1
DVD PLAYER
OWNER’S MANUAL
MODEL : DVD5183
Before connecting, operating or adjusting this product,
please read this instruction booklet carefully and completely.
DV6812E3 HA4ULL_ENG
FOR THE GUARANTEE TERMS & CONDITIONS,
PLEASE REFER TO BACK COVER OF THIS MANUAL.

2
Safety Precautions
This lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to
the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation mark within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.
CAUTION:
This Digital Video Disc Player employs a Laser System.
To ensure proper use of this product, please read this owner’s
manual carefully and retain for future reference, should the unit
require maintenance, contact an authorized service location-
see service procedure.
Use of controls, adjustments or the performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
To prevent direct exposure to laser beam, do not try to open
the enclosure. Visible laser radiation when open. DO NOT
STARE INTO BEAM.
CAUTION: The apparatus shall not be exposed to water (drip-
ping or splashing) and that no objects filled with liquids, such
as vases, shall be placed on the apparatus.
This product is manufactured to comply with
the radio interference requirements of EEC
DIRECTIVE 89/336/EEC, 93/68/EEC and
73/23/EEC.
Notes on copyrights:
It is forbidden by law to copy, broadcast, show, broadcast
via cable, play in public, or rent copyright material without
permission.
This product features the copy protection function developed by
Macrovision. Copy protection signals are recorded on some
discs. When recording and playing the pictures of these discs
on a VCR, the picture noise will appear.
This product incorporates copyright protection technology that
is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright protection tech-
nology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
SERIAL NUMBER: The serial number is found on the back of
this unit. This number is unique to this unit and not available to
others. You should record requested information here and
retain this guide as a permanent record of your purchase.
Model No. ___________________________________
Serial No. ___________________________________
WARNING: TO REDUCE THE RISK OF FIRE OR ELEC-
TRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK
OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
CLASSE 1 PRODUIT LASER
POWER: This DVD player operates on a mains supply of 110-
240V~, 50/60Hz.
WIRING: This DVD player is supplied with a BSI 1363
approved 13 amp mains plug, fused at 5 amp. When replac-
ing the fuse always use a 5 amp BS 1362, BSI or ASTA
approved type. Never use this plug with the fuse cover omit-
ted. To obtain a replacement fuse cover contact your dealer or
“LG Electronics U.K.Ltd.”If the type of plug supplied is not
suitable for the mains sockets in your home, then the plug
should be removed and a suitable type fitted. Please refer to
the wiring instructions below:
WARNING: A mains plug removed from the mains lead of this
DVD player must be destroyed. A mains plug with bared wires
is hazardous if inserted in a mains socket.
Do not connect either wire to the earth pin, marked with the
letter E or with the earth symbol or coloured green or
green and yellow.
If any other plug is fitted, use a 5 amp fuse, either in the plug,
or at the distribution board.
IMPORTANT: The wires in this mains lead are coloured in
accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the
wires in the mains lead of this DVD player may not
correspond with the coloured marking identifying the termi-
nals in your plug, proceed as follows: The wire which is
coloured blue must be connected to the terminal which is
marked with the letter N or coloured black. The wire which is
coloured brown must be connected to the terminal which is
marked with the letter L or coloured red.

3
INTRODUCTION
Table of Contents
Introduction
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . 2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . 5
About Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Front Panel and Display Window . . . . . . . . . . . . . . 6
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Preparation
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Connecting to a TV . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting to Optional Equipment . . . . . . . . . . . 10
Before Operation . . . . . . . . . . . . . . . . . . . . . . . 11-14
General Explanation. . . . . . . . . . . . . . . . . . . . . . 11
On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . 11
Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . 12-14
 Using your DVD player very first time . . . . . . 12
 Initial Settings General Operation. . . . . . . . . 12
 Language . . . . . . . . . . . . . . . . . . . . . . . . . . 12
 Picture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
 Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
 Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
 Parental Control. . . . . . . . . . . . . . . . . . . . . . 14
Operation
Operation with DVD . . . . . . . . . . . . . . . . . . . . . 15-17
Playing a DVD . . . . . . . . . . . . . . . . . . . . . . . . . . 15
General Features . . . . . . . . . . . . . . . . . . . . . . . . 15
 Moving to another TITLE . . . . . . . . . . . . . . . 15
 Moving to another CHAPTER . . . . . . . . . . . 15
 Slow Motion. . . . . . . . . . . . . . . . . . . . . . . . . 15
 Still Picture and Frame-by-Frame Playback . 16
 Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
 Random . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
 Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
 Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . 16
 Time Search . . . . . . . . . . . . . . . . . . . . . . . . 16
 Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
 D Surround . . . . . . . . . . . . . . . . . . . . . . . . 17
 Marker Search . . . . . . . . . . . . . . . . . . . . . . . 17
Special DVD Features . . . . . . . . . . . . . . . . . . . . 17
 Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 17
 Disc Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 17
 Camera Angle . . . . . . . . . . . . . . . . . . . . . . . 17
 Changing the Audio Language . . . . . . . . . . . 17
 Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Operation with Audio CD and MP3 Disc. . . . . . . . 18
Playing an Audio CD and MP3 Disc . . . . . . . . . . 18
 Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
 Moving to another Track . . . . . . . . . . . . . . . . 18
 Repeat Track/All/Off . . . . . . . . . . . . . . . . . . . 18
 Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
 Random . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
 Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . 18
 D Surround . . . . . . . . . . . . . . . . . . . . . . . . 18
 Changing the Audio Channel . . . . . . . . . . . . 18
Programmed Playback . . . . . . . . . . . . . . . . . . . . . 19
Programmed Playback with Audio CD
and MP3 Disc . . . . . . . . . . . . . . . . . . . . . . . . . . 19
 Repeat Programmed Tracks . . . . . . . . . . . . . 19
 Erasing a Track from Program List . . . . . . . . 19
 Erasing the Complete Program List . . . . . . . 19
Additional Information . . . . . . . . . . . . . . . . . . . 20-21
Last Condition Memory . . . . . . . . . . . . . . . . . . . 20
Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Video Mode Setting . . . . . . . . . . . . . . . . . . . . . . 20
Controlling the TV . . . . . . . . . . . . . . . . . . . . . . . 20
Notes on MP3 Discs . . . . . . . . . . . . . . . . . . . . . 21
Reference
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Language Code List . . . . . . . . . . . . . . . . . . . . . . . 23
Country Code List . . . . . . . . . . . . . . . . . . . . . . . . . 24
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
About the symbols for instructions
Indicates hazards likely to cause harm to the unit
itself or other material damage.
Indicates special operating features of this unit.
Indicates tips and hints for making the task easier.

4
Before Use
Playable Discs
DVD
(8 cm / 12 cm disc)
Audio CD
(8 cm / 12 cm disc)
In addition, this unit can play a CD-R or CD-RW that
contains audio titles or MP3 files.
Notes
–Depending on the conditions of the recording equip-
ment or the CD-R/RW disc itself, some CD-R/RW
discs cannot be played on the unit.
–The unit cannot play the CD-R/RW discs that contain
no data, or contain different kinds of formatted data
other than MP3 and CD-DA data.
–Do not attach any seal or label to either side (the
labeled side or the recorded side) of a disc.
–Do not use irregular shaped CDs (e.g., heart-shaped
or octagonal). It may result in malfunctions.
Notes on DVDs
Some playback operations of DVDs may be intentionally
fixed by software manufacturers. As this unit plays DVDs
according to disc content designed by the software
manufacturer, some playback features of the unit may
not be available, or other functions may be added.
Refer also to the instructions supplied with the DVDs.
Some DVDs made for business purposes may not be
played on the unit.
Regional code of the DVD player and DVDs
This DVD player is designed and manufactured
for playback of region “2”encoded DVD software.
The region code on the labels of some DVD discs indi-
cates which type of player can play those discs. This unit
can play only DVD discs labeled “2”or “ALL”. If you try to
play any other discs, the message “Check Regional
Code”will appear on the TV screen. Some DVD discs
may not have a region code label even though their play-
back is prohibited by area limits.
Note on DTS-encoded CDs
To avoid possible damage to the audio system, turn
down the volume before playing back such discs, adjust
the volume gradually, and keep the volume level low. To
enjoy DTS Digital SurroundTM playback, an external 5.1
channel DTS Digital SurroundTM decoder system must
be connected to the digital output of the unit.
Disc-related terms
Title (DVD only)
The main film content or accompanying feature content
or additional feature content, or music album.
Each title is assigned a title reference number enabling
you to locate it easily.
Chapter (DVD only)
Sections of a picture or a musical piece that are smaller
than titles.
A title is composed of one or several chapters. Each
chapter is assigned a chapter number, enable you to
locate the chapter you want. Depending on the disc, no
chapters may be recorded.
Track (Audio CD only)
Sections of a picture or a musical piece on an audio
CD. Each track is assigned a track number, enabling
you to locate the track you want.
2

5
INTRODUCTION
Before Use (Cont’d)
Precautions
Handling the unit
When shipping the unit
The original shipping carton and packing materials
come in handy. For maximum protection, re-pack the
unit as it was originally packed at the factory.
When setting the unit
The picture and sound of a nearby TV, VCR, or radio
may be distorted during playback. In this case, position
the unit away from the TV, VCR, or radio, or turn off the
unit after removing the disc.
To keep the surface clean
Do not use volatile liquids, such as insecticide spray,
near the unit. Do not leave rubber of plastic products in
contact with the unit for a long period of time. They will
leave marks on the surface.
Cleaning the unit
To clean the cabinet
Use a soft, dry cloth. If the surfaces are extremely dirty,
use a soft cloth lightly moistened with a mild detergent
solution. Do not use strong solvents, such as alcohol,
benzine, or thinner, as these might damage the surface
of the unit.
To obtain a clear picture
The DVD player is a high-tech, precision device. If the
optical pick-up lens and disc drive parts are dirty or
worn down, the picture quality will be poor.
Regular inspection and maintenance are recommended
after every 1,000 hours of use. (This depends on the
operating environment.)
For details, please contact your nearest dealer.
Notes on Discs
Handling discs
Do not touch the playback side of the disc.
Hold the disc by the edges so that fingerprints will not
get on the surface.
Do not stick paper or tape on the disc.
Storing discs
After playing, store the disc in its case.
Do not expose the disc to direct sunlight or sources of
heat, or leave it in a parked car exposed to direct sun-
light, as there may be a considerable temperature
increase inside the car.
Cleaning discs
Fingerprints and dust on the disc can cause poor pic-
ture quality and sound distortion. Before playing, clean
the disc with a clean cloth. Wipe the disc from the cen-
ter out.
Do not use strong solvents such as alcohol, benzine,
thinner, commercially available cleaners, or anti-static
spray intended for older vinyl.
About Symbols
About the symbol display
“”may appear on the TV screen during operation.
This icon means the function explained in this owner’s
manual is not available on that specific DVD video disc.
About the disc symbols for instructions
A section whose title has one of the following symbol is
applicable only to the disc represented by the symbol.
DVD
Audio CDs.
MP3 disc.
MP3
CD
DVD
