LF AquaSource 406208234 User manual

ITEM #0016086
MODEL #406208234
PULL-DOWN KITCHEN
AquaSource® is a registered trademark
of LF, LLC. All Rights Reserved.
Français p. 09
Español p. 17
1
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-417-7564, 8 a.m. - 8 p.m., EST, Monday - Friday, 9 a.m. - 6
p.m., EST, Saturday.
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
FAUCET

PACKAGE CONTENTS
2
PART DESCRIPTION QUANTITY
A Faucet 1
B Outlet pipe 1
C Deck plate 1
D Putty plate 1
E Supply hose - cold 1
F Supply hose - hot 1
G Spary hose 1
H Soap dispenser 1
A
C
D
F
H
G
E
J
I
H
G
F
B

SAFETY INFORMATION
3
PREPARATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product. If you have any questions regarding the product, please call customer service at 1-866-
417-7564, 8 a.m. - 8 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday.
WARNING
• Failure to follow correct installation procedures can cause the faucet to become loose, which can
result in serious injury.
CAUTION
• Follow these installation instructions carefully. Proper installation is the installer’s responsibility.
•Check local building codes before beginning installation to ensure compliance.
• This product should be installed by a locally licensed plumber.
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents above. If any part is missing or damaged, do not
attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 15 minutes
Tools Required for Assembly (not included): Plumber’s putty, Adjustable wrench
Helpful Tools (not included): Groove joint pliers
AA
HARDWARE CONTENTS (shown to size)
BB
CC DD
EE
FF
GG
HH
II
Fixing Nut
Qty. 1
Gasket
Qty. 1
Extra 1
Nut
Qty. 1 Washer
Qty. 1
Seal
Qty. 2
Fixing Clip
Qty. 1
Extra 1
(not shown to size)
Weight
Qty. 1
(not shown to size)
Wrench
Qty. 1
(not shown to size)
Support
Qty. 1
(not shown to size)
JJ
Seal
Qty. 1

4
ASSEMBLY INSTRUCTIONS
1
2
3
2. Attach seal (EE) to the bottom of the faucet (A).
If you will use the deck plate (C), install putty plate
(D) and deck plate (C) on the sink. Install faucet
(A) through top of sink.
Apply plumber’s putty or other sealant to the
bottom edges of the putty plate (D).
3. From underneath sink, attach seal (EE), sup-
port (II), washer (DD) and fixing nut (AA). Tighten
with wrench (HH).
1. Shut off main water supply before installation.
Remove old faucet. Clean sink surface. If your
sink/counter does not already contain holes for
faucet installation, follow sink manufacturer’s
instructions for drilling holes. The faucet mounting
hole should be between 1-7/16 in. to 1-1/2 in. in
diameter.
EE
C
D
EE
AA
HH
A
II
DD
Hardware Used
Hardware Used
EE
AA
DD
II
Seal x 1
Fixing nut x 1
Washer x 1
Support x 1
HH Wrench x 1
EE Seal x 1

5
ASSEMBLY INSTRUCTIONS
DD
6
5
4
5. Place the gasket (BB) inside the nut (CC). Thread in
the nut (CC) to the outlet pipe (B) and tighten with the
wrench (HH). Attach spray hose (G) to the nut (CC).
4. Attach weight (GG) to the spray hose (G). Attach the
weight (GG) to the bottom of the loop on spray hose (G)
with the fixing clip (FF). Trim the remaining part of fixing
clip (FF).
6. Attach supply hose - cold (with blue stripes) (F) to cold
water valve and supply hose - hot (with red stripes) (E) to
hot water valve. Open the water valves and check for
leaks at supply line connection.
GG
G
FF
G
BB
B
HH
E
F
CC
Hardware Used
GG Weight x 1
FF Fixing clip x 1
Hardware Used
BB
CC
HH
Gasket x 1
Nut x 1
Wrench x 1
JJ Seal x 1
JJ

6
ASSEMBLY INSTRUCTIONS
DD
DD
9
8
7
7. Remove spray head from faucet (A) and turn on
water for 30 seconds to remove debris from the lines.
8. Re-assemble spray head. Push the button of the
spray head to alternate the spray between stream and
spray.
9. Insert soap dispenser assembly (H) through
desired mounting hole. From underneath
sink, tighten nut until the escutcheon is firmly held in
place and attach bottle.
H
A
A

LIMITED LIFETIME WARRANTY
7
CARE AND MAINTENANCE
• To maintain and protect the fine luster of your faucet, clean with a soft, damp cloth only.
• Do not use detergent or cleanser that may harm the finish.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Leak from handle. 1. Damaged cartridge. 1. Remove handle.
Replace cartridge.
1. Aerator is dirty or misfitted. 1. Unscrew the aerator to check
rubber packing or replace the
aerator.
If you have any questions regarding the product, please call customer service at 1-866-417-7564,
8 a.m. - 8 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday.
The manufacturer warrants this faucet to be free from defects in workmanship and material present at
time of shipment from the factory for a limited lifetime from the date of purchase. This warranty applies
only to the original purchaser. The manufacturer agrees to correct such defects at no charge or, at our
option, replace the faucet with a comparable or superior model.
To obtain warranty service, call our customer service department at 1-866-417-7564 for return authori-
zation and shipping instructions. You may be required to present a copy of your sales receipt as proof
of purchase. All cost of removal and reinstallation are the expressed responsibility of the purchaser. Any
damage to the faucet by accident, misuse or improper installation, or by affixing accessories not
produced by the manufacturer, are the purchaser's responsibility.
The manufacturer assumes no responsibility whatsoever for faucet installation during the warranty
period. There is no further expressed warranty.
The manufacturer disclaims any and all implied warranties. The manufacturer shall not be liable for inci-
dental, consequential or special damages arising at or in connection with product use or performance
except as may otherwise be accorded by law.
This warranty gives you specific legal rights, and you may also have other rights which vary from state
to state.
This warranty supersedes all prior warranties.
Aerator leaks or has
an inconsistent
water flow pattern.

8
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-417-7564, 8 a.m. - 8 p.m., EST,
Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday.
Printed in Turkey
PART DESCRIPTION PART #
1 Spout 416202018
2 Bearing 410808002
3 Faucet body group 406226105
4 Spray guide 410834005
5 Spray hose 406239003
6 Seal 410803029
7 Seal 110803526
8 Weight 410624020
9 Fixing clip 410832001
10 Hand spray 406238002
11 Spray check valve 402126106
A
O
O
O
O
12 O
OO
OOO
O
O
O
O
19
20
21
10
6
41
3
24
25
21
22
23
27
26
28
2
13 14
15 16 18
17
30
29
7
5
8
9
11
12 Aerator 402133031
13 Check valve 402126008
14 Ceramic cartridge 402135001
15 Fixing nut 410618013
16 Cover 416215046
17 Handle 416212017
18 Screw 112222056
19 Hose guide 410824039
20 Ring 416215047
21 Seal 110803723
22 Support 110824553
23 Washer 110717088
24 Deck plate 416215042
25 Putty plate 410834006
26 Fixing nut 110718402
27 Gasket 110803777
28 Nut 110714275
29 Supply hose - cold 402139001
30 Supply hose - hot 402139002
