.

Activation keys can be

purchased from Lenovo,

a Lenovo Solution Partner

or directly from Microsoft.

User, heal thyself.

ThinkVantage®Technologies are integrated into every ThinkPad X60 and X60s notebook to

help users help themselves—and reduce the burden on your help desk. These tools—including

ThinkVantage Access Connections™, ThinkVantage Client Security Solution and ThinkVantage

Rescue and Recovery™—make managing connectivity, security and even recovering from

system crashes, quick and easy.

Just short of omniscient.

The help you need is always standing by—around the clock and around the world5

. ThinkPad

service and support continues to be available from IBM.

Processor (speed, L2 cache, FSB)

Intel Core Duo L2500 (1.83GHz, 2MB, 667MHz)

Intel Core Duo L2400 (1.66GHz, 2MB, 667MHz)

Intel®Core™ Solo U1300 (1.06GHz, 2MB, 533MHz)

Preloaded operating system

Genuine Windows Vista Business 32

Genuine Windows XP Professional

Genuine Windows XP Home

Display/resolution

12.1" XGA or 12.1" UltraLight XGA (1024x768)

Hard disk drive

40, 60, 80, 100, 120GB 5400rpm or 60, 100GB

7200rpm

Memory

Up to 2GB PC2-5300/667MHz or up to 4GB PC2-

4200/533MHz

Optical drive

DVD-ROM, CD-RW/DVD Combo, or Multi-Burner

Plus DVD Dual Layer Recordable

(ThinkPad X6 UltraBase required)

Video graphics

Intel Graphics Media Accelerator 950 up to 128MB

Integrated communications

Modem; Gigabit Ethernet

ThinkPad 11a/b/g Il (select models)

ThinkPad 11a/b/g/n Wireless LAN Mini-PCI Express

Adapter (select models)

Intel PRO/Wireless 3945ABG (select models)

Bluetooth (select models)

Embedded WWAN (select models)

Li-Ion battery life

Up to 3.4hr (4-cell prismatic)

Up to 4.4hr (4-cell cylindrical)

Up to 8.8hr (8-cell cylindrical)

With optional extended-life battery

Up to 11.8hr (standard 8-cell high capacity battery

plus ThinkPad X60 Series Extended Life battery)

Ports

3 USB 2.0, 1394; Infrared; expansion bus

(for optional ThinkPad X6 UltraBase or ThinkPad X60s

Series Extended Life Battery); external display; AC

adapter; RJ-11, RJ-45; audio: headphone/

line-out, external microphone

Slots

1 Type I / II PC Card slot with 34mm ExpressCard

via adapter, 1 Secure Digital card slot

ThinkVantage Active Protection System and

ThinkPad Shock-Mounted Hard Drive

Standard

ThinkVantage Client Security Solution

Standard

Integrated Fingerprint Reader

Select models

Keyboard

Ergonomic keyboard with palm rest, TrackPoint

pointing device with “Press-to-Select,” Internet Scroll

Bar, intuitive volume, ThinkVantage button and

Windows keys

Dimensions

268mm x 211mm x 20–28mm/10.5" x 8.3" x .80–1.11"

Travel weight

12.1" XGA: 1.33kg/2.93 lb (4-cell prismatic),

1.38kg/3.04 lb (4-cell cylindrical),

1.33kg/2.93 lb (8-cell cylindrical)

12.1" UltraLight XGA: 1.24kg/2.73 lb (4-cell prismatic),

1.29kg/2.84 lb (4-cell cylindrical),

1.51kg/3.33 lb(8-cell cylindrical)

Port replicator/dock support

Optional ThinkPad X6 UltraBase

Limited warranty

3yr or 1yr system/1yr battery

Supported operating systems

Genuine Windows Vista Business 32

Genuine Windows XP Professional

Genuine Windows XP Home

Genuine Windows 2000 Professional

Included software (preloaded)

Adobe Reader; Diskeeper Lite; Multimedia

Center for Think Offerings including: InterVideo

WinDVD (DVD, DVD/CD-RW & DVD-RW models),

InterVideo WinDVD Creator (DVD-RW models),

Sonic RecordNow & DLA (DVD/CD-RW & DVD-RW

models); PC-Doctor; Symantec Client Security (with

90 days of virus definitions); ThinkPad Utilities (Power

Manager and Presentation Director); ThinkVantage

Access Connections; ThinkVantage Fingerprint

Software; ThinkVantage Productivity Center with

Away Manager; ThinkVantage Rescue and Recovery;

ThinkVantage System Update

(downloadable)

ThinkVantage System Migration Assistant

(license–CD not included)

IBM Lotus SmartSuite,

IBM Lotus Notes stand-alone client

Certified operating systems

For a listing of completed Linux certifications,

visit lenovo.com/linux

For important warranty information, see page 4.

ThinkPad X60s notebook specifications

ThinkPad X60s Machine types: 1702, 1703, 1704, 1705, 2507, 2508, 2533
