Lexus LS 500h 2022 User manual

1
LS500h_QG_U
Pictorial Index............................................................................................................................. 3
Floor Mat Installation
Floor Mat Installation.......................................................................................................................11
Hybrid System
Hybrid System.................................................................................................................................. 12
Entering and Exiting
Keys......................................................................................................................................................15
Smart Access System with Push-button Start.................................................................... 17
When Driving
Front Seats......................................................................................................................................... 19
Power Rear Seat............................................................................................................................. 21
Driving Position Memory...........................................................................................................22
Digital Rearview Mirror..............................................................................................................24
Power (Ignition) Switch...............................................................................................................25
EV Drive Mode ..............................................................................................................................27
Hybrid Transmission.....................................................................................................................28
Turn Signal Lever............................................................................................................................ 31
Parking Brake..................................................................................................................................32
Brake Hold .......................................................................................................................................34
Multi-information Display...........................................................................................................35
Head-up Display............................................................................................................................37
Headlight Switch............................................................................................................................39
AHB (Automatic High Beam)..................................................................................................40
Windshield Wipers and Washer.............................................................................................42
Driving Mode Select Switch .....................................................................................................44
Contents
The Quick Guide is not intended as a substitute for your
OWNER’S MANUAL . We strongly encourage you to review
the OWNER’S MANUAL and supplementary manuals so you
will have a better understanding of your vehicle’s capabilities
and limitations.

2
LS500h_QG_U
Driving Comfort
Remote Touch................................................................................................................................ 46
Center Display................................................................................................................................47
Energy Monitor/Consumption Screen...............................................................................50
Navigation System*..................................................................................................................... 53
Hands-free System For Cellular Phone*........................................................................... 56
Audio System*...............................................................................................................................60
Lexus Climate Concierge..........................................................................................................67
Front Automatic Air Conditioning System*.....................................................................68
Rear Automatic Air Conditioning System ..........................................................................72
Voice Command System*.........................................................................................................73
USB/AUX Ports .............................................................................................................................81
Garage Door Opener................................................................................................................ 82
Lexus Enform Safety Connect................................................................................................. 87
Lexus Enform Remote ................................................................................................................89
Lexus Enform Service Connect..............................................................................................89
SiriusXM Satellite Radio............................................................................................................90
Opening and Closing
Door Locks........................................................................................................................................91
Power Windows............................................................................................................................ 92
Moon Roof....................................................................................................................................... 93
Fuel Tank Cap ................................................................................................................................ 94
Trunk................................................................................................................................................... 95
What to do if...
List of Warning/Indicator Lights.............................................................................................98
If the electronic key does not operate properly..............................................................102
If the hybrid system will not start............................................................................................104
* : This feature may be operated by Voice command (See P.73 )

3
LS500h_QG_U
Pictorial Index
■Instrument panel
Power switch.............................................................................................................. P.25
Starting the hybrid system/changing the modes....................................................P.25
Emergency stop of the hybrid system .........................................................................P.27
When the hybrid system will not start........................................................................P.104
Warning messages*
Shift lever ....................................................................................................................P.28
Changing the shift position.............................................................................................. P.28
Precautions for towing*
Meters*
Reading the meters/adjusting the instrument panel light*
Warning lights/indicator lights...................................................................................... P.98
When a warning light turns on*
Multi-information display ...................................................................................... P.35
Display...................................................................................................................................... P.35
Energy monitor..................................................................................................................... P.50
When a warning messages is displayed*
Pictorial Index
A
B
C
D

4
LS500h_QG_U
Parking brake switch...............................................................................................P.32
Applying/releasing the parking brake........................................................................P.32
Precautions for winter season*
Warning buzzer/messages*
Turn signal lever......................................................................................................... P.31
Headlight switch .......................................................................................................P.39
Headlights/parking lights/tail lights/license plate lights/
daytime running lights........................................................................................................P.39
AHB (Automatic High Beam)........................................................................................P.40
Windshield wiper and washer switch .................................................................P.42
Usage........................................................................................................................................P.42
Adding washer fluid*
Warning messages*
Emergency flasher switch*
Hood lock release lever*
Tilt and telescopic steering control switch*
Adjustment*
Driving position memory ..................................................................................................P.22
Air conditioning system..........................................................................................P.68
Usage....................................................................................................................................... P.68
Rear window defogger..................................................................................................... P.68
Audio system..............................................................................................................P.60
Brake hold switch .....................................................................................................P.34
Trunk opener main switch*
*: Refer to the “OWNER’S MANUAL”.
E
F
G
H
I
J
K
L
M
N

5
LS500h_QG_U
■Switches
Vehicle height adjustment switch*
1, 2
EV drive mode switch*
3
......................................................................................... P.27
HUD (Head-up display) switch*
1, 3
.................................................................... P.37
Camera switch*
3, 4
Instrument panel light control switches*
2
“ODO TRIP” switch*
2
VSC OFF switch*
2
Snow mode switch.................................................................................................... P.29
Driving mode select switch ................................................................................... P.44
Trunk opener switch ................................................................................................ P.95
Fuel filler door opener switch............................................................................... P.94
*
1
:Ifequipped
*
2
:Refer to the “OWNER’S MANUAL”.
*
3
:Location of the switches varies according to the vehicle grade level.
*
4
:Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
A
B
C
D
E
F
G
H
I
J

6
LS500h_QG_U
Position memory buttons ....................................................................................... P.22
Mode change button...............................................................................................P.20
Window lock switch ................................................................................................. P.92
Outside rear view mirror switches*
1
Door lock switches.................................................................................................... P.91
Power window switches.......................................................................................... P.92
Rear door sunshade switches*
1, 2
*
1
: Refer to the “OWNER’S MANUAL”.
*
2
:If equipped
A
B
C
D
E
F

7
LS500h_QG_U
Meter control switches .......................................................................................... P.36
Paddle shift switches .......................................................................................P.30, 30
Phone switch.............................................................................................................. P.59
LTA (Lane Tracing Assist) switch*
1
Vehicle-to-vehicle distance switch*
1
Cruise control switches*
1, 2
Advanced Drive (driving assist system) switches*
2, 3
Audio remote control switches............................................................................. P.61
Talk switch .................................................................................................................. P.59
*
1
: Refer to the “OWNER’S MANUAL”.
*
2
:If equipped
*
3
:Refer to “Lexus Teammate Advanced Drive OWNER’S MANUAL” at Lexus.com.
A
B
C
D
E
F
G
H

8
LS500h_QG_U
Remote Touch ........................................................................................................... P.46
Seat switch................................................................................................................... P.19
Heated steering wheel/seat heaters/seat ventilators switch*
2
Rear sunshade switch*
1, 2
Advanced Park (parking assist system) main switch*
1, 2
Vehicle height adjustment switch*
1, 2
P position switch........................................................................................................P.28
*
1
:Ifequipped
*
2
:Refer to the “OWNER’S MANUAL”.
A
B
C
D
E
F

9
LS500h_QG_U
■Interior
SRS airbags*
1
Floor mats ......................................................................................................................P.11
Front seats ................................................................................................................... P.19
Head restraints*
1
Seat belts*
1
Inside lock buttons .................................................................................................... P.91
Console box*
1
Cup holders*
1
Assist grips*
1
Coat hooks*
1
Rear Multi Operation Panel*
1, 2
Rear seat entertainment system*
2, 3
*
1
: Refer to the “OWNER’S MANUAL”.
*
2
:If equipped
*
3
:Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
A
B
C
D
E
F
G
H
I
J
K
L

10
LS500h_QG_U
■Ceiling
Moon roof switches .................................................................................................P.93
Personal lights*
1
“SOS” button ............................................................................................................. P.87
Auxiliary box*
1
Vanity mirrors*
1
Sun visors*
1
Door-linked interior light switch*
1
Inside rear view mirror*
1, 2
Digital Rearview Mirror*
2
....................................................................................P.24
Garage door opener buttons................................................................................P.82
Interior light*
1
*
1
: Refer to the “OWNER’S MANUAL”.
*
2
:If equipped
A
B
C
D
E
F
G
H
I
J

11
LS500h_QG_U
FloorMat Installation
1 Insert the retaining hooks (clips) into
the floor mat eyelets.
2 Turn the upper knob of each retaining
hook (clip) to secure the floor mats in
place.
Always align the marks .
The shape of the retaining hooks (clips) may differ from that shown in the illustration.
Floor Mat Installation
Use only floor mats designed specifically for vehicles of the same model and model year
as your vehicle. Fix them securely in place onto the carpet.
A

12
LS500h_QG_U
Hybrid System
Charge area
Shows regeneration*status.
Regenerated energy will be used to
charge the hybrid battery (traction bat-
tery).
Hybrid Eco area
Shows that gasoline engine power is
not being used very often.
The gasoline engine will automatically
stop and restart under various condi-
tions.
Eco area
Shows that the vehicle is being driven
in an Eco-friendly manner.
By keeping the bar display within Eco
area, more Eco-friendly driving can be
achieved.
Power area
Shows that an Eco-friendly driving
range is being exceeded (during full
power driving etc.)
*: When used in this manual, regeneration
refers to the conversion of energy cre-
ated by the movement of the vehicle into
electrical energy.
Hybrid System
Your vehicle is a hybrid electric vehicle. It has characteristics different from conventional
vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and
operate it with care.
The hybrid system combines the use of a gasoline engine and an electric motor (traction
motor) according to driving conditions, improving fuel efficiency and reducing exhaust
emissions.
For details, refer to the “OWNER’S MANUAL”.
Hybrid System Indicator
A
B
C
D

13
LS500h_QG_U
When driving with the gasoline engine stopped, a sound, which changes in accordance with
the driving speed, will be played in order to warn people nearby of the vehicle’s approach.
The sound will stop when the vehicle speed exceeds approximately 22 mph (35 km/h).
If the shift position is in N, the hybrid battery (traction battery) will not be charged. To help
prevent the battery from discharging, avoid leaving the N position selected for an extended
period of time.
In the following situations, kinetic energy is converted to electric energy and deceleration
force can be obtained in conjunction with the recharging of the hybrid battery (traction bat-
tery).
●The accelerator pedal is released while driving with the shift position in D or M.
●The brake pedal is depressed while driving with the shift position in D or M.
Acoustic Vehicle Alerting System
Hybrid battery (traction battery) charge
Regenerative braking

14
LS500h_QG_U
Because there is no engine sound or vibration, it is easy to mistake the hybrid electric vehi-
cle for being off when it is actually still running, as indicated by the “READY” indicator being
illuminated. For safety, make sure to always shift the shift position to P and apply the parking
brake when parked.
The following sounds or vibrations may occur when the hybrid system is operating and are
not a malfunction:
●Motor sounds may be heard from the engine compartment.
●Relay operating sounds such as a snap or soft clank will be emitted from the hybrid bat-
tery (traction battery), behind the rear seats, when the hybrid system is started or
stopped.
●Sounds may be heard from the hybrid battery (traction battery) behind the rear seats
when the hybrid system starts or stops.
●Sounds from the hybrid system may be heard when the trunk lid is open.
●Sounds may be heard from the transmission when the gasoline engine starts or stops,
when driving at low speeds, or during idling.
●Engine sounds may be heard when accelerating sharply.
●Sounds may be heard due to regenerative braking when the brake pedal is depressed or
as the accelerator pedal is released.
●Vibration may be felt or sounds may be heard when the gasoline engine starts or stops.
●Cooling fan sounds may be heard from the air intake vents on the both sides of the rear
seatback.
When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the
vehicle with at least enough gasoline to make the low fuel level warning light go off. If there is
only a small amount of fuel, the hybrid system may not be able to start. (The standard amount
of fuel is about 3.4 gal. [13 L, 2.8 Imp. gal.], when the vehicle is on a level surface. This value
may vary when the vehicle is on a slope. Add extra fuel when the vehicle is inclined.)
A message is automatically displayed when a malfunction occurs in the hybrid system or an
improper operation is attempted.
If a warning message is shown on the multi-
information display, read the message and
follow the instructions.
Sounds and vibrations specific to a hybrid electric vehicle
Running out of fuel
Hybrid warning message

15
LS500h_QG_U
Entering andExiting
Electronic keys
• Operating the smart access system
with push-button start (P.17)
•Operatingthewireless remote con-
trol function
Mechanical keys
Key number plate
Card key (electronic key) (if equipped)
Operating the smart access system with
push-button start (P.17)
Locks the doors
Unlocks the doors
Opens the windows and moon roof
(press and hold)*
Opens the trunk
Sounds the alarm
*: This setting must be customized at your
Lexus dealer.
Keys
The keys
A
B
C
D
Wireless remote control
A
B
C
D
E

16
LS500h_QG_U
To take out the mechanical key, push the
release button and take the key out.
The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
Mechanical key

17
LS500h_QG_U
1 Grip the driver’s door handle to unlock
the door. Holding the driver’s door
handle for approximately 2 seconds
unlocks all the doors. Grip any passen-
ger door handle to unlock all the
doors.*
Make sure to touch the sensor on the
back of the handle.
The doors cannot be unlocked for 3
seconds after the doors are locked.
*: The door unlock settings can be
changed.
2 Touch the lock sensor (indentation on
the upper part of the door handle) to
lock all the doors.
Check that the door is securely locked.
Smart Access System with Push-button Start
The following operations can be performed simply by carrying the electronic key (includ-
ing the card key) on your person, for example in your pocket. The driver should always
carry the electronic key.
For details on starting the hybrid system, see page 25.
Unlocking and locking the doors from the outside

18
LS500h_QG_U
Press the button.
The trunk lid will fully open.
If the button is pressed while the trunk lid is
opening, the trunk lid will stop moving.
When all the doors are unlocked using one
of the following methods, the trunk can be
opened without the electronic key:
●Entry function
●Wireless remote control
●Door lock switches
●Automatic door unlocking system
●Mechanical key
Opening the trunk
For details on what to do when the electronic key does not operate properly, see page 102.

19
LS500h_QG_U
When Driving
■ Seat adjustment switches
Seat position adjustment
Seatback angle adjustment
Head restraint height adjustment (if
equipped)
Seat cushion (front) angle adjustment
Vertical height adjustment
Lumbar support adjustment
Seat cushion length adjustment (if
equipped)
■ Center Display
1
Press the seat switch.
2 Using the Remote Touch pad, select “Driver Seat Adjustment” or “Passenger Seat
Adjustment”.
Front Seats
Adjustment procedure
A
B
C
D
E
F
G
