Lenovo L1940p - ThinkVision - 19" LCD Monitor User manual

Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Optimum resolution
Maximum resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Anti-reflective
Vertical frequency
Horizontal frequency
Viewing angle at 10:1 CR
Stand
Bezel width
Dimensions (HxWxD)
Power supply
Weight
Limited warranty4
Available date
VESA-compliant2
Power management
Ergonomics
Pixel defect
Emission standards
Environmental
Preset resolutions
Presets / user settings
Viewing adjustments
Rotating screen
On screen display
Control features
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
Lenovo®ThinkVision®L1940p Wide
©Lenovo
(L1940P) January 2009
See footnotes for important warranty information
US model announced September 17, 2008
Personal Systems Reference (PSREF)
Limited Warranty
➫3 year limited warranty4
➫International Warranty Service5
➫Rapid Replacement Service at 1-800-IBM-SERV (426-7378)
➫Replacement normally arrives in two business days, excluding holidays
➫Lenovo pays all shipping costs for valid warranty claims6
➫Service upgrade options:7
•3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™part number 41C9209)
•3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
•4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
•4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9234)
•4 year, mail exchange (51J0589)
•5 year, mail exchange (51J0590)
➫24x78day toll-free support for warranty issues during the warranty period4
Accessories
ThinkVision USB Soundbar 40Y7616
Kensington®Cable Lock from Lenovo 73P2582
Kensington Twin Head Cable Lock 45K1620
ThinkPad Convertible Monitor Stand 40Y7620
ThinkVision TFT Radial Arm919K4464
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
ThinkVision L1940p Wide Monitor
Features
• Widescreen 19-inch monitor
•Supports WXGA+ 1440x900 resolution
• Ergonomic stand tilts, swivels, pivots and provides a 4.3"
(110mm) range height adjustment for comfortable viewing
• Detachable rear stand cable cover and clip to hide cables
•Microsoft®Windows®Vista®certified
L1940p Wide Flat Panel Monitor
Business black
4424-HB6
TFT-LCD, twisted nematic (TN), CCFL backlight
19.0" (481mm) diagonal
16.1" x 10" (408.2mm x 255.2mm)
1440x900 at 60Hz
1440x900 at 75Hz (137MHz max pixel rate)
16:10
.285mm
89 dpi
250 nits or cd/m2(typical)
1000:1 (typical)
5ms (typical)
72%
Anti-reflective, anti-glare
50 to 76Hz
30 to 81kHz
160° (+/- 80°) horizontal, 160° (+/- 80°) vertical
Tilt, swivel, pivot, and height adjustable stand
Sides: 0.61" (15.4mm); top: 0.65" (16.4mm);
bottom: 1.1" (27.9mm)
14-18.3" H x 17.3" W x 7.4-9.5" D;
356.1-466.1mm H x 440.2mm W x 188-241.1mm D
16 watts typical, 23 watts maximum,
<1 watts standby/suspend, universal,
integrated (no external brick-like power supply)
12.8 lb; 5.8kg
3 year (includes backlight)
October 2008
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR®3 5.0
ISO 13406 Part 21
ISO 13406-2 Class II pixel defect standard
MPR-2. MPR-3A, FCC Class B
TCO 03, WEEE, RoHS (EU Directive 2002/95/EC),
EPEAT™Gold rating,GREENGUARD® certified
VGA: 640x350, 640x480, 720x400
SVGA: 800x600, 832x624
XGA: 1024x768,1152x864
WXGA: 1280x720, 1280x768
SXGA: 1280x1024
WXGA+: 1440x900
Standard presets: 22;
user settings: 20
Tilt: 30° back, 0° forward; lift: 4.3" (110mm); swivel: +/-45°; detachable stand
Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller),
On screen display with digital user controls (8 languages)
Direct access (buttons on front) for automatic image setup
Multiple input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
15-pin D-shell, analog, blue
(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant
(1) detachable, VGA 15-pin D-shell at each end, analog, 1.8 meter
(2) detachable, DVI-D at each end, digital, 1.8 meter
Wall or desk mounting using the Radial Arm9or third-party accessories meeting the VESA FPMPMI®(100mm mount)
Security keyhole for attachment of optional cable lock (Kensington®lock-compatible)
Monitor, attached stand, cable cover, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide
and monitor installation files, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
