Safety, Warranty, and Setup Guide
Brief user notices
ThinkPad Edge E130 and E135
http://www.lenovo.com/support
Lenovo®electronic manuals... for a greener planet!
Refer to the electronic User Guide for detailed product information:
http://www.lenovo.com/thinkuserguides
Unpack
ThinkPad®
computer
Battery Power cord
ac power adapter Publications
Note: Recovery discs are not provided. Instead, everything needed for recovering factory-installed files and
applications is provided in the Lenovo_Recovery partition on your hard disk drive. If you decide to remove
the Lenovo_Recovery partition, be sure to create a recovery disc first. For more information, see “Recovery
overview” in the User Guide. See “Accessing your User Guide” for instructions on opening the electronic
User Guide provided on your computer.
Initial setup instructions
1. Install the battery pack.
Third Edition (May 2013)
© Copyright Lenovo 2012, 2013.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use,
reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
This system supports only batteries specially designed for this
specific system and manufactured by Lenovo or an authorized
builder. The system does not support unauthorized batteries or
batteries designed for other systems. If an unauthorized battery or
a battery designed for another system is installed, the system will
not charge.
Attention: Lenovo has no responsibility for the performance or
safety of unauthorized batteries, and provides no warranties for
failures or damage arising out of their use.
2. Connect to power. Ensure that all power cord connectors are securely and completely plugged into
receptacles.
3. Press the power button to turn on the computer.
4. Configure the operating system following the on-screen instructions to complete the initial setup. This
process takes several minutes.
Additional information about using your ThinkPad computer is in the User Guide. See “Accessing your User
Guide” later in this document.
Controls and indicators
Camera
Power button
Function keys
: Volume controls
: Microphone mute
: Change camera and audio settings
: Change display settings
: Change display brightness
: Manage wireless connections
: Multimedia controls
Note: To use the F1 through F12 functions,
press the desired key directly.
TrackPoint®pointing stick
TrackPoint buttons
Touch pad
System status indicator
Attention: Do not force the display open
beyond 135 degrees from the relative
position of the keyboard. Forcing the display
beyond this point can cause damage.
Accessing your User Guide
Your User Guide contains detailed information about your computer.
To access our User Guide, do the following:y
Windows®8:
• From the desktop or the Start screen
1. Move the cursor to the top-right or bottom-right corner of the
screen to display the charms, and then click Search.
2. From the Apps screen, click Lenovo User Guide.
• From the Start screen
1. Click Lenovo Support.The Lenovo Support window opens.
2. Click User Guide.
Windows 7:
1. From the Windows desktop, click Start and then click Help and
Support. The Help and Support program opens.
2. Click Lenovo User Guide.
3. In the Lenovo User Guide window, click the link for your model and
the User Guide opens.
Read before using your computer
The following sections provide critical safety and regulatory
information for Lenovo computers and instructions on how to access
electronic versions of the publications developed for your computer.
Read first — regulatory information
Computer models equipped with wireless communications comply
with the radio frequency and safety standards of any country or region
in which it has been approved for wireless use. In addition, if your
product contains a telecom modem, it complies with the requirements
for connection to the telephone network in your country.
Be sure to read the Regulatory Notice for your country or region
before using the wireless devices contained in your computer. To
obtain a PDF version of the Regulatory Notice, refer to the
“Downloading publications” section below.
Downloading publications
Electronic versions of your computer publications are available from
the Lenovo Support Web site. To download the publications for your
computer, go to http://www.lenovo.com/ThinkPadUserGuides and
follow the instructions on the screen.
Downloading drivers
The latest drivers for your computer are available from the Lenovo
Support Web site. To download the latest drivers for your computer,
go to http://www.lenovo.com/drivers and follow the instructions on the
screen.
Service and Support information
The following information describes the technical support that is
available for your product, during the warranty period or throughout
the life of your product. Refer to the Lenovo Limited Warranty for a full
explanation of Lenovo warranty terms. See “Lenovo Limited Warranty
notice” later in this document for details on accessing the full warranty.
If you purchased Lenovo services, refer to the following terms and
conditions for detailed information:
For Lenovo Warranty Service Upgrades or Extensions, go to:
http://support.lenovo.com/lwsu
For Lenovo Accidental Damage Protection Services, go to:
http://support.lenovo.com/ladps
Online technical support
Online technical support is available during the lifetime of a product at
http://www.lenovo.com/support.
Telephone technical support
You can get help and information from the Customer Support Center
by telephone. Before contacting a Lenovo technical support
representative, please have the following information available: model
and serial number, the exact wording of any error message, and a
description of the problem.
Your technical support representative might want to walk you through
the problem while you are at your computer during the call.
Worldwide Lenovo Support telephone list
Important: Telephone numbers are subject to change without notice.
The most up-to-date telephone list for the Customer Support Center is
always available at http://www.lenovo.com/support/phone.
If the telephone number for your country or region is not listed,
contact your Lenovo reseller or Lenovo marketing representative.
Country or region Telephone number
