Lenovo D173 User manual

D173

Product numbers
4427-AB1
First Edition ( )
LENOVO products, data, computer software, and services have been
developed exclusively at private expense and are sold to governmental entities as commercial items as
defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and
disclosure.LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or
services are delivered pursuant a General Services Administration "GSA" contract, use, reproduction, or
disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
May 2008
CopyrightLenovo2008.
(c)

Contents
Safety information ..............................iv
Chapter 1. Getting started ........................... 1-1
Shipping contents ................................. 1-1
Attaching the base and handling your monitor ....................... 1-1
Product overview ................................. 1-2
Types of adjustments ............................... 1-2
User controls ................................. 1-2
Setting up your monitor ............................... 1-3
Connecting and turning on your monitor ........................ 1-3
Registering your option ............................... 1-5
Chapter 2. Adjusting and using your monitor ................... 2-1
Comfort and accessibility .............................. 2-1
Arranging your work area ............................. 2-1
Quick tips for healthy work habits .......................... 2-2
Accessibility information.............................. 2-2
Adjusting your monitor image............................. 2-3
Using the direct access controls ........................... 2-3
Using the On-Screen Display (OSD) controls ....................... 2-3
Selecting asupported display mode ........................... 2-5
Understanding power management ........................... 2-6
Caring for your monitor ............................... 2-7
Chapter 3. Reference information ........................ 3-1
Monitor specifications ............................... 3-1
Troubleshooting.................................. 3-2
Manual image setup ............................... 3-3
Manually installing the monitor driver ......................... 3-5
Service information ............................... 3-7
Appendix A. Service and Support........................ A-1
Online technical support .............................. A-1
Telephone technical support ............................. A-1
Worldwide telephone list ............................. A-1
Appendix B. Notices ............................. B-1
Trademarks ................................... B-2
iii
. ©
CopyrightLenovo2008
©

Safety information
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Lees voordat udit product installeert eerst de veiligheidsvoorschriften.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Antes de instalar este producto lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
ii iv
. ©
CopyrightLenovo2008
©

Shipping contents
The product package should include the following items:
vSetup Poster
vMonitor Safety, Troubleshooting, and Warranty Guide
vReference and Driver CD
vFlat Panel Monitor
vPower Cord
vAnalog Interface Cable dD
Attaching the base and handling your monitor
To set up your monitor, please see the illustrations below.
Note: Do not touch the monitor within the screen area. The screen area is glass
and can be damaged by rough handling or excessive pressure.
Chapter 1. Getting started
This U ser ’s Guide contains detailed information on fffffffffffffFFFFFy Flat
Panel M onitor. For aquick overview, please see the Setup Poster that was shipped
with your monitor.
your
MonitorSafety,Troubleshooting
andWarranty Guide
1-1
vAudio Cable
. ©
CopyrightLenovo2008
©

Product overview
This section will provide information on adjusting monitor positions, setting user
controls, and using the cable lock slot.
Types of adjustments
Please see the illustration below for an example of the tilt range.
User controls
Your monitor has controls on the front which are used to adjust the display.
For information on how to use these controls, please see “Adjusting your monitor
image” on page
1-2 Flat Panel Monitor User’s Guide
520
2-2

Setting up your monitor
This section provides information to help you set up your monitor.
Connecting and turning on your monitor
Note: Be sure to read the Safety Information located in the Monitor Safety,
Troubleshooting, and Warranty Guide before carrying out this procedure.
1. Power off your computer and all attached devices, and unplug the computer
power cord.
Chapter 1. Getting started 1-3

2. Connect the analog signal cable to the video port on the back of the computer.
Note: One end of the signal cable is already pre-attached to your monitor.
3. Insert the power cord into the monitor, then plug the monitor power cord and
the computer cord into grounded electrical outlets.
4. Power on the monitor and the computer.
1-4 Flat Panel Monitor User’s Guide

5. To install the monitor driver, insert the Reference and Driver CD,click Install
driver,and follow the on-screen instructions.
6. To optimize your monitor image, press the Automatic Image Setup key.
Automatic image setup requires that the monitor is warmed up for at least 15
minutes. This is not required for normal operation.
Note: If automatic image setup does not establish the image that you prefer,
perform manual image setup. See “Manual image setup” on page 3-3.
Registering your option
Thank you for purchasing this Lenovo product. Please take afew moments to
register your product and provide us with information that will help Lenovo to
better serve you in the future. Your feedback is valuable to us in developing
products and services that are important to you, as well as in developing better
ways to communicate with you. Register your option on the following Web site:
http://www.lenovo.com/register
Lenovo will send you information and updates on your registered product unless
you indicate on the Web site questionnaire that you do not want to receive further
information.
Chapter 1. Getting started 1-5

Getstared
ReadUser’sGuide
ViewSetupPoster
Installdrivers
Registeryourproduct
C)CopyrightLenovo2008.LENOVO products,data,computersoftware,andservices havebeendevelopedexclusivelyatprivateexpense andaresoldtogovernmentalentities
ascommercialitemsas definedby48C.F.R.2.101withlimited andrestrictedrightstouse,reproduction anddisclosure.LIMITEDANDRESTRICTEDRIGHTSNOTICE:If
products,data,computersoftware, orservicesaredeliveredpursuanta GeneralServicesAdministration"GSA"contract,use,reproduction, ordisclosureissubjecttorestrictionsset forth
inContractNo.GS-35F-05925.
Findmoreinformation Getsupport
Findproquctnumber
Onlinesupport
Adobe Acrobat(R)Reader(R)
ProductRecyclingProgram InfornationSafety,Troubleshooting,andWarranty Guide
LenovoLimitedWarranty
Productaccessoriesand upgrades
ComplianceNotices
)
R

Chapter 2. Adjusting and using your monitor
This section will give you information on adjusting and using your monitor.
Comfort and accessibility
Good ergonomic practice is important to get the most from your personal
computer and to avoid discomfort. Arrange your workplace and the equipment
you use to suit your individual needs and the kind of work that you perform. In
addition, use healthy work habits to maximize your performance and comfort
while using your computer.
For more detailed information on any of these topics, visit the Healthy Computing
Web site at: http://www.ibm.com/pc/ww/healthycomputing
Arranging your work area
Use awork surface of appropriate height and available working area to allow you
to work in comfort.
Organize your work area to match the way you use materials and equipment.
Keep your work area clean and clear for the materials that you typically use and
place the items that you use most frequently, such as the computer mouse or
telephone, within the easiest reach.
Equipment layout and setup play alarge role in your working posture. The
following topics describe how to optimize equipment setup to achieve and
maintain good working posture.
Positioning and viewing your monitor
Position and adjust your computer monitor for comfortable viewing by considering
the following items:
vViewing distance:Optimal viewing distances for monitors range from
approximately 510mm to 760mm (20 in to 30 in) and can vary depending on
ambient light and time of day. You can achieve different viewing distances by
repositioning your monitor or by modifying your posture or chair position. Use
aviewing distance that is most comfortable for you.
vMonitor height:Position the monitor so your head and neck are in a
comfortable and neutral (vertical, or upright) position. If your monitor does not
have height adjustments, you might have to place books or other sturdy objects
under the base of the monitor to achieve the desired height. Ageneral guideline
is to position the monitor such that the top of the screen is at or slightly below
your eye-height when you are comfortably seated. However, be sure to optimize
your monitor height so the line of site between your eyes and the center the
monitor suits your preferences for visual distance and comfortable viewing
when your eye muscles are in arelaxed state.
vTilt:Adjust the tilt of your monitor to optimize the appearance of the screen
content and to accommodate your preferred head and neck posture.
vGeneral location:Position your monitor to avoid glare or reflections on the
screen from overhead lighting or nearby windows.
The following are some other tips for comfortable viewing of your monitor:
2-1
. ©
CopyrightLenovo2008
©

vUse adequate lighting for the type of work you are performing.
vUse the monitor brightness, contrast, and image adjustment controls, if
equipped, to optimize the image on your screen to meet your visual preferences.
vKeep your monitor screen clean so you can focus on the screen’s contents.
Any concentrated and sustained visual activity can be tiring for your eyes. Be sure
to periodically look away from your monitor screen and focus on afar object to
allow your eye muscles to relax. If you have questions on eye fatigue or visual
discomfort, consult avision care specialist for advice.
Quick tips for healthy work habits
The following information is asummary of some important factors to consider to
help you remain comfortable and productive while you use your computer.
vGood posture starts with equipment setup:The layout of your work area and
the setup of your computer equipment have alarge effect on your posture while
using your computer. Be sure to optimize the position and orientation of your
equipment by following the tips outlined in “Arranging your work area” on
page 2-1 so you can maintain acomfortable and productive posture. Also, be
sure to use the adjustment capabilities of your computer components and office
furniture to best suit your preferences now and as your preferences change over
time.
vMinor changes in posture can help avoid discomfort:The longer you sit and
work with your computer, the more important it is to observe your working
posture. Avoid assuming any one posture for an extended period of time.
Periodically make minor modifications in your posture to help deter any
discomforts that might arise. Make use of any adjustments that your office
furniture or equipment provide to accommodate changes in posture
vShort, periodic breaks help ensure healthy computing:Because computing is
primarily astatic activity, it is particularly important to take short breaks from
your work. Periodically, stand up from your work area, stretch, walk for adrink
of water, or otherwise take ashort break from using your computer. Ashort
break from work gives your body awelcome change in posture and helps to
ensure you remain comfortable and productive while you do work.
Accessibility information
Lenovo is committed to providing greater access to information and technology to
people with disabilities. With assistive technologies, users can access information in
the way most appropriate to their disability. Some of these technologies are already
provided in your operating system; others can be purchased through vendors or
accessed at: http://www.ibm.com/able/
2-2 Flat Panel Monitor User’s Guide
Adjusting your monitor image
This section describes the user control features used to adjust your monitor image.
Using the direct access controls
The direct access controls can be used when the On Screen Display (OSD) is not
displayed.

Table 2-1. Direct access controls
Icon Control Description
Activates automatic image adjustment.
Volume
Chapter 2. Adjusting and using your monitor 2-3
Image Setup
Auto
decrease volume.
Increase volume
VOL+
VOL-
Using the On-Screen Display (OSD) controls
1. Press the MENU-button to activate the OSD window .
2. Press or to navigate through the functions. Once the desired function
is highlighted, press the MENU-button to activate it. If the function
selected has a sub-menu, press or again to navigate through the
sub-menu functions. Once the desired function is highlighted, press
MENU-button to activate it.
3. Press or to change the settings of the selected function.
4. To exit and save, select the exit function. If you want to adjust any other
function, repeat steps 2-3.

2-4 Flat Panel Monitor User’s Guide
ADJUSTING THE PICTURE
The descriptions for function control LEDS
Luminance
A
djust Range Description
Brightness 0-100 Backlight Adjustment
Contrast 0-100 Contrast from Digital-register.
Eco
Standard Standard Mode
Text Text Mode
Internet Internet Mode
Game Game Mode
Movie Movie Mode
Sports Sports Mode
Gamma Gamma1
A
djust to Gamma1
Gamma2
A
djust to Gamma 2
Gamma3
A
djust to Gamma 3
DCR Off Disable dynamic contrast ratio
On Enable dynamic contrast ratio
Image Setup
Clock 0-100
A
djust picture Clock to reduce Vertical-Line
noise.
Focus 0-100
A
djust Picture Phase to reduce
Horizontal-Line noise
H.Position 0-100
A
djust the verticalposition of the picture.
V.Position 0-100
A
djust the horizontal position of the picture.
Color Temp.
Warm
Recall Warm Color Temperature from
EEPROM.
Normal
Recall Normal Color Temperature from
EEPROM.
Cool
Recall Cool Color Temperature from
EEPROM.
sRGB
Recall SRGB Color Temperature from
EEPROM.
User
User-B Blue Gain from Digital-register
User-G Green Gain Digital-register.
User-R Red Gain from Digital-register
User-Y Yellow Gain from Digital-register
User-C Cyan Gain from Digital-register
User-M Magenta Gain from Digital-register

Chapter 2. Adjusting and using your monitor 2-5
Color Boost
Full Enhance on or off Disable or Enable Full Enhance Mode
Nature Skin on or off Disable or Enable Nature Skin Mode
Green Field on or off Disable or Enable Green Field Mode
Sky-blue on or off Disable or Enable Sky-blue Mode
A
utoDetect on or off Disable or Enable AutoDetect Mode
Demo on or off Disable or Enable Demo
Picture Boost
Frame Size 0-100
A
djust Frame Size
Brightness 0-100
A
djust Frame Brightness
Contrast 0-100
A
djust Frame Contrast
Hue 0-100
A
djust Frame Hue
Saturation 0-100
A
djust Frame Saturation
Position H. position
A
djust Frame horizontal Position
V.position
A
djust Frame vertical Position
Bright Frame on or off Disable or Enable Bright Frame
OSD Setup
H.Position 0-100
A
djust the verticalposition of OSD
V.Position 0-100
A
djust the horizontal position of OSD
Timeout 0-100
A
djust the OSD Timeout
Language Select the OSD language
Extra
Input Select Digital Select Digital Sigal Source as Input
A
nalog Select Analog Sigal Source as Input
A
uto Config yes or no Auto adjust will automatically adjust size,
position,clock and phase
Reset yes or no Reset monitor to original settings
DDC-CI Turn ON/OFF DDC-CI Support
Information
Show the information of the main image
and sub-image source

The display modes shown below have been optimized at the factory.
Table 2-3. Factory set display modes
Selecting asupported display mode
The display mode the monitor uses is controlled by the computer. Therefore, refer
to your computer documentation for details on how to change display modes.
The image size, position and shape might change when the display mode changes.
This is normal and the image can be readjusted using automatic image setup and
the image controls.
Unlike CRT monitors, which require ahigh refresh rate to minimize flicker, LCD or
Flat Panel technology is inherently flicker-free.
Note: If your system has previously been used with aCRT monitor and is
currently configured to adisplay mode outside the range of this monitor, you may
need to re-attach the CRT monitor temporarily until you have re-configured the
system; preferably to 24 at 60 Hz, which is the Native Resolution Display
mode.
1280 x 1024
AddressabilityRefreshrate
640x48060Hz,67Hz,72Hz,75Hz
720x40070Hz
800x60060Hz,72Hz,75Hz,56Hz
1024x76860Hz,70Hz,75Hz,72Hz
640x40070Hz
1280x102460Hz,75Hz
832x62475Hz
2-6 Flat Panel Monitor User’s Guide

Caring for your monitor
Be sure to turn off the power before you perform any maintenance on the monitor.
Do not:
vApply water or liquid directly to your monitor.
vUse solvents or abrasives.
vUse flammable cleaning materials to clean your monitor or any other electrical
equipment.
vTouch the screen area of your monitor with sharp or abrasive items. This type of
contact may cause permanent damage to your screen.
vUse any cleaner which contains an anti-static solution or similar additives. This
may harm the coating of the screen area.
Do:
vLightly dampen asoft cloth with water and use this to gently wipe the covers
and the screen.
vRemove grease or finger marks with adamp cloth and alittle mild detergent.
Understanding power management
Power management is invoked when the computer recognizes that you have not
used your mouse or keyboard for auser-definable period. There are several states
as described in the table below.
For optimal performance, switch off your monitor at the end of each working day,
or whenever you expect to leave it unused for long periods during the day.
Table 2-4. Power indicator
State Power Indicator Screen
Restoring
Operation Compliance
On SteadyNormal
Standby/Suspend Steady amber Blank Press akey or
move the mouse
There may be a
slight delay
before the image
reappears.
Note: Standby
also occurs if
there is no
image output to
the monitor.
ENERGY STAR
Off Off Blank Press
the
There may be a
slight delay
before the image
reappears.
ENERGY STAR
green
Chapter 2. Adjusting and using your monitor 2-7
Power button

Chapter 3. Reference information
This section contains monitor specifications, instructions to manually install the
monitor driver, troubleshooting information, and service information.
Monitor specifications
Table 3-1. Monitor specifications for type-model 4427-**1
Dimensions Height
Depth
Width
383.4mm
190mm
371.6 mm
Stand Tilt range -5°/+20°
Viewable image size
Maximum height
Maximum width
Pixel pitch
mm (1 .0 in.)
mm
mm
Power input Supply voltage
Power consumption
Note: Power consumption
figures are for the monitor
and the power supply
combined.
Normal operation
Standby/Suspend
Off
< W
< 2 W
< 1 W
Video input Input signal
Horizontal addressability
Vertical addressability
Clock frequency
Analog Direct Drive,
75 ohm 0.7 V
pixels (max)
lines (max)
MHz
Communications VESA DDC
Supported Display Modes
(VESA Standard modes
between noted ranges)
Horizontal frequency
Vertical frequency
30 kHz -kHz
Native Resolution at 60 Hz
Temperature Operating
Storage
Shipping
-20° to 60° C(-4° to 140° F)
-20° to 60° C(-4° to 140° F)
3-1
Hz -75 Hz
. ©
CopyrightLenovo2008
©
431.8
7
337
270
0.264 x 0.264 mm
VESA mount Supported 100mm
CI
30
1280 x 1024
1280
1024
140
83
55
Digital and
0°C to 40°C (32°F to 104°F)
100-240Vac
60/50 ± 3 Hz
Makesureth eACjackis
locateddownsidewhen

usingVESAMountsetup.

Table 3-1. Monitor specifications for type-model (continued)4427-**1
Humidity Operating
Storage
Shipping
10% to 80%
5% to 95%
5% to 95%
Troubleshooting
If you have aproblem setting up or using your monitor, you might be able to
solve it yourself. Before calling your dealer or Lenovo, try the suggested actions
that are appropriate to your problem.
Table 3-2. Troubleshooting
Problem Possible cause Suggested action Reference
The words ″
″are
shown on the
screen,
The system is set
to adisplay
mode which is
not supported by
the monitor.
vIf you are replacing an
old monitor, reconnect
it and adjust the
display mode to within
the specified range for
your new monitor.
vIf using aWindows
system, restart the
system in safe mode,
then select asupported
display mode for your
computer.
vIf these options do not
work, contact the
Customer Support
Center.
“Selecting asupported
display mode” on page
The image
quality is
unnacceptable.
The video signal
cable is not
connected with
the monitor or
system
completely.
Be sure the signal cable is
firmly plugged into the
system and monitor.
“Connecting and turning
on your monitor” on
page 1-3
The color
settings may be
incorrect.
Select another color
setting from the OSD
menu.
“Adjusting your monitor
image” on page
The automatic
image setup
function was not
performed.
Perform automatic image
setup.
“Adjusting your monitor
image” on page
The power
indictator is not
lit and there is
no image.
vThe monitor’s
power switch
is not
switched on.
vThe power
cord is loose
or
disconnected.
vThere is no
power at the
outlet.
vBe sure the power cord
is connected properly.
vBe sure the outlet has
power.
vPower on the monitor.
vTry using another
power cord.
vTry using another
electrical outlet.
“Connecting and turning
on your monitor” on
page 1-3
3-2 Flat Panel Monitor User’s Guide
Input
Not Support 2-6
2-2
2-2

Table 3-2. Troubleshooting (continued)
Problem Possible cause Suggested action Reference
Screen is blank
and power
indicator is
steady amber
The monitor is in
Standby/Suspend
mode
vPress any key on the
keyboard or move the
mouse to restore
operation.
vCheck the Power
Options settings on
your computer.
“Understanding power
management” on page
The power
indicator is
green, but there
is no image.
The video signal
cable is loose or
disconnected
from the system
or monitor.
Be sure the video cable is
connected with the
system properly.
“Connecting and turning
on your monitor” on
page 1-3
The monitor
brightness and
contrast are at
the lowest
setting.
Adjust the brightness and
contrast setting on the
OSD menu.
“Adjusting your monitor
image” on page
One or more of
the pixels appear
discolored
This is a
characteristic of
the LCD
technology and
is not an LCD
defect.
If there are more than
five pixels missing,
contact the Customer
Support Center.
Appendix A, “Service and
Support,” on page A-1
vFuzzy lines in
text or a
blurry image.
vHorizontal or
vertical lines
through the
image.
vImage setup
has not been
optimized
vYour system
Display
Properties
setting have
not been
optimized.
Adjust the resolution
settings on your system
to match the native
resolution for this
monitor:
Hz.
“Adjusting your monitor
image” on page
“Manual image setup”
Perform automatic image
setup. If automatic image
setup does not help,
perform manual image
setup.
“Selecting asupported
display mode” on page
When working in the
native resolution, you
may find additional
improvements by
adjusting the Dots Per
Inch (DPI) setting on
your system.
See the Advanced section
of your system’s display
properties.
Manual image setup
If automatic image setup does not establish the image that you prefer, perform
manual image setup.
Note: Have your monitor powered on for about 15 minutes, until the monitor
warms up.
1. Press Menu
at
the bottom of the monitor to open the OSD menu.
2. Use <<
or >>to select
and press Menu
to access.
3. Use < or >to select Clock and Phase adjustment.
Chapter 3. Reference information 3-3
1024xat 60
1280
2-6
2-2
2-2
2-7

· Clock (pixel frequency) adjusts the number of pixels scanned by one horizontal sweep.
If the frequency is not correct, the screen shows vertical stripes and the picture does not have
the correct width.
· Phase adjusts the phase of the pixel clock signal. With a wrong phase adjustment, the
picture has horizontal disturbances in light picture.
4. When the image no longer looks distorted, save the Clock and Phase adjustments.
5. Press Auto to leave the OSD menu.
3-4 Flat Panel Monitor User 's Guide
Manually installing the monitor driver
Below are steps for manually installing the monitor driver in Microsoft Windows
Vista, Microsoft. Windows XP. and Microsoft Windows 2000 Professional.
Installing the monitor driver in Windows Vista
To install the monitor driver in Microsoft Windows Vista, do the following:
Note: You must download files from the Lenovo Monitor CD to use the Plug and
Play feature in Windows Vista.
1. Turn off the computer and all attached devices.
2. Ensure that the monitor is connected correctly.
3. Turn on the monitor and then the system unit. Allow your computer to start
the Windows Vista operating system.
4. Open the Display Properties window by clicking Start-> Control Panel,
and then double-clicking the Hardware and Sound icon.
5. Click the Personalization icon.
6. Click the Display Settings icon.
7. Click the Advanced Settings button.
8. Click the Monitor tab.
9. Click the Properties button.
10. Click the Driver tab.
11. Open the "Update Driver Software-Generic PnP Monitor" window by
clicking on Update Driver. and then click the "Browse my computer for
driver software" button.
12. Select "Let me pick from a list of device drivers on my computer".
13. Click the Have Disk button. Click on the Browse button and navigate to the
following directory:
X:\Monitor Drivers\Windows Vista
(where X is the drive letter designator for the CD-ROM drive).
14. Select the "LEN114B.inf" file and click the Open button. Click the OK button.
15. Select Lenovo D173 and click Next. The files will be copied from the CD to your
hard disk drive.
16. Close all open windows and remove the CD.
17. Restart the system. The system will automatically select the maximum
refresh rate and corresponding Color Matching Profiles
Note: On LCD monitors, unlike CRTs, a faster refresh rate does not improve
display quality. Lenovo recommends using either 1280 x 1024 at a refresh rate
of 60 Hz, or 640 x 480 at a refresh rate of 60 Hz.
