Panasonic KX-FLM652CX User manual

© 2005 Panasonic Communications Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
KX-FLM652CX
(for Asia and Middle Near East)
Multi-Function Laser Fax
ORDER NO. KMF0512917CE

1 INTRODUCTION 4
1.1. ABOUT LEAD FREE SOLDER (PbF: Pb free) 4
1.2. SAFETY PRECAUTIONS 5
1.3. INSULATION RESISTANCE TEST 5
1.4. FOR SERVICE TECHNICIANS 5
1.5. BATTERY CAUTION 5
1.6. AC CAUTION 6
1.7. PERSONAL SAFETY PRECAUTIONS 6
1.8. SERVICE PRECAUTIONS 8
2 FEATURES AND SPECIFICATIONS 9
2.1. FEATURES 9
2.2. SPECIFICATIONS 10
2.3. OPTIONAL ACCESSORIES 10
3 INSTALLATION 11
3.1. LOCATION OF CONTROLS 11
3.2. CONNECTIONS 14
3.3. CONNECTING TO A COMPUTER 15
3.4. INSTALLATION 16
3.5. INSTALLING MULTI-FUNCTION STATION 29
4 MAINTENANCE 30
4.1. MAINTENANCE ITEMS AND COMPONENT LOCATIONS
30
4.2. PRINTING 32
4.3. PRINTING (PAPER PICK UP) 33
4.4. SCANNING (ADF) 34
4.5. MAINTENANCE 35
4.6. DOCUMENT JAMS 38
4.7. RECORDING PAPER JAMS 39
5 DISASSEMBLY INSTRUCTIONS 44
5.1. UPPER MAIN CABINET SECTION 45
5.2. LOWER MAIN CABINET SECTION 46
5.3. HOW TO REMOVE THE OPERATION PANEL ASS’Y 47
5.4. HOW TO REMOVE THE PICK UP UNIT 48
5.5. HOW TO REMOVE THE PICK UP ROLLER 49
5.6. HOW TO REMOVE THE OPERATION BOARD 50
5.7. HOW TO REMOVE THE LOWER FRAME 51
5.8. HOW TO REMOVE THE SEPARATION RUBBER 51
5.9. HOW TO REMOVE THE TRANSFER ROLLER 52
5.10. HOW TO REMOVE THE SEPARATION ROLLER 53
5.11. HOW TO REMOVE THE BOTTOM PLATE 54
5.12. HOW TO REMOVE THE ANALOG BOARD 54
5.13. HOW TO REMOVE THE HIGH VOLTAGE POWER
BOARD 55
5.14. HOW TO REMOVE THE LASER UNIT 55
5.15. HOW TO REMOVE THE FAN UNIT 56
5.16. HOW TO REMOVE THE LOW VOLTAGE POWER
BOARD 56
5.17. HOW TO REMOVE THE SOLENOID 57
5.18. HOW TO REMOVE THE HANDSET HOLDER 57
5.19. HOW TO REMOVE THE MAIN MOTOR 58
5.20. HOW TO REMOVE THE FUSER UNIT 59
5.21. HOW TO REMOVE THE CIS 60
5.22. NOTE FOR ASSEMBLING 61
5.23. INSTALLATION POSITION OF THE LEAD 62
6 TROUBLESHOOTING GUIDE 63
6.1. USER RECOVERABLE ERRORS 63
6.2. PROGRAMMING AND LISTS 65
6.3. TEST FUNCTIONS 69
6.4. PROBLEMS WITH PC SOFTWARE 73
6.5. REMOTE PROGRAMMING 74
6.6. TROUBLESHOOTING DETAILS 84
7 CIRCUIT OPERATIONS 155
7.1. CONNECTION DIAGRAM 155
7.2. GENERAL BLOCK DIAGRAM 156
7.3. FACSIMILE SECTION 159
7.4. NCU SECTION 172
7.5. ITS (Integrated telephone System) and MONITOR
SECTION 173
7.6. CIS CONTROL SECTION 175
7.7. STEPPING MOTOR DRIVE SECTION 176
7.8. FAN MOTOR SECTION 180
7.9. SOLENOID DRIVE SECTION 182
7.10. LSU (Laser Scanning Unit) SECTION 183
7.11. SENSORS AND SWITCHES SECTION 185
7.12. OPERATION BOARD SECTION 194
7.13. LCD SECTION 195
7.14. HVPS (High Voltage Power Supply) SECTION 196
7.15. HEAT LAMP CONTROL CIRCUIT 198
7.16. POWER SUPPLY BOARD SECTION 204
8 REFERENCE MATERIALS DATA 205
8.1. PRINTING OPERATION PRINCIPLE 205
8.2. TERMINAL GUIDE OF THE ICs TRANSISTORS AND
DIODES 215
8.3. HOW TO REPLACE A FLAT PACKAGE IC 219
8.4. DIGITAL BOARD SECTION 220
8.5. MODEM SECTION 222
8.6. TEST CHART 228
9 FIXTURES AND TOOLS 230
10 CABINET, MECHANICAL AND ELECTRICAL PARTS
LOCATION 231
10.1. GENERAL SECTION 231
10.2. OPERATION COVER SECTION (1) 232
10.3. OPERATION COVER SECTION (2) 233
10.4. OPERATION COVER SECTION (3) 234
10.5. PICK UP SECTION 235
10.6. FUSER SECTION 236
10.7. UPPER MAIN CABINET SECTION 237
10.8. LOWER MAIN CABINET SECTION (1) 238
10.9. LOWER MAIN CABINET SECTION (2) 239
10.10. LOWER MAIN CABINET SECTION (3) 240
10.11. ACTUAL SIZE OF SCREWS AND WASHER 241
11 ACCESSORIES AND PACKING MATERIALS 242
CONTENTS
Page Page
2
KX-FLM652CX

12 REPLACEMENT PARTS LIST 243
12.1. CABINET AND ELECTRICAL PARTS 243
12.2. ACCESSORIES AND PACKING MATERIALS 245
12.3. DIGITAL BOARD PARTS 245
12.4. ANALOG BOARD PARTS 249
12.5. OPERATION BOARD PARTS 251
12.6. MOTOR DRIVER BOARD 252
12.7. HIGH VOLTAGE POWER SUPPLY BOARD PARTS 252
12.8. LOW VOLTAGE POWER SUPPLY BOARD PARTS 253
12.9. EXIT SENSOR BOARD PARTS 254
12.10. DRUM AND TONER SENSOR BOARD PARTS 254
12.11. VARISTOR BOARD PARTS 254
12.12. FIXTURES AND TOOLS 254
12.13. OPTIONS 254
13 FOR THE SCHEMATIC DIAGRAMS 255
14 SCHEMATIC DIAGRAM 256
14.1. DIGITAL BOARD (1) (PCB1) 256
14.2. DIGITAL BOARD (2) (PCB1) 258
14.3. DIGITAL BOARD (3) (PCB1) 260
14.4. ANALOG BOARD (PCB2) 262
15 SCHEMATIC DIAGRAM 264
15.1. OPERATION BOARD (PCB3) 264
15.2. MOTOR DRIVER BOARD (PCB4) 266
15.3. HIGH VOLTAGE POWER SUPPLY BOARD (PCB5) 267
15.4. LOW VOLTAGE POWER SUPPLY BOARD (PCB6) 268
15.5. EXIT SENSOR BOARD (PCB7) 269
15.6. DRUM AND TONER SENSOR BOARD (PCB8) 269
15.7. VARISTOR BOARD (PCB9) 269
15.8. MEMO 270
16 PRINTED CIRCUIT BOARD 271
16.1. DIGITAL BOARD (PCB1) 271
16.2. ANALOG BOARD (PCB2) 273
16.3. OPERATION BOARD (PCB3) 275
17 PRINTED CIRCUIT BOARD 277
17.1. MORTOR DRIVER BOARD (PCB4) 277
17.2. HIGH VOLTAGE POWER SUPPLY BOARD (PCB5) 279
17.3. LOW VOLTAGE POWER SUPPLY BOARD (PCB6) 281
17.4. EXIT SENSOR BOARD PARTS (PCB7) 283
17.5. DRUM AND TONER SENSOR BOARD (PCB8) 284
17.6. VARISTOR BOARD (PCB9) 285
3
KX-FLM652CX

1 INTRODUCTION
1.1. ABOUT LEAD FREE SOLDER (PbF: Pb free)
Note:
In the information below, Pb, the symbol for lead in the periodic table of elements, will refer to standard solder or solder that
contains lead.
We will use PbF solder when discussing the lead free solder used in our manufacturing process which is made from Tin, (Sn),
Silver, (Ag), and Copper, (Cu).
This model, and others like it, manufactured using lead free solder will have PbF stamped on the PCB. For service and repair
work we suggest using the same type of solder although, with some precautions, standard Pb solder can also be used.
Caution
• • •
• PbF solder has a melting point that is 50° ~ 70° F, (30° ~ 40°C) higher than Pb solder. Please use a soldering iron with
temperature control and adjust it to 700° ± 20° F, (370° ± 10°C). In case of using high temperature soldering iron, please
be careful not to heat too long.
• • •
• PbF solder will tend to splash if it is heated much higher than its melting point, approximately 1100°F, (600°C).
• • •
• If you must use Pb solder on a PCB manufactured using PbF solder, remove as much of the original PbF solder as possible
and be sure that any remaining is melted prior to applying the Pb solder.
• • •
• When applying PbF solder to double layered boards, please check the component side for excess which may flow onto the
opposite side (See figure, below).
1.1.1. SUGGESTED PBF SOLDER
There are several types of PbF solder available commercially. While this product is manufactured using Tin, Silver, and Copper,
(Sn+Ag+Cu), you can also use Tin and Copper, (Sn+Cu), or Tin, Zinc, and Bismuth, (Sn+Zn+Bi). Please check the manufac-
turer’s specific instructions for the melting points of their products and any precautions for using their product with other
materials.
The following lead free (PbF) solder wire sizes are recommended for service of this product: 0.3mm, 0.6mm and 1.0mm.
4
KX-FLM652CX

1.2. SAFETY PRECAUTIONS
1.Before servicing, unplug the AC power cord to prevent an electric shock.
2.When replacing parts, use only the manufacturer´s recommended components.
3.Check the condition of the power cord. Replace if wear or damage is evident.
4.After servicing, be sure to restore the lead dress, insulation barriers, insulation papers, shields, etc.
5.Before returning the serviced equipment to the customer, be sure to perform the following insulation resistance test to prevent
the customer from being exposed to shock hazards.
1.3. INSULATION RESISTANCE TEST
1.Unplug the power cord and short the two prongs of the plug with a jumper wire.
2.Turn on the power switch.
3.Measure the resistance value with an ohmmeter between the jumpered AC plug and each exposed metal cabinet part
(screw heads, control shafts, bottom frame, etc.).
Note: Some exposed parts may be isolated from the chassis by design. These will read infinity.
4.If the measurement is outside the specified limits, there is a possibility of a shock hazard.
1.4. FOR SERVICE TECHNICIANS
ICs and LSIs are vulnerable to static electricity.
When repairing, the following precautions will help prevent recurring malfunctions.
1.Cover the plastic part´s boxes with aluminum foil.
2.Ground the soldering irons.
3.Use a conductive mat on the worktable.
4.Do not touch the IC or LSI pins with bare fingers.
1.5. BATTERY CAUTION
CAUTION
Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the
manufacturer. Dispose used batteries according to the manufacturerís instructions:
The lithium battery is a critical component (type No. CR-2032/H9B). Please observe for the proper polarity and exact location
when replacing it and soldering the replacement lithium battery in.
5
KX-FLM652CX

1.6. AC CAUTION
For safety, before closing the lower cabinet, please make sure of the following precautions.
1.The earth lead is fixed with the screw.
2.The AC connector is connected properly.
3.Wind the earth lead around the core 4 times.
4.Wind the earth AC around the core 4 times.
1.7. PERSONAL SAFETY PRECAUTIONS
1.7.1. MOVING SECTIONS OF THE UNIT
Be careful not to let your hair, clothes, fingers, accessories, etc., become caught in any moving sections of the unit.
The moving sections of the unit are the rollers and a gear. There is a separation roller and a document feed roller which are rotated
by the document feed motor. A gear rotates the two rollers. Be careful not to touch them with your hands, especially when the unit
is operating.
6
KX-FLM652CX

1.7.2. LIVE ELECTRICAL SECTIONS
All the electrical sections of the unit supplied with AC power by the AC power cord are live.
Never disassemble the unit for service with the AC power supply plugged in.
CAUTION:
AC voltage is supplied to the primary side of the power supply unit. Therefore, always unplug the AC power cord before
disassembling for service.
1.7.3. LASER BEAM AND FUSER UNIT SECTION
• • •
• The printer of this unit utilizes a laser. Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
• • •
• The fuser unit is inside of the unit and gets hot. Do not touch it when removing the jammed paper or cleaning the lower glass.
7
KX-FLM652CX

1.8. SERVICE PRECAUTIONS
1.8.1. PRECAUTIONS TO PREVENT DAMAGE FROM STATIC ELECTRICITY
Electrical charges accumulate on a person. For instance, clothes rubbing together can damage electric elements or change their
electrical characteristics. In order to prevent static electricity, touch a metallic part that is grounded to release the static electricity.
Never touch the electrical sections such as the power supply unit, etc.
8
KX-FLM652CX

General
• • •
• Help function
Display:
1.BASIC SETTINGS
2.FEATURE LIST
3.DIRECTORY
4.FAX RECEIVING
5.COPIER
6.REPORTS
7.CALLER ID
• • •
• LCD (Liquid Crystal Display) readout
• • •
• TAM (Telephone answering machine) interface
Plain Paper Facsimile Machine
• • •
• Automatic document feeder (20 sheets)
• • •
• Quick scan
• • •
• Resolution: Standard/Fine/Super fine/Photo.
(64 level)
− − −
− STANDARD: For printed or typewritten documents with
normal-sized characters.
− − −
− FINE: For documents with small printing.
− − −
− SUPER FINE: For documents with very small printing.
This setting is effective only when the other party has a
compatible fax machines.
− − −
− PHOTO: For documents containing photographs,
shaded drawing,etc.
• • •
• Broad cast
• • •
• 250-sheet paper capacity (60 g/m2~75g/m
2)
• • •
• Distinctive ring detection.
Integrated Telephone System
• • •
• Monitor speaker
• • •
• Voice muting
• • •
• Redialing function
• • •
• 322-Station telephone directory
• • •
• Caller ID service
This unit is compatible with the Caller ID service offered by
your local telephone company. To use this unit’s Caller ID
features, you must subscribe to Caller ID service.
Important:
− − −
− This unit will only display the caller’s telephone number
and name.
− − −
− This unit will not support future additional telephone
services.
− − −
− Depending on the service of the local telephone
company, the date/time of the call or the caller’s name
may not be displayed.
Make sure the following ring setting is set to 2 or more rings
beforehand.
− − −
− FAX ring setting (feature #210 on P.76)
− − −
− TEL/FAX ring setting (feature #212 on P.76)
Enhanced Copier Function
• • •
• Multi-copy function (up to 99 copies)
• • •
• Enlargement and reduction
• • •
• Collate
• • •
• 64-Level halftone
2 FEATURES AND SPECIFICATIONS
2.1. FEATURES
9
KX-FLM652CX

2.2. SPECIFICATIONS
Applicable Lines: Public Switched Telephone Network
Document Size: Max. 216 mm in width
Max. 600 mm in length
Effective Scanning Width: 208 mm
Effective Printing Width: Letter/Legal : 208mm
A4 : 202mm
Transmission Time*: Approx. 4 s/page (ECM-MMR Memory transmission)**
Scanning Density: Horizontal:
8 pels/mm
Vertical:
3.85 lines/mm -STANDARD
7.7 lines/mm -FINE/PHOTO
15.4 lines/mm -SUPER FINE
Copy Resolution: Up to 600 × 600 dpi
Scanning Resolution: Up to 200 × 400 dpi (Optical)
Up to 9,600 × 9,600 dpi (Interpolated)
Photo Resolution: 64-level
Scanner Type: Contact Image Sensor (CIS)
Printer Type: Laser printer
Data Compression System: Modified Huffman (MH), Modified READ (MR), Modified, Modified READ (MMR)
Modem Speed: 33,600/31,200/28,800/26,400/24,00/21,600/19,200/16,800/14,400/12,000/9,600/7,200/4,
800/2,400 bps; Automatic Fallback
Operating Environment: 10°C—32.5°C, 20—80% RH (Relative Humidity)
Dimensions (H×W×D): 370 mm × 430 mm × 480 mm
Mass (Weight): Approx. 9.4 kg
Power Consumption: Standby: Approx. 9 W
Transmission: Approx. 18 W
Reception: Approx. 290 W
Copy: Approx. 290 W
Maximum: Approx. 950 W (When the fuser lamp turns on)
Power Supply: 220 - 240V AC, 50/60 Hz
Fax Memory Capacity: Approx. 150 pages of memory transmission.
Approx. 170 pages of memory reception.
(Based on ITU-T No. 1 Test Chart in standard resolution.)
Laser diode properties: Laser output: Max. 5 mW
Wave length: 760 nm—800 nm
Emission duration: Continuous
Print Speed: 14 ppm (page per minute)
Printing Resolution: 600 × 600 dpi
Compatible OS: Windows 98/Me/2000/XP
Interface: USB (use only less than 2m shielded USB cable).
* Transmission speed depends upon the contents of the pages, resolution, telephone line conditions and capability of the other
party’s machine.
** Transmission speed is based upon the ITU-T No. 1 Test Chart. (Refer to ITU-T No.1 TEST CHART(P.228).) If the capability of
the other party´s machine is inferior to your unit, the transmission time may be longer.
Note:
• • •
• Any details given in these instructions are subject to change without notice.
• • •
• The pictures and illustrations in these instructions may vary slightly from the actual product.
Design and specifications are subject to change without notice.
2.3. OPTIONAL ACCESSORIES
Model No. Description Specifications
KX-FA83E/A Toner cartridge 1 toner cartridge
KX-FA84E/A Drum unit 1 drum unit
10
KX-FLM652CX

3 INSTALLATION
3.1. LOCATION OF CONTROLS
3.1.1. OVERVIEW
11
KX-FLM652CX

[TONE]
• • •
• To change from pulse to tone temporarily during dialing
when your line has rotary pulse service.
Station keys
• • •
• To use the one-touch dial feature.
[BROADCAST]
• • •
• To send a document to multiple parties.
[MANUAL BROAD]
• • •
• To send a document to multiple parties manually.
[JUNK FAX PROHIBITOR]
• • •
• To use junk fax prohibitor.
[COLLATE]
• • •
• To make a collated copy.
[RESOLUTION]
• • •
• To select a resolution.
[AUTO ANSWER]
• • •
• To turn the auto answer setting ON/OFF.
[SCAN]
• • •
• To scan a document.
• • •
• To store a scanned document into memory, and then
send it.
[REDIAL/PAUSE]
• • •
• To redial the last number dialled. If the line is busy when
you make a phone call using the [MONITOR] button,
the unit will automatically redial the number up to 5
times.
• • •
• To insert a pause during dialling.
[HANDSET MUTE]
• • •
• To mute your voice to the other party during a
conversation. Press again to resume the conversation.
[FLASH]
• • •
• To access special telephone services or for transferring
extension calls.
[MONITOR]
• • •
• To initiate dialling.
[HELP]
• • •
• To print helpful information for quick reference.
[DIRECTORY PROGRAM]
• • •
• To store or edit names and telephone numbers.
[MENU]
• • •
• To initiate or exit programming.
[NAVIGATOR] [VOLUME]
• • •
• To adjust volume.
• • •
• To search for a stored item.
• • •
• To select features or feature settings during
programming.
[CALLER ID PRINT]
• • •
• To print the Caller ID list.
[CALLER ID SEARCH]
• • •
• To view caller information.
3.1.2. CONTROL PANEL
12
KX-FLM652CX

[LOWER] [NAME/TEL NO.]
• • •
• To select stations 12-22 for the one-touch dial feature.
• • •
• To change the display of the caller information.
[STOP]
• • •
• To stop an operation or programming session.
• • •
• To delete a character from names and telephone
numbers.
• • •
• To return to a previous step during operation.
[FAX START] [SET]
• • •
• To start sending or receiving a fax.
• • •
• To store a setting during programming.
[COPY START]
• • •
• To copy a document.
13
KX-FLM652CX

3.2. CONNECTIONS
Caution:
• • •
• When you operate this product, the power outlet should be near the product and easily accessible.
(1) Telephone lene cord
• • •
• Connect to a single telephone line jack.
(2) Power cord
• • •
• Connect to the power outlet (220-240V, 50/60Hz).
(3) [EXT] jack
• • •
• You can connect an answering machine or an extension telephone. Remove the stopper if attached.
(4) Answering machine (not included)
Note:
• • •
• To avoid malfunction, do not position the fax machine near appliances such as TVs or speakers which generate an intense
magnetic field.
• • •
• If any other device is connected to the same telephone line, this unit may disturb the network condition of the device.
• • •
• If you use the unit with a computer and your internet provider instructs you to install a filter (5), please connect it as follows.
14
KX-FLM652CX

3.3. CONNECTING TO A COMPUTER
Panasonic Multi-Function Station software enables the unit to carry out the following functions:
- Printing on plain paper, transparencies, labels and envelopes
- Scanning documents and converting an image into text with Readiris OCR software
- Scanning from other applications for Microsoft®Windows®that support TWAIN scanning
- Storing, editing or erasing items in directories using your computer
- Programming the features using your computer
- Sending, receiving fax documents using your computer
To use Multi-Function Station on your computer, the following are required:
Operating System:
Works with Windows 98/Me/2000/XP*1
CPU:
Windows 98: Pentium®90 MHz or faster
Windows Me: Pentium 150 MHz or faster
Windows 2000: Pentium 166 MHz or faster
Windows XP*1: Pentium 300 MHz or faster
RAM:
Windows 98: 24 MB (32 MB or more recommended)
Windows Me: 32 MB (64 MB or more recommended)
Windows 2000: 64 MB or more
Windows XP*1: 128 MB or more
Other Hardware:
CD-ROM drive
Hard disk drive with at least 100 MB of available space
USB interface
*1 Multi-Function Station software does not work with Windows XP Professional x64 Edition (64bit), a new version of Windows
XP Professional that was released in and after April, 2005.
Important notice for the connection
• • •
• Do not connect the USB cable before installing Multi-Function Station. Be sure to connect the USB cable in step 6 on
P.29.
(1) USB cable
If you need a more than 3m USB cable, Order the extension USB cable
kit by service parts route.
Part No. : PFWAFLB851M
Note:
• • •
• Be sure to use a Hi-Speed USB 2.0 certified cable if your computer is equipped with the Hi-Speed USB 2.0 interface.
Warning:
• • •
• To assure continued emission limit compliance, use only shielded USB cable (2m or less in length).
15
KX-FLM652CX

3.4. INSTALLATION
3.4.1. INSTALLATION SPACE
The space required to install the unit is shown below.
The dimensions given are necessary for the unit to operate efficiently.
Note:
• • •
• Avoid excessive heat or humidity.
• • •
• Use the unit within the following ranges of temperature and humidity.
• • •
• Ambient temperature: 10°C to 32.5°C
• • •
• Relative humidity: 20% to 80% (without condensation)
• • •
• Power cord length should be less than 5 meters. Using a longer cord may reduce the voltage or cause malfunctions.
• • •
• Avoid direct sunlight.
• • •
• Do not install near devices which contain magnets or generate magnetic fields.
• • •
• Do not subject the unit to strong physical shock or vibration.
• • •
• Keep the unit clean. Dust accumulation can prevent the unit from functioning properly.
• • •
• To protect the unit from damage, hold both sides when you move it.
• • •
• Do not place the unit in an area where the paper tray may be obstructed (i.e., by a wall, etc.)
• • •
• Keep this surface ( ) away from walls etc. more than 50 mm to let the unit cool down.
16
KX-FLM652CX

3.4.2. PAPER STACKER
Line up the slots ( ) in the paper stacker with the pegs ( )onthe
bottom of the unit, then insert the two tabs of the paper stacker into the
slots on the unit ( ).
• • •
• The paper stacker can hold up to approximately 100 sheets of
printed paper. Remove the printed paper before the paper stacker
becomes full.
3.4.3. DOCUMENT STACKER
Pull the document stacker ( ) forward gently until it clicks into place,
then press the center part of the document stacker ( ) to open the
document stacker extender ( ).
17
KX-FLM652CX

3.4.4. PAPER TRAY AND PAPER TRAY COVER
1. Insert the paper tray ( ) into the slot ( ) on the back of the unit.
2. Pull the tension plate forward ( ) and attach the paper tray cover ( ),
then push the tension plate back ( ).
Note:
• • •
• Do not place the unit in an area where the paper tray may be
obstructed (i.e., by a wall etc.).
• • •
• Keep this surface ( ) away from walls etc. more than 50 mm (1
31/32") to let the unit cool down.
18
KX-FLM652CX

To remove the paper tray
Pull the paper tray forward in the direction of the arrow.
19
KX-FLM652CX

3.4.5. INSTALLING THE RECORDING PAPER
A4, Letter or legal size recording paper can be used. The unit can hold up to 250 sheets of 60 to 75 g/m2paper, 230 sheets
of 80 g/m2or 200 sheets of 90 g/m2paper. See the note for paper specifications.
• • •
• The unit is set for A4 size paper by default. If you want to use letter or legal size paper, change the setting (feature #380).
1. Before inserting a stack of paper, fan the paper to prevent paper
jams.
2. Pull the tension plate forward ( ).
3. Remove the paper tray cover ( ).
4. Pinch the right side of the recording paper guides ( ), then slide it
open to its full width.
20
KX-FLM652CX
