LG-Nortel LGP-450A User manual

GSM Fixed Wireless Phone
Please read this manual carefully before operating your set.
Retain it for future reference.
P/NO : MMBBxxxxx
APR/2010/ISSUE xx
L G P - 4 5 0 A U s e r G u i d e

1
Installing the SIM Card and Charging the Battery
Installing the SIM Card
When you subscribe to a cellular network,
you are provided with a plug-in SIM card
loaded with your subscription details, such as
your PIN, any optional services available and
many others.
Important!
▶
The plug-in SIM card and its contacts
can be easily damaged by scratches or
bending, so be careful when handling,
inserting or removing the card. Keep
all SIM cards out of the reach of small
children.
▶
To remove, push the back cover down.
Push the tab with one hand and lift the top
of the battery to separate.
Fully charge
the battery
before using
it for the first
time.
Installing Main Phone
Please follow the procedure below to install the phone properly.
12
34
Connect basehandset to the
handset connector.
Connect the antenna to the
TNC connector (Turn right).
Turn the antenna upright. Connect the AC power
supply.
1234

2
Basic Operation
Turning Your Phone On and Off
1. Hold down the
END/PWR
Dial/Flash
[END/PWR] key until the phone switches on.
2. To switch the phone off, hold down the [END/PWR] key until the power-off image displays.
Making a Call
1. Pick up the handset or press
END/PWR
Dial/Flash
[Speaker Phone] key.
2. Listen for dial tone and enter the phone number.
3. Wait for the Auto Time-out or press [Dial/Flash] key.
4. The call is connected and you may start conversation.
5. To disconnect the call, replace the handset or press
END/PWR
Dial/Flash
[Speaker Phone] key.
Answering a Call
When the bell rings in idle state, you can receive a call as follows:
1. Pick up the handset or press the
END/PWR
Dial/Flash
[Speaker Phone] key.
2. Start a conversation. To disconnect the call, replace the handset or press the [Speaker
Phone] key.
Note After the call ends, the phone will go back to standby mode.
Making an International Call
1. Pick up the handset or press
END/PWR
Dial/Flash
[Speaker Phone] key.
2. Listen for dial tone.
3. Press and hold the
END/PWR
Dial/Flash
key for the international prefix. The '+' character automatically selects
the international access code.
4. Enter the country code, area code, and the phone number.
5. The call is connected and you may start conversation.
6. To disconnect the call, replace the handset or press [Speaker Phone] key.
Redialing Last Number
1. Pick up the handset or press [Speaker Phone] key.
2. Listen for dial tone.
3. Press [Dial/Flash] key.
4. The call is connected and you may start conversation.
5. To disconnect the call, replace the handset or press [Speaker Phone] key.
3-way Call Conferencing
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash

3
3-way Call Conferencing
Method 1
1. Enter the phone number of the 2nd party phone while you are in telephonic conversation with
1st party.
2. Press [Dial/Flash] key. And press [Dial/Flash] key again.
Method 2
1. Press [Dial/Flash] key while you are in telephonic conversation with 1st party.
2. If you listen to the dialing tone, Press the phone number of the 2nd party phone.
3. Press [Dial/Flash] key.
4. And press [Dial/Flash] key again.
This service should be provided by your service provider.
Call Wait
1. Press [Dial/Flash] key, you may start conversation with called number.
2. Re-press [Dial/Flash] key, you may start conversation with previous number.
Volume Control
1. Press [Left]/ [Right] key of navigation while in a call, to adjust speaker volume.
2. Press Option + Left Soft Key to prevent sound from your end during the call. To cancel Mute,
Press again + Left Soft Key.
Memo
Allow you to store number during the call.
To store number :
1. Press Option + 4(New Memo).
2. Enter up to 32 numbers using the keypad.
3. Press OK key to save.
Lock Mode
1. You can use a security code to avoid unauthorized use of the phone.
Press soft Left(Menu) + 4(Setting) + 6(Security) + 2(Phone Lock).
2. The phone is now locked. To unlock, press and enter lock code(Default 0000 ).
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash
END/PWR
Dial/Flash

4
Entering Text
You can enter alphanumeric characters by using the phone's keypad. To change modes, press the
END/PWR
Dial/Flash
key.
T9 Mode
This mode allows you to enter words with only one keystroke per letter. Each key on the keypad
has more than one letter. The T9 mode automatically compares your keystrokes with an internal
linguistic dictionary to determine the correct word, thus requiring far fewer keystrokes than the
traditional ABC mode.
ABC Mode
This mode allows you to enter letters by pressing the key labeled with the required letter once,
twice, three or four times until the letter is displayed.
123 Mode (Numbers Mode)
Type numbers using one keystroke per number.
Symbol Mode
This mode allows you to enter special characters by pressing
END/PWR
Dial/Flash
key.
Quick feature reference
This section provides brief explanations of features on your phone.
Messaging Menu 1
This menu includes functions related to SMS (Short Message Services).
New message You can create functions related to SMS (Short Message Services).
Press soft Left( Menu ) + 1( Messaging ) + 1( New message ) or Message button.
Inbox You will be alerted when you have received a message.
Press soft Left( Menu ) + 1( Messaging ) + 2( Inbox ).

5
Drafts This menu shows the preset message list.
Press soft Left( Menu ) + 1( Messaging ) + 3( Drafts ).
Outbox This menu allows to view the message which is about to be sent or has failed to be
sent.
Press soft Left( Menu ) + 1( Messaging ) + 4( Outbox ).
Sent This menu allows you to view the messages which have already been sent,
including time and content.
Press soft Left( Menu ) + 1( Messaging ) + 5( Sent ).
Listen voice mail This menu provides you with a quick way of accessing your voice mailbox
(if provided by your network).
Press soft Left( Menu ) + 1( Messaging ) + 6( Listen voice mail ).
Info messages Info service messages are text messages delivered by the network to your
handset.
Press soft Left( Menu ) + 1( Messaging ) + 7( Info messages ).
Templates There are pre-defined messages in the list. You can view and edit the template
messages or create new messages.
Press soft Left( Menu ) + 1( Messaging ) + 8( Templates ).
Settings This menu allows you to set features of your network service provider.
Press soft Left( Menu ) + 1( Messaging ) + 9( Settings ).
Contacts Menu 2
Search You can Search for contacts in Phonebook.

6
Note:Instant searching is available by inputting the initial letter of the name you
want to search.
Press soft Left( Menu ) + 2( Contacts ) + 1( Search ) or Contacts button.
New contact You can add phonebook entries by using this menu.
Press soft Left( Menu ) + 2( Contacts ) + 2( New contact ).
Speed dials Assign contacts to any of keys from 2 to 9.
Press soft Left( Menu ) + 2( Contacts ) + 3( Speed dials ).
Copy all You can copy all entries from SIM card memory to Phone memory or from Phone
memory to SIM card memory.
Press soft Left( Menu ) + 2( Contacts ) + 4( Copy all ).
Delete all You can delete all entries from SIM card memory or Phone memory.
Press soft Left( Menu ) + 2( Contacts ) + 5( Delete all ).
Memory status You can check free space and memory usage.
Press soft Left( Menu ) + 2( Contacts ) + 6( Memory status ).
Information ▶Service dial number
Access the list of service numbers assigned by service provider safely.
Press soft Left( Menu ) + 2( Contacts ) + 7( Information ) + 1( Service dial number ).
▶Own numbers
You can save and check your own numbers in SIM card.

7
Press soft Left( Menu ) + 2( Contacts ) + 7( Information ) + 2( Own number ).
▶Business card
This option allows you to create your own business card featuring your name,
mobile phone number and so on.
Press soft Left( Menu ) + 2( Contacts ) + 7( Information ) + 3( Business card ).
Call history Menu 3
You can check the record of missed, received, and dialled calls only if the network supports the
Calling Line Identification (CLI) within the service area. The number and name (if available) are
displayed together with the date and time at which the call was made. You can also view call
durations.
All calls Displays all the lists of three types (Received/Dialled/Missed calls) by time.
Press soft Left( Menu ) + 3( Call history ) + 1( All calls ) or Dial/Flash button.
Missed calls This option lets you view the last 20 unanswered calls.
Press soft Left( Menu ) + 3( Call history ) + 2( Missed calls ).
Dialled calls This option lets you view the last 20 outgoing calls (called or attempted).
Press soft Left( Menu ) + 3( Call history ) + 3( Dialled calls ).
Received calls This option lets you view the last 20 incoming calls.
Press soft Left( Menu ) + 3( Call history ) + 4( Received calls ).
Call duration Allows you to view the duration of your incoming and outgoing calls.
Press soft Left( Menu ) + 3( Call history ) + 5( Call duration ).
Settings Menu 4

8
You can set the following menus for your convenience and preferences.
Sound This menu allows you to set sound such as Ring Type, Ring Tones, Ring Volume,
Message Alert Type, Message Tones, Keypad Tones, Key Volume, Effect Sound
Volume, Power On/Off Volume and Speaker Volume.
Press soft Left( Menu ) + 4( Settings ) + 1( Sound ) or Sound button.
Date & Time This menu allows you to set date and time.
Press soft Left( Menu ) + 4( Settings ) + 2( Date & Time ).
Language This menu allows you to select language between English and Spanish.
Press soft Left( Menu ) + 4( Settings ) + 3( Language ).
Display This menu allows you to set the display such as Backlight Time and Contrast
Network Name On/Off.
Press soft Left( Menu ) + 4( Settings ) + 4( Display ).
Call This menu allows you to set the call such as Call Divert, Send My Number, Call
Waiting, Minute Minder, Send DTMF and Autodial Time out.
Press soft Left( Menu ) + 4( Settings ) + 5( Call ).
Security This menu allows you to set the phone safely.
▶
PIN code request
You can set the phone to ask for the PIN code of your SIM card when the phone is
switched on.
Press soft Left( Menu ) + 4( Setting ) + 6( Security ) + 1( Pin code request ).
▶
Phone lock
You can use a security code to avoid unauthorized use of the phone.

9
Press soft Left( Menu ) + 4( Settings ) + 6( Security ) + 2( Phone lock ).
▶
Call barring
The Call barring service prevents your phone from making or receiving a certain
category of calls. This function requires the call barring password.
Press soft Left( Menu ) + 4( Settings ) + 6( Security ) + 3( Call barring ).
▶
Fixed dial number(SIM dependent)
You can restrict your outgoing calls to selected phone numbers. The numbers
are protected by your PIN2 code. The numbers you wish to allow access
to once this service has been enabled, must be added to the contacts after
enabling Fixed dial number.
Press soft Left( Menu ) + 4( Settings ) + 6( Security ) + 4( Fixed dial number ).
▶
Change codes
PIN is an abbreviation of Personal Identification Number to prevent use by
unauthorized persons. You can change the access codes: Security code, PIN
code, PIN2 code.
Press soft Left( Menu ) + 4( Settings ) + 6( Security ) + 5( Change codes ).
Network selection You can select a network that will be registered either automatically or manually.
Usually, the network selection is set to Automatic.
Press soft Left( Menu ) + 4( Settings ) + 7( Network selection ).
Reset settings You can initialize all setting values as defaults. You need a Security code to
activate this function.
Press soft Left( Menu ) + 4( Settings ) + 8( Reset settings ).
Memory status You can check free space and memory usage of each repository.
Press soft Left( Menu ) + 4( Settings ) + 9( Memory status ).
Alarm Menu 5
Allows you to set one of three alarms. The current time is displayed at the top of the screen when
