LevelOne KVM-9007 User manual

LevelOne
KVM-9007
KVM Cat.5 Receiver
User Manual
Ver.1.00-0701

TABLE OF CONTENTS
INTRODUCTION....................................................................................................................... 3
OVERVIEW .............................................................................................................................. 3
FEATURES............................................................................................................................... 3
PACKAGE CONTENTS ............................................................................................................... 4
FRONT PANEL.......................................................................................................................... 4
REAR PANEL ........................................................................................................................... 5
INSTALLATION......................................................................................................................... 5
OSD........................................................................................................................................... 5
1. SECURITY............................................................................................................................ 6
2. HELP................................................................................................................................... 6
3. HOTKEY OSD WINDOW ........................................................................................................ 7
4. REVISE PASSWORD WINDOW ................................................................................................ 7
5. CONSOLESTATUS............................................................................................................. 9
6. LOCAL PC-PORTAND REMOTE PC-PORT SWITCH .................................................................. 9
7. BUZZER CONTROL................................................................................................................ 9
8. SCAN PC PORT.................................................................................................................... 9
TROUBLESHOOTING............................................................................................................ 10
SPECIFICATIONS................................................................................................................... 10
CERTIFICATION......................................................................................................................11
2

Introduction
Overview
Thank you for purchasing LevelOne KVM-9007 Cat.5 receiver. KVM-9007
enables user to access the PC, server or KVM switch up to 300 meters away
from your keyboard, VGA (monitor) and mouse. It receives the signals from
Cat.5 cable and converts them into signals of USB keyboard, VGA and USB
mouse respectively.
KVM-9007 can be used with KVM switch that has remote console port. When
working with KVM switch that has remote console port
(KVM-0831/1631/KCM-0831/1631), users are able to access KVM switch and
control all the PCs which connected to the KVM switch from 300 meters away.
KVM-9007 is a good solution for those noisy server room environment where is
unsuitable for people to work for a long time. Besides, it facilitates effective
management on dispersive computers through one dedicated central control
room, demonstration room, meeting room, or at your desk.
Features
KVM Cat.5/Cat.5e/Cat.6 signal receiver from remote located KVM
switches
Extends, transmits and receives KVM Cat.5 signals from up to 300 meters
(1000 feet) away
Designed for application with KVM switches with built-in remote console
port
Built-in local host-port to manage an additional computer directly
connected
Easy installation with no additional software required
Note:
It is highly recommended to use Cat.5e cable when the connection is shorter
than 150 meters, and to use Cat.6 cable when the connection is between 150
and 300 meters.
3

Package Contents
zKVM-9007
zPower Adapter DC9V 0.5A
zFour Rubber Foot pad
zCD Maunal
If any item is found missing or damaged, please contact your local reseller for
replacement.
Front Panel
Console Port: Connect USB keyboard and mouse.
Remote LED
LED display Indication
Light off Remote port is not selected
Light on Remote port is selected
Light flash Auto detecting device on remote port
Local LED
LED display Indication
Light off Local port is not selected
Light on Local port is selected
Light flash Auto detecting device on local port
Select Button: Select between local and remote side.
4

Rear Panel
DC power jack: Connect power adapter.
Console port: Connect to local monitor.
Local port: Connect to local host PC.
RJ-45 port: Connect to remote KVM switch or severs over Cat.5 cable.
Installation
Connect to KVM switch with ACC-1000 Cat.5 console module
1. Attach the rubber feet to the bottom of KVM-9007.
2. Connect keyboard, VGA and mouse to the console port.
3. If you want to add a local PC, connect local PC to the local host port with 3
to 1 KVM cable (ACC-2101 / 2102 / 2103).
4. Connect one end of Cat.5 cable to the RJ-45 jack of KVM-9007.
5. Connect the other end of Cat.5 cable to the remote console port
(ACC-1000) of the KVM switch (KVM-0831/1631/KCM-0831/1631).
6. Connect the power adapter to the power jack on the rear panel, and the
other side of power adapter connects to the power outlet.
OSD
On screen display (OSD) gives you a convenient way to access and control
the computers. It includes management functions such as security, language
and help etc.
【Note】【Caps Lock】key is the default OSD hotkey, the hotkey can be
changed to other hotkey（see OSD F2 Hotkey, for details）
Hotkey operation
1. scrollÅ【scroll lock】key
2. numÅ【number lock】key
3. capsÅ【caps lock】
4. LctrlÅleft hand site of the 【Ctrl】key.
5. RctrlÅright hand site of the 【Ctrl】key.
5

6. LaltÅleft hand site of the 【Alt】key,
7. RaltÅright hand site of the 【Alt】key.
8. LwinÅleft hand site of the “window” key
9. RwinÅright hand site of the “window” key （some keyboards might not
have this key）
1. Security
S E C U R I T Y
U S E R N A M E
_ _ _ _ _ _ _ _
P A S S W O R D
_ _ _ _ _ _ _ _
To bring up the Security window：
(1) Power-on.
(2) Press “optional hotkey” twice, the press 【F4】key.
【Note】Default user name and password is “00000000”
To close the Security window：
(1) key in a valid user name, then press【Enter】key; key in valid
password, then press【Enter】key.
(2) Press【Esc】key.
(3) Connect to a KVM device（via Cat.5 interface）
【Note】
1. Available keys for user name and passwords are 0 ~ 9, a ~ z（no
capital difference）
2. Numbers on right hand site of the keyboard are not available to use.
2. Help
H E L P
F 2 : H O T K E Y
F 3 : R E V I S E I D
F 4 : S E C U R I T Y
6

To bring up the Help window：
Tap “optional hotkey” twice, then press “F1”
To close the Help window：
Tap any key on your keyboard.
3. Hotkey OSD window
H O T K E Y L I S T
1 . s c r o l l
2 . n u m
3 . c a p s
4 . L c t r l 5 . R c t r l
6 . L a l t 6 . R a l t
8 . L w i n 9 . R w i n
To bring up the Hotkey window：
(1) Tap “optional hotkey” twice, then press “F2”.
(2) In Help window, tap “F2”.
To close the Hotkey window：
(1) Press any key on your keyboard.
(2) Done the setup.
4. Revise Password window
R E V I S E
U S E R N A M E
_ _ _ _ _ _ _ _
P A S S W O R D
_ _ _ _ _ _ _ _
V E R I F Y
_ _ _ _ _ _ _ _
To bring up REVISE Password window：
(1) Tap “optional hotkey” twice, then press【F3】key.
(2) In Help OSD window, tap【F3】key.
【Note】Before Revise Password window appears, user has to enter the user
name and password in Security OSD window.
7

To close the REVISE window：
(1) Tap ”ESC” key.
(2) Complete the USER NAME/ PASSWORD/ VERIFY setup.
【Note】(1) Default user name and password is “00000000”.
(2) Available keys for user name and passwords are 0 ~ 9, a ~ z（no
capital difference）
(3) Press 【Enter】three times，to set up user name &password as
none.
8

5. CONSOLE Status
R E M O T C O N S O L E
H O T K E Y n u m
L O C A L C O N S O L E
H O T K E Y n u m
(1) First row shows remote console/local console status.
(2) Second row shows hotkey mode (e.g. The hotkey user selected now
is 【Num Lock】key)
To bring up REMOT/LOCAL CONSOLE window：
(1) After complete SECURITY OSD window
(2) Change remote/local console mode
(3) Press mouse left-button, then press【ESC】key.
To close REMOT CONSOLE window：
(1) Press any key on your keyboard.
(2) Press any button on your mouse.
6. Local PC-port and Remote PC-port switch
Press “optional hotkey” twice then press letter【C】
7. Buzzer control (audio on/off mode)
Press “optional hotkey” twice then press letter【B】
8. Scan PC port
(Scan Local port and Remote port VGA every 8 seconds)
Press “optional hotkey” twice then press letter【S】
9

Troubleshooting
1. No video signal is displayed on the monitor.
1.1 Please check if VGA cable and Cat.5 cable are properly connected to
the connectors respectively.
1.2 Make sure VGA cable is attached to computer during the boot-up
process.
1.3 Make sure power adapter is connected to the receiver.
2. Video signal is foggy or un-cleared on the screen.
2.1 Please check if the VGA cable is properly connected. Sometimes
reconnect the cable may solve this problem.
2.2 It is highly recommended to use Cat.5e cable when the connection is
shorter than 150 meters, and to use Cat.6 cable when the connection
is between 150 and 300 meters.
Specifications
Keyboard port USB
Mouse port USB
VGA monitor port 1
RJ-45 port 1
RJ-45 port connector 8P8C
Local console port
connector VGA blue HDDB 15 pin, 3 to 1 cable to connect to PC
LED Console port or PC port was
selected
VGA tuning Auto Adjusting
Power adapter DC 9V, 500mA
Weight (g) 360g
Dimension (mm) 160*72*27mm
Resolution 1680 * 1050 (150m)
1280 * 1024 (300m)
10

Certification
CE – Certificate
This equipment is in compliance with the requirements of the following
regulations: EN 55 022: CLASS A
FCC
This equipment has been tested and found to comply with Part 15 of the FCC
Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference
(2)This device must accept any interference received.
Including interference that may cause undesired operation.
