Scan to RightFax
Administrator's Guide
October 2013 www.lexmark.com

Contents
Overview.....................................................................................................3
Configuring Scan to RightFax........................................................................4
Configuring RightFax settings....................................................................................................................4
Adding or editing a profile.........................................................................................................................4
Customizing the application icon..............................................................................................................4
Using Scan to RightFax.................................................................................5
Sending a document automatically...........................................................................................................5
Sending a document manually..................................................................................................................5
Troubleshooting...........................................................................................6
An application error has occurred.............................................................................................................6
Application cannot authenticate user.......................................................................................................6
Application cannot connect to RightFax server.........................................................................................7
An error appears when sending a fax with large attachments.................................................................7
License error..............................................................................................................................................8
Appendix.....................................................................................................9
Notices.......................................................................................................10
Index..........................................................................................................11
Contents 2

Overview
Scan to RightFax lets you easily scan a document and then send it to Web sites housed on RightFax servers using a fax
number.
This application enables users to do the following tasks:
•Create Scan to RightFax destinations.
•Select fax job parameters.
•Send fax destinations manually.
•Send a fax job directly to the RightFax server.
•Receive an e‑mail or print notification when a job completes.
Overview 3

Configuring Scan to RightFax
For the Scan to RightFax integration to work properly, make sure that the following are set up, licensed, and configured
properly:
•OpenText RightFax
For more information, see the standard OpenText RightFax documentations or contact the OpenText technical
support at [e-mail].
Note: Make sure you are using the OpenText RightFax versions 9.4, 10.0, and 10.5 to run the application
properly.
•OpenText RightFax Advanced Web Services
For more information, see the OpenText installation and administration documentations.
Notes:
–For consultation services on certain deployment scenarios, contact the OpenText RightFax Professional
Services.
–For information on ordering and pricing, contact the OpenText Information Exchange Professional Services
at ix‑[e-mail]
Configuring RightFax settings
1From the Embedded Web Server, access the configuration page for the application.
2In the RightFax Server Information section, type the IP address of the RightFax server.
3If necessary, modify the settings for sending the fax manually.
4Save your settings.
Adding or editing a profile
1From the Embedded Web Server, access the configuration page for the application.
2From the Configure, Profile, or Profiles page, add or edit a profile.
3In the RightFax Settings section, assign a fax name and fax number.
4Configure the user authentication settings and scan settings.
5Save your changes.
Customizing the application icon
1From the Embedded Web Server, access the configuration page for the application.
2Specify the text and image that you want to appear on your home screen.
Note: Some applications require you to change the settings from the profile page.
3Save your changes.
Configuring Scan to RightFax 4

Using Scan to RightFax
After the application is installed, RightFax users can use additional scan features on the printer when scanning to a
RightFax server. Within each profile, the prompts that users will see are determined by settings configured by the
administrator. Therefore, users may not see all of the prompts described here.
Sending a document automatically
1Load an original document into the ADF tray or on the scanner glass.
Note: For information on the proper loading of documents, see the printer User's Guide.
2Touch the application icon.
3Select a profile, and then touch Fax.
4If necessary, adjust the settings, and then send the document.
Sending a document manually
1Load an original document into the ADF tray or on the scanner glass.
Note: For information on the proper loading of documents, see the printer User's Guide.
2Touch the application icon.
3Touch Manual.
4Enter the recipient fax number, and then send the document.
Using Scan to RightFax 5

Troubleshooting
An application error has occurred
Try one or more of the following:
CHECK THE SYSTEM LOG
1Open a Web browser, and then type the printer IP address.
Note: View the IP address in the TCP/IP section of the Network/Ports menu.
2Click Settings or Configuration.
3Depending on your printer model, do one of the following:
•Click Apps > Apps Management.
•Click Device Solutions > Solutions (eSF).
•Click Embedded Solutions.
4Click System > Log.
5Generate the log entries of the application.
ADJUST THE SCAN SETTINGS
1From the Embedded Web Server, access the configuration page for the application.
2From the scanning options, select a lower scan resolution.
3Save your changes.
CONTACT YOUR SOLUTIONS PROVIDER
If you still cannot isolate the problem, then contact your solutions provider.
Application cannot authenticate user
Try one or more of the following.
CHECK THE APPLICATION SETTINGS
Make sure that the application settings match the settings for the RightFax server. For more information, see
“Configuring Scan to RightFax” on page 4.
MAKE SURE TO SPECIFY THE CORRECT USER NAME AND PASSWORD
If the application is configured to use RightFax credentials to authenticate users, then make sure to type the correct
user name and password combination from the configuration page for your application.
Troubleshooting 6

CONTACT YOUR SOLUTIONS PROVIDER
If you still cannot isolate the problem, then contact your solutions provider.
Application cannot connect to RightFax server
Try one or more of the following:
CHECK THE APPLICATION SETTINGS
Make sure that the application settings match the settings for the RightFax server. For more information, see
“Configuring RightFax settings” on page 4.
MAKE SURE THAT THE PRINTER IS CONNECTED TO THE NETWORK
Make sure that all appropriate network cables are securely connected and the network settings of the printer are
correctly configured. For information on networking the printer, see the printer User's Guide.
CHECK THE SYSTEM LOG
1Open a Web browser, and then type the printer IP address.
Note: View the IP address in the TCP/IP section of the Network/Ports menu.
2Click Settings or Configuration.
3Depending on your printer model, do one of the following:
•Click Apps > Apps Management.
•Click Device Solutions > Solutions (eSF).
•Click Embedded Solutions.
4Click System > Log.
5Generate the log entries of the application.
An error appears when sending a fax with large attachments
Try one or more of the following:
INCREASE THE BUFFER SIZE ON THE RIGHTFAX WEB SERVICE SETTINGS
1Open the RightFax configuration file.
Note: The configuration file can be found in the folder where the RightFax Web service is installed.
2From the basicHTTPBinding section of the script, increase the buffer sizes.
3Save the configuration file.
4Restart the RightFax Web service.
For more information on configuring the RightFax Web service settings, contact the RightFax representative.
Troubleshooting 7

DELETE THE IMAGE FILES ASSOCIATED WITH THE FAXES FROM THE WINDOWS TEMP FOLDER
WHERE THE RIGHTFAX SERVER IS INSTALLED AND RUNNING.
Make sure to have at least 10GB of free space in the drive where the RightFax server is installed so that the server
does not run out of space when storing the images.
License error
Try one or more of the following:
MAKE SURE THAT THE APPLICATION IS LICENSED
For more information on purchasing a license, contact your Lexmark representative.
MAKE SURE THAT THE LICENSE IS UP‑TO‑DATE
1Open a Web browser, and then type the printer IP address.
Note: View the printer IP address in the TCP/IP section of the Network/Ports menu.
2Click Settings or Configuration.
3Depending on your printer model, do one of the following:
•Click Apps > Apps Management.
•Click Device Solutions > Solutions (eSF).
•Click Embedded Solutions.
4Click the license status of the application from the list.
5Update the license.
Troubleshooting 8

Appendix
Accessing the configuration page for the application using the
Embedded Web Server
1Open a Web browser, and then type the printer IP address.
Note: View the IP address in the TCP/IP section of the Network/Ports menu.
2Click Settings or Configuration.
3Depending on your printer model, do one of the following:
•Click Apps > Apps Management.
•Click Device Solutions > Solutions (eSF).
•Click Embedded Solutions.
4Select the application from the list, and then click Configure.
Licensing applications
Applications require a valid electronic license to run on select printers.
For more information on purchasing a license for an application, or for any other licensing information, contact your
Lexmark representative.
Checking the version of the Embedded Solutions Framework
1From the Embedded Web Server, click Reports > Device Settings.
2In the Embedded Solutions section, note the value associated with “Framework =.”
Note: To view the complete list of supported printers for each version of the Embedded Solutions Framework, see
the Readme file.
Appendix 9
