Lenovo 81M9006EIX User manual

Lenovo 100e/300e 2nd Gen
User Guide
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Lenovo 300e
ChromeBook 81M9006EIX o cerca il tuo prodotto tra le migliori offerte di Notebook

Lenovo 100e/300e 2nd Gen
https://support.lenovo.com
First Edition (January 2020)
© Copyright Lenovo 2020.
LIMITED ND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
dministration “GS ” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

ead this first
Before using this documentation and the product it supports, ensure that you read and understand the
following:
• ppendix “Important safety information” on page 35
• Safety and Warranty Guide
• Setup Guide

Contents
Read this first. . . . . . . . . . . . . . . . . ii
About this documentation . . . . . . . . iii
Chapter 1. Meet your computer . . . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Base . . . . . . . . . . . . . . . . . . . . 2
Left . . . . . . . . . . . . . . . . . . . . 3
Right . . . . . . . . . . . . . . . . . . . . 5
Bottom . . . . . . . . . . . . . . . . . . . 6
Features and specifications . . . . . . . . . . . 7
Statement on USB transfer rate . . . . . . . . 8
Chapter 2. Get started with your
computer . . . . . . . . . . . . . . . . . 9
Get started with Windows 10 . . . . . . . . . . 9
Windows account . . . . . . . . . . . . . 9
Windows user interface . . . . . . . . . . 10
Windows label . . . . . . . . . . . . . 11
Use Lenovo Vantage . . . . . . . . . . . . . 12
Connect to Wi-Fi networks . . . . . . . . . . 12
Use multimedia . . . . . . . . . . . . . . . 13
Use audio . . . . . . . . . . . . . . . 13
Use the camera . . . . . . . . . . . . . 13
Connect to an external display . . . . . . . 13
Interact with your computer . . . . . . . . . . 14
Use Hotkeys . . . . . . . . . . . . . . 14
Use the multi-touch screen (for Lenovo 300e
2nd Gen only) . . . . . . . . . . . . . . 16
Operating modes . . . . . . . . . . . . 18
Lenovo Integrated Pen (for selected models of
Lenovo 300e 2nd Gen) . . . . . . . . . . 19
Chapter 3. Explore your computer . . 21
Lock the computer . . . . . . . . . . . . . 21
Manage power . . . . . . . . . . . . . . . 21
Check the battery status and temperature. . . 21
Charge the battery . . . . . . . . . . . . 21
Maximize the battery life . . . . . . . . . 22
Set power button behaviors . . . . . . . . 22
Set the power plan . . . . . . . . . . . . 22
Transfer data . . . . . . . . . . . . . . . . 22
Connect to a Bluetooth-enabled device. . . . 22
Use a MicroSD card . . . . . . . . . . . 23
Turn on the irplane mode . . . . . . . . . . 23
Chapter 4. Configure advanced
settings. . . . . . . . . . . . . . . . . 25
UEFI BIOS setup utility . . . . . . . . . . . . 25
What is UEFI BIOS setup utility . . . . . . . 25
Enter the UEFI BIOS setup utility . . . . . . 25
Change the startup sequence . . . . . . . 25
Change the hotkey mode . . . . . . . . . 25
Enable or disable the lways On USB
function . . . . . . . . . . . . . . . . 25
Use passwords . . . . . . . . . . . . . . . 26
Password types . . . . . . . . . . . . . 26
Set an administrator password . . . . . . . 26
Change or remove the administrator
password . . . . . . . . . . . . . . . 26
Set a user password . . . . . . . . . . . 27
Change or remove the user password . . . . 27
Enable the power on password . . . . . . . 27
Set a hard disk password . . . . . . . . . 27
Change or remove the hard disk password . . 28
Recovery information . . . . . . . . . . . . 28
Restore system files and settings to an earlier
point . . . . . . . . . . . . . . . . . 28
Restore your files from a backup . . . . . . 28
Reset your computer . . . . . . . . . . . 28
Use advanced options . . . . . . . . . . 29
Windows automatic recovery. . . . . . . . 29
Create and use a recovery USB device . . . . 29
Use firewalls and antivirus programs. . . . . . . 30
Chapter 5. Help and support . . . . . 31
Frequently asked questions . . . . . . . . . . 31
Self-help resources . . . . . . . . . . . . . 32
What are CRUs . . . . . . . . . . . . . . . 32
Call Lenovo . . . . . . . . . . . . . . . . 33
Before you contact Lenovo . . . . . . . . 33
Lenovo Customer Support Center . . . . . . 33
Appendix A. Important safety
information . . . . . . . . . . . . . . . 35
Appendix B. Accessibility and
ergonomic information . . . . . . . . 49
Appendix C. Compliance and TCO
Certified information . . . . . . . . . . 53
Appendix D. Notices and
trademarks . . . . . . . . . . . . . . . 65
© Copyright Lenovo 2020 i

ii Lenovo 100e/300e 2nd Gen User Guide

About this documentation
• Illustrations in this documentation might look different from your product. Please refer to the actual
product.
• Depending on the model, some optional accessories, features, and software programs might not be
available on your computer.
• Depending on the version of operating systems and programs, some user interface instructions might not
be applicable to your computer.
• Documentation content is subject to change without notice. Lenovo makes constant improvements on the
documentation of your computer, including this User Guide. To get the latest documentation, go to https://
support.lenovo.com.
• Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.
s a result, some information in this documentation might become outdated. Refer to Microsoft resources
for the latest information.
© Copyright Lenovo 2020 iii

iv Lenovo 100e/300e 2nd Gen User Guide

Chapter 1. Meet your computer
Front
1. Front camera
Take pictures or record videos by clicking Camera from the Start menu. The
indicator next to the camera is on when the camera is in use.
If you use other apps that support photographing, video chatting, and video
conference, the camera starts automatically when you enable the camera-
required feature from the app.
2. Microphone Captures or records sound and voice.
3. Screen
Displays text, graphics, and videos.
Select models support multi-touch function. See “Use the multi-touch screen (for
Lenovo 300e 2nd Gen only)” on page 16.
© Copyright Lenovo 2020 1

Base
1. WorldFacing camera*
Take pictures or record videos by opening the Start menu and clicking Camera ➙
Change camera .
If you use other apps that support photographing, video chatting, and video
conference, the camera starts automatically when you enable the camera-
required feature from the app.
2. Microphone* Captures or records sound and voice.
Note: This microphone is only available when the WorldFacing camera is in use.
3. Touchpad Performs finger touch and all the functions of a traditional mouse.
* for selected models of Lenovo 300e 2nd Gen
2Lenovo 100e/300e 2nd Gen User Guide

Left
1. Battery/Charging status
indicator
This indicator shows whether the ac power is connected to the computer and the
battery power status of the computer.
• Connected to ac power:
– Solid white (battery power 80%–100%)
– Slow blinking white (battery power 20%–80%)
– Slow blinking amber (battery power 1%–20%)
• Not connected to ac power:
– Off (battery power 20%–100%)
– Solid amber (battery power 5%–20%)
– Fast blinking amber (battery power 1%–5%)
2. USB-C™ connector / Power
connector
• Charges your computer.
• Charges USB-C compatible devices with the output voltage and current of 5 V
and 3 .
• Transfers data at USB 3.1 speed, up to 5 Gbps.
• Connects to an external display.
– USB-C to VG : 1900 × 1200 pixels, 60 Hz
– USB-C to DP: 3840 × 2160 pixels, 60 Hz
• Connects to USB-C accessories to expand computer functionality. To
purchase USB-C accessories, go to https://www.lenovo.com/accessories
Note: When the battery power is below 10%, the connected USB-C
accessories might not work correctly.
This connector also works as the power connector. Connect the computer to ac
power with the shipped USB-C power adapter and power cord.
3. lways On USB 3.1 connector
Gen 1
To charge the USB-compatible devices when your computer is off, in sleep mode,
or in hibernation mode, enable the lways On USB feature on your computer. See
“Enable or disable the lways On USB function” on page 25.
Chapter 1.Meet your computer 3

4. HDMI™ connector Connect to a compatible digital audio device or video monitor, such as an HDTV.
5. udio connector
Connect headphones or a headset with a 3.5-mm (0.14-inch) and 4-pole plug to
listen to the sound from the computer.
Note: The audio connector does not support conventional microphones.
4Lenovo 100e/300e 2nd Gen User Guide

ight
1. Pen slot* For Lenovo 300e 2nd Gen, selected models are equipped with Lenovo Integrated
Pen (an electronic pen). Use the pen slot to store Lenovo Integrated Pen.
2. Volume up/down button* Increase/decrease the volume level.
3. Power button
Press to turn on the computer or put the computer to sleep mode.
To turn off the computer, open the Start menu, click Power, and then click
Shut down.
The indicator on the power button shows the system status of your computer.
• On: The computer is on.
• Off: The computer is off or in hibernation mode.
• Blinking: The computer is in sleep mode.
4. USB 3.1 connector Gen 1 Connect to USB-compatible devices, such as a USB keyboard, USB mouse, USB
storage device, or USB printer.
5. MicroSD card slot Insert a microSD card for data access or storage.
6. Mini security-lock slot Lock your computer to a desk, table, or other fixtures through a compatible
security cable lock.
* for Lenovo 300e 2nd Gen only
Chapter 1.Meet your computer 5

Bottom
1. Speakers Produce sound.
6Lenovo 100e/300e 2nd Gen User Guide

Features and specifications
Dimensions
• Length: 290 mm (11.4 inches)
• Width: 204 mm (8.1 inches)
• Thickness:
– Lenovo 100e 2nd Gen: 19.9 mm (0.78 inches)
– Lenovo 300e 2nd Gen: 20.85 mm (0.82 inches)
Power source (ac power
adapter)
• Sine-wave input at 50 Hz to 60 Hz
• Input rating of the ac power adapter: 100 V to 240 V ac, 50 Hz to 60 Hz
Battery • 42 Wh
• 3 cells
Microprocessor To view the microprocessor information of your computer, right-click the Start
button and then click System.
Memory Low Power Double data rate (LPDDR) 4, on-board memory
Storage device M.2 solid-state drive or on-board eMMC
Display
• Display size: 294.6 mm (11.6 inches)
• Display resolution: 1366 x 768 pixels
• Multi-touch technology (for Lenovo 300e 2nd Gen only)
Keyboard • Function keys
• Six-row keyboard
Connectors and slots
• USB-C connector/Power connector
• Two USB 3.1 connectors Gen 1 (including one lways On USB 3.1 connector
Gen 1)
• udio connector
• HDMI connector
• MicroSD card slot
• Mini security-lock slot
• Pen slot (for selected models of Lenovo 300e 2nd Gen)
Security features
• Password
• Mini security-lock slot
• Trusted Platform Module (TPM)
Wireless features • Bluetooth
• Wireless L N
Others
• Front camera
• World-Facing camera (for selected models of Lenovo 300e 2nd Gen)
• Microphones
• Speakers
Chapter 1.Meet your computer 7

Note: The battery capacity is the typical or average capacity as measured in a specific test environment.
Capacities measured in other environments may differ but are no lower than the rated capacity (see product
label).
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 / 3.1 Gen 1 5
3.2 Gen 2 / 3.1 Gen 2 10
3.2 Gen 2 × 2 20
8Lenovo 100e/300e 2nd Gen User Guide

Chapter 2. Get started with your computer
Get started with Windows 10
Learn the basics of Windows 10 and start working with it right away. For more information about Windows
10, see the Windows help information.
Windows account
user account is required to use the Windows operating system. It can either be a Windows user account or
a Microsoft account.
Windows user account
When you start Windows for the first time, you are prompted to create a Windows user account. This first
account you created is of the “ dministrator” type. With an dministrator account, you can create additional
user accounts or change account types by doing the following:
1. Open the Start menu and select Settings ➙ Accounts ➙ Family & other users.
2. Follow the on-screen instructions.
Microsoft account
You can also log in to the Windows operating system with a Microsoft account.
To create a Microsoft account, go to the Microsoft sign-up page at https://signup.live.com and follow the on-
screen instructions.
With a Microsoft account, you can:
• Enjoy one-time signing in if you are using other Microsoft services, such as OneDrive, Skype, and Outlook.
com.
• Sync personalized settings across other Windows-based devices.
© Copyright Lenovo 2020 9

Windows user interface
1. Account Change account settings, lock the computer, or sign out from the current account.
2. Documents Open the Documents folder, a default folder to save your received files.
3. Pictures Open the Pictures folder, a default folder to save your received pictures.
4. Settings Launch Settings.
5. Power Shut down, restart, or put the computer into sleep mode.
6. Start button Open the Start menu.
7. Windows Search Type what you are looking for in the search box and get search results from your
computer and the Web.
8. Task View Display all opened apps and switch among them.
9. Windows notification area Display notifications and status of some features.
10. Battery status icon Display power status and change battery or power settings. When your computer
is not connected to ac power, the icon changes to .
11. Network icon Connect to an available wireless network and display the network status. When
connected to a wired network, the icon changes to .
12. Action center Display the latest notifications from apps and provide quick access to some
features.
Open the Start menu
• Click the Start button.
• Press the Windows logo key on the keyboard.
Access Control Panel
• Open the Start menu and click Windows System ➙ Control Panel.
10 Lenovo 100e/300e 2nd Gen User Guide

• Use Windows Search.
Launch an app
• Open the Start menu and select the app you want to launch.
• Use Windows Search.
Windows label
Your computer might have a Windows 10 Genuine Microsoft label affixed to its cover depending on the
following factors:
• Your geographic location
• Edition of Windows 10 that is preinstalled
Go to https://www.microsoft.com/en-us/howtotell/Hardware.aspx for illustrations of the various types of
Genuine Microsoft labels.
• In the People’s Republic of China, the Genuine Microsoft label is required on all computer models
preinstalled with any version of Windows 10.
• In other countries and regions, the Genuine Microsoft label is required only on computer models licensed
for Windows 10 Pro.
The absence of a Genuine Microsoft label does not indicate that the preinstalled Windows version is not
genuine. For details on how to tell whether your preinstalled Windows product is genuine, refer to the
information provided by Microsoft at https://www.microsoft.com/en-us/howtotell/default.aspx.
There are no external, visual indicators of the Product ID or Windows version for which the computer is
licensed. Instead, the Product ID is recorded in the computer firmware. Whenever a Windows 10 product is
installed, the installation program checks the computer firmware for a valid, matching Product ID to complete
the activation.
In some cases, an earlier Windows version might be preinstalled under the terms of the Windows 10 Pro
license downgrade rights.
Chapter 2.Get started with your computer 11

Use Lenovo Vantage
The preinstalled Lenovo Vantage is a customized one-stop solution to help you maintain your computer with
automated updates and fixes, configure hardware settings, and get personalized support.
Access Lenovo Vantage
Open the Start menu and click Lenovo Vantage. You also can type Lenovo Vantage in the search box.
To download the latest version of Lenovo Vantage, go to Microsoft Store and search by the app name.
Key features
Lenovo Vantage enables you to:
• Know the device status easily and customize device settings.
• Download and install UEFI BIOS, firmware, and driver updates to keep your computer up-to-date.
• Monitor your computer health, and secure your computer against outside threats.
• Look up warranty status (online).
• ccess User Guide and helpful articles.
Notes:
• The available features vary depending on the computer model.
• Lenovo Vantage makes periodic updates of the features to keep improving your experience with your
computer. The description of features might be different from that on your actual user interface.
Connect to Wi-Fi networks
Click the network icon in the Windows® notification area, and then select a network for connection. Provide
required information, if needed.
12 Lenovo 100e/300e 2nd Gen User Guide
