Lenoxx BCR663 User manual

MODEL: BCR663
BATCH NO: PR3659
PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

SAFETY INFORMATION AND WARNINGS:
* Do not press two or more keys at the same time.
* To avoid failure, the interval of every touch must be more than 1 second.
* If there is any malfunction, please unplug the unit for 3 seconds.
* If the batteries are not used for a long time, please remove.
* When the batteries voltage becomes low, the product will get restart and all settings will be lost.
Please replace with new batteries.
* The adaptor is designed to be used with this product only, please do not use the adaptor to charge
other devices such as a Mobile Phones.
* If the USB lead or power adaptor have become damage, please do not use the USB lead or power
adaptor.
* The unit does not have an ON/OFF switch. To disconnect the unit from it’s power source, remove
the plug from the wall outlet and/or remove the batteries if added.
1. This unit is for indoor use only.
2. Do not expose the unit to dripping or splashing.
3. Do not place any object filled with liquids, such as vases, on the unit.
4. The mains plug of the unit should not be obstructed OR should be easily accessed during
intended use.
5. Do not expose batteries to excessive heat such as sunshine, fire or the like.
6. Ensure there is 10cm distance around the unit for sufficient ventilations.
7. The ventilation should not be impeded by covering the ventilation openings with items such as
newspaper, table-cloths, curtains etc.
8. No naked flame sources such as lighted candles should be placed on the unit.
9. Store in a cool, dry place with the batteries removed if the unit will not be used for a long time.

FUNCTIONS:
• LED time display in 12-hour or 24-hour format
• White light and colour light
• Sunrise simulation wake-up light
• Sunset simulation sleep light
• 10 levels of light brightness
• Automatic mood light colour changing
• Choose a coloured mood light from 6 different colours
• Dimmable time display: high, low or off
• 6 x pre-set wake up sounds
• Wake by FM radio
• FM radio with antenna lead
• Power supply: DC 5V or 2 x AAA batteries (not included)
Use batteries as a backup power source. ln case of electricity failure this will be used to save the
settings.
When the product is running on batteries, the Function are abilities limited:
-Time display will be switched off after 10 seconds. Press any key to switch on time display.
-Alarm function is available; the display will be switched off after 10 seconds.
- Radio is available.
-All light functions are unavailable in battery mode
Battery installation:
Require 2 AAA Batteries (not included)
- Open the battery compartment
- Insert 2 AAA batteries.
- Observe the polarity.
- Close the battery compartment.
To power on, connect the
USB cable to the adapter
and product. Plug the adapter
to a power socket.

OVERVIEW:
light display
Time display
Snooze
Current
time
Alarm
Down
Light
FM
Sunset
Up
Nature
sounds
Volume
Battery
compartment
Stand
12H-24H format
Intensity
of time
display
USB 5V
Antenna

OPERATION:
1. Place the Wake-up Light 40-50 cm from your head, for example on a bedside table.
2. Connect with DC 5V power, after 1 second the unit will enter the clock setting mode.
SETTING THE CLOCK TIME:
1. You must set the clock time when you plug in the appliance for the first time and when there
has been a power failure.
2. The hour on the time display will blink. You can adjust hour by touching the
buttons.
3. Touch the button to confirm the hour. Setting will be cancelled if no action in 5
seconds.
4. The minutes on the time display will blink. You can adjust hour by touching the
buttons.
5. Touch the button to confirm the minutes. Setting will be cancelled if no action in 5
seconds.
6. Choose between a 12-hour and a 24-hour clock by pressing the button which is on
the rear of the unit.
When the 12-hour time format is selected, AM or PM will be displayed.
7. Press the button on the rear of the unit to adjust the intensity of time display: Low -
High - Off.

8. When powered by 2 x AAA batteries, time display will automatically disappear in 5 seconds,
you can press any of the buttons to show the time display.
LIGHT:
1. First touch the button to switch on white light and use it as a bedside lamp. You can
adjust the white light intensity by touching the buttons , there are 10 different
levels of brightness.
2. Touch the button a second time to enter into automatically colour changing mode
and use it as a mood light. You can touch the buttons repeatedly to choose to
display a single colour light. The light colour options are green, red, blue, pink, orange and
aqua.
3. Third touch button to switch off the light.
SETTING THE ALARM/WAKE UP TIME:
1. Touch the button if you want to switch the alarm on or off. The alarm symbol
appears on the time display when you switch on the alarm. It disappears when you switch
off the alarm.
2. Long touch the button for 3 seconds to set the alarm, the hour indication will start to
blink and you can adjust the hour of alarm time by pressing the buttons. Setting
will be cancelled if nothing is pressed within 5 seconds.
3. Touch the button. The minute indication will start to blink and you can adjust the
minutes of alarm time by pressing the buttons.
Setting will be cancelled if no action in 5 seconds.
4. Touch the button to save the alarm time.
5. Press the button on the rear of the unit, then touch the buttons on the
front of the unit to choose between 1 and 7 as a wake-up sound. 1-6 are pre-set natural
sounds and 7 is FM radio). If switching between 1 and 6 as a new alarm sound, a preview of
that sound will be played for 10 seconds. Switching to number 7, no sound will be played
and your last listened to FM station will be the wake-up sound.

Press the button again to confirm the wake-up sound. The setting will be cancelled if
there is no action in 5 seconds.
6. You can choose a volume level (for the wake-up sound) between 00 and 15 (default is 10) by
pressing the button on the rear of the unit repeatedly to increase the volume level to
your chosen level. There is no volume decrease button.
SUNRISE SIMULATION WAKE UP LIGHT/ ALARM/ SNOOZE:
30 minutes before alarm time, the sunrise simulation white light will come on and the light will
gradually increase in intensity to the alarm time.
At alarm time, the wake-up sound will play for 2 minutes.
While the wake-up sound playing, touch the button to enter snooze mode. The wake-
up sound will play again after 5 minutes and last for 2 minutes.
Touch/Press any button except for the button to stop the wake-up sound.
During wake-up light period, you can switch off the wake-up light by long touching the
button for 3 seconds.
SETTING THE SUNSET/SLEEP TIME:
1. Touch the button to switch sunset on or off. The sunset symbol
appears on the display when you switch on, it disappears when you switch off.
2. Long touch the button to set the alarm, the hour indication starts to blink.
You can adjust the hour by touching the buttons.
Press the button again and the minute indication will start to blink.
You can adjust the minutes by touching the buttons.
.
3. Touch the button again to confirm the sunset time.
Setting will be cancelled if nothing is pressed within 5 seconds.
SUNSET SIMULATION SLEEP LIGHT:

1. 30 minutes before sunset time, the sunset simulation white light will be on at 100% intensity
whatever at any mode, and then it will become lower and lower intensity until turn off at
sunset time.
2. During sunset light period, you can switch off sunset light by long touching the
button for 3 seconds.
FM RADIO:
1. Touch "FM button" to turn the radio on. Press it again to turn the radio off.
2. When the radio is on, long touch the "FM" button for 3 seconds to scan radio frequencies
automatically. The scanned frequencies will be saved automatically. The saved radio stations
can not manually be pre-set into various positions.
3. Touch the buttons choose between the saved radio stations.
4. Tip: To get a good radio signal, fully unwind antenna and move it around until you receive
the best reception.
5. Press the button on the rear of the unit repeatedly to increase the volume level to
your chosen level. There is no volume decrease button.
