Leviton VSIND User manual

DESCRIPTION
The Leviton Indoor video monitoring camera uses a single Cat 5e cable to distribute both power and video between the camera and Leviton Structured Media™ Center.
INSTALLATION
Install with a single gang low voltage ring for new construction or a single gang low voltage ring for retrofit installations at each of the camera locations.
NOTE: For retrofit installations you may need to install a surface mount box when installing the camera to a wall or ceiling location.
WIRING:
To prewire for the Indoor Camera, simply run a single Cat 5e UTP
cable from the SMC to each camera location desired.
NOTE: If your cable run length to the camera exceeds 100
meters (328ft) you should power your camera locally. Install a two
conductor (minimum 16 ga.) cable in addition to your Cat 5e cable
to provide enough current for the camera.
INSTALLING THE INDOOR CAMERA:
•Strip back your Cat 5e cable and terminate to camera using
one of the following methods:. Punch it onto the camera
board following your preferred termination method.
a) Terminate the camera Cat 5e cable directly onto the
camera board using the 110 IDC termination block provided.
Fan out your Cat 5e cable and follow the color code
indicated in Figure 2. Punch down your Cat 5e cable using
a 110 punch tool.
b)
Terminate a Cat 5e jack 5G108-R*5 (sold separately) to
your cable (use T568A color codes - Figure 3), then use
a short Cat 5e patch cord from the jack to the RJ-45 on the
camera board to complete the connection (Figure 4).
•Set Dip Switch to termination method used (Figure 1):
a) IDC (*Leviton recommended) b) RJ-45
c) LOCAL
NOTE: Local is only used if powering your camera locally
for test purposes.
•Set the camera or cameras that exceed the maximum 100 meter limit into your box and
align the mounting strap with the screw slots on your gang box or low voltage ring.
• After you have secured the mounting strap to the box using the provided screws you can
adjust the camera viewing angle by pivoting the mounting strap up or down, left or right,
within certain limits, to the desired location.
• Using a small flat blade screwdriver slide it into the positioning slot and bend strap
according to the desired viewing angle.
• Once camera is positioned insert black felt over the lens. Next choose
a clear or tinted lens cover and snap it onto strap in designated slots
locations. Please note that the black felt is not necessary when using the
tinted lens cover.
• Finally install your single gang wall plate to the single gang box or low
voltage ring.
LED: There is a green Led that will light when power is applied to the
connector indicated by the slide switch.
RCA Jack: There is an RCA jack accessible from the back of the camera that
can be used for testing purposes.
POWERING YOUR CAMERA:
Powering Remotely with Camera Hub (Cat. No. VSHUB):
If your camera Cat 5e cable is 100 Meters (328ft) or less, your camera
can be powered over the Cat 5e from the Camera Hub located inside
your Structured Media System. A power jack on the Camera Hub requires
12VDC power from either the power supply provided with the Camera Hub
board or one of the power supplies listed on the next page:
Indoor Camera
Installation Instructions
DI-000-VSIND-00A VSIND
59-25 Little Neck Parkway.
Little Neck, N.Y. 11362-2591, USA
Tech Support: 800-824-3005
www.leviton.com
Figure 4
LED
BL OR BRGR
Cat # VSIND/VSOUT
Assembled in Mexico
www.leviton.com
RCA
IDC
local
RJ45
Camera Board
RJ45 Jack
inserts here
Cat 5e
Patch Cord
Cat 5e Jack
5G108-R*5
(to Voice and Data Board)
Package Contents:
Camera Unit (1)
Felt Pad (1)
Lenses - Smoked Glass (1) and Clear (1)
Power Adapter (1) with screws
LED
BL OR BRGR
IN
OUT
Cat # VSIND/VSOUT
Assembled in Mexico
www.leviton.com
RCA
local RJ-45 IDC
RJ45
Power/Video
LED
BL OR BRGR
IN
OUT
Cat # VSIND/VSOUT
Assembled in Mexico
www.leviton.com
RCA
IDC local RJ45
IDC
Power/Video
LED
BL OR BRGR
IN
OUT
Cat # VSIND/VSOUT
Assembled in Mexico
www.leviton.com
RCA
local RJ45 IDC
Local Power
Video over
IDC/RJ45
RJ45 jack
inserts here
a) b)
*Recommended for Indoor Camera
c)
Figure 1 – Dip Switch Settings
White/Green
Green
White/Orange
Orange
Blue
White/Blue
White/Brown
Brown
Figure 2
White/Blue 5
White/Orange 3
Green 2
PIN #
White/Green 1
PIN #
6 Orange
4 Blue
7 White/Brown
8 Brown
Figure 3

Leviton Compatible Power Supplies:
NOTE: Each Indoor Camera in no light conditions draws as much as 220 mA from the Camera Hub. Each
Indoor Camera draws about 110 mA from the Camera Hub. Make sure the sum of the currents from all
devices powered by the power supply in the SMC does not exceed the maximum output of that power supply.
• 47605-PSA (Maximum output: 12VDC at 3000 mA)
• 47605-PSB (Maximum output: 12VDC at 750 mA)
• 48212-DCS (Maximum output: 12VDC at 1500 mA)
NOTE: The Camera Hub board regulates and raises the voltage of the 12VDC input to 15VDC before sending
it over the Cat 5e to the camera. Power is sent over 3 pairs of Cat 5e conductors to reduce the resistance
loss in the cable. A regulator circuit at the camera reduces the voltage back to 12VDC to power the camera
engine.
One pair of the Cat 5e is a balanced video signal from the camera to the SMC Camera Hub.
IMPORTANT INSTRUCTIONS
1. Read and understand all instructions. Follow all warnings and instructions marked on the product.
2. Do not use this product near water—e.g., near a tub, wash basin, kitchen sink or laundry tub, in a wet basement, or
near a swimming pool.
3. Never push objects of any kind into this product through openings, as they may touch dangerous voltages.
4. SAVE THESE INSTRUCTIONS.
SAFETY INFORMATION
1. Never install communications wiring or components during a lightning storm.
2. Never install communications components in wet locations unless the components are designed specifically for use
in wet locations.
3. Never touch uninsulated wires or terminals unless the wiring has been disconnected at the network interface.
4. Use caution when installing or modifying communications wiring or components.
5. To prevent electrical shock, each opening must be filled with a module.
LIMITED 2 YEAR WARRANTY AND EXCLUSIONS
Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that this product at
the time of its sale by Leviton is free of defects in materials and workmanship under normal and proper use for
two years from the purchase date. Leviton’s only obligation is to correct such defects by repair or replacement,
at its option, if within such two year period the product is returned prepaid, with proof of purchase date, and
a description of the problem to Leviton Manufacturing Co., Inc., Att: Quality Assurance Department, 59-25
Little Neck Parkway, Little Neck, New York 11362-2591. This warranty excludes and there is disclaimed liability
for labor for removal of this product or reinstallation. This warranty is void if this product is installed improperly
or in an improper environment, overloaded, misused, opened, abused, or altered in any manner, or is not used
under normal operating conditions or not in accordance with any labels or instructions. There are no other or
implied warranties of any kind, including merchantability and fitness for a particular purpose, but if any
implied warranty is required by the applicable jurisdiction, the duration of any such implied warranty, including
merchantability and fitness for a particular purpose, is limited to two years. Leviton is not liable for incidental,
indirect, special, or consequential damages, including without limitation, damage to, or loss of use of,
any equipment, lost sales or profits or delay or failure to perform this warranty obligation. The remedies
provided herein are the exclusive remedies under this warranty, whether based on contract, tort or otherwise.
For Technical Assistance Call:
1-800-824-3005 (U.S.A. Only)
www.leviton.com DI-000-VSIND-00A
TROUBLESHOOTING:
No Video from camera RCA?
• Ensure camera board and Camera Hub board are powered Green LED should be lit on each board.
• Plug RCA cable into monitor and set to composite video signal.
No Video at Camera Hub board?
• Verify all RJ-45 plugs are wired T568-A
Out of Focus (Indoor Camera with adjustable lens only)
• Remove wallplate cover and rotate lens until TV picture is clearRemove wallplate cover and rotate lens until TV
picture is clear
IN
OUT
IN
OUT
IN
OUT
IN
OUT
To Modulator, Sequencer,
IP Quad or direct to TV monitor
Cat 5e
Patch Cord
Camera Hub
Voice and Data
Module
47605-C5
Power Jack
Center Conductor
is +12 VDC
Note: All UTP
Terminations
based on T568A
Composite
RCA
Cables to
device
Indoor Camera or
Outdoor Camera
Figure 5
CONNECTING YOUR Cat 5e CAMERA CABLE IN THE SMC (Figure 5):
•Mount the Camera Hub board (Cat. No. VSHUB) onto a Leviton plastic mounting bracket.
•Terminate the Cat 5e Camera cable in the SMC to an open port on a Leviton Voice and Data board (Cat. No.
47605-C5 - sold separately).
•Next connect a Cat 5e patch cable from the Voice and Data board to one of the 4 ports on the Camera Hub
board (Cat. No. VSHUB).
NOTE: Leviton recommends terminating Cat 5e camera cables to the 110 IDC block on a Voice and Data
Board for long term reliability and to avoid wiring mistakes (Figure 2).
Signal Connections (T568A)
Wire Color
White/Green
Green
White/Orange
Blue
White/Blue
Orange
White/Brown
Brown
Signal
Power
Ground
Video Signal
Ground
Power
Video Signal Ground (-)
Power
Ground
Camera Parameter Value
Pick up device 1/3” CCD
Picture Elements H*V NTSC 510*492
Camera Resolution 420 lines
Lens 3.6 mm
Sensitivity 0.05 Lux
S/N Ratio > 48 dB (AGC off)
White Balance Auto
Video Out 1Vpp, 75 Ohm
Auto Gain control Auto
Camera Assembly Power Requirements Value
Input Voltage +15V DC +/- 10%.
Current Consumption 100 mA +/- 10%.
Power Consumption < 2W max.
CAMERA SPECIFICATIONS:
