Specification
• Asuitableconduitentries,knock-outsorglandsshallbeprovidedinthecableentriesofthis
productintheenduser.
• Caution:Dangerofexplosionifbatteryisincorrectlyreplaced.Replacedonlywiththesameor
equivalenttyperecommendedbythemanufacturer.Disposeofusedbatteriesaccordingto
themanufacturer’sinstructions.
• Holesinmetal,throughwhichinsulatedwirespass,shallhavesmoothwellroundedsurfaces
orshallbeprovidedwithbrushings.
Warning:Donotinstallthisequipmentinaconfinedspacesuchasabookcaseorsimilarunit.
Warning:WiringmethodsshallbeinaccordancewiththeNationalElectricCode,ANSI/NFPA70.
Warning: ThisisaclassAproduct.Inadomesticenvironmentthisproductmaycauseradio
interferenceinwhichcasetheusermayberequiredtotakeadequatemeasures.
Warning:Toreduceariskoffireorelectricshock,donotexposethisproducttorainormoisture.
Warning: Theproducthasbeendroppedorthecaseisbroken,turnoffthepowerandunplugthe
powercord.(Thismaycausefire,electricshock,orinjury.)
Warning:Iftheproducthasnovideooutorsound,pleasestopusing.Unplugthepowercable
immediatelyandcontacttheservicecenter.(Thismaycausefireorelectricshock.)
Caution:Thisinstallationshouldbemadebyaqualifiedservicepersonandshouldconformtoall
localcodes.
Caution:Toavoidelectricalshock,donotopenthecabinet.Referservicingtoqualifiedpersonnel
only.
Caution:Theapparatusshallnotbeexposedtowater(drippingorsplashing)andnoobjectsfilled
withliquids,suchasvases,shallbeplacedontheapparatus.
Caution:Preventthepowercablefrombeingseverelybentorhavingpressureexertedonitbya
heavyobject.
LGElectronicsherebydeclaresthatthis/theseproduct(s)is/arein
compliancewiththeessentialrequirementsandotherrelevant
provisionsofDirective2004/108/ECand2011/65/EU.
Contact office for compliance of this product:
LGElectronicsInc.
EURepresentative,Krijgsman1,1186DMAmstelveen,TheNetherlands
• PleasenotethatthisisNOTaCustomerServicecontactpoint.ForCustomerService
Information,seeWarrantyCardorcontactthedealerthatyoupurchasedthisproduct.
Disposal of your old appliance
1. Thiscrossed-outwheeledbinsymbolindicatesthatwaste
electricalandelectronicproducts(WEEE)shouldbedisposedof
separatelyfromthemunicipalwastestream.
2. Oldelectricalproductscancontainhazardoussubstancesso
correctdisposalofyouroldappliancewillhelppreventpotential
negativeconsequencesfortheenvironmentandhumanhealth.
Youroldappliancemaycontainreusablepartsthatcouldbe
usedtorepairotherproducts,andothervaluablematerialsthat
canberecycledtoconservelimitedresources.
3. Youcantakeyourapplianceeithertotheshopwhereyou
purchasedtheproduct,orcontactyourlocalgovernmentwaste
officefordetailsofyournearestauthorisedWEEEcollection
point.Forthemostuptodateinformationforyourcountry
pleaseseewww.lg.com/global/recycling
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TOREDUCETHERISKOFELECTRICSHOCK
DONOTREMOVECOVER(ORBACK)
NOUSER-SERVICEABLEPARTSINSIDE
REFERSERVICINGTOQUALIFIEDSERVICEPERSONNEL.
Thislightningflashwitharrowheadsymbolwithinanequilateraltriangleis
intendedtoalerttheusertothepresenceofuninsulateddangerousvoltage
withintheproduct’senclosurethatmaybeofsufficientmagnitudeto
constituteariskofelectricshocktopersons.
Theexclamationpointwithinanequilateraltriangleisintendedtoalertthe
usertothepresenceofimportantoperatingandmaintenance(servicing)
instructionsintheliteratureaccompanyingtheproduct.
FCC WARNING: Thisequipmentmaygenerateoruseradiofrequencyenergy.Changesor
modificationstothisequipmentmaycauseharmfulinterferenceunlessthemodificationsare
expresslyapprovedintheinstructionmanual.Theusercouldlosetheauthoritytooperatethis
equipmentifanunauthorizedchangeormodificationismade.
REGULATORY INFORMATION: FCC Part 15
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferencewhentheequipmentisoperatedinacommercialenvironment.
Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalled
andusedinaccordancewiththeinstructionmanual,maycauseharmfulinterferencetoradio
communications.
Operationofthisequipmentinaresidentialareaislikelytocauseharmfulinterferenceinwhich
casetheuserwillberequiredtocorrecttheinterferenceathisownexpense.
MODEL
LCB5300-BN
LCB5300-BP
LCB5300 Series
Please read this manual carefully before operating
your set and retain it for future reference.
OWNER'S MANUAL
Color Video Camera
Item LCB5300-BN LCB5300-BP
Signal System NTSC PAL
Total Pixels number 520 000 Pixels 610 000 Pixels
Effective Pixels number 480 000 Pixels 570 000 Pixels
Image Sensor 6 mm (1/3 Type) Exview HAD II CCD
ISP XDI-V
Lens C / CS Mount
Horizontal
Resolution
Color 650 TV Lines
B / W 700 TV Lines
S/N Ratio 50 dB
Day & Night ICR (AUTO / DAY / NIGHT / EXT)
Sens-up OFF / AUTO(x2, ... x512) /MANUAL(x2, ... x512)
Minimum
Illumination
(F1.2, 30 IRE)
Color 0.03 lx (Sens-up Off), 0.000 3 lx (Sens-up Auto),
0.000 1 lx (Sens-up X512)
B / W 0.002 lx (Sens-up Off ), 0.000 03 lx (Sens-up Auto),
0.000 001 lx (Sens-up X512)
White Balance ATW / AUTO / AWC/SET KEY / MANUAL
Digital Zoom X16
IRIS Control DC
Scanning Frequency (H/V) 15.734 kHz / 59.94 Hz 15.625 kHz / 50 Hz
Sync. System Internal / Line Lock
Item LCB5300-BN LCB5300-BP
Auto Gain Control OFF/ LOW/ MIDDLE/ HIGH
Exposure ALC / ELC
Video Output 1 Vp-p Composite (75 Ω)
Electronic Shutter 1/60 to 1/120 000 1/50 to 1/120 000
Protocol RS-485 : LG, Pelco-D, Pelco-P
Backlight Compensation BLC / HSBLC / OFF
Motion Detection 8 Zones
Privacy Masking 14 Mask Zones
3D-DNR 2D + 3D-DNR
Digital Effect Off / V-Flip / Mirror / Rotate
Control Method RS-485, Coaxial Communication
Power Source DC 12V / AC 24V
Power Consumption 240 mA
Operating Temperature/
Humidity -10 ºC to 50 ºC / 0 % RH to 80 % RH
Storage Temperature/
Humidity -20 ºC to 60 ºC / 0 % RH to 85 % RH
Dimension (W x H x D) 68.6 mm x 54.0 mm x 121.5 mm
Weight 362 g
Power Supply
ThiscameramustalwaysbeoperatedAC24VorDC12V.Certified/ListedAdaptorwhichcomply
withLPS.
Handling of the unit
Becarefulnottospillwaterorotherliquidsontheunit.Becautionsnottogetcombustibleor
metallicmaterialinsidethebody.Ifusedwithforeignmatterinside,thecameraisliabletofailorto
getcauseoffireorelectricshock.
• Removedustordirtonthesurfaceofthelenswithablower.
• Useadrysoftclothtocleanthebody.Ifitisverydirty,useaclothdampenedwithasmall
quantityofneutraldetergentthenwipedry.
• Avoidtheuseofvolatilesolventssuchasthinners,alcohol,benzeneandinsecticides.They
maydamagethesurfacefinishand/orimpairtheoperationofthecamera.
Operating and storage location
Avoidviewingaverybrightobject(suchaslightfittings)duringanextendedperiod.Avoid
operatingorstoringtheunitinthefollowinglocations.
• Extremelyhotorcoldplaces(operatingtemperature-10°Cto50°C,however,we
recommendthattheunitbeusedwithinatemperaturerangeof0°Cto45°C)
• Dampordustplace
• Placesexposedtorain
• Placessubjecttostrongvibration
• ClosetogeneratorsofpowerfulelectromagneticradiationsuchasradioorTV
transmitters.
Important Safety Instructions
1. Readtheseinstructions.
2. Keeptheseinstructions.
3. Heedallwarnings.
4. Followallinstructions.
5. Donotusethisapparatusnearwater.
6. Cleanonlywithdrycloth.
7. Donotblockanyventilationopenings.Installinaccordancewiththemanufacturer’s
instructions.
8. Donotinstallnearanyheatsourcessuchasradiators,heatregisters,stoves,orotherapparatus
(includingamplifiers)thatproduceheat.
9. Donotdefeatthesafetypurposeofthepolarizedorgrounding-typeplug.Apolarizedplug
hastwobladeswithonewiderthantheother.Agroundingtypeplughastwobladesand
athirdgroundingprong.Thewidebladeorthethirdprongareprovidedforyoursafety.If
theprovidedplugdoesnotfitintoyouroutlet,consultanelectricianforreplacementofthe
obsoleteoutlet.
10. Protectthepowercordfrombeingwalkedonorpinchedparticularlyatplugs,convenience
receptacles,andthepointwheretheyexitfromtheapparatus.
11. Onlyuseattachments/accessoriesspecifiedbythemanufacturer.
12. Useonlywiththecart,stand,tripod,bracket,ortablespecifiedbythemanufacturer,or
soldwiththeapparatus.Whenacartisused,usecautionwhenmovingthecart/apparatus
combinationtoavoidinjuryfromtip-over.
13. Unplugthisapparatusduringlightningstormsorwhenunusedforlongperiodsoftime.
14. Referallservicingtoqualifiedservicepersonnel.Servicingisrequiredwhentheapparatushas
beendamagedinanyway,suchaspower-supplycordorplugisdamaged,liquidhasbeen
spilledorobjectshavefallenintotheapparatus,theapparatushasbeenexposedtorainor
moisture,doesnotoperatenormally,orhasbeendropped.
*MFL69441502*

1. Installthecameraandmountingbracketsecurely.
TRX -
TRX +
TRX -
TRX +
<ITALIANO> Montarelavideocameraallastaffainmanierasicura.
<ESPAÑOL> Montelacámarayelsoporte.
<PORTUGUÊS> Instaleacâmeraeosuportedemontagemfirmemente.
<PYCCKNЙ> Надежноустановитькамеруимонтажныйкронштейн.
<TÜRKÇE> Kameravekamerabağlantıparçasınısağlambirşekildemonteedin.
2. InstalltheCorCSmounttypelens.
C mount type
CS mount type
Note:
Turnoffthecameraessentiallybeforethelensconnectionorreplacement.
<ITALIANO> InstallareunobiettivoditipoCoCS.
<ESPAÑOL> InstaleunobjetivoCoCS.
<PORTUGUÊS> InstaleaslentesdemontagemdotipoCouCS.
<PYCCKNЙ> УстановитьоправыобъективатипаCилиCS.
<TÜRKÇE> CveCStipilenstakın.
3. Installthecameraandmountingarm.
TRX -
TRX +
TRX -
TRX +
<ITALIANO> Montarelavideocameraalbraccio.
<ESPAÑOL> Montelacámarayelbrazodesoporte.
<PORTUGUÊS> Instaleacâmeraeobraçodemontagem.
<PYCCKNЙ> Установитькамеруимонтажныйкронштейн.
<TÜRKÇE> Kameravekamerabağlantıparçasıkolunumonteedin.
4. Loosentheflange-backfixinglever.Upanddowntheflange-backadjusting
levertoobtainafocusedpoint.
<To loosen the lever.> <To adjust the focus.>
TRX-
TRX+
TRX-
TRX+
TRX-
TRX+
TRX-
TRX+
<ITALIANO>
Allentarelalevaperilfissaggiodellaflangiaposteriore.Sollevaree
abbassarelalevadiregolazionedellaflangiaposterioreperottenere
unpuntodimessaafuoco.
<ESPAÑOL> Aflojelapalancadefijación.Subaobajelapalancadeajustepara
obtenerunpuntodeenfoque
<PORTUGUÊS> Afrouxeoniveladordefixaçãodaflangetraseira.Suspendaeabaixe
oniveladordefixaçãodaflangetraseiraparaobteropontodofoco.
<PYCCKNЙ>
Ослабитькрепежныевинтызаднегофланца.Использовать
регулирующеекольцозаднегофланцадлядостиженияточки
фокуса.
<TÜRKÇE> Flanşarkakolututanvidalarıgevşetin.Flanşarkaayarhalkasını
kullanarakodaknoktasınıbelirleyin.
1. Connectthedisplaydeviceandexternaldevice.
External D&N
Switch
Alarm (Relay)
Device
Night Mode
S/W Close
Day Mode
S/W Open
RS-485 Unit
<ITALIANO> Collegareildispositivodeldisplay.Collegareildispositivoesterno.
<ESPAÑOL> Conecteeldispositivodevisualización.Conecteelaparatoexterno.
<PORTUGUÊS> Ligueovisor.Ligueodispositivoexterno.
<PYCCKNЙ> Подключитеустройствоотображения.
Подключениевнешнегоустройства.
<TÜRKÇE> Görüntülemeaygıtınıbağlayın.Hariciaygıtıbağlayın.
2. Connectthepowersource.
2mm
<ITALIANO> Collegarel’alimentazioneelettrica.
<ESPAÑOL> Conectelafuentedeenergía.
<PORTUGUÊS> Conecteafontedealimentação.
<PYCCKNЙ> Подключитеисточникпитания.
<TÜRKÇE> Güçkaynağınıbağlayın.
Connections
Installation
RS-485 Protocol
DataCommunicationFormat
• DataLength:1Byte(8Bit)
• Start/StopBit:1Bit
• ParityBit:None
• Baudrate:9600bps
Format
BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6
0xE5 0x86 CameraID CODE1 CODE2 *C.S.
*C.S.=CheckSum
• Thedataoftotal6bytesistransmittedfromtheexternalRS-485devicetothe
camera.
• BYTE6:ThevalueofCheckSumfrom‘BYTE1’to‘BYTE5’.
ex)Incaseoftransmission,0xC5,0x5F,0x02,0x00,0x0A”
C.S.=0xC5+0x5F+0x02+0x00+0x0A=0x0130
therefore,C.S.=0x30
Commands
Function Command
OSD Menu ON/OFF E5, 86, ID, 41, 02, C.S.
LEFT Button E5, 86, ID, 12, 80, C.S.
Right Button E5, 86, ID, 12, 90, C.S.
Up Button E5, 86, ID, 11, 80, C.S.
Down Button E5, 86, ID, 11, 90, C.S.
Menu Button E5, 86, ID, 41, 01, C.S.
Lens iris output connector
Pinlayoutforthelensirisoutputconnector.
No. DCtypelenses
1 Damping-
2 Damping+
3Drive+
4 Drive-
Rewire the lens iris plug
1. Cutofftheplugofthelenscable,cutoffapproximately8mmoftheinsulation,
andthenstripapproximately2mmoftheendsofthecablesheaths.
8mm
2mm
2. Soldertheendsofthecablewirestotheendsofthepins,andthenattachthe
coverofthelensirisplug.
Additional Information
