Lepai LP40PA User manual

Model: LP40PA
Mini Stereo Plate Amplier
with Bluetooth and Control Panel
OPERATING MANUAL

AMP PANEL
1. Output for left speaker
2. Power switch
3. Power input
4. Auxiliary input
REAR PANEL
5. Mode
6. Press - Volume Down / Hold - Skip Back
7. Press - Volume Up / Hold - Skip Forward
8. LED status indicator
9. Play/Pause
Front View of Amplier
Control Panel
INTRODUCTION
The Lepai LP40PA Mini Stereo Plate Amplier provides clean Class D power
for your speaker building projects, and is also perfect for repairing existing
powered speakers or retrotting as an upgrade to your favorite bookshelf
speakers. 40 watts of power will drive your speakers to very satisfying volume
levels, while 3.5 mm input and Bluetooth will make your speakers easy to use
in any common application.

Power Output: 20W x 2 RMS; 40W x 2 peak
Minimum impedance: 4 ohms
Power input: 18VDC, 2A (AC adapter included)
Frequency response: 20 - 20,000 Hz
THD + N: <0.7%
Bluetooth version: 4.2
Bluetooth range: Up to 30 meters
AMPLIFIER AND CONTROL PANEL INSTALLATION
The plate amp panel requires a cutout 2.75" x 1.75" (70 x 45 mm) with at
least 2.625" (67 mm) depth. Mount the plate to your right speaker cabinet,
and connect the included output leads to the terminals of your speaker or
crossover network, observing correct polarity.
The control panel requires a cutout approximately 2.6" x 0.79" with at least 1"
depth. The control panel is press-t, and uses no mounting hardware. Different
materials will have various degrees of “give” or resistance to the pressure t
of the panel. Therefore, you may wish to cut a test hole(s) in a piece of scrap
material to ensure a proper t, and only cut the hole in your nished cabinet
once this has been determined.
Connect the control panel to the amp panel using the included leads, then
press the control panel into place.
CONNECTING YOUR SPEAKERS
With the power turned OFF, use high quality wire for the connection between
the right and left speakers. For distances up to 10 feet, conventional 18AWG
wire is acceptable. For longer runs, heavier wire should be used. For proper
performance please observe correct polarity.
BLUETOOTH CONNECTION
Turn the power switch ON. The speaker will enter pairing mode, and the LED
indicator will ash blue quickly. Open the Bluetooth menu on your device and
select “LP40PA”. You will hear two beeps when pairing is complete, and the
LED will remain solid blue.
AUX CONNECTION
Plug your device into the AUX jack on the right speaker using a 3.5 mm stereo
cable (not included). The LED indicator will light solid red to indicate AUX
connection.
PLEASE NOTE: for the best sound quality in Bluetooth or AUX mode, we
recommend that your device’s volume level be set no higher than 90%.
SPECIFICATIONS

Lepai® is a registered trademark of parts-express.com
1-year limited warranty
See lepaiaudio.com for details
