LG DLEY1701V User manual

DLEY1701V
LAUNDRY
ELECTRIC DRYERS
Graphite Steel
Technology Benefits
•LoDecibel Quiet Operation
™
DLEY1701V
Ultra Large Capacity Steam Dryer
with Front Control Design
Style and Design
•Front Electronic Control Panel with LED Display
•Touch Buttons
•Chrome Edged Diamond Glass Door
•Reversible Door
Intelligent Fabric Care
•Custom Program
•Wrinkle Free Cycle
•Wrinkle Care Option
•12 Drying Programs
•3 Minute Installation Check
•5 Temperature Settings
•SmartDiagnosis™
•Precise Temperature Control
with Variable Heat Souce
•FlowSense Duct Clogging Indicator
™
•Anti-Bacterial Cycle
•Damp Dry Signal
•Rack Dry Option
•SteamFresh Cycle
™
•Steam Technology
•Sensor Dry System for Intelligent Fabric Care
and Energy Efficiency
Performance
•7.3 cu.ft. Ultra Large Capacity with
NeveRust Stainless Steel Drum
™

DLEY1701V
TYPE
Front Loader
Front ControlDesign Look
Front Electronic Control Panel with LED Display
Touch Buttons
7.3 cu.ft.Capacity
>10.2 kgDry Linen Capacity
DRYING PROGRAMS
12 Programs Sensor Dry: Cotton/Normal, Perm. Press/Casual,
Heavy Duty, Small Load, Bulky/Bedding, Anti-Bacterial,
Towels, Delicates, SteamFresh™, Wrinkle Free
Manual Dry: Speed Dry, Air Dry
The Refreshing Power of Steam
There’s no clean like a steam clean. Our Steam Technology
gently but powerfully penetrates fabrics to virtually eliminate
dirt, odours and wrinkles.
Front Control Design
LG puts a modern spin on the traditional top load design.
By moving the control panel from the back to the front,
the buttons and LED display are easier to read and use.
This simple change makes for a more intuitive and functional
design and a look that is unlike anything you’ve ever seen.
Call, Connect, Resolve
SmartDiagnosis™ uses self-diagnosing technology that
can communicate 24/7 with LG customer service over the
telephone providing you with comfort and reliability.
Keep it Quiet
There’s no need for laundry to be noisy. Thanks to LG's
LoDecibel™ Operation, chances are you’ll never even
notice it.
Dry Big Loads
Do laundry a little less often. With 7.3 cu.ft. Ultra Large
Capacity, this dryer handles really large loads, saving you
time and energy.
8 Options More Time, Less Time, Wrinkle Care,
Custom Program, Child Lock, Damp Dry Signal,
End of Cycle Signal, Rack Dry
5 Temperature Settings High, Medium High,
Medium, Low, Ultra Low
5 Drying Levels Very Dry, More Dry, Normal Dry,
Less Dry, Damp Dry
60 min., 50 min., 40 min., 30 min.,
20 min., More Time/Less Time
Dry Times
FABRIC CARE FEATURES
SteamFresh™ Cycle
Wrinkle Free Cycle
Precise Temperature Control and Variable Heater
Sensor Dry
Child Lock
Drum Light
CONVENIENCE FEATURES
Wrinkle Care Option
Remaining Time Display/Status Indicator(s)
End of Cycle Signal
Anti-Bacterial Cycle
FlowSense™ Duct Clogging Indicator
SmartDiagnosis™
Leveling Legs 4 Adjustable Legs
Venting Option
3 Minute Installation Check
LoDecibel™ Quiet Operation
4 Way Venting
Reversible Door
MATERIALS AND FINISHES
NeveRust™ Stainless Steel Drum
Painted SteelCabinet
PlasticControl Panel
PlasticTop Cover
Diamond Glass Door
Door Rim Chrome
Dark Gray Tint
Graphite Steel (V)Available Colours
POWER SOURCE
Ratings UL Listed
Electrical Requirements 240V, 30 Amps
Type Electric
DIMENSIONS
Product (WxHxD) 27" x 40 5/32" x 28 3/8"
(50 1/4" D with door open)
29 1/2" x 43 7/10" x 31 1/4"Carton (WxHxD)
133.7 lbs./152.2 lbs.Weight (Product/Carton)
UPC CODES
DLEY1701V 772454 061646
WARRANTY
Design, features and specifications are subject to change without notice.
Non-metric weights and measurements are approximate.
All trademarks are property of their respective owners.
1 year parts and labour
20 Norelco Drive, North York, Ontario, M9L 2X6
Customer Service & Parts
Tel: [phone] LG.com
1-888-542-2623
LG ELECTRONICS CANADA INC.
ELECTRIC DRYERS
Accurate Drying
LG’s Sensor Dry System measures the moisture levels
during the cycle and automatically adjusts the drying time,
assuring you get dry laundry every time.
Printed in January 2014
