Lenovo ThinkPad Twist S230u Service manual

Personal Systems Reference
Lenovo®ThinkPad
®Edge Notebooks
July 2013 - Version 439
Visit www.lenovo.com/psref for the latest version

Lenovo®ThinkPad Twist S230u
(Tent Mode)
Lenovo®ThinkPad Twist S230u
Lenovo®ThinkPad Twist S230u
(Tablet Mode)
Lenovo®ThinkPad Twist S230u
Lenovo®ThinkPad Twist S230u
(Stand Mode)
Lenovo®ThinkPad Twist S230u
(Notebook Mode)

Supports ThinkVantage®technologies
Convertible tablet ultrabook™; one spindle
Intel®Core™i5-3427U processor (2 cores, 1.80GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (2.80GHz), HT technology
Intel Core i7-3667U processor (2 cores, 2.0GHz, 4MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.20GHz), HT technology
4GB or 8GB / PC3-10600 1333MHz DDR3 / soldered to systemboard, no SO-DIMM sockets
None
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high, Active Protection System™
All: removable, upgradable
Some: 24GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
12.5" (317.5mm) HD (1366x768) TFT color,
smudgeless and anti-reflective display with Corning®Gorilla®Glass,
LED backlight, 350 nits, 16:9 aspect ratio, 500:1 contrast ratio, IPS, rotate and swivel hinge
Bottom buttons: volume up / down and Windows buttons
Side buttons: power and auto rotation buttons
Projected Capacitive Touch (PCT) technology, supports 5-point multi-touch
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 4000 in processor,
supports external digital monitor via Mini HDMI and Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600 (Mini DisplayPort)@60Hz;
1920x1200 (Mini HDMI)@60Hz
6-row, 83-key, spill-resistant, multimedia Fn keys
TrackPoint pointing device
UltraNav™, buttonless touchpad below keyboard, Tap Zones, multi-touch
Ambient light sensor
None
8-cell: 12.32" x 9.29" x 0.79"; 313mm x 236mm x 20mm
8-cell: from 3.50 lb (1.60kg)
Display cover: Magnesium + Polyphenylene sulfide (PPS); Bottom: Magnesium + PPS
Integrated Li-Polymer 8-cell, HW Authentication
None
8-cell (42.4Whr): up to 6.0 hr
Mobile Intel HM77 Express Chipset
4-in-1 reader (SD, SDHC, SDXC, MMC)
None
None
Two USB 3.0, external monitor (mini-HDMI, mini-DisplayPort), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some: 11a/b/g/n , PCIe Half Mini Card, ThinkPad 11a/ b/g/n,
Some:
Wi-Fi + Bluetooth combo adapter, 2x2
Some: 11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230,
Some: Wi-Fi + Bluetooth combo adapter, 2x2
None
None
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit Network Connection Realtek® RTL8111F, PHY, PCIe x1
None
High Definition (HD) Audio, Realtek ALC3202 codec /
stereo speakers, 2 watt x 2, Dolby®Home Theater®v4 certified /
volume up, down, mute buttons /
dual array microphone , combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Multi-touch
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
Light sensor
ThinkLight™
Dimensions3
Weight2
Case material
Battery - type
Extended Battery
Battery - life10
Chipset
Multicard Reader
ExpressCard
Smart Card Read
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Twist S230u (20C4) - Ultrabook
20C4-29U i7-3667U 8GB 12.5" HD Multi 720p 128G SSD Intel 223028 None None Black BT 8 Win8 Pro64 06/13
20C4-28U i7-3667U 8GB 12.5" HD Multi 720p 128G SSD TP 11a/b/g/n None None Black BT 8 Win8 Pro64 06/13
20C4-27U i7-3667U 8GB 12.5" HD Multi 720p 500G 7200 Intel 2230 24GB None Black BT 8 Win8 Pro64 06/13
20C4-26U i7-3667U 8GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 24GB None Black BT 8 Win8 Pro64 06/13
20C4-25U i5-3427U 4GB 12.5" HD Multi 720p 128G SSD Intel 2230 None None Black BT 8 Win8 Pro64 06/13
20C4-24U i5-3427U 4GB 12.5" HD Multi 720p 128G SSD TP 11a/b/g/n None None Black BT 8 Win8 Pro64 06/13
20C4-23U i5-3427U 4GB 12.5" HD Multi 720p 500G 7200 Intel 2230 24GB None Black BT 8 Win8 Pro64 06/13
20C4-22U i5-3427U 4GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 24GB None Black BT 8 Win8 Pro64 06/13
65-watt AC Adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
ROHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Personal Systems Reference (PSREF)
© Lenovo
(TANR1-4) July 2013
See footnotes for more detailed information
US model(s) announced June 4, 2013
Type-model
Widescreen
displayMemory
Disk
SATA
GB8 rpm
PCIe Mini Card
WWAN/
mSATA
PCIe
Mini Card
WLAN
Bat-
tery
cellsProcessor Camera
Preloaded operating system20
- Windows 8 Pro 64-bit
Preloaded applications14 (only some
listed)
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
•Password Manager
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
• Microsoft Office 2013 preloaded;
purchase product key to activate
•Skype™
Blue-
tooth
Ann
date
(mm/yy)
SIM card Preload
Top
color
For Lenovo 22 service upgrade
options, please go to S-EDGE sheet

Supports ThinkVantage®technologies
Convertible tablet ultrabook™; one spindle
Intel®Core™i3-3217U processor (2 cores, 1.80GHz, 3MB Cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i5-3317U processor (2 cores, 1.70GHz, 3MB Cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (2.60GHz), HT technology
Intel Core i7-3517U processor (2 cores, 1.90GHz, 4MB Cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.00GHz), HT technology
2GB, 4GB or 8GB / PC3-10600 1333MHz DDR3 / soldered to systemboard,
no SO-DIMM sockets
None
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high, Active Protection System™
All: removable, upgradable
Some: 24GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
12.5" (317.5mm) HD (1366x768) TFT color,
smudgeless and anti-reflective display with Corning®Gorilla®Glass,
LED backlight, 350 nits, 16:9 aspect ratio, 500:1 contrast ratio, IPS, rotate and swivel hinge
Bottom buttons: volume up / down and Windows buttons
Side buttons: power and auto rotation buttons
Projected Capacitive Touch (PCT) technology, supports 5-point multi-touch
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 4000 in processor,
supports external digital monitor via Mini HDMI and Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600 (Mini DisplayPort)@60Hz;
1920x1200 (Mini HDMI)@60Hz
6-row, 83-key, spill-resistant, multimedia Fn keys
TrackPoint pointing device
UltraNav™, buttonless touchpad below keyboard, Tap Zones, multi-touch
Ambient light sensor
None
8-cell: 12.32" x 9.29" x 0.79"; 313mm x 236mm x 20mm
8-cell: from 3.50 lb (1.60kg)
Display cover: Magnesium + Polyphenylene sulfide (PPS); Bottom: Magnesium + PPS
Integrated Li-Polymer 8-cell, HW Authentication
None
8-cell (42.4Whr): up to 6.0 hr
Mobile Intel HM77 Express Chipset
4-in-1 reader (SD, SDHC, SDXC, MMC)
None
None
Two USB 3.0, external monitor (mini-HDMI, mini-DisplayPort), ethernet (RJ-45)
Two PCI Express Mini Card slots
11a/b/g/n , PCIe Half Mini Card, ThinkPad 11a/ b/g/n, Wi-Fi + Bluetooth combo adapter, 2x2
None
None
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit Network Connection Realtek® RTL8111F, PHY, PCIe x1
None
High Definition (HD) Audio, Realtek ALC3202 codec /
stereo speakers, 2 watt x 2, Dolby®Home Theater®v4 certified /
volume up, down, mute buttons / dual array microphone , combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Multi-touch
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
Light sensor
ThinkLight™
Dimensions3
Weight2
Case material
Battery - type
Extended Battery
Battery - life10
Chipset
Multicard Reader
ExpressCard
Smart Card Read
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Twist S230u (3347) - TopSeller (Ultrabook)
3347-2YU i3-3217U 4GB 12.5" HD Multi 720p 320G 7200 TP 11a/b/g/n28 24GB None Black BT 8 Win8 Pro64 10/12
3347-2RU i7-3517U 8GB 12.5" HD Multi 720p 128G SSD TP 11a/b/g/n None None Black BT 8 Win8 Pro64 10/12
3347-2QU i5-3317U 4GB 12.5" HD Multi 720p 128G SSD TP 11a/b/g/n None None Black BT 8 Win8 Pro64 10/12
3347-2NU i3-3217U 4GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 24GB None Black BT 8 Win8 Pro64 10/12
3347-2HU i5-3317U 4GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 24GB None Black BT 8 Win8 Pro64 10/12
3347-2GU i7-3517U 8GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 24GB None Black BT 8 Win8 Pro64 10/12
65-watt AC Adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
ROHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Personal Systems Reference (PSREF)
© Lenovo
(TANR1-1) October 2012
See footnotes for more detailed information
US model(s) announced October 23, 2012
•Small and medium business (SMB) model(s), part of the US TopSeller ™Program
•A depot repair service 1-year limited warranty
Type-model
Widescreen
displayMemory
Disk
SATA
GB8 rpm
PCIe
Mini Card
WLAN
Bat-
tery
cellsProcessor Camera
Preloaded operating system20
- Windows®8 Pro 64-bit
Preloaded applications14 (only some
listed)
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
•Password Manager
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
• Microsoft Office 2013 preloaded;
purchase product key to activate
•Skype™
Blue-
tooth
Ann
date
(mm/yy)
SIM card Preload
Top
color
For Lenovo 22 service upgrade
options, please go to S-EDGE sheet
PCIe Mini Card
WWAN/
mSATA

Supports ThinkVantage®technologies
Convertible tablet ultrabook™; one spindle
Intel®Core™i3-3227U processor (2 cores, 1.90GHz, 3MB Cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i5-3337U processor (2 cores, 1.80GHz, 3MB Cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (2.70GHz), HT technology
Intel Core i5-3427U processor (2 cores, 1.80GHz, 3MB Cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (2.80GHz), HT technology
Intel Core i7-3537U processor (2 cores, 2.00GHz, 4MB Cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
4GB or 8GB / PC3-10600 1333MHz DDR3 / soldered to systemboard,
no SO-DIMM sockets
None
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high, Active Protection System™
All: removable, upgradable
Some: 24GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
12.5" (317.5mm) HD (1366x768) TFT color,
smudgeless and anti-reflective display with Corning®Gorilla®Glass,
LED backlight, 350 nits, 16:9 aspect ratio, 500:1 contrast ratio, IPS, rotate and swivel hinge
Bottom buttons: volume up / down and Windows buttons
Side buttons: power and auto rotation buttons
Projected Capacitive Touch (PCT) technology, supports 5-point multi-touch
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 4000 in processor,
supports external digital monitor via Mini HDMI and Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600 (Mini DisplayPort)@60Hz;
1920x1200 (Mini HDMI)@60Hz
6-row, 83-key, spill-resistant, multimedia Fn keys
TrackPoint pointing device
UltraNav™, buttonless touchpad below keyboard, Tap Zones, multi-touch
Ambient light sensor
None
8-cell: 12.32" x 9.29" x 0.79"; 313mm x 236mm x 20mm
8-cell: from 3.50 lb (1.60kg)
Display cover: Magnesium + Polyphenylene sulfide (PPS); Bottom: Magnesium + PPS
Integrated Li-Polymer 8-cell, HW Authentication
None
8-cell (42.4Whr): up to 6.0 hr
Mobile Intel HM77 Express Chipset
4-in-1 reader (SD, SDHC, SDXC, MMC)
None
None
Two USB 3.0, external monitor (mini-HDMI, mini-DisplayPort), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some: 11a/b/g/n , PCIe Half Mini Card, ThinkPad 11a/ b/g/n,
Some: Wi-Fi + Bluetooth combo adapter, 2x2
Some: 11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230,
Some: Wi-Fi + Bluetooth combo adapter, 2x2
None
None
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit Network Connection Realtek® RTL8111F, PHY, PCIe x1
None
High Definition (HD) Audio, Realtek ALC3202 codec /
stereo speakers, 2 watt x 2, Dolby®Home Theater®v4 certified /
volume up, down, mute buttons / dual array microphone , combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Multi-touch
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
Light sensor
ThinkLight™
Dimensions3
Weight2
Case material
Battery - type
Extended Battery
Battery - life10
Chipset
Multicard Reader
ExpressCard
Smart Card Read
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Twist S230u (3347) - TopSeller (Ultrabook) - II
3347-7EU i5-3427U 4GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n28 24GB None Black BT 8 Win8 Pro64 02/13
3347-7DU i5-3427U 4GB 12.5" HD Multi 720p 500G 7200 Intel 2230 24GB None Black BT 8 Win8 Pro64 02/13
3347-7CU i5-3427U 4GB 12.5" HD Multi 720p 128G SSD Intel 2230 None None Black BT 8 Win8 Pro64 02/13
3347-7BU i5-3427U 4GB 12.5" HD Multi 720p 128G SSD TP 11a/b/g/n None None Black BT 8 Win8 Pro64 02/13
3347-78U i5-3337U 4GB 12.5" HD Multi 720p 500G 7200 Intel 2230 24GB None Black BT 8 Win8 Pro64 02/13
3347-77U i7-3537U 8GB 12.5" HD Multi 720p 128G SSD TP 11a/b/g/n None None Black BT 8 Win8 Pro64 02/13
3347-76U i5-3337U 4GB 12.5" HD Multi 720p 128G SSD TP 11a/b/g/n None None Black BT 8 Win8 Pro64 02/13
3347-6WU i3-3227U 4GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 24GB None Black BT 8 Win8 Pro64 02/13
3347-6VU i5-3337U 4GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 24GB None Black BT 8 Win8 64 02/13
3347-6UU i5-3337U 4GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 24GB None Black BT 8 Win8 Pro64 02/13
3347-6LU i7-3537U 8GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 24GB None Black BT 8 Win8 Pro64 02/13
65-watt AC Adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
ROHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Personal Systems Reference (PSREF)
© Lenovo
(TANR1-3) February 2013
See footnotes for more detailed information
US model(s) announced February 5 or February 19, 2013
Type-model
Widescreen
displayMemory
Disk
SATA
GB8 rpm
PCIe
Mini Card
WLAN
Bat-
tery
cellsProcessor Camera
Preloaded operating system20
- Some: Windows 8 64-bit
- Some: Windows 8 Pro 64-bit
Preloaded applications14 (only some
listed)
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
•Password Manager
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
• Microsoft Office 2013 preloaded;
purchase product key to activate
•Skype™
Blue-
tooth
Ann
date
(mm/yy)
SIM card Preload
Top
color
For Lenovo 22 service upgrade
options, please go to S-EDGE sheet
PCIe Mini Card
WWAN/
mSATA

Supports ThinkVantage®technologies
Convertible tablet; one spindle
Intel®Core™i3-2365M processor (2 cores, 1.40GHz, 3MB Cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i3-2375M processor (2 cores, 1.50GHz, 3MB Cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
2GB / PC3-10600 1333MHz DDR3 / soldered to systemboard, no SO-DIMM sockets
None
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm high, Active Protection System™,
removable, upgradable
16GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
12.5" (317.5mm) HD (1366x768) TFT color,
smudgeless and anti-reflective display with Corning®Gorilla®Glass,
LED backlight, 350 nits, 16:9 aspect ratio, 500:1 contrast ratio, IPS, rotate and swivel hinge
Bottom buttons: volume up / down and Windows buttons
Side buttons: power and auto rotation buttons
Projected Capacitive Touch (PCT) technology, supports 5-point multi-touch
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 in processor,
supports external digital monitor via Mini HDMI and Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600 (Mini DisplayPort)@60Hz;
1920x1200 (Mini HDMI)@60Hz
6-row, 83-key, spill-resistant, multimedia Fn keys
TrackPoint pointing device
UltraNav™, buttonless touchpad below keyboard, Tap Zones, multi-touch
Ambient light sensor
None
8-cell: 12.32" x 9.29" x 0.79"; 313mm x 236mm x 20mm
8-cell: from 3.50 lb (1.60kg)
Display cover: Magnesium + Polyphenylene sulfide (PPS); Bottom: Magnesium + PPS
Integrated Li-Polymer 8-cell, HW Authentication
None
8-cell (42.4Whr): up to 6.0 hr
Mobile Intel HM77 Express Chipset
4-in-1 reader (SD, SDHC, SDXC, MMC)
None
None
Two USB 3.0, external monitor (mini-HDMI, mini-DisplayPort), ethernet (RJ-45)
Two PCI Express Mini Card slots
11a/b/g/n , PCIe Half Mini Card, ThinkPad 11a/ b/g/n, Wi-Fi + Bluetooth combo adapter, 2x2
None
None
None
Bluetooth 4.0 wireless, integrated in WLAN PCIe Half Mini Card
Gigabit Network Connection Realtek® RTL8111F, PHY, PCIe x1
None
High Definition (HD) Audio, Realtek ALC3202 codec /
stereo speakers, 2 watt x 2, Dolby®Home Theater®v4 certified /
volume up, down, mute buttons / dual array microphone , combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Multi-touch
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
Light sensor
ThinkLight™
Dimensions3
Weight2
Case material
Battery - type
Extended Battery
Battery - life10
Chipset
Multicard Reader
ExpressCard
Smart Card Read
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
SIM card
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Twist S230u (3347) - TopSeller
3347-2PU i3-2365M 2GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n28 16GB None Black BT 8 Win8 Pro64 10/12
3347-79U i3-2375M 2GB 12.5" HD Multi 720p 320G 7200 TP 11a/b/g/n 16GB None Black BT 8 Win8 Pro64 02/13
3347-84U i3-2375M 2GB 12.5" HD Multi 720p 500G 7200 TP 11a/b/g/n 16GB None Black BT 8 Win8 Pro64 05/13
3347-83U i3-2375M 2GB 12.5" HD Multi 720p 320G 7200 TP 11a/b/g/n 16GB None Black BT 8 Win8 64 05/13
65-watt AC Adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
ROHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Personal Systems Reference (PSREF)
© Lenovo
(TANR1-2) June 2013
See footnotes for more detailed information
US model(s) announced October 23, 2012; February 19 or May 21, 2013
•Small and medium business (SMB) model(s), part of the US TopSeller ™Program
•A depot repair service 1-year limited warranty
Type-model
Widescreen
displayMemory
Disk
SATA
GB8 rpm
PCIe Mini Card
WWAN/
mSATA
PCIe
Mini Card
WLAN
Bat-
tery
cellsProcessor Camera
Preloaded operating system20
- Some: Windows®8 64-bit
- Some: Windows 8 Pro 64-bit
Preloaded applications14 (only some
listed)
•Lenovo Support
•Lenovo Companion
•Lenovo Cloud Storage
•Password Manager
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•Norton™Internet Security
(30 days of virus definitions)
• Microsoft Office 2013 preloaded;
purchase product key to activate
•Skype™
Blue-
tooth
Ann
date
(mm/yy)
SIM card Preload
Top
color
For Lenovo 22 service upgrade
options, please go to S-EDGE sheet

Memory
None
Storage and removable storage
ThinkPad 16GB mSATA Solid State Cache Drive 0B47309 ann 12/11/12
USB 2.0 Portable 500GB Hard Disk 45K1690 ann 05/26/09
USB 3.0 Secure 500GB Hard Drive 0A65619 ann 11/29/11
USB 3.0 Secure 750GB Hard Drive 0A65616 ann 11/29/11
USB 3.0 Secure 1TB Hard Drive 0A65621 ann 08/28/12
ThinkPad Expansion
None
Keyboard
TrackPoint Cap Collection 73P2698 ann 12/16/03
Ultraslim Plus Wireless Keyboard and Mouse52 0A34032 ann 04/05/11
USB Numeric Keypad 33L3225 ann 05/01/00
Preferred Pro USB Keyboard 73P5220 ann 06/21/05
Enhanced Performance USB Keyboard 73P2620 ann 03/23/04
ThinkPad USB Keyboard with TrackPoint 55Y9003 ann 08/18/09
Lenovo USB Fingerprint Keyboard 73P4730 ann 02/22/05
Lenovo USB Smartcard Keyboard 51J0155 ann 03/24/09
Mouse
ThinkPad Bluetooth Laser Mouse 0A36407 ann 06/26/12
Lenovo Optical Mouse (USB) 06P4069 ann 05/21/03
Lenovo Laser Mouse (USB) 41U3074 ann 01/23/07
ThinkPad USB Laser Mouse 57Y4635 ann 12/15/09
Lenovo ScrollPoint®Mouse (USB, Optical) 31P7405 ann 08/27/02
ThinkPad Travel Mouse (USB, Optical) 31P7410 ann 06/04/02
Lenovo Wireless Laser Mouse52 0A36188 ann 12/20/11
52
Wireless via 2.4GHz technology using a micro-size USB receiver.
Security
Kensington®MicroSaver®Cable Lock 73P2582 ann 12/29/03
Kensington Twin Head Cable Lock 45K1620 ann 09/30/08
Lenovo Security Cable Lock 57Y4303 ann 08/24/10
USB Gemplus GemPC Smart Card Reader 41N3040 ann 02/21/06
Multimedia
ThinkPad In-Ear Headphones with mic 57Y4488 ann 01/07/10
Lenovo Mini Speakers M220 55Y2033 ann 01/07/10
Modem
USB 2.0 Lenovo Modem 43R1814 ann 02/26/08
Power adapters
ThinkPad 65W AC Adapter45 40Y7696 ann 01/05/06
45
Only compatible with the integrated graphics models.
ThinkPad 90W AC Adapter 40Y7659 ann 09/20/05
More information at www.lenovopowertips.com
Carrying Cases
Up to 13.3" widescreen models:
ThinkPad Ultraportable Case 41U5062 ann 05/13/08
Up to 15.6" widescreen models:
Lenovo Performance BackPack 41U5254 ann 05/01/07
ThinkPad Business Topload Case 43R2476 ann 05/13/08
ThinkPad Business Backpack 43R2482 ann 05/13/08
ThinkPad Deluxe Expander Case 43R2478 ann 05/13/08
ThinkPad Executive Leather Case 43R2480 ann 05/13/08
Lenovo Sport Backpack - Red 0A33896 ann 02/28/12
Lenovo Sport Slimcase - Red 0A33897 ann 02/28/12
Lenovo Sport Messenger - Red 0A33898 ann 02/28/12
More information at www.lenovo.com/support/cases
Monitors
ThinkVision LT2323p Wide 23" (VGA, DP, DVI-D)
69
3024HB1 ann 09/13/11
Lenovo LS2023 Wide 20" (VGA, DVI) 3778HB2 ann 08/02/11
Lenovo LS1922 Wide 18.5" (VGA) 2580AF1 ann 08/02/11
Lenovo LS2223 Wide 21.5" (VGA, DVI) 3783HB2 ann 08/02/11
Lenovo LS2323 Wide 23" (VGA, DVI) 3794HB1 ann 08/02/11
More information at www.lenovo.com/support/monitors
Monitor Accessories46
Lenovo Mini DisplayPort to VGA Adapter 0A36536 ann 05/17/11
Lenovo Mini DisplayPort to SL-DVI-D Adapter 0B47090 ann 06/12/12
Lenovo Mini DisplayPort to DisplayPort Cable 0B47091 ann 07/24/12
Kensington MicroSaver Cable Lock 73P2582 ann 12/29/03
Kensington Twin Head Cable Lock 45K1620 ann 09/30/08
Lenovo Security Cable Lock 57Y4303 ann 08/24/10
46
Compatible on selected Lenovo and ThinkVision monitors.
More information at www.lenovo.com/support/monitoraccessories
For more information on accessories:
www.lenovo.com/accessories
Purchase Lenovo accessories
www.lenovo.com/support/accessories
Product specifications on Lenovo Support
www.lenovo.com/accessoriesguide
Option Compatibility Matrix (OCM) and accessory brochures
www.lenovoquickpick.com
An Options Compatibility Configurator for Lenovo systems
© Lenovo
(O-S230-U) May 2013
ThinkPad®Twist S230u Accessories Personal Systems Reference (PSREF)

Lenovo®ThinkPad Edge E430
Lenovo ThinkPad Edge E430
Lenovo ThinkPad Edge E430
Lenovo ThinkPad Edge E430c
Lenovo ThinkPad Edge E430
Lenovo ThinkPad Edge E430

65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: Genuine Windows®7
Home Premium 64
- Some: Genuine Windows 7
Professional 64
Ready to install applications14 (only
some listed)
•One Key Recovery Pro
Preloaded applications14 (only some
listed)
•Access Connections™
•TrueSuite Fingerprint Software
(includes password manager
function)
•ThinkVantage System Update
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
•Corel®WinDVD®(DVD±RW)
•Corel Burn.Now™Lenovo Edition
(DVD±RW)
•Corel DVD MovieFactory®Lenovo
Edition (DVD±RW)
For compatible accessories, please
go to O-E430 sheet;
For Lenovo22 service upgrade
options, please go to S-EDGE sheet
Sophisticated design with quality, durability and reliability for SMB customers; two spindles
Intel®Core™i3-2350M processor (dual-core, 2.30GHz, 3MB Cache),
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i5-2450M processor (dual-core, 2.50GHz, 3MB Cache),
DDR3 memory controller (up to 1333MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
16GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
DVD burner, 12.7mm high, fixed, not removable, tray-in
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
Some: 16GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
Some: 14.0" (355mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
Some: 14.0" (355mm) HD (1366x768) color, VibrantView (glossy),
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution,face track, low light sensitive, fixed focus, LED indicator
Intel HD Graphics 3000 in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, Internet Scroll Bar13
UltraNav™, wide touchpad below keyboard, Tap Zones, multi-touch
None
Matte black or Matte red (top): 14.0W" (WxDxH): 13.36" x 9.21" x 1.12-1.33";
339.4 x 234mm x 28.5-33.9mm
Black aluminum (top): 14.0W" (WxDxH): 13.36" x 9.21" x 1.08-1.29";
339.4 x 234mm x 27.4-32.8mm
6-cell: from 4.74 lb (2.15kg)
Some: Matte black or Matte red (top), trimmed with a thin silver band (side); black bottom
Some: Black aluminum (top); black bottom
Matte black or Matte red (top): Acrylonitrile-Butadiene-Styrene (ABS) plastic
Black aluminum (top): Aluminum
Lithium Ion 6-cell
6-cell (48Whr): up to 6.4 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Three USB 3.0, one USB 2.0 (powered),
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some: 11 b/g/n , PCIe Half Mini Card, ThinkPad 11 b/g/n, 1x1
Some:
11 b/g/n , PCIe Half Mini Card, ThinkPad 11 b/g/n,
Wi-Fi + Bluetooth combo adapter, 1x1
Some: 11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230,
Wi-Fi + Bluetooth combo adapter, 2x2
None
None
Some: Bluetooth 4.0 wireless, integrated in selected WLAN PCIe Half Mini Card
Realtek®RTL8111F Gigabit Network Connection
High Definition (HD) Audio, Conexant 20671 codec / stereo speakers, 2 watt x 2/
Stereo digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
Some: UPEK Fingerprint reader on palm rest, swipe sensor
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
WLAN4
WWAN
Modem
Bluetooth™
Ethernet
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E430 3254 (Intel) - TopSeller
3254-DNU i3-2350M 4GBx1 14.0" HD 720p 320G 7200 Intel 2230 + BT None None Black aluminum Finger 6 Pro 64 04/12
3254-AHU i5-2450M 4+2GB 14.0" HD Glos 720p 500G 5400 TP 11b/g/n + BT None None Matte black Finger 6 Prem 64 04/12
3254-AGU i3-2350M 4+2GB 14.0" HD Glos 720p 500G 5400 TP 11b/g/n + BT None None Matte black Finger 6 Prem 64 04/12
3254-AFU i3-2350M 2GBx1 14.0" HD Glos 720p 320G 5400 TP 11b/g/n None None Matte black 6 Prem 64 04/12
3254-AEU i5-2450M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT None None Matte black Finger 6 Pro 64 04/12
3254-ADU i3-2350M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT None None Matte black Finger 6 Pro 64 04/12
3254-ACU i3-2350M 4GBx1 14.0" HD 720p 320G 7200 TP 11b/g/n None None Matte black 6 Pro 64 04/12
3254-AMU i5-2450M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT 16GB None Black aluminum Finger 6 Pro 64 04/12
3254-ALU i3-2350M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT None None Black aluminum Finger 6 Pro 64 04/12
3254-HJU i5-2450M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT None None Black aluminum Finger 6 Pro 64 05/12
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(LEE1-1) September 2012
PCIe
Mini Card
WLAN / BT
Finger
print
readerProcessor Preload
Top color
See footnotes for more detailed information
US model(s) announced April 10 or May 22, 2012
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA Carrier
●Small and medium business (SMB) model(s), part of the US TopSeller™Program
●Microsoft®Office 2010 Product Key Ready (O10PKR)
Ann
date
(mm/yy)

65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Supports ThinkVantage®technologies
Preloaded operating system20
- Some: Genuine Windows®7
Home Premium 64
- Some: Genuine Windows 7
Professional 64
Ready to install applications14 (only
some listed)
•One Key Recovery Pro
Preloaded applications14 (only some
listed)
•Access Connections™
•TrueSuite Fingerprint Software
(includes password manager
function)
•ThinkVantage System Update
•ThinkVantage Power Manager
•ThinkVantage Tools
•Lenovo SimpleTap
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
•Corel®WinDVD®(DVD±RW)
•Corel Burn.Now™Lenovo Edition
(DVD±RW)
•Corel DVD MovieFactory®Lenovo
Edition (DVD±RW)
For compatible accessories, please
go to O-E430 sheet;
For Lenovo22 service upgrade
options, please go to S-EDGE sheet
Sophisticated design with quality, durability and reliability for SMB customers; two spindles
Intel®Core™i3-3110M processor (dual-core, 2.40GHz, 3MB Cache),
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i5-3210M processor (dual-core, 2.50GHz, 3MB Cache),
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
Intel Core i7-3612QM processor (quad-core, 2.10GHz, 6MB Cache),
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
16GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
DVD burner, 12.7mm high, fixed, not removable, tray-in
Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
Some: 16GB mSATA Solid State Drive (SSD), via PCIe Mini Card slot
Some: 14.0" (355mm) HD (1366x768) color, anti-glare,
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
Some: 14.0" (355mm) HD (1366x768) color, VibrantView (glossy),
LED backlight, 200 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution,face track, low light sensitive, fixed focus, LED indicator
Intel HD Graphics 4000 in processor,
external analog monitor support via VGA DB-15 connector and
digital monitor support via HDMI™(supporting HDCP to output protected content);
supports dual independent display;
Max external resolution: 2048x1536 (VGA)@75Hz; 1920x1200 (HDMI)@60Hz
6-row, spill-resistant, multimedia Fn keys
TrackPoint pointing device, Internet Scroll Bar13
UltraNav™, wide touchpad below keyboard, Tap Zones, multi-touch
None
Matte black or Matte red (top): 14.0W" (WxDxH): 13.36" x 9.21" x 1.12-1.33";
339.4 x 234mm x 28.5-33.9mm
Black aluminum (top): 14.0W" (WxDxH): 13.36" x 9.21" x 1.08-1.29";
339.4 x 234mm x 27.4-32.8mm
6-cell: from 4.74 lb (2.15kg)
Some: Matte black or Matte red (top), trimmed with a thin silver band (side); black bottom
Some: Black aluminum (top); black bottom
Matte black or Matte red (top): Acrylonitrile-Butadiene-Styrene (ABS) plastic
Black aluminum (top): Aluminum
Lithium Ion 6-cell
6-cell (48Whr): up to 6.4 hr
6-cell (62Whr): up to 8.4 hr
Mobile Intel HM77 Express Chipset
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
Three USB 3.0, one USB 2.0 (powered),
external monitor (VGA DB-15, HDMI), ethernet (RJ-45)
Two PCI Express Mini Card slots
Some:
11 b/g/n , PCIe Half Mini Card, ThinkPad 11 b/g/n , 1x1
Some:
11 b/g/n , PCIe Half Mini Card, ThinkPad 11 b/g/n,
Wi-Fi + Bluetooth combo adapter, 1x1
Some:
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2230,
Wi-Fi + Bluetooth combo adapter, 2x2
None
None
Bluetooth 4.0 wireless, integrated in selected WLAN PCIe Half Mini Card
Realtek®RTL8111F Gigabit Network Connection
High Definition (HD) Audio, Conexant 20671 codec / stereo speakers, 2 watt x 2/
Stereo digital microphone, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
None
Some: UPEK Fingerprint reader on palm rest, swipe sensor
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touchpad
ThinkLight™
Dimensions3
Weight
2
Case color
Case material
Battery - type37
Battery - life10
Chipset
ExpressCard
Multicard Reader
Ports
PCIe Mini Card
WLAN4
WWAN
Modem
Bluetooth™
Ethernet
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®Edge E430 3254 (Intel) - TopSeller - II
3254-HKU i7-3612QM 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT None Black aluminum Finger 6 62 Pro 64 05/12
3254-GLU i5-3210M 4+2GB 14.0" HD Glos 720p 750G 5400 Intel 2230 + BT None Black aluminum Finger 6 48 Pro 64 06/12
3254-GKU i5-3210M 4+2GB 14.0" HD Glos 720p 500G 7200 Intel 2230 + BT None Black aluminum Finger 6 48 Pro 64 06/12
3254-GJU i5-3210M 4GBx1 14.0" HD Glos 720p 500G 7200 Intel 2230 + BT None Black aluminum Finger 6 48 Prem 64 06/12
3254-AKU i5-3210M 4+2GB 14.0" HD Glos 720p 500G 5400 TP 11b/g/n + BT None Matte black Finger 6 48 Prem 64 06/12
3254-AJU i5-3210M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT None Matte black Finger 6 48 Pro 64 06/12
3254-ANU i5-3210M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT None Black aluminum Finger 6 48 Pro 64 06/12
3254-LWU i5-3210M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT 16GB Black aluminum Finger 6 62 Pro 64 06/12
3254-HMU i3-3110M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT None Black aluminum Finger 6 48 Pro 64 06/12
3254-HLU i3-3110M 4GBx1 14.0" HD 720p 320G 7200 TP 11b/g/n None Matte black None 6 48 Pro 64 06/12
3254-TNU i3-3110M 4GBx1 14.0" HD 720p 500G 7200 Intel 2230 + BT None Matte black Finger 6 48 Pro 64 07/12
Type-model
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Personal Systems Reference (PSREF)
© Lenovo
(LEE1-2) September 2012
PCIe
Mini Card
WLAN / BT
Finger
print
readerProcessor Preload
Top color
See footnotes for more detailed information
US model(s) announced May 22, June 5, June 26 or July 31, 2012
Bat-
tery
cellsCamera
PCIe Mini Card
WWAN
/mSATA
●Small and medium business (SMB) model(s), part of the US TopSeller™Program
●Microsoft®Office 2010 Product Key Ready (O10PKR)
Ann
date
(mm/yy)
Bat-
tery
/Wh
