LevelOne HVE-9002 User manual

HDSpider™ HDMI Cat.5 Sender
+ 1 HDMI Out
HVE-9002
Digital Data Communications GmbH.
Zeche-Norm St. 25, 44319, Dortmund, Germany
All mentioned brand names are registered trademarks and property of their owners.
Technical specifications are subject to change without notice.
© 2008 All Rights Reserved
www.level1.com
What is HDMI?
The High-Definition Multimedia Interface (HDMI) is a
revolutionary technology that allows viewers to
experience the highest quality digital images available. It
is able to deliver top-quality video as well as audio over a
single cable.
Introducing the HDSpider™Series from LevelOne
The HDSpider™Series is a collection of HDMI Cat.5 senders
and receivers, offering a full range of HDMI extender
solutions. Choose from our 5 different HDSpider extenders
to build a flexible network to send your high-quality HDMI
signals to greater distances, and at a reduced cost.
What does a Cat.5 sender + 1 HDMI Out do?
This compact device is deployed at the HD source,
generally connected to an HD player, PS3, or Xbox 360.
HVE-9002 accepts the HD signal from the HDMI source and
then uses Cat.5 cable to send the HDMI signal to the
receiver. This allows for a cost-effective long range HDMI
solution, up to 60 meters with Cat.5 cable as the signal
carrier. HVE-9002 also includes a local HDMI port which
allows for an additional monitor to be placed next to the
device. This is especially useful for deploying an HDMI
network that has requires many different displays in one
area. HVE-9002 also supports full 1080p resolution and has
an audio out port.
Surround sound: HVE-9002 also supports 7.1 multichannel
stereo surround sound, providing an easy way to extend
the high-quality video of HDMI with the superior 7.1
capabilities of Dolby Digital Plus.
To see this device in action, please see the diagram
below.
Related Products
HDSpider™HDMI Cat.5 Receiver
(Long)
HVE-9000
HDSpider™HDMI Cat.5
Sender (Cascadable)
HVE-9003
Installation Diagram

HDSpider™ HDMI Cat.5 Sender
+ 1 HDMI Out
HVE-9002
Digital Data Communications GmbH.
Zeche-Norm St. 25, 44319, Dortmund, Germany
All mentioned brand names are registered trademarks and property of their owners.
Technical specifications are subject to change without notice.
© 2008 All Rights Reserved
www.level1.com
Technical Specifications
Model
HVE-9000
HVE-9001
Description
HDSpider™HDMI Cat.5
Receiver (Long)
HDSpider™HDMI Cat.5
Sender
Video Bandwidth
1.65Gbps
1.65Gbps
Input
1x RJ-45
1x HDMI
Output
1x HDMI
1x RJ-45
Cascading
-
-
Resolution
1080i/ 1080p@60m/40m
1080i/ 1080p@60m/40m
Audio
-
-
Power
5V/2Am
5V/2Am
Dimensions
87x60x25 (mm)
87x60x25 (mm)
Weight
160g
160g
Model
HVE-9002
HVE-9003
HVE-9900
Description
HDSpider™HDMI Cat.5
Sender + 1 HDMI Out
HDSpider™HDMI Cat.5
Sender (Cascadable)
HDSpider™ HDMI Cat.5
Receiver (Short)
Video Bandwidth
1.65Gbps
1.65Gbps
1.65Gbps
Input
1x HDMI
1x RJ-45
1x RJ-45
Output
1x HDMI & 1x RJ-45
1x 3.5mm audio socket
1x HDMI & 1x RJ-45
1x 3.5mm audio socket
1x HDMI
Cascading
-
∞
-
Resolution
1080i/ 1080p@60m/40m
1080i/ 1080p@60m/40m
1080i/1080p@25m/15m
Audio
7.1-Ch
7.1-Ch
-
Power
5V/4Am
5V/4Am
-
Dimensions
180x108x27 (mm)
180x108x27 (mm)
45x25X20 (mm)
Weight
430g
430g
25g
Package Contents
[1] HVE-9002
[1] Power Adapter
[1] User Manual
Ordering Information
HVE-9002, HDSpider™HDMI Cat.5 Sender + 1 HDMI Out
