Thank you for choosing WINDCUBE® v2 Offshore 8.66 for your wind measurement
activities. WINDCUBE® v2 Offshore 8.66 has been designed to ensure you a reliable
and easy way to measure wind profiles. We wish you success in its use and hope
that it will contribute to the advancement of your projects.
The WINDCUBE® v2 Offshore 8.66 technology has been developed in cooperation
with the Applied and Theoretical Optics Department (DOTA/SLS, ONERA, France).
ONERA has granted an exclusive licence for the manufacturing of the WINDCUBE® v2
Offshore 8.66 to LEOSPHERE.
LEOSPHERE and WINDCUBE® v2 Offshore 8.66 are registered trademarks.
Contact information regarding this document:
LEOSPHERE
14-16 rue Jean Rostand
91400 Orsay, France
SUPPORT PHONE: [phone]
FAX [phone]
E-mail: [email protected]om
ACKNOWLEDGEMENTS

5
CONFIDENTIAL
45
CONFIDENTIAL
LASER SAFETY
The WINDCUBE®v2 Offshore 8.66 is a class 1M Laser product, at the output.
CAUTION: The laser beam emitted by WINDCUBE®v2 Offshore 8.66 is in the infrared spectrum and is
not
visible to the naked eye.
CAUTION: Do not stare directly into beam with optical instruments (binoculars or telescopes).
The beam is emitted through the Laser aperture situated on the top of the
WINDCUBE®v2 Offshore 8.66 at 28° angle off vertical. (Fig. 2).
CAUTION: The WINDCUBE®v2 Offshore 8.66 utilizes a class 4 LASER, inside the system itself. In order
to avoid eye injury, do not open the optical head nor disconnect any optical fibers.
CAUTION: If the equipment is used in a manner not specified in this manual, it may result in
hazardous radiation exposure.
28°
Fig. 2 - LASER aperture
GENERAL SAFETY INSTRUCTIONS
The WINDCUBE®v2 Offshore 8.66 system is intended to be used for wind measurement
purposes only.
The WINDCUBE®v2 Offshore 8.66 is designed for outdoor use only.
Review this manual thoroughly before powering up and operating the WINDCUBE®v2 Offshore
8.66.
CAUTION: The protection provided by the WINDCUBE®v2 Offshore 8.66 could be compromised
if it is used in a manner not specified in this manual.
In case of emergency (fire, water flood risk), unplug the WINDCUBE®v2 Offshore 8.66
main power supply from 90~264 VAC plug (Fig. 1).
SAFETY
Fig. 1 - IP67 power converter
90~264 VAC connector

7
CONFIDENTIAL
67
CONFIDENTIAL
SYMBOLS APPENDED ON WINDCUBE® v2 Offshore 8.66
The following symbols are present in the WINDCUBE®v2 Offshore 8.66 trapdoor:
Caution, risk of danger: Documentation must be consulted.
Power connector: provides 24VDC and a maximum power of 200W.
*Certification pending
ELECTRICAL SAFETY
CAUTION: Always unplug the WINDCUBE® v2 Offshore 8.66 power supply cable before servicing any
part of the system.
CAUTION: Check power supply quality. Poor quality may result in electrical shocks and damage
of electronic components.
STANDARD COMPLIANCE
EMC IEC EN 61326-1, July 2006*
Safety IEC EN 61010-1, June 2001
LASER IEC EN 60825-1, January 2008
Class 1M
Degrees of protection provided
by enclosure
IEC EN 60529, June 2000
IP66 : enclosure
IP67 : power supply and critical internal components
Transport ISTA, FEDEX 6B (International Safe Transport Association)
Salt atmosphere compliance IEC 60068-2-52

9
CONFIDENTIAL
89
CONFIDENTIAL
4 - FIELD OPERATION 55
1. FTP DATA TRANSFER .................................................................................................................................56
2. TRANSPORTATION.................................................................................................................................... 60
3. STORAGE...................................................................................................................................................61
5 - MONITORING 63
1. MEASUREMENT VISUALIZATION ............................................................................................................... 64
2. VISUAL INDICATORS..................................................................................................................................67
3. ALARMS.................................................................................................................................................... 71
6 - DATA FILE DESCRIPTION 73
1. INTRODUCTION..........................................................................................................................................74
2. WIND VECTOR DESCRIPTION BACKGROUND .............................................................................................75
3. STA FILE.....................................................................................................................................................76
4. STA FILE MANAGEMENT............................................................................................................................81
5. STA FILE DISPLAY ......................................................................................................................................83
6. OTHER DATA FILES ....................................................................................................................................87
7. GYRO DATA FILES.......................................................................................................................................91
8. DATA VOLUME...........................................................................................................................................93
7 - MAINTENANCE AND SERVICE 95
1. MAINTENANCE ......................................................................................................................................... 96
2. FIRST LEVEL DIAGNOSIS.......................................................................................................................... 101
3. CUSTOMER SERVICE.................................................................................................................................106
4. WARRANTY..............................................................................................................................................111
5. DATE OF CARE - RECYCLING MATTERS .................................................................................................... 112
1 - WINDCUBE®v2 Offshore 8.66 DESCRIPTION 13
1. PACKING LIST.............................................................................................................................................14
2. WINDCUBE v2 OFFSHORE 8.66 OVERVIEW................................................................................................16
3. WINDWEB OVERVIEW................................................................................................................................18
4. DIMENSIONS.............................................................................................................................................19
5. SPECIFICATIONS ........................................................................................................................................20
2 - REQUIREMENTS 23
1. GENERAL CONDITIONS OF USE..................................................................................................................24
2. CONTEXT OF DEPLOYMENT........................................................................................................................26
3 - FIELD INSTALLATION 27
1. IDENTIFY LOCATION...................................................................................................................................28
2. PREPARE AND SECURE LOCATION.............................................................................................................29
3. WINDCUBE ANYWHERE-3G OPTION..........................................................................................................30
4. WINDCUBE ANYWHERE SATELLITE OPTION...............................................................................................33
5. BIRD SPIKES INSTALLATION......................................................................................................................36
6. EXTERNAL PUMP CONNECTION.................................................................................................................37
7. POWER SUPPLY CONNECTION....................................................................................................................39
8. SWITCH ON ...............................................................................................................................................41
9. DIRECT CONNECTION.................................................................................................................................42
10. WIRELESS CONNECTION ..........................................................................................................................44
11. CHECK INSTALLATION ............................................................................................................................. 48
12. MEASUREMENT CONFIGURATION............................................................................................................ 51
13. STARTING MEASUREMENTS.....................................................................................................................54
TABLE OF CONTENTS TABLE OF CONTENTS

11
CONFIDENTIAL
10 11
CONFIDENTIAL
A LIDAR installation on a floating buoy or other
dynamic environment can potentially result
in a measurement bias in the measurement
accuracy and and have effects on LIDAR wind
measurement reliability overall. In order to
accurately retrieve and process properly the
wind speed and wind data, an inertial sensor
has been installed within the WINDCUBE®
v2 Offshore 8.66 system. Additionnal built-in
software (real time Inertial Measurement Unit
with advanced filtering capabilities) takes into
account the pitch, roll and yaw movements.
This algorithm allows for the compensation
of such movements and the achievement of
high quality wind measurement in dynamic
environements.
These innovations allow for the accurate mea-
surement of wind ressource in sea state, for
both statistical and real time data. Accurate
real time data are required for turbulence
intensity measurement, which is a parameter
of high interest for site assessment as well as
power curve measurement.
The WINDCUBE® v2 Offshore 8.66 works also in
harsh conditions, as it integrates a watertight
casing structure immune to corrosion with
surface treated components, and corrosion
resistant connectors.
WINDCUBE® v2 Offshore 8.66 introduction
The WINDCUBE®v2 Offshore 8.66 is a LIDAR (Light
Detection And Ranging) used for wind profile measu-
rement from 40m to 200m.
The LIDAR sends infrared laser pulses into the at-
mosphere. Four beams are sent successively in four
cardinal directions along a 28°scanning cone angle,
followed by a fifth, vertical beam. Laser pulses are
backscattered by aerosol particles in the air (dust, wa-
ter droplets, aerosol, etc.), that move at wind speed.
The collected backscattered light allows for the cal-
culation of wind speed and direction using Doppler
induced laser wavelength shift. Up to 12 different
range gates can simultaneously be measured using
the laser pulse time of flight allowing to measure the
wind speed at 12 different heights.
The backscattered light is converted into an electro-
nic signal and digitized. A dedicated signal processing
algorithm computes wind vector components from
five consecutive line of sight measurements. Leos-
phere Windsoft software controls the hardware and
performs the processing. The user interacts with the
WINDCUBE®v2 Offshore 8.66 (measurement configu-
ration and real-time monitoring) through a graphical
user interface, Windweb. Windweb can be displayed
on any web-browser.
Real time and statistical wind data are stored on
WINDCUBE®v2 Offshore 8.66’s solid-state hard disk
drive. The user downloads accumulated data files via
the Windweb.
Fig. 3 - WINDCUBE®v2 Offshore 8.66 functioning scheme
Remote access option or
Ethernet connection

CONFIDENTIAL
BLANK PAGE
1 - WINDCUBE®v2 Offshore 8.66 DESCRIPTION
1. Packing List
2. WINDCUBE® v2 overview
3. Windweb overview
4. Dimensions
5. Specications

15
CONFIDENTIAL
14 15
CONFIDENTIAL
IP67 Power Converter
Voltage Input: 90~264 VAC / 127~373 VDC
Voltage Output: 24VDC
External water pump with connector kit, and a water
tank
Accessories: bird spikes, fuses, spare wiper blade.
Photo for information only
3 Ferrites
1 Ethernet cable
Optional: 3G/GPRS antenna, Satellite antenna
1. PACKING LIST
WINDCUBE®v2 Offshore 8.66 system
WINDCUBE®v2 Offshore 8.66 standard system parts provided to users are :
User Guide
Front_Bouée_v02.indd 1 25/07/2014 13:33:28
Shipping case
User manual
Photo for information only

17
CONFIDENTIAL
16 17
CONFIDENTIAL
Fig. 4 - Connection trap
PORT 1
LAPTOP
RJ45
PORT 2
LAN
RJ45
MAIN
Power
Supply
PUMP
Power
Supply
PORT 3
THP* probe
(Optional) RJ 45 USB Port Measurement
LED
Satellite
Antenna Cable
(Optional)
Main switch
*Temperature Humidity Pressure
3G/GSM
antenna cable
(Optional)
Photo for information only
2. WINDCUBE v2 OFFSHORE 8.66 OVERVIEW
Window Wiper arm
Front door
Handle
Connection
trapdoor
Rear door
Wiper blade
Door locker
Fixing ring
against theft
Photo for information only

19
CONFIDENTIAL
18 19
CONFIDENTIAL
543
552 46,5
547
387
80 80
79 394
79
25
70
44
180
1
2
3
633
10°
5°
15°
A
A
COUPE A-A
AV
AR
1/4
Montage des accastillages extérieure aux rivets Inox téflonés
No. article Description Numéro utilisation/Quantité
1 Couvercle AR "Cont. Monobloc C8 "Windcube version offshore" $2903022607B 1
2Tube "Cont. Monobloc C8 "Windcube version offshore"
$2901022607A 1
3
Couvercle AV "Cont. Monobloc C8 "Windcube version offshore" $2902022607B 1
1:4
2607B
LEOSPHERE
Polyester
+/- 2
2.1398
$2900022607B
22/12/2011
L. PERICHET
C8 blanc
Conteneur Monobloc C8 "Windcube version offshore"
-
-
CE PLAN EST LA PROPRIETE D'ART CONCEPT COMPOSITES ET NE PEUT ETRE REPRODUIT OU COMMUNIQUE SANS AUTORISATION
DENOMINATION
ENSEMBLE
SOUS ENSEMBLE
ECHELLE
PROTECTION
DESSINE PAR
DATE
VERIFIE PAR
MATIERE
CLIENT
N° AFFAIRE
CODE
TOL. GENERALE
INDICE
PLAN N°
MODIFICATION VERIF. DESS. DATE IND.
B
21/09/12
A.T
Modification de l'empreinte et de la mousse de couvercle AV pour GPS
JCN
A. THIMEUR
B
4. DIMENSIONS
Door opens on this side
* Units: millimeters
543
552 46,5
547
387
80 80
79 394
79
25
70
44
180
1
2
3
633
10°
5°
15°
A
A
COUPE A-A
AV
AR
1/4
Montage des accastillages extérieure aux rivets Inox téflonés
No. article Description Numéro utilisation/Quantité
1 Couvercle AR "Cont. Monobloc C8 "Windcube version offshore" $2903022607B 1
2Tube "Cont. Monobloc C8 "Windcube version offshore"
$2901022607A 1
3
Couvercle AV "Cont. Monobloc C8 "Windcube version offshore" $2902022607B 1
1:4
2607B
LEOSPHERE
Polyester
+/- 2
2.1398
$2900022607B
22/12/2011
L. PERICHET
C8 blanc
Conteneur Monobloc C8 "Windcube version offshore"
-
-
CE PLAN EST LA PROPRIETE D'ART CONCEPT COMPOSITES ET NE PEUT ETRE REPRODUIT OU COMMUNIQUE SANS AUTORISATION
DENOMINATION
ENSEMBLE
SOUS ENSEMBLE
ECHELLE
PROTECTION
DESSINE PAR
DATE
VERIFIE PAR
MATIERE
CLIENT
N° AFFAIRE
CODE
TOL. GENERALE
INDICE
PLAN N°
MODIFICATION VERIF. DESS. DATE IND.
B
21/09/12
A.T
Modification de l'empreinte et de la mousse de couvercle AV pour GPS
JCN
A. THIMEUR
B
453
74
305
100
9
Fig. 5 - Side view Fig. 6 - Door with the trap
Fig. 7 - Top view Fig. 8 - Bottom view
3. WINDWEB OVERVIEW
Start/stop wind
measurements
System status
indicators
Display wind
measurements
Horizontal wind speed
profile
Horizontal wind direction
profile Restart button

21
CONFIDENTIAL
20 21
CONFIDENTIAL
TRANSPORTATION
Size System: 547x 552 x 633 mm (without bird spikes)
Transport case: 705 x 775 x 705 mm
Weight System: 45 kg
Transport case only : 30 kg
SOFTWARE / DATA
Data format ASCII
Data storage SSD and Compact Flash (Backup storage)
Data Transfer 3G / GPRS (Optional)
Satellite (Optional)
Standard WINDSOFT™ Software Configuration & Control
Real time display
Diagnosis
Output Data 1s/10 min horizontal, vertical windspeed min & max
Direction
Carrier to Noise Ratio (CNR)
Horizontal & vertical wind speed standard deviation
Quality factor (data availability)
GPS coordinates
(*): According to atmospheric conditions, higher or lower range can be reached. Furthermore, if the
LiDAR moves out of +/-25 degrees, the measurements accuracy decreases out of the range [45 to 135]
m.
MEASUREMENTS
Range 40m to 200m*
Data sampling rate 1 sec
Number of measurement heights 12
Speed accuracy min-max bias versus reference 0.1 m/s (on 10 min averaged speed)
Speed range 0 to +55 m/s
0 to 33 m/s for extreme angles of tilt (+/- 25°)
Direction accuracy +/- 5°
ELECTRICAL
Input Power Supply 18-32 V DC
18-28 V DC with the Windcube Anywhere 3G option
Power Supply with the transformer provided
with the WINDCUBE®v2 Offshore 8.66
90 ~ 264 VAC / 127 ~ 373 VDC
47 ~ 63 Hz
Power consumption 45 W between -5°C and 30°C / 23°F and 86°F
100 W below - 5°C / 23°F
ENVIRONMENTAL
Temperature range -20°C to +25°C / -4°F to 77°F
Operating humidity 0 to 100% RH (non-condensing)
Rain protection Wiper
Housing classification IP66 for the external casing
IP67 (internal module and power supply converter)
Shock & Vibration ISTA/FEDEX 6B
LASER Safety Compliance Class 1M IEC/EN 60825-1
Salt Atmosphere Compliance IEC 60068-2-52
5. SPECIFICATIONS

CONFIDENTIAL
BLANK PAGE
2 - REQUIREMENTS
1. General conditions of use
2. Context of deployment
2

25
CONFIDENTIAL
24 25
CONFIDENTIAL
The product specifications are related to a usage of the WINDCUBE® v2 Offshore 8.66 in an environment
that does not disrupt the measurements (for example but not limited to: no physical blocking of the lines
of sight, no magnetic perturbations). Likewise, the above specifications are inherent to the WINDCUBE®
v2 Offshore 8.66 LIDAR mounted on an industry standard buoy. In particular, no obstacle has to interfere
with any of the four 28 degrees laser beams within the tilt window range of +/- 25 degrees.
The device has been designed to operate in harsh sea conditions and can resist all (non-breaking) wave
heights given appropriate floating structure design but no to be submerged under water.
The device has been designed to operate on a floating structure (being 3 m above / below the water line)
but the operation cannot be warrantied after an impact from an external object (such as, but not limited
to a boat) on the WINDCUBE and/or on the buoy.
SYSTEM INTEGRATION
The design of the integration of the LIDAR on the buoy system in order to guarantee that the integration
steps do not alter the system performance.
Before any manipulation of the buoy-adapted LIDAR system, it is mandatory to read the following
informations concerning the specific usage and integration terms.
SYSTEM INTEGRITY
The entire product or its components (inside and outside parts of the buoy adapted LIDAR unit) and also its
accessories and peripherals (for example but not limited to cables, options, etc…) cannot be modified in any
way without written agreement from the supplier.
No component can be added in the WINDCUBE casing without written agreement from the supplier.
Any modifications on the LIDAR for integration to the buoy system must be considered and validated by the
supplier before being integrated.
The power system of the buoy integrated LIDAR system is part of the buoy system. The supplier is not
responsible for electrical system failure arising from a power supply not complying with the electrical
specifications of the product and standard CE regulations with regards to safety and stability.
SYSTEM ENVIRONMENT
The system performance commitment is related to a maximum tilt and roll angle of the system of 25
degrees (no limitations on turn between 0 and 360 degrees with a direction accuracy of 5°), with a
maximum speed of 55 m/s corresponding to a speed accuracy of 0.1 m/s depending on the seawater
conditions (down to [0;33] m/s if the LIDAR moves out of +/- 25 degrees). Given that, It is recommended that
a passive damping system be used to keep maximum tilt within +/- 20 degrees with a nominal tilt of +/- 10
degrees or below.
1. GENERAL CONDITIONS OF USE

CONFIDENTIAL
CONFIDENTIAL
26
3 - FIELD INSTALLATION
3
2. CONTEXT OF DEPLOYMENT
The system should be installed on a floating structure (being 3 m above / below the water line).
The floating structure must be validated by the WINDCUBE LIDAR supplier.
A voltage converter is supplied with the WINDCUBE®v2 Offshore 8.66, with specifications available in
this manual. The user is responsible of the power supply on the floating platform.
Before installing the system on a floating platform, prepare the system and the location, as pre-
sented in the following chapter.
1. Identify location
2. Prepare and secure location
3. WINDCUBE®Anywhere-3G option
4. WINDCUBE®Anywhere-Satellite option
5. Bird spikes installation
6. External pump connection
7. Power supply connection
8. Switch on
9. Direct connection
10. Wireless connection
11. Check installation
12.Measurement configuration
13. Starting Measurements

29
CONFIDENTIAL
28 29
CONFIDENTIAL
2. PREPARE AND SECURE LOCATION
Before installing the system, make sure to have the following accessories or components:
• at least 40L of soft water
• at least 10L of isopropanol
• a proper power supply that conforms to the specifications mentioned in this manual
• in case the options WINDCUBE Anywhere 3G or Satellite have been subscribed, make sure to have a
mast installed high enough for each antenna (see p.32-34 for more information).
Unpack the system and its elements. Store the shipping case.
Shipping case is not waterproof and must be stored in a dry environment.
Before putting the WINDCUBE®v2 Offshore 8.66 on its floating platform, put it on a stable and firm surface,
and install all its peripheral accessories (more information from the section 3.3).
The following chapters explains the installation of:
• WINDCUBE Anywhere 3G/GPRS option (only if subscribed)
• WINDCUBE Anywhere Satellite option (only if subscribed)
• Bird spikes
• Water tank
These installations should be prepared before launching the system on the buoy.
28°
•BeforeinstallingyourWINDCUBE®v2 Offshore 8.66, determine its future location and
ensure that the structure where it will be installed respects the following parameters.
1. IDENTIFY LOCATION
The system is located away from any
obstacles in all wind directions of
interest.
Wind
Obstacles do not interfere with any of the five
laser beams.
Fig. 9 - No obstacle in prevailing wind direction Fig. 10 - No obstacle in scanning cone
28°

31
CONFIDENTIAL
30 31
CONFIDENTIAL
UR5i ROUTER OVERVIEW
Fig. 12 - UR5i router face view
SIM card
slot
SIM CARD INSTALLATION
An activated SIM card, with data transfer enabled, is required for the GPRS/3G connection.
The APN (Access Point Name) address, login and password may also be required to configure the modem
properly.
• SIM card installation
- Open the door without the trap. You have access to the modem, installed on the right.
- Press on the yellow button with a fine needle or a pen to open the card slot.
- Insert the SIM card and close the slot. Finally, close the WINDCUBE main door.
NOTE: Supplier is not responsible for any problems due to bad coverage on site, or GPRS/3G subscription
plan.
Button
The WINDCUBE®v2 Anywhere-3G option provides remote access to WINDCUBE®v2 Offshore
8.66 via 3G/GPRS connection. It allows the user to access the WINDCUBE®v2 Offshore 8.66
system from any computer with an internet connection, to download data and receive data
daily by email.
PACKING LIST
WINDCUBE®v2 Anywhere 3G option provided parts are:
- UR5i router: this 3G/GPRS router is already installed and connected in the WINDCUBE®v2.
- External Antenna: omnidirectional triple band marine antenna for 900MHz, 1800MHz and
1900MHz bands.
Fig. 11 - Antenna representation
3. WINDCUBE ANYWHERE-3G OPTION

33
CONFIDENTIAL
32 33
CONFIDENTIAL
Windcube Anywhere - Satellite option allows remote access to WINDCUBE®v2 via a satellite
network. System graphical user interface (Windweb) is accessible from any computer connected
to internet through any web browser.
Averaged data can be directly downloaded from Windweb or automatically sent by e-mail.
4. WINDCUBE ANYWHERE SATELLITE OPTION
ANTENNA OVERVIEW
Upper part of
the antenna
Lower part of the
antenna
TNC connector
RF cable
Fig. 14 - Satellite antenna
ANTENNA OVERVIEW
• Antenna installation:
- Plug the FME/SMA adaptater into the external antenna plug.
- Fix the external antenna on a mast using the 2 U-bolts.
NOTE : The antenna must be oriented to the sky.
- Setup an appropriate grounding of the antenna using the lightning protection.
External
Antenna FME/SMA
Adapter
6 meters-
FME cable
Protective
sleeve
Lightning
protection
U-bolts
(x2)
Fig. 13 - Antenna overview

35
CONFIDENTIAL
34 35
CONFIDENTIAL
CABLE INSTALLATION: REQUIREMENTS
Cable installation should also take into account the following recommendations:
Route and restrain the cables to prevent them from vibrating or moving under normal conditions, which
could result in damage to the antenna, or the coaxial cable connections.
When you must bend a cable, avoid kinking it, and ensure that each bend radius follows the cable supplier’s
recommended limits.
NOTE: A bad connection may corrode, causing performance problems and potentially affecting warranty
coverage of the modem.
SIM CARD REQUIREMENTS
The modem requires a valid Iridium SIM card. When delivered, the SIM card is already installed and opera-
tional.
ANTENNA INSTALLATION: REQUIREMENTS
For effective operation of the satellite option, it is essential that the antenna is deployed in a suitable loca-
tion. The following section provides a series of guidelines for best practice in antenna installation.
Obstructions to the line-of-sight can create areas of poor system coverage. The antenna MUST have a clear
view to the satellite at ALL TIMES.
The antenna must be upright/facing the sky to ensure maximum exposure of and for the satellite.
The antenna must be located so that it has a good view of the sky, ideally providing good horizon coverage.
For optimum coverage the satellite antenna should be deployed in a location where it has clear and un-
interrupted view of the sky from 10 degrees above horizontal in all directions.
Antenna should be mounted so that they are away from structures (masts, buildings, etc) by a minimum
distance of at least 0.5metres.
Ensure that the antenna is mounted so that it will not become detached from its supporting structure under
normal external forces.
ANTENNA INSTALLATION
Install the antenna on its final location, according the previous requirements. Screw the RF cable to the SMA
connector inside the WINDCUBE®v2 Offshore 8.66 trap.
NOTE: Make sure the SMA connector is screwed enough to ensure waterproofing of the connection and a
good signal transmission.

37
CONFIDENTIAL
36 37
CONFIDENTIAL
6. EXTERNAL PUMP CONNECTION
Fig. 17 - Water container
External Pump
Neoprene Water
Conductor
External Pump
Power Supply Cable
Pump filter
•Mountthecontainerbyinsertingthe5feetintheirdedicatedlocationsonthelower
part
Container foot
Drain valve
Opening for cables
Fig. 18 - External water pump
of the container.
•Installthepump:firstinsertthepowersupplycableinthecontaineropeningandthen,
the Neoprene cable, so that the pump is in the container.
Six pairs of clips are already attached to the top of WINDCUBE®v2 Offshore 8.66.
• Place one bird spike in diagonal between each pair of clips and turn it according to the blue arrows on
the picture below. The bird spike strip is now partly clipped on the system.
• Take a new clip, remove the green plastic film and gently raise the free end of the bird spike strip.
• Hang the third clip on the strip as shown on the picture above and add some superglue under. Loctite
454 glue works well for this purpose.
5. BIRD SPIKES INSTALLATION
Fig. 15 - Bird spike installation Fig. 16 - Clip insertion
• Attach the thrid clip to the enclosure without removing the bird spike strip.
• Repeat the same procedure for the 5 other bird spike strips.

39
CONFIDENTIAL
38 39
CONFIDENTIAL
•ConnectthemainpowersupplyinWINDCUBE®v2 Offshore 8.66 trapdoor to its power
supply.
7. POWER SUPPLY CONNECTION
The WINDCUBE® v2 Offshore 8.66 does not integrate an emergency stop. When powered by the
included AC/DC power adapter, the user must remove the adapter’s main power plug from the grid in
order to cut power to the WINDCUBE. The user is responsible for posting safety signs and maintaining
easy access to the main power plug.
Fig. 20 - Connection Trap - Main power supply and GND plug
Main power
supply
Fig. 19 - Connection trap - Pump power supply connector
Pump power
supply
•ConnectneoprenewaterconductorfromexternalpumptoWINDCUBE®v2 Offshore 8.66 wiper
water conductor using the included adapter.
NOTE: The pump filter should be regularly cleaned, to ensure external pump efficiency.
• Fill the container with a mixture of water and isopropanol (isopropyl rubbing alcohol)
according to the maintenance program (see section 7.1). Water level must be a minimum
of 10 cm in order to completely cover the pump.
•ConnectexternalpumppowersupplycableintoWINDCUBE®v2 Offshore 8.66 trapdoor.
